XS Instruments Temp70 PT100 vio User manual

INSTRUCTIONS MANUAL
Temp70 PT100

1
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021

2
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Index
Safety information...................................................................................................................................4
•Definition of warning words and symbols ....................................................................................4
•Reporting terms:...........................................................................................................................4
•Additional documents providing safety information....................................................................4
•Use according to destination ........................................................................................................5
•Basic requirements for safe use....................................................................................................5
•Unauthorised use..........................................................................................................................5
•Device maintenance......................................................................................................................5
•Responsibility of instrument owner..............................................................................................5
Instrumental features..............................................................................................................................6
•Datasheet......................................................................................................................................6
Instrument description............................................................................................................................7
•Display...........................................................................................................................................7
•Keypad ..........................................................................................................................................7
•LED ................................................................................................................................................8
Setup........................................................................................................................................................8
•Supplied components ...................................................................................................................8
•Start-up .........................................................................................................................................8
•Switching On/Off...........................................................................................................................8
•Batteries replacement...................................................................................................................8
•Instrument transportation............................................................................................................9
•Key Functions................................................................................................................................9
•Inputs / Outputs connections .......................................................................................................9
•Display symbols and icons ..........................................................................................................10
Device operation....................................................................................................................................10
Setup menu ...........................................................................................................................................11
•Setup Menu Structure.................................................................................................................11
Temp Settings parameter.......................................................................................................................11
Log Settings Menu .................................................................................................................................13
Instrument configuration menu ............................................................................................................14
Temperature measurement...................................................................................................................16
•Measurement .............................................................................................................................16
•MAX/MIN function......................................................................................................................16
•HOLD function.............................................................................................................................16
Other features .......................................................................................................................................17
•Automatic switch-off...................................................................................................................17
•Offset adjustment.......................................................................................................................17
DataLink+ Software................................................................................................................................17

3
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Warranty................................................................................................................................................18
•Warranty period and limitations.................................................................................................18
Disposal of electrical devices.................................................................................................................18
XS Instruments
Via della Meccanica n.25
41012 Carpi (MO) ITALY
Tel.[phone] Fax [phone]
www.xsinstruments.com

4
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Safety information
•Definition of warning words and symbols
This manual contains extremely important safety information, in order to avoid personal injury, damage to
the instrument, malfunctions or incorrect results due to failure to comply with them. Read entirely and
carefully this manual and be sure to familiarize with the tool before starting to work with it.
This manual must be kept near to the instrument, so that the operator can consult it easily, if necessary.
Safety provision are indicated with warning terms or symbols.
•Reporting terms:
ATTENTION for a medium-risk hazardous situation, which could lead to serious injury or death, if not
avoided.
ATTENTION for a dangerous situation with reduced risk which can cause material damaged, data loss or
minor or medium-sized accidents, if not avoided.
WARNING for important information about the product.
NOTE for useful information about the product.
Warning symbols:
•Additional documents providing safety information
The following documents can provide the operator with additional information to work with the measuring
system safely:
•Specific notes on product safety.
Attention
This symbol indicates a potential risk and warns you to proceed with caution.
Attention
The instrument must be used following the indications of the reference manual.
Read the instructions carefully.
Advice
This symbol draws attention to possible damage to the instrument or instrumental
parts.
Note
This symbol highlights information and tips.
Attention
This symbol draws attention to a possible danger from electric current.

5
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
•Use according to destination
This instrument is designed exclusively for electrochemical measurements both in the laboratory and
directly in the field.
Pay attention to the technical specifications shown in the INSTRUMENT FEATURES / TECHNICAL DATA table;
any other use is to be considered unauthorized.
This instrument has left the factory in perfect technical and safety conditions.
The regular functionality of the device and the operator safety are guaranteed only if all the normal
laboratory safety standards are respected and if all the specific safety measures described in this manual
are observed.
•Basic requirements for safe use
The regular functionality of the device and the operator safety are guaranteed only if all the following
indications are respected:
•The instrument can be used in accordance with the specifications mentioned above only.
•The instrument must operate exclusively in the environmental conditions indicated in this manual.
•The only part of the instrument that can be opened by the user is the battery compartment.
Any other operation have to be authorised by the manufacturer.
•Unauthorised use
The instrument must not run, if:
•It is visibly damaged (for example due to transportation).
•it has been stored for a long period of time in adverse conditions (exposure to direct light, heat sources
or places saturated by gas or vapours) or in environments with conditions different from those
mentioned in this manual.
•Device maintenance
If used correctly and in a suitable environment, the instrument does not require maintenance procedures.
It is recommended to occasionally clean the instrument case with a damp cloth and a mild detergent. This
operation must be performed with the instrument off and by authorized personnel only.
The housing is in ABS/PC (acrylonitrile butadiene styrene /polycarbonate). This material is sensitive to some
organic solvents, for example toluene, xylene and methyl ethyl ketone (MEK).
If liquids get into the housing, they could damage the instrument.
Do not open the instrument housing: it does not contain parts that can be maintained, repaired or replaced
by the user. In case of problems with the instruments, contact your local distributor.
It is recommended to use original spare parts only. Contact your local distributor for information. The use
of non-original spare parts can lead to malfunction or permanent damage to the instrument. Moreover, the
use of spare parts not guaranteed by the supplier can be dangerous for the user himself.
•Responsibility of instrument owner
The person who owns and uses the tool or authorizes its use by other people is the owner of the tool and
is responsible for the safety of all users of the tool and third parties.
The owner of the instrument must inform users of the use of the same safely in their workplace and on the
management of potential risk, also providing the required protective devices.
When using chemicals or solvents, follow the manufacturer’s safety data sheets.

6
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Instrumental features
•Datasheet
Instrument
Temp70 PT100 Vio
Temperature
Probes
PT100 (x2)
Inputs
Double connector with 3 pins
Measuring range
-200,0…+999,9 °C
Resolution
0,01 °C (from -99,99 to +99,99 °C)
0,1 °C elsewhere in the scale
Accuracy
± 0,03 °C (from -99,99 to +99,99 °C)
± 0,1 elsewhere in the scale
System
Display
Backlit colour LCD
Brightness and contrast management
Manual and automatic with integrated sensor
Sleep mode
Yes
Auto switch-off
Yes, after 20 minutes (deactivable)
LED indication
Yes
Reading stability indicator
Yes adjustable (Low-Med-High)
Stability filter (HOLD)
Yes
Reading MAX/MIN
Yes
Offset adjustment
Yes
Internal memory
1000 data
Sampling
1 min…99 hours
Working conditions
Temperature: 0…+60 °C
humidity: <95% U.R. (non-condensing)
Maximum altitude of use
2000 m
Dimensions
185 x 85 x 45 mm
Weight
400 g
IP protection
IP 56
Sound level during standard operation
< 80 dB
Power supply
3 x 1,5V “AA” alkaline
Battery life
> 550 hours
Reference standards
EMC 2014/30/UE
RoHS 2011/65/EU
EN 61326-1

7
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Instrument description
•Display
•Keypad
Text string
Indication of instrumental
mode
Date and
time
Actual value
Type of temperature
probe
Stability indication
Error symbol
Text string
Battery
charge level
On-Off key to switch the
device on and off
MAX/MIN and HOLD key
Press fast to turn on the
recording function MAX/MIN,
view the MAX and MIN
recorded values.
Press for 3 seconds to activate
and deactivate the HOLD
function and to deactivate the
recording function MAX/MIN
(if active)
OK / Setup Key to confirm the
values and enter into the
setup menu from the
meausure mode.
Up directional Key/Save data for
scrolling through menus and
parameters. Press fast to activate
/deactivate the data saving function.
Measurement
unit
Text string
Saved data icon
Indication to use
the directional
keys
Connection icon with
the DataLink+ software
Automatic saved
data icon
Down directional key /
Recall memory to scroll
through the menus, the
paramenters and manage
the recall of data
Directional key INPUT/ ESC to change
the type of screen only with both
probes connected: channel 1, channel
2 or two channels simultaneously.
Press fast into a menu to return to the
measure mode.

8
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
•LED
All instruments are equipped with a two-colour LED (red and green) that provides the user with important
information on the system status:
Function
LED
Description
Power on
GREEN
Fixed
Power off
RED
Fixed
Standby
GREEN
Flashing every 20 s
Stable measurement
GREEN
Flashing every 3 s
Error during calibration
RED
Flashing every 3 s
Selection confirmation / DataLogger
(saving data)
GREEN
Switched on for 1 s
Recall data saved
GREEN/RED
0,5 seconds green and 0,5 seconds red
Setup
•Supplied components
The instrument is always supplied inside the specific carrying case.
Into the carrying case there are always: instrument with batteries, screwdriver, user manual,
connection cable and power supply.
•Start-up
•The device leaves the factory ready to be used by the user.
•Batteries are included.
•Switching On/Off
Turn on the system by pressing the button . The display initially activates all segments and then
appears:
•model and firmware of the instrument;
•information about the calibration of the channel 1 and the channel 2;
•screen of the measured temperature;
•to switch off the instrument, press the key in measure mode.
•Batteries replacement
The instrument works with 3 batteries AA 1,5V.
To proceed with the replacement:
1. Turn off the device;
2. Turn the instrument downwards, with the side of the connectors placed on a stable surface: in this way
the battery stopper cap will be turned towards the operator;
3. Keep pressed the battery stopper cap with two fingers;
4. Using the screwdriver supplied, completely unscrew the screw closed to the battery symbol;
5. Remove the battery stopper cap with the help of the lanyard;
6. Remove the 3 exhausted batteries and insert the new ones. Pay attention to the correct polarity. Follow
the diagram above the battery symbol in the rear compartment of the instrument;
7. Reinsert the battery stopper cap; always keep it pressed with two fingers, insert the screw and tighten.

9
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
•Instrument transportation
The instrument is always supplied with the appropriate carrying case. Use the original case only, to transport
the instrument. If you need to buy it again, contact your local distributor. The interior of the case is shaped
to be able to house the instrument and the sensors still connected.
•Key Functions
Button
Pression
Function
Short
Press to turn the device on or off
Short
In measure mode, press to enter into the Setup menu.
In the setup menus, press to select the desired program and / or value
Short
Turn on the MAX/MIN recording function, view of the MAX and MIN
recorded values
Long
Turn on/tun off of HOLD function.
Turn off of the MAX/MIN recordings (if active)
Short
To scroll the different views while the two probes are connected: channel 1,
channel 2 and both channels simultaneously.
Into the setup menus, press to return to measure mode
Short
To scroll and modify the values of the parameters in the Setup menu.
Turn on/turn off data recording
Short
To scroll and modify the values of the parameters in the Setup menu.
Recall the saved data
IMPORTANT:
•When the Sleep mode is active (by default after two minutes of inactivity of the instrument) press any
key to reactivate the brightness of the display.
•Only at this point do the keys regain their function.
•Inputs / Outputs connections
Use original accessories guaranteed by the manufacturer only.
If necessary, contact your local distributor.
Temp70 PT100 Vio upper board
Read the manual before proceeding to connect the probes
CHANNEL 1
SINGLE 3 PIN CONNECTOR
for temperature probe
PT100
CHANNEL 2
SINGLE 3 PIN CONNECTOR
for temperature probe
PT100
Micro USB for connection
to PC and power supply

10
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
•Display symbols and icons
Symbol
Description
Type of probe connected
Error in measurement
Battery charge indication
Measurement stability indicator
The bars scroll if the measurement is not stable
Number of data stored in Data Logger mode on instrumental memory
Press the directional keys to change the parameter or value on the display
FIXED: Automatic Data Logger set
INTERMITTENT: Automatic Data Logger in operation
Instrument connected to the DataLink+ software
Device operation
On the left side of the display, through a string of different colours, it is always indicated how the instrument
is located.
String
Meaning
The instrument is in measure mode.
The instrument is in the Recall phase of the recorded MAX or
MIN value.
The function HOLD is active.
Recall of the saved data.
The user is in the setup mode.
The configuration menus can concern the characteristics of the
parameters or the general setting of the instrument
M+

11
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Setup menu
•In measure mode, press the key to enter SETUP mode, select the parameter to edit by using the
directional keys ( and ) and confirming with ;
•Within the selected menu, move between the different programs using the directional buttons and press
the button to access the submenu you want to edit;
•The icon indicates that the value or parameter to choose is editable using the directional keys;
•Using the directional keys, select the desired option or modify the numerical value and confirming with
;
•Press the key to return to the previous menu.
•Setup Menu Structure
P7.0
TEMP
SETTINGS
P7.2
Offset settings
P7.3
Calibration data
P7.4
Select resolution
P7.5
Stability filter
P7.6
Reset settings
P8.0
LOG
SETTINGS
P8.1
Log type
P8.2
Clear data
P9.0
SETTINGS
P9.1
Temperature unit
P9.2
Date and time
P9.3
Backlight mode
P9.4
Brightness
P9.5
Sleep mode
P9.7
View difference
P9.8
Reset settings
P9.9
Auto off
Temp Settings parameter
•In measure mode press to access the Setup Menu;
•Press the key to enter into the menu TEMP SETTINGS P7.0;
•Move with the keys and to select the programs to access.
The table below shows the setup menu structure for the parameter, and for each program the options that
the user can choose and the default value:
Configuration of the Temp settings menu
Program
Description
Options
Factory Default Settings
P7.2
OFFSET SETTINGS
± 5 °C
---
P7.3
CALIBRATION DATA
---
---
P7.4
SELECT RESOLUTION
0,1/0,01
0,01
P7.5
STABILITY FILTER
LOW-MED-HIGH
MED
P7.6
RESET SETTINGS
YES – NO
NO

12
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
P7.2 Offset settings
Enter into this menu to adjust the offset.
Note: enter in the menu only if the temperature probe is connected.
If menu P 7.2 is accessed without a temperature probe connected, the display will show an error
message: “CONNECT THE PROBE”, followed by the flashing of the icon .
Note: if the display shows the temperature of the channel 1, the Offset menu settings will be the
one of the channel 1. if the display shows the channel 2, enter to modify the offset of the channel
2. If the display shows the screen with both channels simultaneously, the user will select which
offset has to be modified: channel 1 or channel 2.
P7.3 Calibration data
Access this menu to get information about the last offset calibration performed.
The following screens will automatically scroll on the display (the view changes according to the one
selected):
Note: the message “NO CAL DATA” will be shown for each channel if the offset has been never
modified or a reset has been effected from the menu P7.6.
P7.4 Select resolution
Access to this menu to select the desired resolution for the temperature reading:
•0,1
•0,01 (Factory Default settings)
Note: changing the temperature resolution, the temperature resolution for both channels will
change too.
P7.5 Stability filter
To consider the reading of a value truthful, we recommend waiting for the measurement stability, indicated
by the icon . When the measurement is not stable, four red flashing bands appear on the
display. Access this menu to change the measurement stability criterion:
•Low: changes less than or equal to 3 hundredth of a degree, the stability icon is fixed and means that the
value is stable;
•Med: : changes less than or equal to 2 hundredth of a degree, the stability icon is fixed and means that
the value is stable;
•High: : changes less than or equal to 1 hundredth of a degree, the stability icon is fixed and means that
the value is stable.
View of the
Channel 1
View of the
Channel 2
View of the double
channel
First
screen:
Date and time of
the offset setting
for the channel 1
Date and time of
the offset
setting for the
channel 2
Date and time of
the offset setting
for the channel 1
Second
screen:
Set offset value for
the channel 1
Set offset value
for the channel
2
Set offset value for
the channel 1
Third
screen:
Date and time of
the offset setting
for the channel 2
Fourth
screen:
Set offset value
for the channel 2

13
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
P7.6 Reset settings
Access this Setup to reset the parameters of the Temp Settings menu.
The reset will restore all the parameters to the default settings shown in the table above.
Note: after the Reset is complete, the instrument returns to measure mode and all the parameters
return to their default settings.
Log Settings Menu
•In measure mode press to enter the SETUP menu;
•Press the key or to move to LOG SETTINGS P8.0 menu;
•Press the Key to enter the menu;
•Move with the keys and to select the desired program.
The table below shows the setup menu structure for the parameter and for each program the options that
the user can choose and the default value are listed:
Log settings Menu Configuration
Program
Description
Options
Factory Default Settings
P8.1
LOG TYPE
MANUAL / HOURS / MINUTES
MANUAL
P8.2
CLEAR DATA
YES / NO
NO
P8.1 Log type
Access this menu to select the data acquisition mode:
•MANUAL: The data is acquired only when the user presses the button .
•HOURS - MINUTES: Set a frequency range of automatic data acquisition.
With the direction keys move from MANUAL to HOURS or MINUTES. Access by pressing the key
and, as indicated by the icon change the value of the acquisition time. Confirm the setting with the
key .
Use of automatic Data Logger
In measure mode press the key to start or stop the automatic recording.
When the automatic data saving is running, the icon flashes.
When it is set, but not in operation, the icon on the screen remains fixed. When the 1000 total values are
reached, the recording stops automatically.
Note: Entering the Setup menu, the recording stops.
Note: if the recording is on, while on the display is shown the measure of the channel 1, only its
data will be saved. if the recording is on, while on the display is shown the measure of the channel
2, only its data will be saved. If the recording is on when both channels are shown, both channels
data will be saved.
P8.2 Clear data
Access this menu and select YES to clear the saved data. After that the instrument returns into measure
mode.

14
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Example of automatic Data Logger mode
Example: automatic recording of channel 1 on internal memory every 2 minutes.
•Connect the temperature probe only on channel 1;
•Access to the LOG SETTING P8.0 setup menu;
•Enter the LOG TYPE P8.1 menu, press the button and move with directional keys to MINUTES;
•Use the directional keys to change the number that flashes on the display. Enter "2" and confirm with
key .
•Return to measure mode.
The icon is on, which indicates that an automatic frequency Data Logger has been set.
Press to start recording; the icon starts flashing, indicating that the storage is in progress. The
number next to the M+ icon indicates how much data has been saved.
•Press again to end the recording and the icon returns fixed on the display.
Note: if the automatic switch off is activated, the instrument will turn off after 20 minutes.
For a longer recording is necessary to deactivate the auto-switch off P9.9.
Instrument configuration menu
•In measure mode, press button to access the SETUP menu;
•Press the key or to move to SETTINGS menu P9.0;
•Press the key to access the menu;
•Move with keys and to select the program to access.
The table below shows the setup menu structure for the instrument, for each program, there are the options
that the user can choose and the default value:
Configuration Settings menu
Program
Description
Options
Factory Default Settings
P9.1
TEMPERATURE UNIT
°C - °F
°C
P9.2
DATE AND TIME
---
---
P9.3
BACKLIGHT MODE
INDOOR / OUTDOOR / AUTO
AUTO
P9.4
BRIGHTNESS
LOW / MED / HIGH
MED
P9.5
SLEEP MODE
2 MIN / 5 MIN / OFF
2 MIN
P9.7
VIEW DIFFERENCE
YES / NO
NO
P9.8
RESET SETTINGS
YES / NO
NO
P9.9
AUTO OFF
YES / NO
YES
P9.1 Temperature unit
Access this setup menu to select the temperature unit to use: (°C - °F).
Note: by setting a different unit of measurement, the offset will be convert to the new measure unit. The
offset correction is shown when the instrument is turned on and in menu P7.3.
P9.2 Date and time setting
Access this setup menu to update the date and time of the device. Use the directional keys to change the
year, confirm with button and repeat the same operation for month, day, hours and minutes.

15
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
P9.3 Backlight mode
Access this setup menu to select the contrast mode to use for the display backlight:
•INDOOR (In) – Recommended if you use the device indoors;
•OUTDOOR (Out) – Recommended if you use the device outdoors;
•AUTO – Default option. Thanks to the brightness sensor, the display automatically adapts to the
environment conditions. This mode also ensures longer battery life.
P9.4 Brightness
Access this setup menu to choose between three different levels of display brightness:
•LOW – low;
•MEDIUM – medium;
•HIGH – high.
Note: Keeping the display bright always adversely affects battery life.
P9.5 Sleep mode
Access this setup menu to select whether and after how long activating the device Sleep mode:
•OFF: Sleep mode off.
•2 MIN: The instrument enters Sleep mode if no key is pressed for 2 minutes;
•5 MIN: The instrument enters Sleep mode if no key is pressed for 5 minutes.
When the device is in Sleep mode, the brightness of the display is reduced to a minimum, significantly saving
battery consumption.
Note: To exit from the Sleep mode and return the display to normal brightness, press ANY button.
Once the display brightness is activated, the buttons reacquire their function (paragraph "Key
function").
P9.7 View difference
Access this Setup to set how to view the temperature difference between the two channels as absolute
value. This difference will be shown in the middle of the display in the screen with double channel.
Note: the difference is shown also for recall of data saved, HOLD function, MAX/MIN recording
and recall of MAX/MIN value.
P9.8 Reset settings
Access this Setup to restore the parameters of Settings menu.
The reset takes all the parameters to the default settings shown in the table above.
Note: after the Reset, the instrument returns in measure mode and all the parameters return to
the default settings.
P9.9 Auto off
Access this setup menu to activate or deactivate the auto-shutdown of the instrument:
•YES: The instrument automatically turns off after 20 minutes of inactivity;
•NO: The instrument remains always on, even if you are not using it.
IMPORTANT: The correct and systematic use of parameters P9.3 / P9.4 / P9.5 / P9.9 allows to significantly
lengthen battery life.

16
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Temperature measurement
•Measurement
Always connect the probe before switching on the device.
•Press the key to turn on the instrument.
•After a self-diagnosis the instrument starts in measure:
- probe connected to channel 1: the instrument turns on in the screen of the temperature channel 1;
- probe connected to channel 2: the instrument turns on in the screen of the temperature channel 2;
- both probes connected: the instrument turns on in the screen with simultaneously temperature for
both channels.
•Place the probe/s in the measuring point and wait for the stability.
•When the reading is stable, the icon appears on the display. When the measurement is not stable,
four red flashing bands appear on the display. Always wait for measurement stability.
Note: if the probe is not connected, the message “CONNECT THE PROBE” appears, followed by the
flashing of the icon .
Note: connecting or disconnecting the probes, the instrument will automatically update the
measuring screen, to show the temperatures of the connected probes.
•MAX/MIN function
During the measurement, press the key to start the MAX/MIN values recording.
According to the number of probes connected and the screen on the display, a text string will flash:
•“MIN/MAX REC” 1 probe connected;
•“REC” both probes connected.
Press the key once to check the maximum value reached up to that moment, press it another
time to check the minimum value reached up to that moment. Pressing again, the instrument starts the
recording of the MAX/MIN value with the flashing string. To exit from the MAX/MIN recording, keep pressed
the key for at least 3 seconds, the flashing string disappears from the display.
Note: if the auto-switch off is activated, the instrument automatically switch off after 20 minutes
of inactivity. For a longer recording of the MAX/MIN values is necessary to deactivate the auto-
switch off P9.9.
Note: if some data are saved in the internal memory, the function MAX/MIN cannot be activated.
It is necessary to download the data on DataLink+ software or clear them.
•HOLD function
During measurement, keep pressed the key for 3 seconds to stop the reading. On the display, the
string HOLD appears and the reading stops. Keep pressed for 3 seconds to unlock the reading.
Note: during MAX/MIN (record and recall values) and HOLD functions, the icon indicates
that the measurement is stable. When the measurement is not stable, four red flashing bands
appear on the display.
Note: if some data are saved in the internal memory the function HOLD cannot be activated. It
is necessary to download the data on DataLink+ software or clear them.

17
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Other features
•Automatic switch-off
The instrument automatically turns off after 20 minutes of inactivity.
To deactivate the automatic switch off, enter the parameter P9.9 of the Setup menu and select Off.
•Offset adjustment
All the instruments are pre-calibrated from the factory and remain stable over time, but in case of a reading
error, it is possible to calibrate the device to clear that error.
To recalibrate the instrument at 0,0°C proceed as follows:
•Prepare some ice with double-distilled water;
•Put the ice cubes in a 500 ml beaker up to half of its volume;
•Add some double-distilled water to reach ¾ of its volume;
•Place the beaker over a magnetic stirrer under gentle agitation;
•Dip the probe in the beaker assuring it is well deep in the water and does not touch the sides of the
beaker;
•Cover the beaker with some polystyrene to isolate the mixture of water/ice from the air as much as
possible;
•Keep stirring for 10 minutes at least;
•Wait to reach the temperature of 0°C.
If the instrument reads 0,0°C (± Accuracy of the measuring range), then the device is working properly and
there is no need to calibrate it; on contrary, access the Setup menu P7.2, calibrate the value with the key
or and confirm with the key .
In the middle of the display, the correct temperature is displayed, while the partial value of the calibration
is displayed below it. The adjustment changes the entire measuring scale, for example if the calibration is -
1.0°C, then the measurement moves by -1,0°C over the whole scale.
In this way, the calibration is saved even after the instrument is switched off and after the replacement of
the batteries.
In case of sensor replacement, it is necessary to restore the factory calibration from the Setup menu P7.6,
and, if necessary, proceed with a new calibration.
Note: The offset cannot be modified, if it is not possible to change the offset.
The error string “CONNECT THE PROBE” appears followed by the flashing of the icon .
DataLink+ Software
It is possible to connect the instruments of the 70 Vio series to the PC and then use the DataLink software
to perform data download, Data Logger directly on PC and exports in Excel and PDF.
The software can be downloaded for free from the web site:
•https://www.giorgiobormac.com/it/download-software_Download.htm.
•Connect the USB cable inside each package to the USB port on the top panel of the instrument and the
other end to a COM port on the computer.
•Use the USB cable supplied with the instrument only.
•Start the program and then switch on the instrument.
•Wait for connection to be established (the connection data are shown at the bottom left of the display).

18
UM Termometri Temp70 PT100 Vio ENG rev.0 05.04.2021
Warranty
•Warranty period and limitations
•The manufacturer of this device and its accessories offers the final consumer of the new device the five-
year warranty from the date of purchase, in the event of state-of-the-art maintenance and use;
•During the warranty period, the manufacturer will repair or replace defective components;
•This warranty is valid only and exclusively on the electronic parts of the device and does not apply, if the
product has been damaged, used incorrectly, exposed to radiation or corrosive substances, if foreign
materials have penetrated inside the product or if changes have been made, which have not been
authorized by the manufacturer.
Disposal of electrical devices
This equipment is subject to the regulations for electronic devices. Dispose of in accordance
with local regulations.
