Xoro HSD 7510 User manual

3
English
CONTENT
Safety Informations 4
Features 9
Accessories 10
Output and control elements 11
Remote control 14
The rechargeble battery 17
Connecting the Player to other componets 19
Basic operations 20
System setup 32
Specifications 37
Troubleshooting 38
Glossary 39

4
English
SAFETY INFORMATION
The lightning flash with an arrowhead symbol within an equilateral triangle is
intended to alert the user of the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended toalert the
user of the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the ap-
pliance.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERA-
TION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)THIS
DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED. INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
WARNING: DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DUE TO THE
HIGH RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OPEN THE CABINET DANGE-
ROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. ONLY QUALIFIED
SERVICE PERSONNEL SHOULD ATTEMPT THIS. CAUTION: DURING PLAYBACK, THE
DISC SPINS AT HIGH SPEED, SO DO NOT LIFT OR MOVE THE PLAYER, DOING SO
MAY DAMAGE THE DISC.
CAUTION:This Digital Video Disc Player employs a Laser System. Make sure the device is
shut down prior to opening player lid.Visible laser radiation when open and interlocks defea-
ted.Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
The lightning flash with an arrowhead symbol within an equilateral triangle is intended to
alert the user of the presence of uninsulated "dangerous voltage" within the product's enclo-
sure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The
exclamation point within an equilateral triangle is intended to alert the user of the presence
of important operating and maintenance (servicing) instructions in the literature accompany-
ing the appliance.
DO NOT STARE INTOBEAM.
To ensure proper use of this product, please read this owner's manual carefully and retain
for future reference. Should the unit require maintenance, contact an authorized service
location, or contact us.Only qualified service personnel should remove the cover.

5
English
FCC NOTICE: This equipment has been tested and found to comply with the limits for a
Class B digital device. Pursuant with the FCC Rules, Part 15. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates,uses and can radiate radio frequency energy and,if not installed
and used in accordance with the instructions, may cause harmful interference to radio com-
munication, However,this is no guarantee that interference will not occur in a particular in-
stallation.If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,the user is encouraged to try
to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:To assure continued compliance,(example-use only shielded interface cables
when connecting to computer or peripheral devices).Any changes or modifications not ex-
pressly approved by the party responsible for compliance could void the user's authority to
operate this equipment.
BATTERYWARNING:
The DVD player contains a NiMH battery pack. There is a risk of fire and burns if the battery
pack is handled improperly. Do not disassemble, crush, puncture, short external contacts, or
dispose of in fire or water. Do not attempt to open or service the battery pack. Replace only
with the battery pack designated for this product. Discard used batteries according to the
manufacturer's instructions.
CAUTION: Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Please carefully study this manual and always keep it available. There are, however, some
installation and operation precautions which you should be aware of.
1. Read Instructions - All the safety and operating instructions should be read before
the product is operated.
2. Retain Instructions - The safety and operating instructions should be retained for
future reference.
3. Heed Warnings - All warnings on the product and in the operating instructions should
be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product m a -
nufacturer as they may cause hazards.
SAFETY INFORMATION

6
English
7. Water and Moisture - Do not use this product near water for example, near a bath
tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming
pool; and the like.
8. Accessories - Do not place this product on an unstable cart, stand, tripod, bra-
cket, or table. The product may fall, causing serious injury to a child or adult, and seri-
ous damage to the product. Use only with a cart, stand, tripod, bracket, or table recommen-
ded by the manufacturer, or sold with the product. Any mounting of the product should
follow the manufacturer's instructions, and should use a mounting accessory recom-
mended by the manufacturer.
9. A product and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the product and cart combination to overturn.
10. Ventilation - Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from overheating, and these
openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should
not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer's instructions have been adhered to.
11. Power Sources - This product should be operated only from the type of power sour-
ce indicated on the marking label. If you are not sure of the type of power supply to
your home, consult your product dealer or local power company. For products inten-
ded to operate from battery power, or other sources, refer to the operating instructi-
ons.
12. Grounding or Polarization - This product may be equipped with a polarized alterna-
ting-current line plug (a plug having one blade wider than the other). This plug will fit
into the power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to
fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug. Alternate Warnings - This product is equipped with a
three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will
only fit into a grounding-type power outlet. This is a safety feature, If you are unable
to insert the plug into the outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the grounding-type plug.
13. Power-Cord Protection - Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying parti-
cular attention to cords at plugs, convenience receptacles, and the point where they
exit from the product.
14. Protective Attachment Plug - The product is equipped with an attachment plug ha-
ving overload protection. This is a safety feature. See Instruction Manual for replace-
ment or resetting of protective device. If replacement of the plug is required, be sure
the service technician has used a replacement plug specified by the manufacturer
that has the same overload protection as the original plug.
SAFETY INFORMATION

7
English
15. Outdoor Antenna Grounding - If an outside antenna or cable system is connected to
the product, be sure the antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static charges. Article 810 of the Nati-
onal Electrical Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size or grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the groundin
telectrode.
16. Lightning - For added protection for this product during a lightning storm, or when it
is left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system. This will prevent damage to the pr o -
duct due to lightning and power-line surges.
17. Power Lines - An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as contact
with them might be fatal.
18. Overloading - Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
19. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock.Never spill liquid of any kind on the product.
20. Servicing - Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
21. amage Requiring Service - Unplug this product from the wall outlet and refer servi-
cing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Ad-
just only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance this indicates a need for
service.
22. Replacement Parts - When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the
same characteristics as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
SAFETY INFORMATION

8
English
23. Safety Check - Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in pro-
per operating condition.
24. Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
25. Heat - The product should be situated away from heat sources such as radiators,
heat registers, stoves or other products (including amplifiers) that produce heat.
26. Rechargeable battery - Charge voltage cannot be below 12V.
SAFETY INFORMATION

9
English
FEATURES
• Portable DVD-Player and DVB-T TV (integrated)
• 9,2 inch 16:9 TFT display (resolution 800 x 480)
• Play DVD, VCD, SVCD, MPEG-1 and MPEG-2 Video, MPEG-4
• Video, AUDIO-CD, JPEG, Kodak Picture CD
• Integrated card reader for SD, MMC and MS memories
• USB 1.1 port for external storage
• DVB-T receiver with automatic channel scan, EPG and Teletext
• Removable Li-Ion battery
• Video In and Out
• Can be used as a digital picture frame (power supply use recommended

10
English
ACCESSORIES
Package Contents
When opening the package of this Portable-DVD player please make sure that the
following accessories are included:
AC-DC power adapter
Remote control ink. batte-
ries
User manual
Warranty card
Car power supply cable
Battary Pack
Antenna
headphones
transportation bag

11
English
Front panel
1. LCD Display
2. Speaker
3. Control keys
4. IR receiver window
5. Power LED Indicator
• Red: When CD / MP3/ DVD discs are
played
• Blinking green: when the player turns
off and the battery is charging
• Off: The main unit is turned off
Back panel
1. VOL+ / VOL– : Press to increase /
reduce the volume or a value in the
menu.
2. MENU: Press to display the TFT´s
menu.
3. AV: Press to switch the video input
mode between DVD / DVB-T and
AUX
4. Tuner Port: Connect antenna to this
player
5. Disc Cover
6. Fixing holes
7. Screw hole
8. Battery Connector
OUTPUTS AND CONTROL ELEMENTS

12
English
OUTPUTS AND CONTROL ELEMENTS
Control keys
1. DVD / DVB-T : Press to select DVD or DVB-T mode.
2. /  (UP / DOWN) : Press to move the cursor up / down.
3. SETUP: Press to access the DVD Setup Menu to modify the DVD player settings
when the player is in DVD mode; Press to access the DVB-T Setup Menu to modify
the DVB-T settings when the player is in DVB-T mode.
4. STOP: Press this button to stop playback. Press this button for 1.5 second to turn
off the unit.
5. (PREVIOUS) : Press to go to the previous track or chapter.
6. (PLAY / ENTER) Press to begin playback; Press to pause Playback during
playing, press again to resume playback. Press to confirm the items or settings
7. (NEXT) : press to go to the next track to chapter.
Left side of the player
1. DC 12V IN: Connecting the AC-DC
adapter or car adapter to DC IN jack.
2. Memory Socket: Inserting the
memory card ( SD / MMC / MS) to
the memory socket of player
3. Headphone Jack : Plugging the
headphone in the HP1 or HP2 jack
of player
4. USB Socket: Connecting USB
storage to the player.
5. AV Out: This is used in combination
with the audio / video input devices
6. AV In : This is used in combination
with the audio/ video output devices
7. Coaxial: This is uased in combinati-
on with the digital audio input devi-
ces

13
English
OUTPUTS AND CONTROL ELEMENTS
Right side of the player
1. Power Switch: Slide power
switch to position „ON“, then
the player turns on. Slide
power switch to position
„OFF“, then the player turns
off.
Part names of the battery
1. Battery support: Pull out the support to the proper position in order to let the unit
stand when battery is installed.
2. Fixing pole
3. Battery socket
4. Screw
5. Handle

14
English
REMOTE CONTROL
1. Open the battery drawer
Hold in addition the equipment by point 1 (see picture) and push the cover into the
direction 2 (see picture).
2. Please insert the battery into the drawer.
3. Push the drawer back into the remote control
Pay attention when inserting the battery to the correct polarity (/-).
Always direct the remote control toward the sensor field of the DVD Players
Introduction of the remote control
Operation of the DVD Players with the remote control

15
English
REMOTE CONTROL
1. DVD / DVB-T : Select DVD / DVB-T mode
2. SETUP: Access the OSD setup menu
3. MUTE: Turn the sound on or off
4. TV / RADIO: Select TV / Radio mode
5. RECALL: return to the disc´s root menu
6.  : Move the cursor up
7. MENU PBC: Display the root menu of disc
8. OSD: Display the information of disc ( title, chapter, track, time,etc..)
9.  : Move the cursor left
10. ENTER: Confirm the items or settings
11. : Move the cursor right
12. VOL+: Increase the volume
13. BACKWARD: Press to fast backward playback
Button discription of remote control

16
English
REMOTE CONTROL
Button discription of remote control
14. : Move the cursor down
15. FORWARD: Press to fast forward playback
16. VOL- : Decrease the volume
17. PREV: Go to the previous track or chapter
18. PLAY / PAUSE : Press to play or pause the CD or DVD
19. NEXT : Go to the next track or chapter
20. STOP : Press to stop playback
21. 23,25-27,29-31,33 : Select track numbers directly
24. AUDIO ST : DVD: select the audio language
VCD or CD : Select the audio channel
28. TITLE : Display the DVD title
32. SUBTITLE : select and turn on subtitle
34. PROGRAM : Program the palyback sequnce
35. GOTO : Start playback at a selected track, chapter or time
36. D ANGLE ( DVD only) : Press to select the disc's angle
37. REPEAT : Repeat the track, chapter or the enter disc
38. SLOW : Press to reduce the speed of playback
39. P POWER : Turn the screen on or off
40. AV : Press to switch the video input mode between DVD/ DVB-T and AUX
41. -: Press to decrease the value of selected items when in the TFT´s setup menu
42. P MENU : Press P MENU continuously to select the Brightness, Contrast, Colours,
Sharpness, Screen mode, Screen on/off.
43. + : Press to increase the value of selected items when in the TFT´s setup menu
44. P ANGLE : Switch screen normal or reverse

17
English
THE RECHARGEABLE BATTERY
• Please fully charge the battery unit before using it for the first time.
• When the battery unit is recharged in a hot environment, it may not become fully
recharged.
• It´ s normal that the battery unit temperature is about 20°C higher than the
surrounding temperature during a recharge.
• Please store the battery in a proper temperature environment (15°C to 25°C). To
avoid damage do not store the battery in environments with higher or lower
temperatures.
• Please recharge the battery once per year if it is not used for a long time.
• The battery unit can be used for about 300 cycles of recharging and operation.
However, this depends on the specific operating conditions.
• The picture may be unstable if the battery power is too low
• Please recharge the battery when the main unit is powered off. Otherwise the battery
recharge will takes about 5 to 6 hours.
• The moment the battery power is depleted, OSD shows „WARNING LOW
BATTERY“
• Please remove the battery unit from the main unit when it is not going to be used for
a long period of time
Precautions
Battery storage
Battery life
Using the battery

18
English
THE RECHARGEABLE BATTERY
Installing the battery
Please install the battery unit as following:
1. Attach the battery unit to the main unit
2. Pull up the battery until the battery unit is locked to
the main unit
3. Then the power LED indicator is light on .
Removing the battery
Please remove the battery unit as following:
1. Turn off the main unit
2. Press the battery lock key and pulldown the battery unit,
then the battery is removed
Note:
• Before installing and removing the battery, it is required
Recharging the battery by using AC-DC adapter
Please recharge the battery unit as explained in the following:
1. Install the battery
2. Connect AC-DC adapter to the player
• When charging, the charge LED indicator lights up.
( Red)
• When the battery is full, the LED indictor is green
• The charing time is around 5 to 6 hours (player is
powerd off)
Note:
• Please place the battery on a level, flat surface for
recharging
• Failure to do so many cause the battery short circuit
• The temperature during recharging affects the recharging efficiency.
• Recharging is most efficient between temperatures from 0°C to 45°C.
• To protect the battery unit, do not recharge a fully charged battery unit repeatedly.
Repeated overcharging of the battery may deteriorate the battery performance.
• When the battery unit is hot, it may take longer to recharge or it may be not be
possible to recharge altogether. Wait for the battery unit to cool down before you try
again to recharge
Caution

19
English
CONNECTING THE PLAYER TO OTHER
COMPONENTS
Using the AC-DC adapter
Connect the power cord to the DC IN jack as shown
in the illustration.
Note:
• AC-DC adapter specifiction : 12V/1.5A.
Please use the adapter that is the standartd
accessory of the main unit.
Using the earphone
• Connect the earphone plug secrely to the
earphone jack on the main unit
• Using +/- to adjust the volume
Note :
• Please do not play DTS disc. It will produ-
ce some strong noises.
• Insert the earphones plug securely, otherweise
sound will not be heard.
Connecting to USB storage
1. Please connect the USB device to the
USB terminal of the main unit.
2. The main unit will read the contents of
the USB storage device automatically.
Note:
• The USB terminal of the main unit
supports USB1.1 only.
• The main unit can read the contents of
USB storage when there is no disc in the
main unit.

20
English
CONNECTING THE PLAYER TO OTHER
COMPONENTS
1. Please insert the memory card to the memory
card socket of the main unit.
2. The main unit will read the contents of the
memory card automatically.
Note:
• Please insert the memory card in correct
direction (see picture).
• The main unit can only read the contents of
memory card if there is no disc inserted in the
main unit.
Connecting to a TV set
Before connecting turn off the player and the external devices
Output the signals from the
player´s AV out to a TV
set.
Black
Viedo /audio cable
Yellow
White
Red
Signal Flow
To video input jack
(yellow)
To audio input jack
(white)
To audio input jack
(red)
Note:
• Please set the main unit to AV output mode.
Connecting to a memory card (SD/MMC/MS)
