Xpress XPRESSO M1 User manual
INSTRUCTION MANUAL
1/10 RWD ELECTRIC M CHASSIS KIT
2. XP-10008
Gear Differential Case (1)
1. XP-10008
Gear Differential Cover (1)
3. XP-10011
Differential Gasket (1)
4. XP-10051
Differential O-ring (Big) (1)
5. XP-10051
Differential O-ring (Small) (2)
6. XP-10009
Differential Bevel Gears (2)
7. XP-10011
Spacer 5x15.5x0.4mm (2)
8. XP-10011
Pin 2x9.7mm (2)
9. XP-10010
Alu. Gear Diff Outdrive Adapter (2)
1. GEAR DIFFERENTIAL
ATTENTION:
BAG A BAG o
3
9
2
8
5
7
6
4
6
7
5
9
8
1
1. XP-10009
Differential Satellite Gears (4)
2. XP-10011
Spacer 3.5x9.5x0.2mm (4)
3. XP-10009
Composite Gear Diff Cross (1)
4. XP-10011
Flat Head Screw M2.5 x10mm (4)
5. 3000Cst Oil (1)
3
1
2
4
Fill 3000CST diff oil to
differential up to the
top of the diff pin.
DO NOT fill the diff
to the top of the housing
2. Shock Body (4)
Option Parts: XP-10057
7. XP-10051
O-Ring (Small) (4)
11. XP-10016
Shock Rod Guide (4)
4. XP-10039
Cylinder End (4)
5. XP-10051
Oil Seal (4)
6. XP-10051
O-Ring (Large) (4)
3. XP-10039
Cylinder Nut (4)
8. XP-10016
Pistons - 1 hole (2)
9. XP-10016
Pistons - 2 holes (2)
15. XP-10050
Shock Shaft (4)
14. XP-10015
Shock End (4)
13. XP-10015
Shock Head (4)
1. XP-10039
Cylinder Cap (4)
10. XP-10016
Spacer (4)
12. XP-40047
E-Clips 2.5mm (8)
16. 500Cst Oil (1)
BAG B BAG O
front rear
X2 X2
X4
X4
2. SHOCK ABSORBERS
10
11
4
3
5
8
15
12
15
14
9
7
2
12
1. Fully extend the piston rod so the bottom of the shock body.
2. Hold the shock upright and slightly overfill the shock body
with shock oil.
3. Let the oil settle and allow air bubbles to rise to the top.
4. Slowly move the piston up and down to allow oil into all
cavities within the shock body.
5. Extend the piston rod most of the way out of the shock body.
Let the shock rest till no air bubbles visible in the oil.
6. Add shock oil as necessary.
X2 X2
1. XP-10079
Shock Spring - White (2)
2. XP-10078
Shock Spring - Blue (2)
3. XP-10015
Spring Cup (4)
3
1 2
3
front rear
front rear
1.50
1.50
Notice
2
2
Notice
1. XP-10012
Shock Mount - F (2)
3. XP-10042
Ball Stud 4.8 x 3.5mm (4)
5. XP-40035
Round Head M2.5 x 6mm (4)
6. XP-40036
Round Head M3 x 6mm (4)
4. XP-10043
Ball Stud 4.8 x 5mm (2)
7. XP-10090
Spacer 3 x 6 x 2mm (2)
2. XP-10012
Shock Mount - R (2)
10. XP-10094
Rear Lower Arm (2)
8. XP-10093
Front Lower Arm - Right (1)
9. XP-10093
Front Lower Arm - Left (1)
9
8
3
1
6
5
10
3
5
2
6
7
4
left right
3. FRONT LOWER ARM
4. REAR LOWER ARM
BAG c
2
4
3
6
6
5
7
3
2
1. XP-10091
Main Chassis (1)
2. XP-10003
Arm Joint Spacer (8)
To Arm Joint
3. XP-10046
Ball Nut 5.5mm (8)
4. XP-40041
Flat Head Screw M3 x 6mm (4)
5. XP-40042
Flat Head Screw M3 x 7mm (4)
6. XP-40048
E-Clips 6mm (8)
7. XP-10090
Spacer 3 x 7 x 2mm (4)
To Arm Joint
BAG c
5. LOWER ARM TO CHASSIS
BAG p
1. XP-10028
Front Bulkhead - Right (1)
3. XP-10030
Rear Bulkhead - Right (1)
4. XP-10029
Rear Bulkhead - Left (1)
5. XP-40038
Round Head M3 x 14mm (1)
6. XP-40036
Round Head M3 x 6mm (4)
7. XP-40041
Flat Head M3 x 6mm (6)
8. XP-40043
Ball Stud 4.8 x 5mm (4)
9. XP-10054
Ball Bearing 3 x 6 x 2.5mm (3)
10. XP-10090
Spacer 3 x 5 x 3mm (1)
2. XP-10027
Front Bulkhead - Left (1)
left
left
right
right
BAG d 6. BULKHEAD TO CHASSIS
BAG e
7
7
8
7
2
3
5
9
10
4
1
6
6
6
1. XP-40050
Round Head M3 x 10mm (1)
13. XP-10036
Servo Saver Extender (1)
14. XP-10012
Servo Saver For KO / Sanwa (1)
15. XP-10012
Servo Saver For Futaba (1)
16. XP-10012
Servo Saver Arm (1)
2. XP-40037
Round Head M3 x 8mm (2)
3. XP-40036
Round Head M3 x 6mm (4)
4. XP-40041
Flat Head M3 x 6mm (6)
5. XP-10054
Ball Bearing 5 x 8 x 2.5mm (1)
6. XP-10006
Servo Spacer (4)
7. XP-10045
Ball Nut 4.8mm (2)
8. XP-10012
Servo Saver Spring - Small (1)
9. XP-10012
Servo Saver Spring - Middle (1)
10. XP-10012
Servo Saver Spring - Large (1)
11. XP-10034
Servo Mount - Rear (1)
12. XP-10035
Servo Mount - Front (1)
17. XP-10012
Servo Saver Cover (1)
5
73
17
2
11
6
4
12 11
3
1
4
Servo (NOT INCLUDED)
16 10 98
14 / 15
BAG f 7. STEERING
BAG g
1.XP-10092
Upper Deck (2)
4. XP-10037
Upper Deck Post (1)
10. XP-10006
Driver Shaft Spacer (1)
11. XP-10044
Ball Stud 4.8 x 8mm (4)
12. XP-40036
Round Head M3 x 6mm (2)
13. XP-40037
Round Head M3 x 8mm (2)
14. XP-40044
Set Screw M3 x 3mm (2)
15. XP-10054
Ball Bearing 10 x 15 x 4mm (2)
16. XP-10054
Ball Bearing 5 x 9 x 3mm (2)
17. XP-10052
Driver Belt 189T (1)
3. XP-10006
Pulley 20T (1)
2.
Driver Shaft (1)
Option Parts: XP-10085
5. XP-10031
Rear Upper Clamp - Right (1)
6. XP-10031
Rear Upper Clamp - Left (1)
7. XP-10002
Bearing Hub -15mm (2)
8. XP-10002
Bearing Hub -9mm (2)
9. XP-10033
Spur Gear Adapter (1)
13
3
8
7
15
17
11
816
14 14
9
6
5
8
16
10
14
12
Apply C.A.
BAG h
1. XP-10020
Rear Shock Tower (1)
2. XP-10019
Front Shock Tower (1)
3. XP-40040
Round Head Screw 3 x 18mm (2)
4. XP-40039
Round Head Screw 3 x 16mm (2)
5. XP-40036
Round Head Screw 3 x 6mm (4)
6. XP-10038
Shock Post (4)
7. XP-10045
Ball Nut 4.8mm (4)
8. XP-10090
Spacer 3 x 6 x 1mm (2)
BAG i 9. SHOCK TOWER
4
1
6
7
5
3
2
8
6
7
5
A
B
A
B
D
E
D
E
C
F
Normal Position More Grip Position
Rear Suspension Check:
Default Setting :
(Ride Height 4.0mm)
A = 35.5mm
B = 24.9mm
C = 45.7mm
Default Setting :
(Ride Height 4.5mm)
D = 39.1 mm
E = 31.1 mm
F = 37.5 mm(More Grip Position)
Rod Reference (Ride Height 4.5mm)
Rod Reference (Ride Height 4mm)
1. XP-10003
Upper Arm - Left (2) 2. XP-10003
Upper Arm - Right (2)
10. XP-10098
Turnbuckle M3 x 14mm (2)
11. XP-10098
Turnbuckle M3 x 18mm (2)
12. XP-10098
Turnbuckle M3 x 20mm (2)
13. XP-10098
Turnbuckle M3 x 24mm (6)
3. XP-10002
Ball End 4.8 x 15mm (8)
5. XP-10002
Ball End 4.8 x 13mm (4)
7. XP-10048
Pivot Ball (4)
9. XP-40037
Round Head Screw M3 x 8mm (4)
6. XP-10003
Ball End 4.8 x 8.5mm (2)
8. XP-10003
Ball End 4.8 x 10.5mm (4)
4. XP-10002
Ball End 4.8 x 10mm (4)
3
3
4
13
13 33
11
5
7
8
712
9
9
4
5
2
1610
X2
X2
1 2
13
wrong less grip more grip
front
rear
BAG j 10. SUSPENSION
2. XP-10097
Drive Shaft 28mm (2)
3.
XP-10041 Front Axle (2)
7. XP-10004
Drive Shaft Cap (2)
4. XP-10026
Set Screw M3 x 3mm (2)
8. XP-10026
Pin 2 x 10mm - Flat (2)
9. XP-10026 Pin 2 x 10mm (6)
1. XP-10097
Drive Axle (2)
6. XP-10026 Axle Spring (2)
5. XP-10026 Cross Joint (2)
10. XP-10044
Ball Stud 4.8 x 8mm (2)
11. XP-10043
Ball Stud 4.8 x 5mm (4)
12. XP-10047
Ball Stud 5.5 x 3.8mm (4)
13. XP-10045
Ball Nut 4.8mm (2)
14. XP-40037
Round Head M3 x 8mm (2)
15. XP-40034
Cap Head M2 x 5mm (4)
16.
Wheel Adapter (4)
Option Parts: XP-10061
17.
XP-10054
Ball Bearing 5 x 10 x 4mm (8)
18. XP-10013
Front Knuckle Arm (2)
19. XP-10014
Rear Upright - Left (1)
20. XP-10014
Rear Upright - Right (1)
X2
X2
49
6
28
10
14
14 93
17
6
12 13
16 17 18
5
1
11
20
17 19
17
8
16
11 12
14
BAG k BAG l
2
1
Tie Rod C (45.7mm)
Tie Rod F (37.5mm)
1
1. XP-10003
Arm Ball Joint - 5.5mm (4)
2. XP-40048
E-Clips - 6mm (4)
BAG G
10
2
9
1
510
11
4
3
8 9
10
612
7
5. XP-10001 Bumber (1)
1. XP-10001 Body Post - Front (2)
2. XP-10001 Body Post - Rear (2)
4. XP-10001 Foam Plate (1)
10. XP-40041
Flat Head M3 x 6mm (13)
11. XP-40049
Flat Head M3 x 10mm (2)
9. XP-40036
Round Head M3 x 6mm (4)
8. XP-10053 Spur Gear (1)
3. XP-10095 Bumber Foam (1)
6. XP-10005 Battery Mount Cover (2)
7. XP-10005 Battery Mount (2)
12. XP-10055 Body Clips (4)
BAG m 11. FRONT & REAR ASSEMBLY
BAG n
3. XP-10090
Spacer 3 x 6 x 1mm (2)
2. XP-40037
Round Head M3 x 8mm (2)
4. XP-10001
Antenna Holder (1)
1. XP-40041
Flat Head M3 x 6mm (1)
6. XP-10055
Body Clips (4)
5. XP-10001
Body Mount (4)
Motor (NOT INCLUDED)
Pinion Gear (NOT INCLUDED)
ESC (NOT INCLUDED)
Receiver (NOT INCLUDED)
4
32
1
6
5
Set Screw M3x3mm (NOT INCLUDED)
12. FINAL ASSEMBLY
1. Wheel Nut (4)
2. XP-40041
Flat Head M3 x 6mm (2)
3. XP-10024
Gyro Plate (1)
1
2
3
30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53
90 5.70 5.52 5.34 5.18 5.03 4.89 4.75 4.62 4.50 4.38 4.28 4.17 4.07 3.98 3.89 3.80 3.72 3.64 3.56 3.49 3.42 3.35 3.29 3.23
91 5.76 5.58 5.40 5.24 5.09 4.94 4.80 4.67 4.55 4.43 4.32 4.22 4.12 4.02 3.93 3.84 3.76 3.68 3.60 3.53 3.46 3.39 3.33 3.26
92 5.83 5.64 5.46 5.30 5.14 4.99 4.86 4.72 4.60 4.48 4.37 4.26 4.16 4.07 3.97 3.88 3.80 3.72 3.64 3.57 3.50 3.43 3.36 3.30
93 5.89 5.70 5.52 5.35 5.20 5.05 4.91 4.78 4.65 4.53 4.42 4.31 4.21 4.11 4.02 3.93 3.84 3.76 3.68 3.61 3.53 3.46 3.40 3.33
94 5.95 5.76 5.58 5.41 5.25 5.10 4.96 4.83 4.70 4.58 4.47 4.36 4.25 4.15 4.06 3.97 3.88 3.80 3.72 3.64 3.57 3.50 3.43 3.37
95 6.02 5.82 5.64 5.47 5.31 5.16 5.01 4.88 4.75 4.63 4.51 4.40 4.30 4.20 4.10 4.01 3.92 3.84 3.76 3.68 3.61 3.54 3.47 3.41
96 6.08 5.88 5.70 5.53 5.36 5.21 5.07 4.93 4.80 4.68 4.56 4.45 4.34 4.24 4.15 4.05 3.97 3.88 3.80 3.72 3.65 3.58 3.51 3.44
97 6.14 5.95 5.76 5.58 5.42 5.27 5.12 4.98 4.85 4.73 4.61 4.50 4.39 4.29 4.19 4.10 4.01 3.92 3.84 3.76 3.69 3.61 3.54 3.48
98 6.21 6.01 5.82 5.64 5.48 5.32 5.17 5.03 4.90 4.77 4.66 4.54 4.43 4.33 4.23 4.14 4.05 3.96 3.88 3.80 3.72 3.65 3.58 3.51
99 6.27 6.07 5.88 5.70 5.53 5.37 5.23 5.08 4.95 4.82 4.70 4.59 4.48 4.37 4.28 4.18 4.09 4.00 3.92 3.84 3.76 3.69 3.62 3.55
100 6.33 6.13 5.94 5.76 5.59 5.43 5.28 5.14 5.00 4.87 4.75 4.63 4.52 4.42 4.32 4.22 4.13 4.04 3.96 3.88 3.80 3.73 3.65 3.58
101 6.40 6.19 6.00 5.82 5.64 5.48 5.33 5.19 5.05 4.92 4.80 4.68 4.57 4.46 4.36 4.26 4.17 4.08 4.00 3.92 3.84 3.76 3.69 3.62
102 6.46 6.25 6.06 5.87 5.70 5.54 5.38 5.24 5.10 4.97 4.85 4.73 4.61 4.51 4.40 4.31 4.21 4.12 4.04 3.96 3.88 3.80 3.73 3.66
103 6.52 6.31 6.12 5.93 5.76 5.59 5.44 5.29 5.15 5.02 4.89 4.77 4.66 4.55 4.45 4.35 4.25 4.16 4.08 3.99 3.91 3.84 3.76 3.69
104 6.59 6.37 6.18 5.99 5.81 5.65 5.49 5.34 5.20 5.07 4.94 4.82 4.70 4.60 4.49 4.39 4.30 4.20 4.12 4.03 3.95 3.87 3.80 3.73
105 6.65 6.44 6.23 6.05 5.87 5.70 5.54 5.39 5.25 5.12 4.99 4.87 4.75 4.64 4.53 4.43 4.34 4.24 4.16 4.07 3.99 3.91 3.84 3.76
106 6.71 6.50 6.29 6.10 5.92 5.75 5.59 5.44 5.30 5.16 5.04 4.91 4.80 4.68 4.58 4.48 4.38 4.29 4.20 4.11 4.03 3.95 3.87 3.80
107 6.78 6.56 6.35 6.16 5.98 5.81 5.65 5.49 5.35 5.21 5.08 4.96 4.84 4.73 4.62 4.52 4.42 4.33 4.24 4.15 4.07 3.99 3.91 3.84
108 6.84 6.62 6.41 6.22 6.04 5.86 5.70 5.55 5.40 5.26 5.13 5.00 4.89 4.77 4.66 4.56 4.46 4.37 4.28 4.19 4.10 4.02 3.95 3.87
109 6.90 6.68 6.47 6.28 6.09 5.92 5.75 5.60 5.45 5.31 5.18 5.05 4.93 4.82 4.71 4.60 4.50 4.41 4.31 4.23 4.14 4.06 3.98 3.91
110 6.97 6.74 6.53 6.33 6.15 5.97 5.81 5.65 5.50 5.36 5.23 5.10 4.98 4.86 4.75 4.64 4.54 4.45 4.35 4.27 4.18 4.10 4.02 3.94
111 7.03 6.80 6.59 6.39 6.20 6.03 5.86 5.70 5.55 5.41 5.27 5.14 5.02 4.90 4.79 4.69 4.58 4.49 4.39 4.30 4.22 4.14 4.06 3.98
112 7.09 6.86 6.65 6.45 6.26 6.08 5.91 5.75 5.60 5.46 5.32 5.19 5.07 4.95 4.84 4.73 4.63 4.53 4.43 4.34 4.26 4.17 4.09 4.02
113 7.16 6.93 6.71 6.51 6.31 6.13 5.96 5.80 5.65 5.51 5.37 5.24 5.11 4.99 4.88 4.77 4.67 4.57 4.47 4.38 4.29 4.21 4.13 4.05
114 7.22 6.99 6.77 6.56 6.37 6.19 6.02 5.85 5.70 5.55 5.42 5.28 5.16 5.04 4.92 4.81 4.71 4.61 4.51 4.42 4.33 4.25 4.17 4.09
115 7.28 7.05 6.83 6.62 6.43 6.24 6.07 5.91 5.75 5.60 5.46 5.33 5.20 5.08 4.97 4.86 4.75 4.65 4.55 4.46 4.37 4.28 4.20 4.12
116 7.35 7.11 6.89 6.68 6.48 6.30 6.12 5.96 5.80 5.65 5.51 5.38 5.25 5.13 5.01 4.90 4.79 4.69 4.59 4.50 4.41 4.32 4.24 4.16
20 38 1.90
Xpress Xpresso M1 (64Pitch-Spur Gear 90T~116T)
Pinion Gear
Spur Gear
Belt Pully =
Differential Pully=
Internal Gear Ratio =
53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76
69 2.47 2.43 2.38 2.34 2.30 2.26 2.22 2.19 2.15 2.11 2.08 2.05 2.02 1.99 1.96 1.93 1.90 1.87 1.85 1.82 1.80 1.77 1.75 1.73
70 2.51 2.46 2.42 2.38 2.33 2.29 2.25 2.22 2.18 2.15 2.11 2.08 2.05 2.02 1.99 1.96 1.93 1.90 1.87 1.85 1.82 1.80 1.77 1.75
71 2.55 2.50 2.45 2.41 2.37 2.33 2.29 2.25 2.21 2.18 2.14 2.11 2.08 2.04 2.01 1.98 1.96 1.93 1.90 1.87 1.85 1.82 1.80 1.78
72 2.58 2.53 2.49 2.44 2.40 2.36 2.32 2.28 2.24 2.21 2.17 2.14 2.10 2.07 2.04 2.01 1.98 1.95 1.93 1.90 1.87 1.85 1.82 1.80
73 2.62 2.57 2.52 2.48 2.43 2.39 2.35 2.31 2.27 2.24 2.20 2.17 2.13 2.10 2.07 2.04 2.01 1.98 1.95 1.93 1.90 1.87 1.85 1.83
74 2.65 2.60 2.56 2.51 2.47 2.42 2.38 2.34 2.30 2.27 2.23 2.20 2.16 2.13 2.10 2.07 2.04 2.01 1.98 1.95 1.93 1.90 1.87 1.85
75 2.69 2.64 2.59 2.54 2.50 2.46 2.42 2.38 2.34 2.30 2.26 2.23 2.19 2.16 2.13 2.10 2.07 2.04 2.01 1.98 1.95 1.93 1.90 1.88
76 2.72 2.67 2.63 2.58 2.53 2.49 2.45 2.41 2.37 2.33 2.29 2.26 2.22 2.19 2.16 2.12 2.09 2.06 2.03 2.01 1.98 1.95 1.93 1.90
77 2.76 2.71 2.66 2.61 2.57 2.52 2.48 2.44 2.40 2.36 2.32 2.29 2.25 2.22 2.18 2.15 2.12 2.09 2.06 2.03 2.00 1.98 1.95 1.93
78 2.80 2.74 2.69 2.65 2.60 2.56 2.51 2.47 2.43 2.39 2.35 2.32 2.28 2.25 2.21 2.18 2.15 2.12 2.09 2.06 2.03 2.00 1.98 1.95
79 2.83 2.78 2.73 2.68 2.63 2.59 2.54 2.50 2.46 2.42 2.38 2.35 2.31 2.27 2.24 2.21 2.18 2.14 2.11 2.08 2.06 2.03 2.00 1.98
80 2.87 2.81 2.76 2.71 2.67 2.62 2.58 2.53 2.49 2.45 2.41 2.38 2.34 2.30 2.27 2.24 2.20 2.17 2.14 2.11 2.08 2.05 2.03 2.00
81 2.90 2.85 2.80 2.75 2.70 2.65 2.61 2.57 2.52 2.48 2.44 2.40 2.37 2.33 2.30 2.26 2.23 2.20 2.17 2.14 2.11 2.08 2.05 2.03
82 2.94 2.89 2.83 2.78 2.73 2.69 2.64 2.60 2.55 2.51 2.47 2.43 2.40 2.36 2.33 2.29 2.26 2.23 2.19 2.16 2.13 2.11 2.08 2.05
83 2.98 2.92 2.87 2.82 2.77 2.72 2.67 2.63 2.59 2.54 2.50 2.46 2.43 2.39 2.35 2.32 2.29 2.25 2.22 2.19 2.16 2.13 2.10 2.08
84 3.01 2.96 2.90 2.85 2.80 2.75 2.71 2.66 2.62 2.57 2.53 2.49 2.46 2.42 2.38 2.35 2.31 2.28 2.25 2.22 2.19 2.16 2.13 2.10
85 3.05 2.99 2.94 2.88 2.83 2.78 2.74 2.69 2.65 2.60 2.56 2.52 2.48 2.45 2.41 2.38 2.34 2.31 2.27 2.24 2.21 2.18 2.15 2.13
86 3.08 3.03 2.97 2.92 2.87 2.82 2.77 2.72 2.68 2.64 2.59 2.55 2.51 2.48 2.44 2.40 2.37 2.33 2.30 2.27 2.24 2.21 2.18 2.15
87 3.12 3.06 3.01 2.95 2.90 2.85 2.80 2.76 2.71 2.67 2.62 2.58 2.54 2.50 2.47 2.43 2.40 2.36 2.33 2.30 2.26 2.23 2.20 2.18
88 3.15 3.10 3.04 2.99 2.93 2.88 2.83 2.79 2.74 2.70 2.65 2.61 2.57 2.53 2.50 2.46 2.42 2.39 2.35 2.32 2.29 2.26 2.23 2.20
89 3.19 3.13 3.07 3.02 2.97 2.92 2.87 2.82 2.77 2.73 2.68 2.64 2.60 2.56 2.52 2.49 2.45 2.42 2.38 2.35 2.32 2.29 2.25 2.23
90 3.23 3.17 3.11 3.05 3.00 2.95 2.90 2.85 2.80 2.76 2.71 2.67 2.63 2.59 2.55 2.51 2.48 2.44 2.41 2.38 2.34 2.31 2.28 2.25
91 3.26 3.20 3.14 3.09 3.03 2.98 2.93 2.88 2.83 2.79 2.74 2.70 2.66 2.62 2.58 2.54 2.51 2.47 2.44 2.40 2.37 2.34 2.31 2.28
92 3.30 3.24 3.18 3.12 3.07 3.01 2.96 2.91 2.87 2.82 2.77 2.73 2.69 2.65 2.61 2.57 2.53 2.50 2.46 2.43 2.39 2.36 2.33 2.30
93 3.33 3.27 3.21 3.16 3.10 3.05 2.99 2.95 2.90 2.85 2.80 2.76 2.72 2.68 2.64 2.60 2.56 2.52 2.49 2.45 2.42 2.39 2.36 2.33
94 3.37 3.31 3.25 3.19 3.13 3.08 3.03 2.98 2.93 2.88 2.83 2.79 2.75 2.71 2.67 2.63 2.59 2.55 2.52 2.48 2.45 2.41 2.38 2.35
95 3.41 3.34 3.28 3.22 3.17 3.11 3.06 3.01 2.96 2.91 2.87 2.82 2.78 2.73 2.69 2.65 2.62 2.58 2.54 2.51 2.47 2.44 2.41 2.38
20 38 1.90
Xpress Xpresso M1 (64Pitch-Spur Gear 95T~69T)
Spur Gear
Pinion Gear
Belt Pully =
Differential Pully=
Internal Gear Ratio =
Strong
☐
Name:____________________
Date:_______________ City / Country: __________ Race: ________________ Track: _____________
Temperature Track: ______
Temperature Air: _______ Track Surface:
☐
Carpet
☐
Asphalt Track Layout:
☐
Technical
☐
Mixed
☐
Fast
Best Lap: __________
Total Time__________Lap______
Memo:
Transmission
Differential Oil : ________________________
Gear Differential
:
☐
or Locker :
☐
Gear Ratio
Power
Motor : ____________Esc : _____________
Batteries : ___________________________
Oil Weight : ___________________________
Pinion/ T:_______ Spur Gear/ T:_______
(Shaft Pulley : 38T / Diff. Pulley: 20T = 1.9 Internal Gear Ratio)
Front Suspension Rear
Shock Oil
Rebound
Spring
Piston
Foam Insert
Anti-Roll Bar
Front Wheel / Tires Rear
Tires
Additive Timing
Inserts
Treated Area
Body: ____________ Wing: ______________
Other
SpurGear
Pinion
x 1.9 = Finial Drive Ratio: ____:1
________
Esc Setting / Memo :
Memo :
Gyro: ______________
Memo :
Memo :
Memo :
Memo :
Front Left Front Right Rear Left Rear Right
Memo :
Rear Active Toe In Position Memo:
End Bell Timing: ______________________
Additive
Normal
☐
Front Rear
Front Rear
Front Rear
Cooling Fan: _________________________
SET-UP SHEET
Rear Active Toe In Position
CASTER SHIM SHIM
SHIM
SHIM
SHIM
CAMBER
CAMBER
RIDE HEIGHT RIDE HEIGHT
1
2
3
4
5
6
7
810
9
8
7
6
5
4
3
2
1
SHIM SHIM
SHIM
HUB
+
-
-
+
DOWNSTOP
HUB
DOWNSTOP
SHIM SHIM
SHIMSHIM
SHIM
TOE DEGREE
Battery Mount Position
STEERING
%
TOE DEGREE
SHIM
SHIM
SHIM
+
-
+
-
Table of contents
Other Xpress Motorized Toy Car manuals
