Yolink YS4803-UC User manual

Smart IR Remote
User Guide
YS4803-UC

Contents
Introduction··········································· · ·· 1·········· ···· ··
Product Requirements····························· ··· ··········· ···· ··2
Features··································································2
Set Up mart IR Remote····················· ··· · S ················· ···· ·3
Using YoLink A with pp Smart IR Remote···························10
Specifications····································· ·········· ···········16
Maintaining the IR Remote·········· · ·· Smart ···· ········· ········14
Troubleshooting ·················· ····· ·········· 17··········· ····· ······ ·
What’s In The Box······· ····· · ·· · ·2······················ ····· ·········· · ·
WARNING··········· ····· ······ ·· ·· ··················· ····· ·· ·· ········· 18
Customer Service & Warranty ····· ·· ·········· 19················ ·· ··· ·

Introduction
Worked as All-in-one IR remote controller, Smart IR Remote allows you to copy all frequency
of 38k infrared remote. Place it to wherever in front of the TV, DVD or other infrared appliance,
download YoLink App, add Smart IR Remote to your smart home system, which will able to
remote control the infrared appliance.
1
LED light can show you the current status. See the explanation below:s
POWER BUTTON
GREEN ONCE
Remote Controlled.
BLINKING RED AND GREEN ALTERNATELY
Factory resetting.
SLOW BLINKING GREEN
Updating.
BLINKING RED
Copying the button of remote.
BLINKING GREEN
Connecting to cloud.

2
Features
Product Requirements
Control from anywhere - Control your infrared appliance remotely via YoLink App on your
iOS or Android device.
Schedule - Automatically control your infrared appliance at a certain time.
Scene - One click control. Tap the scene button to automatically control your infrared appliance
and action of other devices.
Automation - Set up rules for “If this then that” function.
Voice Control - Use Alexa or Google Assistant to control your devices with voice commands.
Battery Status - Update battery level and send low battery alert.
A YoLink Hub.
A smartphone or tablet running iOS 9
or higher; Android 4.4 or higher.
What’s In The Box
Qty1 - Smart IR Remote
Quick Start Guide

3
Set Up Smart IR Remote
Follow the steps below to set up your Smart IR Remote via YoLink App.
Step 1: Set up YoLink App
Get the YoLink App from the Apple App Store or Google Play.

4
If you don’t have a YoLink account, tap Sign up for an account and follow the steps
to sign up an account.
Open the App. Use your YoLink account to log in.
Step 2: Log in or sign up with YoLink account

5
Step 3: Add device to YoLink App
b. Room - Choose a room for Smart IR Remote.
a. Name - Name Smart IR Remote.
You can customize the name, set the room, add to/remove from favourite.
Tap the “ ” in YoLink App. Scan the QR Code on the device.
Tap the “Bind Device” to add the device to your YoLink account.
c. Favourite - Click “ ” icon to add/remove from Favourite.
a
b
c

6
Step 4: Connect to the cloud
Press the SET button once and your device will connect to the cloud automatically.
Note
Make sure you hub is connected to internet.
Cloud
Internet
POWER BUTTON

7
Step 5: Copy the remote button
Tap the “Smart IR Remote” in App to go to its controls.
Note
Maximum 64 buttons can be copied to one Smart IR Remote.
Tap “Add Remote” in App to add a remote controller.
Select a type of remote controller and set a name.
Tap each of the button to copy the remote controller, LED light blinks red, press the
corresponding button on the remote controller with aiming the remote at the middle of the
Smart IR Remote.
No limit to the number of remote added.

Diagram
8
ok
Inp ut
aux
dvd
cbl
tv
set up
D
C
B
A
*
menu
volch
ch
3
2
ente r
6
5
4
9
8
7
0
1
Press the button on
the remote controller
Button Copied Copy Failed

Step 6: Device placement
Place your Smart IR Remote in front of your infrared appliance.
Note
Please keep no objects between the Smart IR Remote and controlled infrared appliance.
9

Using YoLink App with Smart IR Remote
Details
You can customize the name, set the room, add to/remove from favourite, check device history.
d. History - Check the history log for the Smart IR
Remote.
b. Room - Choose a room for Smart IR Remote.
a. Nam e - Nam e S mar t I R Re mot e.
e. Delete - The device will be removed from your
YoLink account.
Tap the icon for each of the settings you want to
personalize.
Tap the “ ” icon at the top-right corner to go to
details.
Tap t he “Sm art IR Remot e” in App to go to its
co ntrols.
c. Favourite - Click “ ” icon to add/remove from
Favourite.
a
b
c
d
e
10

Schedule
You can create button control schedules to automate your switch to cooperate with your
home and work schedules.
Within the Add Schedule screen, set the time,
your p r e f e r r e d b e h a v i o r for t h e infr a r e d
appliance, and repeating frequency.
Note
Tap “Schedule” to open the Schedule screen,
tap “ ” to add a new schedule.
Activate or deactivate the schedule at schedule
screen.
Swipe left each schedule to edit or delete it.
You can keep maximum 10 schedules at one time.
The schedule here is running at device without
internet.
You can add schedule at Automation where you
can add as many as you want. The automation
setting is saved in cloud.
Tap “ ” icon to save.
Tap t he “Sm art IR Remot e” in App to go to its
co ntrols.
11

Scene
Set one-click control for multiple devices in your YoLink App. Only one scene can be run at
a time on YoLink App.
To set a Scene, you will be able to put one or more
devices under this scene, and define their actions
and/or states.
Tap “ ” to create your own Scene.
Tap “Smart” to switch to Smart Screen.
Swipe left any Scene order to edit or delete it.
To execute a Scene, you may tap any scene at
“Smart” or “Favourite” if you mark it as favourite.
Note
You must have at least one YoLink Device in order
to create a Scene.
12

Automation
Automation allows you to set up “If this then that” rules so the devices could act automatically.
Tap “Smart” to switch to Smart screen and tap
“Automation”.
To set an Automation, you will need to set a trigger
time, local weather condition, or choose a device
with certain stage as a triggered condition. Then
set one or more devices, scenes to be executed.
Tap “ ” to create an automation.
13

Maintaining the Smart IR Remote
Firmware Update
To ensure our customer have the best user experience, we highly recommend you could
update our newest version firmware.
Note
Only the Smart IR Remote that is currently
reachable and has an available update will be
shown on the Details screen.
The light will be slowly blinking green during the
update and stop blinking when the update done.
Tap “Firmware”.
Tap the “ ” icon at the top-right corner to go to
details.
Tap t he “Sm art IR Remot e” in App to go to its
co ntrols.
14

Factory Reset
Factory reset will erase all your settings and bring it back to default. After the factory reset,
your device will still in your Yolink account.
Hold the power button for 20-25 seconds until the LED blinks red and green alternately.
Factory reset will be done when the light stops flashing.
POWER BUTTON
15

Specifications
Infrared Remote Distance: 7~8m
Environment: Working Temperature: 0°C~50°C (32°F~122°F)
Working Humidity: 0%~90% non-condensing
Voltage: 3V DC (2 - AA Battery)
16

Troubleshooting
Problem Possible Reason Solution
Smart IR Remote is
offline.
Smart IR Remote is battery died. Please replace the two batteries.
Please power on the hub again and press
the set button of Smart IR Remote once.
Hub is offline.
Please reconnect your hub to the Internet
and press the set button of Smart IR
Remote once.
Hub is powered off.
Press button via App,
infrared appliance has
no action.
Other problems. Please contact customer service.
Other reasons. Please contact customer service.
Smart IR Remote is battery died. Please replace the two batteries.
Mix a new battery with an old one. Please replace the two batteries.
Button has not copied. Please copy the button first.
Please re-adjust the Smart IR Remote.
There is objects between Smart IR
Remote and controlled infrared
appliance.
17

WARNING
This product is not waterproof, please keep it dry.
Keep away from dusty, wet or dirty.
Keep away from high temperature or fire.
On ly support 38k serie s r emo tes.
Do not expose the product and its batteries to high temperatures or heating devices such
as sunlight, heaters, microwaves, ovens or water heaters.
Please do not mix a new battery with an old one, or it may affect the use of product.
To avoid dust entering the product and affect the usage of the product, do not use strong
chemicals or cleaning agents to clean this product, please use a clean, dry cloth to wipe
this product.
Pl ace the pr odu ct in an ope n p lace, wall and other fac tors will aff ect the
co mmunicat ion dista nce and range .
Do not disassemble or modify this product by yourself. In case of equipment failure,
please contact our customer service.
Keep the product from strong shocking, so as not to damage the product.
Do not treat this product, battery and other accessories as domestic garbage to
avoid environmental pollution. Please dispose them according to local regulations.
