Xpresskit DLPKGM User manual

D I G I T A L O E M I N T E G R A T I O N
tm
INSTALLATION
GUIDE
© 2009 Directed Electronics. All rights reserved.
www.xpresskit.com
Rev: 20091217
Update Alert: Firmware updates
are posted to the web on a regular
basis. We recommend you check for
firmware and/or install guide
updatespriortoinstallationofthisproduct.
DLPKGM
GM, DODGE, JEEPAND
CHRYSLER DOORLOCKAND
PASSKEY INTERFACE
HARDWARE : V2
FIRMWARE : V3.00
REQUIRED
DLPKGM
D2D INTERFACE
MODULE COMPATIBLE
Hardware Vr:2
Software Vr:3.00
D/C: 9L
www.xpresskit.com MADE IN CANADA
Digital OEM Integration
Module label

DLPKGM
DOORLOCK AND PASSKEY INTERFACE
2
1
INSTALLATION MANUAL
See wiring schematic configuration
Lock Red/White
Unlock Driver 1 Lt.Blue
Ignition White
(-) While running (status)
White/Black
Door trigger Violet/White
Data OBD2 Tan/White
Bypass PK Pink/Black
Lt.Green Trunk release
Blue Unlock Driver 2
Pink Parking light
Blue/White
Green
Purple Data BCM
Pink/White Bypass PK3
3
Connect wire to vehicle Connect wire to Remote-Starter/Alarm INPUT
ENTRÉE
OUTPUT
SORTIE
2
3
5
6
7
IGN
START
OFF
8
9
10
IGN
START
OFF
IGN
START
OFF
Press and hold the
programming button. Plug in
the connector 1 in the
DLPKGM interface.
The LED will turn on, indicating
thebeginningofprogramming.
Turn the key to the ignition
position.
The LED will flash rapidly.
GM vehicle: Start the vehicle
with the key.
The LED will turn off.
Turn the key OFF.
The interface is
programmed.
Make the connections of
the DLPKGM to the vehicle:
1.A
1.B Connector2(White):
(I)Locatethewiringtypeforthevehicleonthe
VEHICLEFITGUIDE(P.2-3)
(II) Make the connections associated with the
vehicle in the WIRING SCHEMATIC
CONFIGURATION(P.4-6)
START HERE
INSTALLATION AND PROGRAMMING INSTRUCTIONS
Connector1(White):
Determinethetypeofinstallation:
INSTALLATIONWITHD2D( )
INSTALLATIONWITHOUTD2D(Seeplan2,P.4)
Seeplan1,P.4
1
WARNING: Connector 2 can
be easily plugged in
backwards.
(Type 3 only) (Type 3 only)
Future Input
Tach
~
Chrysler vehicle go step 9
(Can be programmed 5 times max.)
1
To enable D2D, the DLPKGM
need to see Data
communication from the
remote car starter. Hit LOCK.
PRESS
LOCK
from RCS
Programming
button
D2D Cable
Connecteur1(Noir):
Déterminezletyped’installation(D2DounonD2D)
Pour l’installation avec D2D assurez vous de la
présenceduconnecteurD2D surledémarreur.Voir
schéma1(P.4).
PourinstallationnonD2Dvoirschéma2(P.4).
Effectuez les connexions
du DLPKGM au véhicule:
Connecteur2(Blanc):
Déterminez le type de branchement selon votre
véhicule(VoirGUIDEDESVOITURES,P.2-3)
Effectuez les branchements selon le type
d’installation (Voir SCHÉMA DE BRANCHEMENT,
P.4-6)
Maintenez le bouton de
programmation enfoncé.
Branchez le connecteur 1
dans le module DLPKGM.
Le DEL s’allume pour indiquer
ledébutde la programmation.
Tournez la clef en position
ignition.
LeDELclignote rapidement.
Relâchez le bouton de
programmation.
Véhicules Chrysler allez à l’étape 9
(Peux être reprogrammé 5 fois max.)
Vehicules GM: Démarrez le
véhiculeavecla clef.
LeDELs’éteint.
Tournezlaclef à OFF.
Le module est programmé.
Pour activer le D2D, le DLPKGM à besoin de voir la
communication Data du démarreur à distance.
Appuyez sur LOCK (verrouillage).
4
2
Plug the connector 2 into the
DLPKGMinterface.
WARNING: Connector 2 can be easily
pluggedinbackwards.
Branchez le connecteur 2
danslemodule .DLPKGM
ATTENTION: Ne pas brancher à l'envers.
Branchement du filage au véhicule Branchement du filage au démarreur à distance/Alarme
P.1

:Functional only when the vehicle is running.
Fonctionne seulement lorsque le véhicule est en fonction.
A-Contournement PK3, Passlock, ou VATS
B-Verrouillage et déverrouillage des portes
C-Contrôle d'Alarme d'origine (OEM)
D-Valise
E-Status des portes
F-Sièges et rétroviseurs chauffants
G-Dégivreur arrière
H-Contrôle des feux de stationnement
I-Radio RAP accessoires
J-Selection de mémoires conducteur 1 et 2 (par
déverrouillage)
K-Démarrage
L-Portes coulissantes
M-Tach
N-Contournement du Transpondeur
O-Schéma de Branchements (Voir page 5-7)
Note : Heated seats will turn ON (low power) ONLY if the
enginetempisbelow0°C(32°F)whenremotestarted.
Note : Les sièges chauffants s'allument à faible intensité
SEULEMENT si la température du moteur est sous 0°C
(32°F)au démarrage.
Titres des colonnes
VEHICLE APPLICATION GUIDE / GUIDE DES VOITURES
En D2D les entrées analogues (déverrouillé, (-) lorsqu’en marche
(status)) sont désactivées pour augmenter la sécurité.
In D2D mode the analog Input (unlock, (-) while running (status))
are disabled for security.
DLPKGM
DOORLOCK AND PASSKEY INTERFACE
*1/4*Indicatesthat eitherconfiguration#1 and#4can beused,or
even combined together. When both configuration #1 and #4 are
combined both the Purple wire andTan/White wires must be
connected to the OBDII and BCM respectively. In this case White
inputwillcontroltheRightSlidingDoor;nottheParklights.
NOTE: The security light will turn OFF when the key is inserted in
theignitionbarrel.
*1/4*indique que l'une ou l'autre configuration #1 et #4 peut être
employée, ou même combinée ensemble. Quand la configuration
#1 et les #4 sont combinés, le fil Mauve et le fils Beige/Blanc
doivent être reliés à l'OBDII et au BCM respectivement. Dans ce
cas-ci, l'entrée du fil Blanc commandera la Porte Coulissante
Droiteetnonleslumièresdestationnement(Parklights).
NOTE: La lumière de sécurité dans le tableau de bord s'éteindra
lorsquelacléseraintroduitedanslebarilletd'ignition.
SRX 3
