volkano Mamba Series User manual

INSTRUCTION MANUAL
Please read and retain these instructions for future reference.
VK-3202-BK/BL
Mamba Series

• Bluetooth
Version: 5.0
Chipset: JL
Profiles: A2DP / AVRCP
Distance: Up to 33 ft / 10 m
• Sensitivity: 88 dB ± 3 dB
• Signal to Noise Ratio: 65 dB
• Driver: 3”
• Impedance: 4Ω
• Frequency Response: 120 Hz – 12 kHz
• Total Power Output: 8 W RMS / 12 W Peak
• Charge Input: DC 5 V, 1 A
• Battery Capacity: 1 500 mAh, Lithium Rechargeable Battery
• Charge Time: 4 Hours
• Playback Time: 2 – 4 Hours
• Product Size: 287 X 112 X 127 mm
• Max Size for Micro SD Card Input: 32 GB
• Max Size for USB Input: 32 GB
• Volkano Mamba Series Bluetooth Speaker
• Micro USB Charging Cable
• Aux Cable
• Instruction Manual
• Carry Handle
• Bluetooth
• True Wireless Pairing
• FM Radio
• Aux Input
• USB Input
• Micro SD Card Input
• 12 W Peak Power
• Up to 4 Hours Playtime
• Carry Handle
PACKAGE CONTENTS
HIGHLIGHTS
SPECIFICATIONS
1

IDENTIFYING PARTS
CHARGING
• Please fully charge the Volkano Mamba Series Bluetooth Speaker before using it for
the first time.
• Connect the USB A end of the charging cable to a USB charging port and insert the
micro USB end to the port on the speaker. Make sure it is properly connected.
• The red indicator light will be lit while the speaker is charging. When the battery is
full, the red indicator light will switch off automatically.
• Please do not charge the speaker for more than 8 hours.
2
1.MMode Button
2.V– / Previous Track / Volume Down Button
3.USB Input
4.Micro SD Card Input
5.LED Indicator
6.Micro USB Charge Input
7.Aux Input
8. /V+ Next Track / Volume Up Button
9. Power Button
10. Play / Pause and FM Auto Scan

3
PAIRING WITH BLUETOOTH DEVICES
Your speaker must be paired to a Bluetooth device before it can be used. It is only
necessary to pair your speaker once with each device.
1. Press and hold the Power Button for about 3 seconds until the blue LED light
turns on and starts flashing.
2. Cycle to Bluetooth mode by pressing the MMode Button, the speaker will beep
twice, this means that the speaker is ready to pair with your Bluetooth playback
device.
Pairing a second Mamba Speaker / Daisy Chaining:
3. The Volkano Mamba Speakers needs to pair to each other before connecting to
your Bluetooth device.
4. Once the speakers are in Bluetooth Mode press and hold the Play / Pause and
FM Auto Scan Button for 3 seconds on one of your speakers, this will pair your two
speakers together, a connection tone will be audible once both speakers are paired.
It is only necessary to pair your speakers with each other once.
5. Activate the Bluetooth on your playback device and search for “Mamba”. Select
“Mamba” from the device’s list to connect. You will hear a connection tone after
the speaker has been paired successfully and the Bluetooth LED will start flashing
slower.
6. You can now playback audio through the speaker.
7. Music tracks can be selected either on the speaker or on your playback device
(smartphone, computer, tablet etc.). Press the /V+ Next Track / Volume Up
Button to skip to the next song. Press the V– / Previous Track / Volume Down
Button to play the previous song.
8. Volume can be controlled either on the speaker or on your playback device
(smartphone, computer, tablet etc.). Press and hold the /V+ Next Track /
Volume Up Button or the V– / Previous Track / Volume Down Button on the
speaker to adjust the volume as preferred.
9. Press the Button on the speaker to play or stop music.

4
CONTROLS
Function Operation
Increase Volume Long press the /V+ Next Song / Next Station /
Volume Up Button
Decrease Volume Long press the V– / Previous Song / Previous Station
/ Volume Down Button
Next Track Short press the /V+ Next Song / Next Station /
Volume Up Button
Previous Track Short press the V– / Previous Song / Previous
Station / Volume Down Button
Play / Pause Track Short press the Play / Pause and FM Auto Scan
Button
Function Operation
Increase Volume Long press the /V+ Next Song / Next Station /
Volume Up Button
Decrease Volume Long press the V– / Previous Song / Previous Station
/ Volume Down Button
Next Track Short press the /V+ Next Song / Next Station /
Volume Up Button
Previous Track Short press the V– / Previous Song / Previous
Station / Volume Down Button
Play / Pause Track Short press the Play / Pause and FM Auto Scan
Button
To navigate between the USB, Micro SD, Bluetooth and Aux Modes short press the
MMode Button.
Note: Increase and decrease buttons can work in Aux Input Mode.
2. Bluetooth, USB and SD Card Mode
1. Controls

1. Press MMode Button to cycle the speaker to Aux mode.
2. Plug the provided audio cable into the compatible device’s Aux input and then into
the Aux input of the speaker.
Aux-In
5
3. FM Radio
Function Operation
Increase Volume Long press the /V+ Next Song / Next Station /
Volume Up Button
Decrease Volume Long press the V– / Previous Song / Previous
Station / Volume Down Button
Navigate up through
saved channels
Short press the /V+ Next Song / Next Station /
Volume Up Button
Navigate down through
saved channels
Short press the V– / Previous Song / Previous
Station / Volume Down Button
Automatic Station Scan Short press the Play / Pause and FM Auto Scan
Button
1. Switch the power on.
2. Insert USB flash disk or SD card into the slot. The music stored will be played
automatically.
3. Music tracks can be selected either on the speaker or on your playback device
(smartphone, computer, tablet etc.). Press the /V+ Next Track / Volume Up
Button to skip to the next song. Press the V– / Previous Track / Volume Down
Button to play the previous song.
4. Volume can be controlled either on the speaker or on your playback device
(smartphone, computer, tablet etc.). Press and hold the /V+ Next Track /
Volume Up Button or the V– / Previous Track / Volume Down Button on the
speaker to adjust the volume as preferred.
5. Press the Play / Pause and FM Auto Scan Button to play or pause the music.
Note: In Bluetooth Mode, inserting a USB flash disk will disconnect the Bluetooth and
switch to playing from the USB flash disk. Press the MMode Button to switch back to
Bluetooth mode.
Playing MP3’s from a USB Flash Drive or Micro SD Card

6
1. My smartphone cannot find any new Bluetooth devices?
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within an effective working range.
2. Bluetooth device cannot pair up?
Ensure your mobile phone allows new connections and has not reached the
maximum number of allowed devices.
Troubleshooting
iPhone, iPad, and iPod Touch:
a) On your device, go to Settings.
b) Select Bluetooth. If Bluetooth is not on, turn it on.
c) The iPhone / iPad / iPod will automatically search for new devices.
Android Phones and Tablets:
a) On your device, go to the Settings Menu.
b) Select Bluetooth (on older Android devices Bluetooth is found in the Wireless and
Networks Menu). If Bluetooth is not on, turn it on.
c) Select “Search for Devices” if your phone or tablet does not automatically search for
new devices.
NOTE: If you are unsure on how to access your Bluetooth Menu on your device, please
refer to your device’s instruction manual.
LOCATING THE BLUETOOTH MENU
1. Use the provided audio cable as an antenna to receive a good FM radio signal.
2. Once the device has been turned on, press the MMode Button to cycle to FM radio
mode.
3. Press the Play / Pause and FM Auto Scan Button to search for all available FM
channels and store them automatically.
4. To navigate between radio stations, press the /V+ Next Track / Volume Up
Button or the V– / Previous Track / Volume Down Button to select radio
stations.
Note: Inserting the audio cable while the speaker is in FM mode, will cause the speaker
to automatically switch to Aux mode. Pressing the MMode Button again will cycle back
to FM mode.
FM Radio Mode

7
Safety Precaution
• To reduce the risk of fire or electric shock, do not expose
this equipment to rain or moisture.
• To reduce the risk of fire or electric shock, keep this equip
ment away from all liquids. Use and store only in locations
which are not exposed to the risk of dripping or splashing
liquids, and do not place any liquid containers on top of the
equipment.
This product is not intended for commercial use and has been tested for household
use only.
• This product is not intended for use by small children, or persons with diminished
mental capabilities. Ensure that use of this product is monitored by a guardian
or parent.
• CAUTION: Do not remove the panel covers by unscrewing them. To reduce the risk of
electric shock, do not the remove cover. No user-serviceable parts inside. Refer
servicing to qualified service personnel.
• DO NOT use any accessories, plugs or power supplies not recommended by this
document, or of a lesser Amperage or Voltage.
• CAUTION: To reduce the risk of fire or electric shock and annoying interference, use
the recommended accessories only.
• CAUTION: In order to maintain adequate ventilation, do not install or place this unit
in a bookcase, built in cabinet or any other confined space. To prevent risk of electric
shock or fire hazard due to overheating, ensure that curtains and any other materials
do not obstruct the ventilation.
• CAUTION: Do not lift, move or otherwise transport the device by pulling on the
cables. Always lift your device by the Carry Strap and with a firm grip.
Safety Precaution
3. The device does not play music when it is connected to a Bluetooth mobile phone.
a. Ensure your mobile phone supports A2DP profiles.
b. Ensure your mobile phone is within an effective working range.
4. When paired with my computer, Windows asks for a new driver.
Can you supply this?
We recommend you find compatible drivers for your computer online.
5. Why can I not remotely control the Pause / Play / Previous / Next functions when
music is playing?
This feature needs the Bluetooth device paired with the speaker to support
AVRCP (Audio / Video Remote Control Profile). Please ensure your device
supports this.

• WARNING: Always keep optional accessories, small parts and packaging out of the
reach of babies and small children, as these items may be a choking hazard.
• Servicing: Do not attempt to service this unit yourself as opening or removing the
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
• DO NOT overcharge your Volkano Mamba Series Speaker, doing so will shorten the
lifespan of the built-in battery and could cause your device to overheat.
• CAUTION: Do not disassemble the battery or dispose of it in fire.
• CAUTION: Should your battery show signs of overheating, smoke or fumes being
emitted during charging, remove the charging cable immediately.
Prevent battery leakage from contacting your eyes, skin or clothing. Should this
happen, flush the area with clean water and see a doctor immediately.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT.
• At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center
or to a dealer providing this service. Disposing of a household appliance separately
avoids possible negative consequences for the environment and health deriving from
8
Cleaning & Caring Instruction - General
ENVIRONMENTALLY FRIENDLY DISPOSAL
• Before Cleaning: Ensure that your Volkano Mamba Series Speaker is turned
off and not plugged into any Wall Charger / USB Charging Cable before cleaning or
maintaining your device.
• Cleaning: Wipe down the surface of your Volkano Mamba Series Speaker using
a soft, slightly damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Volkano
Mamba Series Speaker as doing so may damage or scratch the surface finish.
• Do not expose Volkano Mamba Series Speaker to direct sunlight or high tem
peratures for extended periods of time.
• Do not store in temperatures over 60°C. Do not expose the battery to excessive heat
such as sunshine, fire or the like. Store in a cool, dry place.
• DO NOT submerge or expose your Mamba Series Speaker or any parts, including the
cables, power supply or inner workings in or to water.
• DO NOT drag your Volkano Mamba Series Speaker across the floor. Doing so may
damage the base of the unit or the surface you a pulling your device across.

inappropriate disposal and enables the constituent materials to be recovered to obtain
significant savings in energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a crossed-out wheeled
dustbin.
* Never dispose of used electronics with ordinary solid wastes, since they
contain toxic substances.
* Always dispose of used electronics in accordance with the prevailing
community regulations that apply to the disposal of electronics. If there
are no local regulations concerning electronics disposal, please dispose of
the device in a waste bin for electronic devices.
9
This Volkano Mamba Series Bluetooth Speaker comes with a standard 12-month
limited warranty against manufacturing defects and faults. Should your Volkano Mam-
ba Series be unboxed with any faulty parts, poor finishing or visible damage, or fail
to perform due to a manufacturing defect or poor workmanship, please return it with
your proof of purchase (till slip or invoice) to the store of purchase for an exchange, or
repair, depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
Note: The Warranty does not apply to Product that:
1. Has failed due to excessive wear and tear beyond what is considered to
be reasonable.
2. Has been misused or neglected.
3. Has been damaged accidentally or by acts of God including fire and flooding.
4. Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not been
returned in accordance with this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on your warranty,
please call our Customer Care Number on: 011 608 3633.
Warranty
