Yamaha UD-Stomp Manual

EFFECT BAND
SWITCH
CONNECT
1ON IN NOR 1->1 OFF SIN 23.6 OFF OFF 0 100 3.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 30 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 38.1 OFF OFF 0 100 4.2 2.5 R10 10
4ON IN NOR 4->4 OFF SIN 47.6 OFF OFF 0 100 3.7 2.5 L10 10
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 3.5 2.5 L10 6.5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 3.5 100 3.8 2.5 R10 6.5
7ON IN NOR 7->7 OFF SIN 341 OFF OFF 4.3 100 4.7 2.5 L10 6.5
8ON IN NOR 8->8 OFF SIN 450 OFF OFF 3.4 100 3.3 2.5 R10 6.5
8.5 5 C
* AC= ASSIGNABLE CONTROL
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
011 Chorus 1
by Allan Holdsworth
012 Chorus 2
by Allan Holdsworth
013 Chorus 3
by Allan Holdsworth
021 Chorus 4
by Allan Holdsworth
022 Chorus 5
by Allan Holdsworth
023 Chorus 6
by Allan Holdsworth
031 Chorus 7
by Allan Holdsworth
032 Chorus 8
by Allan Holdsworth
033 Chorus 9
by Allan Holdsworth
1ON IN NOR 1->1 OFF SIN 25.1 OFF OFF 0 100 3 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 33.4 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 43.1 OFF OFF 0 100 3.4 2.5 R10 10
4ON IN NOR 4->4 OFF SIN 50 OFF OFF 0 100 4.2 2.5 L10 10
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 3.5 2.5 L10 6
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 3.5 100 3.8 2.5 R10 6
7ON IN NOR 7->7 OFF SIN 341 OFF OFF 4.3 100 4.7 2.5 L10 6
8ON IN NOR 8->8 OFF SIN 450 OFF OFF 3.4 100 3.3 2.5 R10 6
10 6.5 C
1ON IN NOR 1->1 OFF SIN 25.1 OFF OFF 0 100 3 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 33.4 OFF OFF 0 100 4.5 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 95.6 OFF OFF 0 100 3.4 2.5 R7.0 7
4ON IN NOR 4->4 OFF SIN 120 OFF OFF 0 100 4.2 2.5 L7.0 5.7
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 3.5 2.5 L10 4.5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 3.5 100 3.8 2.5 R10 4.5
7ON IN NOR 7->7 OFF SIN 341 OFF OFF 4.3 100 4.7 2.5 L10 4.5
8ON IN NOR 8->8 OFF SIN 450 OFF OFF 3.4 100 3.3 2.5 R10 4.5
10 6.5 C
1ON IN NOR 1->1 OFF SIN 15.1 OFF OFF 0 100 3.8 2.7 L10 10
2ON IN NOR 2->2 OFF SIN 29 OFF OFF 0 100 4.3 2.7 R10 10
3ON IN NOR 3->3 OFF SIN 41.1 OFF OFF 0 100 5 2.7 L10 10
4ON IN NOR 4->4 OFF SIN 37 OFF OFF 0 100 5.6 2.7 R10 10
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 6 100 3.5 2.7 L10 4
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 5.2 100 3.8 2.7 R10 4
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 5.8 100 4.7 2.7 L10 4
8ON IN NOR 8->8 OFF SIN 463 OFF OFF 5 100 3.3 2.7 R10 4
8 7.5 C
1ON IN NOR 1->1 OFF SIN 21.6 OFF OFF 0 100 3.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 29 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 50 OFF OFF 0 100 4.2 2.5 L10 10
4ON IN NOR 4->4 OFF SIN 40 OFF OFF 0 100 3.7 2.5 R10 10
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 5 100 3.5 2.5 L10 5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 3.8 2.5 R10 5
7ON IN NOR 7->7 OFF SIN 341 OFF OFF 5 100 4.7 2.5 L10 5
8ON IN NOR 8->8 OFF SIN 450 OFF OFF 3.8 100 3.3 2.5 R10 5
88C
1ON IN NOR 1->1 OFF SIN 21.6 OFF OFF 0 100 3.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 29 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 43.2 OFF OFF 0 100 4.3 2.5 L10 10
4ON IN NOR 4->4 OFF SIN 37 OFF OFF 0 100 3.7 2.5 R10 10
5ON IN NOR 5->5 OFF SIN 301 OFF OFF 6 100 3.4 2.5 L10 4.5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 5.2 100 2.3 2.5 R10 4.5
7OFF----- --- - ---- -
8OFF----- --- - ---- -
8.5 6.5 C
1ON IN NOR 1->1 OFF SIN 31.5 OFF OFF 0 25.4 4.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 22.6 OFF OFF 0 25.4 5.2 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 40 OFF OFF 0 25.4 4 2.5 L10 10
4ON IN NOR 4->4 OFF SIN 48 OFF OFF 0 25.4 4.9 2.5 R10 5
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 5 100 3.8 2.5 L10 4
6ON IN NOR 6->6 OFF SIN 361 OFF OFF 4 100 4.2 2.5 R10 4
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5 100 3.5 2.5 L10 4
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 3 100 5 2.5 R10 4
88C
1ON IN NOR 1->1 OFF SIN 31.5 OFF OFF 0 100 4.7 3 L10 10
2ON IN NOR 2->2 OFF SIN 22.6 OFF OFF 0 100 4.8 3 R10 10
3ON IN NOR 3->3 OFF SIN 40 OFF OFF 0 100 6.2 1.7 L10 10
4ON IN NOR 4->4 OFF SIN 48 OFF OFF 0 100 7.1 1.7 R10 10
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 5 100 3.8 2.7 L10 5
6ON IN NOR 6->6 OFF SIN 351 OFF OFF 4 100 4.2 2.7 R10 5
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5 100 3.5 2.7 L10 5
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 3 100 5 2.7 R10 5
7.5 8.5 C
1ON IN NOR 1->1 OFF SIN 31.5 OFF OFF 0 25.4 4.5 5 L10 10
2ON IN NOR 2->2 OFF SIN 22.6 OFF OFF 0 25.4 5.2 5 R10 10
3ON IN NOR 3->3 OFF SIN 40 OFF OFF 0 25.4 4 5 L10 10
4ON IN NOR 4->4 OFF SIN 48 OFF OFF 0 25.4 4.9 5 R10 10
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 5 100 3.8 3.5 L10 4
6ON IN NOR 6->6 OFF SIN 341 OFF OFF 4 100 4.2 3.2 R10 4
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5 100 3.5 3.5 L10 4
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 4 100 5 3.2 R10 4
7.5 8.2 C
V839870 Printed in Taiwan
PATCH LIST

111 Chorus 10
by Allan Holdsworth
112 Chorus 11
by Allan Holdsworth
113 Chorus 12
by Allan Holdsworth
121
Stereo Enhanced Lead Solo Patch 1
by Allan Holdsworth
122 Stereo Enhanced Lead Solo Patch 2
by Allan Holdsworth
123 Stereo Enhanced Lead Solo Patch 3
by Allan Holdsworth
131 Stereo Enhanced Lead Solo Patch 4
by Allan Holdsworth
132 Stereo Enhanced Lead Solo Patch 5
by Allan Holdsworth
133 Stereo Enhanced Lead Solo Patch 6
by Allan Holdsworth
211 Stereo Enhanced Lead Solo Patch 7
by Allan Holdsworth
212 Stereo Enhanced Lead Solo Patch 8
by Allan Holdsworth
213 Stereo Enhanced Lead Solo Patch 9
by Allan Holdsworth
* AC= ASSIGNABLE CONTROL
EFFECT BAND
SWITCH
CONNECT
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
1ON IN NOR 1->1 OFF SIN 29.7 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 40 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 96 OFF OFF 0 100 0 0 L5.0 4
4ON IN NOR 4->4 OFF SIN 110 OFF OFF 0 100 0 0 R5.0 4
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 0 0 L10 5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 5
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 3.5 100 0 0 L10 5
8ON IN NOR 8->8 OFF SIN 461 OFF OFF 3 100 0 0 R10 5
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 25 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 36.8 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 96 OFF OFF 0 100 0 0 L7.5 7
4ON IN NOR 4->4 OFF SIN 110 OFF OFF 0 100 0 0 R7.5 7
5ON IN NOR 5->5 OFF SIN 276 OFF OFF 4.5 100 0 0 L10 5
6ON IN NOR 6->6 OFF SIN 370 OFF OFF 4 100 0 0 R10 5
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 3.5 100 0 0 L10 5
8ON IN NOR 8->8 OFF SIN 461 OFF OFF 3 100 0 0 R10 5
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 36.1 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 45.4 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 92 OFF OFF 0 100 0 0 L7.5 8.5
4ON IN NOR 4->4 OFF SIN 112 OFF OFF 0 100 0 0 R7.5 8.5
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 0 0 L10 4
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 4
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 4 100 0 0 L10 4
8ON IN NOR 8->8 OFF SIN 455 OFF OFF 3.5 100 0 0 R10 4
8.1 8.5 C
1ON IN NOR 1->1 OFF SIN 36.1 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 45 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 134 OFF OFF 0 100 0 0 C 5
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 2.5 100 0 0 L10 4
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 2 100 0 0 R10 4
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 1.7 100 0 0 L10 4
8ON IN NOR 8->8 OFF SIN 455 OFF OFF 1 100 0 0 R10 4
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 20.5 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 37.7 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 96 OFF OFF 0 100 0 0 L5.0 4.5
4ON IN NOR 4->4 OFF SIN 110 OFF OFF 0 100 0 0 R5.0 4.5
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 0 0 L10 4
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 4
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 3.5 100 0 0 L10 4
8ON IN NOR 8->8 OFF SIN 461 OFF OFF 3 100 0 0 R10 4
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 29.7 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 40 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 96 OFF OFF 0 100 0 0 L5.0 6
4ON IN NOR 4->4 OFF SIN 110 OFF OFF 0 100 0 0 R5.0 6
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 0 0 L10 5.5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 5.5
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 3.5 100 0 0 L10 5.5
8ON IN NOR 8->8 OFF SIN 461 OFF OFF 3 100 0 0 R10 5.5
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 23.1 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 33.1 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 110 OFF OFF 0 100 0 0 C 7.5
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 0 0 L10 5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 5
7OFF----- --- - ---- -
8OFF----- --- - ---- -
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 31.8 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 42.1 OFF OFF 0 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 95 OFF OFF 0 100 0 0 L0.0 6
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7ON IN NOR 7->7 OFF SIN 333 OFF OFF 4 100 0 0 L10 4.5
8ON IN NOR 8->8 OFF SIN 445 OFF OFF 3.8 100 0 0 R10 4.5
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 21.2 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 32.1 OFF OFF 0 100 0 0 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 5 100 0 0 L10 4
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 4 100 0 0 R10 4
7OFF----- --- - ---- -
8OFF----- --- - ---- -
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 19.4 OFF OFF 0 25.4 4.5 2.7 L10 10
2ON IN NOR 2->2 OFF SIN 15 OFF OFF 0 25.4 5.2 2.7 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 5 100 3.8 3 L10 3.5
6ON IN NOR 6->6 OFF SIN 351 OFF OFF 4 100 4.2 3 R10 3.5
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5 100 3.5 3 L10 3.5
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 3 100 5 3 R10 3.5
8.5 6 C
1ON IN NOR 1->1 OFF SIN 23.6 OFF OFF 0 25.4 3.9 5 L10 10
2ON IN NOR 2->2 OFF SIN 30 OFF OFF 0 25.4 5.2 5 R10 10
3ON IN NOR 3->3 OFF SIN 40.9 OFF OFF 0 25.4 4 3.5 L10 10
4ON IN NOR 4->4 OFF SIN 48.2 OFF OFF 0 25.4 4.9 3.5 R10 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
88C
1ON IN NOR 1->1 OFF SIN 22 OFF OFF 0 100 4.7 2.3 L10 10
2ON IN NOR 2->2 OFF SIN 27.1 OFF OFF 0 100 5.8 2.3 R10 10
3ON IN NOR 3->3 OFF SIN 30 OFF OFF 0 100 6.8 1 L10 10
4ON IN NOR 4->4 OFF SIN 40 OFF OFF 0 100 7.2 1 R10 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5 100 3.5 3.2 L10 4.5
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 3 100 5 3.2 R10 4.5
7.5 7.5 C

221 Volume Pedal Swell FX 1
by Allan Holdsworth
222 Volume Pedal Swell FX 2
by Allan Holdsworth
223 Single Source Point Stereo Micro-
phone + Echos
by Allan Holdsworth
231 Vintage Echo 1
by Allan Holdsworth
232 Vintage Echo 2
by Allan Holdsworth
233 Vintage Echo 3
by Allan Holdsworth
311
Reverse Phase 4-Band Stereo Chorus 1
(Sine Wave Modulation)
312 Reverse Phase 4-Band Stereo Chorus 2
(Triangle Wave Modulation)
313 6-Band Chorus + Stereo Delay
321 8-Band Chorus 1
(AC: Stereo Effect)
322 8-Band Chorus 2
323 Rotary Chorus
(AC: Rotary Speed)
EFFECT BAND
SWITCH
CONNECT
* AC= ASSIGNABLE CONTROL
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
1ON IN NOR 1->1 OFF SIN 21.6 OFF OFF 0 100 3.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 29 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 350 OFF OFF 4 100 4.2 2.5 L10 10
4ON IN NOR 4->4 OFF SIN 463 OFF OFF 3 100 3.7 2.5 R10 10
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 5.4 100 3.5 2.5 L10 10
6ON IN NOR 6->6 OFF SIN 347 OFF OFF 4.2 100 3.8 2.5 R10 10
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 5.8 100 4.7 2.5 R10 10
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 5 100 3.3 2.5 L10 10
7.5 5 C
1ON IN NOR 1->1 OFF SIN 23.1 OFF OFF 0 100 3.5 2.5 L10 10
2ON IN NOR 2->2 OFF SIN 33.6 OFF OFF 0 100 4 2.5 R10 10
3ON IN NOR 3->3 OFF SIN 43.3 OFF OFF 0 100 4.2 2.5 L10 10
4ON IN NOR 4->4 OFF SIN 51.1 OFF OFF 0 100 3.7 2.5 R10 10
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 6 100 3.5 2.5 L10 10
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 5.2 100 3.8 2.5 R10 10
7ON IN NOR 7->7 OFF SIN 345 OFF OFF 5.8 100 4.7 2.5 L10 10
8ON IN NOR 8->8 OFF SIN 465 OFF OFF 5 100 3.3 2.5 R10 10
7.5 0 C
1ON IN NOR 1->1 OFF SIN 5.25 OFF OFF 0 100 0 0 L10 7
2OFF----- --- - ----
3ON IN REV 3->3 OFF SIN 5.48 OFF OFF 0 100 0 0 R10 10
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 4 100 0 0 L10 3.7
6ON IN NOR 6->6 OFF SIN 341 OFF OFF 3.5 100 0 0 R10 3.7
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 4 100 0 0 L10 3.7
8ON IN NOR 8->8 OFF SIN 400 OFF OFF 3.5 100 0 0 R10 3.7
10 8 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 321 OFF OFF 4.7 100 3.7 2.3 L10 5.5
6ON IN NOR 6->6 OFF SIN 429 OFF OFF 4 100 4.1 2.3 R10 5.5
7ON IN NOR 7->7 OFF SIN 360 OFF OFF 3.5 100 4.6 2.3 C 5
8OFF----- --- - ---- -
8.5 8.5 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 300 OFF OFF 4.5 100 4.5 2 L10 5.5
6ON IN NOR 6->6 OFF SIN 400 OFF OFF 3.7 100 5.4 2 R10 5.5
7ON IN NOR 7->7 OFF SIN 355 OFF OFF 3.5 100 3.9 2 L10 5.5
8ON IN NOR 8->8 OFF SIN 461 OFF OFF 2.7 100 3.4 2 R10 5.5
8.5 8.5 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 250 OFF OFF 4.5 100 3.5 2 L10 5
6ON IN NOR 6->6 OFF SIN 330 OFF OFF 4 100 4.1 2 R10 5
7ON IN NOR 7->7 OFF SIN 300 OFF OFF 3.5 100 3.1 2 L10 5
8ON IN NOR 8->8 OFF SIN 401 OFF OFF 3 100 4.5 2 R10 5
8.5 8.5 C
1ON IN NOR 1->1 OFF SIN 11.3 OFF OFF 0 100 3.3 4.5 L10 10
2ON IN REV 2->2 1 SIN 11.3 OFF OFF 0 100 0 4.5 R10 10
3ON IN NOR 3->3 OFF SIN 15.7 OFF OFF 0 100 4 4 R10 10
4ON IN REV 4->4 3 SIN 15.7 OFF OFF 0 100 0 4 L10 10
5ON IN NOR 5->5 OFF SIN 21.1 OFF OFF 0 100 5 2.5 L10 10
6ON IN REV 6->6 5 SIN 21.1 OFF OFF 0 100 0 2.5 R10 10
7ON IN NOR 7->7 OFF SIN 27 OFF OFF 0 100 5.7 1.5 R10 10
8ON IN REV 8->8 7 SIN 27 OFF OFF 0 100 0 1.5 L10 10
10 10 C
1ON IN NOR 1->1 OFF TRI 11.3 OFF OFF 0 100 3.3 6 L10 10
2ON IN REV 2->2 1 TRI 11.3 OFF OFF 0 100 0 6 R10 10
3ON IN NOR 3->3 OFF TRI 15.7 OFF OFF 0 100 4 5.5 R10 10
4ON IN REV 4->4 3 TRI 15.7 OFF OFF 0 100 0 5.5 L10 10
5ON IN NOR 5->5 OFF TRI 21.1 OFF OFF 0 100 5 3.5 L10 10
6ON IN REV 6->6 5 TRI 21.1 OFF OFF 0 100 0 3.5 R10 10
7ON IN NOR 7->7 OFF TRI 27 OFF OFF 0 100 5.7 2.5 R10 10
8ON IN REV 8->8 7 TRI 27 OFF OFF 0 100 0 2.5 L10 10
10 10 C
1ON IN NOR 1->1 2 TRI 15.1 OFF OFF 0 100 5.7 4.5 L10 7.6
2ON IN NOR 2->2 OFF SIN 19.1 OFF OFF 0 100 4.5 4.1 R10 7.6
3ON IN NOR 3->3 4 TRI 25 OFF OFF 0 100 5.8 4.7 L10 7.6
4ON IN NOR 4->4 OFF TRI 30 OFF OFF 0 100 3.9 4.9 R10 7.6
5ON IN NOR 5->5 6 TRI 37.2 OFF OFF 0 100 4.9 3.5 L10 7.6
6ON IN NOR 6->6 OFF TRI 44 OFF OFF 0 100 3.5 4.4 R10 7.6
7ON 1 NOR 7->7 OFF TRI 400 OFF 3.2 4 0 0 0 L10 8
8ON 2 NOR 8->8 OFF TRI 532 OFF 3.2 1.8 100 0 0 R10 6.9
10 10 C
1ON IN NOR 1->1 OFF SIN 14.1 OFF OFF 0 100 5.7 4.5 L10 7.5
2ON IN NOR 2->2 OFF SIN 18.1 OFF OFF 0 100 4.5 4.1 R10 7.5
3ON IN NOR 3->3 OFF TRI 20.1 OFF OFF 0 100 5.8 4.7 L10 7.5
4ON IN NOR 4->4 OFF TRI 25.1 OFF OFF 0 100 3.9 4.9 R10 7.5
5ON IN NOR 5->5 OFF TRI 29.1 OFF OFF 0 100 4.9 3.5 L10 7.5
6ON IN NOR 6->6 OFF TRI 35.1 OFF OFF 0 100 3.5 4.4 R10 7.5
7ON IN NOR 7->7 OFF SIN 42 OFF OFF 0 100 3 3 L10 8
8ON IN NOR 8->8 OFF SIN 50 OFF OFF 0 100 3.5 3 R10 8
10 10 C
1ON IN NOR 1->1 OFF SIN 15.2 OFF OFF 0 100 2.1 7.9 L10 10
2ON IN NOR 2->2 OFF SIN 80 OFF OFF 0 100 8.1 1.7 C 10
3ON IN NOR 3->3 OFF SIN 50 OFF OFF 0 100 1.6 10 L10 10
4ON IN NOR 4->4 OFF SIN 0.43 OFF OFF 0 100 2.5 7.6 C 10
5ON IN NOR 5->5 OFF SIN 2.72 OFF OFF 4.1 25 5.8 10 C 10
6ON IN NOR 6->6 OFF SIN 7.51 OFF OFF 7.2 93.4 5.8 4.1 L10 10
7ON IN NOR 7->7 OFF SIN 200 OFF OFF 2.2 9.38 0 0 R10 8.4
8ON IN NOR 8->8 OFF SIN 4 OFF OFF 7.7 19.5 3.1 1.1 C 10
10 10 C
1ON IN NOR 1->1 OFF SIN 5 OFF 10 0 100 3.6 8.5 L10 10
2ON IN NOR 2->2 1 SIN 5 OFF 10 0 100 3 8.5 R10 10
3ON IN NOR 3->3 OFF SIN 8 10 OFF 0 100 8.3 3.3 L10 10
4ON IN NOR 4->4 3 SIN 8 10 OFF 0 100 7 3.3 R10 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C

331 Flanger Chorus
(AC: Flanger Feedback)
332 Stereo Flanger + Stereo Delay
333 Delay Chorus
411 Stereo Multi-Delay
(Doubling + Medium Delay + Long Delay)
412 Stereo Filter Delay + Chorus
413 Reverse Phase Stereo Multi-Delay
421
Short + Long Delay for Distortion Solo
(AC: Long Delay Feedback)
422 8-Tap Multi Tap Delay
423 Reverse Delay
431 Multi Tap Pan Delay
(AC: Delay Time)
432 Multi Tap Ping-Pong Delay
433 Volume Style Delay
(AC: Delay Time)
* AC= ASSIGNABLE CONTROL
EFFECT BAND
SWITCH
CONNECT
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
1ON IN NOR 1->1 OFF SIN 40.1 OFF OFF 0 100 0 0 L10 7
2ON IN NOR 2->2 OFF SIN 60 OFF OFF 0 100 0 0 R10 7
3ON 1 NOR 3->3 OFF SIN 145 OFF OFF 0 100 0 0 L10 5
4ON 2 NOR 4->4 OFF SIN 237 OFF OFF 0 100 0 0 R10 5
5ON 1 NOR 5->5 OFF SIN 400 OFF OFF 4.1 100 0 0 L10 10
6ON 2 NOR 6->6 OFF SIN 550 OFF OFF 3.1 100 0 0 R10 10
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 5.61 OFF 10 0 100 5.3 5.8 L10 10
2ON IN NOR 2->2 OFF SIN 5 10 OFF 0 100 5.9 6.5 R10 10
3ON 1 NOR 3->3 OFF SIN 300 OFF 9.3 3.7 100 0 0 L10 10
4ON 2 NOR 4->4 OFF SIN 600 10 5 1.7 100 0 0 R10 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 200 OFF OFF 5 100 0 0 R10 10
2ON IN NOR 2->2 OFF SIN 320 OFF OFF 4.5 100 0 0 L10 10
3ON IN NOR 3->3 OFF SIN 431 OFF OFF 4 100 0 0 R10 10
4ON IN NOR 4->4 OFF SIN 697 OFF OFF 3.6 100 0 0 L10 10
5ON IN REV 5->5 OFF SIN 200 OFF OFF 5 100 0 0 L10 10
6ON IN REV 6->6 OFF SIN 320 OFF OFF 4.5 100 0 0 R10 10
7ON IN REV 7->7 OFF SIN 431 OFF OFF 4 100 0 0 L10 10
8ON IN REV 8->8 OFF SIN 697 OFF OFF 3.6 100 0 0 R10 10
8.2 10 C
1ON IN NOR 1->1 OFF SIN 40 0.1 0.1 0 100 0 0 L10 8
2ON IN NOR 2->2 OFF SIN 60 0.1 0.1 0 100 0 0 R10 8
3ON IN NOR 3->3 OFF SIN 400 OFF 0.1 4.1 100 0 0 L10 10
4ON IN NOR 4->4 OFF SIN 572 OFF 0.1 3.5 100 0 0 R10 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 100 OFF 0.4 7.2 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 151 OFF 0.8 7.1 100 0 0 R10 10
3ON IN NOR 3->3 OFF SIN 211 OFF 1.2 5.4 100 0 0 L10 9
4ON IN NOR 4->4 OFF SIN 280 OFF 1.6 4.5 100 0 0 R10 9
5ON IN NOR 5->5 OFF SIN 361 OFF 2 3.2 100 0 0 L10 8
6ON IN NOR 6->6 OFF SIN 450 OFF 2.4 3.2 100 0 0 R10 8
7ON IN NOR 7->7 OFF SIN 551 OFF 2.8 2.7 100 0 0 L10 7
8ON IN NOR 8->8 OFF SIN 661 OFF 3.2 2.5 100 0 0 R10 7
710 C
1ON IN NOR 1->1 OFF SIN 0.02 OFF OFF 0 100 0 0 L10 3
2ON 1 NOR 2->2 OFF SIN 20 OFF OFF 0 100 0 0 L9.0 4
3ON 2 NOR 3->3 OFF SIN 500 OFF OFF 0 100 0 0 L7.0 5
4ON 3 NOR 4->4 OFF SIN 90 OFF OFF 0 100 0 7.5 L4.0 6
5ON 4 NOR 5->5 OFF SIN 141 OFF OFF 0 100 0 0 L1.0 7
6ON 5 NOR 6->6 OFF SIN 200 OFF OFF 0 100 0 0 R2.5 8
7ON 6 NOR 7->7 OFF SIN 270 OFF OFF 0 100 0 0 R6.0 9
8ON 7 NOR 8->8 OFF SIN 350 OFF OFF 0 100 0 0 R10 10
10 0 C
1ON IN NOR 1->1 OFF SIN 0.02 OFF OFF 0 100 0 4.4 L10 6
2ON IN NOR 2->2 OFF SIN 150 OFF OFF 0 100 0 4.3 L7.5 7
3ON IN NOR 3->3 OFF SIN 300 OFF OFF 0 100 0 0 C 8
4ON IN NOR 4->4 OFF SIN 451 OFF OFF 0 100 0 0 R7.4 9
5ON IN NOR 5->5 OFF SIN 600 OFF OFF 5.4 100 0 0 R10 10
6ON IN NOR 6->7 OFF SIN 1000 OFF OFF 3 100 0 0 L10 10
7OFF----- --- - ---- -
8OFF----- --- - ---- -
6.7 7 C
1ON IN NOR 1->8 OFF SIN 1330 OFF OFF 0.5 12.5 0 0 L5.0 9.2
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 25 0 0 C 8.4
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑37.5 0 0 R5.0 7.6
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 50 0 0 R10 6.8
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑62.5 0 0 R5.0 6
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 75 0 0 C 5.2
7ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑87.5 0 0 L5.0 4.4
8ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑100 0 0 L10 3.6
8.2 10 L10
1ON IN NOR 1->8 OFF S.DN 1970 2 6.1 3.6 100 10 0 L10 10
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑85.5 9 0 R10 9
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑70.3 8 0 L8.1 8
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 57 7 0 R7.1 7
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 43 6 0 L6.1 6
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑28.5 5 0 R5.0 5
7ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑14.5 4 0 L4.1 4
8ON IN NOR 1->8 OFF S.DN ↑↑ ↑ ↑ 0 3 0 R3.1 3
10 0 C
1ON IN REV 1->1 OFF SIN 15.8 OFF OFF 0 100 4 4.5 L10 8
2ON IN NOR 2->2 OFF SIN 18 OFF OFF 0 100 4.5 4.1 R10 8
3ON IN NOR 3->3 OFF SIN 21.1 OFF OFF 0 100 4.6 4.1 L10 7.5
4ON IN NOR 4->4 OFF SIN 23.8 OFF OFF 0 100 5.1 4.1 R10 7.5
5ON IN NOR 5->5 OFF SIN 27 OFF OFF 0 100 4 4.4 L10 7.5
6ON IN NOR 6->6 OFF SIN 29.5 OFF OFF 0 100 2.9 4.4 R10 7.5
7ON IN NOR 7->7 OFF SIN 3 OFF 3.2 7.5 100 3.6 9.1 L10 8.3
8ON IN NOR 8->8 OFF SIN 5.7 OFF 3.2 7.9 100 2.1 9.4 R10 8.3
10 10 C
1ON 3 NOR 1->1 OFF SIN 4 OFF OFF 7 100 3.6 8.2 L10 8.5
2ON 5 NOR 2->2 OFF SIN 4.83 OFF OFF 8 100 2.7 8.4 R10 8.5
3ON IN NOR 3->4 OFF SIN 800 OFF OFF 2.3 100 0 0 L10 5
4OFF----- --- - ---- -
5ON IN NOR 5->6 OFF SIN 1000 OFF OFF 1.8 100 0 0 R10 5
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->2 OFF SIN 400 OFF OFF 2.9 100 0 0 L10 7.5
2ON IN NOR 1->2 OFF SIN ↑↑ ↑ ↑99.6 3.8 2.8 L10 7.5
3ON IN NOR 3->4 OFF SIN 501 OFF OFF 2.5 100 0 0 R10 7.5
4ON IN NOR 3->4 OFF SIN ↑↑ ↑ ↑99.2 3.2 3.4 R10 7.5
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
810 C

511 3-Head Monaural Tape Echo
(AC: Tape Speed)
512 4-Head Monaural Tape Echo
(AC: Tape Speed)
513 5-Head Monaural Tape Echo
(AC: Tape Speed)
521 Stereo Doubling
522 Stereo Slapback Delay
523 Tremolo Chorus
(AC: Speed)
531 Simple Stereo Chorus 1
532 Simple Stereo Chorus 2
(AC: Speed, Depth)
533 Simple Flanger
611 Reverb 1
(AC: Reverb Time)
612 Reverb 2
613 Modulation Reverb
EFFECT BAND
SWITCH
* AC= ASSIGNABLE CONTROL
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
1ON IN NOR 1->3 OFF SIN 841 2.1 8.5 0 100 1.5 1.8 C 3.2
2ON IN NOR 1->3 OFF SIN ↑↑ ↑ ↑72.3 0.9 1.8 C 5.9
3ON IN NOR 1->3 OFF SIN ↑↑ ↑ ↑40.2 0.7 1.8 C 10
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
6.2 10 C
1ON IN NOR 1->4 OFF SIN 1120 2.1 8.5 0 100 1.5 1.8 C 3.2
2ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 75 0.9 1.8 C 5.9
3ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 50 0.7 1.8 C 8
4ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 25 0 0 C 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
6.2 10 C
1ON IN NOR 1->5 OFF SIN 1400 2.1 8.5 0 100 1.5 1.8 C 3.2
2ON IN NOR 1->5 OFF SIN ↑↑ ↑ ↑81.2 0.9 1.8 C 5.4
3ON IN NOR 1->5 OFF SIN ↑↑ ↑ ↑62.9 0.7 1.8 C 6.7
4ON IN NOR 1->5 OFF SIN ↑↑ ↑ ↑44.1 1 1.8 C 8.7
5ON IN NOR 1->5 OFF SIN ↑↑ ↑ ↑ 25 1.2 1.8 C 10
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
5.9 10 C
1ON IN NOR 1->1 OFF SIN 40 OFF OFF 0 100 0 0 L10 10
2ON IN NOR 2->2 OFF SIN 60 OFF OFF 0 100 0 0 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 90 OFF OFF 0 100 0 0 L10 8
2ON IN NOR 2->2 OFF SIN 141 OFF OFF 0 100 0 0 R10 8
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 0.12 OFF 5.7 8 100 6.6 10 C 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 0 C
1ON IN NOR 1->1 OFF TRI 30 OFF 2 0 100 4 3.4 L10 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 R10
1ON IN NOR 1->1 OFF SIN 20 OFF 1 0 100 3.5 3.5 L10 10
2ON IN REV 2->2 1 SIN 20 OFF 1 0 100 0 3.5 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 4.07 OFF OFF 6 100 1.8 9.6 C 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 60 0.3 0.3 0 40.2 0 0 L10 8.1
2ON IN NOR 2->2 OFF SIN 90 0.1 0.1 0 40.6 0 0 R10 8
3ON 2 NOR 3->3 OFF SIN 151 0.1 0.1 1.1 40.6 0 0 L8.0 9
4ON 1 NOR 4->4 OFF SIN 211 0.1 0.1 1.3 40.2 0 0 R8.0 9
5ON 4 NOR 5->5 OFF SIN 310 OFF OFF 3.6 40.2 0 0 C 9
6ON 4 NOR 6->6 OFF SIN 426 OFF OFF 3.9 39.8 0 0 L10 9
7ON 5 NOR 7->7 OFF SIN 496 2 2 3.2 41 0 0 L10 6.3
8ON IN NOR 8->8 OFF SIN 697 2 2 3.7 40.2 0 0 R10 6.8
610 C
1ON IN NOR 1->1 OFF SIN 100 OFF 4 6.5 50 0 0 L10 10
2ON 1 NOR 2->2 OFF SIN 121 OFF 4 6.1 50 0 0 R10 10
3ON 2 NOR 3->3 OFF SIN 150 OFF 4 5.6 50 0 0 L5.0 10
4ON 3 NOR 4->4 OFF SIN 211 OFF 4 5.3 34 0 0 R5.0 10
5ON 4 NOR 5->5 OFF SIN 234 OFF 4 4.7 50 0 0 C 10
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
3.2 10 C
1ON IN NOR 1->1 OFF SIN 100 OFF 4 6.5 50 1 5 L10 10
2ON 1 NOR 2->2 OFF SIN 121 OFF 4 6.1 50 2 4 R10 10
3ON 2 NOR 3->3 OFF SIN 150 OFF 4 5.6 50 3 3 L5.0 10
4ON 3 NOR 4->4 OFF SIN 211 OFF 4 5.3 34 4 2 R5.0 10
5ON 4 NOR 5->5 OFF SIN 234 OFF 4 4.7 50 5 1 C 10
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
3.2 10 C
CONNECT

* AC= ASSIGNABLE CONTROL
EFFECT BAND
SWITCH
CONNECT
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
621 Chorus + Delay + Reverb
(AC: Chorus Level)
622 Analog Reverb Simulation
623 Reverse Phase Delay
631 6-Tap Multi Tap Delay
(AC: Tempo)
632 Long Stereo Delay
633 Tremolo Delay
(AC: Tremolo Depth)
711 Rhythm Delay 1
(AC: Tempo)
712 Rhythm Delay 2
(AC: Tempo)
713 Rhythm Delay 3
(AC: Tempo)
721 Rhythm Delay 4
(AC: Tempo)
722 Ritardando
723 Accelerando
1ON IN NOR 1->6 OFF SIN 1010 OFF 7 1.1 0 0 0 C 3.4
2ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑11.3 0 0 C 6.5
3ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑ 23 0 0 C 10
4ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑ 34 0 0 C 10
5ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑55.9 0 0 C 7
6ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑77.7 0 0 C 5
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF SIN 5890 OFF 7.8 2.8 50.4 0.9 10 L10 10
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑100 0.9 10 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF SIN 1800 OFF 2 4.5 0 0 0 C 4
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑12.5 0 0 C 5.5
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 25 0 0 C 7
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑37.5 0 0 C 8.5
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 50 0 0 C 10
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑62.5 0 0 C 8.5
7ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 75 0 0 C 7
8ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑87.5 0 0 C 5.5
10 0 C
1ON IN NOR 1->2 OFF SIN 750 OFF OFF 2.7 100 0 0 L10 6.3
2OFF----- --- - ---- -
3ON IN NOR 3->4 OFF SIN 1000 OFF OFF 0 100 5.8 2 R10 6.7
4OFF----- --- - ---- -
5ON IN NOR 5->5 OFF SIN 377 OFF OFF 0 100 7.4 1.4 L1.4 7.4
6ON IN NOR 6->6 OFF SIN 250 OFF OFF 0 100 0 0 R5.0 3.7
7ON IN NOR 7->8 OFF SIN 876 OFF OFF 0 100 8.9 2.3 R10 4.8
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF SIN 2400 OFF OFF 0 0 0 0 C 10
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑19.1 0 0 C 10
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑37.9 0 0 C 10
4ON IN NOR 1->8 OFF S.DN ↑↑ ↑ ↑62.9 4.6 7.6 C 10
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 77 0 0 C 10
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->6 OFF SIN 3670 OFF OFF 0 0 0 0 L10 10
2ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑8.59 0 0 L10 10
3ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑17.2 0 0 L10 10
4ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑55.1 0 0 R10 10
5ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑64.1 0 0 R10 10
6ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑72.3 0 0 R10 10
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 0 C
1ON IN NOR 1->2 OFF SIN 800 OFF OFF 5 25.4 0 0 L10 10
2ON IN NOR 1->2 OFF SIN ↑↑ ↑ ↑ 75 0 0 R10 10
3ON IN NOR 3->4 OFF SIN 800 OFF OFF 5 100 0 0 C 10
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF SIN 1800 OFF OFF 0 6.25 0 0 C 10
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑13.7 0 0 C 9.5
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑22.3 0 0 C 9
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑32.4 0 0 C 8.5
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑45.3 0 0 C 8
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑60.2 0 0 C 7.5
7ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑78.1 0 0 C 7
8ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑100 0 0 C 6.5
6.5 10 C
1ON IN NOR 1->8 OFF SIN 1600 OFF OFF 0 21.9 0 0 C 10
2ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑39.8 0 0 C 9.2
3ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑54.7 0 0 C 8.4
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑67.6 0 0 C 7.6
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑77.7 0 0 C 6.8
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑86.3 0 0 C 6
7ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑93.8 0 0 C 5.2
8ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑100 0 0 C 4.4
6.5 10 C
1ON 7 NOR 1->1 OFF SIN 100 OFF 4 6.5 50 1 5 L10 6
2ON 1 NOR 2->2 OFF SIN 121 OFF 4 6.1 50 2 4 R10 6
3ON 2 NOR 3->3 OFF SIN 150 OFF 4 5.6 50 3 3 L5.0 6
4ON 3 NOR 4->4 OFF SIN 211 OFF 4 5.3 34 4 2 R5.0 6
5ON 4 NOR 5->5 OFF SIN 234 OFF 4 4.7 50 5 1 C 6
6ON IN NOR 6->6 OFF SIN 10 OFF OFF 0 100 4 6 C 7.2
7ON 6 NOR 7->7 OFF SIN 270 OFF 3.8 5 100 0 0 C 6
8OFF----- --- - ---- -
810 C
1ON IN NOR 1->6 OFF SIN 92.1 1.6 4.3 5.6 11.3 0 0 C 9.4
2ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑21.1 0 0 C 8.7
3ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑36.7 0 0 C 8.5
4ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑ 52 0 0 C 6.9
5ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑83.6 0 0 C 7
6ON IN NOR 1->6 OFF SIN ↑↑ ↑ ↑100 0 0 C 6.8
7OFF----- --- - ---- -
8OFF----- --- - ---- -
8.5 10 C
1ON IN NOR 1->2 OFF SIN 600 OFF OFF 3.6 100 0 0 L10 10
2ON IN REV 1->2 OFF SIN ↑↑ ↑ ↑100 0 0 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C

EFFECT BAND
SWITCH
CONNECT
* AC= ASSIGNABLE CONTROL
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
731 Scratch Sound
732 Rhythm Delay 5
(AC: Tempo)
733 Dotted 8th Sequence Phrase
w/Tap Tempo
811 Sound Effect 1
812 Sound Effect 2
813 Sound Effect 3
(AC: Alters Sound)
821 Techno Sound
(AC: Alters Sound)
822 Steel Drum
(AC: Stereo Effect)
823 Tape Echo w/Abnormal Head
(AC: Tape Speed)
831 Sound Effect 4
832 Doppler Effect
(AC: Delay Time)
833 Sound Effect 5
1OFF----- --- - ---- -
2ON IN NOR 2->3 OFF SIN 600 OFF OFF 0 29.7 0 0 C 10
3ON IN NOR 2->3 OFF SIN ↑↑ ↑ ↑100 0 0 L10 10
4ON 3 NOR 4->5 OFF S.UP 800 OFF OFF 0 100 0 10 R10 0
5ON 4 NOR 4->5 OFF SIN ↑↑ ↑ ↑100 8.2 9.9 R10 5
6ON 5 NOR 6->8 OFF SIN 1600 3.1 OFF 0 100 0 0 L10 10
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF SIN 1150 OFF OFF 0 0 0 0 C 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑37.5 0 0 C 10
5ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑ 50 0 0 C 10
6ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑62.5 0 0 C 10
7OFF----- --- - ---- -
8ON IN NOR 1->8 OFF SIN ↑↑ ↑ ↑87.5 0 0 C 10
10 0 C
1ON IN NOR 1->2 OFF SIN 486 OFF OFF 0 75 0 0 C 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 100 OFF OFF 4.6 100 5.2 9.6 L10 10
2ON 1 NOR 2->2 OFF SIN 150 OFF OFF 3.8 100 3.2 4.7 R9.6 10
3ON 2 NOR 3->3 OFF SIN 184 OFF OFF 3.8 100 4.5 3 L10 10
4ON 3 NOR 4->4 OFF SIN 200 OFF OFF 4.1 100 2.3 5.3 L10 10
5ON 4 NOR 5->5 OFF SIN 246 OFF OFF 3.8 100 3.4 3.6 L10 10
6ON 5 NOR 6->6 OFF SIN 300 3.1 OFF 4.7 100 0.8 5.1 L10 10
7ON 6 NOR 7->7 OFF SIN 370 4.5 OFF 3.4 100 4.9 1.8 L10 10
8ON 7 NOR 8->8 OFF SIN 400 5.2 OFF 5.7 100 2 2.2 R2.5 10
4.4 0 C
1ON IN NOR 1->1 OFF S.DN 93.1 OFF OFF 8.6 100 6 10 R10 10
2ON 1 NOR 2->2 OFF SIN 300 OFF OFF 5.4 100 2.7 10 L10 10
3ON 2 NOR 3->3 OFF SIN 247 OFF OFF 3.2 27.7 0 0 C 10
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 6 0.1 OFF 10 100 4.4 10 C 6
2ON 1 NOR 2->2 OFF TRI 9 0.2 OFF 10 100 5.4 10 C 5.9
3ON 2 NOR 3->3 OFF SIN 367 0.1 OFF 4.9 100 0 0 C 6
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
5.8 0 C
1ON IN NOR 1->1 OFF S.DN 8.35 OFF 1.4 10 100 10 8.7 C 4.3
2ON 1 NOR 2->2 OFF SIN 1.17 0.4 OFF 7.6 100 10 9.2 C 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN REV 1->1 OFF TRI 3.07 OFF OFF 9.7 100 0 10 L10 10
2ON IN REV 2->2 OFF TRI 1.46 OFF OFF 9.7 100 0 10 R10 10
3ON IN REV 3->3 OFF TRI 1.8 OFF OFF 9.7 100 0 10 L10 10
4ON IN REV 4->4 OFF TRI 1.64 OFF OFF 9.7 100 0 10 R10 10
5ON IN REV 5->5 OFF TRI 3.18 OFF OFF 9.7 100 0 10 L10 10
6ON IN REV 6->6 OFF TRI 4.75 OFF OFF 9.6 100 0 10 R10 10
7ON IN REV 7->7 OFF SIN 3.28 OFF OFF 9.7 100 0 0 L10 10
8ON IN REV 8->8 OFF SIN 4.12 OFF OFF 9.7 100 0 0 R10 10
6.5 6.5 C
1ON IN NOR 1->1 OFF SIN 600 OFF 10 2.7 100 0.6 10 C 8.6
2ON IN NOR 2->2 OFF SIN 600 OFF 10 10 100 0.7 10 C 1.1
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF S.DN 400 OFF OFF 7 29.7 9.3 8.2 L0.2 5.2
2ON 1 NOR 2->2 OFF SIN 30 OFF OFF 9.1 100 1.4 1.4 R10 6.6
3ON 1 NOR 3->3 OFF SIN 34.5 OFF OFF 8.6 100 1.8 4.8 L10 6.6
4ON IN NOR 4->4 OFF SIN 207 OFF OFF 5.3 100 0 0 C 10
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->8 OFF S.DN 1970 2 6.1 3.2 100 2 8.9 L10 10
2ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑85.5 1 5 L7.0 9
3ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑70.3 0 5 L4.0 8
4ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑ 57 0 4 L0.9 7
5ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑ 43 0 3.1 R3.0 6
6ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑28.5 0 2 R7.1 5
7ON IN NOR 1->8 1 SIN ↑↑ ↑ ↑14.5 0 1 R10 4
8ON IN NOR 1->8 1 S.DN ↑↑ ↑ ↑ 0 0 0 R10 3
10 0 C
1ON IN NOR 1->1 OFF SIN 15.2 OFF OFF 0 100 2.1 7.9 L10 10
2ON 1 NOR 2->2 OFF SIN 80 OFF OFF 0 100 8.1 1.7 C 10
3ON 2 NOR 3->3 OFF SIN 50 OFF OFF 0 100 1.6 10 L10 10
4ON 3 NOR 4->4 OFF SIN 0.43 OFF OFF 0 100 2.5 7.6 C 10
5ON 4 NOR 5->5 OFF SIN 2.72 OFF OFF 4.1 25 5.8 10 C 10
6ON 5 NOR 6->6 OFF SIN 7.51 OFF OFF 7.2 93.4 5.8 4.1 L10 10
7ON 6 NOR 7->7 OFF SIN 200 OFF OFF 2.2 9.38 0 0 R10 8.4
8ON 7 NOR 8->8 OFF SIN 4 OFF OFF 7.7 19.5 3.1 1.1 C 10
2.9 2.3 C

* AC= ASSIGNABLE CONTROL
EFFECT BAND
SWITCH
CONNECT
PHASE GROUP SYNC WAVE DELAY TIME LCF HCF FEEDBACK TAP SPEED DEPTH PAN LEVEL EFFECT LEVEL DIRECT LEVEL DIRECT PAN
911 Blank
912 Tap Parameter Sample
913 Connect Sample
921 16-Beat
922 Sync Parameter Sample
923 Wave Parameter Sample
931 Loop Sampling 1
932 Loop Sampling 2
933 Loop Sampling 3
1ON IN NOR 1->4 OFF SIN 459 0.1 OFF 4.8 100 0 0 C 10
2ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 25 0 0 C 6.5
3ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 50 0 0 C 7.1
4ON IN NOR 1->4 OFF SIN ↑↑ ↑ ↑ 75 0 0 C 6.5
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 10 OFF OFF 0 100 3 6.1 L10 10
2ON IN NOR 2->2 1 SIN 10 OFF OFF 0 100 0 6.1 R10 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 30 OFF OFF 0 100 5.7 10 L10 10
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 5.7 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8ON IN NOR 8->8 OFF SIN 300 OFF OFF 3.7 100 0 0 C 7.6
10 10 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8ON 1 NOR 8->8 OFF SIN 300 OFF OFF 3 100 0 0 C 8
10 10 C
1OFF----- --- - ---- -
2OFF----- --- - ---- -
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 361 OFF OFF 0 100 0 0 C 10
2ON IN NOR 2->2 OFF SIN 361 OFF OFF 0 100 0 0 C 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
1ON IN NOR 1->1 OFF SIN 600 OFF OFF 0 100 0 0 C 10
2ON IN NOR 2->2 OFF SIN 80 OFF OFF 0 100 0 0 C 10
3OFF----- --- - ---- -
4OFF----- --- - ---- -
5OFF----- --- - ---- -
6OFF----- --- - ---- -
7OFF----- --- - ---- -
8OFF----- --- - ---- -
10 10 C
