Xtool X-Series User manual

X-Series Service Tool
User Manual

X-Series Service Tool
1
Trademark：
is the registered trademark of Shenzhen Xtooltech Co., Ltd. In
countries that the trademarks, service marks, domain names, logos and the name of
the company are not registered, Xtool claims that it still reserves the ownership of
the unregistered trademarks, service marks, domain names, logos and the company
name. All other marks for the other products and the company’s name mentioned
in the manual still belong to the original registered company.
Copyright：
You may not use the trademarks, service marks, domain names, logos and company
name of Xtool or other companies mentioned without written permission from the
trademark holder.
Responsibility：
Xtool shall not be liable for any incidental or consequential damages or for any
economic consequential damages arising from the accidents of individual users and
the third parties, misuse or abuse of the device, unauthorized change or repair of
the device, or the failure made by the user not to use the product according to the
manual.

X-Series Service Tool
2
After sale：
After-Sale Service Hotline[phone])
Email: [email protected]
Official website:http://www.xtooltech.com
Safety：
This product is intended for automotive technicians only.
When the engine is running, please keep the maintenance area well
ventilated, properly connect the engine and the building's exhaust system.
The carbon monoxide generated by the engine will cause the body to be
unresponsive and even cause serious personal injury or death.
Wear ANSI-compliant goggles and keep clothing, hair, hands, tools,
diagnostics, etc. away from running or hot engine parts.

X-Series Service Tool
3
Contents
CHAPTER I ABOUT MAINFRAME .........................................................4
1.1 PRODUCT OVERVIEW.........................................................................4
1.2APPEARANCE ....................................................................................5
1.3 TECHNICAL PARAMETERS OF EQUIPMENT..........................................6
CHAPTER II HOW TO USE ...........................................................7
2.1 FUNCTIONAL SELECTION OF HOME PAGE .........................................7
2.2 SPECIAL FUNCTIONS .........................................................................9
2.3 SYSTEM SETTINGS ..........................................................................10
CHAPTER III SOFTWARE UPGRADING .....................................16
3.1 WIFI ONE-CLICK UPGRADE............................................................16
3.2 USB DATA WIRE UPGRADE ..............................................................18

X-Series Service Tool
4
Chapter I About Mainframe
1.1 Product overview
X300P and X100Pro2 are service tools for special functions of automobiles
produced by Shenzhen Xtooltech CO., LTD .
X300P includes maintenance reset, EPB replacement, OBD II, tooth learning,
BMS battery replacement, TPS throttle relearn, tire pressure reset, electronic
steering matching, ABS bleeding function and so on.
X100Pro2 includes key programming and dashboard recovery.
These two equipments is anti-seismic and durable which can meet the actual
needs of different users such as automobile repair plants and fast repair shops.

X-Series Service Tool
5
1.2 Appearance
①LCD display
Display product function menu
②Return
Cancel the selection or return to
the previous menu
③Direction key
Up/Down: Move the menu
up/down in menu mode;
Left/Right: You can view
information on the front/next
screen.
④Trigger
WIFI Connection Key

X-Series Service Tool
6
⑤DB15 connector
Connect X300P/X100Pro2 to
OBD II Port of vehicle
⑥assist
Providing assist information
⑦OK
Confirm selection
⑧USB interface
Connect X300P/X100Pro2 to
computer for software updates
⑨Reserved key
1.3 Technical parameters of equipment
Monitor：
320x480 dpi TFT color display screen
Working voltage：
9V-18V
Working temperature：
-10℃-60℃
Storage temperature：
-20-70℃
Appearance size：
200×92×33mm
Weight:
0.35kg

X-Series Service Tool
7
Chapter II How to Use
2.1 Functional Selection of Home Page
Use the up/down key and left/right key to switch, select the corresponding function
and click OK to enter.
(X300P)

X-Series Service Tool
8
(X100Pro2)

X-Series Service Tool
9
2.2 Services
Select services, you can select special functions bypressing up/down key, pressOK
key to enter.
(X300P)
For X100Pro2, you can directly enter Immobiliser, dashboard, eeprom or OBDII
menu directly from the home page.

X-Series Service Tool
10
2.3 System Settings
Select options to enter, you can choose WIFI settings, language settings, unit
settings, software upgrades by up/down keys.

X-Series Service Tool
11
2.3.1 WIFI settings
Enter the WIFI settings, click OK to open the WIFI switch, connect the WIFI, click
OK to enter the password, and then press the trigger button to connect, as shown
below.

X-Series Service Tool
12
2.3.2 Language settings
The operating system of this device supports multi-language switching: English,
Spanish, French, Portuguese, German, Russian, Polish and Italian. Select the
language you need by pressing the up/down button and switch by pressing the OK
key, as shown below.

X-Series Service Tool
13
2.3.3 Unit settings
According to the demand, select Metric or British system by up/down key and
switch by OK key, as shown below.

X-Series Service Tool
14
2.3.4 Tip sound settings
According to the requirement, select whether to open the button prompt tone by
up/down key, and switch by OK key, as shown below.

X-Series Service Tool
15
2.3.5 About
On the page, you can view the current software version and hardware version
number.

X-Series Service Tool
16
Chapter III Software Upgrading
3.1 WIFI One-click Upgrade
The product supports one-click upgrade through WIFI upgrade. The upgrade
module can be selected by up/down keys or all modules can be upgraded by one-
click, and can be returned by pressing the return key.

X-Series Service Tool
17

X-Series Service Tool
18
3.2 USB data wire upgrade
The product supports the upgrading of computers through USB connection, and
downloads the upgrade program to upgrade the equipment according to the prompt
information.
The upgrade method is as follows.
1. Log on the Xtool official website: www.xtooltech.com, Select ’Download
Upgrade Tool’ on the page of ‘Service&Support’, and install the upgrade tool.
2. Open the upgrade software, enter the product serial number and activation code
to log in the software.
3. Connect the X300P/X100Pro2 handheld device to the computer through the USB
cable.
4. When the X300P/X100Pro2 handheld device is turned on, the computer software
will automatically connect the device and log in.
5. Select installation items for computer software to upgrade procedures.
6. Disconnect the USB cable and restart the X300P/X100Pro2 handheld device to
start using the upgrade software.
