YahBoom Smartduino HC-SR04 User manual

Smartduino Robots Operation Manual
Shenzhen YahBoom Technology Co.,Ltd
www.yahboom.com

Solemnly Declare
Shenzhen YahBoom Technology Co.,Ltd. Represent that:
I. The procedures and learning materials for this product belong to
Shenzhen YahBoomTechnology Co., Ltd. No entity or individual may use
the data for commercial purposes without the authorization of the
company.
II. When using this product, please use the power supply and electronic
accessories provided by the company. If you replace, disassemble, or
solder the components and modules on the smart car to cause
irreversible damage to the car, you will not be able to enjoy the warranty
service.
III.This product is suitable for makers, students and educational purposes.
It is not applicable to industries, consumer, military and other fields.
IV. The company reserves all rights to interpret this product, including
but not limited to the contents of the product manual, product
description changes and product upgrades. The company will also
replace the manual in time after upgrading the product.
V.Consumers should read this statement before using this product.

Content
目录
I. Packing List.............................................................................................................................................. 1
Arduino Smart Car (Standard Version).............................................................................................. 1
II. Installation For Arduino Smart Car........................................................................................................ 2
2.1 Installation for Servo................................................................................................................... 2
2.2 Installation for Motor & Wheel................................................................................................... 3
2.3 Installation for Battery Box..........................................................................................................3
2.4 Installation for Copper Pillars...................................................................................................... 3
2.5 Installation for Universal Wheel.................................................................................................. 4
2.6 Installation for Servo and Ultrasonic Board................................................................................ 4
2.7 Installation for Arduino board..................................................................................................... 5
2.8 Installation for Breadboard...................................................................................................... 5
III. Fuctions of Usage Intstructions.............................................................................................................6
IV. Wiring Instructions................................................................................................................................7
4.1 Motor drive wiring diagram.........................................................................................................7
4.2 Tracking wiring diagram.............................................................................................................. 8
4.3 Infrared obstacle avoidance wiring diagram............................................................................... 9
4.4 Ultrasonic obstacle avoidance(no servo) wiring diagram......................................................... 10
4.5 Ultrasonic obstacle avoidance(with servo) wiring diagram...................................................... 11
4.6 Remote control wiring diagram.................................................................................................12
4.7 Tracking & Ultrasonic wiring diagram....................................................................................... 13
4.8 Bluetooth remote control wiring diagram................................................................................ 14

1
I. Packing List
Arduino Smart Car (Standard Version)
1. Packing List
1. Arduino UNO Controller * 1
20. Infrared Receiver Module*1
2. Car chassis * 1
21. Active Buzzer * 1
3. Ultrasonic Module * 1
22. Flame Sensor * 1
4. SG90 Servo pan-tilt * 2
23. Light thermistor* 2
5. SG90 Servo & accessories * 1
24. Resistance * 20
6. Wheel * 2
25. Button Switch * 4
7. Reduction motor * 2
26. Adjustable Resistance * 3
8. Breadboard * 2
27. LCD1602 screen* 1
9. Motor Fixing Support * 4
28. USB Cable * 1
10. Battery Box * 1
29. Mini Remote Control * 1
11. Universal Wheel *1
30. 14500 Rechargeable Li Battery * 2
12. Screw&nut&copper pole * 6
31. Male-to-Male Breadboard wire * 30
13. 830 Breadboard * 1
32. Male-to-female Dupont wire * 25
14. 1-digit nixie tube * 1
33. Double-headed Screwdriver * 1
15. 4-digit Nixie Tube * 1
34. Operation Manual * 1
16. 8x8 LED matrix display * 1
17. 74HC595 Chip * 1
18. LED Light * 15
19. Tiltable witch * 2
2. Function Introduction
The standard version of the Arduino Smart Car is a Starter Kit + Smart Car 2-in-1 product. It can
complete small experiments such as answering device, advertising light, and flame alarm. Not
only that,but also infrared obstacle avoidance, follow, ultrasonic automatic driving and other
smart car experiments can be completed. Supporting a full curriculum program and teaching
video. All the codes are open to enthusiasts, and it is the first choice for the pioneering education

2
II. Installation For Arduino Smart Car
Accessory Introduction
M3*8mm Copper
Pillar*7
M3*40mm Copper Pillar*2
M3*4mm Copper
Pillar*4
Fixing Support*4
Need to take away from the two
sides of the car chassis center.
M3 Nut*6
M3*8mm
Screw *2
M3*6mm
Screw*2
M3*30mm
Screw*4
Self-tapping
Screw*2
Small Screw*1
NOTE: The self-tapping screws and small screw are put in the servo accessory bag.
2.1 Installation for Servo
Design Sketch (After Installation)
Installation Instruction: Pass the servo through the lower fixing plate and fix it with self-tapping
screws. The ultrasonic fixing plate is installed on the servo and fixed with small screws.
Small Screw
Self-tapping
Screw

3
2.2 Installation for Motor & Wheel
Design Sketch (After Installation)
Installation Instruction: The motor fixing support passes through the car chassis, and fixed with
screw and nut, then the wheels are mounted on the motors
2.3 Installation for Battery Box
Design Sketch (After Installation)
Installation Instruction: Install the battery box on the bottom of car chassis, fixed with the
M3*8mm screw and nut.
2.4 Installation for Copper Pillars
Design Sketch (After Installation)
M3*8mm
Screw
M3*30 Screw
M3*45mm Copper
pillar
M3*40mm
Copper pillar
M3*8mm
Copper pillar
M3*6mm
Screw

4
Installation Instruction: Install the fixing copper pillar in the right side of the car chassis, 2pcs
M3*40mm copper pillars in the car head, 4pcs M3*45mm copper pillars in the middle, 3pcs
M3*8mm copper pillars in the tailstock. Then using M3*6mm screws to fix them at the bottom
of the car chassis.
2.5 Installation for Universal Wheel
Design Sketch (After Installation)
Installation Instruction: Install 4pcs copper pillars on the back of the tailstock and fix it with
screws on the front. Then install the universal wheel on the back of the car corresponding to the
copper pillar and fix it with screws.
2.6 Installation for Servo and Ultrasonic Board
Design Sketch (After Installation)
Installation Instruction: Install the servo support on the M3*40mm copper pillars at car head and
fixed with the M3*6mm screws.
M3*6mm
Screw
M3*8mm
Copper pillar
M3*6mm
Screw

5
2.7 Installation for Arduino board
Design Sketch (After Installation)
Installation Instruction: Install Arduino board on the 4pcs M3*45mm copper pillars,then fixed by
M3*6mm screws.
2.8 Installation for Breadboard
Design Sketch (After Installation)
Installation Instruction: Install a breadboard holder on the 3pcs M3*8mm copper pillars at
tailstock and fixed with screws. Remove the sticker on the back of the breadboard and affix it to
the holder. After the installation is completed, please select the connection diagram according to
the experimental requirements.
M3*6mm
Screw
M3*6mm
Screw

6
III. Fuctions of Usage Intstructions
Infrared Tracking Mode
①Adjust potentiom【SW3】to make photoelectric sensor【P3】against white undersurface, then
LED light【L3】illumiinates while against black surface, LED light【L3】goes off.
②Adjust potentiom【SW4】to make photoelectric sensor【P2】against white undersurface, then
LED light【L2】illumiinates while against black surface, LED light【L2】goes off.
Caution:Don’t excessively rotate potentiometer while adjusting. It should be within 30°.
Obstacle Avoidance Mode
①Adjust potentiometer【SW1】to make the infrared light-emitting diode【LEAS1】and infrared
light-receiving diode【RC1】away from obstacle less than 10cm, then LED light 【L4】illuminates,
otherwise, it goes off.
②Adjust potentiometer【SW2】to make the infrared light-emitting diode【LEAS2】and infrared
light-receiving diode【RC2】away from obstacle less than 10cm, then LED light 【L5】illuminates,
otherwise, it goes off.
Caution:Don’t excessively rotate potentiometer while adjusting. It should be within 30°.

7
IV. Wiring Instructions
4.1 Motor drive wiring diagram
According to this wiring diagram, the smart car can realize forward, backward, left, right, and
specified fancy movements after uploading the corresponding program.

8
4.2 Tracking wiring diagram
According to the wiring diagram , the smart car can realize the black line tracking function after
uploading the corresponding program. Before the experiment, please refer to (III. Fuctions of
Usage Intstructions).
Active buzzer
Start button

9
4.3 Infrared obstacle avoidance wiring diagram
According to the wiring diagram, the smart car can realize infrared obstacle avoidance and
infrared follow-up functions after uploading the corresponding program. Before the experiment,
please refer to (III. Fuctions of Usage Intstructions).
Active buzzer
Start button

10
4.4 Ultrasonic obstacle avoidance(no servo) wiring diagram
Note: At the J2 slot, insert the ultrasonic sensor as picture.
If you only use the ultrasonic obstacle avoidance function without displaying the distance, you
can not install the 1602 sdisplay and yellow adjustable resistance.
Start button
Active Buzzer

11
4.5 Ultrasonic obstacle avoidance(with servo) wiring diagram
If you only use the ultrasonic obstacle avoidance function without displaying the distance, you
can not install the 1602 sdisplay and yellow adjustable resistance.
Start button
Active Buzzer

12
4.6 Remote control wiring diagram
This experiment requires the use of an infrared remote control. Before use, please remove the
insulated plastic sheet at the bottom of the remote control. The numbers 2,8,4,6 on the remote
control correspond to advance, return back, turn left and ture right; 1,3 corresponds to left and
right rotation; 5 is the stop button.

13
4.7 Tracking & Ultrasonic wiring diagram
Note: At the J2 slot, insert the ultrasonic sensor as picture.
This experiment is a 2in1 comprehensive experiment. The car can detect the obstacles while
tracking. When encountering an obstacle, the car stops waiting in place. After clearing obstacle,
the car continues to track.
Active buzzer
Start botton

14
4.8 Bluetooth remote control wiring diagram
As the Bluetooth module and the serial port of the writer share the IO ports 0 and 1, it will cause
failure in burning. Please remove the VCC of the Bluetooth module power supply before burning,
and then supply power to the Bluetooth module after finishing.

15
Arduino smart car( with bluetooth)
1.Package list
Arduino smart car( standard) + Bluetooth module
2.Introdution
The Arduino Smart Car (Bluetooth Version) has a Bluetooth module added to the standard
configuration. Users can use the APP we provide to perform Bluetooth remote control. The
Bluetooth remote control includes controlling the car's front, rear, left and right travel, adjusting
the speed, and rotating. Smooth operation, good experience, suitable for users who need to play
with remote control cars. The current APP program only supports Android phones.
3. Bluetooth remote control instructions
①First, connect the car according to the Bluetooth experiment
wiring diagram P15.
②Turn on the smart car to ensure the power of the Bluetooth
module is normal (the light of the Bluetooth module is blinking)
③Open the Bluetooth of the mobile phone and find the
Bluetooth module device in the Bluetooth settings. Click to
enter the password: 1234.
④Open Bluetooth App, remote control interface
is as follows. If the Bluetooth function is not
enabled on the phone, the display button next to
the "Bluetooth switch" is dark. Click to open, as
shown in the photo
(Bluetooth can also be set in the mobile system)
⑤Click “Search”
⑥Click the drop-down button to select the physical address of the connected
Bluetooth module
⑦Click“connect”. You will be prompted after successful connection. If the connection fails, you
return to the first step to check and try to reconnect.
