Yamaha MWS150-C User manual

DIC183
MWS150-C
MWS150-A
OWNER’S MANUAL
Read this manual carefully before operating this vehicle.
BE2-F8199-EY
[English (E)]

EAU46091
Readthis manual carefully before operatingthis vehicle. This manual shouldstay with this vehicle if it is sold.
UBE2EYE0.book Page 1 Monday, July 17, 2017 2:03 PM

Introduction
EAU60580
Welcome to the Yamaha world of motorcycling!
As the owner of the MWS150-C / MWS150-A, you are benefiting from Yamaha’s vast experience and newest technology
regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MWS150-C / MWS150-A. The
Owner’s Manual does not only instruct you in how to operate, inspect and maintain your vehicle, but also in how to safe-
guard yourself and others from trouble and injury.
In addition, the many tips given in this manual will help keep your vehicle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your vehicle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA17780
Please readthis manual carefully andcompletely before operatingthis vehicle.
UBE2EYE0.book Page 1 Monday, July 17, 2017 2:03 PM

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is usedto alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoidpossible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, couldresult in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoiddamage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
UBE2EYE0.book Page 1 Monday, July 17, 2017 2:03 PM

Important manual information
EAU37432
MWS150-C / MWS150-A
OWNER’S MANUAL
©2017 by Thai Yamaha Motor Co., Ltd.
1st edition, July 2017
All rights reserved.
Any reprintingor unauthorizeduse
without the written permission of
Thai Yamaha Motor Co., Ltd.
is expressly prohibited.
Printedin Thailand.
UBE2EYE0.book Page 2 Monday, July 17, 2017 2:03 PM

Table of contents
Location of important labels ........... 1-1
Safety information............................ 2-1
Further safe-riding points ............... 2-5
Helmets .......................................... 2-6
Description ....................................... 3-1
Left view ......................................... 3-1
Right view....................................... 3-2
Controls and instruments ............... 3-3
Instrument andcontrol functions... 4-1
Remote control unit ....................... 4-1
Main switch/steering lock............... 4-3
Keyhole shutter .............................. 4-4
Indicator lights and warning
lights............................................ 4-4
Multi-function meter unit ................ 4-6
Handlebar switches...................... 4-10
Front brake lever .......................... 4-11
Rear brake lever ........................... 4-11
ABS (for ABS models) .................. 4-12
Fuel tank cap................................ 4-13
Fuel............................................... 4-14
Fuel tank overflow hose ............... 4-15
Catalytic converter ....................... 4-15
Seat .............................................. 4-16
Passenger footrest ....................... 4-17
Storage compartment .................. 4-17
Accessory box.............................. 4-18
Luggage hook............................... 4-19
Sidestand ......................................4-19
Ignition circuit cut-off system .......4-20
Auxiliary DC jack ..........................4-22
Auxiliary DC connector .................4-22
For your safety – pre-operation
checks ...............................................5-1
Operation andimportant riding
points .................................................6-1
Starting the engine..........................6-1
Starting off ......................................6-2
Acceleration and deceleration ........6-3
Braking............................................6-3
Tips for reducing fuel
consumption................................6-3
Engine break-in...............................6-4
Parking ............................................6-4
Periodic maintenance and
adjustment ........................................7-1
Owner’s tool kit...............................7-2
Periodic maintenance chart for the
emission control system..............7-3
General maintenance and
lubrication chart...........................7-5
Removing and installing the
panel ..........................................7-10
Checking the spark plug...............7-10
Canister.........................................7-12
Engine oil and oil strainer..............7-12
Final transmission oil .................... 7-14
Coolant ......................................... 7-15
Air filter and V-belt case air filter
elements.................................... 7-16
Checking the throttle grip free
play............................................ 7-19
Valve clearance............................. 7-19
Tires .............................................. 7-20
Cast wheels .................................. 7-21
Checking the front brake lever
free play..................................... 7-22
Checking the rear brake lever
free play..................................... 7-22
Checking the front and rear
brake pads ................................ 7-23
Checking the brake fluid level ...... 7-23
Changing the brake fluid .............. 7-25
Checking the V-belt...................... 7-25
Checking and lubricating the
cables........................................ 7-25
Checking and lubricating the
throttle grip and cable............... 7-26
Lubricating the front and rear
brake levers............................... 7-26
Checking and lubricating the
centerstand and sidestand........ 7-27
Checking the front fork................. 7-27
Checking the steering................... 7-28
Checking the wheel bearings ....... 7-28
Checking the steering tie rod ....... 7-29
Checking the leaning system ....... 7-29
UBE2EYE0.book Page 1 Monday, July 17, 2017 2:03 PM

Table of contents
Battery...........................................7-29
Replacing the fuses.......................7-31
Headlight .......................................7-32
Auxiliary lights ...............................7-33
Brake/tail light ...............................7-33
Turn signal light bulb .....................7-33
Replacing the license plate light
bulb ............................................7-34
Troubleshooting ............................7-34
Troubleshooting charts .................7-36
Vehicle care andstorage.................8-1
Matte color caution .........................8-1
Care.................................................8-1
Storage............................................8-4
Specifications....................................9-1
Consumer information ...................10-1
Identification numbers...................10-1
Diagnostic connector ....................10-2
Vehicle data recording ..................10-2
Index ................................................11-1
UBE2EYE0.book Page 2 Monday, July 17, 2017 2:03 PM

Location of important labels
1-1
1
EAU10385
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement
label is available from your Yamaha dealer.
12
UBE2EYE0.book Page 1 Monday, July 17, 2017 2:03 PM

Location of important labels
1-2
1
100kPa=1bar kPa, psi kPa, psi
200, 29 225, 33
200, 29 225, 33
2BL-F1668-00
12
UBE2EYE0.book Page 2 Monday, July 17, 2017 2:03 PM

2-1
2
Safety information
EAU60750
Be a Responsible Owner
As the vehicle’s owner, you are re-
sponsible for the safe and proper oper-
ation of your vehicle.
This is a leaning multi-wheel vehicle.
The safe use and operation of this ve-
hicle is dependent upon the use of
proper riding techniques as well as the
expertise of the operator. Every opera-
tor should know the following require-
ments before riding this vehicle.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of this vehicle’s operation.
Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.
Obtain qualified training in safe
and proper riding techniques.
Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
Never operate a vehicle without
proper training or instruction. Take
a training course. Beginners
should receive training from a cer-
tified instructor. Contact a
Yamaha dealer to find out about
the training courses nearest you.
Safe Riding
Perform the pre-operation checks
each time you use the vehicle to make
sure it is in safe operating condition.
Failure to inspect or maintain the vehi-
cle properly increases the possibility of
an accident or equipment damage.
See page 5-1 for a list of pre-operation
checks.
This vehicle is designed to carry
the operator and a passenger.
The failure of motorists to detect
and recognize scooters and mo-
torcycles in traffic is the predomi-
nating cause of automobile and
such smaller vehicle accidents.
Many accidents have been
caused by an automobile driver
who did not see the smaller vehi-
cle. Making yourself conspicuous
appears to be very effective in re-
ducing the chance of this type of
accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for such smaller vehicle
accidents to occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
• Never maintain a vehicle with-
out proper knowledge. Contact
a Yamaha dealer to inform you
on basic vehicle maintenance.
Certain maintenance can only
be carried out by certified staff.
Many accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent driver’s license.
• Make sure that you are qualified
and that you only lend your ve-
hicle to other qualified opera-
tors.
