FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
FT-2000
CAT O PERATION
R EFERENCE B OOK

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
OVERVIEW
The CAT (Computer Aided Transceiver) System in the
FT-2000 provides control of frequency, VFO, memory,
and other settings such as dual-channel memories and di-
versity reception using an external personal computer. This
allows multiple control operations to be fully automated
as single mouse clicks or keystroke operations on the com-
puter keyboard.
The FT-2000 has a built-in level converter, allowing di-
rect connection from the rear-panel CAT jack to the serial
port of your computer without the need of any external
boxes. You will need a serial cable for connection to the
RS-232C (serial or COM port) connector on your com-
puter. Purchase a standard serial cable (not the so-called
“null modem” type), ensuring it has the correct gender
and number of pins (some serial COM port connectors
use a 9-pin rather than 25-pin configuration). If your com-
puter uses a custom connector, you may have to construct
the cable. In this case, refer to the technical documenta-
tion supplied with your computer for correct data connec-
tion.
Vertex Standard does not produce CAT System operating
software due to the wide variety of personal computers
and operating systems in use today. However, the infor-
mation provided in this chapter explains the serial data
structure and opcodes used by the CAT system. This in-
formation, along with the short programming examples,
is intended to help you start writing programs on your
own. As you become more familiar with CAT operation,
you can customize programs later on for your operating
needs and discover the true operating potential of this sys-
tem.
Page 1
COM
CAT
RS-232C “Straght” Cable
CAT JACK
PIN NO.
c
d
e
f
g
h
i
j
k
PIN NAME
N/A
SERIAL OUT
SERIAL IN
N/A
GND
N/A
RTS
CTS
N/A
FUNCTION
---
Outputs the Serial Data from the
transceiver to the computer.
Inputs the Serial Data from the
computer to the transceiver.
---
Signal Ground
---
When the computer is not ready
to receive data, this port goes to
“L” for inhibit the transmit data
from the transceiver.
When the transceiver is not ready
to receive data, this port goes to
“L” for inhibit the transmit data
from the computer.
---
I/O
---
Output
Input
---
---
---
Input
Output
---

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND
A computer control command is composed of an alpha-
betical command, various parameters, and the terminator
that signals the end of the control command.
Example: Set the main band (VFO-A) frequency to
14.250000 MHz.
FA 14250000 ;
KKK
Command Parameter Terminator
There is three for the FT-2000 Command as shown below:
Set command: Set a particular condition
(to the FT-2000)
Read command: Reads an answer
(from the FT-2000)
Answer command: Transmits a condition
(from the FT-2000)
For example, note the following in the case of the FA com-
mand (Set the main band (VFO-A) frequency):
To set the main band (VFO-A) frequency to 14.250000
MHz, the following command is sent from the com-
puter to the transceiver:
“FA14250000;” (Set command)
To read the main band (VFO-A) frequency, the fol-
lowing command is sent from the computer to the trans-
ceiver:
“FA;” (Read command)
When the Read command above has been sent, the
following command is returned to the computer:
“FA14250000;” (Answer command)
Alphabetical Commands
A command consists of 2 alphabetical characters.
You may use either lower or upper case characters. The
commands available for this transceiver are listed in the
“PC Control Command Tables” on the following pages.
Page 2
Parameters
Parameters are used to specify information necessary to
implement the desired command.
The parameters to be used for each command are prede-
termined. The number of digits assigned to each param-
eter is also predetermined. Refer to the “Control Com-
mand List” and the “Control Command Tables” to con-
figure the appropriate parameters.
When configuring parameters, be careful not to make the
following mistakes.
For example, when correct parameter is “IS0+1000” (IF
SHIFT):
IS01000;
Not enough parameters specified (No direction (+)
given for the IF shift)
IS0+100;
Not enough digits (Only three frequency digits
given)
IS0_+_1000;
Unnecessary characters between parameters
IS0+10000;
Too many digits (Five frequency digits given)
Note: If a particular parameter is not applicable to the FT-
2000, the parameter digits should be filled using any char-
acter except the ASCII control codes (00 to 1Fh) and the
terminator (;).
Terminator
To signal the end of a command, it is necessary to use a
semicolon (;). The digit where this special character must
appear differs depending on the command used.

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
VFO-A TO VFO-B
ANTENNA TUNER CONTROL
AF GAIN
AUTO INFORMATION
VFO-A TO MEMORY CHANNEL
ANTENNA NUMBER
AUTO NOTCH
BAND DOWN
BREAK-IN
MANUAL NOTCH
BAND SELECT
BAND UP
BUSY
CHANNEL UP/DOWN
CTCSS NUMBER
CONTOUR
CW SPOT
CTCSS
DIMMER
DOWN
DISPLAY
DIMMER SWITCH
ENCORDER DOWN
ENT KEY
ENCORDER UP
MENU
FREQUENCY VFO-A
FREQUENCY VFO-B
FUNCTION KEY
FUNCTION RX
FAST STEP
FUNCTION TX
AGC FUNCTION
IDENTIFICATION
INFORMATION
IF-SHIFT
KEYER MEMORY
KEY PITCH
KEYER
KEY SPEED
CW KEYING
LOCK
LOAD MESSEGE
MEMORY CHANNEL TO VFO-A
MEMORY CHANNEL
MODE
MIC GAIN
MODE KEY
MONITOR LEVEL
AB
AC
AG
AI
AM
AN
BC
BD
BI
BP
BS
BU
BY
CH
CN
CO
CS
CT
DA
DN
DP
DS
ED
EK
EU
EX
FA
FB
FK
FR
FS
FT
GT
ID
IF
IS
KM
KP
KR
KS
KY
LK
LM
MA
MC
MD
MG
MK
ML
C OMMAND FUNCTION SET READ AI
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
C OMMAND FUNCTION SET READ AI
X
O
O
O
X
O
O
X
O
O
X
X
O
X
O
O
O
O
O
X
O
O
X
X
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
X
O
O
X
O
O
O
X
O
X
O
O
O
X
O
O
X
O
O
X
X
O
X
O
O
O
O
O
X
O
O
X
X
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
X
O
O
X
O
O
O
X
O
X
O
X
O
O
O
O
O
X
O
O
X
X
O
O
X
X
X
X
O
X
X
O
O
O
O
X
X
O
O
X
O
O
O
O
X
O
X
O
O
O
X
O
O
O
X
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
O
X
X
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O
X
O
X
O
O
O
O
O
O
X
O
O
O
O
X
O
O
O
O
O
O
O
O
MEMORY READ
METER SW
MEMORY WRITE
MOX SET
NARROW
NOISE BLANKER
NOISE BLANKER LEVEL
NOISE REDUCTION
OPPOSITE BAND INFORMATION
OFFSET (REPEATER SHIFT)
PRE-AMP (IPO)
PLAY BACK
POWER CONTROL
SPEECH PROCESSOR LEVEL
SPEECH PROCESSOR
POWER SWITH
QMB STORE
QMB RECALL
QUICK SPLIT
RF ATTENUATOR
CLAR CLEAR
CLAR DOWN
ROOFING FILTER
RF GAIN
RADIO INFORMATION
NOISE REDUCTION LEVEL
READ METER
ROTATOR
RADIO STATUS
CLAR
CLAR UP
SCAN
SEMI BREAK-IN DELAY TIME
SUB-DIAL FUNCTION
WIDTH
S METER
SQUELCH LEVEL
SWAP VFO
TXW
TX SET
UNLOCK
UP
VOX DELAY TIME
VRF FILTER
VOX GAIN
[V/M]KEY FUNCTION
VFO SELECT
VOX
TX CLAR
MR
MS
MW
MX
NA
NB
NL
NR
OI
OS
PA
PB
PC
PL
PR
PS
QI
QR
QS
RA
RC
RD
RF
RG
RI
RL
RM
RO
RS
RT
RU
SC
SD
SF
SH
SM
SQ
SV
TS
TX
UL
UP
VD
VF
VG
VM
VS
VX
XT
CONTROL COMMAND LIST
Page 3
ANS.
X
O
O
X
X
O
O
X
O
O
X
X
O
X
O
O
O
O
X
X
O
O
X
X
X
O
O
O
X
O
O
O
O
X
O
O
X
O
O
O
X
O
X
X
X
O
O
X
O
ANS.
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
O
X
X
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
ABAB
ABAB
AB VFO-A TO VFO-B
Set 12345678910
AB ;
Read 12345678910
Answer 12345678910
BCBC
BCBC
BC AUTO NOTCH
Set 12345678910
BCP1 P2 ;
Read 12345678910
BCP1 ;
Answer 12345678910
BCP1 P2 ;
P1 0:Fixed
P2 0: Auto Notch “OFF”
1: Auto Notch “ON”
BDBD
BDBD
BD BAND DOWN
Set 12345678910
BDP1 ;
Read 12345678910
Answer 12345678910
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
CONTROL COMMAND TABLES
ANAN
ANAN
AN ANTENNA NUMBER
Set 12345678910
ANP1 P2 ;
Read 12345678910
ANP1 ;
Answer 12345678910
ANP1 P3 P4 ;
P1 0: Fixed
P2 1: ANT “1”
2: ANT “2”
5: ANT “RX”
P3 1: ANT “1”
2: ANT “2”
AA
AA
AGG
GG
GAF GAIN
Set 12345678910
AGP1 P2 P2 P2 ;
Read 12345678910
AGP1 ;
Answer 12345678910
AGP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
AA
AA
ACC
CC
CANTENNA TUNER CONTROL
Set 12345678910
ACP1 P2 P3 ;
Read 12345678910
AC ;
Answer 12345678910
ACP1 P2 P3 ;
P1 0: Fixed P3 0: Tuner “OFF”
P2 0: Fixed 1: Tuner “ON”
2: Tuning Start
AIAI
AIAI
AI AUTO INFORMATION
Set 12345678910
AIP1 ;
Read 12345678910
AI ;
Answer 12345678910
AIP1 ;
P1 0: Auto Information “OFF”
1: Auto Information “ON”
This parameter is set to “0” (OFF) automatically when the transceiver is turned “OFF.”
AMAM
AMAM
AM VFO-A TO MEMORY CHANNEL
Set 12345678910
AM ;
Read 12345678910
Answer 12345678910
P4 0: ANT “RX” “OFF”
1: ANT “RX” “ON”
Page 4
BIBI
BIBI
BI BREAK-IN
Set 12345678910
BIP1 ;
Read 12345678910
BI ;
Answer 12345678910
BIP1 ;
P1 0: Break-in “OFF”
1: Break-in “ON”

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CNCN
CNCN
CN CTCSS TONE FREQUENCY
Set 12345678910
CNP1 P2 P2 ;
Read 12345678910
CNP1 ;
Answer 12345678910
CNP1 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0 - 49: Tone Frequency Number (See Table 1)
COCO
COCO
CO CONTOUR
Set 12345678910
COP1 P2 P3 P3 ;
Read 12345678910
COP1 P2 ;
Answer 12345678910
COP1 P2 P3 P3 ;
P1 0:Fixed
P2 0: CONTOUR “ON/OFF”
1: CONTOUR LEVEL
P3 When P2=0,
000: CONTOUR “OFF”
001: CONTOUR “ON”
When P2=1,
01 - 40 (CONTOUR Frequency)
CSCS
CSCS
CS CW SPOT
Set 12345678910
CSP1 ;
Read 12345678910
CS ;
Answer 12345678910
CSP1 ;
P1 0: OFF
1: ON
CONTROL COMMAND TABLES
BSBS
BSBS
BS BAND SELECT
Set 12345678910
BSP1 P1 ;
Read 12345678910
Answer 12345678910
P1 00: 1.8 MHz 06: 18 MHz
01: 3.5 MHz 07: 21 MHz
02: 5 MHz 08: 24.5 MHz
03: 7 MHz 09: 28 MHz
04: 10 MHz 10: 50 MHz
05: 14 MHz 11: GEN
BPBP
BPBP
BP MANUAL NOTCH
Set 12345678910
BPP1 P2 P3 P3 P3 ;
Read 12345678910
BPP1 P2 ;
Answer 12345678910
BPP1 P2 P3 P3 P3 ;
P1 0:Fixed
P2 0: Manual NOTCH “ON/OFF”
1: Manual NOTCH LEVEL
P3 When P2=0
000: OFF
001: ON
When P2=1
001 - 400 (NOTCH Frequency : x 10 Hz )
BB
BB
BUU
UU
UBAND UP
Set 12345678910
BUP1 ;
Read 12345678910
Answer 12345678910
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
BYBY
BYBY
BY BUSY
Set 12345678910
Read 12345678910
BY ;
Answer 12345678910
BYP1 P2 ;
P1 0: Main (VFO-A) Band BUSY “OFF”
1: Main (VFO-A) Band BUSY “ON”
P2 0: Sub (VFO-B) Band BUSY “OFF”
1: Sub (VFO-B) Band BUSY “ON”
CHCH
CHCH
CH CHANNEL UP/DOWN
Set 12345678910
CHP1 ;
Read 12345678910
Answer 12345678910
P1 0: Memory Channel “UP”
1: Memory Channel “DOWN”
Page 5
TABLE
00
01
02
03
04
05
06
07
08
67.0 Hz
69.3 Hz
71.9 Hz
74.4 Hz
77.0 Hz
79.7 Hz
82.5 Hz
85.4 Hz
88.5 Hz
09
10
11
12
13
14
15
16
17
91.5 Hz
94.8 Hz
97.4 Hz
100.0 Hz
103.5 Hz
107.2 Hz
110.9 Hz
114.8 Hz
118.8 Hz
123.0 Hz
127.3 Hz
131.8 Hz
136.5 Hz
141.3 Hz
146.2 Hz
151.4 Hz
156.7 Hz
159.8 Hz
27
28
29
30
31
32
33
34
35
162.2 Hz
165.5 Hz
167.9 Hz
171.3 Hz
173.8 Hz
177.3 Hz
179.9 Hz
183.5 Hz
186.2 Hz
36
37
38
39
40
41
42
43
44
189.9 Hz
192.8 Hz
196.6 Hz
199.5 Hz
203.5 Hz
206.5 Hz
210.7 Hz
218.1 Hz
225.7 Hz
45
46
47
48
49
---
---
---
---
229.1 Hz
233.6 Hz
241.8 Hz
250.3 Hz
254.1 Hz
---
---
---
---
CTCSS TONE CHART
18
19
20
21
22
23
24
25
26

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND TABLES
DD
DD
DAA
AA
ADIMMER
Set 12345678910
DAP1 P1 P2 P2 ;
Read 12345678910
DA ;
Answer 12345678910
DAP1 P1 P2 P2 ;
P1 00 - 07: VFD Backlight Brightness Level
P2 00 - 15: Meter (except VFD) Brightness Level
DNDN
DNDN
DN MIC DWN
Set 12345678910
DN ;
Read 12345678910
Answer 12345678910
CTCT
CTCT
CT CTCSS
Set 12345678910
CTP1 P2 ;
Read 12345678910
CTP1 ;
Answer 12345678910
CTP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: CTCSS “OFF”
1: CTCSS ENC/DEC “ON”
2: CTCSS ENC “ON”
DPDP
DPDP
DP DISPLAY
Set 12345678910
DPP1 ;
Read 12345678910
DP ;
Answer 12345678910
DPP1 ;
P1 0: World Clock Display
1: Band Scope Display
2: AF Oscilloscope/Spectrum Analyzer Display
3: Log Book Display
4: Temperature/SWR Display
5: Rotator Display
6: Memory Channel List Display
DSDS
DSDS
DS DIMMER SWITCH
Set 12345678910
DSP1 ;
Read 12345678910
DS ;
Answer 12345678910
DSP1 ;
P1 0: DIMMER “OFF”
1: DIMMER “ON”
Page 6
EDED
EDED
ED ENCORDER DOWN
Set 12345678910
EDP1 P2 P2 ;
Read 12345678910
Answer 12345678910
P1 0: MAIN ENCORDER
1: SUB ENCORDER
P2 01-99: Steps
EKEK
EKEK
EK ENT KEY
Set 12345678910
EK ;
Read 12345678910
Answer 12345678910
EUEU
EUEU
EU ENCORDER UP
Set 12345678910
EUP1 P2 P2 ;
Read 12345678910
Answer 12345678910
P1 0: MAIN ENCORDER
1: SUB ENCORDER
P2 01-99: Steps
Ú: This command does not acti-
vates when the optional Data
Managemnt Unit is not attached.

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
Page 7
EXEX
EXEX
EX MENU
Set 12345678nn
**
EXP1 P1 P1 P2 P2 ~ P2 ;
Read 12345678910
EXP1 P1 P1 ;
Answer 12345678nn
**
EXP1 P1 P1 P2 P2 ~ P2 ;
P1 : 001-136 (MENU Number)
P2 : Parameter
See Table 2 and Table 3
CONTROL COMMAND TABLES
P1 FUNCTION P2
001 AGC FAST DELAY TIME 0020 ~ 4000 msec (20 msec/step)
002 AGC FAST PEAK HOLD TIME 0000 ~ 2000 msec (20 msec/step)
003 AGC MID DELAY TIME 0020 ~ 4000 msec (20 msec/step)
004 AGC MID PEAK HOLD TIME 0000 ~ 2000 msec (20 msec/step)
005 AGC SLOW DELAY TIME 0020 ~ 4000 msec (20 msec/step)
006 AGC SLOW PEAK HOLD TIME 0000 ~ 2000 msec (20 msec/step)
007 DISPLAY COLOR 0: COOL BLUE 1: CONTRAST BLUE 2: FLASH BLUE 3: CONTRAST UMBER 4: UMBER
008 METER DIMMER 00 ~ 15
009 DISPLAY DIMMER 00 ~ 07
010 TUNING OFFSET INDICATOR 0: CLARIFIER OFFSET 1: CW TUNIG METER 2: VRF PEAK POSITION
011 S-METER PEAK HOLD 0: OFF 1: 0.5 sec 2: 1.0 sec 3: 2.0 sec
012 ROTATOR STARTING POINT 0: 0° 1: 90° 2: 180° 3: 270°
013 ROTATOR NEEDLE PRECISELY 00 ~ 30° (0 ~ –30°, 2° step)
014 QMB MAKER 0: OFF 1: ON
015 VOICE MEMORY AUDIO OUTPUT LEVEL 000 ~ 100
016 VOICE MEMORY AUDIO TX LEVEL 000 ~ 100
017 CW BEACON 000 (OFF) ~ 255 sec
018 CONTEST NUMBER STYLE 0: 1290 1: AunO 2: Aunt 3: A2nO 4: A2nt 5: 12nO 6: 12nt
019 CONTEST NUMBER 0000 ~ 9999
020 CW MEMORY “1” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY
021 CW MEMORY “2” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY
022 CW MEMORY “3” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY
023 CW MEMORY “4” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY
024 CW MEMORY “5” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY
025 ANTENNA SELECTION MODE 0: BAND 1: STACK
026 BEEP LEVEL 000 ~ 255
027 CAT BAUD RATE 0: 4800 bps 1: 9600 bps 2: 19200 bps 3: 38400 bps
028 CAT TIME-OUT TIMER 0: 10 msec 1: 100 msec 2: 1000 msec 3: 3000 msec
029 CAT RTS PORT 0: OFF 1: ON
030 MEMORY GROUP 0: OFF 1: ON
031 QUICK SPLIT TUNING OFFSET –20 ~ +00 (or –00) ~ +20 kHz
032 VFO TRACK 0: OFF 1: BAND 2: FREQUENCY
033 TX TIME OUT TIMER 0: OFF 1: 5 min 2: 10 min 3: 15 min 4: 20 min 5: 25 min 6: 30 min
034 TRANSVERTER FREQUENCY DISPLAY 30 ~ 49 MHz
035 μ-TUNE DIAL 0: STEP-2 1: STEP-1 2: OFF
036 SUB (VFO-B)BAND NB LEVEL 1000: NB KNOB 0000 ~ 0100 (FIX)
037 SUB (VFO-B)BAND CW NARROW FILTER 0: 1200 Hz 1: 500 Hz 2: 300 Hz
038 MIC SCAN 0: OFF 1: ON
039 SCAN RESUME 0 PAUSE 1: TIME
040 VOX ANTI-TRIP LEVEL 000 ~ 100
041 FREQUENCY ADJUST –25 ~ +00 (or –00) ~ +25
042 SUB (VFO-B)BAND IF SHIFT (LSB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
043 SUB (VFO-B)BAND IF SHIFT (USB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
044 SUB (VFO-B) BAND IF SHIFT (CW-LSB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
045 SUB (VFO-B)BAND IF SHIFT (CW-USB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
046 SUB (VFO-B)BAND IF SHIFT (RTTY-LSB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
047 SUB (VFO-B)BAND IF SHIFT (RTTY-USB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
048 SUB (VFO-B)BAND IF SHIFT (PKT-LSB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
049 SUB (VFO-B)BAND IF SHIFT (PKT-USB)– 1000 ~ +0000 (or –0000) ~ +1000 Hz
050 AM MIC GAIN 1000: MIC KNOB 0000 ~ 0100 (FIX)
051 AM MIC SELECT 0: MIC JACK 1: DATA JACK 2: N.C.
052 FRONT PANEL KEY JACK TYPE 0: OFF 1: BUG 2: IAMBIC KEYER W/O ACS 3: IAMBIC KEYER W/ACS
053 FRONT PANEL KEY JACK WIRING 0: NORNAL 1: REVERSE
054 REAR PANEL KEY JACK TYPE 0: OFF 1: BUG 2: IAMBIC KEYER W/O ACS 3: IAMBIC KEYER W/ACS
055 REAR PANEL KEY JACK WIRING 0: NORNAL 1: REVERSE
056 CW AUTO MODE 0: OFF 1: 50 MHz ONLY 2: ON
057 CW BFO INJECTION SIDE 0: USB 1: LSB 2: AUTO
058 CW BREAK-IN MODE 0: SEMI BREAK-IN 1: FULL BREAK-IN
059 CW CARRIER WAVE FORM SHAPE 0: 1 msec 1: 2 msec 2: 4 msec 3: 6 msec
060 CW WEIGHT 25 (1:2.5)~ 45 (1:4.5)
061 CW FREQUENCY DISPLAY 0: DIRECT FREQUENCY 1: PITCH OFFSET
062 CW PC KEYING 0: OFF 1: ON
063 CW QSK TIME 0: 15 msec 1: 20 msec 2: 25 mesc 3: 30 msec
064 AFSK MODE DATA INPUT PORT 0: DATA JACK 1: N.C.
065 AFSK MODE DATA INPUT LEVEL 000 ~ 100
066 AFSK MODE DATA OUTPUT BAND 0: MAIN (VFO-A)BAND 1: SUB (VFO-B)BAND
067 AFSK MODE DATA OUTPUT LEVEL 000 ~ 100
068 PSK MODE VOX DELAY TIME 0030 ~ 3000 msec
069 PSK MODE VOX GAIN 000 ~ 100
070 PACKET MODE FREQUENCY DISPLAY OFFSET –3000 ~ +0000 (or –0000) ~ +3000 Hz (10 Hz/step)
071 PACKET MODE CARRIER POINT FREQUENCY –3000 ~ +0000 (or –0000) ~ +3000 Hz (10 Hz/step)
072 FM MIC GAIN 1000: MIC KNOB 0000 ~ 0100 (FIX)
073 FM MIC SELECT 0: MIC JACK 1: DATA JACK 2: N.C.
074 28 MHz REPEATER SHIFT 0000 ~ 1000 kHz (10 Hz/step)
075 50 MHz REPEATER SHIFT 0000 ~ 4000 kHz (10 Hz/step)
TABLE 2

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
P1 FUNCTION P2
076 RTTY MODE RX POLARITY (MARK/SPACE)0: NORNAL 1: REVERSE
077 RTTY MODE TX POLARITY (MARK/SPACE)00.: NORNAL 1: REVERSE
078 RTTY MODE DATA OUTPUT BAND 0: MAIN (VFO-A)BAND 1: SUB (VFO-B)BAND
079 RTTY MODE DATA OUTPUT LEVEL 000 ~ 100
080 RTTY MODE SHIFT FREQUENCY 1: 170 Hz 1: 200 Hz 2: 425 Hz 3: 850 Hz
081 RTTY MODE MARK FREQUENCY 1: 1275 Hz 2: 2125 Hz
082 SSB MODE MIC SELECT 0: MIC JACK 1: DATA JACK 2: N.C.
083 SSB MODE TX BPF BANDWIDTH 0: 50 - 3000 Hz 1: 100 - 2900 Hz 2: 200 - 2800 Hz
3: 300 - 2700 Hz 4: 400 - 2600 Hz 5: 3000WB
084 MAIN (VFO-A)BAND LSB CARRIER POINT –200 ~ +000 (or –000) ~ +200 Hz (10 Hz/step)
085 MAIN (VFO-A)BAND USB CARRIER POINT –200 ~ +000 (or –000) ~ +200 Hz (10 Hz/step)
086 SUB (VFO-B)BAND LSB CARRIER POINT –200 ~ +000 (or –000) ~ +200 Hz (10 Hz/step)
087 SUB (VFO-B)BAND USB CARRIER POINT –200 ~ +000 (or –000) ~ +200 Hz (10 Hz/step)
088 AGC GAIN CURVE 0: NORMAL 1: SLOPED
089 HEADPHONE MODE 0: SEPARATE 1: COMBINE 1 2: COMBIN 2
090 CONTOUR GAIN –40 ~ +00 (or –00) ~ +20 dB
091 CONTOUR WIDTH 01 ~ 11
092 IF NOTCH WIDTH 0: NARROW 1: WIDE
093 DSP CW FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP
094 DSP CW FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE
095 DSP CW NARROW FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz
06: 500 Hz 07: 800 Hz 08: 1200 Hz 09: 1400 Hz 10: 1700 Hz 11: 2000 Hz
096 DSP PSK FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP
097 DSP PSK FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE
098 DSP PSK FILTER BANDWIDTH 0: 25 Hz 1: 50 Hz 2: 100 Hz 3: 200 Hz 4: 300 Hz 5: 400 Hz
099 DSP RTTY FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP
100 DSP RTTY FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE
101 DSP RTTY FILTER BANDWIDTH 0: 25 Hz 1: 50 Hz 2: 100 Hz 3: 200 Hz 4: 300 Hz 5: 400 Hz
102 DSP SSB FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP
103 DSP SSB FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE
104 DSP SSB NARROW FILTER BANDWIDTH 00: 200 Hz 01: 400 Hz 02: 600 Hz 03: 850 Hz 04: 1100 Hz 05: 1350 Hz
06: 1500 Hz 07: 1650 Hz 08: 1800 Hz 09: 1950 Hz 10: 2100 Hz 11: 2250 Hz
105 SPECTRUM SCOPE SCAN START FREQUENCY (1.8 MHz)01800 ~ 01999 (1.800 MHz ~ 1.999 MHz)
106 SPECTRUM SCOPE SCAN START FREQUENCY (3.5 MHz)03500 ~ 03999 (3.500 MHz ~ 3.999 MHz)
107 SPECTRUM SCOPE SCAN START FREQUENCY (5.0 MHz)05250 ~ 05499 (5.250 MHz ~ 5.499 MHz)
108 SPECTRUM SCOPE SCAN START FREQUENCY (7.0 MHz)07000 ~ 07299 (7.000 MHz ~ 7.299 MHz
109 SPECTRUM SCOPE SCAN START FREQUENCY (10 MHz)10100 ~ 10149 (10.100 MHz ~ 10.149 MHz)
110 SPECTRUM SCOPE SCAN START FREQUENCY (14 MHz)14000 ~ 14349 (14.000 MHz ~ 14.349 MHz)
111 SPECTRUM SCOPE SCAN START FREQUENCY (18 MHz)18000 ~ 18199 (18.000 MHz ~ 18.199 MHz
112 SPECTRUM SCOPE SCAN START FREQUENCY (21 MHz)21000 ~ 21449 (21.000 MHz ~ 21.449 MHz)
113 SPECTRUM SCOPE SCAN START FREQUENCY (24.5 MHz)24800 ~ 24989 (24.800 MHz ~ 24.989 MHz)
114 SPECTRUM SCOPE SCAN START FREQUENCY (28 MHz)28000 ~ 29699 (28.000 MHz ~ 29.699 MHz)
115 SPECTRUM SCOPE SCAN START FREQUENCY (50 MHz)50000 ~ 53999 (50.000 MHz ~ 53.999 MHz)
116 MAIN TUNING DIAL KNOB DIALSTEP 0: 1 Hz 1: 10 Hz
117 MAIN TUNING DIAL KNOB CW FINE TUNING 0: OFF 1: ON
118 SUB VFO-B KNOB MHz STEP 0: 0.1 MHz 1: MHz
119 MICROPHNE [UP]/[DOWN]KEY AM STEP 0: 2.5 kHz 1: 5 kHz 2: 9 kHz 3: 10 kHz 4:12.5 kHz
120 MICROPHNE [UP]/[DOWN]KEY FM STEP 0: 5 kHz 1: 6.25 kHz 2: 10 kHz 3: 12.5 kHz 4: 25 kHz
121 MAIN TUNING DIAL KNOB DIALSTEP (FM MODE)0: 10 Hz 1: 100 Hz
122 MY BAND SELECT 0: OFF 1: ON
P2(6): 1.8 MHz P2(7): 3.5 MHz P2(8): 5 MHz P2(9): 7 MHz P2(10): 10 MHz
P2(11): 14 MHz P2(12): 18 MHz P2(13): 21 MHz P2(14): 24.5 MHz P2(15): 28 MHz
P2(16): 50 MHz P2(17): GENERAL P2(17): TRANSVERTER
Example: P2 = 1101010101100 (My Band = 1.8/3.5/7/14/21/28/50 MHz)
123 MIC EQUAQLIZER CENTER FREQUENCY (LOW RANGE)0: OFF 1: 100 Hz 2: 200 Hz 3: 300 Hz 4: 400 Hz 5: 500 Hz
6: 600 Hz 7: 700 Hz
124 MIC EQUAQLIZER GAIN (LOW RANGE)– 10 ~ +00 (or –00) ~ +10
125 MIC EQUAQLIZER BANDWIDTH (LOW RANGE)1 ~ 10
126 MIC EQUAQLIZER CENTER FREQUENCY (MID RANGE)0: OFF 1: 700 Hz 2: 800 Hz 3: 900 Hz 4: 1000 Hz 5: 1100 Hz
6: 1200 Hz 7: 1300 Hz 8: 1400 Hz 9: 1500 Hz
127 MIC EQUAQLIZER GAIN (MID RANGE)– 10 ~ +00 (or –00) ~ +10
128 MIC EQUAQLIZER BANDWIDTH (MID RANGE)01 ~ 10
129 MIC EQUAQLIZER CENTER FREQUENCY (HIGH RANGE)00: OFF 01: 1500 Hz 02: 1600 Hz 03: 1700 Hz 04: 18000 Hz 05: 1900 Hz
06: 2000 Hz 07: 2100 Hz 08: 2200 Hz 09: 2300 Hz 10: 2400 Hz 11: 2500 Hz
12: 2600 Hz 13: 2700 Hz 14: 2800 Hz 15: 2900 Hz 16: 3000 Hz 17: 3100 Hz
18: 3200 Hz
130 MIC EQUAQLIZER GAIN (HIGH RANGE)– 10 ~ +00 (or –00) ~ +10
131 MIC EQUAQLIZER BANDWIDTH (HIGH RANGE)01 ~ 10
132 BIAS LEVEL NO FUNCTION
133 MAXIMUM OUTPUT POWER LIMIT 0: 10 W 1: 20 W 2: 50 W 3: 100 W
134 RF PWR KNOB FUNCTION 0: ALL MODE 1: CARRIER
135 TX-GND JACK 0: DISABLE 1: ENABLE
136 TUNER DRIVEING POWER 0: 10 W 1: 20 W 2: 50 W 3: 100 W
137 VOX OPERATION 0: MIC INPUT 1: DATA INPUT
138 EMERGENCY CHANNEL 0: DISABLE 1: ENABLE
CONTROL COMMAND TABLES
TABLE 3
Page 8

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
FTFT
FTFT
FT FUNCTION TX
Set 12345678910
FTP1 ;
Read 12345678910
FT ;
Answer 12345678910
FTP1 ;
P1 0: Main (VFO-A) Band Transmitter: TX
1: Sub (VFO-B) Band Transmitter: TX
GTGT
GTGT
GT AGC FUNCTION
Set 12345678910
GTP1 P2 ;
Read 12345678910
GTP1 ;
Answer 12345678910
GTP1 P3 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 0: AGC “OFF”
1: AGC “FAST”
2: AGC “MID”
3: AGC “SLOW”
4: AGC “AUTO”
P3 0: AGC “OFF”
1: AGC “FAST”
2: AGC “MID”
3: AGC “SLOW”
4: AGC “AUTO-FAST”
5: AGC “AUTO-MID”
6: AGC “AUTO-SLOW”
FSFS
FSFS
FS FAST STEP
Set 12345678910
FSP1 ;
Read 12345678910
FS ;
Answer 12345678910
FSP1 ;
P1 0: FAST Key “OFF”
1: FAST Key “ON”
IDID
IDID
ID IDENTIFICATION
Set 12345678910
Read 12345678910
ID;
Answer 12345678910
IDP1 P1 P1 P1 ;
P1 0251 (Fixed value)
CONTROL COMMAND TABLES
FF
FF
FAA
AA
AFREQUENCY VFO-A
Set 12345678910
FAP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
Read 12345678910
FA ;
Answer 12345678910
FAP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
P1 30000 - 60000000 (Hz)
FBFB
FBFB
FB FREQUENCY VFO-B
Set 12345678910
FBP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
P1 P1 P1 ;
Read 12345678910
FB ;
Answer 12345678910
FBP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
P1 P1 P1 ;
P1 300000 - 60000000 (Hz)
FKFK
FKFK
FK FUNCTION KEY
Set 12345678910
FKP1 ;
Read 12345678910
Answer 12345678910
P1 1: F1
2: F2
3: F3
4: F4
5: F5
6: F6
7: F7
FRFR
FRFR
FR FUNCTION RX
Set 12345678910
FRP1 ;
Read 12345678910
FR ;
Answer 12345678910
FRP1 ;
P1 0: Main (VFO-A) Band Receiver: RX, Sub (VFO-B) Band Receiver: “OFF”
1: Main (VFO-A) Band Receiver: Mute, Sub (VFO-B) Band Receiver: “OFF”
2: Main (VFO-A) Band Receiver: RX, Sub (VFO-B) Band Receiver: RX
3: Main (VFO-A) Band Receiver: Mute, Sub (VFO-B) Band Receiver: RX
Page 9

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
KSKS
KSKS
KS KEY SPEED
Set 12345678910
KSP1 P1 P1 ;
Read 12345678910
KS ;
Answer 12345678910
KSP1 P1 P1 ;
P1 004 - 060 (WPM)
KYKY
KYKY
KY CW KEYING
Set 12345678910
KYP1 ;
Read 12345678910
Answer 12345678910
P1 1: Keyer Memory “1” Playback 6: Message Keyer “1” Playback
2: Keyer Memory “2” Playback 7: Message Keyer “2” Playback
3: Keyer Memory “3” Playback 8: Message Keyer “3” Playback
4: Keyer Memory “4” Playback 9: Message Keyer “4” Playback
5: Keyer Memory “5” Playback A: Message Keyer “5” Playback
LKLK
LKLK
LK LOCK
Set 12345678910
LKP1 ;
Read 12345678910
LK ;
Answer 12345678910
LKP1 ;
P1 0: DIAL Lock “OFF”
1: DIAL Lock “ON”
KRKR
KRKR
KR KEYER
Set 12345678910
KRP1 ;
Read 12345678910
KR ;
Answer 12345678910
KRP1 ;
P1 0: KEYER “OFF”
1: KEYER “ON”
Page 10
KMKM
KMKM
KM KEYER MEMORY
Set 1234567~53
**
KMP1 P2 P2 P2 P2 ~ P2 ;
Read 12345678910
KMP1 ;
Answer 1234567~53
**
KMP1 P2 P2 P2 P2 ~ P2 ;
P1 1 - 5 : Keyer Memory Channel Number
P2 Message Characters (up to 50 characters)
IFIF
IFIF
IF INFORMATION
Set 12345678910
Read 12345678910
IF;
Answer 12345678910
IFP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 000-117 (Memory Channel) P2 VFO-A Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory 2: Memory Tune 3: Quick Memory Bank (QMB) 4: QMB-MT
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See Table 1)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
CONTROL COMMAND TABLES
ISIS
ISIS
IS IF-SHIFT
Set 12345678910
ISP1 -/+ P2 P2 P2 P2 ;
Read 12345678910
ISP1 ;
Answer 12345678910
ISP1 -/+ P2 P2 P2 P2 ;
P1 0:Fixed
P2 -- 1000 ~ +1000 Hz
KPKP
KPKP
KP KEY PITCH
Set 12345678910
KPP1 P1 ;
Read 12345678910
KP ;
Answer 12345678910
KPP1 P1 ;
P1 00: 300 Hz
01: 350 Hz
02: 400 Hz
03: 450 Hz
04: 500 Hz
05: 550 Hz
06: 600 Hz
07: 650 Hz
08: 700 Hz
09: 750 Hz
10: 800 Hz
11: 850 Hz
12: 900 Hz
13: 950 Hz
14: 1000 Hz
15: 1050 Hz

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
MGMG
MGMG
MG MIC GAIN
Set 12345678910
MGP1 P1 P1 ;
Read 12345678910
MG ;
Answer 12345678910
MGP1 P1 P1 ;
P1 000 - 255
CONTROL COMMAND TABLES
MDMD
MDMD
MD OPERATING MODE
Set 12345678910
MDP1 P2 ;
Read 12345678910
MDP1 ;
Answer 12345678910
MDP1 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
MAMA
MAMA
MA MEMORY CHANNEL TO VFO-A
Set 12345678910
MA ;
Read 12345678910
Answer 12345678910
Page 11
LMLM
LMLM
LM LOAD MESSEGE
Set 12345678910
LMP1 P2 ;
Read 12345678910
LMP1 ;
Answer 12345678910
LMP1 P2 ;
P1 0: DVS P2 When P1=0 When P1=1
1: P. B 0: DVS (Recording Stop) 0: P.B (Recording Stop)
1: DVS (CH “1” Recording Start/Stop) 1: P.B (Recording Start)
2: DVS (CH “2” Recording Start/Stop)
3: DVS (CH “3” Recording Start/Stop)
4: DVS (CH “4” Recording Start/Stop)
5: DVS (CH “5” Recording Start/Stop)
MCMC
MCMC
MC MEMORY CHANNEL
Set 12345678910
MCP1 P1 P1 ;
Read 12345678910
MC ;
Answer 12345678910
MCP1 P1 P1 ;
P1 000 - 117: Memory Channel Number
000 - 099: Regular Memory Channel
100: P1L
101: P1U
116: P9L
117: P9U
~
MLML
MLML
ML MONITOR LEVEL
Set 12345678910
MLP1 P2 P2 P2 ;
Read 12345678910
MLP1 ;
Answer 12345678910
MLP1 P2 P2 P2 ;
P1 0: MONI “ON/OFF”
1: MONI Level
P2 When P1=0
000: MONI “OFF”
001: MONI “ON”
When P1=1
001 - 255
MRMR
MRMR
MR MEMORY CHANNEL READ
Set 12345678910
Read 12345678910
MRP1 P1 P1 ;
Answer 12345678910
MRP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 Memory Channel Number P2 Memory Channel Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See Table 1)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
MKMK
MKMK
MK MODE KEY
Set 12345678910
MKP1 ;
Read 12345678910
Answer 12345678910
P1 KEY 0: LSB
1: USB
2: CW
3: AM
4: FM
5: RTTY
6: PKT

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
NBNB
NBNB
NB NOISE BLANKER STATUS
Set 12345678910
NBP1 P2 ;
Read 12345678910
NBP1 ;
Answer 12345678910
NBP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: Noise Blanker “OFF”
1: Noise Blanker “ON”
2: Noise Blanker (Wide) “ON”
MWMW
MWMW
MW MEMORY CHANNEL WRITE
Set 12345678910
MWP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
Read 12345678910
Answer 12345678910
P1 Memory Channel Number P2 Memory Channel Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: (Fixed)
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See Table 1)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
MSMS
MSMS
MS METER SW
Set 12345678910
MSP1 ;
Read 12345678910
MS ;
Answer 12345678910
MSP1 ;
P1 0: COMP
1: ALC
2: PO
3: SWR
4: ID
5: VDD
MXMX
MXMX
MX MOX SET
Set 12345678910
MXP1 ;
Read 12345678910
NX ;
Answer 12345678910
NXP1 ;
P1 0: MOX “OFF”
1: MOX “ON”
NN
NN
NAA
AA
ANARROW
Set 12345678910
MAP1 P2 ;
Read 12345678910
NAP1 ;
Answer 12345678910
NAP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: OFF
1: ON
CONTROL COMMAND TABLES
OIOI
OIOI
OI OPPOSITE BAND INFORMATION
Set 12345678910
Read 12345678910
OI ;
Answer 12345678910
OIP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 Current Memory Channel P2 VFO-B Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Crarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See Table 1)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
NLNL
NLNL
NL NOISE BLANKER LEVEL
Set 12345678910
NLP1 P2 P2 P2 ;
Read 12345678910
NLP1 ;
Answer 12345678910
NLP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
NRNR
NRNR
NR NOISE REDUCTION
Set 12345678910
NRP1 P2 ;
Read 12345678910
NRP1 ;
Answer 12345678910
NRP1 P2 ;
P1 0: Main Band (VFO-A) Receiver
1: Sub Band (VFO-B) Receiver
P2 0: Noise Reduction “OFF”
1: Noise Reduction “ON”
Page 12

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND TABLES
Page 13
OSOS
OSOS
OS OFFSET (REPEATER SHIFT)
Set 12345678910
OSP1 P2 ;
Read 12345678910
OSP1 ;
Answer 12345678910
OSP1 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 0: Simplex
1: Plus Shift
2: Minus Shift
ÚÚ
ÚÚ
Ú: FM mode only
PCPC
PCPC
PC POWER CONTROL
Set 12345678910
PCP1 P1 P1 ;
Read 12345678910
PC ;
Answer 12345678910
PCP1 P1 P1 ;
P1 000 - 255
PP
PP
PAA
AA
APRE-AMP (IPO)
Set 12345678910
PAP1 P2 ;
Read 12345678910
PAP1 ;
Answer 12345678910
PAP1 P2 ;
P1 0:Fixed
P2 0: IPO
1: AMP 1
2: AMP 2
PBPB
PBPB
PB PLAY BACK
Set 12345678910
PBP1 P2 ;
Read 12345678910
PBP1 ;
Answer 12345678910
PBP1 P2 ;
P1 0: DVS P2 When P1=0 When P1=1
1: P.B 0: DVS 0: P.B (Playback Stop)
1: DVS (CH “1” Playback Start) 1: P.B (Playback Start)
2: DVS (CH “2” Playback Start)
3: DVS (CH “3” Playback Start)
4: DVS (CH “4” Playback Start)
5: DVS (CH “5” Playback Start)
PLPL
PLPL
PL SPEECH PROCESSOR LEVEL
Set 12345678910
PLP1 P1 P1 ;
Read 12345678910
PL ;
Answer 12345678910
PLP1 P1 P1 ;
P1 000 - 255
PRPR
PRPR
PR SPEECH PROCESSOR
Set 12345678910
PRP1 ;
Read 12345678910
PR ;
Answer 12345678910
PRP1 ;
P1 0: Speech Processor “OFF”
1: Speech Processor “ON”
QIQI
QIQI
QI QMB STORE
Set 12345678910
QI ;
Read 12345678910
Answer 12345678910
QRQR
QRQR
QR QMB RECALL
Set 12345678910
QR ;
Read 12345678910
Answer 12345678910
PSPS
PSPS
PS POWER SWITCH
Set 12345678910
PSP1 ;
Read 12345678910
PS ;
Answer 12345678910
PSP1 ;
P1 0: POWER “OFF”
1: POWER “ON”

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
QSQS
QSQS
QS QUICK SPLIT
Set 12345678910
QS ;
Read 12345678910
Answer 12345678910
RARA
RARA
RA RF ATTENUATOR
Set 12345678910
RAP1 P2 ;
Read 12345678910
RAP1 ;
Answer 12345678910
RAP1 P2 ;
P1 0:Fixed
P2 0: OFF
1: 6 dB
2: 12 dB
3: 18 dB
RR
RR
RCC
CC
CCLAR CLEAR
Set 12345678910
RC ;
Read 12345678910
Answer 12345678910
RDRD
RDRD
RD CLAR MINUS OFFSET
Set 12345678910
RDP1 P1 P1 P1 ;
Read 12345678910
Answer 12345678910
P1 0000 - 9999 (Hz)
RFRF
RFRF
RF ROOFING FILTER
Set 12345678910
RFP1 P2 ;
Read 12345678910
RFP1 ;
Answer 12345678910
RFP1 P3 ;
P1 0:Fixed P3 1: 15 kHz
P2 0: AUTO 2: 6 kHz
1: 15 kHz 3: 3 kHz
2: 6 kHz 4: AUTO - 15 kHz
3: 3 kHz 5: AUTO - 6kHz
6: AUTO - 3 kHz
CONTROL COMMAND TABLES
Page 14
RR
RR
RGG
GG
GRF GAIN
Set 12345678910
RGP1 P2 P2 P2 ;
Read 12345678910
RGP1 ;
Answer 12345678910
RGP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
RLRL
RLRL
RL NOISE REDUCTION LEVEL
Set 12345678910
RLP1 P2 P2 ;
Read 12345678910
RLP1 ;
Answer 12345678910
RLP1 P2 P2 ;
P1 0:Fixed
P2 01 - 15
RIRI
RIRI
RI RADIO INFORMATION
Set 12345678910
Read 12345678910
RIP1 ;
Answer 12345678910
RIP1 P2 ;
P1 0: Hi-SWR
1: MIC-EQ
2: CLASS-A
3: REC
4: PLAY
P2 0: OFF
1: ON
RMRM
RMRM
RM READ METER
Set 12345678910
Read 12345678910
RMP1 ;
Answer 12345678910
RMP1 P2 P2 P2 ;
P1 0: Depends of the front panel’s METER knob
1: S Meter (Main) 5: PO Meter
2: S Meter (Sub) 6: SWR Meter
3: COMP Meter 7: ID Meter
4: ALC Meter 8: VDD Meter
P2 0 - 255

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
RR
RR
RTT
TT
TCLAR
Set 12345678910
RTP1 ;
Read 12345678910
RT ;
Answer 12345678910
RTP1 ;
P1 0: RX Clarifier “OFF”
1: RX Clarifier “ON”
RR
RR
RUU
UU
URX CLARIFIER PLUS OFFSET
Set 12345678910
RUP1 P1 P1 P1 ;
Read 12345678910
Answer 12345678910
P1 0000 - 9999 (Hz)
SCSC
SCSC
SC SCAN
Set 12345678910
SCP1 ;
Read 12345678910
SC ;
Answer 12345678910
SCP1 ;
P1 0: Scan “OFF”
1: Scan “ON” (Upward)
2: Scan “ON” (Downward)
CONTROL COMMAND TABLES
RR
RR
ROO
OO
OROTATOR
Set 12345678910
ROP1 ;
Read 12345678910
RO ;
Answer 12345678910
ROP1 P2 P2 P2 P3 P3 P3 ;
P1 0: OFF
1: Counter Clockwise
2: Clockwise
3: SPEED 1 % UP
4: SPEED 1 % DOWN
P2 DIRECTION (0 - 450)
P3 SPEED (0 - 100 %)
RSRS
RSRS
RS RADIO STATUS
Set 12345678910
Read 12345678910
RS ;
Answer 12345678910
RSP1 ;
P1 0: NORMAL MODE
1: MENU MODE
Page 15
SHSH
SHSH
SH WIDTH
Set 12345678910
SHP1 P2 P2 ;
Read 12345678910
SHP1 ;
Answer 12345678910
SHP1 P2 P2 ;
P1 0:Fixed
P2 00 (Counter Clockwise) - 31 (Clockwise), 16 (Center)
SDSD
SDSD
SD CW BREAK-IN DELAY TIME
Set 12345678910
SDP1 P1 P1 P1 ;
Read 12345678910
SD ;
Answer 12345678910
SDP1 P1 P1 P1 ;
P1 0000: Full Break-in
0001 - 5000 mS
SFSF
SFSF
SF SUB VFO-B KNOB FUNCTION
Set 12345678910
SFP1 ;
Read 12345678910
SF ;
Answer 12345678910
SFP1 ;
P1 0: BAND (VFO-A) 4: BAND (VFO-B)
1: MHz (VFO-A) 5: MHz (VFO-B)
2: GRP 6: FAST (VFO-B)
3: MCH 7: A/B
8: Off (Read only)
SMSM
SMSM
SM S-METER READING
Set 12345678910
Read 12345678910
SMP1 ;
Answer 12345678910
SMP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band S-meter
1: Sub (VFO-B) Band S-meter
P2 000 - 255

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
UPUP
UPUP
UP UP
Set 12345678910
UP ;
Read 12345678910
Answer 12345678910
VDVD
VDVD
VD VOX DELAY TIME
Set 12345678910
VDP1 P1 P1 P1 ;
Read 12345678910
VD ;
Answer 12345678910
VDP1 P1 P1 P1 ;
P1 0000 - 5000 mS (20 mS multiples)
VV
VV
VGG
GG
GVOX GAIN
Set 12345678910
VGP1 P1 P1 ;
Read 12345678910
VG ;
Answer 12345678910
VGP1 P1 P1 ;
P1 000 - 255
VFVF
VFVF
VF VRF FILTER
Set 12345678910
VFP1 P2 P3 P4 ;
Read 12345678910
VFP1;
Answer 12345678910
VFP1 P2 P5 P5 P5 P6 ;
P1 0: Fixed P4 0 - 9 (Step)
P2 0: OFF P5 000 - 255
1: ON P6 0: VRF
2: Default set 1: μTUNE
P3 +: Plus Shift
–: Minus Shift
SQSQ
SQSQ
SQ SQUELCLH LEVEL
Set 12345678910
SQP1 P2 P2 P2 ;
Read 12345678910
SQP1 ;
Answer 12345678910
SQP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 000 - 255
ULUL
ULUL
UL PLL UNLOCK STATUS
Set 12345678910
Read 12345678910
UL ;
Answer 12345678910
ULP1 ;
P1 0: PLL “Lock”
1: PLL “Unlock”
CONTROL COMMAND TABLES
SVSV
SVSV
SV SWAP VFO
Set 12345678910
SV ;
Read 12345678910
Answer 12345678910
TSTS
TSTS
TS TXW
Set 12345678910
TSP1 ;
Read 12345678910
TS ;
Answer 12345678910
TSP1 ;
P1 0: TXW “OFF”
1: TXW “ON”
TXTX
TXTX
TX TX SET
Set 12345678910
TXP1 ;
Read 12345678910
TX ;
Answer 12345678910
TXP1 ;
P1 0: RADIO TX “OFF” CAT TX “OFF”
1: RADIO TX “OFF” CAT TX “ON”
2: RADIO TX “ON” CAT TX “OFF” (Answer)
Page 16

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
VXVX
VXVX
VX VOX STATUS
Set 12345678910
VXP1 ;
Read 12345678910
VX ;
Answer 12345678910
VXP1 ;
P1 0: VOX “OFF”
1: VOX “ON”
XTXT
XTXT
XT TX CLAR
Set 1213 4 5 6 7 8 910
XTP1 ;
Read 12345678910
XT ;
Answer 12345678910
XTP1 ;
P1 0: TX CLAR “OFF”
1: TX CLAR “ON”
CONTROL COMMAND TABLES
VMVM
VMVM
VM VFO-A TO MEMORY CHANNEL
Set 12345678910
VM ;
Read 12345678910
Answer 12345678910
VSVS
VSVS
VS VFO SELECT
Set 12345678910
VSP1 ;
Read 12345678910
VS ;
Answer 12345678910
VSP1 ;
P1 0: VFO-A
1: VFO-B
Page 17

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
Page 18
NOTE

FT-2000 CAT OPERATION REFERENCE BOOK
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
Copyright 2006
VERTEX STANDARD CO., LTD.
All rights reserved
No portion of this manual
may be reproduced without
the permission of
VERTEX STANDARD CO., LTD.
Printed in Japan.
0607h-AY
EH025H121
