YI AT325 User manual

The AT325 smartwatch instruction manual
01 Product introduction
Please read the manual carefully and keep it properly. For more detailed
product information, please bind the watch first and then check the
instruction manual.
The products, accessories, and user interface in the instruction manual
are schematic drawings for reference only. Due to the update and
upgrade of the product, the physical product and the schematic diagram
may be slightly different, please refer to the physical object.
Note: The watch is made of healthy material. After a strict skin allergy test, you can
wear it safely. Due to personal differences, if you feel skin discomfort when wearing
them, please stop wearing them and consult your doctor.
02 Install the watch APP
Scan the QR code below or enter the major app market to download
it Install the 'GloryFitPro's
Open the mobile phone APP to set up
your personal information

Wechat scans the QR code on the watch
03 Use operation
1. Slide down from the top edge on the dial home page: open the
shortcut menu.
2. Slide right on the dial home page: open the split screen page.
3. Slide on the bottom edge on the dial homepage: open the
Switch to the Device page and click
BinDevice
Click on your device in the list of
scanned devices
Bindin
g
comple
ted

message notification.
4. Slide left on the dial home page: switch between the function
card.
5. Swipe right from the left edge on the other page: Return to
the upper level.
6. Press the length of the dial home page: select another dial
setting.
04. Core functions
The watch supports Bluetooth call, daily activity monitoring,
exercise mode monitoring, health management data monitoring,
message reminder and other functions.
1、Bluetooth call
The watch can be connected to the smartphone through Bluetooth,
and it can also call / answer and reject the calls at the end
of the watch, and check the call records and contacts.
2、Monitoring of daily activities
A watch worn on the wrist can monitor and record the number of steps,

distances, and calories in daily activities.
Note: The frequency of hand movements will affect the accuracy of data recording.
3、Health management monitoring
The watch supports the monitoring and display of health data such as
heart rate, blood oxygen, pressure and sleep (the health data provided is
for reference only and not as medical diagnosis data).
A. Heart rate monitoring
Monitor the real-time heart rate, the watch can record and display the
heart rate value of 24h all day, and set the highest and lowest heart rate
warning.
B. Blood oxygen monitoring
Measure the current blood oxygen value, the watch can record and
display the blood oxygen value of 24h all day, and set the hypotension
warning.
C. pressure monitoring
Measure the current pressure value, easily, normal, medium, and high.

D. Sleep information
Record and display total sleep duration, deep sleep, light sleep, rapid eye
movement, wake duration, and check more on the APP.
E. One key measurement
You can measure heart rate, blood oxygen and pressure with one key.
F. Women's health
The female physiological cycle and prompt time can be set in the APP to
synchronize to the watch. The corresponding information and prompts
can be displayed on the watch end.
4、Motion mode monitoring
The watch supports a multi-function motion mode, and can set the
movement targets and data records.
Exercise supports 100 + sports modes: outdoor running, outdoor cycling,
indoor running, indoor cycling, rope skipping, badminton, table tennis,
tennis, mountaineering, basketball, football, baseball, volleyball, cricket,
rugby, hockey, dancing, yoga, sit-ups, gymnastics, boating, opening and
closing, free training...

5、Other functions
Information, weather, music, voice assistant, low power reminder, alarm
clock, call reminder, looking for mobile phone, sedentary reminder, wrist
bright screen, 12 / 24 time system, flashlight, stopwatch, timer, screen
display, calculator, etc. (due to the functional differences between
various types of watch, the specific physical object shall prevail).
05 Charging
When the watch indicates that the power level is low, please charge it in
time.
The watch is a magnetic suction charging, charging the charging contact
of the charging cable at the charging port of the watch until the charging
power appears on the watch screen
point out:
1. Please use the watch special charging line for charging. The charging
mode is single direction. Please pay attention to the charging direction.

2. When charging, in order to ensure the stability of charging, the watch
will charge on the screen, click the button to wake up the watch, when
the watch power is too low, it needs to charge for 3~5 minutes to wake
up the watch, which is normal, please wait for 5 minutes to check the
charging situation of the watch.
3. Please use the charger with rated output voltage 5V and rated output
current 0.5A or the computer USB interface to charge the watch.
06. Basic parameters
Main control chip
ATS3085L
battery capacity
340mAh
Display size
1.78" Amoled
duration of flight
10 Days

resolution ratio
368*448px
PDA
Bluetooth5.3
Product weight
About 35g
working temperature
0°C~45°C
product size
50.8*39.3*12.3mm
Compatible system
Android5.0+IOS10.0
Carpal band material
silica gel
packing list
Host machine, charging cable, and
instruction manual
07 Notes
1. Please avoid strong impact, extreme heat and sun exposure
to the watch.
2. Do not disassemble, repair, or modify the machine by
yourself.
3. The use environment of this machine is 0°C~45°C. It is
forbidden to throw it into the fire to avoid causing explosion.
4. When the watch is wet, please dry with a soft cloth before

running charging operation, otherwise it will corrode the
charging contact point and lead to charging fault.
5. Do not make contact with chemicals such as gasoline,
cleaning solvents, propanol, alcohol, or insect repellent.
6. Do not use this product in a high pressure and high magnetic
environment.
7. Please dry the sweat drops on your wrist. Long time contact
with soap, sweat, allergens or contamination ingredients,
which may cause skin allergy and itching.
8. If you wear it regularly, it is recommended to clean the
watch every week, wipe it with a wet cloth, and remove oil or
dust with mild soap. It can be worn when washing your face and
hands, and it is not recommended to wear it when taking a bath
or swimming.
9.Charge with the attached charging cable and the CCC certified
power adapter.

Three guarantees of vouchers
Three guarantees of vouchers
customer
information
model
Selling
machine
unit
Customer
name
contact
number
Sales
telephone
date of
purchase
Customer
address
Sales
address
abstract
date
fault
phenomenon

examine and
repair
remarks
[Product name] Smart watch
[Product Model] AT325
[Wireless Connection] Bluetooth BLE 5.3
[Execution standard] GB-XXXX-XXXX
[Manufacturer] Uchuang yi Health Technology (Guangzhou) Co., Ltd
[Address] No.228, Huadi Avenue, Liwan District, Guangzhou city
This device complies with part 15 of the FCC Rules. Operation is subject to the foll

owing two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Cl
ass B digital device, pursuant to part 15 of the FCC Rules. These limits are designe
d to provide reasonable protection against harmful interference in a residential ins
tallation. This equipment generates uses and can radiate radio frequency energy a
nd, if not installed and used in accordance with the instructions, may cause harmf
ul interference to radio communications. However, there is no guarantee that inter
ference will not occur in a particular installation. If this equipment does cause har
mful interference to radio or television reception, which can be determined by tur
ning the equipment off and on, the user is encouraged to try to correct the interfe
rence by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The devi
ce can be used in portable exposure condition without restriction.
