Yamaha YVC-1000 User manual

YVC-1000
Kurzanleitung
Quick Start Guide
Guide de référence rapide
Guida rapida
Guía de Inicio Rápido
Guia de Início Rápido

1
English
Safety Precautions ......................................................2
Precautions for Use .....................................................4
About Bluetooth®.....................................................4
Locations of name plates ............................................5
Introduction .................................................................6
Check the contents ....................................................6
About this manual .....................................................6
Please read other instruction manuals as well as
this manual ................................................................7
Using the Latest Features ..........................................7
Use of open-source software .....................................7
Controls and Functions ..............................................8
Control Unit (YVC-CTU1000) .................................8
Control Unit (YVC-CTU1000): Back ......................9
Control Unit (YVC-CTU1000): Bottom ...................9
Microphone (YVC-MIC1000) ............................... 10
Microphone (YVC-MIC1000): Side ...................... 10
Microphone (YVC-MIC1000): Bottom ................. 11
Setting up for use ...................................................... 12
Installation .............................................................. 12
Connecting the microphone and power cables ....... 13
Connecting to communication equipment ............. 14
Connecting to a PC or Mac using the USB
cable ........................................................................ 14
Connecting to a video conference system using
audio cables ............................................................ 14
Connecting to a smartphone or tablet via
Bluetooth ................................................................ 15
Specifications ............................................................ 16
General ................................................................... 16
Audio ...................................................................... 17
Contents

2
1 Please ensure to immediately remove the power plug from the
outlet in any of the following cases.
Failure to observe this may result in fire or an electric shock.
Please ensure to request the dealer concerned to carry out any
necessary repairs or inspections.
• Any abnormal odor or noise occurs;
• Smoke is emitted;
• The product is broken; or
• The product has been exposed to water.
2 Ensure not to damage the power cable. Failure to observe this
could result in fire, electric shock, or damage to the product.
• Ensure not to place any heavy objects on the cable.
• Ensure not to process the cable in any way.
• Ensure not use any staples to fix the cable in place.
• Ensure not to apply excessive force to the cable.
• Ensure to keep the cable away from anything hot.
3 Ensure to only use the included power cable. Failure to observe
this could result in fire, electric shock, or damage to the product.
4 Ensure to only use the specified power supply voltage. Failure to
observe this could result in fire, electric shock, or damage to the
product.
5 Connect the power plug to an outlet that you can see and reach in
thereby ensuring that you can easily remove it if the necessity
arises.
6 Ensure to fully and securely insert the power plug into the outlet.
Being insufficiently inserted could result in an electric shock. It
could also lead to dust accumulating on the plug, which could then
result in heat or fire.
7 Verify that the current capacity of the outlet or a power strip in
thereby ensuring that use of the product does not exceed it. Any
overheating or degradation of the power strip could result in fire.
8 Do not touch the terminals with your fingers or metal objects.
Failure to observe this may result in electric shock or damage to
the product.
9 Ensure the product does not fall or strongly impacted. The internal
parts could break, which could then result in electric shock, fire, or
damage to the product.
10 If the product has been damaged, request repair or inspection
services from a dealer.
Continued use of the product may result in fire or electric shock.
11 Do not disassemble or alter this product in any way.
Failure to observe this could result in fire, electric shock, or
damage to the product.
12 Do not obstruct heat dissipation.
– Do not place a cloth, tablecloth or other such object over the
product.
– Do not place the product on top of a rug, carpet, etc.
– Do not wedge or squeeze the product into a narrow space that
has poor air circulation.
– Do not block the ventilation holes.
Allow ventilation space of at least 1 cm on the top, 1 cm on the left
and right, and 5 cm on the back of this product.
Failure to observe the above may result in heat being trapped
inside the product and cause a fire or damage to the product.
13 Do not place the product outdoors or in a location where water
may drip on it.
Failure to observe this may result in fire, electric shock or damage
to the product.
14 Do not install the product anywhere it will be exposed to dust or
humidity, oily smoke or steam, or corrosive gas. Failure to observe
this could result in fire, electric shock, or damage to the product.
15 Ensure that the product is on the level.
Do not place it upside down or in a vertical orientation. Failure to
observe this may result in fire, electric shock or damage to the
product.
16 Avoid installing the product where foreign object may fall onto the
product and/or the product may be exposed to liquid dripping or
splashing. On the top of the product, do not place:
• Other components, as they may cause damage and/or
discoloration on the surface of the product.
• Burning objects (i.e. candles), as they may cause fire, damage to
the product, and/or personal injury.
• Containers with liquid in them, as they may fall and liquid may
cause electrical shock to the user and/or damage to the product.
17 Do not insert foreign objects such as metal or paper in the product.
Failure to observe this may result in fire, electric shock or damage
to the product.
18 If thunder is heard, avoid touching the product.
Failure to observe this may result in electric shock.
19 Periodically remove any dirt and dust from the power plug. Failure
to observe this could result in fire.
20 The product should be used at least 22 cm away from persons
using a pacemaker, defibrillator, or similar device.
Failure to observe this may affect the pacemaker, resulting in a
serious accident.
21 Do not use this product near medical equipment. Radio waves
from this product may adversely affect the operation of electro-
medical equipment. Do not use this product in locations where use
of radio waves is restricted, such as near medical equipment.
22 Avoid damaging the USB and microphone cables.
• Do not place heavy objects on cables.
• Do not modify cables.
• Do not affix cables using staples.
• Do not apply unnecessary force to cables.
• Do not place cables near heat sources.
Doing so may result in fire, electric shock or damage to the
product.
23 Be sure to use the USB and microphone cables that come with the
product.
Using other USB or microphone cables may result in fire, electric
shock, or damage to the product.
24 When this product is not used for a long period of time, be sure to
unplug all power plugs.
Failure to observe this may result in fire or electric shock.
25 Ensure your hands are dry when connecting or disconnecting the
power plug or cables.
Failure to observe this may result in electric shock or damage to
the product.
26 Ensure not to install the product anywhere unstable or where it will
be exposed to vibrations as it could fall over or turn upside down,
thus resulting in injury or damage to the product.
27 Ensure not to install the product anywhere it will be exposed to
direct sunlight or extraordinarily high temperatures (near a heater,
etc.). Failure to observe this could result in damage to the product.
28 Do not sit/stand on the product or place other objects on top of it.
Failure to observe this may result in damage to the product.
Safety Precautions

3
English
29 Turn the volume down to the minimum level before starting
playback.
Failure to observe this will cause loud noises to be emitted that
may result in hearing impairment.
30 Ensure not to use the product anywhere it will be exposed to rapid
changes in the ambient temperature. Any rapid change in the
ambient temperature could result in condensation on the product,
which could then result in damage to the product. Ensure to leave
the product for a while until it has dried off with the power turned
off if any condensation has occurred.
31 Ensure not to connect any cables while the power is turned on.
Failure to observe this could result in damage to the product and
any connected equipment.
32 Ensure to earth any static electricity from your body or clothing
before touching the product. Failure to observe this could result in
damage to the product.
33 Route and connect the cables correctly.
If the cables are pulled or become caught on someone’s leg, the
product or connected equipment could tip over or fall, thus
resulting in injury or damage to the product.
34 Before connecting external equipment, thoroughly read the
instruction manuals provided with the equipment and make
connections according to the instructions.
■For U.K. customers
If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the instructions described below.
The plug severed from the mains lead must be destroyed, as a plug with bared flexible cord is hazardous if engaged in a live
socket outlet.
■Special Instructions for U.K. Model
This unit is not disconnected from the AC power source as long as it is connected to the AC wall outlet, even if this unit
itself is turned off. This state is called the standby mode. In this state, this unit is designed to consume a very small quantity
of power.
WARNING
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.
We, Revolabs, Inc. (UK), hereby declare that this unit is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Revolabs, Inc. (UK)
190, High Street, Tonbridge, Kent, TN9 1BE, UK.
Tel: [phone]
Note
IMPORTANT
THE WIRES IN MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
Blue: NEUTRAL
Brown: LIVE
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is
coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
Make sure that neither core is connected to the earth terminal of the three pin plug.

4
•This product is intended for use in general offices and is not designed for use in any fields requiring a high degree of
reliability in the handling of human lives or valuable assets.
•Please note that Yamaha cannot assume any responsibility for any damage resulting from improper use or configuration of
the product.
•Depending on the usage environment, this product may generate noise in a telephone, radio, television etc. If this occurs,
change the location where it is installed or its orientation.
•If you transfer this product to a third party, please pass this manual and accessories along with it.
•Ensure to follow the instructions of your local government when disposing of the product.
•Do not connect any equipment that generates any noise on the same power line as the product.
•Bluetooth is a technology for wireless communication employing the 2.4 GHz frequency band, a band which can be used
without a license.
•The 2.4 GHz band used by Bluetooth compatible devices is a radio band shared by many types of equipment. While
Bluetooth compatible devices use a technology minimizing the influence of other components using the same radio band,
such influence may reduce the speed or distance of communications and in some cases interrupt communications.
•The speed of signal transfer and the distance at which communication is possible differs according to the distance between
the communicating devices, the presence of obstacles, radio wave conditions and the type of equipment.
•Yamaha does not guarantee all wireless connections between this product and devices compatible with Bluetooth function.
Precautions for Use
Information for Users on Collection and Disposal of Old Equipment
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic
products should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in
accordance with your national legislation and the Directives 2012/19/EU.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative
effects on human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your
waste disposal service or the point of sale where you purchased the items.
[For business users in the European Union]
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further
information.
[Information on Disposal in other Countries outside the European Union]
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local
authorities or dealer and ask for the correct method of disposal.
About Bluetooth®

5
English
The name plates are placed on the bottom of the Control Unit and the microphone.
Locations of name plates

6
Thank you for purchasing a Yamaha YVC-1000. The YVC-1000 is a unified communications microphone and speaker system
that serves as an audio terminal when connected to communication equipment, such as a PC or a Mac, a smartphone or tablet,
and a video conference system.
Please thoroughly read this manual before installing and connecting the product.
Keep this manual in a safe place for future reference.
•Control Unit (YVC-CTU1000) x 1
•Microphone (YVC-MIC1000) x 1
•Power cable (3 m) x 1
•USB cable (5 m) x 1
•Microphone cable (5 m) x 1
•Quick Start Guide (this manual) x 1
■About abbreviations
In this manual, the product names are described as follows.
•Yamaha YVC-1000: the product
•Microsoft®Windows®: Windows
•Microsoft®Windows®7: Windows 7
•Microsoft®Windows®8: Windows 8
•Microsoft®Windows®8.1: Windows 8.1
•Mac OS®X 10.8: Mac OS X 10.8
•Mac OS®X 10.9: Mac OS X 10.9
■About trademarks
•Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and other countries.
•Macintosh, Mac, and Mac OS are registered trademarks of Apple Inc.
•Android™is a trademark or registered trademark of Google Inc.
•Bluetooth®is a registered trademark of the Bluetooth SIG and is used by Yamaha in accordance with a license agreement.
•NFC logo (N-Mark) is a trademark or registered trademark of NFC Forum, Inc.
Introduction
•No part of this manual may be copied or used in any form without permission of Yamaha.
•Specifications of the product and contents of this manual are subject to change without notice.
•Yamaha is not liable for any loss or damage to data resulting from use of the product. Please note that the warranty
covers repair of the product only.
Check the contents
About this manual

7
English
This manual contains fundamental information only.
For detailed information on how to use the product, please read the following:
User’s manual: Contains information about utilizing the product, including detailed settings and useful features.
Please download the latest user’s manual from the download page of our website.
To configure the settings of communication equipment, refer to the instruction manuals provided with the equipment.
You can download the firmware (program of the product) from the download page of our website to use the latest features.
■Download page
http://www.yamaha.com/products/en/communication/download/
This product uses open-source software.
The contents of the license are included in the user’s manual.
Please read other instruction manuals as well as this manual
Using the Latest Features
Use of open-source software

8
1Power button/indicator
Press to turn the product on. Press and hold the power
button for two or more seconds to enter standby mode. It
lights up green when the product is turned on and lights
up red in standby mode.
2Volume +/- button/indicator
Press to adjust the speaker volume. Hold down the
appropriate button for 0.5 or more seconds to
continuously increase or decrease the volume.
Press both the + and - buttons simultaneously for two or
more seconds to switch the output device between the
built-in and external speakers.
3Volume level indicator
It normally indicates the input level of an incoming
voice. It indicates settings when adjusting the speaker
volume or when selecting an output speaker.
4Tuning fork button/indicator
It lights up or flashes orange if there is a problem. If a
problem is indicated, press the tuning fork button to
activate the voice guidance about the detected problem.
When it is pressed and held for two or more seconds, the
product automatically measures acoustic conditions and
tunes the audio settings to an optimal condition
(automatic audio tuning).
5Bluetooth button/indicator
Press to pair or connect with a Bluetooth compatible
smartphone or tablet.
If this button is pressed while being connected to a
Bluetooth device, Bluetooth will be disconnected.
6NFC logo (N-Mark)
Placing an NFC (Near Field Communication)-equipped
Bluetooth compatible smartphone or tablet over the
N-Mark allows you to pair or connect it with the
product, or to disconnect it.
7Built-in speaker
Outputs an incoming voice.
Controls and Functions
Control Unit (YVC-CTU1000)
123 4 5 6
7

9
English
1Power terminal
Used to connect the supplied power cable.
2USB port
Used to connect the product to a PC or Mac using the
supplied USB cable.
3Microphone terminal
Used to connect the supplied microphone using the
microphone cable.
4External speaker terminals
Used to connect the speakers with a built-in amplifier.
5Audio output terminals (AUDIO OUT)
Used to connect to the audio input terminals of a video
conference system.
6Audio input terminals (AUDIO IN)
Used to connect to the audio output terminals of a video
conference system.
1Name plate
Provides the following information.
Model No.: Model number of the product
SERIAL LABEL: Serial number of the product
Control Unit (YVC-CTU1000): Back
1 2 3 4 5 6
Control Unit (YVC-CTU1000): Bottom
1

10
1Microphone mute button
Press to temporarily turn off (mute) the microphone. To
cancel the mute function, press it again.
2Microphone status indicator
Lights up green when the microphone is active. Lights
up red when the microphone is set to mute.
1Input terminal (IN)
Connects the optional microphone (YVC-MIC1000EX)
using the microphone cable.
2Output terminal (OUT)
Connects the Control Unit using the microphone cable.
Microphone (YVC-MIC1000)
12
Microphone (YVC-MIC1000): Side
12

11
English
1Name plate
Provides the following information.
Model No.: Model number of the product
SERIAL LABEL: Serial number of the product
Microphone (YVC-MIC1000): Bottom
1

12
Install the product in a location where it will be used.
Notes on installation
•Place the microphone at least 1 m (3.3 ft) away from the Control Unit.
•Keep the microphone away from any noise sources.
Setting up for use
Installation
At least
1 m (3.3 ft)

13
English
Connect the microphone and power cables supplied with the product.
•When connecting the microphone cable, be sure to
match the color of the labels on the microphone cable
and of the microphone output terminal (OUT).
•Be sure to fully insert the power cable into the power
terminal of the Control Unit and into the outlet.
yTip
A total of five microphones, including the supplied
microphone and optional microphones (YVC-
MIC1000EX), can be connected to the product. (For details,
refer to the user’s manual.)
Connecting the microphone and power cables
Notes
1
1
3
2
Match the
color of the
labels. Plug into an outlet

14
After connecting the product, turn the product on and confirm that it is recognized correctly by the PC or Mac.
For detailed instructions, refer to the user’s manual.
After connecting the product, change the settings of the video conference system so that the product will be used as a
microphone and speaker.
For detailed instructions, refer to the user’s manual.
Connecting to communication equipment
Connecting to a PC or Mac using the USB cable
Connecting to a video conference system using audio cables
To USB port
Plug into
an outlet
Connect to a
microphone
Audio Output
terminals
Video conference
system
Audio Input
terminals
Plug into
an outlet
Connect to a
microphone

15
English
■Pairing
1 Press the power button to turn the product on.
2 Press the Bluetooth button.
The Bluetooth button blinks blue.
3 Press and hold the Bluetooth button for two or more seconds.
The Bluetooth button blinks blue quickly to indicate that pairing can be performed.
4 Perform the pairing procedure using the smartphone or tablet.
■Connecting to a paired smartphone or tablet via Bluetooth
1 Press the power button to turn the product on.
2 Press the Bluetooth button.
The Bluetooth button blinks blue to indicate that the product can be connected via Bluetooth.
3 Perform the Bluetooth-connection procedure using the smartphone or tablet.
When the connection is established, the Bluetooth button lights up blue.
For detailed instructions, refer to the user’s manual.
Connecting to a smartphone or tablet via Bluetooth
Power button Bluetooth button

16
Specifications
General
Interface: Control Unit: USB 2.0 High Speed, Bluetooth, NFC (Near Field Communication),
Audio Input terminals (stereo RCA pin), Audio Output terminals (stereo RCA pin), External
speaker terminal (RCA pin) x 2, Power terminal, Microphone terminal
Microphone: Input and output terminals
Power
consumption
(max):
20 W (one microphone connected), 35 W (five microphones connected)
Radio
interference
standard:
EN55013/20, EN55022/24
Operating
environment:
Temperature: 0 to 40°C (32 to 104°F)
Humidity: 20 to 85% (no condensation)
Storage
environment:
Temperature: -20 to +50°C (-4 to 122°F)
Humidity: 10 to 90% (no condensation)
Dimensions: Control Unit (W x H x D): 332 x 95 x 162 mm (13.1 x 3.74 x 6.38 in)
Microphone (W x H x D): 136 x 36 x 136 mm (5.35 x 1.42 x 5.35 in)
Weight: Control Unit: 1.8 kg (4.0 lbs)
Microphone: 0.4 kg (0.9 lbs)
Power source: AC 220 to 240 V (50 Hz)
PC environment: OS: 32-bit or 64-bit Windows 8.1, 32-bit or 64-bit Windows 8,
32-bit or 64-bit Windows 7
USB: USB 2.0 or later
Mac
environment:
OS: Mac OS X 10.9, Mac OS X 10.8
USB: USB 2.0 or later
Bluetooth: Bluetooth specification version: 2.1 + EDR
Supported profiles: HFP (1.6), A2DP
Supported Codec: SBC, mSBC
Wireless output: Class 2
Maximum communication distance: 10 m
NFC: Compatible devices: NFC-compatible Android devices, versions 4.1, 4.2, 4.3 and 4.4
Voice guidance: English, Japanese, Chinese, Korean, French, Spanish, German
Accessories: Power cable (3 m), USB cable (5 m), Microphone cable (5 m), Quick Start Guide
Others: Firmware update (transfer from PC through USB)

17
English
Audio
Microphone
units:
Unidirectional x 3
Speaker unit: Full-range x 1
Frequency
bandwidth for
sound pickup:
100 to 20,000 Hz
Frequency
bandwidth for
playback:
100 to 20,000 Hz
Signal
processing:
Adaptive echo canceller, Noise reduction, Automatic tracking, Automatic gain control,
Automatic room EQ, Dereverberation, Automatic audio tuning

1
Français
Consignes de sécurité ..................................................2
Précautions d’utilisation ............................................4
À propos de Bluetooth®............................................4
Emplacements des plaques signalétiques ..................5
Introduction .................................................................6
Vérification du contenu .............................................6
À propos de ce mode d’emploi .................................6
Veillez lire les autres manuels d’instructions
en plus de ce mode d’emploi ....................................7
Utilisation des dernières fonctions ............................7
Utilisation de logiciels Open Source .........................7
Commandes et leurs fonctions ...................................8
Unité de commande (YVC-CTU1000) .....................8
Unité de commande (YVC-CTU1000): vue
arrière ........................................................................9
Unité de commande (YVC-CTU1000): vue de
dessous ......................................................................9
Microphone (YVC-MIC1000) ............................... 10
Microphone (YVC-MIC1000): vue latérale ........... 10
Microphone (YVC-MIC1000) : vue de
dessous ................................................................... 11
Configuration d’utilisation ...................................... 12
Installation .............................................................. 12
Raccordement du microphone et des câbles
d’alimentation ......................................................... 13
Raccordement à un équipement de
communication ......................................................... 14
Raccordement à un ordinateur ou un
Mac à l’aide du câble USB ..................................... 14
Raccordement à un système de conférence vidéo
via un câble audio ................................................... 14
Raccordement à un smartphone ou une tablette
via Bluetooth (fonction NFC) ................................ 15
Caractéristiques techniques .................................... 16
Généralités .............................................................. 16
Son .......................................................................... 17
Table des matières

2
1 Retirez immédiatement la fiche d’alimentation de la prise dans
tous les cas suivants.
Le non-respect de cette consigne pourrait provoquer un incendie
ou une décharge électrique. Demandez à votre revendeur
d’effectuer les réparations ou les inspections nécessaires.
• Présence d’une odeur ou d’un bruit inhabituel ;
• Émission de fumée ;
• Endommagement de l’appareil ; ou
• Exposition de l’appareil à l’eau.
2 Veillez à ne pas endommager le câble d’alimentation. Le non-
respect de cette consigne pourrait provoquer un incendie, une
décharge électrique ou endommager le produit.
• Veillez à ne pas placer d’objet lourd sur le câble.
• Ne manipulez pas le câble de quelque manière que ce soit.
• N’utilisez pas d’agrafes pour maintenir le câble en place.
• N’exercez pas de contrainte excessive sur le câble.
• Tenez le câble éloigné de toute source de chaleur.
3 Veillez à utiliser uniquement le câble d’alimentation fourni. Le
non-respect de cette consigne pourrait provoquer un incendie, une
décharge électrique ou endommager le produit.
4 Veillez à utiliser exclusivement la tension d’alimentation spécifiée.
Le non-respect de cette consigne pourrait provoquer un incendie,
une décharge électrique ou endommager le produit.
5 Branchez la fiche d’alimentation sur une prise que vous pouvez
voir et atteindre de manière à pouvoir facilement la débrancher en
cas de nécessité.
6 Veillez à insérer complètement et soigneusement la fiche
d’alimentation dans la prise. Une insertion insuffisante pourrait
provoquer une décharge électrique. De la poussière peut également
s’accumuler sur la fiche, ce qui pourrait provoquer un
échauffement ou un incendie.
7 Vérifiez la capacité maximale de la prise ou d’une éventuelle
multiprise et, ainsi, que l’utilisation du produit ne la dépasse pas.
Toute surchauffe ou dégradation de la multiprise pourrait
provoquer un incendie.
8 Ne touchez pas les bornes avec vos doigts ou des objets métalliques.
Le non-respect de cette consigne pourrait provoquer une décharge
électrique ou endommager le produit.
9 Veillez à ce que le produit ne tombe pas ou ne soit soumis à aucun
choc violent. Les composants internes pourraient se casser, ce qui
pourrait provoquer une décharge électrique, un incendie ou
endommager le produit.
10 En cas d’endommagement du produit, demandez à un revendeur de
le réparer ou de l’inspecter.
Si vous continuez à utiliser le produit dans ces conditions, vous
risquez de provoquer un incendie ou une décharge électrique.
11 Ce produit ne peut être démonté ou modifié d’aucune manière.
Le non-respect de cette consigne pourrait provoquer un incendie,
une décharge électrique ou endommager le produit.
12 N’empêchez pas la dissipation de chaleur.
• Ne couvrez pas l’appareil d’un chiffon, d’une nappe ou d’un
autre objet de ce type.
• Ne placez pas le produit sur un tapis, une moquette, etc.
• Ne coincez ou n’enfoncez pas le produit dans un espace exigu
mal ventilé.
• N’obstruez pas les orifices d’aération.
Laissez un espace d’aération d’au moins 1 cm au dessus, 1 cm à
gauche et à droite et 5 cm à l’arrière de l’appareil.
Le non-respect des consignes ci-dessus pourrait emprisonner la chaleur à
l’intérieur de l’appareil et provoquer un incendie ou endommager le produit
13 Ne placez pas le produit à l’extérieur ou dans un endroit
susceptible d’être exposé à l’eau.
Le non-respect de cette consigne pourrait provoquer un incendie,
une décharge électrique ou endommager le produit.
14 N’installez pas le produit dans un endroit où il pourrait être exposé
à la poussière ou l’humidité, à de la fumée ou à de la vapeur
huileuse, ou à un gaz corrosif. Le non-respect de cette consigne
pourrait provoquer un incendie, une décharge électrique ou
endommager le produit.
15 Veillez à placer le produit sur une surface plane.
Ne le placez pas à l’envers ou à la verticale. Le non-respect de cette
consigne pourrait provoquer un incendie, une décharge électrique
ou endommager le produit.
16 Évitez d’installer l’appareil dans un endroit où des objets peuvent
tomber et où l’appareil pourrait être exposé à des éclaboussures ou
des gouttes d’eau. Sur le dessus de cet appareil, ne placez pas:
• d’autres appareils car cela risquerait d’endommager la surface
de l’appareil ou de provoquer sa décoloration.
• des objets se consumant (par exemple, une bougie) car cela pourrait
provoquer un incendie, endommager l’appareil ou vous blesser.
• des récipients contenant des liquides car ils risqueraient de se
renverser et de causer des décharges électriques ou
d’endommager l’appareil.
17 N’introduisez pas de corps étrangers, tels que du métal ou du
papier, dans le produit.
Le non-respect de cette consigne pourrait provoquer un incendie,
une décharge électrique ou endommager le produit.
18 Évitez de toucher le produit lors d’un orage.
Le non-respect de cette consigne pourrait provoquer une décharge électrique.
19 Dépoussiérez et nettoyez régulièrement la fiche d’alimentation. Le
non-respect de cette consigne pourrait provoquer un incendie.
20 Il convient d’utiliser le produit à plus de 22 cm d’un stimulateur cardiaque.
Le non-respect de cette consigne pourrait perturber le stimulateur
et provoquer un accident grave.
21 N’utilisez pas ce produit à proximité d’équipement médical. Les
ondes radio émises par ce produit peuvent nuire au fonctionnement
des appareils électriques utilisés en médecine. N’utilisez pas ce
produit dans des endroits où l’utilisation d’ondes radio est
restreinte, comme à proximité d’équipement médical.
22 Évitez d’endommager les câbles USB et les câbles du microphone.
• Ne déposez pas d’objets lourds sur les câbles.
• Ne modifiez pas les câbles.
• Ne fixez pas les câbles à l’aide d’agrafes.
• Ne forcez pas inutilement sur les câbles.
• Ne placez pas les câbles à proximité de sources de chaleur.
Cela pourrait provoquer un incendie ou une décharge électrique,
ou encore endommager le produit.
23 Utilisez le câble USB et le câble du microphone fournis avec le produit.
L’utilisation d’autres câbles pourrait provoquer un incendie, une
décharge électrique ou endommager le produit.
24 Si vous ne comptez pas utiliser l’appareil pendant une période
prolongée, pensez à débrancher toutes les fiches d’alimentation.
Le non-respect de cette consigne pourrait provoquer un incendie
ou une décharge électrique.
25 Vos mains doivent être sèches pour brancher et débrancher la fiche
d’alimentation ou les câbles.
Le non-respect de cette consigne pourrait provoquer une décharge
électrique ou endommager le produit.
26 N’installez pas l’appareil sur une surface non stable ou dans un
endroit où il pourrait être exposé à des vibrations pouvant le faire
tomber ou le renverser, provoquant ainsi des lésions ou des
dommages à l’appareil.
27 N’installez pas cet appareil dans un endroit où il pourrait être
exposé à la lumière directe du soleil ou à des températures
extrêmement élevées (à proximité d’un chauffage, etc.). Le non-
respect de cette consigne pourrait endommager l’appareil.
28 Ne vous asseyez pas/mettez pas debout sur l’appareil et ne placez
pas d’autres objets dessus.
Le non-respect de cette consigne pourrait endommager l’appareil.
Consignes de sécurité
