Yaber K2s User manual

K2s PROJECTOR

LANGUAGE
English
Deutsch
Français
Italia
日本語日本語
한국인한국인
01~25
26~50
51~75
76~100
101~125
126~150
151-175
176-200
Polish
Spanish

EN 01
CONTENTS
YABER Lifetime Professional Support 02
Tips 02
Package List 03
Projector Specifications 04
Projector Overview 05
Remote Control Overview 06
1. Android TV Remote Control 06
2. Projector Remote Control 06
Installation 07
1. Install the TV Dongle 07
2. Distance and Projection Size 08
3. Angle Adjustment 08
4. Install on the Ceiling 09
5. Connect Devices 09
Operation 10
1. Starting Up the Projector 10
2. Image Adjustment 11
3. Switching Input Signal 14
4. USB Disk Input Mode 14
5. Screencast 15
6. Bluetooth Setting 18
7. Quiet Mode 19
8. Alexa Setup 20
9. System Update 23
10. Power On Mode 23
11. Safe Shutdown 23
Maintainance Tips 23
1. Care of Projectors 23
2. Cleaning the Air Filter 24

EN 02
YABER Lifetime Professional Support
Tips
Thank you for your support of YABER! Before using your projector, please take a moment
to read through the manual thoroughly. Should you encounter any issues, simply email
[e-mail] with your order number and a brief explanation of the problem.
Our team will respond within 24 hours with a fast and effective solution.
Many common issues such as signal or sound problems, failed Bluetooth or WiFi connections,
dark spots, or choppy animations can often be resolved through simple adjustments to the
settings. Rest assured that all of our projectors have undergone a rigorous 100% inspection and
packaging process prior to shipping.
If you have any further questions or concerns, please don't hesitate to contact us. We welcome
the opportunity to improve and guarantee that we will work with you to find a satisfactory
solution.
Thank you for your understanding and for choosing YABER!
Best regards, The YABER Service Team.
1. To ensure the longevity of your projector, it is important to avoid placing it in excessively
hot or cold environments. The optimal working temperature range is between 5°C and
35°C.
2. If you notice any black spots on the projection screen, please don't worry. Simply contact
us at [e-mail] and we will provide a video tutorial on how to remove dust
particles.
3. To prevent damage to the projector, it is crucial to protect it from strong impact, extrusion,
and vibration. Avoid moving the device during operation, as this can lead to internal circuit
faults.
4. The lens is a critical component of the projector that directly impacts picture quality. To
ensure optimal performance, it is important to keep the lens clean and free of dust. Use
a soft cotton cloth to gently wipe the glass lens surface, avoiding the use of abrasive
materials or hard cloths.

EN 03
Package List
K2s Projector
TV Dongle
3-in-1 AV Cable
Projector
Remote Control
TV Dongle
Remote Control
Quick Start Guide
Lens Cover
HDMI Cable
Power Cord
Cleaning Kits

EN 04
Projector Specifications
Model No. K2s
Native Resolution 1920*1080P Keystone Correction Auto/Manual Vertical&
Horizontal
Compatible Resolution 4K(H265 only) Light Source LED
Aspect Ratio 16:9 / 4:3 Display Technology LCD
Projection Ratio 1.54:1 Interfaces
HDMI*2/USB*1/
USB-C*1/Earphone*1/
AV*1
Recommended
Projection Distance 4.5-22.4ft Projector Weight 7.05 pounds(3.2 kg)
Power Voltage AC 100-240V Wi-Fi Wi-Fi 6
Power Consumption 140W Bluetooth 5.0
Projection Method Front/Rear on Desk, Front/ Rear on Ceiling
Picture Format JPG/JPEG/BMP/PNG
Video Format MP4/MKV/WMV/3GP/MPG/VOB/TP/TS/DAT/MOV/FLV/TRP/4K H.264/
H.265(≤30fps)
Audio Format MP3/WAV/WMA/M4A/AAC/OGG/FLAC

EN 05
Projector Overview
Automatic Focus
Signal Receiver
IR Window IR Window
Air Inlet
Power Port
HDMI Port
USB Port
USB-C Port
Headphone Jack
AV Port
NFC Area
Quiet Mode
Bluetooth Speaker Mode
Angle Adjusting Stand
Rubber Pad (Remove for Ceiling Mount)
TV Dongle Slot
Bottom Label
Volume
Power
Projector
Lens
Heat-Sink Window

EN 06
Standby On/Off
Home Page
Back/Exit
Back/Exit
Volume +/-
Home Page
Voice Search
Arrow Keys
Arrow Keys
APPs
Menu
Focus +/-
Auto Focus
OK
Power On/Off
OK
Remote Control Overview
VOL
Google Play
1. Android TV Remote Control
2. Projector Remote Control

EN 07
Installation
1. Install the TV Dongle
Lid
Tray
TV Dongle
Slot
1. Push once to open the lid, and take out the tray.
2. Mount the TV Dongle and make sure the Micro HDMI port downside and the Micro USB port
upside.
3. Insert the mounted TV Dongle into the slot.
4. Plug the USB power cable into the Micro USB port, and push to close the lid.
Micro USB port
(Mark on the Back)
Micro HDMI port
(Mark on the Back)
USB Power
Cable
Mounted TV
Dongle

EN 08
2. Distance and Projection Size
3. Angle Adjustment
The projector is equipped with an angle adjuster foot. Push the button to adjust its angle.
1. Place the projector on flat surface, press and hold the adjuster button and lift the projector.
2. Release the button when you find a suitable angle and the adjuster foot will drop into position
and be locked.
Max degree: 60°
Distance Screen Size
1.4m (4.5ft) 40"
2.1m (6.7ft) 60"
2.7m (8.9ft) 80"
3.4m (11.2ft) 100"
4.1m (13.4ft) 120"
5.1m (16.8ft) 150"
6.8m (22.4ft) 200"
The recommended projection distance is about 8.9ft, the shortest projection distance is 4.5ft.
The image size depends on the distance between projector and screen, there may be 3%
deviation among above listed data. Different settings cause various distances.

EN 09
The YABER Projector Manual Catalog provides detailed instructions for hanging your projector on
the ceiling. To do so, you will need to purchase a universal projector ceiling mount. Once you have
the mount, remove the four rubber pads on the bottom of the projector to reveal the screw holes.
Use M5*10mm screws to securely install the projector on the ceiling using the hanger frame. With
these simple steps, you can easily mount your projector for the best viewing experience.
The projector has 5 ports, HDMI port/USB port/USB-C port/AV_in/Audio out.
Please select the correct connecting ports to connect your devices.
Screw holes: M5*10mm
210mm
200mm
DVD
4. Install on the Ceiling
5. Connect Devices

EN 10
1. Open the battery compartment.
2. Insert two AAA batteries with correct polarity indicated.
3. Close the battery compartment.
Note: You must use the Yaber remote control to complete the first time setup of the projector.
Press the power key on the remote controller or projector. The power LED on the projector
turns from orange to off.
To turn off the projector, press once and then press it again when the power menu pops up.
The power LED on the projector lights up.
When you turn on the projector for the first time or the projector is reset to the Factory Default
Settings, you are prompted to make the first time setup.
You can select your system language, connect to Wi-Fi, and learn about the new features and
tips of the projector.
After setup, the projector will go to the Home Page.
· Prepare the remote control
· Power on
· First time setup
Operation
1. Starting Up the Projector

EN 11
When using the projector for the first time, it normally displays an unclear image. This is due to
the lens being out of focus or the incorrect keystone setting.
Please use the auto focus and manual focus key on remote control to get the best image. The
auto focus can also be triggered by moving the projector to another location.
· Focus the image
Alexa
Auto Focus
Focus +/-
2. Image Adjustment

EN 12
When the projection screen is not rectangular, it can be adjusted by auto keystone and 4-point
manual keystone correction.
The image will be adjusted automatically when you move the projector to another location.
For the extra spacing between the auto keystone correction, go to "Settings" -> "Projection" ->
"Projection Settings" -> "Manual Keystone". Use the arrow keys on the remote control to adjust
the horizontal or vertical parameters of each point, until the projection screen becomes the
desired rectangle.
· Auto and Manual Keystone

EN 13
For different projector placements, choose the appropriate projection mode to get the
correct image.
· Rotate the Image by Placement
1. Front projection Ceiling mount 2. Rear projection Ceiling mount
3. Front projection Desk mount 4. Rear projection Desk mount

EN 14
The projector can be connected to multiple devices at the same time but it can only display
one full screen at a time. Select the desired signal source (Android TV/HDMI/AV) on the home-
page.
1. Insert the USB Disk, the [USB] icon of the homepage will turn white.
2. Select the [USB] icon, or File Manager.
3. Select the desired file (or folder to enter the subfolder) in the USB disk, then press the [OK]
button to play.
· Play Video/Music/Photo in the File Manager
· Play Interface
3. Switching Input Signal
4. USB Disk Input Mode

EN 15
Warming Tips:
1. The fluency of screen mirroring with wireless connection will be affected by the network
environment. A bandwidth of 100Mbit or more is recommended when using screen
mirroring.
2. Make sure your mobile device is close to the projector when using wireless connection. A
distance within 1 meter is recommended.
3. Some mobile devices may not support screen mirroring due to the compatibility.
4. Any questions, please feel free to email YABER via [e-mail]
1. Connect the projector to your home Wi-Fi.
2. Turn on the Wi-Fi on your iPhone/iPad, and connect to the same network.
3. Press the Screen Mirroring on your iPhone/iPad and then choose [K2s_xxxx].
· iOS Wi-Fi Mirroring
For iPhone/iPad
For Macbook
iOS Cast (for iOS Devices)
5. Screencast
Chrome
About This Mac
System Preferences...
App Store...
Recent Items
Force Quit Chrome
File Edit View
AirPlay Looking for TV
K2s_440E
AirPlay To
Open Displays Preferences
95% A

EN 16
1. Turn on the Wi-Fi on your iPhone/iPad and connect to projector hotspot: [K2s_xxxx]
2. Press the Screen Mirroring of iOS device and then choose [K2s_xxxx].
1. Make sure your Mac and projector are on the same network.
2. Click Apple menu -> System Preference -> Sharing -> Airplay Display.
3. Click Airplay icon on menu bar and Select [K2s_xxxx] to connect and start wireless projection.
1. Make sure your Mac and projector are on the same network.
2. Click Apple menu -> System Preference -> Sharing -> Airplay Display.
3. Click Airplay icon on menu bar and Select [K2s_xxxx] to connect and start wireless projection.
· iOS AP Mirroring
For iPhone/iPad
For Macbook
K2s_xxxx
Chrome
About This Mac
System Preferences...
App Store...
Recent Items
Force Quit Chrome
File Edit View
AirPlay Looking for TV
K2s_440E
AirPlay To
Open Displays Preferences
95% A

EN 17
· Android Mirroring
Miracast for Android Devices
NFC Screencast
1. Turn on the Wi-Fi on the mobile phone.
2. Turn on the Wireless Display / Screen Mirroring function in the phone settings and choose
[K2s_xxxx] to start screen mirroring.
1. Press Windows logo key [Win+K] on your keyboard.
2. Select [K2s_xxxx] to connect and start wireless projection.
1. Download and install E-share App by scan QR code or visit http://h.eshare.app
2. Make sure your phone and projector are connected to same network, and connect the
projector on E-share App.
EShare
K2s_1234
Connected to:
CONNECT
Dirplay
K2s_440E
Search
Searching for wireless display and audio devices
Where in my devices

EN 18
· Bluetooth Connection
3. Go to Settings on E-share App, Select "Write NFC Tags" and follow the prompts to activate
the NFC area on the projector.
4. Now you can tap your phone closely on the NFC area to Screencast while the projector is
powered on and on the same Wi-Fi network as your phone.
Note:
1. NFC screencast requires your phone to touch the NFC detection area on the projector, which
may not be suitable for ceiling mounts.
2. NFC reading areas and the range of your smartphone vary from brand and model. Please
refer to your smartphone manufacturer for detailed instructions.
3. Currently the NFC tag does not support cross-OS use. An activated tag can only be read by
casting devices with the same operating system as the setting device.
Go to home page -> Select the [ Settings ] -> [ Bluetooth ] -> Scan the Bluetooth devices
nearby automatically -> Choose the Bluetooth device desired -> it will be paired and
connected automatically.
NFC
E-share
6. Bluetooth Setting
