9465/9465KPM
PC/ATFlat Panel
Industrial Computer
P/N 118369-001E
1998 XYCOM, INC. Printed in the United States of America
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Xycom Revision Record
Revision Description Date
A Manual Released 5/97
B Manual Updated 9/97
C Manual Updated 1/98
D Manual Updated 8/98
E Pentium II updates 11/98
Trademark Information
Brand or product names are registered trademarks of their respective owners.
Windows is a registered trademark of Microsoft Corp. in the United States and other countries.
Copyright Information
This document is copyrighted by Xycom Incorporated (Xycom) and shall not be reproduced or copied without expressed written
authorization from Xycom.
The information contained within this document is subject to change without notice. Xycom does not guarantee the accuracy of the
information and makes no commitment toward keeping it up to date.
United States FCC Part 15, Subpart B, Class A EMI Compliance Statement:
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
For European Users:
WARNING
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
INSTALLATION: Electromagnetic Compatibility WARNING
The connection of non-shielded equipment interface cables to this equipment will invalidate FCC EMI and European Union EMC
compliance and may result in electromagnetic interference and/or susceptibility levels which are in violation of regulations which
apply to the legal operation of this device. It is the responsibility of the system integrator and/or user to apply the following
directions which relate to installation and configuration:
1. All interface cables must include shielded cables. Braid/foil type shields are recommended. Communication cable connectors
must be metal, ideally zinc die-cast backshell types, and provide 360 degree protection about the interface wires. The cable
shield braid must be terminated directly to the metal connector shell, ground drain wires alone are not adequate.
2. For systems other than Pentium II logic board (AHIP6+): In those cases where an external mouse is used, the snap-on ferrite
bead provided (P/N 116046) must be installed on the mouse cable at the host end in order to comply with relevant EMI
regulations.
3. Protective measures for power and interface cables as described within this manual must be applied. Do not leave cables
connected to unused interfaces or disconnected at one end. Changes or modifications to this device not expressly approved
by the manufacturer could void the user’s authority to operate the equipment.
4. EMC compliance is, in part, a function of PCB design. Third party add-on AT/XT peripheral PCB assemblies installed within
this apparatus may void EMC compliance. FCC/CE compliant PCB assemblies should always be used where possible.
XYCOM can accept no responsibility for the EMC performance of this apparatus after system integrator/user installation of
PCB assemblies not manufactured and/or expressly tested and approved for compliance by XYCOM. It is the responsibility of
the system integrator/user to ensure that installation and operation of such devices does not void EMC compliance.
xycom
Technical Publications Department
750 North Maple Road
Saline, MI 48176–1292
734-429-4971 (phone)
734-429-1010 (fax)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
i
Table of Contents
Chapter 1 – Introduction..........................................................................................................................1-1
Product Overview..................................................................................................................................................1-1
Standard Features...................................................................................................................................................1-1
With AHIP5+ board............................................................................................................................................1-1
With AHIP6+ board............................................................................................................................................1-1
On all units..........................................................................................................................................................1-1
Optional Features...................................................................................................................................................1-2
Unpacking the System ...........................................................................................................................................1-3
Quick Start-up........................................................................................................................................................1-4
Chapter 2 – Testing..................................................................................................................................2-5
Preparing for the Tests...........................................................................................................................................2-5
Running the Tests ..................................................................................................................................................2-7
Chapter 3 – Installation............................................................................................................................3-1
System Components...............................................................................................................................................3-1
9465 Front Panel....................................................................................................................................................3-1
9465KPM Front Panel...........................................................................................................................................3-3
I/O Panel................................................................................................................................................................3-5
Back Panel.............................................................................................................................................................3-7
Bottom Panel .........................................................................................................................................................3-7
Power Panel...........................................................................................................................................................3-8
Installation Options................................................................................................................................................3-9
Internal Hardware Options.....................................................................................................................................3-9
DRAM and Additional DRAM Single In-Line Memory Modules (SIMMs)......................................................3-9
PC/AT or PCI Boards.........................................................................................................................................3-9
External Hardware Options..................................................................................................................................3-10
Externally Mounted Floppy Drive ....................................................................................................................3-10
Front Access Keyboard and Floppy Connectors...............................................................................................3-12
Serial AUX .......................................................................................................................................................3-14
Creating a Custom Logo......................................................................................................................................3-14
9465..................................................................................................................................................................3-14
9465KPM..........................................................................................................................................................3-14
Creating Custom Keypad Inserts (9465KPM only) .............................................................................................3-15
Installing Operating Systems ...............................................................................................................................3-17
Installing Drivers .................................................................................................................................................3-18
Ethernet Drivers...................................................................................................................................................3-18
Video Drivers ......................................................................................................................................................3-19
Touchscreen Drivers............................................................................................................................................3-19
CD-ROM Drivers ................................................................................................................................................3-19
Miscellaneous Drivers .........................................................................................................................................3-19
Using a Touchscreen............................................................................................................................................3-20
Using a Pointing Device with a Touchscreen ......................................................................................................3-21
Specifying the Port...............................................................................................................................................3-21
Calibrating the Touchscreen................................................................................................................................3-21
Video Expansion..................................................................................................................................................3-21
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
ii
Mounting Considerations.....................................................................................................................................3-23
Enclosures............................................................................................................................................................3-24
System Power ......................................................................................................................................................3-24
Excessive Heat.....................................................................................................................................................3-25
Electrical Noise....................................................................................................................................................3-25
Line Voltage Variation ........................................................................................................................................3-26
Creating a Power Cable .......................................................................................................................................3-26
AC Power Cable ...............................................................................................................................................3-26
Cable Retainer Bracket .....................................................................................................................................3-28
DC Power Cable ...............................................................................................................................................3-28
Mounting the Unit................................................................................................................................................3-29
System Cutout Dimensions..................................................................................................................................3-30
Hazardous Locations Installations.......................................................................................................................3-30
Definitions ...........................................................................................................................................................3-32
Class I Locations...............................................................................................................................................3-32
Class II Locations .............................................................................................................................................3-32
Division 1 Locations.........................................................................................................................................3-32
Division 2 Locations.........................................................................................................................................3-33
Groups...............................................................................................................................................................3-33
Power Switch.......................................................................................................................................................3-33
Cable Connections...............................................................................................................................................3-34
Operation and Maintenance.................................................................................................................................3-34
Safety Agency Approval......................................................................................................................................3-35
Chapter 4 – Keypad Utility Program (9465KPM)....................................................................................4-1
Loading the Keypad Utility....................................................................................................................................4-1
Using the Keypad Utility.......................................................................................................................................4-1
Startup....................................................................................................................................................................4-2
Utility Batch Mode ................................................................................................................................................4-2
Main Menu.............................................................................................................................................................4-2
Exit ........................................................................................................................................................................4-2
Files Menu.............................................................................................................................................................4-2
Macros Keypad Type Menu...................................................................................................................................4-3
Macros Edit Menu .................................................................................................................................................4-4
Upload Menu.........................................................................................................................................................4-5
Download Menu ....................................................................................................................................................4-6
Utilities Menu........................................................................................................................................................4-6
Keypad Scan Codes...............................................................................................................................................4-6
Chapter 5 – Maintenance.........................................................................................................................5-1
Preventive Maintenance.........................................................................................................................................5-1
Fuse Replacement..................................................................................................................................................5-1
Fan Filter Replacement..........................................................................................................................................5-2
Chemical Compatibility.........................................................................................................................................5-2
Compatible Lubricants...........................................................................................................................................5-3
Compatible Cleaning Agents .................................................................................................................................5-4
Noncompatible Cleaning Agents ...........................................................................................................................5-4
Spare Parts List......................................................................................................................................................5-4
Product Repair Program/Returning a Unit to Xycom ............................................................................................5-6
Appendix A – Technical Specifications................................................................................................A-1
Hardware Specifications....................................................................................................................................... A-1
Environmental Specifications ............................................................................................................................... A-2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 1– Introduction
iii
Appendix B – Block Diagrams...............................................................................................................B-1
Appendix C – Pinouts.............................................................................................................................C-1
Keyboard Port Connectors.....................................................................................................................................C-1
Aux Port Connector ...............................................................................................................................................C-1
Dual USB Connector (USB1)................................................................................................................................C-1
Parallel Port Connector (LPT1).............................................................................................................................C-2
Serial Port Connectors...........................................................................................................................................C-2
COM1....................................................................................................................................................................C-2
COM2....................................................................................................................................................................C-3
VGA Connector.....................................................................................................................................................C-3
External Floppy Connector....................................................................................................................................C-4
Appendix D – Replacing Flat Panel Display Bulbs..............................................................................D-1
Sharp 15-inch TFT Flat Panel Display (#LQ15X01W)....................................................................................... D-1
Kyocera 15-inch STN Flat Panel Display (#KCT10276BSTT) ........................................................................... D-3
Sharp 13.8-inch TFT Flat Panel Display (#LQ14X03)........................................................................................ D-4
Kyocera 12.1-inch STN Flat Panel Display (#KCB8060BSTT) .......................................................................... D-5
Sharp 12.1-inch TFT Flat Panel Display (#LQ12S41) ......................................................................................... D-7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1-1
Chapter 1 – Introduction
Product Overview
The 9465 and 9465KPM PC/AT™flat panel industrial computers combine a PC/AT
computer with a flat panel display to offer a powerful, compact package for the factory
floor and other harsh environments. The 9465 and 9465KPM feature an open architec-
ture to meet a wide variety of applications that require both a powerful PC and a durable
industrial front panel. The systems integrate a computer card cage, mass storage, display,
and power supply in a truly industrial form.
The 9465 is a PC/AT with a display only (touchscreen optional). The 9465KPM is a
PC/AT with a display, integrated keypads, and an integrated mouse.
The front panels of both systems are sealed to NEMA 4/4X/12, and the flat panel display
is protected by an impact-resistant shield.
The system’s modular design allows easy access to expansion boards, jumpers, power
supply, flat panel display, and disk drives.
Standard Features
With AHIP5+ board
•Pentium® technology
•PCI 64 bit video controller, 2 MB video RAM
•PCI local-bus IDE controller
•Two 72-pin EDO DRAM SIMMs that support 8, 16, 32, 64, and 128 MB options
With AHIP6+ board
•Celeron ® or Pentium II technology
•PCI 64 bit video controller, 2 MB video RAM
•PCI local-bus IDE controller
•Two 168-pin SDRAM DIMMs that support 32, 64, 128, and 256 MB options
•Two USB ports
•100MHz front side bus with Pentium II processors
On all units
•Two serial COM ports
•RS-232
•RS-232 or RS-485
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
1-2
•Flat panel display
•15-inch STN flat panel, 1024x768 resolution (9465)
•12.1-inch STN flat panel, 800x600 resolution (9465KPM)
•Parallel port
•VGA port
•Flash BIOS
•9-inch mounting depth
•3.5-inch internal, side access floppy drive
•Six AT-bus full-length expansion slots
•Four ISA slots
•One ISA or PCI slot
•One PCI (4.8” maximum length with AHIP6+ board)
•IR Port (IrDA and ASKIR compatible)
•Rear PS/2 keyboard port and AUX port (also a front PS/2 keyboard port on
9465KPM)
•Status LEDs
•Power
•Disk
•Com
•Input
•3.5-inch internal IDE hard drive
•MS-DOS®
•Front panel sealed to meet NEMA 4/4X/12 specifications when panel mounted in a
suitable fire and electrical enclosure.
•Approved for use in Class I, Division 2 hazardous locations
•Autosensing AC power supply
•Side power connector with retainer bracket
Optional Features
•Touchscreen—resistive technology with less than 1.5% linearity error
•24 VDC power supply (not with AHIP6+ board)
•Larger IDE hard drives and solid state drives
•9465KPM
•40 relegendable function keys (80 with the F/A function)
•Numeric, PC control, and alpha keypads
•Integrated mouse
•Flat-panel display
•15.0-inch TFT flat panel (9465)
•13.8-inch TFT flat panel (9465 and 9465KPM)
•12.1-inch TFT flat panel (9465KPM)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 1– Introduction
1-3
•CD-ROM (internal)
•Pre-installed PCI 10/100 Base-T Ethernet card
•External floppy drive 9000-EXF
•Front mount floppy kit 9000-FFK
•Front access panel for floppy port and keyboard port 9000-FKA
•Microsoft® Windows® version 3.11 4100 WIN
•Preloaded Microsoft Windows 95 or Windows NT® operating system
Unpacking the System
When you remove the system from its box, verify that you have the parts listed below.
Save the box and inner wrapping in the event you need to reship the unit.
•9465 or 9465KPM unit
•AC power connector
•Power connector retainer bracket with AC power supply
•Plastic p-clamp for DC power cable strain relief
•Sixteen 10-32 hex nuts (2 spares)
•Clip-on Ferrite for AUX cables
•Documentation kit, which includes:
•Diagnostic software disk (only on units shipped with DOS)
•VGA utility disk
•9465/9465KPM manual
•CPU manual
•Business reply card
If you ordered the system with a touchscreen installed, you will also receive a touch-
screen driver disk and manual. If you ordered a CD-ROM installed, you will receive the
drivers disk. If you ordered a 9465KPM, you will receive a mouse disk and manual.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
1-4
Quick Start-up
This section provides the steps to get the 9465 up and running without explaining the ca-
pabilities and options of the system.
Warning
Turn off power to the unit and disconnect the power cord before making
any adjustments to the inside or the outside of the computer.
Perform the following steps to prepare the system for use.
1. Attach an optional keyboard to the keyboard port.
2. Attach other optional equipment following the instructions in Chapter 3.
3. Attach the power cord from the power receptacle to a properly grounded 115/230
VAC, 50-60 Hz outlet or a 24 VDC outlet, whichever applies (Refer to the Creating
a Power Cable section in Chapter 3 for more information.)
4. Turn on the power to the unit. Depending on your operating system, one of the fol-
lowing will occur:
•In DOS, the system will boot up at the C: prompt
•In Windows 95, the Windows logo will display on the screen
•In Windows NT, the log-on box will display on the screen.
5. Adjust the contrast on the 9465 using the contrast adjust keys on the front panel.
These keys are available on the STN passive color options only.
On the 9465KPM press the F/A key so that the LED is lit, then press the left and
right cursor control keys to adjust the contrast.
6. Install application software via the floppy, a network connection, the IR port, or a
CD-ROM.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2-5
Chapter 2 – Testing
On units with MS-DOS installed, diagnostic tests are provided as a tool to verify the op-
eration of system hardware functions. If any of these tests fails, either you do not have
the correct default setting or there is a failure. Check the default settings and run the tests
again. If another failure occurs, contact Xycom’s Product Repair & Customization De-
partment (see Chapter 4).
Note
Remove any device drivers or memory resident programs (TSRs) in-
stalled on the system before running Xycom diagnostic tests. If you do
not, unexpected failures may occur.
The diagnostic disk does not provide an option to test a CD-ROM drive.
Make sure the BIOS setup menus are configured properly (factory set configuration).
To enter the BIOS setup menus,
1. Press F2 after the POST RAM test has completed.
2. Make the necessary changes by following directions on the screen.
3. Press ESC.
4. Press ENTER twice to save the settings and exit the BIOS setup menus.
Refer to your CPU manual for more information on the BIOS setup menus.
Preparing for the Tests
You need the following equipment to test your system:
•Floppy disk drive
•IBM PC/AT or PS/2-compatible keyboard (Xycom part number 8000-KBX or
equivalent)
•Xycom System Test Disk (3.5-inch, DS/DD bootable disk, Xycom part number
99290-001)
•Centronics-compatible printer cable
•Parallel printer (Centronics-style interface)
•Two serial loopback test connectors (refer to Figure 2-1 for pinouts)
•Formatted 3.5-inch, DS/HD disk (1.44 MB)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
2-6
Perform the steps below before starting the system tests:
1. Place the CPU board jumpers and switches to the factory set positions. Refer to your
CPU manual for these settings.
2. Plug the female end of the AC power cable into the side of the unit and the male end
into a properly grounded outlet.
3. Connect the serial loopback connector(s) and the printer cable to the appropriate
connectors and connect a PC/AT or PS/2 keyboard. Figure 2-1 illustrates the wiring
necessary for the loopback connection.
4. Default the CMOS setup to the factory settings.
Figure 2-1. Serial Loopback Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 2 – Testing
2-7
Running the Tests
To run the test, insert the diagnostics disk into drive A. Turn on the computer (the diag-
nostics program will boot-up). Figure 2-2 shows the Main Menu.
Copyright 1990-1996, Xycom, Inc. All rights reserved.
Diagnostic Tests Sequence/Selection Menu (Rel. xx)
1. WILL pause on error
2. SINGLE PASS test mode
3. Save setup to file
4. Extract setup from a file
5. Auto-select tests
6. Deselect all tests
7. Quit and exit to DOS
8. Return to previous screen
A) RAM Test
B) Video RAM Test
C) Extended RAM Test
D) Real Time Clock Test
E) COM1 Serial Port Test
F) COM2 Serial Port Test
G) COM3 Serial Port Test
H) COM4 Serial Port Test
I) Math Coprocessor Test
J) Video Adjustments Test
K) Video Interface Test
L) Speaker Port Test
M) LPT1: Printer Port Test
N) LPT2: Printer Port Test
O) C: Hard Drive Interface Test
P) D: Hard Drive Interface Test
Q) A: Floppy Drive Interface Test
R) B: Floppy Drive Interface Test
S) Keyboard, Keypad Tests
≡= Test Selected
[ENTER]=START TESTING
Use the letters to move the cursor and select/deselect, or use the arrow keys to move, then
use the [SPACE] key to select/deselect a test or function.
Figure 2-2. Main Menu
Note
Please read the DIAG.TXT file on the diagnostics disk for detailed in-
formation about the tests.
Note
Avoid repeated running of any hard disk diagnostic utility if you use the
Solid State (Flash) drive option. The Flash drive has a limited number of
writes to each logical sector. Repeated writes from a diagnostic utility
will prematurely shorten the life of the drive.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3-1
Chapter 3 – Installation
System Components
This section describes the components on the unit to help you locate features relevant
to installation.
9465 Front Panel
The 9465 comes with a NEMA 4/4X/12 and IP65 sealed front panel with a TFT (Figure
3-1) or STN (Figure 3-2) display. The panel protects the system’s interior when the sys-
tem is properly panel mounted.
Figure 3-1. 9465 TFT Active Display Front Panel
IR P O R T
POWER DISK COM INPUT
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
3-2
Figure 3-2. 9465 STN Passive Display Front Panel
Feature Description
Display The 9465 comes standard with a 15-inch STN flat panel or an optional 13.8- or
15-inch TFT flat panel. Impact-resistant shields protect the displays from break-
age. If a touchscreen is factory installed, the touchscreen is backed by heat-
annealed safety glass replacing the impact-resistant shield.
System Status LEDs The 9465 features four status LEDs on the front panel, which you can use to
monitor system operation.
Power There is power to the 9465.
Disk The computer module is accessing the disk drive.
COM There is communication activity on one of the computer module’s serial
ports, including communication between the computer module and the
touchscreen (if on COM2) or a serial device.
Input The unit has a touchscreen and the LED gets brighter when a touch in-
put is detected.
During power-up, firmware on the processor board checks the hardware configu-
ration against the configuration stored in the CMOS memory.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 3 – Installation
3-3
Feature Description
IR (Infrared) The IR port transceiver is located behind this window. The 9465 IR port is IrDA,
and ASK-IR compliant. You can connect the 9465 to any IrDA compatible de-
vice, if you load special software (not included). The infrared (IR) link operates
at a distance of 0 to 1 meter and is capable of 115 Kbaud transfer rates. Enable
the interface through the BIOS setup menus.
Note: When the IR port is chosen,
COM2 is not available. Correspondingly, if COM2 is in use by the touchscreen the IR is
not operational.
Contrast Control The 9465 with the STN flat panel display uses two Contrast Adjust keys on the
front panel to control the contrast. The left contrast adjust key decreases contrast;
the right contrast adjust key increases contrast.
9465KPM Front Panel
The 9465KPM comes with a NEMA 4/4X/12 sealed front panel (Figure 3-3). The panel
protects the system’s interior when the system is properly panel mounted.
Figure 3-3. 9465KPM Front Panel with Keypad
xycom
FLAT-PANEL
DISPLAY
FUNCTION KEYS (F1-F20) MOUSE
SYSTEM
STATUS
LEDS
CURSOR
CONTROL
NUMERIC
KEYPAD
F/A KEY
PROGRAMMABLE
FUNCTION KEYS
(PF11-PF20)
PROGRAMMABLE
FUNCTION KEYS
(PF1-PF10)
CONFIGURATION
KEY (PF10)
KEYBOARD &
IR-PORT ACCESS DOOR
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
9465/9465KPM System Manual
3-4
Feature Description
Display The 9465KPM comes with a 12.1-inch SVGA (800 x 600) STN or an optional
12.1-inch or 13.8-inch TFT flat panel. Impact-resistant shields protects the display
from breakage. If a touchscreen is factory installed, the touchscreen is backed by
heat-annealed safety glass replacing the impact-resistant shield.
System Status LEDs The 9465KPM features status LEDs on the front panel, which you can use to
monitor system operation.
Power Lit when there is power to the 9465.
Disk Lit when the computer is accessing the disk drive.
COM Lit when there is communication activity on one of the serial ports, in-
cluding communication between the computer module and the touch-
screen (if on COM2) or a serial device.
Input Lit when the unit has a touchscreen; the LED gets brighter when a touch
input is detected or a key is pressed.
F/A key Lit when alpha characters are being returned.
During power-up, firmware on the processor board checks the hardware configu-
ration against the configuration stored in the CMOS memory.
Function and User-
Defined Keys The 40 relegendable function keys (80 using the F/A key) provide easy access to
familiar routines. (The F/A key can be used for alpha and symbol entry). See
the
Customizing Keypad Inserts
section in this chapter for details on customizing your
keypad inserts.
Numeric/Cursor
Control Keypad The data entry keypads are for entering data and moving the cursor.
F/A Key When the LED is lit, alpha characters are returned. You can use the F/A key to
adjust contrast on STN displays by holding it down while pressing a cursor
control keys.
PF10 Key (Keypad
Configuration) This key configures your keypad.
Keyboard Port (front
access) The 9465KPM supports one PS/2 keyboard, located on the lower left side of the
front panel behind the access door. When using this port, the side port cannot
be used.
Mouse The built-in pointing device is located on the right-hand side of the front panel. It
operates in the same manner as a conventional mouse. Refer to the mouse disk-
ette and manual supplied with your documentation kit. This mouse consists of
three basic parts:
Left mouse key Serves the same function as the left button on a conventional
mouse.
Mouse dome Moves the pointer around the screen. Press the edge of the
dome that corresponds to the direction in which you wish to
move the pointer.
Right mouse key Serves the same function as the right button on a conven-
tional mouse.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 3 – Installation
3-5
I/O Panel
Figure 3-4 illustrates the I/O Panel on the right side of the 9465 and 9465KPM.
Figure 3-4. 9465 I/O Panel
Feature Description
Parallel Port The parallel printer port (LPT1) is a stacked DB-25 pin female connector.
This port provides a standard PC compatible printer interface. An external
push-button reset option is available. Consult the CPU board manual for
the jumper which controls this option.
COM Ports COM1 consists of two connectors (RS-232 and RS-485) attached to one
logical port. Only one connector can be used at a time. COM2 consists of
one connector (RS-232). connector.
Keyboard Port (both units) The keyboard port is a PS/2 stacked mini-din that allows you to attach a
PC/AT keyboard at the side of the unit. Do not use in a hazardous envi-
ronment.
Note: You cannot use both keyboard ports on the 9465KPM at
the same time.
USB Port (only units with the
AHIP6+ CPU board) USB (Universal Serial Bus) is a "plug-and-play" interface between a com-
puter and add-on devices (such as audio players, joysticks, keyboards,
telephones, scanners, and printers). With USB, a new device can be
added to your computer without having to add an adapter card or even
having to turn the computer off. USB supports a data speed of 12 megabits
per second. This speed will accommodate a wide range of devices, in-
cluding MPEG-2 video devices, data gloves, and digitizers.
COM 2
RS-232
PARALLEL RS-232
COM 1
RS-485 AUX
KEYBD
VIDEO
USB1
LID
SAFETY
RETENTION
SCREW (2)
MOUNTING
STUD (14)
FRONT
PANEL
EXPANSION
SLOTS (6)
ETHERNET
PORT
(OPTIONAL)
LID LATCH (2)
(on back)
VENT
FILTER
(on bottom)
3.5"
FLOPPY
DRIVE
5.25"
DRIVE BAY
KNOCKOUT
OR CD-ROM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
