Yard force LS V14 User manual

READ & UNDERSTAND
INSTRUCTION MANUAL
Save all warnings and instructions for future reference.
CORDLESS PRUNER
Original Instructions
GB
LS V14

2 3
LS V14 Original Instruction
CONTENT
Intended use 04
General safety warnings 04
Product safety warnings 09
Symbols 11
Technical data 14
Description of product 15
Installation 16
Operation 17
Maintenance and storage 18
Troubleshooting 19
Declaration of conformity 20

4 5
INTENDED USE
This pruner is designed for pruning branches and plants with a thickness up to 14 mm. It is
designed for domestic use and is not designed for commercial, trade or industrial use.
For safety reasons it is essential to read this entire instruction manual before initial operation
and to observe all the instructions inside.
This product is intended for private domestic use only, not for commercial trade use. It must
not be used for any purposes other than those described.
GENERAL SAFETY WARNINGS
WARNING: Read all safety directions and instructions.
Omissions in the compliance with safety directions and
instructions can cause electrical shock, re and/or severe
injuries.
Retain all safety directions and instructions for future use.
The term “Power Tools” used in the safety instructions
refers to mains-operated power tools (with power cord)
and to battery operated power tools (without power cord).
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas increase the chances of accidents.
2. Do not operate power tools in explosive atmospheres,
in the presence of ammable Iiquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause momentary loss
of control.
Electrical safety
1. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodied
plugs and matching outlets will reduce risk of electric
shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
GENERAL SAFETY WARNINGS

6 7
GENERAL SAFETY WARNINGS
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result
in serious personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
masks, nonskid safety shoes, hard hats, and hearing
protection can reduce personal injury.
3. Prevent unintentional starting. Ensure the switch is in
the off position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or
energizing power tools that have the switch on invites
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personal injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. The use of dust
collection can reduce dust-related hazards.
Power tool use and care
1. Do not use excessive force while using the power
tool. Use the correct power tool for your application.
The correct power tool will do the job better and more
safely at the rate for which it was designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate. Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect its operation. If
damaged, have the power tool repaired before use.
Many accidents are caused due to poor maintenance.
GENERAL SAFETY WARNINGS

8 9
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
Battery tool use and care
1. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
2. Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a re.
4. Under intensive use, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery
may cause irritation or burns.
GENERAL SAFETY WARNINGS PRODUCT SAFETY WARNINGS
Service
1. Have your power tool serviced by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
Pruner safety warnings
1. Keep all parts of the body away from the cutter blade.
Do not remove cut material or hold material to be cut
when blades are moving. Make sure the switch is off
when clearing jammed material.
2. Hold the pruner by insulated gripping surface only,
because the cutter blade may contact hidden wiring.
Cutter blades contacting a "live" wire may make
exposed metal parts of the pruner "live" and could
give the operator an electric shock.
3. Check and make sure no wire fences or foreign
objects that the pruner may contact during operation.
4. Never operate the pruner with damaged blades.

10 11
PRODUCT SAFETY WARNINGS
Residual risks
Additional residual risks may arise when using the
tool which may not be included in the enclosed safety
warnings. These risks can arise from misuse, prolonged
use etc.
Even with the application of the relevant safety
regulations and the implementation of safety devices,
certain residual risks cannot be avoided. These included:
1. Injuries caused by touching any rotating/moving
parts.
2. Injuries caused when changing any parts, blades or
accessories.
3. Injuries caused by prolonged use of a tool. When
using any tool for prolonged periods ensure you take
regular breaks.
4. Impairment of hearing.
5. Health hazards caused by breathing dust developed
when using your tool (e.g. working with wood,
especially oak, beech and MDF).
SYMBOLS
Safety symbols
The purpose of safety symbols is to attract your attention
to possible dangers. The safety symbols and the
explanations with them require your careful attention
and full understanding. The symbol warnings do not, by
themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand all safety
instructions in this operator’s manual, including all safety
alert symbols such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, re
and/or serious personal injury.
SAFETY ALERT SYMBOL: Indicates DANGER,
WARNING, or CAUTION. May be used in conjunction
with other symbols or pictographs.
Symbol meaning
This page depicts and describes safety symbols that may
appear on this product. Read, understand and follow
all instructions on the machine before attempting to
assemble and operate.

12 13
Symbols on the battery pack
Do not dispose of a battery pack in water!
Do not set on re to dispose!
Do not expose the battery pack to sunlight or
increased temperatures!
Do not dispose of batteries. Return exhausted
batteries to your local collection or recycling point.
Batteries contain Li-ion waste. Do not dispose
of batteries as unsorted municipal waste with
household waste. Check with your Local Authority
or local store for recycling advice.
SYMBOLS
Read the user manual before using the machine.
Warning! Danger!
WEEE symbol. Electrical products should not be
disposed of with household waste. Please recycle
where facilities exist. Check with your Local
Authority or local store for recycling advice.
Batteries contain Li-ion waste. Do not dispose
of batteries as unsorted municipal waste with
household waste. Check with your Local Authority
or local store for recycling advice.
Do not expose the product to rain or wet
conditions.
Keep hands away from blades.
A product placed on the United Kingdom market
meets the UKCA Marking requirements
The product complies with the applicable
European directives and an evaluation method of
conformity for these directives was done.
Li-Ion
SYMBOLS
Li-Ion

14 15
Parts description
1. Blade
2. Electric safety button - ON/OFF
3. Battery pack release lever
4. Safety lever
5. Main trigger
6. Blade cover
Checking the box contents
a. Cordless pruner
b. Balde cover
c. Battery pack
d. Charging wire
e. Manual
Type LS V14
Degree of protection IP X1
MAX Cutting diameter 14 mm
Net weight 0.65kg
Battery pack type AL V40
Battery capacity 4V 4A, 14.4Wh
Input max. 5V 1A
Output (USB type A) 5V 1A
Measured sound power level(LwA) 78.10 dB(A)
Vibration 0.592 m/s2
TECHNICAL DATA DESCRIPTION OF PRODUCT
b
e
c
d
a
1
2
3
4
5
6

16 17
Charging the battery pack
WARNING! Do not use other charging wires which are not recommended by the
manufacturer.
NOTE: The battery is supplied partially charged. To ensure full capacity of the battery, fully
charge the battery before using it on the product.
1. Connect the battery with the charging wire (Type C adaptor).
2. Select an USB type A power source that match to 5V 1A or less.
3. The green indicator will ash during normal use.
4. The Indicator will show solid green light when battery pack has been fully charged.
Insert the battery
- Insert the battery in to the device; make sure the battery pack is in the right orientation.
IMPORTANT: Make sure that the battery pack is inserted in the right orientation, torch light
button on up side.
- If you want to uninstall the battery pack, press the battery pack release lever and then
remove the battery pack.
OPERATION
5V 1A
WARNING: Always wear protective gloves when using the product
WARNING: Whilst cutting the branch make sure your second hand is kept well
away from the pruner blades
To switch ON:
1. Press the electric button and you will see the green light is ON.
2. Hold the pruner rmly, depress and hold the safety lever with middle ngure and ring
ngure, then active the main trigger with index nger.
To switch OFF:
1. Release the main switch.
2. Press the electric button and you will see the green light is OFF.
NOTE: For safety, this pruner could switch off by the blade closed.
- Depress and hold the safety lever with middle ngure and ring ngure, then active the
main trigger with index nger. Hold in the position until the blade is totally closed.
- Press the electric button and you will see the green light is OFF.
Cutting Branch
NOTICE! Risk of damage to the unit!
Be especially careful when working near fences! If material such as fence wire should get
caught up in the cutting unit then switch off the device immediately.
Risk of environmental damage! Before cutting a branch, check no birds are nesting.
NOTE: Do not use the device to cut the branch with diameter over 14mm.
WARNING: Whilst cutting the branch make sure your second hand is kept well away from the
Pruner blades
OPERATION

18 19
MAINTENANCE AND STORAGE
WARNING: Always remove the battery pack before carrying out any cleaning, maintenance
and storage.
WARNING: Always wear protective gloves before doing any cleaning and maintenance.
Maintenance
1. Always switch the product off, disconnect the battery pack and let the product cool
down before performing inspection, maintenance and cleaning work.
2. Keep the product clean. Remove debris from it after each use and before storage, using
a soft damp cloth.
3. Regular and proper cleaning will help ensure safe use and prolong the life of the product.
4. Inspect the product before each use for worn or damaged parts. Do not operate if you
nd broken or worn parts.
WARNING! Only perform repairs and maintenance work according to these instructions. All
further works must be performed by a qualied specialist.
Cleaning
WARNING: Remove the battey pack before making any cleaning or repairs.
Before cleaning, inspecting or repairing your unit, make sure that the motor has stopped and
is cool. Disconnect the battery pack to prevent accidental starting.
NOTE: To ensure the best performance of your product, it is important to keep it clean.
Always clean your cordless pruner immediately after use.
Do not allow debris to become dry and hard on any of the product surfaces. This will directly
affect the cutting performance. Never clean the product with a water jet or high pressure
cleaner. The motor must remain dry. Do not use aggressive cleaning agents such as cold
cleaner or petroleum ether.
Transportation
1. Switch the product off and disconnect the battery pack from the machine before
transporting it anywhere.
2. Attach transportation guards, if applicable.
3. Always transport the product by its handle. When lifting the product use the
transportation handle as an aid.
4. Protect the product from any heavy impact or strong vibrations which may occur during
transportation in vehicles.
5. Secure the product to prevent it from slipping or falling over.
Storage
1. Clean the product as described above and disconnect the battery pack.
2. Store the product and its accessories in a dry, frost-free area.
3. Always store the product in a place that is inaccessible to children. The ideal storage
temperature is between 10°C and 30°C.
4. We recommend using the original packaging for storage or covering the product with a
suitable cloth or enclosure to protect it against dust.
TROUBLESHOOTING
Fault Possible cause Troubleshooting
Device fails to start
Battery pack discharged? Charge the battery
Battery pack defective? Contact service center
Is the device defective? Contact service center
Bad cutting
performance
The blade is worn Resharpen the blades
Branch diameter over 14 mm Try to cut small branch
Device fails to start Battery pack not fully inserted Reinsert battery pack fully (sound
"click")

20 21
DECLARATION OF CONFORMITY
To the provisions of Council Directives
We
SUMEC UK Co.,Ltd.
Unit A&B, Escrick Business Park
Escrick, York YO 19 6FD
Declare that the product:
Machine Description: Cordless Pruner
Machine Type: LS V14
Function: Cutting branch
Complies with the essential health and safety requirements of the following directives:
Supply of Machinery (Safety) Regulations 2008
Electromagnetic Compatibility Regulations 2016
Noise Emission in the Environment by Equipment for use Outdoors Regulations 2001
The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012
Standards and technical specication referred to :
EN 55014-1:2017+A11:2020
EN 55014-2:2015
EN 60335-1
EN 50636-2-94
Authorized Signatory
Date: 18.01.2022
Signature: ________________________
Place: York
Name: Mariana Hall
General Manager
SUMEC UK
Unit A&B Escrick Business Park
Escrick, York
YO19 6FD
DECLARATION OF CONFORMITY
To the provisions of Council Directives
We
MEROTEC GmbH
Otto-Brenner-Str. 8, 47877 Willich
Germany
Declare that the product:
Machine Description: Cordless Pruner
Machine Type: LS V14
Function: Cutting branch
Complies with the essential health and safety requirements of the
following directives:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
Noise Directive, amended by 2005/88/EC
EC Directive 2011/65/EU and its amendment Directive (EU) 2015/863 (RoHS)
Standards and technical specification referred to:
EN 55014-1:2017+A11:2020
EN 55014-2:2015
EN 60335-1
EN 50636-2-94
Authorized Signatory
Date: 18.01.2022
Signature:________________________
Place: Willich
Name: Ronald Menken
General Manager
MEROTEC GmbH
Otto-Brenner-Str. 8
D-47877 Willich,Germany
