YOSHINO SP200 User manual

Portable Solar Panel 200W
Rated Output: 200W / 18.24V
User Manual
SP200
01
1. Why isn't my device charging?
A. Check cable is connected properly and securely.
B. Check the panel is getting adequate sunlight.
C. Check the surface of the panel is clean and clear of debris.
2. Why won't my solar panel reach the maximum rated power output?
The rated power of the solar panel is a value calculated under STC, or standard test conditions with a
surface temperature of 25
°C , air mass of 1.5, and a solar intensity of 1000W/m².
Under actual use the solar panel will be affected by the sun's intensity and angle.
3. Is my solar panel waterproof?
The solar panel has a rating of IP67. While it is resistant to water and rain, it is not waterproof and should
not be left outside in constant wet conditions.
Frequently Asked Questions
Warranty
Note:
This warranty applies only for customers who purchased their product on Yoshino's website or
Yoshino authorized retailers. Do not use your product until you have read the terms of the warranty.
Limited Warranty
These after-sales polices apply to Yoshino Technology, Inc. (Yoshino) products purchased directly
from YoshinoPower.com or authorized resellers in North America and are provided only to the original
purchaser of the product.
By using your Yoshino product, you agree to be bound by these terms. If you do not agree or are not
eligible for these terms of use, do not use your Yoshino product and return to the place of purchase or
contact us within seven days to obtain a refund in accordance with our return policies.
What is Covered
Under this limited warranty, Yoshino Technology, Inc. warrants that each product will be free from
defects in material and workmanship for a period of 12 months from the date the product is
purchased or delivered to the purchaser.
What is Not Covered
This policy does not cover the following:
Product that has been abused, misused, or otherwise not operated within the parameters of the
literature provide with the product
Product with evidence of water damage or from use in bad weather (i.e., rain, dust/sandstorms)
Product that has been modified or had a repair attempted by anyone other than a Yoshino
authorized repair facility
Any product not purchased directly from Yoshino or an authorized reseller
To Obtain Warranty Service Contact Customer Support at [email protected]
Note:
This warranty applies only for customers who purchased their product on Yoshino's website or
Yoshino authorized retailers. Do not use your product until you have read the terms of the warranty.
Limited Warranty
These after-sales polices apply to Yoshino Technology, Inc. (Yoshino) products purchased directly
from YoshinoPower.com or authorized resellers in North America and are provided only to the original
purchaser of the product.
By using your Yoshino product, you agree to be bound by these terms. If you do not agree or are not
eligible for these terms of use, do not use your Yoshino product and return to the place of purchase or
contact us within seven days to obtain a refund in accordance with our return policies.
What is Covered
Under this limited warranty, Yoshino Technology, Inc. warrants that each product will be free from
defects in material and workmanship for a period of 12 months from the date the product is
purchased or delivered to the purchaser.
What is Not Covered
This policy does not cover the following:
Product that has been abused, misused, or otherwise not operated within the parameters of the
literature provide with the product
Product with evidence of water damage or from use in bad weather (i.e., rain, dust/sandstorms)
Product that has been modified or had a repair attempted by anyone other than a Yoshino
authorized repair facility
Any product not purchased directly from Yoshino or an authorized reseller
To Obtain Warranty Service Contact Customer Support at [email protected]
Tech support based in the USA!
1 [phone] [email protected]
Operating hours are 8:00 am - 4:30 pm PST (M-F).
YoshinoPower.com
For FAQs and more information, please Visit:
Yoshino Technology Inc.
18529 East Gale Avenue, City of Industry, CA 91748
www.YoshinoPower.com
Tech support based in the USA!
1 [phone]
[email protected]
Operating hours are 8:00 am - 4:30 pm PST (M-F).

02
Model
Rated Power
Cell Efficiency
Open Circuit Voltage
Short Circuit Current
MC4 Output
Operating Temperature Range
Dimensions Folded
Unfolded
SP200
200W
23%
18.24V
12.06A
21.8V
12.66A
200W / 18.24V
14 to 158°F / -10 to 70°C
19.4 x 30.8 x 2.0 inches / 494 x 782 x 50 mm
71.7 x 30.8 x 0.2 inches / 1820 x 782 x 5 mm
IP67
Thank you for purchasing a Yoshino solar panel. Before attempting to use this product. Please read
these instructions carefully to learn about the features and capabilities of the solar panel and how
you can get the best out of it.
Product Features
In the Box
1. One piece foldable design for easy setup and transport.
2. Carefully selected monocrystalline solar cells for reliable performance.
3. Protective ETFE lamination and IP67 rating provides protection against the environment.
Technical Specifications
SP200 Solar Panel
User Manual
Made In Vietnam
IP67
IP Rating
12 Months
Warranty Period
Tested And Certified
Rated Voltage
Rated Current
Tech support based in the USA!
1 [phone] [email protected]
Operating hours are 8:00 am - 4:30 pm PST (M-F).
Morning and Winter Noon or Summer
Correct Angle Correct Angle
90° 90°
1. Unzip the cable storage pouch on back of unit to access the MC4 connection cable.
2. Unfold the solar panels and spread the stands on back of unit to support the solar panels.
3. Plug the MC4 connection cable to the MC4 to XT60 connection cable provided with the portable power
station.
Unfolded Front Unfolded Back
Operating Instructions
03
MC4 to XT60 Cable
(not included)
MC4 Connector
SP200 B330 SST
Folded
Example 1
The SP200 Solar Panel can be used to charge Yoshino Portable Power Stations in series or parallel as
shown in the following illustrations.
*Please make sure to use the same model for series or parallel connection.
*MC4 to XT60 Cable (not included)
Supported Product
B330 SST
B660 SST
B2000 SST
B4000 SST
SP200(200W)
*√
*√
√
√
1 2
2
1
1
3
Limited 100W
SP200 Solar Panel does not include the MC4 to XT60 Cable. This cable is included with all Yoshino
Portable Power Stations.
*Note:
1
2
Tech support based in the USA!
1 [phone] [email protected]
Operating hours are 8:00 am - 4:30 pm PST (M-F).
Male
Male
Female
Female
Female
Male
Male
Female
04
SP200 Solar Panel does not include the MC4 to XT60 Cable. This cable is included with all Yoshino Portable
Power Stations.
*Note:
SP200 Solar Panel does not include the MC4 to XT60 Cable. This cable is included with all Yoshino Portable
Power Stations.
*Note:
Female Male FemaleMale
Male
Female
Male
Female
Male
Female
Example 3 (Series)
*MC4 to XT60 Cable (not included)
Female
Male
Female
Male
Example 2 (Series)
*MC4 to XT60 Cable (not included)
Supported Product
B330 SST
B660 SST
B2000 SST
B4000 SST
SP200(200W)
×
×
√
√
Supported Product
B330 SST
B660 SST
B2000 SST
B4000 SST
SP200(200W)
×
×
√
√
