Yaesu FTM-3200DR User manual

C4FM/FM
VHF DIGITAL/ANALOG TRANSCEIVER
FTM-3200DR/DE
Operating Manual
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz

2
Contents
FTM-3200DR/DE Operating Manual
Safety Precautions (Be Sure to Read) .................. 3
FTM-3200DR/DE Quick Reference Guide ............. 5
Introduction ............................................................. 6
Features of this radio ............................................. 6
Accessories & Options .......................................... 7
Supplied Accessories ............................................ 7
Optional Accessories ............................................. 7
Installation ............................................................... 8
Connecting the Microphone ................................... 8
Connecting the Antenna ........................................ 8
Mobile Installation .................................................. 9
Power connection ............................................. 10
Base Station Installation ....................................... 11
AC Power Supplies ............................................ 11
Front Panel Controls & Switches ........................ 12
Front Panel .......................................................... 12
Microphone Switches ........................................... 14
Microphone (MH-48A6JA) ................................... 14
[P1] button ........................................................ 14
[P2] button ........................................................ 14
[P3] button (Wires-X) ........................................ 14
[P4] button (WX CH/T.CALL) ............................ 14
Rear Panel ........................................................... 15
Basic Operation .................................................... 16
Turning the Transceiver ON and OFF ................. 16
Inputting the call sign ........................................... 16
Adjusting the Audio Volume Level ....................... 16
Adjusting the Squelch Setting .............................. 16
Frequency Navigation .......................................... 17
Using the Dial ................................................... 17
Using the MH-48A6JA Microphone ................... 17
Channel Step Selection ....................................... 17
Selecting the communication mode ..................... 18
Setting the transmission mode when using the AMS
function ............................................................. 19
Transmission ....................................................... 20
Adjusting the transmit power ............................ 21
Lock Feature ........................................................ 21
Advanced Operation ............................................ 22
Digital Group ID (DG-ID) feature ......................... 22
Register the DG-ID number in the DG-ID memory
............................................................................ 22
Recall and use the DG-ID number registered in the
DG-ID memory .................................................. 23
Restore the DG-ID number to “00” for both transmit
and receive without using the DG-ID memory .. 24
Use the GM (Group Monitor) with the DG-ID
function ............................................................. 24
Digital Personal ID (DP-ID) feature ..................... 25
Registering the DP-ID to a DR-2X digital repeater
............................................................................ 25
Register the transceivers .................................. 25
Deleting the registered DP-ID ........................... 26
Repeater Operation ............................................. 27
Checking the Repeater Uplink (Input) Frequency .
............................................................................ 27
Tone Calling (1750 Hz) ..................................... 27
Weather Broadcast Reception ............................. 28
Severe Weather Alert Feature .......................... 28
CTCSS Operation ................................................ 29
Tone Search ...................................................... 29
DCS Operation .................................................... 29
DCS Search ...................................................... 30
EPCS (Enhanced Paging & Code Squelch)
Operation ............................................................. 30
Split Tone Operation ............................................ 30
DTMF Operation .................................................. 30
Memory Operation ................................................ 31
Memory Storage .................................................. 31
Split Memory ..................................................... 31
Naming a Memory Channel .............................. 31
Memory Recall ..................................................... 32
Memory Recall from the Microphone Keypad ... 32
Moving Memory Data to the VFO .................. 32
Memory Only Mode .......................................... 32
Masking Memories .............................................. 33
Unmasking Memories ....................................... 33
HOME Channel Memory ..................................... 33
Changing the frequency of the home channel .. 33
Scanning ............................................................... 34
Basic Scanner Operation ..................................... 34
Scan Resume Options ...................................... 34
Memory Skip Scanning ..................................... 34
Preferential Memory Scan ................................ 34
Programmable Memory Scan (PMS) ................ 34
Priority Channel Scanning (Dual Watch) .......... 34
GM Function .......................................................... 35
What is the GM (Group Monitor) Function? ......... 35
Displaying all the stations using the GM function ..
............................................................................ 35
Reset Procedure/Clone ........................................ 36
Reset Procedure .................................................. 36
Microprocessor Resetting ................................. 36
Set Mode Resetting .......................................... 36
Clone ................................................................... 36
Connecting the WIRES-X feature ........................ 37
What is WIRES-X? .............................................. 37
Connecting to a WIRES-X digital node
(Recommended) ............................................... 37
Connecting to the other node ID or the other room
ID ...................................................................... 37
Disconnecting from the node or room ............... 40
Miscellaneous Settings ........................................ 41
Programming the Key Assignments .................... 41
Keyboard Beeper ................................................. 41
Display Brightness ............................................... 41
Time-Out-Timer (TOT) ......................................... 41
Automatic Power Off (APO) ................................. 41
Busy Channel Lock-Out (BCLO) ......................... 41
TX Deviation Level .............................................. 41
MIC Gain Setting ................................................. 41
Displaying the Supply Voltage ............................. 42
Displaying the Temperature ................................. 42
Band Edge Beeper .............................................. 42
Setup (Menu) Mode .............................................. 43
Maintenance .......................................................... 46
Care and maintenance ........................................ 46
Replacing the fuse ............................................... 46
Replacing the fuse of the DC power supply cable .
............................................................................ 46
Specifications ....................................................... 47
EU Declaration of Conformity ........................... 49

3FTM-3200DR/DE Operating Manual
Be sure to read these important precautions, and use this product safely.
Yaesu is not liable for any failures or problems caused by the use or misuse of this product by the
purchaser or any third party. Also, Yaesu is not liable for damages caused through the use of this product
by the purchaser or any third party, except in cases where ordered to pay damages under the laws.
Types and meanings of the marks
DANGER This mark indicates an imminently hazardous situation, which, if not
avoided, could result in death or serious injury.
WARNING This mark indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
This mark indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury or only property damage.
Types and meanings of symbols
These symbols signify prohibited actions, which must not be done to use this product safely.
For example: indicates that the product should not be disassembled.
These symbols signify required actions, which must be done to use this product safely. For
example,:
indicates that the power plug should be disconnected.
DANGER
Safety Precautions (Be Sure to Read)
WARNING
Do not use the device in “regions or aircrafts and
vehicles where its use is prohibited” such as in
hospitals and airplanes.
This may exert an impact on electronic and medical
devices.
Do not use this product while driving or riding a
motorbike. This may result in accidents.
Make sure to stop the car in a safe location first
before use if the device is going to be used by the
driver.
Do not operate the device when flammable gas
is generated.
Doing so may result in fire and explosion.
Never touch the antenna during transmission.
This may result in injury, electric shock and equip-
ment failure.
Do not transmit in crowded places in consider-
ation of people who are fitted with medical devic-
es such as heart pacemakers.
Electromagnetic waves from the device may affect
the medical device, resulting in accidents caused by
malfunctions.
When an alarm goes off with the external anten-
na connected, cut off the power supply to this
radio immediately and disconnect the external
antenna from this radio.
If not, this may result in fire, electric shock and equip-
ment failure.
Do not touch any liquid leaking from the liquid
display with your bare hands.
There is a risk of chemical burns occurring when
the liquid comes into contact with the skin or gets
into the eyes.
In this case, seek medical treatment
immediately.
Do not use voltages other than the specified
power supply voltage.
Doing so may result in fire and electric shock.
Do not transmit continuously for long periods of time.
This may cause the temperature of the main body
to rise and result in burns and failures due to over-
heating.
Do not dismantle or modify the device.
This may result in injury, electric shock and equip-
ment failure.
Do not handle the power plug and connector etc.
with wet hands. Also do not plug and unplug the
power plug with wet hands.
This may result in injury, liquid leak, electric shock
and equipment failure.
When smoke or strange odors are emitted from
the radio, turn off the power and disconnect the
power cord from the socket.
This may result in fire, liquid leak, overheating, dam-
age, ignition and equipment failure. Please contact
our company amateur customer support or the retail
store where you purchased the device.
Keep the power plug pins and the surrounding
areas clean at all times.
This may result in fire, liquid leak, overheating,
breakage, ignition etc.
Disconnect the power cord and connection ca-
bles before incorporating items sold separately
and replacing the fuse.
This may result in fire, electric shock and equipment
failure.

4FTM-3200DR/DE Operating Manual
CAUTION
Never cut off the fuse holder of the DC power
cord.
This may cause short-circuiting and result in ignition
and fire.
Do not use fuses other than those specified.
Doing so may result in fire and equipment failure.
Do not allow metallic objects such as wires and
water to get inside the product.
This may result in fire, electric shock and equipment
failure.
Do not place the device in areas that may get wet
easily (e.g. near a humidifier).
This may result in fire, electric shock and equipment
failure.
When connecting a DC power cord, pay due care
not to mix up the positive and negative polarities.
This may result in fire, electric shock and equipment
failure.
Do not use DC power cords other than the one
enclosed or specified.
This may result in fire, electric shock and equipment
failure.
Do not bend, twist, pull, heat and modify the pow-
er cord and connection cables in an unreason-
able manner.
This may cut or damage the cables and result in fire,
electric shock and equipment failure.
Do not pull the cable when plugging and unplug-
ging the power cord and connection cables.
Please hold the plug or connector when unplugging.
If not, this may result in fire, electric shock and equip-
ment failure.
Refrain from using headphones and earphones
at a loud volume.
Continuous exposure to loud volumes may result in
hearing impairment.
Do not use the device when the power cord and
connection cables are damaged, and when the
DC power connector cannot be plugged in tight-
ly.
Please contact our company amateur customer
support or the retail store where you purchased the
device as this may result in fire, electric shock and
equipment failure.
Follow the instructions given when installing
items sold separately and replacing the fuse.
This may result in fire, electric shock and equipment
failure.
Do not use the device when the alarm goes off.
For safety reasons, please pull the power plug of the
DC power equipment connected to the product out
of the AC socket.
Never touch the antenna as well. This may result
in fire, electric shock and equipment failure due to
thunder.
Do not place this device near a heating instru-
ment or in a location exposed to direct sunlight.
This may result in deformation and discoloration.
Do not place this device in a location where there
is a lot of dust and humidity.
Doing so may result in fire and equipment failure.
Stay as far away from the antenna as possible
during transmission.
Long-term exposure to electromagnetic radiation
may have a negative effect on the human body.
Do not wipe the case using thinner and benzene etc.
Please use a soft and dry piece of cloth to wipe away
the stains on the case.
Keep out of the reach of small children.
If not, this may result in injuries to children.
Do not put heavy objects on top of the power
cord and connection cables.
This may damage the power cord and connection
cables, resulting in fire and electric shock.
Do not transmit near the television and radio.
This may result in electromagnetic interference.
Do not use optional products other than those
specified by our company.
If not, this may result in equipment failure.
When using the device in a hybrid car or fu-
el-saving car, make sure to check with the car
manufacturer before using.
The device may not be able to receive transmissions
normally due to the influence of noises from the elec-
trical devices (inverters etc.)fitted in the car.
For safety reasons, switch off the power and pull
out the DC power cord connected to the DC pow-
er connector when the device is not going to be
used for a long period of time.
If not, this may result in fire and overheating.
Do not throw or subject the device to strong im-
pact forces.
This may result in equipment failure.
Do not the put this device near magnetic cards
and video tapes.
The data in the cash card and video tape etc. may
be erased.
Do not turn on the volume too high when using a
headphone or earphone.
This may result in hearing impairment.
Do not place the device on an unsteady or slop-
ing surface, or in a location where there is a lot
of vibration.
The device may fall over or drop, resulting in fire,
injury and equipment failure.
Do not stand on top of the product, and do not
place heavy objects on top or insert objects in-
side it.
If not, this may result in equipment failure.
Do not use a microphone other than those speci-
fied when connecting a microphone to the device.
If not, this may result in equipment failure.
Do not touch the heat radiating parts.
When used for a long period of time, the temperature
of the heat radiating parts will get higher, resulting in
burns when touched.
Do not open the case of the product except when replac-
ing the fuse and when installing items sold separately.
This may result in injury, electric shock and equip-
ment failure.

5FTM-3200DR/DE Operating Manual
FTM-3200DR/DE Quick Reference Guide
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz
LOCK
P3
P2
P1
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
LAMP
DTMF MICROPHONE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC
Power Switch
Press and hold for one second.
Frequency DIAL Knob
Selects the operating Frequency.
VOL Knob
Adjusts the audio
volume level.
Microphone
Transmission Switch
Speak into the microphone in
a normal voice level while
pressing this switch.

6FTM-3200DR/DE Operating Manual
Introduction
Features of this radio
144 MHz mobile radio, equipped with a C4FM digital communication modem
65 Watts of power output, with selection of three power levels for every operating situ-
ation
Clear audio and data communication is achieved using the digital modem functions
With the DG-ID (Digital Group ID), the Group Monitor (GM) feature enables automati-
cally locating, and communicating with other stations that have the same DG-ID num-
ber within contact range, by utilizing a matching group ID number from 00 to 99
The Digital Personal ID (DP-ID) feature may communicate only by the transceivers
registered the individual ID information that is different for each transceiver included in
the transmission radio wave of C4FM digital communication
Expanded receiver coverage: 136-174 MHz
Easily connect with the WIRES-X linking system
Keyboard entry of operating frequencies from the microphone
220 memories (199 “basic” memory channels, 10 sets of band-edge memory channels,
and one “Home” channel) which can store repeater shifts, odd repeater shifts, CTCSS/
DCS tones, and 8-character Alpha-Numeric labels for easy channel recognition
10 NOAA Weather Broadcast Channels, with Weather Alert and a Volume Control for
the Weather Alert tone
Built-in CTCSS and DCS Encoder/Decoder circuits
Extensive Menu system, which allows customization of a number of transceiver perfor-
mance characteristics
Equipped with the GM (Group Monitor) function.
Additional features include a transmit Time-Out-Timer (TOT), Automatic Power-Off (APO),
and Automatic Repeater Shift (ARS). Also included is an RF Squelch circuit that allows
the owner to set the squelch to open at a programmed setting of the S-Meter, thus reduc-
ing guesswork in setting the squelch threshold.
Congratulations on your purchase of the FTM-3200DR/DE! Whether this is your first rig,
or if Yaesu equipment is already the backbone of your station, the Yaesu organization
is committed to ensuring your enjoyment of this high-performance transceiver. It should
provide you with many years of satisfying operation. Our dealer network and technical
support personnel stand behind every product we sell, and we invite you to contact us
should you require technical advice or assistance.
We recommend that you read this manual in its entirety prior to installing the FTM-
3200DR/DE, so that you fully understand the capabilities of your new transceiver.

7FTM-3200DR/DE Operating Manual
Accessories & Options
Supplied Accessories
 DTMF Microphone
MH-48A6JA

Mobile Mounting Bracket
(Attachment screw set)

DC power cable w/Fuse
 Spare fuse (25 A)  USB cable
(20 A, European version)
Operating Manual
Safety Guide
Warranty Card
Optional Accessories
MH-42C6J Microphone
MH-48A6JA DTMF Microphone
MLS-100 High-Power External Speaker
FP-1023 AC Power Supply (USA market only)
FP-1030A AC Power Supply (USA/EXP market only)

8FTM-3200DR/DE Operating Manual
Installation
Connecting the Microphone
Connect the supplied MH-48A6JA microphone to the FTM-3200DR/DE.
Plug the microphone connector into the MIC jack on the front panel until it clicks.
Note: When disconnecting the microphone, pull the cable while pressing the connector
latch.
LOCK
P3
P2
P1
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
LAMP
DTMF MICROPHONE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC
Connector
Microphone
Connecting the Antenna
Connect the coaxial cable to the body.
Plug the coaxial cable jack into the ANT terminal on the rear panel of the body, then rotate
and tighten it.
Rear panel
Coaxial cable plug

9
Installation
FTM-3200DR/DE Operating Manual
Mobile Installation
The FTM-3200DR/DE must only be installed in vehicles having a 13.8 Volt negative
ground electrical system. Mount the transceiver where the display, controls, and micro-
phone are easily accessible, using the supplied mounting bracket.
The transceiver may be installed in almost any location, but should not be positioned
near a heating vent nor anywhere where it might interfere with driving (either visually or
mechanically).
Make sure to provide plenty of space on all sides of the transceiver so that air can flow
freely around the radio’s case. Refer to the diagrams showing proper installation proce-
dures.

10
Installation
FTM-3200DR/DE Operating Manual
Power connection
To minimize voltage drop and avoid blowing the vehicle’s fuses, connect the supplied
DC power cable directly to the battery terminals. Do not attempt to defeat or bypass the
DC cable fuse - it is there to protect you, your transceiver, and your vehicle’s electrical
system.
Warning!
Never apply AC power to the power cable of the FTM-3200DR/DE, nor DC
voltage greater than 15.8 Volts. When replacing the fuse, only use a 25-A (20-A,
European version) fuse. Failure to observe these safety precautions will void
the Limited Warranty on this product.
Before connecting the transceiver, check the voltage at the battery terminals while rev-
ving the engine. If the voltage exceeds 15 Volts, adjust the vehicle’s voltage regulator
before proceeding with installation.
Connect the RED power cable lead to the POSITIVE (+)battery terminal, and the
BLACK power cable lead to the NEGATIVE (–)terminal. If you need to extend the
power cable, use #12 AWG or larger insulated, stranded copper wire. Solder the splice
connections carefully, and wrap the connections thoroughly with insulating electrical
tape.
Before connecting the cable to the transceiver, verify the voltage and polarity at the
voltage at the transceiver end of the DC cable, using a DC voltmeter. Now connect the
transceiver to the DC cable.
Rear panel
Power cable
(DC 13.8 V)
Black
DC power supply
cable (supplied)
DC 12 V battery
Fuse holder
Red
Warning!
• Do not use a DC power supply cable other than the one that is supplied or
specified.
• Do not place anything on the DC power supply cable or step on it.
• Do not use the DC power supply cable with the fuse holder cut off.
• Do not reverse the polarity (positive and negative) when connecting the
battery.

11
Installation
FTM-3200DR/DE Operating Manual
Base Station Installation
The FTM-3200DR/DE is ideal for base station use as well as in mobile installations. The
FTM-3200DR/DE is specifically designed to integrate into your station easily, using the
following information as a reference.
AC Power Supplies
Operation of the FTM-3200DR/DE from an AC line requires a power source capable of
providing at least 20 Amps continuously at 13.8 Volts DC. The FP-1023 (USA market
only) and FP-1030A (USA/EXP market only) AC Power Supplies are available from your
Yaesu dealer to satisfy these requirements. Other well-regulated power supplies may be
used as well, if they meet the above voltage and current specifications.
Use the DC power cable supplied with the transceiver to make the power connection to
the power supply. Connect the RED power cable lead to the POSITIVE (+)power supply
terminal, and connect the BLACK power cable lead to the NEGATIVE (–)power supply
terminal.
Rear panel
Power cable
(DC 13.8 V)
Black
Direct current
power supply
AC power
outlet
DC power supply
cable (supplied)
Red
Fuse holder

12 FTM-3200DR/DE Operating Manual
Front Panel Controls & Switches
Front Panel
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz

     
 


VOL knob
Turning the knob clockwise increases the volume, whereas turning it counterclock-
wise decreases the volume.

Mode/Status indicator
Indicates the transmission/reception status with a two-color combination on the upper
and lower portions of the mode/status indicator.
Communication status Upper portion Lower portion
Receiving analog audio Green Green
Transmitting analog audio Red Red
Receiving digital audio Green Blue
Transmitting digital audio Red Blue
Receiving digital data Green White
Transmitting digital data Red White
Receiving signals with unmatched
audio or data conditions øGreen Blink in Blue
ø• Receiving signals with unmatched tone frequency or DCS code.
• Receiving analog audio in digital mode.
• Receiving signals with unmatched SQL code in digital mode.
• Receiving a signal level less than the RF Squelch S-meter level setting.

DIAL Knob
• Allows setting the operating band frequency.
Turning clockwise increases the frequency, whereas turning counterclockwise de-
creases the frequency.
• Allows selecting the desired items for setup, memory registration, group monitoring
operation, etc.

MIC Jack
Connect the provided microphone cable.

13
Front Panel Controls & Switches
FTM-3200DR/DE Operating Manual

[SQL(TXPO)] key
Press and hold the key in for over one second to select the transmit power (HIGH: 65
W / MID: 30 W / LOW: 5 W).

[REV(DW)] key
During split-frequency operation, such as through a repeater, this key reverses the
transmit and receive frequencies.
Press and hold the key in for over one second to activate the Dual Watch feature.
Note: For details, refer to the Advanced Manual (download from the Yaesu website).

[D/A(GM)] key
Briefly pressing each time switches the operating band communication mode.
Press and hold in this key for over one second to activate the GM (Group Monitor)
function.
Note: For details on the GM function, see “GM (Group Monitor) Function” on 35

[MHz(SETUP)] key
This key allows tuning in 1 MHz steps (the MHz digits will blink on the display).
Press and hold this key in for over one second to activate the Setup (Menu) Mode.

[V/M(MW)] key
Pressing this key briefly, switches between VFO mode and memory mode. Press and
hold the key for over one second to display the memory registration screen.

Power/Lock key
Press and hold in this key for over one second to switch the power between ON and
OFF. Briefly pressing the key while the transceiver is turned ON engages or releases the
key lock.
Speaker
The internal speaker is located here.
LCD Display
The main digits on the display may show the operating frequency, memory name, or
any of many parameters during Menu setup.
S and TX Power Meter
Communication mode
Lock Feature Active
DTMF Memory Mode
SKIP/Preferential Scan Channel
Narrow Deviation
LOW/MID TX Power Selected
Memory mode
Memory Channel Number
GM Feature Communica-
tion range indicator
AMS Function
GM Feature Active
Frequency/Message
Area
HOME Channel
CTCSS/DCS/EPCS Bell Paging
CTCSS
(
Continuous Tone Coded Squelch System )
DCS (Digital Code Squelch)
Repeater Shift Direction

14 FTM-3200DR/DE Operating Manual
Microphone Switches
Microphone (MH-48A6JA)

PTT Switch
Press this switch to transmit, and release
it to receive.

KEY Pad
These 16 keys generate DTMF tones during
transmission.
In the receive mode, these 16 keys can be
used for direct frequency entry and/or direct
numeric recall of the Memory channels.

[P1] / [P2]keys
[P1] button
Press this button to recall the DG-ID
memory.
[P2] button
Press and hold this button to enter the DG-
ID memory screen.
LOCK
P3
P2
P1
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
LAMP
DTMF MICROPHONE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC







[P3] / [P4]keys
These two keys are user programmable, allowing quick access to features used often.
The default functions are described below.
[P3] button (Wires-X)
Press this button to activate the Wires-X feature.
[P4] button (WX CH/T.CALL)
In the USA version, pressing this button recalls the “Weather” broadcast channel bank.
In the EXP/European version, pressing this button activates T.CALL (1750 Hz) for
repeater access.
You can reprogram the [P3]and [P4]buttons for other functions, if desired.
Note: For details, refer to the Advanced Manual (download from the Yaesu website).

MIC
Speak into this port during transmission.

[UP] / [DWN]keys
Press (or hold in) either of these buttons to tune (or scan up or down) the operating
frequency or through the memory channels. In many ways, these buttons emulate the
function of the (rotary) DIAL knob.

LOCK switch
This switch locks out the Microphone buttons (except for the keypad and PTT switch).

LAMP switch
This switch illuminates the Microphone keypad.

15FTM-3200DR/DE Operating Manual
Rear Panel
    

ANT Coaxial Socket
Connect a 144 MHz antenna to this type-M (SO-239) socket using 50-Ohm coaxial
cable and a type-M (PL-259) plug. Make sure the antenna is designed specifically for
use on the operating frequency.

EXT SP Jack
This 2-contact 3.5-mm mini phone jack provides receiver audio output for an optional
external speaker. The audio impedance is 4 Ohms, and the level varies according to
the setting of the front panel VOL control. Inserting a plug into this jack disables audio
from the transceiver’s internal speaker.

13.8 V DC Cable
Connect the provided DC power supply cable (with fuse attached).

DATA Jack
Use this jack when updating the firmware. When a new firmware update for the FTM-
3200DR/DE is available, go to the YAESU website to download the programming data
and update the FTM-3200DR/DE to its newest state.

Cooling Fan

16 FTM-3200DR/DE Operating Manual
Basic Operation
Turning the Transceiver ON and OFF
1. To turn the transceiver ON, press and hold
the PWR/LOCK key for one second.
2. To turn the transceiver OFF, again press and
hold the PWR/LOCK key for one second.
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz
You can compose any desired Opening Message (up to 8 characters) via Setup Menu
Item “OPEN MSG 26” see 44 for details.
Inputting the call sign
A screen requesting input of a call sign appears when turning the transceiver on for the
first time, or after resetting the transceiver. The call sign is used to identify the transmit-
ting station when communicating in digital mode.
1. Press the [V/M(MW)] key.
2. Rotate the DIAL knob to select characters,
then press the [V/M(MW)].
By rotating the DIAL knob, you can switch
the characters in the following order:
“space” à“-” à“/” à“0” to “9” à“A” to “Z”
Up to 10 characters (alphanumeric characters including hyphen) can be entered.
“space”, “-”, and “/” are not selectable for the first character.
3. Press and hold the [MHz(SETUP)] key for one second to save the call sign and exit to
normal operation.
Adjusting the Audio Volume Level
Rotate the VOL knob to adjust the receiver
volume. Clock-wise rotation increases the audio
output level.
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz
Adjusting the Squelch Setting
1. Press the [SQL(TXPO)] key, then rotate the
DAIL knob to select the Squelch level.
2. Press the [SQL(TXPO)] key again.
Note: A special “RF Squelch” feature is pro-
vided on this radio. This feature al-
lows setting the squelch so that only
signals exceeding a certain S-meter
level will open the squelch. For de-
tails, refer to the Advanced Manual
(download from the Yaesu website).
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz

17
Basic Operation
FTM-3200DR/DE Operating Manual
Frequency Navigation
Using the Dial
Rotating the DIAL knob allows tuning in the
pre-programmed steps. Clockwise rotation
tunes the frequency upwards, whereas coun-
terclockwise rotation tunes the frequency
downwards.
Press the [MHz(SETUP)] key momentarily,
then rotate the DIAL knob, to change the fre-
quency steps to 1 MHz per step.
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz
Using the MH-48A6JA Microphone
Using the [UP]and [DWN]key:
Pressing [UP]momentarily, tunes the frequen-
cy upwards. Whereas pressing [DWN]mo-
mentarily tunes the frequency in the downward
direction.
Using the number keys:
Use the [0]to [9]number keys to directly input
the frequency.
There is no “decimal point” key on the MH-
48A6JA keypad. However, there is a short-cut
for frequencies ending in zero:
press the [#]key after the last non-zero digit.
UP
DWN
Number
keys
Examples: To enter 146.520 MHz, press [1]à[4]à[6]à[5]à[2]à[0]
To enter 146.000 MHz, press [1]à[4]à[6]à[#]
Channel Step Selection
The frequency tuning step of the DIAL and the microphone [UP]/[DWN]keys can be
changed.
Note: See Setup Menu Item “STEP 40” on 45

18
Basic Operation
FTM-3200DR/DE Operating Manual
Selecting the communication mode
The FTM-3200DR/DE transceiver is equipped with the AMS (Automatic Mode Select)
function which automatically selects from two modes of transmission corresponding to
the signal being received.
The transmit mode is selected according to the received signal so that C4FM digital sig-
nals, and analog signals are received and transmitted automatically.
Press [D/A(GM)] key to display “ ” (blinks) icon on the screen.
Display example when in AMS mode
AMS transmission mode
To operate in fixed communication mode, press [D/A(GM)] key to switch the communi-
cation mode.
Each time [D/A(GM)] key is pressed, the communication mode changes in the following
order:
àAMS (“ ” blinks) àV/D (“ ” lights up) àFM (no icon) à
Communication mode Icon Description of modes
AMS (Automatic Mode Select) (blinks)
Transmit mode is automatically selected from 3
types according to the signal received.
The AMS function operation can be changed
from the Setup menu setting. See “Setting the
transmit mode when using the AMS function
(11 DIG AMS)” on 43
V/D Mode
(Voice/Data simultaneous
transmission mode) (light up)
Calls are less prone to interruptions due to de-
tection and correction of voice signals during
digital voice signal transmission. This is the
standard mode for C4FM Digital.
Analog FM Mode no icon
Analog communication using FM mode.
Effective when the signal is weak and audio is
susceptible to interruption in digital mode.

19
Basic Operation
FTM-3200DR/DE Operating Manual
Setting the transmission mode when using the AMS function
TXMANUAL (“ ” blinks: 1 sec on, 0.5 sec off)
Automatically selects one of the two communication modes according to the received
signal. Briefly pressing [PTT]on the microphone switches between digital mode and
analog mode.
Blinks: 1 sec on, 0.5 sec off
D: DN mode
F: FM mode
TX FMFIX (“ ” blinks: 0.5 sec on, 0.5 sec off)
Automatically selects one of the two communication modes according to the received
signal. Always switches to FM mode for transmission.
Blinks: 0.5 sec on, 0.5 sec off
FM mode
TX DNFIX (“ ” blinks: 0.5 sec on, 0.5 sec off)
Automatically selects one of the two communication modes according to the received
signal. Always switches to DN mode for transmission.
Blinks: 0.5 sec on, 0.5 sec off
DN mode
AUTO (“ ” blinks: 0.5 sec of, 0.5 sec off)
Automatically selects one of the two communication modes according to the received
signal.
Blinks: 0.5 sec on, 0.5 sec off
D: DN mode
F: FM mode

20
Basic Operation
FTM-3200DR/DE Operating Manual
Transmission
1. Press and hold PTT on the microphone.
In analog mode, both the upper and lower
portions of the PTT mode/status indicator
light red.
In digital mode, the upper portion of the
mode/status indicator lights red and the low-
er portion of the mode/status indicator lights
blue.
LOCK
P3
P2
P1
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
LAMP
DTMF MICROPHONE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC
MIC
PTT
VOL
DIAL
SQL
TXPO DW MW
SETUP
REV D/A V/MMHz
Analog mode: Both the upper and lower portions light red
Digital mode: The upper portion lights red and the lower portion lights blue
2. Speak into MIC on the microphone.
Note: Keep the microphone about 5 cm away from your mouth.
The sensitivity (gain) of the microphone can be adjusted. For details, refer to the
Advanced Manual (download from the Yaesu website).
3. Release PTT.
The transmit mode/status indicator turns off and the transceiver returns to the receive
mode.
Caution: Do not continue transmitting for a prolonged period. The transceiver may
overheat, resulting in malfunction or injury.
Note: “ERROR” appears if you attempt to transmit on an unavailable frequency.
