Xview XV4KDVR User manual

XV4KDVR
USER MANUAL
xviewdrive.com.au
for more information on
the Xview range go to
our website
VIEW
INCLUSIONS:
Dash Cam, GPS power cable, camera mount, charger,
USB cable, memory card

2
1. PRODUCT PICTURE AND FUNCTIONS
1) Lens
2) Speaker
3) Touch Screen
1
2
3

3
NOTE: Car camera supports up to 128GB Micro SD card.
Class 10 Micro SD card is required.
4 5
6 7
8
9
4) Mini USB input
5) Mounting Slot
6) Microphone
7) Reset hole
8) POWER Button
9) Micro SD Card Slot

4
2. INSTALLATION
2.1 Insert Micro SD card into the Dash Cam
2.2 Attach the mounting bracket to the Dash Cam by sliding
the mount into the mounting slot of the Dash Cam
2.3 Check position of the Dash Cam before fixing the camera
on the inside surface of the windshield. The area near the
rear-view mirror is suggested. (See installation diagram).
Make sure the windscreen is clean and free of debris. Use
an Alcohol wipe to enhance adhesion. Remove the tape off
the adhesive mount and adhere to the windshield holding in
position for 60 seconds
2.4 Insert the Mini USB end of the GPS power cable into the
Mini USB Power socket/ charging point of the Dash Cam.
Remove backing off 3M tape of GPS cable and fix to
window. For a better GPS signal ,make sure the 3M sticker
faces toward the sky and is not blocked or obstructed.
Connect USB charging end of the GPS power cable into
12/24V power socket of vehicle
2.5 Adjust the mounting bracket and rotate the camera
direction to get the best view.
2.6 Turn vehicles ignition to accessories and the Dash Cam
will power ON and start recording automatically. An audible
tone will heard once powered.
2.7 The recording indicator light will start flashing RED on the
screen and a will appear when recording has started.
2.8 For the Dash Cam to work it must receive power from
the charging adapter. Once power is removed or turned off
the Dash Cam will save the current file and turn off.

5
3. INSTALLATION DIAGRAM
INCLUSIONS:
Dash Cam, GPS power cable, camera mount, charger,
USB cable, memory card
Suggested
GPS
NOTE: The Dash Cam GPS power cable must be used
to retain date and time settings.

6
4. SCREEN FUNCTIONALITY
4.1 When connected to power the Dash Cam will
automatically turn on. Once power is disconnected it will
automatically turn off.
4.2 To turn the Dash Cam on or off manually, press and hold
the button.
4.3 The indicator light on the side of the Dash Cam
illuminates blue when charging. Once fully charged it will turn
off.
4.4 The indicator light on the side of the Dash Cam flashes
red when its recording
4.5 A red circle also flashes on the screen of the Dash Cam
when its recording
4.6 When you touch the screen it reveals 5 icons on the
bottom of the screen.
4.7 Touch the video icon to stop and start recording
4.8 Touch the camera icon to take a picture
4.9 When in recording mode touch the lock icon to lock and
unlock current recording file
4.10 When not in recording mode touch the playback icon to
play or view video and picture files
4.11 When not in recording mode touch the settings icon
icon to display Dash Cam settings

7
5. DASH CAM SETTINGS MENU
Settings can only be accessed when not in recording mode
5.1 Video Resolution
5.2 Photo Resolution
5.3 Loop recording
5.4 Exposure
5.5 WiFi
5.6 Parking Monitor
5.7 G Sensor
5.8 Screen Save
5.9 Language
5.10 Beep Sound
5.11 Record Audio
5.12 Frequency
5.13 Delayed Power Off
5.14 GPS
5.15 Time Zone
5.16 Speed Unit
5.17 Daylight Saving
5.18 Date/Time
5.19 Format
5.20 Default Setting
5.21 Version

8
6. VIDEO AND PHOTO PLAYBACK
Playback Mode:
Touch the playback symbol to display all video or photos
taken. Use the [UP] and [DOWN] arrows to scroll through
files. Touch the file thumbnail to view or playback. Icons will
appear at the bottom of the screen to return to previous
screen, previous file, next file, delete or play.
Protected files:
The thumbnail will have a red warning triangle icon. When you
select the file for playback a key symbol will appear at the top
of the screen.
7. ACCESSING FILES VIA YOUR COMPUTER
8. RESETTING THE DASH CAM
To access video and images from your Dash Cam, connect
the USB cable to your computer. Two options will appear on
the Dash Cam screen. Select Mass storage and a folder
called “Untitled” will appear on your computer. Select PC
camera to use Dash Cam as a web cam. Or alternatively
remove the SD card from the Dash Cam and the SD card into
a card reader to connect to your computer.
Inside this folder will be 3 folders:
Movie folder: recorded movie files (MP4)
Photo folder: picture files (JPG)
EMR folder: locked/Gsensor movie files (MP4)
Insert a pin into the reset hole on the bottom the Dash Cam
and press in with the Dash Cam turned on.

9
9. CONNECTING TO WIFI & USING THE APP
Recording video, taking photos, live streaming, GPS data,
download files and changing Dash Cam settings can all be
done via WiFi and downloading the ‘Xview XV4kDVR’ APP.
For iPhones search the APP Store or for Android devices via
Google Play.
9.1 To pair the Dash Cam with your smartphone, go into the
settings menu on your Dash Cam and turn Wifi on.
9.2 The Dash Cam will display the SSID name and password
to connect to your phone.
9.3 Then go to your WiFi settings on your smartphone, turn
WiFi on and it should display all devices for connection.
9..4 Select your Dash Cam model SSID name.
9..5 Enter the password 12345678.
9.6 Once successfully paired to your DASH CAM the display
will say WiFi Connected
9.7 Then launch the ‘Xview XV4kDVR’ Dash Cam APP to
access functions.
9.8 Once connection is successful, the indicator light on the
side of your Dash Cam turns red.
9.9 What files do you need to download to use in the App

10
10. USING GPS FUNCTION
To use the GPS function, the GPS antenna module must be
plugged into the Dash Cam. The GPS functionality will not be
available with the Dash Cam if removed.
Notes: For a better GPS signal ,make sure the 3M sticker
faces toward the sky and is not blocked or obstructed.
10.1 For GPS data go into the settings menu on your Dash
Cam and turn GPS on.
10.2 This function is only valid when the external GPS module
is connected. After the external GPS is connected, this
function can be turned on to record, store and output data of
the driving speed, time, mileage and other state information of
the car.
10.3 When activated a GPS symbol will appear on screen and
flash, until it receives a signal then it will turn green
10.4 To view the GPS map using the mobile phone APP, you
need to download the video file in the Dash Camera to the
mobile phone for normal viewing.
10.5 You can also download a free GPS player for your
computer to display data at:
http://www.goodcam.net/download/GPSPlaySetup.zip

11
11. INTERNAL BATTERY
The internal battery is small and only designed to provide
enough power to securely save the last recording when power
is disconnected and to retain date and time settings. The
Dash Cam is designed to be connected to power at all times
when operating. If the Dash Cam is not used for an extended
period of time the battery may become completely discharged
which will cause the time and date on the device to default to
the factory settings. If this occurs please completely recharge
the Dash Cam before use.
12. FORMATTING THE SD CARD
It is advisable to format the card weekly if you have the
Gravity Sensing (Gsensor) setting turned on, or create locked
files. This will fill up the card causing it to stop recording any
footage.
13. LOCKING VIDEO FOOTAGE
Whilst recording, press the lock icon on the Dash Cam screen
to activate the lock footage function. A key icon will display on
the screen. This will lock the file currently being recorded to
prevent it being recorded over. Press lock icon again to
unlock footage.

12
15. USER SUPPORT
If you need assistance setting up or have an issue regarding
the use of your Xview product contact Xview Customer
Support.
Australian Agent
TEL: 03 – 8587 8898 FAX: 03 – 8587 8866
Mon-Fri 9am – 5pm AEST
Please retain this user guide for future reference.
For more information, manuals, software or other products in
the Xview range please go to our website.Xviewdrive.com.au
This manual is considered correct at time of printing but is
subject to change. For latest manuals and updates refer to
the website.
14. SPECIFICATION
Display: 3.0" High-resolution LCD touch screen
Video information: 4K 3840*2160 @30fps, *.MP4
Photo information: 3648*2736, *.JPG.
Storage: Supports Micro SD Card Class10 up to 128GB
Viewing Angle: 160 degree
Functions: WiFi, GPS, G-Sensor, Loop recording &
Parking Monitor
Audio: Built-in Microphone and speaker
OSD Language: Multiple
Input / Output: Mini USB (Power)
Car charger: DC input: 12 or 24V, output: 5V

13
16. TROUBLE SHOOTING
Problem: The adhesive mount will not stay attached to the
windscreen
Solution: • Ensure windscreen is clean and free of debris,
use glass cleaner or an alcohol swab to clean.
• Ensure that the plastic film has been removed from the
adhesive pad.
• When mounting hold the bracket firmly to the windscreen for
at least 60 seconds.
Problem: The Dash Cam will not power on
Solution: • Vehicle Accessory Socket - Check the vehicle
accessory socket has power, simply plug another device and
see if it powers up (or use a test light / multimeter to check for
power).
• Dash Cam Power Cable - Check the fuse in the tip of the
accessory plug, it may need to be replaced.
• Dash Cam - Connect the Dash Cam to a computer via the
USB cable to see if it powers up.
Problem: The Dash Cam shuts down when connected to the
vehicle and the battery will not charge
Solution: • The battery will only charge while the vehicle is
switched on.
• If the vehicle is not frequently used the Dash Cam battery
will fully discharge and may need to be connected to a
domestic USB charger (such as a smartphone charger) for
approximately 3 hours to fully charge.
Problem: The Dash Cam battery only lasts for a few minutes
when power is disconnected
Solution: • This is normal. Batteries in Dash Cams only hold
enough power to safely shut down the Dash Cam, securely
save the last file when power is disconnected and retain
settings.
• The Dash Cam is designed to be connected to power at all
times while being used.

14
Problem: The time & date settings reset every time the Dash
Cam is powered on
Solution: • The time and date settings will reset when the
Dash Cams battery is flat. Make sure the Dash Cams battery
is fully charged in order to retain the time and date settings.
Problem: The Dash Cam menu cannot be accessed
Solution: • While the Dash Cam is recording the Menu can
not be accessed. Stop recording before pressing the Menu
button.
Problem: The Dash Cam screen turns off after a few minutes
when the Dash Cam is powered on
Solution: • Dash Cams have an automatic screen saver
feature. This helps reduce heat in the Dash Cam and also
makes the Dash Cam less distracting to the driver.
• If you prefer the screen remain on, this can be changed in
the Dash Cam settings under “Screen Saver”.
Problem: The Dash Cam feels warm when it is operating
Solution: • It is normal for the Dash Cam to feel warm to the
touch during typical use, especially when it is recording HD
video.
Problem: The Dash Cam stops automatically while recording
Solution: • Check to see whether there is enough space on
the Micro SD card.
• Ensure correct Micro SD card is being used, 8-32Gb Class
10 or above Micro SDHC is recommended. Other types of
Micro SD cards may not be suitable for use in Dash Cams.
• If the correct Micro SD Card is being used, format the Micro
SD Card in a computer.
• Micro SD cards have a limited lifespan and become corrupt
after a period of time, due to the continuous loop recording
function. If this has occurred replace you Micro SD Card.

15
Problem: The Micro SD card is not recognised by the Dash
Cam
Solution: • Format the Micro SD card before using. Be sure the
Micro SD card is compatible with the device, see “Stops
automatically while recording” fault.
Problem: The Dash Cam will not record video or take pictures
Solution: • Check to see whether there is enough space on the
Micro SD card. If not, the Micro SD card will need to be
formatted.
Problem: Video files can not be played on the PC
Solution: • The video files from the Dash Cam are in .MP4
format and may not be compatible with your PC if suitable
playback software is not installed.
Problem: My videos are blurry, dirty or discoloured
Solution: • Check to see if there are any finger prints or dirt
present on the camera lens. If needed, clean with a soft dry
cloth before recording.
• Also be sure to have removed the transparent lens cover
during installation.
Problem: The Dash Cam is frozen or not responding
Solution: • Reset the unit by inserting a pin into the reset hole,
push and hold the reset button for a few seconds and try again.
• Format Micro SD Card in a computer.
Problem: Unresolved issues
Solution: • Reset the unit by inserting a pin into the reset hole,
push and hold the reset button for a few seconds and try again.
• Format Micro SD Card in a computer.
• Contact Xview Technical Department

16
If you need assistance setting up or have an issue regarding
the use of your Xview product contact Xview Customer
Support.
Australian Agent
TEL: 03 – 8587 8898 FAX: 03 – 8587 8866
Mon-Fri 9am – 5pm AEST
Please retain this user guide for future reference.
For more information, manuals, software or other products in
the Xview range please go to our website.Xviewdrive.com.au
This manual is considered correct at time of printing but is
subject to change. For latest manuals and updates refer to
the website.
17. SAFETY INFORMATION & WARNINGS
Do not use the Dash Cam in damp working conditions; the
Dash Cam is not waterproof.
Do not try opening the shell or trying to repair the Dash Cam
by yourself. If the accessories for the Dash Cam have any
problems, please take it to an authorised repair agent for
repair.
Do not use a chemical substance, cleaning solvent or cleaner
to clean the Dash Cam, please use a moist soft cloth if you
would like to clean the Dash Cam.
Do not use the Dash Cam under conditions where dust is
present.
Use a moist soft cloth to clean the lens before use, to avoid
poor video footage.
Xview is NOT responsible for the loss of any recorded video
during operation. Although designed to withstand high impact
of car collision.
Xview does NOT guarantee recording of accidents where the
impact may cause the device to be damaged.
