1 Welcome to coax XL-PBW224CW Integrated Access System 1
1.1 Recognizing XL-PBW224CW_ 1
1.2 XL-PBW224CW System Products 1
1.2.1XL-PB224C Terminal Products 2
Appearance of the products 2
1.1.2 Indicator 3
1.1.3 Ports 3
2 Connection 5
2.1Connect power and network 5
2.1.1 Connect network 5
2.1.2 Connect Power 6
3XL-PB224C Information Interface 7
3.1Login Page7
3.2 Bridge Page 8
3.2.1 Basic System Introduction 8
3.2.2 Bridge Systems to send and receive data packets statistics 9
3.2.3 IP Address distribution 9
3.3PLC Page10
3.3.1 PLC The basic configuration system information 10
3.3.2 PLC System Equipment style 11
3.3.3 PLC Flow Control Systems and Equipment 11
3.3.4 PLC Systems to send and receive data packets statistics 12
3.4 Ethernet Page 13
3.4.1 Ethernet link layer information 13
3.4.2 Ethernet Systems to send and receive data packets statistics 13
3.4.3 Ethernet Flow Control Systems and Equipment 13
3.5 Software Page 14
3.5.1 Current software version information 15
3.5.2 Delete procedures 15
3.5.3 Upload upgrade procedures 16
3.5.4 Change Keywords 16
3.6VLAN Page 17
4 Attachment 18
4.1Specification 18
4.1.1 Products specification 18

4.1.2
Environmental Characteristics
18
4.1.3 Application Characteristics
18
4.1.4 Manage and Maintain 19
4.1.5
Adjust Technology
19
4.1.6 Instruction and ports
19
4.2 Frequently Questions answer

1
1. Welcome to coax XL-PBW224CW Integrated
Access
System
1.1 Recognizing
XL-PBW224CW
Today's cable networks in households, by telephone twisted pair, power lines and
the
most common CATV coaxial cable. Also among the coaxial cable which, with its large
bandwidth, shielding is good, the high rate of households, business is rich in resource s
and become an ideal medium for broadband Inter net access. However, the existing
CATV HFC network is a one-wa y broadcast, in the rapid development of technology
and the dema nd today, as digital television, digital voice, online games, IPTV and
other emer ging business and promotion, the user demand for bandwidth keeps to
climb, one-wa y broadcast networks can not meet the new business
requirements,
upgrading the network will be inevitable. XL-PBW224CW in the existing HFC
network based on the construction of a residential area to meet the multi-user (MDU)
to use a new type of coaxial cable Integrated Access Ether net access technology. Its
working principle is to use existing coaxial cable network, in its RF spectrum to add
Ether
net data channels, without prejudice to the nor mal work of the existing CATV
system, not to the existing network of large-scale changes, the Data CATV signal and
the signal with the original transmission, for carrying IP-based data, voice and video
and other multimedia ser vices. The transfor mation of the less cost and engineering will
be the original one-way CATV network into a two-way, digital, and can carry
multimedia broadband networking platform.
Its advantages in
• the need to upgrade the current coaxial
network
• no need to re-erection of the new cable to the user's home
• able to provide the
sa me coaxial port RF video signals and Ether net business
• rapid establishment of a two-way interactive TV business communications
reverse
transmission channel
• Support for VoIP and IPTV and other IP ser vice access network for data transmission
XL-PBW224CW system to bring in the enjoyment of your video / data multiple
experience before you recognize your system XL-PBW224CW.
1.2 XL-PBW224CW system
products
XL-PBW224CW system includes headend equipment and terminal equipment. Its
power ful network carrying capacity makes a head-end equipment to support 31 or
63 or
even
127 * terminal equipment business. Their applications are as follows topology
*: The actual load with a concrete model version shall
prevail

2
1.1.1 XL-PBW224CW End
Products
Appearance

3
1.1.2
Indicator
Item Meaning Desctription
POWER Power Indicator Light Always have electricity, you can start using the
XL-PBW224CW.
System
System Indicator The system to start successfully.
Data
Data Indicator Successfully connected to the network. Flicker:There
are data transmission
Ethernet
LAN network
Interface
Indicator
LAN port connected to the network. Flicker: There are
data transmission.
1.1.3
Ports
Item Meaning Description
POWER Power port Input:100V～265V
Ethernet Network Port
10/100M Adaptive connected computer
RF IN TV Signal port Connect TV Signal
RF＋DATA OUT Synthesis of
signal output Connect terminal equipment
XL-PB224C terminal equipment connected diagram as shown above, insert the
power supply before you carefully read the manual on the "safe
Notes.
"

4
2
Connection
Before you begin using XL-PB224C before the installation of the
following:
2.1 Connect power and
network
2.1.1 Connect
network
XL-PB224C
XL-PB224C
XL-PB224C
Coax cable
XL-PBW224CW
Coax Cable
Ethernet cable
CATV
Centre
Network
Access
2 . 1 . 2 Connect t he power
1.In this step, please confirm your power connector and the power outlet XL-PBW224CW
line voltage and current at the sa me time is also in line with XL-PBW224CW work.
2. The
excha nge received a power outlet plugs, XL-PBW224CW to boot.
3. Boot after the POWER indicator light, about 10 seconds after the System
indicator
will begin to flicker, the system began to self-test, and then after about 10 seconds, such
as monitoring systems are completed and
nor mal, System indicator will Always.
4. At this point in accordance with the network if you have completed these steps,
both
through the terminal equipment (XL-PB224C) watching television or sur fing the Inter net.

5
3 XL-PBW224CW Information Interface
XL-PBW224CW easy to set up, simple operation, users do not need to
carry
out any operation . XL-PBW224CW random will be attached to one
for
the equipment condition monitoring of private IP addresses, you can use
a
web
browser through the IP address of the page to enter the state of the state
of
obser
vation equipment .
3.1 Login
Page
(In this case to use the IE browser, IP address 192.168.2.1 as an example), enter in the address bar
192.168.2.1, landing interface appears, enter your user name (admin) and password (admin), as
shown in Figure 3-1
Pic 3-1

6
3.2 Bridge
Page
Pic 3-2-1
3.2.1 The basic configuration system
information
Pic3-2-2

3.2.2 BridgeSystems to send and receive data packets statistics
7
Pic3-2-3
3.2.3 IP Address
distribution
Pic3-2-4

3.3
PLC Page
8
Pic3-3-1
3.3.1 PLC System Equipment
Information
Pic3-3-2

3.3.2 PLC System Equipment style
13
Pic3-3-3
3.3.3 PLC Flow Control Systems and
Equipment
Click on "TC
ACTIVE"
In the "Rate" column need to limit the rate of
input
Click "Save Configuration" button to
save
Pic3-3-4

3.3.4 PLC Systems to send and receive data packets statistics
14
Pic 3-Pic-5
3.4 Ethernet
Page
Pic 3-Pic-1

3.4.1 Ethernet link layer information
15
Pic 3-Pic-2
3.4.2 Ethernet Systems to send and receive data
packets
statistics
Pic 3-Pic-3

3.5.1 Current software version information
16
Click on "TC ACTIVE"
In the "Rate" column need to limit the rate of
input
Click "Save Configuration" button to
save
Pic 3-Pic-4
3.5 Software
Page

3.5.1 Current software version information
17
Pic 3-Pic-2
3.5.2 Delete
procecures
Backup software to choose a
name
Click Remove
button .
Pic 3-Pic-3

3.5.3
Upload upgrade procedures
18
Enter promotion procedures need to upload the file name
Enter FTP
ser ver IP address
Enter the display name in the
machine
Click
" send " button
图 3-Pic-4
3.5.4 Change Keywords
Enter the need to amend the new
password
Re - enter new password to confirm

19
Pic 3-Pic-5
3.6 VLAN
Page
Enter the need for the VID, click
" add " button to add a VLAN
Pic 3-Pic

20
4 Attachment
4.1
Specification
4.1.1 Products
Specification
Item XL-
Network standard
IEEE802.3、IEEE802.3u
Link standard
IEEE HomePlug BPL
Physical layer bandwidth
224Mbps
Data throughput
Exclusive or shared 50Mbps
Work of the band
2－30MHz
work of a frequency bandwidth
Single Frequency 28MHz，
Broadband multi-carrier
number
7 (Wavelet) X128 (carrier) = 896 (Carrier)
Communication
frequency division duplex / full-time
Security
-45dBuV
Network tolerance of the
attenuation
70dB (0-60dB range of the average throughput of 50Mbps,
70dB at 35Mbps)
Output
110－135dBuV
Transmission media and
impedance
TV Cable 75Ω
Power supply
AC 100V～265V
4.1.2
E n v i r o n m e n t a l C h a r ac t e r i s t i c s
Temperature
-10—55'C
Working humidity
10%--90%
4.1.3
A pp l i ca t i o n C h a r ac t e r i s t i c s
Security VLAN (IEEE802.1Q) to ensure security and to reduce regional
broadcasting
QoS
QoS (802.1p) priorit y to provide multimedia applications and
bandwidth management
