Yamaha Cp88 Instructions and recipes

Contents

New Functions in CP Version 1.30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Storing Master EQ settings to the Live Set Sound. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . 3

Improved operability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Additional new Voices . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Additional new Live Set Sounds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

New Functions in CP Version 1.20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Additional new parameters for controllers.. . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Selecting menus with the LIVE SET [1]-[6] buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Initializing the current Live Set Sound with the [EXIT] + [SETTINGS] buttons. . . . . . .. . . . . . . . . . . . 13

Additional new Voices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Additional new Live Set Sounds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

New Functions in CP Version 1.10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Loading a specific Live Set Sound from all data files. . . . . . . . . . . . . . . . . . . . . . . . . . . 18

MIDI Control Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Additional new Voices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Additional new Live Set Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

CP88/73 Supplementary Manual 2

New Functions in CP Version 1.30

Yamaha has upgraded the CP firmware, adding the following new functions.

This manual describes additions and changes with respect to the Owner’s Manual that came with your instrument.

• You can now store the Master EQ settings to the Live Set.

• Operability has been improved.

• New Voices have been added.

• New Live Set Sounds have been added.

CP88/73 Supplementary Manual 3

Storing Master EQ settings to the Live Set Sound

[SETTINGS] →Selecting the Function with encoder dial →[ENTER]

Live Set EQ has been added to the Function section.

Function

Function name Description

Live Set EQ Mode SW Determines whether or not to store the Master EQ settings to the Live

Set Sound. When this is set to “On,” an EQ icon is displayed in the Top

screen.

EQ Settings You can check the saved Master EQ settings in the EQ settings. You

can also set the EQ using the EQ settings, as well as with the knobs and

buttons.

High Gain Use this knob to adjust the gain of the high EQ band (5 kHz).

Settings: -12 dB – +12 dB

Mid Gain Use this knob to adjust the gain of the mid EQ band (100 Hz – 10 kHz).

Settings: -12 dB – +12 dB

Mid

Frequency

Use this knob to adjust the center frequency of the midrange.

Settings: 100 Hz – 10 kHz

Low Gain Use this knob to adjust the gain of the low EQ band (80 Hz).

Settings: -12 dB – +12 dB

ON/OFF Use this function to determine whether to apply the Master EQ (ON)

or not (OFF).

CP88/73 Supplementary Manual 4

Improved operability

The setting at the start of the operation is also shown in the display along with the newly changed setting.

When you press [ENTER] on the Name display, a popup appears prompting you to either store or not store the settings. Select “Store” to go

to the Store display, or select “Do not store now” to return to the Home display, with setting only the Live Set name.

NOTE

Keep in mind that the Live Set name is not stored when you select “Do not store now.” If you want the Live Set and its name to be stored,

make sure to execute the Store operation.

You can now move to the Fixed Velocity display by pressing both the [EXIT] and [TOUCH] buttons.

You can now set the Split Point and close the screen automatically, by pressing both the [SPLIT] button and the desired key.

CP88/73 Supplementary Manual 5

Additional new Voices

This CP update provides 3 new Voices ( ).

Voice List

Section Category No. Voice CC No.

PIANO Grand Piano 01 CFX 1

02 Imperial 2

03 S700 3

04 Digi Piano 4

05 C7 58

06 CF3 92

Upright Piano 01 U1 5

02 SU7 6

CP 01 CP80 1 7

02 CP80 2 8

Special Piano 01 Piano Strings 9

02 Piano Synth 10

E.PIANO Rd 01 78Rd 11

02 75Rd Funky 12

03 73Rd 13

04 67Rd Dark 59

05 67Rd Bright 60

06 73Rd Studio 93

07 74Rd Stage 94

Wr 01 Wr Warm 14

02 Wr Bright 15

03 Wr Wide 61

Clv 01 Clavi B 16

02 Clavi S 17

03 Harpsichord 18

DX 01 DX Legend 19

02 DX Woody 20

03 DX FTine 21

04 DX 7 II 22

05 DX Mellow 23

06 DX Crisp 24

SUB Pad/Strings 01 Mellow Pad 25

02 Spectrum 26

03 Back Pad 27

04 Air Choir 28

05 Natural Str 29

06 Warm Strings 30

07 OB Strings 31

08 Section Str 32

09 Fat Saw Pad 62

10 Noble Pad 63

11 Pop Pad 64

12 Analog Pad 65

13 Itopia 66

14 Marcato Str 67

15 Slow Str 68

16 Tape Str 69

17 Oct Syn Str 70

Organ 01 Bright Bars 33

02 Click Organ 34

03 Draw Organ 1 35

04 All Bars Out 36

05 Draw Organ 2 37

06 60s Combo 38

07 Compact 39

08 Panther 40

09 Pipe Organ 1 41

10 Pipe Organ 2 42

Chromatic Perc. 01 Glocken 43

02 Vibraphone 44

03 Xylophone 45

04 Marimba 46

05 Brightness 47

06 Jazz Vibes 71

07 Marimba 2 72

08 Kalimba 73

09 Heaven Bell 74

10 Nice Bell 48

11 Stack Bell 49

Section Category No. Voice CC No.

SUB Others 01 Syn Lead 1 50

02 Syn Lead 2 51

03 Syn Bass 52

04 E.Bass 53

05 A.Bass 54

06 Steel Gt 55

07 Clean Gt 56

08 Syn Brass 57

09 Sine Lead 75

10 Sync Saw 76

11 Dirty Hook 77

12 Classic Mini 78

13 Funky Mini 79

14 Nu Mini 80

15 80s Pop Bass 81

16 Sub Bass 82

17 Unison Bass 83

18 Finger Bass 84

19 Brass 85

20 Syn Brass 2 86

21 OB Brass 1 87

22 OB Brass 2 88

23 Jazz Flute 89

24 Tape Flute 90

25 Harmonica 91

Additional new Live Set Sounds

This CP update provides new Live Set Sounds ( ) to page 8.

Live Set Sound List

Page

No Name

Split

Point

Section Voice Name MSB LSB PC Page No Name

Split

Point

Section Voice Name MSB LSB PC

1

Natural CFX

G2

Piano

CFX

63

0

1

3

7

Big S700

G2

Piano

S700

63

2

7

E.Piano

-

E.Piano

73Rd

Sub

-

Sub

OB Strings

1

2

NaturalImperial

G2

Piano

Imperial

63

0

2

3

8

Piano Scape

G2

Piano

Imperial

63

2

8

E.Piano

-

E.Piano

DX Legend

Sub

-

Sub

Mellow Pad

1

3

Jazz S700

G2

Piano

S700

63

0

3

4

1

Compressed CFX

G2

Piano

CFX

63

3

1

E.Piano

-

E.Piano

-

Sub

-

Sub

-

1

4

Rock Upright

G2

Piano

U1

63

0

4

2

Kinda Squashed

G2

Piano

Imperial

63

3

2

E.Piano

-

E.Piano

-

Sub

-

Sub

-

1

5

Simple 78

G2

Piano

-

63

0

5

4

3

Layered CFX

G2

Piano

CFX

63

3

E.Piano

78Rd

E.Piano

75Rd Funky

Sub

-

Sub

Mellow Pad

1

6

Funky Tines

G2

Piano

-

63

0

6

4

Chorus CFX

G2

Piano

CFX

63

3

4

E.Piano

75Rd Funky

E.Piano

-

Sub

-

Sub

-

1

7

Tremolo Wr

G2

Piano

-

63

0

7

4

5

Upright

G2

Piano

U1

63

3

5

E.Piano

Wr Warm

E.Piano

-

Sub

-

Sub

-

1

8

Clavi B Amped

G2

Piano

-

63

0

8

4

6

A Tacky Piano

G2

Piano

SU7

63

3

6

E.Piano

Clavi B

E.Piano

75Rd Funky

Sub

-

Sub

Brightness

2

1

CFX+DX Legend

G2

Piano

CFX

63

1

4

7

HonkyTonk Piano

G2

Piano

U1

63

3

7

E.Piano

DX Legend

E.Piano

-

Sub

-

Sub

-

2

A.Bass/78Rd

G2

Piano

U1

63

1

2

4

8

Old Record

G2

Piano

U1

63

3

8

E.Piano

78Rd

E.Piano

-

Sub

A.Bass

Sub

-

2

3

80s El Grand

G2

Piano

CP80 1

63

1

3

5

1

Case 73

G2

Piano

-

63

4

1

E.Piano

-

E.Piano

73Rd

Sub

-

Sub

-

2

4

Brite Pop 8ve

G2

Piano

Digi Piano

63

1

4

5

2

Chimin' Tines

G2

Piano

Digi Piano

63

4

2

E.Piano

DX Legend

E.Piano

78Rd

Sub

OB Strings

Sub

Glocken

2

5

E.Bass/78Rd

G2

Piano

-

63

1

5

3

Slow Phase

G2

Piano

-

63

4

3

E.Piano

78Rd

E.Piano

73Rd

Sub

E.Bass

Sub

-

2

6

Driven Wr+Pad

G2

Piano

-

63

1

6

5

4

73 Tines OD

G2

Piano

-

63

4

E.Piano

Wr Warm

E.Piano

73Rd

Sub

Warm Strings

Sub

-

2

7

Imperial + Str

G2

Piano

Imperial

63

1

7

5

Fast Phaser

G2

Piano

-

63

4

5

E.Piano

-

E.Piano

75Rd Funky

Sub

Section Str

Sub

-

2

8

Ghostly U1

G2

Piano

U1

63

1

8

5

6

Ampy Funk

G2

Piano

-

63

4

6

E.Piano

Wr Warm

E.Piano

75Rd Funky

Sub

-

Sub

-

3

1

Rock Grand

G2

Piano

CFX

63

2

1

5

7

Wet Phase

G2

Piano

-

63

4

7

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

-

3

2

S700 + Pad

G2

Piano

S700

63

2

5

8

78 & Pad

G2

Piano

-

63

4

8

E.Piano

-

E.Piano

78Rd

Sub

OB Strings

Sub

Mellow Pad

3

MonoCmp CFX

G2

Piano

CFX

63

2

3

6

1

Wr Bright

G2

Piano

-

63

5

1

E.Piano

-

E.Piano

Wr Bright

Sub

-

Sub

-

3

4

Lo Fi Grand

G2

Piano

CFX

63

2

4

6

2

Wr Comp

G2

Piano

-

63

5

2

E.Piano

-

E.Piano

Wr Warm

Sub

-

Sub

-

3

5

Piano Grind Pad

G2

Piano

Piano Synth

63

2

5

6

3

Clavi B

G2

Piano

-

63

5

3

E.Piano

73Rd

E.Piano

Clavi B

Sub

Mellow Pad

Sub

-

3

6

Lush Love

G2

Piano

Imperial

63

2

6

4

Driven S

G2

Piano

-

63

5

4

E.Piano

78Rd

E.Piano

Clavi S

Sub

Brightness

Sub

-

CP88/73 Supplementary Manual 7

Page No Name

Split

Point

Section Voice Name MSB LSB PC Page No Name

Split

Point

Section Voice Name MSB LSB PC

6

5

Clavi Wah Dist

G2

Piano

-

63

5

9

7

Syn Brass

G2

Piano

-

63

8

7

E.Piano

Clavi B

E.Piano

-

Sub

-

Sub

Syn Brass

6 6 Squeeze B G2 Piano - 63 5 6

9 8 Syn Lead1 G2 Piano - 63 8 8

E.Piano

Clavi B

E.Piano

78Rd

Sub

-

Sub

Syn Lead 1

6

7

Long Chorus S

G2

Piano

-

63

5

7

10

1

Harpsichord

G2

Piano

-

63

9

1

E.Piano Clavi S

E.Piano Harpsichord

Sub

-

Sub

-

6

8

Rock Wr w/Ba

G2

Piano

Digi Piano

63

5

8

10

2

Electric Harpsi

G2

Piano

-

63

9

2

E.Piano

Wr Bright

E.Piano

Harpsichord

Sub E.Bass

Sub -

7

1

CP80 Comp

G2

Piano

CP80 1

63

6

1

10

3

Pipes Rd PBMW

G2

Piano

Digi Piano

63

9

3

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

Pipe Organ 2

7 2 Natural CP80 G2 Piano CP80 2 63 6 2

10 4 Funky w/RdBass G2 Piano CP80 1 63 9 4

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

Marimba

7

3

Chorus Legend

G2

Piano

-

63

6

3

10

5

Rough Lead

G2

Piano

CP80 2

63

9

5

E.Piano DX Legend

E.Piano 78Rd

Sub

-

Sub

Back Pad

7

4

Chorus FTine

G2

Piano

-

63

6

4

10

6

Clavi Syn Wah

G2

Piano

-

63

9

6

E.Piano

DX FTine

E.Piano

Clavi B

Sub Mellow Pad

Sub Syn Lead 1

7

5

Chorus 7II

G2

Piano

-

63

6

5

10

7

Chimin' Crs

G2

Piano

Digi Piano

63

9

7

E.Piano

DX 7 II

E.Piano

75Rd Funky

Sub

-

Sub

Glocken

7 6 Legend + Pad G2 Piano - 63 6 6

10 8 Brite Pop G2 Piano Digi Piano 63 9 8

E.Piano

DX Legend

E.Piano

DX Legend

Sub

OB Strings

Sub

OB Strings

7

SynBass/DXEP

G2

Piano

-

63

6

7

11

1

Back to 60s SP

G2

Piano

-

63

10

1

E.Piano DX Mellow

E.Piano 67Rd Dark

Sub

Syn Bass

Sub

-

7

8

Digi DX Pads

G2

Piano

Digi Piano

63

6

8

11

2

80s Piano JG

G2

Piano

C7

63

10

2

E.Piano

DX Legend

E.Piano

78Rd

Sub Mellow Pad

Sub -

8

1

Bright Bars

G2

Piano

-

63

7

1

11

3

NaturalWrWideJG

G2

Piano

-

63

10

3

E.Piano

-

E.Piano

Wr Wide

Sub

Bright Bars

Sub

-

8 2 All Bars Out G2 Piano - 63 7 2 11 4

Chorused67Rd

SP

G2 Piano - 63 10 4

E.Piano

-

E.Piano

67Rd Bright

Sub

All Bars Out

Sub

-

8 3 PipeOrgan1 G2 Piano - 63 7 3

11 5 R&B Ballad NS G2 Piano - 63 10 5

E.Piano

-

E.Piano

67Rd Dark

Sub

Pipe Organ 1

Sub

-

8

4

PipeOrgan2

G2

Piano

-

63

7

4

11

6

Squashed C7 NS

G2

Piano

C7

63

10

6

E.Piano -

Sub

Pipe Organ 2

Sub

-

8 5 The Red Combo G2 Piano - 63 7 5 11 7

WrWideChorus

SP

G2 Piano - 63 10 7

E.Piano

-

E.Piano

Wr Wide

Sub

60s Combo

Sub

-

8

6

Italian Combo

G2

Piano

-

63

7

6

11

8

Driven 67Rd JG

G2

Piano

-

63

10

8

E.Piano -

E.Piano 67Rd Bright

Sub

Compact

Sub

-

8

7

Aggro Syn Pad

G2

Piano

-

63

7

12

1

CFX + Slow Str

G2

Piano

CFX

63

11

1

E.Piano

78Rd

E.Piano

-

Sub Panther

Sub Slow Str

8

RdBa/60sCombo

G2

Piano

-

63

7

8

12

2

C7 + Noble Pad

G2

Piano

C7

63

11

2

E.Piano

78Rd

E.Piano

-

Sub

60s Combo

Sub

Noble Pad

9 1 Strings1 G2 Piano - 63 8 1

12 3 78Rd+AnalogPad G2 Piano - 63 11 3

E.Piano

-

E.Piano

78Rd

Sub

Natural Str

Sub

Analog Pad

9 2 Strings2 G2 Piano - 63 8 2 12 4

78Rd+OBBrass

MW

G2 Piano - 63 11 4

E.Piano

-

E.Piano

78Rd

Sub

Section Str

Sub

OB Brass 1

9

3

Synth Pad1

G2

Piano

-

63

8

3

12

5

Sync Saw/DX EP

G2

Piano

-

63

11

5

E.Piano -

E.Piano DX Legend

Sub

Mellow Pad

Sub

Sync Saw

9

4

Synth Pad2

G2

Piano

-

63

8

4

12

6

Fat Saw Pad MW

G2

Piano

-

63

11

6

E.Piano

-

E.Piano

-

Sub Warm Strings

Sub Fat Saw Pad

9

5

Vibraphone

G2

Piano

-

63

8

5

12

7

OB Brass

G2

Piano

-

63

11

7

E.Piano

-

E.Piano

-

Sub

Vibraphone

Sub

OB Brass 2

9 6 Nice Bell G2 Piano - 63 8 6 12 8 Marcato Str G2 Piano - 63 11 8

E.Piano

-

E.Piano

-

Sub

Nice Bell

Sub

Marcato Str

CP88/73 Supplementary Manual 8

Page No Name

Split

Point

Section Voice Name MSB LSB PC

13

1

73Rd Studio

G2

Piano

-

63

12

1

E.Piano

73Rd Studio

Sub

-

13 2 73Rd Chorus G2 Piano - 63 12 2

E.Piano

73Rd Studio

Sub

-

14

3

73Rd+AnalogPad

G2

Piano

-

63

12

3

E.Piano 73Rd Studio

Sub

Analog Pad

14

4

73Rd+AP

G2

Piano

C7

63

12

4

E.Piano

73Rd Studio

Sub -

15

5

74Rd Stage

G2

Piano

-

63

12

5

E.Piano

74Rd Stage

Sub

-

15 6Overdriven 74Rd G2 Piano - 63 12 6

E.Piano

74Rd Stage

Sub

-

16

7

CF3

G2

Piano

-

63

12

7

E.Piano CF3

Sub

-

16

8

CF3+AnalogPad

G2

Piano

CF3

63

12

8

E.Piano

-

Sub Analog Pad

CP88/73 Supplementary Manual 9

New Functions in CP Version 1.20

Yamaha has upgraded the CP firmware, adding the following new functions.

This manual describes additions and changes with respect to the Owner’s Manual that came with your instrument.

• Menus and parameters below Controllers have been added.

• You can now select menus with the LIVE SET [1]-[6] buttons.

• You can now initialize the current Live Set Sound with the [EXIT] button + [SETTINGS] button.

• New Voices have been added.

• New Live Set Sounds have been added.

CP88/73 Supplementary Manual 10

Additional new parameters for controllers

[SETTINGS] →Selecting the Controllers with encoder dial →[ENTER]

The menus under the Controllers have been changed to Bend Range, Modulation Lever, Foot Controller 1, Foot Controller 2

and Receive SW, and parameters have been added.

Controllers

Function name Description

Bend Range Piano Determines the maximum Pitch Bend Range in semitones for each

Voice section.

Settings: -24 – +0 – +24

Default: +2

E.Piano

Sub

Modulation Lever Assign MIDI control change numbers generated by operating the Modulation

Lever.

Default: 1 (Modulation)

NOTE

You can now assign the USB Audio Volume to the Modulation Lever.

Limit Low Determines the upper and lower limits for the control change values

generated by operating the modulation lever.

Limit High

P.Mod Depth Piano Determines the depth of vibrato effect on keyboard sound. This can be

set individually for each Voice section.

Settings: 0 – 127

Piano/E.Piano default: 0

Sub default: 10

NOTE

Since the vibrato effect is disabled when a “Rotary” effect of the Sub

section is selected, this setting will also be disabled.

E.Piano

Sub

P.Mod Speed Piano Determines the speed of the vibrato effect on the keyboard sound, and

can be set individually for each Voice section.

Settings: -64 – +63

Default: 0

NOTE

Since the vibrato effect is disabled when a “Rotary” effect of the Sub

section is selected, this setting will also be disabled.

E.Piano

Sub

CP88/73 Supplementary Manual 11

Function name Description

Foot Controller 1 Assign MIDI control change numbers generated by operating a foot controller

(sold separately) connected via the FOOT CONTROLLER [1] jack.

Default: 11 (Expression)

NOTE

You can now assign the USB Audio Volume to the Foot Controller 1.

Limit Low

Determines the upper and lower limits for the control change values

generated by operating the foot controller.

Limit High

Foot Controller 2 Assign MIDI control change numbers generated by operating a foot controller

(sold separately) connected via the FOOT CONTROLLER [2] jack.

Default: 4 (Pedal Wah)

NOTE

You can now assign the USB Audio Volume to the Foot Controller 2.

Limit Low

Determines the upper and lower limits for the control change values

generated by operating the foot controller.

Limit High

Receive SW Expression

Piano

Determines whether to recognize (On) or ignore (Off) the

corresponding MIDI messages received by each Voice section from

external devices or the MIDI messages generated by operating a foot

switch and foot controller.

Default: On

E.Piano

Sub

Sustain

Piano

E.Piano

Sub

Sostenuto

Piano

E.Piano

Sub

Soft

Piano

E.Piano

Sub

CP88/73 Supplementary Manual 12

Selecting menus with the LIVE SET [1]-[6] button

LIVE SET [1]-[6] (when operating MENU or SETTINGS)

You can now select menus with the LIVE SET [1]-[6] buttons. The LIVE SET [1]-[6] buttons correspond to the menus displayed in order

from top to bottom. When this function is working, the LIVE SET [1]-[6] buttons light.

Example:

When in the General menu, you can select USB Audio Volume pressing LIVE SET [5] button.

NOTE

When there are seven or more menus available, this function cannot be used and the LIVE SET [1]-[6] buttons do not light.

CP88/73 Supplementary Manual 13

Initializing the current Live Set Sound with the [EXIT] + [SETTINGS]

buttons

[EXIT] + [SETTINGS]

You can now initialize the current Live Set Sound by pressing both the [EXIT] and [SETTINGS] buttons. Only the current data is initialized.

The data stored previously is not initialized.

CP88/73 Supplementary Manual 14

Additional new Voices

This CP update provides 30 new Voices ( ).

Voice List

Section Category No. Voice CC No.

PIANO Grand Piano 01 CFX 1

02 Imperial 2

03 S700 3

04 Digi Piano 4

05 C7 58

Upright Piano 01 U1 5

02 SU7 6

CP 01 CP80 1 7

02 CP80 2 8

Special Piano 01 Piano Strings 9

02 Piano Synth 10

E.PIANO Rd 01 78Rd 11

02 75Rd Funky 12

03 73Rd 13

04 67Rd Dark 59

05 67Rd Bright 60

Wr 01 Wr Warm 14

02 Wr Bright 15

03 Wr Wide 61

Clv 01 Clavi B 16

02 Clavi S 17

03 Harpsichord 18

DX 01 DX Legend 19

02 DX Woody 20

03 DX FTine 21

04 DX 7 II 22

05 DX Mellow 23

06 DX Crisp 24

SUB Pad/Strings 01 Mellow Pad 25

02 Spectrum 26

03 Back Pad 27

04 Air Choir 28

05 Natural Str 29

06 Warm Strings 30

07 OB Strings 31

08 Section Str 32

09 Fat Saw Pad 62

10 Noble Pad 63

11 Pop Pad 64

12 Analog Pad 65

13 Itopia 66

14 Marcato Str 67

15 Slow Str 68

16 Tape Str 69

17 Oct Syn Str 70

Organ 01 Bright Bars 33

02 Click Organ 34

03 Draw Organ 1 35

04 All Bars Out 36

05 Draw Organ 2 37

06 60s Combo 38

07 Compact 39

08 Panther 40

09 Pipe Organ 1 41

10 Pipe Organ 2 42

Chromatic Perc. 01 Glocken 43

02 Vibraphone 44

03 Xylophone 45

04 Marimba 46

05 Brightness 47

06 Jazz Vibes 71

07 Marimba 2 72

08 Kalimba 73

09 Heaven Bell 74

10 Nice Bell 48

11 Stack Bell 49

Section Category No. Voice CC No.

SUB Others 01 Syn Lead 1 50

02 Syn Lead 2 51

03 Syn Bass 52

04 E.Bass 53

05 A.Bass 54

06 Steel Gt 55

07 Clean Gt 56

08 Syn Brass 57

09 Sine Lead 75

10 Sync Saw 76

11 Dirty Hook 77

12 Classic Mini 78

13 Funky Mini 79

14 Nu Mini 80

15 80s Pop Bass 81

16 Sub Bass 82

17 Unison Bass 83

18 Finger Bass 84

19 Brass 85

20 Syn Brass 2 86

21 OB Brass 1 87

22 OB Brass 2 88

23 Jazz Flute 89

24 Tape Flute 90

25 Harmonica 91

Additional new Live Set Sounds

This CP update provides new Live Set Sounds ( ) to page 12.

Live Set Sound List

Page

No Name

Split

Point

Section Voice Name MSB LSB PC Page No Name

Split

Point

Section Voice Name MSB LSB PC

1

Natural CFX

G2

Piano

CFX

63

0

1

3

7

Big S700

G2

Piano

S700

63

2

7

E.Piano

-

E.Piano

73Rd

Sub

-

Sub

OB Strings

1

2

NaturalImperial

G2

Piano

Imperial

63

0

2

3

8

Piano Scape

G2

Piano

Imperial

63

2

8

E.Piano

-

E.Piano

DX Legend

Sub

-

Sub

Mellow Pad

1

3

Jazz S700

G2

Piano

S700

63

0

3

4

1

Compressed CFX

G2

Piano

CFX

63

3

1

E.Piano

-

E.Piano

-

Sub

-

Sub

-

1

4

Rock Upright

G2

Piano

U1

63

0

4

2

Kinda Squashed

G2

Piano

Imperial

63

3

2

E.Piano

-

E.Piano

-

Sub

-

Sub

-

1

5

Simple 78

G2

Piano

-

63

0

5

4

3

Layered CFX

G2

Piano

CFX

63

3

E.Piano

78Rd

E.Piano

75Rd Funky

Sub

-

Sub

Mellow Pad

1

6

Funky Tines

G2

Piano

-

63

0

6

4

Chorus CFX

G2

Piano

CFX

63

3

4

E.Piano

75Rd Funky

E.Piano

-

Sub

-

Sub

-

1

7

Tremolo Wr

G2

Piano

-

63

0

7

4

5

Upright

G2

Piano

U1

63

3

5

E.Piano

Wr Warm

E.Piano

-

Sub

-

Sub

-

1

8

Clavi B Amped

G2

Piano

-

63

0

8

4

6

A Tacky Piano

G2

Piano

SU7

63

3

6

E.Piano

Clavi B

E.Piano

75Rd Funky

Sub

-

Sub

Brightness

2

1

CFX+DX Legend

G2

Piano

CFX

63

1

4

7

HonkyTonk Piano

G2

Piano

U1

63

3

7

E.Piano

DX Legend

E.Piano

-

Sub

-

Sub

-

2

A.Bass/78Rd

G2

Piano

U1

63

1

2

4

8

Old Record

G2

Piano

U1

63

3

8

E.Piano

78Rd

E.Piano

-

Sub

A.Bass

Sub

-

2

3

80s El Grand

G2

Piano

CP80 1

63

1

3

5

1

Case 73

G2

Piano

-

63

4

1

E.Piano

-

E.Piano

73Rd

Sub

-

Sub

-

2

4

Brite Pop 8ve

G2

Piano

Digi Piano

63

1

4

5

2

Chimin' Tines

G2

Piano

Digi Piano

63

4

2

E.Piano

DX Legend

E.Piano

78Rd

Sub

OB Strings

Sub

Glocken

2

5

E.Bass/78Rd

G2

Piano

-

63

1

5

3

Slow Phase

G2

Piano

-

63

4

3

E.Piano

78Rd

E.Piano

73Rd

Sub

E.Bass

Sub

-

2

6

Driven Wr+Pad

G2

Piano

-

63

1

6

5

4

73 Tines OD

G2

Piano

-

63

4

E.Piano

Wr Warm

E.Piano

73Rd

Sub

Warm Strings

Sub

-

2

7

Imperial + Str

G2

Piano

Imperial

63

1

7

5

Fast Phaser

G2

Piano

-

63

4

5

E.Piano

-

E.Piano

75Rd Funky

Sub

Section Str

Sub

-

2

8

Ghostly U1

G2

Piano

U1

63

1

8

5

6

Ampy Funk

G2

Piano

-

63

4

6

E.Piano

Wr Warm

E.Piano

75Rd Funky

Sub

-

Sub

-

3

1

Rock Grand

G2

Piano

CFX

63

2

1

5

7

Wet Phase

G2

Piano

-

63

4

7

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

-

3

2

S700 + Pad

G2

Piano

S700

63

2

5

8

78 & Pad

G2

Piano

-

63

4

8

E.Piano

-

E.Piano

78Rd

Sub

OB Strings

Sub

Mellow Pad

3

MonoCmp CFX

G2

Piano

CFX

63

2

3

6

1

Wr Bright

G2

Piano

-

63

5

1

E.Piano

-

E.Piano

Wr Bright

Sub

-

Sub

-

3

4

Lo Fi Grand

G2

Piano

CFX

63

2

4

6

2

Wr Comp

G2

Piano

-

63

5

2

E.Piano

-

E.Piano

Wr Warm

Sub

-

Sub

-

3

5

Piano Grind Pad

G2

Piano

Piano Synth

63

2

5

6

3

Clavi B

G2

Piano

-

63

5

3

E.Piano

73Rd

E.Piano

Clavi B

Sub

Mellow Pad

Sub

-

3

6

Lush Love

G2

Piano

Imperial

63

2

6

4

Driven S

G2

Piano

-

63

5

4

E.Piano

78Rd

E.Piano

Clavi S

Sub

Brightness

Sub

-

CP88/73 Supplementary Manual 16

Page No Name

Split

Point

Section Voice Name MSB LSB PC Page No Name

Split

Point

Section Voice Name MSB LSB PC

6

5

Clavi Wah Dist

G2

Piano

-

63

5

9

7

Syn Brass

G2

Piano

-

63

8

7

E.Piano

Clavi B

E.Piano

-

Sub

-

Sub

Syn Brass

6 6 Squeeze B G2 Piano - 63 5 6

9 8 Syn Lead1 G2 Piano - 63 8 8

E.Piano

Clavi B

E.Piano

78Rd

Sub

-

Sub

Syn Lead 1

6

7

Long Chorus S

G2

Piano

-

63

5

7

10

1

Harpsichord

G2

Piano

-

63

9

1

E.Piano Clavi S

E.Piano Harpsichord

Sub

-

Sub

-

6

8

Rock Wr w/Ba

G2

Piano

Digi Piano

63

5

8

10

2

Electric Harpsi

G2

Piano

-

63

9

2

E.Piano

Wr Bright

E.Piano

Harpsichord

Sub E.Bass

Sub -

7

1

CP80 Comp

G2

Piano

CP80 1

63

6

1

10

3

Pipes Rd PBMW

G2

Piano

Digi Piano

63

9

3

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

Pipe Organ 2

7 2 Natural CP80 G2 Piano CP80 2 63 6 2

10 4 Funky w/RdBass G2 Piano CP80 1 63 9 4

E.Piano

-

E.Piano

78Rd

Sub

-

Sub

Marimba

7

3

Chorus Legend

G2

Piano

-

63

6

3

10

5

Rough Lead

G2

Piano

CP80 2

63

9

5

E.Piano DX Legend

E.Piano 78Rd

Sub

-

Sub

Back Pad

7

4

Chorus FTine

G2

Piano

-

63

6

4

10

6

Clavi Syn Wah

G2

Piano

-

63

9

6

E.Piano

DX FTine

E.Piano

Clavi B

Sub Mellow Pad

Sub Syn Lead 1

7

5

Chorus 7II

G2

Piano

-

63

6

5

10

7

Chimin' Crs

G2

Piano

Digi Piano

63

9

7

E.Piano

DX 7 II

E.Piano

75Rd Funky

Sub

-

Sub

Glocken

7 6 Legend + Pad G2 Piano - 63 6 6

10 8 Brite Pop G2 Piano Digi Piano 63 9 8

E.Piano

DX Legend

E.Piano

DX Legend

Sub

OB Strings

Sub

OB Strings

7

SynBass/DXEP

G2

Piano

-

63

6

7

11

1

Back to 60s SP

G2

Piano

-

63

10

1

E.Piano DX Mellow

E.Piano 67Rd Dark

Sub

Syn Bass

Sub

-

7

8

Digi DX Pads

G2

Piano

Digi Piano

63

6

8

11

2

80s Piano JG

G2

Piano

C7

63

10

2

E.Piano

DX Legend

E.Piano

78Rd

Sub Mellow Pad

Sub -

8

1

Bright Bars

G2

Piano

-

63

7

1

11

3

NaturalWrWideJG

G2

Piano

-

63

10

3

E.Piano

-

E.Piano

Wr Wide

Sub

Bright Bars

Sub

-

8 2 All Bars Out G2 Piano - 63 7 2 11 4

Chorused67Rd

SP

G2 Piano - 63 10 4

E.Piano

-

E.Piano

67Rd Bright

Sub

All Bars Out

Sub

-

8 3 PipeOrgan1 G2 Piano - 63 7 3

11 5 R&B Ballad NS G2 Piano - 63 10 5

E.Piano

-

E.Piano

67Rd Dark

Sub

Pipe Organ 1

Sub

-

8

4

PipeOrgan2

G2

Piano

-

63

7

4

11

6

Squashed C7 NS

G2

Piano

C7

63

10

6

E.Piano -

Sub

Pipe Organ 2

Sub

-

8 5 The Red Combo G2 Piano - 63 7 5 11 7

WrWideChorus

SP

G2 Piano - 63 10 7

E.Piano

-

E.Piano

Wr Wide

Sub

60s Combo

Sub

-

8

6

Italian Combo

G2

Piano

-

63

7

6

11

8

Driven 67Rd JG

G2

Piano

-

63

10

8

E.Piano -

E.Piano 67Rd Bright

Sub

Compact

Sub

-

8

7

Aggro Syn Pad

G2

Piano

-

63

7

12

1

CFX + Slow Str

G2

Piano

CFX

63

11

1

E.Piano

78Rd

E.Piano

-

Sub Panther

Sub Slow Str

8

RdBa/60sCombo

G2

Piano

-

63

7

8

12

2

C7 + Noble Pad

G2

Piano

C7

63

11

2

E.Piano

78Rd

E.Piano

-

Sub

60s Combo

Sub

Noble Pad

9 1 Strings1 G2 Piano - 63 8 1

12 3 78Rd+AnalogPad G2 Piano - 63 11 3

E.Piano

-

E.Piano

78Rd

Sub

Natural Str

Sub

Analog Pad

9 2 Strings2 G2 Piano - 63 8 2 12 4

78Rd+OBBrass

MW

G2 Piano - 63 11 4

E.Piano

-

E.Piano

78Rd

Sub

Section Str

Sub

OB Brass 1

9

3

Synth Pad1

G2

Piano

-

63

8

3

12

5

Sync Saw/DX EP

G2

Piano

-

63

11

5

E.Piano -

E.Piano DX Legend

Sub

Mellow Pad

Sub

Sync Saw

9

4

Synth Pad2

G2

Piano

-

63

8

4

12

6

Fat Saw Pad MW

G2

Piano

-

63

11

6

E.Piano

-

E.Piano

-

Sub Warm Strings

Sub Fat Saw Pad

9

5

Vibraphone

G2

Piano

-

63

8

5

12

7

OB Brass

G2

Piano

-

63

11

7

E.Piano

-

E.Piano

-

Sub

Vibraphone

Sub

OB Brass 2

9 6 Nice Bell G2 Piano - 63 8 6 12 8 Marcato Str G2 Piano - 63 11 8

E.Piano

-

E.Piano

-

Sub

Nice Bell

Sub

Marcato Str

CP88/73 Supplementary Manual 17

New Functions in CP Version 1.10

Yamaha has upgraded the CP firmware, adding the following new functions.

This manual describes additions and changes with respect to the Owner’s Manual that came with your instrument.

• You can now load a specific Live Set Sound from all data files.

•A new function “MIDI Control Delay” has been added to the Advanced Settings.

• New Voices have been added.

• New Live Set Sounds have been added.

• CP is now compatible with Soundmondo.

CP88/73 Supplementary Manual 18

Loading a specific Live Set Sound from all data files

[MENU] →“File” →Select a file you wish to load from the USB flash drive →“Load Live Set Sound” or “Load All”

You can now load a specific Live Set Sound from data files (Backup File, Live Set File, Live Set Page File.)

Select a folder containing the file you wish to load, and then the following screen is shown.

When you select “Load Live Set Sound,” the following screen is shown, and then you can choose the desired Live Set Sound to load to your

CP.

The file will be loaded to (and overwrites) the currently selected Live Set Sound.

When you select “Load All,” all Live Set Sound data contained in the file will be loaded.

CP88/73 Supplementary Manual 19

MIDI Control Delay

[MENU] →“Control Panel” →“Advanced Setting” →“MIDI Control Delay”

An additional function “MIDI Control Delay” allows you to adjust the timing of control change messages that are transmitted as you change

Live Set Sounds.

When the application on your computer does not properly receive control change messages, you may be able to remedy that by adjusting the

transmit timing here.

Settings: 0 msec – 1500 msec

Default: 0 msec

CP88/73 Supplementary Manual 20

Additional new Voices

This CP update provides 4 new Voices ( ).

Voice List

Section Category No. Voice CC No.

PIANO Grand Piano 01 CFX 1

02 Imperial 2

03 S700 3

04 Digi Piano 4

05 C7 58

Upright Piano 01 U1 5

02 SU7 6

CP 01 CP80 1 7

02 CP80 2 8

Special Piano 01 Piano Strings 9

02 Piano Synth 10

E.PIANO Rd 01 78Rd 11

02 75Rd Funky 12

03 73Rd 13

04 67Rd Dark 59

05 67Rd Bright 60

Wr 01 Wr Warm 14

02 Wr Bright 15

03 Wr Wide 61

Clv 01 Clavi B 16

02 Clavi S 17

03 Harpsichord 18

DX 01 DX Legend 19

02 DX Woody 20

03 DX FTine 21

04 DX 7 II 22

05 DX Mellow 23

06 DX Crisp 24

SUB Pad/Strings 01 Mellow Pad 25

02 Spectrum 26

03 Back Pad 27

04 Air Choir 28

05 Natural Str 29

06 Warm Strings 30

07 OB Strings 31

08 Section Str 32

Organ 01 Bright Bars 33

02 Click Organ 34

03 Draw Organ 1 35

04 All Bars Out 36

05 Draw Organ 2 37

06 60s Combo 38

07 Compact 39

08 Panther 40

09 Pipe Organ 1 41

10 Pipe Organ 2 42

Chromatic Perc. 01 Glocken 43

02 Vibraphone 44

03 Xylophone 45

04 Marimba 46

05 Brightness 47

06 Nice Bell 48

07 Stack Bell 49

Others 01 Syn Lead 1 50

02 Syn Lead 2 51

03 Syn Bass 52

04 E.Bass 53

05 A.Bass 54

06 Steel Gt 55

07 Clean Gt 56

08 Syn Brass 57

Yamaha CP88 Instructions and recipes

Popular Musical Instrument manuals by other brands
