York Sunline 2000 Quick start guide

637367-XTG-B-1110
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
TECHNICAL GUIDE (R-407C)
SINGLE PACKAGE GAS/ELECTRIC UNITS
AND SINGLE PACKAGE
AIR CONDITIONERS
DC 036, 048, 060 & 076
3, 4, 5 & 6.3 NOMINAL TONS
(50 HZ EXPORT)
®
DESCRIPTION
YORK Sunline 2000TM units are convertible single package
air conditioners with a common cabinet and a common roof
curb for the 3, 4, 5 and 6.3 ton sizes. The units were designed
for light commercial and commercial applications. They can
easily be installed on a roof curb, slab, roof jack or frame.
All units include:
• Powder Paint finish that meets ASTM-B-117 1000 hour
salt spray standards
• Permanently lubricated motors
• Bottom or side air discharge configuration capability
(field convertible)
• Manufactured under the quality standards of ISO9001
•Simplicity® Control Board
• Copper tube/aluminum fin coils
• Easy access to all components
• Rigging holes in base rails for lifting
• Fork lift slots on three sides
• Single point power connection
• Complete factory package - tested, charged and wired

637367-XTG-B-1110
2Johnson Controls Unitary Products
TABLE OF CONTENTS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
PRODUCT NOMENCLATURE . . . . . . . . . . . . . . . . . 3
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FACTORY-INSTALLED OPTIONS . . . . . . . . . . . . . . 7
FIELD-INSTALLED ACCESSORIES . . . . . . . . . . . . 7
LIST OF FIGURES
Fig. # Pg. #
1 UNIT CUTAWAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 TYPICAL FIELD POWER & CONTROL WIRING . . . .20
3 UNIT DIMENSIONS (3 - 6 TON COOLING ONLY/
ELECTRIC HEAT) FRONT VIEW . . . . . . . . . . . . . . . .21
4 UNIT DIMENSIONS (3 - 6 TON COOLING/GAS HEAT)
FRONT VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5 UNIT WITH ECONOMIZER RAINHOOD . . . . . . . . . .22
6 UNIT WITH FIXED OUTDOOR AIR/MOTORIZED
DAMPER RAINHOOD . . . . . . . . . . . . . . . . . . . . . . . .22
7 UNIT DIMENSIONS (REAR VIEW) . . . . . . . . . . . . . .23
8 DISCONNECT/BLOWER ACCESS LOCATION . . . .23
9 TYPICAL APPLICATIONS . . . . . . . . . . . . . . . . . . . . .24
10 FOUR AND SIX POINT LOADING . . . . . . . . . . . . . . .25
11 ROOF CURB DIMENSIONS . . . . . . . . . . . . . . . . . . . .26
LIST OF TABLES
Tbl. # Pg. #
1 SOUND POWER RATING . . . . . . . . . . . . . . . . . . . . . . 9
2 CAPACITY RATINGS - (ARI 210/240) . . . . . . . . . . . . . 9
3 GAS HEAT RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 DC036 COOLING CAPACITIES (3 TON) . . . . . . . . . 10
5 DC048 COOLING CAPACITIES (4 TON) . . . . . . . . . 11
6 DC060 COOLING CAPACITIES (5 TON) . . . . . . . . . 12
7 DC076 COOLING CAPACITIES (6.3 TON) . . . . . . . . 13
8 SUPPLY AIR BLOWER PERFORMANCE (3 & 4 TON
DIRECT DRIVE) - SIDE DUCT APPLICATION . . . . . 14
9 SUPPLY AIR BLOWER PERFORMANCE (5 TON
BELT DRIVE) - SIDE DUCT APPLICATION. . . . . . . . 15
10 SUPPLY AIR BLOWER PERFORMANCE (6.3
TON BELT DRIVE) - SIDE DUCT APPLICATION . . . 16
11 BELT DRIVE MOTOR AND DRIVE DATA . . . . . . . . . 17
12 STATIC RESISTANCES . . . . . . . . . . . . . . . . . . . . . . 17
13 ELECTRIC HEATER SUPPLY AIR LIMITATIONS . . 17
14 ELECTRICAL DATA: 3 - 6.3 TON . . . . . . . . . . . . . . . 18
15 PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
16 ELECTRIC HEAT CORRECTION FACTORS . . . . . . 19
17 VOLTAGE LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . 19
18 UTILITIES ENTRY . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
19 MINIMUM CLEARANCES . . . . . . . . . . . . . . . . . . . . . 23
20 DC 4 POINT LOADS WEIGHT DISTRIBUTION
(KG / LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
21 DC 6 POINT LOADS WEIGHT DISTRIBUTION
(KG / LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
22 CENTER OF GRAVITY . . . . . . . . . . . . . . . . . . . . . . . 25
23 OPERATING WEIGHTS (KG / LBS.) . . . . . . . . . . . . . 26

637367-XTG-B-1110
Johnson Controls Unitary Products 3
PRODUCT NOMENCLATURE
D C 048 N04 A 7 A AA 1 0 1 2 4 A
D = A/C, Single Pkg.
Product Category
A = Direct Drive
Airflow
B = Direct Drive/Single Input Economizer
D = Direct Drive/Motorized Damper
N = Belt Drive
P = Belt Drive/Single Input Economizer
R = Belt Drive/Motorized Damper
1 = First Generation
Product Generation
2 = Second Generation
3 = Third Generation
C00 = Cooling Only. Suitable for Field
Installed Electric Heat
Heat Type and Nominal Heat Capacity
N04 = 40 MBH Output Aluminized Steel, 1 Stage (036)
N06 = 60 MBH Output Aluminized Steel, 1 Stage (048)
N08 = 80 MBH Output Aluminized Steel, 1 Stage
(060, 076)
E05 = 5 KW
E07 = 7 KW
E10 = 10 KW
E15 = 15 KW
E20 = 20 KW
E30 = 30 KW
Gas Heat Options
Electric Heat Options
036 = 3.0 Ton
Nominal Cooling Capacity
048 = 4.0 Ton
060 = 5.0 Ton
076 = 6.3 Ton
Product Identifier
C = R-407C
Voltage
7 = 380/415-3-50
Product Style
A = Style A
A = No Options Installed
Installation Options
B = Option 1
C = Option 2
D = Options 1 & 2
E = Option 3
F = Option 4
G = Options 1 & 3
H = Options 1 & 4
J = Options 1, 2 & 3
K = Options 1, 2, & 4
L = Options 1,3 & 4
M = Options 1, 2, 3, & 4
N = Options 2 & 3
P = Options 2 & 4
Q = Options 2, 3, & 4
R = Options 3 & 4
S = Option 5
T = Options 1 & 5
U = Options 1, 3, & 5
V = Options 1, 4, & 5
W = Options 1, 3, 4, & 5
X = Options 3 & 5
Y = Options 4 & 5
Z = Options 3, 4 & 5
1 = Disconnect
2 = Non-Pwr'd Conv. Outlet
3 = Smoke Detector S.A.
4 = Smoke Detector R.A.
5 = Pwr'd Conv. Outlet
Options
SS Drain Pan
Configuration Options (not required for all units)
These four digits will not be assigned until a quote is requested, or an order placed.
CPC Controller, DFS, APS
Johnson Controller, DFS, APS
Honeywell Controller, DFS, APS
Novar Controller, DFS, APS
Simplicity IntelliComfort Controller
Simplicity IntelliComfort Controller w/ModLinc
2" Pleated filters
BAS Ready Economizer (2-10 V. D. C. Actuator without a Controller)
Any Combination of Additional Options that Don’t Have an Option Code Pre-assigned
AA = None
Standard Cabinet
AB = Phase Monitor
AC = Coil Guard
AD = Dirty Filter Switch
AE = Phase Monitor & Coil Guard
AF = Phase Monitor & Dirty Filter Switch
AG = Coil Guard & Dirty Filter Switch
AH = Phase Monitor, Coil Guard & Dirty Filter Switch
AS = Bottom Drain Connection
RC = Coil Guard & American Flag
TA = Technicoat Condenser Coil
TJ = Technicoat Evaporator Coil
TS = Technicoat Evaporator and Condenser Coil
Additional Options
Hinged Filter Door & Toolless Access Cabinet
BA = Hinged Filter Door & Toolless Access Panels
BB = Phase Monitor, Hinged Filter Door & Toolless
Access Panels
BC = Coil Guard, Hinged Filter Door & Toolless
Access Panels
BD = Dirty Filter Switch, Hinged Filter Door &
Toolless Access Panels
BE = Phase Monitor & Coil Guard, Hinged Filter
Door & Toolless Access Panels
BF = Phase Monitor & Dirty Filter Switch, Hinged
Filter Door & Toolless Access Panels
BG = Coil Guard & Dirty Filter Switch, Hinged Filter
Door & Toolless Access Panels
BH = Phase Monitor, Coil Guard & Dirty Filter Switch,
Hinged Filter Door & Toolless Access Panels
BA = Hinged Filter Door & Toolless Access Panels
BA = Hinged Filter Door & Toolless Access Panels
ZZ = If desired option combination is not listed above, ZZ will be assigned and configuration options will be
located in digits 15-18.

637367-XTG-B-1110
4Johnson Controls Unitary Products
FEATURES
All models are available with a wide variety of factory-
mounted options such as stainless steel heat exchangers,
phase monitor, dirty filter switch, and coil guard to make them
suitable for almost every application.
All units are self-contained and assembled on full perimeter
base rails with forklift holes on three sides and holes for over-
head rigging. Every unit is completely piped, wired, charged
and tested at the factory to simplify the field installation and to
provide years of dependable operation.
All models (including those with an economizer) are suitable
for either bottom or horizontal duct connections. For bottom
duct, remove the sheet metal panels from the supply and
return air openings through the base of the unit. For horizon-
tal duct, remove the supply and return air panels on the rear
of the unit.
All models are available with these “factory mounted” outdoor
air damper options:
• Single enthalpy economizer
• Motorized outdoor air damper
Supply air blowers are equipped with either a direct drive or a
belt drive that can be adjusted to meet the exact require-
ments of the job.
All compressors are equipped with internal pressure relief.
Every refrigerant circuit includes a liquid line filter-drier, a high
pressure switch and a suction line with a freezestat and low
pressure/loss of charge switch to protect all system compo-
nents.
•Simplicity®Controls - Simplicity®control boards have
standardized a number of features previously available
only as options or by utilizing additional controls.
•Low Ambient - An integrated low-ambient control
allows all units to operate in the cooling mode down
to 0ºF outdoor ambient without additional assis-
tance. Optionally, the control board can be pro-
grammed to lockout the compressors when the
outdoor air temperature is low or when free cooling
is available.
•Anti-Short Cycle Protection - To aid compressor
life, an anti-short cycle delay is incorporated into the
standard controls. Compressor reliability is further
ensured by programmable minimum run times. For
testing, the anti short cycle delay can be temporarily
overridden with the push of a button.
•Fan Delays - Fan on and fan off delays are fully pro-
grammable and are independent of one another. All
units are programmed with default values based
upon their configuration of cooling and heat.
•Safety Monitoring - The control board monitors the
high and low-pressure switches, the freezestats, the
gas valve, if applicable, and the temperature limit
switch on gas heat units. The unit control board will
alarm on ignition failures, compressor lockouts and
repeated limit switch trips.
•Nuisance Trip Protection- To prevent nuisance
trouble calls, the control board uses a “three strikes,
you’re out” philosophy. The high and low-pressure
switches and the freezestats must trip three times
within two hours before the unit control board will
lock out the compressor.
•On Board Diagnostics - Each alarm will energize a
trouble light on the thermostat, if so equipped, and
flash an alarm code on the control board LED. Each
high and low-pressure switch alarm as well as each
freezestat alarm has its own flash code. The control
board saves the five most recent alarms in memory,
and these alarms can be reviewed at any time.
Alarms and programmed values are retained
through the loss of power.
The Simplicity® control board used in this product
will effectively operate the cooling system down to
0°F when this product is applied in a comfort cooling
application for people. An economizer is typically
included in this type of application. When applying
this product for process cooling applications (com-
puter rooms, switchgear, etc.), please reference
applications bulletin AE-011-07 or call the applica-
tions department for Unitary Products @ 1-877-
UPG-SERV for guidance. Additional accessories
may be needed for stable operation at temperatures
below 30° F.

637367-XTG-B-1110
Johnson Controls Unitary Products 5
All units have long lasting powder paint cabinets with 1000
hour salt spray test approval under ASTM-B117 procedures.
•Gas Heat Operation - All gas heat units have a mini-
mum AFUE of 80%. Each section includes a durable
heat exchanger with aluminized steel or optional stain-
less steel tubes, a redundant gas valve, spark ignition,
power venting, an ignition module for 100% shut-off and
all of the safety controls required to meet the latest ANSI
standards.
The gas supply piping can be routed into the heating
compartment through a hole in the base pan of the unit
or through a knockout in the piping panel on the front of
the unit.
•Electric Heat Operation - All electric heat models are
wired for a single power source and include a bank of
nickel chromium elements mounted at the discharge of
the supply air blower to provide a high velocity and uni-
form distribution of air across the heating elements.
Every element is fully protected against excessive tem-
perature by thermal limit switches.
The power supply wiring can be routed into the control
box through a threaded pipe connection (field supplied)
in the base pan of the unit or through a knockout in the
wiring panel on the side of the unit.
•BAS Controls - York’s Sunline™ series units offer fac-
tory mounted BAS controls such as Novar, Honeywell,
Johnson, and CPC.

637367-XTG-B-1110
6Johnson Controls Unitary Products
GAS/ELECTRIC
ELECTRIC/ELECTRIC
FIGURE 1 - UNIT CUTAWAY
3/4 " PVC female
condensate drain
Knockout
for side
control entry
GFCI
convenience outlet
Smoke
detector
Slide-in
economizer
Economizer
hood
HACR
breaker
20 Gauge aluminized
steel tubular heat exchanger
Electric heat
accessory location
Power ventor motor with
post purge cycle
High efficiency
compressor
Knockout for side
gas supply entry
Simplicity® Lite™
control board
Copper tube/
aluminum fin
condensing coil
Full perimeter baserails
with forklift slots and
lifting holes
Knockout
for side
power entry
Belt drive or
Direct drive
blower
3/4 " PVC female
condensate drain
Knockout
for side
control entry
GFCI
convenience outlet
Smoke
detector
Slide-in
economizer
Economizer
hood
HACR
breaker
Belt drive or
Direct drive
blower
High efficiency
compressor
Copper tube/
aluminum fin
condensing coil
Full perimeter baserails
with forklift slots and
lifting holes
Knockout
for side
power entry
Electric Heat
accessory location
Simplicity® Lite™
control board

637367-XTG-B-1110
Johnson Controls Unitary Products 7
FACTORY-INSTALLED OPTIONS
•SINGLE INPUT ELECTRONIC ENTHALPY ECONO-
MIZERS - Includes a slide-in / plug-in damper assembly
with fully modulating spring-return motor actuator capa-
ble of introducing up to 100% outdoor air with nominal
1% leakage type dampers.
The enthalpy system contains one sensor that monitors
the outdoor air and determines when the air is cool
enough and dry enough to provide free cooling.
The rainhood is painted to match the basic unit and must
be field-assembled before installing.
•MOTORIZED OUTDOOR AIR INTAKE DAMPER -
Includes a slide-in / plug-in damper assembly with a 2-posi-
tion, spring return motor actuator which opens to a pre-set
position whenever the supply air blower is operating and
will drive fully closed when the blower unit shuts down.
The rain hood is painted to match the basic unit and
must be field assembled before installing.
•PHENOLIC COATED EVAPORATOR AND CON-
DENSER COILS - Special coating process that utilizes
Technicoat 10-1TM processes. Coating is applied by total
immersion of the complete coil for maximum protection.
•ELECTRIC HEATERS wired for single point power sup-
ply. These nickel chromium heater elements are pro-
vided with limit and automatic reset capability to prevent
operation at excessive temperatures.
•FILTER OPTIONS - Standard units are shipped with
25mm (1”) throw-away filters installed. 50mm (2”)
pleated filters are offered as a factory installed option.
•CONVENIENCE OUTLET - The unit may be ordered
with a “non-powered” convenience outlet that can be
wired in the field.
•DISCONNECT SWITCH - For gas heat units and cooling
units with electric heat, a HACR breaker sized to the unit
is provided. For cooling only units, a switch sized to the
largest electric heat available for the particular unit is
provided. Factory installed option only.
•BAS - See “Additional Options” section in the product
nomenclature.
•SMOKE DETECTORS - (supply air & return air) The
smoke detectors stop operation of the unit by interrupting
power to the control board if smoke is detected within the
air compartment.
m
•COIL GUARD - Customers can purchase a coil guard kit
to protect the condenser coil from damage. This is not a
hail guard kit.
•STAINLESS STEEL HEAT EXCHANGER - For applica-
tions in corrosive environments, this option provides a
full stainless steel heat exchanger assembly.
•PHASE MONITORS - Designed to prevent unit damage.
The phase monitor will shut the unit down in an out-of-
phase condition.
•DIRTY FILTER SWITCH - This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally high
pressure drop across the filters. Factory installed option
or field installed accessory.
•HINGED FILTER DOOR/“TOOLLESS” BLOWER AND
ACCESS PANELS (not hinged) - This option allows for
easy access and maintenance.
NOTE:Knobs are shipped inside the unit to prevent ship-
ping damage. These must be field installed for
tool-less operation.
FIELD-INSTALLED ACCESSORIES
•SINGLE INPUT ELECTRONIC ENTHALPY ECONO-
MIZERS - Includes a slide-in / plug-in damper assembly
with fully modulating spring-return motor actuator capa-
ble of introducing up to 100% outdoor air with nominal
1% leakage type dampers.
The enthalpy system contains one sensor that monitors
the outdoor air and determines when the air is cool
enough and dry enough to provide free cooling.
The rainhood is painted to match the basic unit and must
be field-assembled before installing.
•MOTORIZED OUTDOOR AIR INTAKE DAMPER -
Includes a slide-in / plug-in damper assembly with a 2-
position, spring return motor actuator which opens to
some pre-set position whenever the supply air blower is
operating and will drive fully closed when the blower unit
shuts down.
The rain hood is painted to match the basic unit and
must be field assembled before installing.
•ELECTRIC HEATERS wired for single point power sup-
ply. These nickel chromium heater elements are pro-
vided with limit and automatic reset capability to prevent
operation at excessive temperatures.
•ROOF CURBS - Eight and fourteen-inch high roof curbs
provide a water-tight seal between the unit and the finished
roof. These full perimeter curbs meet the requirements of
the National Roofing Contractors Association (NRCA) and
are shipped knocked-down for field assembly.
Roof curbs are designed to fit inside the base rails of the
unit and include both a wood nailing strip and duct
hanger supports.
Factory installed Smoke Detectors in the Return
Air, may be subjected to freezing temperatures
during “off” times due to Out Side Air infiltration.
These Smoke Detectors have an operational limit
of 32°F to 131°F. Smoke Detectors installed in
areas that could be out side those limitations will
have to be moved to prevent having false alarms.

637367-XTG-B-1110
8Johnson Controls Unitary Products
•HIGH ALTITUDE NATURAL GAS - Burner orifices and
pilot orifices are provided for proper furnace operation at
altitudes up to 6,000 feet.
•PROPANE - Burner orifices, pilot orifices and gas valve
parts are provided to convert a natural gas furnace to
propane.
•HIGH ALTITUDE PROPANE - Burner orifices and pilot
orifices are provided for proper furnace operation at alti-
tudes up to 6,000 feet. This accessory supplements the
basic propane conversion kit.
•POWER EXHAUST - Our single input economizer
options are available with power exhaust. Whenever the
outdoor air intake dampers are opened for free cooling,
the exhaust fan will be energized to prevent the condi-
tioned space from being over-pressurized during econo-
mizer operation.
The power exhaust option can only be used on bot-
tom duct configurations.
•BAROMETRIC RELIEF DAMPER - This damper acces-
sory can be used to relieve internal building air pressure
on units with an economizer without power exhaust. This
accessory includes a rain hood, a bird screen and a fully
assembled damper. With bottom duct connections, the
damper should be mounted over the opening in the
return air panel. With horizontal ductwork, the accessory
should be mounted on the return air duct.
•ENTHALPY ACCESSORY CONTROL KIT - This kit
contains the required components to convert a single
enthalpy economizer to dual enthalpy.
•BURGLAR BARS - Mount in the supply and return
openings to prevent entry into the duct work.
•FLUE EXHAUST EXTENSION KIT - In locations with
wind or weather conditions which may interfere with
proper exhausting of furnace combustion products, this
kit can be installed to prevent the flue exhaust from
entering nearby fresh air intakes.
•CO2SENSOR - Senses CO2levels and automatically
overrides the economizer when levels rise above the
present limits.
•COIL GUARD - Customers can purchase a coil guard kit
to protect the condenser coil from damage. This is not a
hail guard kit.
•PHASE MONITORS - Designed to prevent unit damage.
The phase monitor will shut the unit down in an out-of-
phase condition.

637367-XTG-B-1110
Johnson Controls Unitary Products 9
TABLE 1: SOUND POWER RATING1
1. These values have been accessed using a model of sound propagation from a point source into the hemispheric\free field. The
dBA values provided are to be used for reference only. Calculation of dBA values cover matters of system design and the fan
manufacture has no way of knowing the details of each system. This constitutes and expectation to any specification or guaran-
tee requiring a dBA value or sound data in any other form than sound power level ratings.
UNIT
SIZE CFM ESP BLOWER SOUND POWER (db 10-12 Watts)
Octave Band Centerline Frequency (Hz) SWL
dB(A)
dB(A)
@
10Ft.2
2. At a distance of 10 feet from the blower.
IWG SPEED KW 63 125 250 500 1,000 2,000 4,000 8,000
036 1,200 0.6 LOW 0.60 84 84 74 67 69 62 57 52 74 41
048 1,600 0.55 HIGH 0.80 85 85 75 68 70 63 58 53 75 42
060 2,000 0.45 HIGH 1.00 86 86 76 69 71 64 59 54 76 43
076 2,2000.3HIGH1.3587877770726560557744
TABLE 2: CAPACITY RATINGS - (ARI 210/240)
UNIT SIZE Cooling Capacity (80/67-95ºF)/(27/19-35ºC)
Mbh/kW
Total Input
kW COP1
1. COP = Coefficient of Performance - total output kW divided by the total input kW.
EER2
2. EER = Energy Efficiency Ratio - total output Mbh divided by the total input kW.
ELECTRIC HEAT3
NOMINAL CAPACITY
kW
3. Heaters available as factory-installed options or field-installed accessories - all with single point power supply.
036 35.5 / 10.4 4.0 2.6 9.0 5.1, 7.5, 10.2, 14.6
048 45.1 / 13.2 5.1 2.6 8.9 5.1, 7.5, 10.2, 14.6
060 61.1 / 17.9 6.9 2.6 8.9 5.1, 7.5, 10.2, 14.6, 21.5
076 69.6 / 20.4 8.7 2.4 8.1 5.1, 7.5, 10.2, 14.6, 21.5
TABLE 3: GAS HEAT RATINGS
GAS HEAT
OPTION INPUT CAPACITY kW/{MBH} OUTPUT CAPACITY kW{MBH} AVAILABLE ON MODELS GAS RATE1
M3/S{Ft3/Hr}
1. Based on 1075 Btu/Ft3.
TEMPERTURE RISE °C{°F} AT FULL INPUT2
2. The air flow must be adjusted to obtain a temperature rise within the range shown.
NOTE: Gas Heaters are shipped available for natural gas, but can be coverted to L.P. with Kit Model No. 1NP0434. All furnaces meet
the latest California seasonal efficiency requirements.
MIN. MAX
N04 15{50} 12{40} 3 TON 0.02{47} 8{15} 25{45}
N06 22{75} 18{60} 4 TON 0.03{70} 14{25} 21{70}
N08 29{100} 23{79} 5/6 TON 0.04{93} 14{25} 31{55}

637367-XTG-B-1110
10 Johnson Controls Unitary Products
TABLE 4: DC036 COOLING CAPACITIES (3 TON)
M3/S
Air On
Evap. Temperature of Air on Condenser Coil
35°C 41°C 46°C 52°C
M3/S WB
(°C)
Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C)
31 28 25 22 31 28 25 22 31 28 25 22 31 28 25 22
0.70
23 12.1 3.6 9.0 6.1 3.4 - 10.7 3.9 8.2 5.7 3.0 - 9.3 4.1 7.5 5.2 2.7 - 7.7 4.2 6.5 4.3 2.3 -
20 11.4 3.5 11.4 8.7 5.9 3.2 10.2 3.8 10.1 8.1 5.3 2.8 8.9 4.0 8.9 7.4 4.7 2.4 7.2 4.1 7.2 6.3 4.1 2.0
17 11.4 3.5 11.4 10.6 8.4 5.6 10.2 3.8 10.1 9.1 7.6 5.0 8.9 4.0 8.9 8.5 6.9 4.4 7.2 4.1 7.2 7.0 6.0 3.8
14 11.4 3.5 11.4 10.6 9.8 8.1 10.2 3.8 10.1 9.1 8.7 7.4 8.8 4.0 8.8 8.5 7.6 6.6 7.2 4.1 7.2 6.9 6.4 5.8
0.55
23 11.7 3.5 7.8 5.4 3.3 - 10.5 3.8 7.1 5.0 2.9 - 9.0 3.9 6.4 4.5 2.5 - 7.4 4.0 5.6 3.8 2.2 -
20 10.9 3.4 10.0 7.6 5.3 3.1 9.7 3.6 9.2 7.0 4.7 2.7 8.5 3.8 8.4 6.5 4.2 2.3 7.1 3.9 6.9 5.4 3.7 1.9
17 10.7 3.4 10.7 9.8 8.0 5.1 9.6 3.7 9.5 8.8 7.3 4.6 8.3 3.9 8.3 7.8 6.5 4.0 6.9 4.0 6.9 6.5 5.7 3.5
14 10.7 3.4 10.7 10.0 9.3 7.2 9.6 3.7 9.5 9.0 8.2 6.5 8.3 3.9 8.3 8.0 7.1 5.8 6.9 4.0 6.9 6.6 6.0 5.0
0.45
23 11.2 3.5 6.4 4.7 3.1 - 10.0 3.8 5.8 4.3 2.7 - 8.6 3.9 5.2 3.9 2.4 - 7.1 4.0 4.6 3.2 2.0 -
20 10.3 3.4 8.2 6.4 4.6 3.0 9.2 3.7 7.5 5.9 4.1 2.6 7.9 3.8 6.7 5.4 3.7 2.3 6.5 3.9 5.9 4.5 3.1 1.9
17 9.7 3.3 9.7 8.1 6.3 4.5 8.7 3.5 8.6 7.5 5.6 4.0 7.5 3.6 7.5 6.9 5.0 3.5 6.2 3.8 6.2 5.7 4.4 3.0
14 9.7 3.3 9.7 9.0 8.0 6.1 8.7 3.6 8.6 8.2 7.3 5.6 7.5 3.7 7.5 7.2 6.4 4.9 6.2 3.8 6.2 5.9 5.5 4.2
CFM
Air On
Evap. Temperature of Air on Condenser Coil
95°F 105°F 115°F 125°F
CFM WB
(°F)
Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
86 80 74 68 86 80 74 68 86 80 74 68 86 80 74 68
1500
72 41.1 3.6 30.7 21.0 11.6 - 36.6 3.9 28.0 19.4 10.4 - 31.6 4.1 25.4 17.6 9.1 - 26.3 4.2 22.3 14.7 7.7 -
67 38.9 3.5 38.9 29.8 20.0 10.8 35.0 3.8 34.5 27.6 18.1 9.6 30.2 4.0 30.2 25.3 16.1 8.2 24.6 4.1 24.6 21.4 13.9 6.8
62 38.9 3.5 38.9 36.2 28.8 19.0 34.9 3.8 34.5 31.0 26.0 17.1 30.2 4.0 30.2 29.0 23.5 15.1 24.7 4.1 24.7 23.7 20.5 13.1
57 38.8 3.5 38.8 36.2 33.6 27.7 34.8 3.8 34.4 31.0 29.6 25.2 30.2 4.0 30.2 29.0 25.8 22.6 24.6 4.1 24.6 23.7 21.7 19.7
1200
72 40.1 3.5 26.5 18.5 11.2 - 35.7 3.8 24.1 17.1 9.9 - 30.8 3.9 21.9 15.5 8.7 - 25.2 4.0 19.0 12.9 7.4 -
67 37.2 3.4 34.1 25.8 17.9 10.5 33.2 3.6 31.3 23.9 16.1 9.2 29.1 3.8 28.5 22.0 14.3 8.0 24.1 3.9 23.6 18.5 12.5 6.6
62 36.5 3.4 36.5 33.3 27.2 17.4 32.8 3.7 32.4 30.1 24.8 15.6 28.4 3.9 28.4 26.7 22.2 13.7 23.6 4.0 23.6 22.1 19.3 11.9
57 36.4 3.4 36.4 34.0 31.6 24.4 32.7 3.7 32.3 30.7 27.9 22.3 28.3 3.9 28.3 27.2 24.3 19.9 23.5 4.0 23.5 22.5 20.5 17.1
900
72 38.3 3.5 21.9 16.0 10.6 - 34.1 3.8 19.8 14.7 9.3 - 29.4 3.9 17.8 13.3 8.2 - 24.1 4.0 15.5 11.1 6.8 -
67 35.2 3.4 27.9 21.7 15.8 10.2 31.4 3.7 25.4 20.2 14.1 9.0 27.0 3.8 22.9 18.3 12.5 7.7 22.2 3.9 20.0 15.4 10.7 6.3
62 33.0 3.3 33.0 27.6 21.3 15.3 29.6 3.5 29.2 25.6 19.2 13.7 25.6 3.6 25.6 23.5 17.2 12.0 21.2 3.8 21.2 19.6 14.9 10.2
57 33.0 3.3 33.0 30.8 27.3 20.9 29.6 3.6 29.2 27.9 24.9 19.0 25.6 3.7 25.6 24.7 21.7 16.8 21.2 3.8 21.2 20.2 18.8 14.5
1. These capacities are gross ratings. For net capacity, determine the kW of the supply air blower motor from the SUPPLY AIR
BLOWER PERFORMANCE. Table, multiply this value by 3.415 MBH/kW to determine the motor heat, and deduct this heat from
the gross capacity of the unit.
2. These ratings include the compressor and the condensate fan motors but not the supply air blower motor. The total condenser
fan motor power input is 0.46kW. Refer to the SUPPLY AIR BLOWER PERFORMANCE Table for the kW of the supply air blower
motor.
NOTE: Shaded areas indicate nominal ratings

637367-XTG-B-1110
Johnson Controls Unitary Products 11
TABLE 5: DC048 COOLING CAPACITIES (4 TON)
M3/S
Air On
Evap. Temperature of Air on Condenser Coil
35°C 41°C 46°C 52°C
M3/S WB
(°C)
Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To tal 
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C)
31 28 25 22 31 28 25 22 31 28 25 22 31 28 25 22
0.95
23 15.4 4.5 11.5 7.5 4.0 - 13.7 4.8 10.5 7.0 3.5 - 11.8 5.1 9.6 6.3 3.1 - 9.9 5.2 8.4 5.3 2.6 -
20 14.9 4.4 14.9 11.3 7.2 3.6 13.4 4.7 13.2 10.5 6.6 3.2 11.6 5.0 11.6 9.6 5.8 2.8 9.4 5.1 9.4 8.2 5.0 2.3
17 14.8 4.4 14.8 13.8 11.0 6.9 13.3 4.7 13.2 11.9 10.0 6.2 11.5 5.0 11.5 11.1 9.0 5.5 9.4 5.1 9.4 9.1 7.9 4.8
14 14.8 4.4 14.8 13.8 12.8 10.7 13.3 4.7 13.2 11.9 11.3 9.7 11.5 5.0 11.5 11.1 9.8 8.7 9.4 5.1 9.4 9.0 8.3 7.6
0.75
23 15.0 4.4 9.9 6.7 3.8 - 13.4 4.7 9.0 6.2 3.3 - 11.5 4.9 8.2 5.6 2.9 - 9.4 5.1 7.1 4.7 2.5 -
20 13.9 4.3 13.2 9.8 6.5 3.5 12.4 4.6 12.1 9.0 5.9 3.1 10.9 4.9 11.0 8.3 5.2 2.7 9.0 5.0 9.1 7.0 4.6 2.2
17 14.0 4.3 14.0 13.0 9.6 6.3 12.6 4.6 12.4 11.8 8.7 5.6 10.9 4.9 10.9 10.5 7.8 5.0 9.0 5.0 9.0 8.7 6.8 4.3
14 14.0 4.3 14.0 13.0 12.1 9.4 12.5 4.6 12.4 11.8 10.7 8.5 10.9 4.9 10.9 10.4 9.3 7.6 9.0 5.0 9.0 8.6 7.9 6.6
0.55
23 14.4 4.3 8.2 5.8 3.6 - 12.8 4.6 7.4 5.3 3.1 - 11.1 4.8 6.6 4.8 2.7 - 9.1 4.9 5.8 4.0 2.3 -
20 13.2 4.2 10.7 8.2 5.7 3.4 11.8 4.5 9.8 7.6 5.1 3.0 10.2 4.7 8.8 6.9 4.5 2.6 8.4 4.9 7.7 5.8 3.8 2.1
17 12.7 4.2 12.7 10.7 8.1 5.5 11.4 4.4 11.3 9.9 7.3 5.0 9.9 4.6 9.9 9.1 6.5 4.4 8.2 4.8 8.2 7.6 5.6 3.7
14 12.7 4.2 12.7 11.9 10.6 7.9 11.4 4.5 11.3 10.7 9.6 7.2 9.9 4.7 9.9 9.5 8.4 6.4 8.2 4.9 8.2 7.8 7.3 5.5
CFM
Air On
Evap. Temperature of Air on Condenser Coil
95°F 105°F 115°F 125°F
CFM WB
(°F)
Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
86 80 74 68 86 80 74 68 86 80 74 68 86 80 74 68
2000
72 52.5 4.5 39.4 25.7 13.6 - 46.7 4.8 36.0 23.8 12.1 - 40.4 5.1 32.7 21.6 10.6 - 33.6 5.2 28.6 18.0 9.0 -
67 50.7 4.4 50.7 38.7 24.7 12.4 45.6 4.7 45.0 35.9 22.3 11.0 39.4 5.0 39.4 32.8 19.9 9.5 32.1 5.1 32.1 27.9 17.2 7.9
62 50.6 4.4 50.6 47.2 37.6 23.7 45.4 4.7 44.9 40.5 34.0 21.3 39.4 5.0 39.4 37.9 30.7 18.8 32.1 5.1 32.1 31.0 26.8 16.3
57 50.6 4.4 50.6 47.1 43.7 36.4 45.4 4.7 44.9 40.4 38.6 33.1 39.3 5.0 39.3 37.8 33.6 29.6 32.1 5.1 32.1 30.9 28.3 25.8
1600
72 51.2 4.4 33.9 23.0 12.8 - 45.6 4.7 30.8 21.2 11.4 - 39.4 4.9 28.0 19.2 9.9 - 32.2 5.1 24.3 16.1 8.4 -
67 47.5 4.3 45.0 33.3 22.3 12.0 42.3 4.6 41.3 30.8 20.1 10.6 37.1 4.9 37.6 28.4 17.8 9.2 30.7 5.0 31.1 23.9 15.5 7.6
62 47.7 4.3 47.7 44.5 32.7 21.4 42.9 4.6 42.4 40.3 29.8 19.2 37.1 4.9 37.1 35.7 26.7 16.9 30.9 5.0 30.9 29.5 23.3 14.6
57 47.6 4.3 47.6 44.4 41.3 31.9 42.8 4.6 42.3 40.1 36.5 29.2 37.0 4.9 37.0 35.6 31.7 25.9 30.8 5.0 30.8 29.4 26.8 22.3
1200
72 49.2 4.3 27.9 19.7 12.1 - 43.8 4.6 25.2 18.1 10.7 - 37.7 4.8 22.6 16.4 9.4 - 31.0 4.9 19.8 13.6 7.8 -
67 45.2 4.2 36.7 27.8 19.3 11.7 40.3 4.5 33.4 25.9 17.2 10.3 34.6 4.7 30.0 23.5 15.3 8.9 28.6 4.9 26.2 19.7 13.1 7.3
62 43.4 4.2 43.4 36.6 27.5 18.9 38.9 4.4 38.4 33.8 24.8 16.9 33.7 4.6 33.7 31.0 22.2 14.9 27.9 4.8 27.9 25.9 19.3 12.6
57 43.4 4.2 43.4 40.5 36.1 27.0 38.9 4.5 38.4 36.7 32.9 24.5 33.7 4.7 33.7 32.5 28.7 21.7 27.9 4.9 27.9 26.5 24.9 18.7
1. These capacities are gross ratings. For net capacity, determine the kW of the supply air blower motor from the SUPPLY AIR
BLOWER PERFORMANCE. Table, multiply this value by 3.415 MBH/kW to determine the motor heat, and deduct this heat from
the gross capacity of the unit.
2. These ratings include the compressor and the condensate fan motors but not the supply air blower motor. The total condenser
fan motor power input is 0.46kW. Refer to the SUPPLY AIR BLOWER PERFORMANCE Table for the kW of the supply air blower
motor.
NOTE: Shaded areas indicate nominal ratings

637367-XTG-B-1110
12 Johnson Controls Unitary Products
TABLE 6: DC060 COOLING CAPACITIES (5 TON)
M3/S
Air On
Evap. Temperature of Air on Condenser Coil
35°C 41°C 46°C 52°C
M3/S WB
(°C)
Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To ta l 
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot. 
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C)
31 28 25 22 31 28 25 22 31 28 25 22 31 28 25 22
1.15
23 20.7 6.1 15.2 10.5 5.8 - 18.4 6.4 13.9 9.7 5.1 - 15.9 6.8 12.6 8.8 4.5 - 13.2 7.0 11.1 7.4 3.8 -
20 19.8 6.0 19.8 15.1 9.9 5.3 17.8 6.3 17.6 14.0 8.9 4.7 15.4 6.7 15.4 12.8 7.9 4.1 12.6 6.9 12.6 10.9 6.9 3.4
17 19.8 6.0 19.8 18.8 14.4 9.5 17.8 6.3 17.6 16.1 13.0 8.5 15.4 6.7 15.4 15.1 11.8 7.5 12.6 6.9 12.6 12.3 10.3 6.5
14 19.8 6.0 19.8 18.8 17.1 13.9 17.7 6.3 17.5 16.1 15.1 12.6 15.4 6.7 15.4 15.1 13.2 11.3 12.5 6.9 12.5 12.3 11.1 9.9
0.95
23 20.2 6.1 13.5 9.6 5.5 - 18.0 6.4 12.3 8.9 4.9 - 15.5 6.7 11.2 8.1 4.3 - 12.7 6.9 9.7 6.7 3.6 -
20 18.8 5.9 17.6 13.5 9.2 5.2 16.7 6.2 16.1 12.5 8.2 4.6 14.7 6.6 14.7 11.5 7.3 4.0 12.1 6.8 12.1 9.7 6.4 3.3
17 18.8 5.9 18.8 17.9 12.9 8.8 16.9 6.2 16.7 16.2 11.8 7.9 14.7 6.6 14.7 14.4 10.5 7.0 12.2 6.8 12.2 11.9 9.2 6.0
14 18.8 5.9 18.8 17.9 16.3 12.5 16.9 6.2 16.7 16.2 14.4 11.5 14.6 6.6 14.6 14.4 12.5 10.2 12.2 6.8 12.2 11.9 10.6 8.8
0.75
23 19.6 6.0 11.9 8.6 5.3 - 17.5 6.3 10.7 8.0 4.7 - 15.0 6.6 9.6 7.2 4.1 - 12.3 6.8 8.4 6.0 3.4 -
20 18.1 5.8 15.2 11.8 8.3 5.1 16.1 6.1 13.8 11.0 7.4 4.5 13.9 6.4 12.4 10.0 6.6 3.8 11.4 6.6 10.9 8.4 5.6 3.1
17 17.6 5.8 17.6 15.3 11.5 8.1 15.8 6.0 15.6 14.2 10.3 7.2 13.6 6.3 13.6 13.0 9.3 6.3 11.3 6.5 11.3 10.9 8.0 5.4
14 17.5 5.7 17.5 16.7 14.8 11.1 15.7 6.0 15.5 15.1 13.5 10.1 13.6 6.3 13.6 13.4 11.8 9.0 11.3 6.5 11.3 10.9 10.2 7.7
CFM
Air On
Evap. Temperature of Air on Condenser Coil
95°F 105°F 115°F 125°F
CFM WB
(°F)
Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity To ta l 
Cap.1
(MBH)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH)
Tot. 
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
86 80 74 68 86 80 74 68 86 80 74 68 86 80 74 68
2400
72 70.5 6.1 52.0 35.8 19.7 - 62.8 6.4 47.5 33.2 17.5 - 54.2 6.8 43.1 30.1 15.4 - 45.2 7.0 37.7 25.1 13.0 -
67 67.7 6.0 67.7 51.6 33.7 18.1 60.8 6.3 60.1 47.9 30.5 16.1 52.6 6.7 52.6 43.8 27.1 13.9 42.8 6.9 42.8 37.1 23.4 11.5
62 67.6 6.0 67.6 64.2 49.2 32.3 60.6 6.3 59.9 55.1 44.5 29.1 52.5 6.7 52.5 51.5 40.1 25.7 42.9 6.9 42.9 42.1 35.1 22.2
57 67.5 6.0 67.5 64.2 58.5 47.4 60.5 6.3 59.8 55.1 51.5 43.1 52.4 6.7 52.4 51.4 44.9 38.6 42.8 6.9 42.8 42.0 37.9 33.6
2000
72 68.9 6.1 46.1 32.9 18.9 - 61.4 6.4 41.9 30.4 16.7 - 52.9 6.7 38.0 27.5 14.6 - 43.3 6.9 33.0 23.0 12.4 -
67 64.1 5.9 59.9 46.0 31.3 17.7 57.1 6.2 55.0 42.6 28.1 15.6 50.1 6.6 50.1 39.2 25.0 13.5 41.4 6.8 41.4 33.0 21.8 11.1
62 64.3 5.9 64.3 61.2 44.0 30.1 57.8 6.2 57.1 55.4 40.2 27.0 50.0 6.6 50.0 49.1 36.0 23.8 41.6 6.8 41.6 40.5 31.4 20.5
57 64.2 5.9 64.2 61.1 55.7 42.8 57.7 6.2 57.0 55.2 49.2 39.1 49.9 6.6 49.9 49.0 42.8 34.8 41.5 6.8 41.5 40.5 36.1 30.0
1600
72 66.9 6.0 40.6 29.5 18.0 - 59.6 6.3 36.6 27.1 15.9 - 51.3 6.6 32.9 24.5 13.9 - 42.1 6.8 28.7 20.4 11.6 -
67 61.7 5.8 51.9 40.4 28.3 17.3 55.0 6.1 47.2 37.6 25.3 15.2 47.3 6.4 42.4 34.0 22.5 13.1 38.9 6.6 37.1 28.6 19.2 10.7
62 59.9 5.8 59.9 52.2 39.1 27.5 53.8 6.0 53.1 48.3 35.3 24.6 46.6 6.3 46.6 44.3 31.6 21.6 38.6 6.5 38.6 37.0 27.4 18.4
57 59.8 5.7 59.8 57.0 50.4 38.0 53.7 6.0 53.0 51.5 46.0 34.6 46.5 6.3 46.5 45.7 40.1 30.6 38.5 6.5 38.5 37.3 34.8 26.4
1. These capacities are gross ratings. For net capacity, determine the kW of the supply air blower motor from the SUPPLY AIR
BLOWER PERFORMANCE. Table, multiply this value by 3.415 MBH/kW to determine the motor heat, and deduct this heat from
the gross capacity of the unit.
2. These ratings include the compressor and the condensate fan motors but not the supply air blower motor. The total condenser fan
motor power input is 0.46kW. Refer to the SUPPLY AIR BLOWER PERFORMANCE Table for the kW of the supply air blower
motor.
NOTE: Shaded areas indicate nominal ratings

637367-XTG-B-1110
Johnson Controls Unitary Products 13
TABLE 7: DC076 COOLING CAPACITIES (6.3 TON)
M3/S
Air On
Evap. Temperature of Air on Condenser Coil
35°C 41°C 46°C 52°C
M3/S WB
(°C)
Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To t al 
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(kW)
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C) Return Dry Bulb (°C)
31 28 25 22 31 28 25 22 31 28 25 22 31 28 25 22
1.40
23 23.9 7.7 18.7 13.6 8.9 - 21.2 8.2 17.0 12.6 7.9 - 18.3 8.6 15.5 11.5 6.9 - 15.3 8.9 13.5 9.6 5.9 -
20 23.2 7.6 23.2 17.9 13.0 8.1 20.9 8.1 20.6 16.6 11.7 7.2 18.1 8.5 18.1 15.1 10.4 6.2 14.7 8.8 14.7 12.9 9.0 5.1
17 23.2 7.6 23.2 21.7 17.2 12.4 20.8 8.1 20.6 18.6 15.5 11.1 18.0 8.5 18.0 17.4 14.0 9.8 14.7 8.8 14.7 14.2 12.2 8.5
14 23.2 7.6 23.2 21.6 20.1 16.5 20.8 8.1 20.5 18.6 17.7 15.0 18.0 8.5 18.0 17.3 15.4 13.4 14.7 8.8 14.7 14.2 13.0 11.7
1.15
23 23.2 7.6 16.7 12.7 8.4 - 20.7 8.1 15.2 11.7 7.5 - 17.9 8.4 13.8 10.6 6.6 - 14.6 8.6 12.0 8.9 5.6 -
20 21.6 7.3 20.2 16.2 12.1 7.9 19.2 7.8 18.6 15.0 10.9 6.9 16.9 8.2 16.9 13.8 9.7 6.0 14.0 8.5 14.0 11.6 8.4 5.0
17 21.9 7.4 21.9 20.4 15.6 11.5 19.7 7.9 19.4 18.5 14.2 10.3 17.0 8.3 17.0 16.4 12.7 9.1 14.2 8.6 14.2 13.6 11.1 7.8
14 21.8 7.4 21.8 20.4 19.0 15.0 19.6 7.9 19.4 18.4 16.8 13.7 17.0 8.3 17.0 16.4 14.6 12.2 14.1 8.6 14.1 13.5 12.3 10.5
0.85
23 22.2 7.5 14.6 11.5 8.0 - 19.8 8.0 13.2 10.6 7.1 - 17.1 8.3 11.8 9.5 6.2 - 14.0 8.5 10.3 7.9 5.2 -
20 20.5 7.2 17.3 14.2 11.0 7.6 18.3 7.7 15.8 13.2 9.8 6.7 15.7 8.0 14.2 12.0 8.7 5.8 12.9 8.3 12.4 10.1 7.4 4.7
17 20.0 7.2 20.0 16.9 13.8 10.5 17.9 7.5 17.7 15.7 12.4 9.4 15.5 7.9 15.5 14.4 11.1 8.3 12.9 8.1 12.9 12.0 9.6 7.0
14 19.9 7.1 19.9 18.7 16.4 13.2 17.9 7.6 17.7 16.9 14.9 12.0 15.5 7.9 15.5 15.0 13.0 10.7 12.8 8.2 12.8 12.2 11.3 9.2
CFM
Air On
Evap. Temperature of Air on Condenser Coil
95°F 105°F 115°F 125°F
CFM WB
(°F)
Total
Cap.1
(MBH
Tot.
Input2
(kW)
Sensible Capacity To t al 
Cap.1
(MBH
Tot.
Input2
(kW)
Sensible Capacity To tal
Cap.1
(MBH
Tot.
Input2
(kW)
Sensible Capacity Total
Cap.1
(MBH
Tot.
Input2
(kW)
Sensible Capacity
Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
86 80 74 68 86 80 74 68 86 80 74 68 86 80 74 68
3000
72 81.4 7.7 63.6 46.5 30.3 - 72.5 8.2 58.1 43.1 26.9 - 62.6 8.6 52.8 39.1 23.7 - 52.1 8.9 46.2 32.6 20.0 -
67 79.2 7.6 79.2 60.9 44.2 27.6 71.2 8.1 70.4 56.5 40.0 24.5 61.6 8.5 61.6 51.7 35.6 21.1 50.1 8.8 50.1 43.9 30.7 17.5
62 79.2 7.6 79.2 73.9 58.6 42.2 71.0 8.1 70.2 63.4 53.0 38.0 61.5 8.5 61.5 59.3 47.7 33.5 50.2 8.8 50.2 48.5 41.7 29.0
57 79.1 7.6 79.1 73.8 68.6 56.3 70.9 8.1 70.1 63.3 60.4 51.1 61.4 8.5 61.4 59.2 52.7 45.8 50.1 8.8 50.1 48.3 44.4 39.9
2400
72 79.2 7.6 57.1 43.3 28.8 - 70.6 8.1 52.0 39.9 25.6 - 60.9 8.4 47.2 36.1 22.4 - 49.8 8.6 41.0 30.2 19.0 -
67 73.7 7.3 69.1 55.2 41.4 26.9 65.7 7.8 63.4 51.1 37.2 23.7 57.6 8.2 57.7 47.1 33.0 20.5 47.6 8.5 47.7 39.6 28.8 16.9
62 74.7 7.4 74.7 69.7 53.1 39.2 67.1 7.9 66.3 63.1 48.4 35.2 58.1 8.3 58.1 55.9 43.4 31.0 48.3 8.6 48.3 46.2 37.8 26.8
57 74.5 7.4 74.5 69.6 64.9 51.1 66.9 7.9 66.1 62.9 57.3 46.7 57.9 8.3 57.9 55.9 49.8 41.5 48.1 8.6 48.1 46.2 42.1 35.8
1800
72 75.9 7.5 49.8 39.2 27.4 - 67.6 8.0 44.9 36.1 24.1 - 58.2 8.3 40.3 32.5 21.1 - 47.8 8.5 35.2 27.1 17.7 -
67 69.8 7.2 59.1 48.5 37.5 26.0 62.3 7.7 53.8 45.2 33.5 22.9 53.5 8.0 48.3 40.9 29.8 19.6 44.1 8.3 42.2 34.4 25.4 16.1
62 68.2 7.2 68.2 57.8 46.9 36.0 61.2 7.5 60.5 53.5 42.3 32.2 53.0 7.9 53.0 49.1 37.9 28.3 43.9 8.1 43.9 41.0 32.8 24.0
57 68.0 7.1 68.0 63.7 55.9 45.2 61.0 7.6 60.3 57.6 50.9 41.1 52.8 7.9 52.8 51.1 44.4 36.4 43.7 8.2 43.7 41.7 38.6 31.4
1. These capacities are gross ratings. For net capacity, determine the kW of the supply air blower motor from the SUPPLY AIR
BLOWER PERFORMANCE. Table, multiply this value by 3.415 MBH/kW to determine the motor heat, and deduct this heat from
the gross capacity of the unit.
2. These ratings include the compressor and the condensate fan motors but not the supply air blower motor. The total condenser
fan motor power input is 0.46kW. Refer to the SUPPLY AIR BLOWER PERFORMANCE Table for the kW of the supply air blower
motor.
NOTE: Shaded areas indicate nominal ratings

637367-XTG-B-1110
14 Johnson Controls Unitary Products
TABLE 8: SUPPLY AIR BLOWER PERFORMANCE (3 & 4 TON DIRECT DRIVE) - SIDE DUCT APPLICATION
M3/S WATTS M3/S WATTS M3/S WATTS M3/S WATTS M3/S WATTS
HI ----0.80 825 0.78 785 0.74 755
MED 0.79 800 0.77 780 0.75 750 0.72 720 0.67 690
LOW 0.70 710 0.69 690 0.67 670 0.64 650 0.62 620
HI 0.94 960 0.91 936 0.88 910 0.85 880 0.81 845
MED 0.85 838 0.83 810 0.80 785 0.78 765 0.75 735
LOW 0.79 760 0.77 738 0.76 715 0.73 695 0.70 670
M3/S WATTS M3/S WATTS M3/S WATTS M3/S WATTS
HI 0.67 725 0.64 700 0.60 680 0.56 655
MED 0.62 650 0.59 630 0.59 610 0.52 590
LOW 0.59 605 0.56 590 0.55 570 0.48 545
HI 0.77 820 0.73 790 0.67 765 0.61 740
MED 0.71 705 0.66 675 0.61 645 0.56 625
LOW 0.67 645 0.63 620 0.58 595 0.53 575
CFM WATTS CFM WATTS CFM WATTS CFM WATTS CFM WATTS
HI ----1699 825 1650 785 1570 755
MED 1684 800 1631 780 1582 750 1524 720 1410 690
LOW 1487 710 1464 690 1421 670 1367 650 1315 620
HI 1996 960 1933 936 1868 910 1795 880 1722 845
MED 1804 838 1765 810 1714 785 1650 765 1589 735
LOW 1681 760 1640 738 1604 715 1541 695 1490 670
CFM WATTS CFM WATTS CFM WATTS CFM WATTS
HI 1430 725 1360 700 1280 680 1180 655
MED 1324 650 1260 630 1185 610 1100 590
LOW 1246 605 1185 590 1110 570 1020 545
HI 1635 820 1544 790 1419 765 1300 740
MED 1508 705 1407 675 1306 645 1195 625
LOW 1416 645 1337 620 1230 595 1120 575
31
41
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
M3/S
14950 74 99 124
UNIT
TONNAGE MOTOR SPEED
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
223198 248
31
41
174
UNIT
TONNAGE MOTOR SPEED
CFM
UNIT
TONNAGE MOTOR SPEED
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.20 0.30 0.40 0.50 0.60
31
41
UNIT
TONNAGE MOTOR SPEED
31
41
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.70 0.80 0.90 1.00
1. Side Duct application (380/415 Volts)
* . Includes allowances for a wet evaporator coil, 25mm [1 in] filters, and the heat exchangers. Refer to STATIC RESISTANCES Table for resistance
values on applications other than gas/electric units with side duct airflows.

637367-XTG-B-1110
Johnson Controls Unitary Products 15
TABLE 9: SUPPLY AIR BLOWER PERFORMANCE (5 TON BELT DRIVE) - SIDE DUCT APPLICATION
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
1.18 1059 1560 1077 1590 1095 1630 1114 1650 1134 1660 1158 1685 - -
1.13 1032 1405 1054 1470 1074 1525 1094 1560 1116 1595 1140 1620 1167 1640
1.08 1005 1260 1024 1275 1049 1370 1069 1440 1090 1475 1116 1505 1142 1535
1.04 980 1160 1002 1170 1022 1190 1044 1250 1066 1350 1090 1410 1117 1440
0.99 930 1060 957 1070 983 1080 1010 1100 1039 1160 1064 1260 1092 1340
0.94 877 950 908 975 941 1000 976 1020 1009 1050 1040 1100 1070 1225
0.90 ----8948859409409809801014 1020 1047 1095
0.85 ----8558159038609509059889401022 970
0.80 ------8848159258509648801001 910
0.75 ------864770908805948835987870
0.71 --------882740926780965830
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
1.18 --------------
1.13 --------------
1.08 1170 1580 ------------
1.04 1148 1480 1180 1530 ----------
0.99 1121 1385 1155 1425 ----------
0.94 1100 1285 1133 1340 1169 1385 --------
0.90 1079 1180 1110 1240 1143 1280 1178 1330 ------
0.85 1058 1060 1090 1135 1122 1190 1158 1240 ------
0.80 1035 960 1071 1030 1103 1100 1134 1140 1164 1175 ----
0.75 1020 900 1056 965 1088 1035 1118 1065 1145 1105 1170 1130 - -
0.71 1004 860 1038 880 1070 925 1101 980 1130 1045 1158 1075 - -
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
2500 1059 1560 1077 1590 1095 1630 1114 1650 1134 1660 1158 1685 - -
2400 1032 1405 1054 1470 1074 1525 1094 1560 1116 1595 1140 1620 1167 1640
2300 1005 1260 1024 1275 1049 1370 1069 1440 1090 1475 1116 1505 1142 1535
2200 980 1160 1002 1170 1022 1190 1044 1250 1066 1350 1090 1410 1117 1440
2100 930 1060 957 1070 983 1080 1010 1100 1039 1160 1064 1260 1092 1340
2000 877 950 908 975 941 1000 976 1020 1009 1050 1040 1100 1070 1225
1900 ----8948859409409809801014 1020 1047 1095
1800 ----8558159038609509059889401022 970
1700 ------8848159258509648801001 910
1600 ------864770908805948835987870
1500 --------882740926780965830
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
2500 --------------
2400 --------------
2300 1170 1580 ------------
2200 1148 1480 1180 1530 ----------
2100 1121 1385 1155 1425 ----------
2000 1100 1285 1133 1340 1169 1385 --------
1900 1079 1180 1110 1240 1143 1280 1178 1330 ------
1800 1058 1060 1090 1135 1122 1190 1158 1240 ------
1700 1035 960 1071 1030 1103 1100 1134 1140 1164 1175 ----
1600 1020 900 1056 965 1088 1035 1118 1065 1145 1105 1170 1130 - -
1500 1004 860 1038 880 1070 925 1101 980 1130 1045 1158 1075 - -
1.50
51
M3/S
CFM
51
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.90 1.00 1.10 1.20 1.30 1.40
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.20 0.30 0.40 0.50 0.60 0.70 0.80
51
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
223 248 273 298 322 347 372
UNIT
TONNAGE
AIR
FLOW
M3/S
51
UNIT
TONNAGE
AIR
FLOW
M3/S
149 174 198
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
50 74 99 124
1. Side duct application (380/415 Volts)
* . Includes allowances for a wet evaporator coil, 25mm [1in] filters, and the heat exchangers. Refer to STATIC RESISTANCE Table for
resistance values on applications other than gas / electric units with side duct airflows.

637367-XTG-B-1110
16 Johnson Controls Unitary Products
TABLE 10: SUPPLY AIR BLOWER PERFORMANCE (6.3 TON BELT DRIVE) - SIDE DUCT APPLICATION
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
1.50 1150 2325 1182 2425 ----------
1.42 1100 2010 1129 2090 1157 2150 1185 2225 ------
1.32 1045 1700 1074 1780 1102 1850 1131 1940 1160 2025 1190 2075 - -
1.23 985 1425 1015 1475 1045 1540 1075 1630 1103 1715 1135 1760 1163 1825
1.13 930 1240 958 1300 990 1350 1020 1400 1051 1430 1081 1490 1111 1600
1.04 - - 905 1070 933 1160 965 1210 997 1250 1028 1285 1060 1325
0.94 ------9191025 950 1100 982 1130 1014 1160
0.85 --------9099259391005 968 1030
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
1.50 --------------
1.42 --------------
1.32 --------------
1.23 1193 1920 ------------
1.13 1142 1675 1173 1730 ----------
1.04 1090 1380 1124 1450 1155 1550 1186 1640 ------
0.94 1045 1175 1077 1200 1109 1275 1140 1360 1170 1460 ----
0.85 998 1050 1028 1060 1058 1060 1087 1075 1118 1150 1148 1250 1176 1360
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
3200 1150 2325 1182 2425 ----------
3000 1100 2010 1129 2090 1157 2150 1185 2225 ------
2800 1045 1700 1074 1780 1102 1850 1131 1940 1160 2025 1190 2075 - -
2600 985 1425 1015 1475 1045 1540 1075 1630 1103 1715 1135 1760 1163 1825
2400 930 1240 958 1300 990 1350 1020 1400 1051 1430 1081 1490 1111 1600
2200 - - 905 1070 933 1160 965 1210 997 1250 1028 1285 1060 1325
2000 ------9191025 950 1100 982 1130 1014 1160
1800 --------9099259391005 968 1030
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
3200 --------------
3000 --------------
2800 --------------
2600 1193 1920 ------------
2400 1142 1675 1173 1730 ----------
2200 1090 1380 1124 1450 1155 1550 1186 1640 ------
2000 1045 1175 1077 1200 1109 1275 1140 1360 1170 1460 ----
1800 998 1050 1028 1060 1058 1060 1087 1075 1118 1150 1148 1250 1176 1360
1.50
6.31
M3/S
CFM
6.31
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.90 1.00 1.10 1.20 1.30 1.40
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.20 0.30 0.40 0.50 0.60 0.70 0.80
6.31
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
223 248 273 298 322 347 372
UNIT
TONNAGE
AIR
FLOW
M3/S
6.31
UNIT
TONNAGE
AIR
FLOW
M3/S
149 174 198
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
50 74 99 124
1. Side duct application (380/415 Volts)
* . Includes allowances for a wet evaporator coil, 25mm [1in] filters, and the heat exchangers. Refer to STATIC RESISTANCE Table for
resistance values on applications other than gas / electric units with side duct airflows.

637367-XTG-B-1110
Johnson Controls Unitary Products 17
TABLE 11: BELT DRIVE MOTOR AND DRIVE DATA
TABLE 12: STATIC RESISTANCES
TABLE 13: ELECTRIC HEATER SUPPLY AIR LIMITATIONS
mm inch mm inch mm inch mm inch mm inch
5 TON 812-1102 1.5 1450 56 1.0 IVL44 69-97 2.8-3.8 22 7/8 127 5.0 25 1 922 36.3 A35
6 TON 948-1227 1.5 1450 56 1.0 IVM50 86-112 3.4-4.4 22 7/8 132 5.2 25 1 947 37.3 A36
DESIG-
NATION
BELTFIXED BLOWER PULLY
BORE PITCH DIA. BORE PITCH
LENGTH
MODEL
BLOWER
RANGE
(RPM)
MOTOR1ADJUSTABLE MOTOR PULLY
HP RPM FRAME
SIZE
SERVICE
FACTOR
DESIG-
NATION
PITCH DIA.
1. All motors have solid bases and are inherently protected. These motors can be selected to operate into their service factor because
they are located in the moving air, upstream of any heating device.
0.47 0.57 0.66 0.75 0.85 0.94 1.03 1.13 1.23 1.32 1.42
17.4 19.8 22.3 27.3 32.2 37.2 42.2 49.6 57.0 64.5 74.4
7-15KW 10.0 12.4 14.9 17.4 19.8 24.8 29.8 34.7 39.7 47.1 54.6
20-30KW 14.9 17.4 19.8 22.3 27.3 32.2 37.2 42.2 49.6 57.0 64.5
14.9 17.4 19.8 22.3 24.8 27.3 29.8 34.7 39.7 47.1 54.6
19.8 25.0 29.8 34.7 39.7 44.6 49.6 57.0 64.5 71.9 79.4
1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000
0.07 0.08 0.09 0.11 0.13 0.15 0.17 0.20 0.23 0.26 0.30
7-15KW 0.04 0.05 0.06 0.07 0.08 0.10 0.12 0.14 0.16 0.19 0.22
20-30KW 0.06 0.07 0.08 0.09 0.11 0.13 0.15 0.17 0.20 0.23 0.26
0.06 0.07 0.08 0.09 0.10 0.11 0.12 0.14 0.16 0.19 0.22
0.08 0.10 0.12 0.14 0.16 0.18 0.20 0.23 0.26 0.29 0.32
BOTTOM DUCT CONNECTIONS1
ELECTRIC
HEATERS1
RESISTANCE, Pa
M3/S
DESCRIPTION
ECONOMIZER1, 3
RESISTANCE, IWG
CFM
ECONOMIZER1, 3
COOLING ONLY2
ELECTRIC
HEATERS1
BOTTOM DUCT CONNECTIONS1
COOLING ONLY2
DESCRIPTION
1. Deduct these resistance values from the available external static pressure shown in SUPPLY AIR BLOWER PERFORMANCE Tables.
3. The pressure through the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air
duct system is less than 62.0 Pa [0.25 IWG], the unit will deliver less M 3/S or CFM during full economizer operation.
2. Add these resistance values to the available static resistance values on SUPPLY AIR BLOWER PERFORMANCE Tables.
7 10152030
M3/S 0.47 0.57 0.57 0.61 -
CFM 1100 1200 1200 1300 -
M3/S 0.61 0.61 0.61 0.61 -
CFM 1300 1300 1300 1300 -
M3/S 0.75 0.75 0.75 0.75 0.75
CFM 1600 1600 1600 1600 1600
M3/S 0.85 0.85 0.85 0.85 0.85
CFM 1800 1800 1800 1800 1800
380/415-3-50
380/415-3-50
380/415-3-50
380/415-3-50
3
4
5
6
HEATER SIZE NOMINAL KW
MINIMUM
SUPPLY AIR
VOLTAGE
UNIT MODEL SIZE
NOMINAL TONS

637367-XTG-B-1110
18 Johnson Controls Unitary Products
Note 1: HACR Type per NEC.
Note 2: These electric heaters DO NOT include a fuse box. If a fuse box is required to meet a local code, the fuse block accessory 2FB04700546 is available
for field installation.
Note 3: Heaters are suitable for operation on 380/415V-3-50Hz power supply.
TABLE 14: ELECTRICAL DATA: 3 - 6.3 TON
Size
(Tons) Voltage
Compressors OD Fan
Motor
FLA
ID
Blower
Motor
FLA
Electric Heater
Model No.3Heater
KW Heater Amps
Min.
Circuit
Ampacity
(Amp)
Max Fuse /
Brkr1
Size
(Amps)
RLA Each LRA Each
DC036
(3.0)
380-3-50 7.7 67 1.3 2.5 None - - 13.4 20 2CE0451074624.3 6.5 13.4 20
2CE0451104626.3 9.6 15.1 20
415-3-50 7.7 67 1.3 2.5 None - - 13.4 20 2CE0451074625.1 7.1 13.4 20
2CE0451104627.5 10.4 16.2 20
DC048
(4.0)
380-3-50 9.9 79 1.3 4.24 None - - 17.9 25 2CE0451074624.3 6.5 17.9 25
2CE0451104626.3 9.6 17.9 25
415-3-50 9.9 79 1.3 4.24 None - - 17.9 25 2CE0451074625.1 7.1 17.9 25
2CE0451104627.5 10.4 18.3 25
DC060
(5.0)
380-3-50 9.6 79 1.3 2.7
None - - 16 25
2CE0451074624.3 6.5 16 25
2CE0451104626.3 9.6 16 25
2CE0451154628.5 12.9 19.5 25
2CE04512046212.2 18.5 26.5 30
415-3-50 9.6 79 1.3 2.7
None - - 16 25
2CE0451074625.1 7.1 16 25
2CE0451104627.5 10.4 16.4 25
2CE04511546210.2 14.2 21.1 25
2CE04512046214.6 20.3 28.8 30
DC076
(6.3)
380-3-50 16.7 90 1.3 2.7
None - - 41.6 50
2CE0451074624.3 6.5 41.6 50
2CE0451104626.3 9.6 41.6 50
2CE0451154628.5 12.9 41.6 50
2CE04512046212.2 18.5 41.6 50
415-3-50 16.7 90 1.3 2.7
None - - 41.6 50
2CE0451074625.1 7.1 41.6 50
2CE0451104627.5 10.4 41.6 50
2CE04511546210.2 14.2 41.6 50
2CE04512046214.6 20.3 41.6 50

637367-XTG-B-1110
Johnson Controls Unitary Products 19
TABLE 15: PHYSICAL DATA
MODELS1DC
036 048 060 076
EVAPORATOR
BLOWER
Centrifugal Blower Dia. x Wd. mm (in) 305 X 254
(12 X 10) 305 X 254 (12 X 10) 305 X 254 (12 X 10) 305 X 254 (12 X 10)
Fan Motor HP (Direct Drive) 1/3 3/4 ---- ----
Fan Motor HP (Belt Drive) ---- ---- 1 1/2 1 1/2
EVAPORATOR
COIL
RowsDeep 3333
Fins Per Inch (25 mm) 13 13 13 13
Face Area m2 (ft.2)0.33 (3.6) 0.40 (4.3) 0.57 (5.1) 0.57 (5.1)
CONDENSER
FANS
Propeller Dia. mm (in.) 610 (24) 610 (24) 610 (24) 610 (24)
Fan Motor Hp 1/2 1/2 1/2 1/2
Nom.CFM 4500450045004500
CONDENSER
COILS
RowsDeep 1112
Fins Per Inch (25 mm) 16 19 22 16
Face Area m2 (ft.2)1.60 (17.1) 1.60 (17.1) 1.60 (17.1) 1.60 (17.1)
COMPRESSOR
(Qty. Per Unit) Hermetic Recip. 1 1 1 1
(tandem)
AIR
FILTERS
QuantityPerUnit(15”X20”X1”or2“)2222
QuantityPerUnit(14”X25”X1”or2“)1111
Total Face Area m2 (ft.2)0.59 (6.3) 0.59 (6.3) 0.59 (6.3) 0.59 (6.3)
CHARGE Refrigerant 407C
kg (lbs./oz) 2.7 (6/0) 3.0 (6/10) 2.8 (6/12) 4.5/10
1. R-407C units may require a super heat and sub-cooling check at the job site to ensure proper charge and operation.
TABLE 16: ELECTRIC HEAT CORRECTION
FACTORS
NOMINAL VOLTAGE VOLTAGE kW CAP.
MULTIPLIER
380 380 0.627
415 415 0.75
TABLE 17: VOLTAGE LIMITATIONS
POWER SUPPLY VOLTAGE
MIN. MAX.
380/415-3-50 342 456

637367-XTG-B-1110
20 Johnson Controls Unitary Products
TYPICAL POWER WIRING
TYPICAL CONTROL WIRING
FIGURE 2 - TYPICAL FIELD POWER & CONTROL WIRING
W1
W2
Y1
G
OCC
P
P1
Y2
X
R
SD
C
C
SD
SD
R
OCC
C
RC
G
Y2
Y1
W2
W1
Jumper
Smoke
Detector
24 VAC
Class 2
X
R
THERMOSTAT
TERMINALS
CONTROL
TERMINAL
BLOCK
TERMINALS ON
A LIMITED
NUMBER OF
THERMOSTATS
3
1
2
4
3
1
2
4
Second stage heating not required on single stage heating units.
Second stage cooling not required on single stage cooling units.
Jumper is required if there is no Smoke Detector circuit.
Jumper is required for any combination of R, RC, or RH.
6
5
5
6
OCC is an output from the thermostat to indicate the Occupied condition.
X is an input to the thermostat to display Error Status conditions.
