YOU TiO StealthStream 1 User manual

StealthStream™ 1: AZSS1
Amplied Streaming Audio Player
Installation Guide
Imagined by You™

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
2
Safety Information 3
Product Overview 4
Introduction 5
Front-Panel 6
Back-Panel 7
Installation
Standard In-wall 8, 9
TiO Home App User Interface
Buttons and Controls 10
Audio 11, 12
Audio Menu
Basic Operation 13
Setting Moods and Experiences 13
Rhapsody 14
SiriusXM Radio 15
TuneIn Radio 15
vTuner Radio 16
Conguring a Stand-alone
AZSS1 using the TiO Home App
Music Setup 17
Music Settings 18
System Overview 19
Audio Applications 20
Troubleshooting Guide 21
Technical Specications/
Trademark Acknowledgements 22
Contact Information 23
Table of Contents

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
3
1. Read all instructions. Read and understand all the
applicable instructions before installing or operating
the product.
2. Retain all instructions. Keep this manual in a convenient
place for reference.
3. Heed warnings. Be aware of all warnings on the product
and in the instructions.
4. Follow instructions. Install and use this product only as
described. Don’t try to use this product in ways for which
it wasn’t designed.
5. Use indoors only. Don’t expose this product to the weather
or harsh environmental conditions such as continuous
sunlight, excessive humidity, or moisture.
6. Keep product dry. Don’t use the product near water – for
example, near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement, or near a swimming pool. Also, do
not handle the product when your hands are wet or damp.
7. Use the right power source. Don’t connect the product
directly to electrical line voltage. Use only an approved
power adapter.
8. Ground product properly. Make sure the product’s means
of grounding or polarization is not defeated.
9. Power cord protection. Power supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, receptacles, and
the point where they exit from the product.
10. Keep product clean. From time to time, wipe off the
exposed parts of the product with a clean, dry, soft cloth.
Don’t use abrasive materials, thinners, alcohol or other
chemical solvents or materials.
11. Avoid spills and foreign objects. Make sure liquids and
objects don’t get into the product enclosure through
any openings.
12. Get professional service. Have the product serviced
only by certied TiO service personnel when:
• Liquids spilled/objects have fallen into the product
• The product has been exposed to excess humidity
• The product doesn’t appear to operate normally
• The product is damaged
13. Don’t attempt to service the product yourself. Doing
so will void the warranty. If you have any questions, call
TiO Support at 1-855-999-9846 or 1-407-278-1200
or email us at [e-mail]
Safety Information
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of or more of the following measures: reorient or relocate the receiving antenna; increase the separation
between the equipment and receiver; connect the equipment into an outlet on a circuit different from that to which the receiver is connected,
or consult the dealer or an experienced radio/TV technician for help.
In accordance with FCC requirements, changes or modications not expressly approved by Automated Control Technology Partners, Inc.
could void the user’s authority to operate this product.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
This device complies with Industry Canada licence- ‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

AZSS1 Installation Guide
StealthStream™1: AZSS1
Amplied Streaming Audio Player
Box Contents
n StealthStream™ 1
n Mounting Hardware – In-wall mounting kit:
• Mounting Bracket
• Two (2) 6-32 large screws (to mount assembly
to wall box)
• Two (2) 4-40 small screws (to mount bracket
to AZSS1)
n Speaker Connector – Male four (4) conductor
n Power Connector – Male two (2) conductor
n Four (4) adhesive backed rubber feet (for table top use)
Additional TiO Products (sold separately)
n AZPS1 – Remote Power Supply (supports one AZSS1)
n AZPC1 – Remote Power Coupler (an optional product,
used when needed for power over Cat5 installations)
Dimensions (overall) – 6.99W x 4.78H x 9.91D cm /
2.75W x 1.88H x 3.90D in.
Amplier – 100W class D amplier (2 x 50W @ 4Ohms).
Wireless Connectivity – Wi-Fi® connectivity 802.11n
using WPS.
Wired Connectivity – 802.3 100Mbit/s wired Ethernet.
Bluetooth Support – Integrated Bluetooth support for
connecting Bluetooth devices supporting A2DP.
Network-based music – Stream music from any DLNA
compliant network device.
Optical Audio Input – Connect your TV, satellite, cable
box, CD player or any other digital source to your AZSS1
and listen in one room or throughout your home.
Auto-switching – Switches to the optical input when
your TV, CD player or cable box is turned on.
Analog Audio Output – Outsource your sound to an
external amplier or home theater receiver.
Party Mode – TiO’s StreamShare™ feature can synchronize
and control up to 6 audio players.
Dedicated Streamer – Listen to the best audio content from
popular streaming services.
Mounting Options – Tabletop, surface mount or in-wall
options.
IMPORTANT NOTE: The TiO Pro App is required to program
the AZSS1 StealthStream™1 and available to certied
TiO installation professionals only. Please contact
your TiO Representative or register to be a TiO Dealer
at www.tiohome.com
Product Overview
Imagined by You™
www.tiohome.com
4

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
5
The TiO StealthStream™ 1 (AZSS1) is the most
versatile and powerful digital audio player on the
market. The StealthStream™1 connects to your home
network and offers access to all of today’s popular
music services. If that’s not enough, just connect any
Bluetooth-enabled device and stream your favorite
audio music.
The AZSS1’s stealth design allows the robust player
to be hidden out of sight. Powered by an integrated
100 watt amplier, the AZSS1 provides outstanding
sound quality but ts in the palm of your hand! In
fact, it’s so compact that it installs into a standard,
single-gang wall opening.
The StealthStream™ 1 can also be used as a stand-
alone music player and be directly controlled from
the TiO Home mobile App. For more information
see page (7).
Go Small or Go Home: Its compact size (1.88”H x
2.75”W x 3.90”D) makes it the smallest audio player
in the world. The days of needing huge and costly
ampliers are over.
Plenty of Power: Despite its compact size, the AZSS1
boasts a high-performance 100 watt digital amplier.
With the AZSS1 you’ll enjoy crystal clear, high delity
music in every room.
Mobile by Design: Controlled and congured through
the TiO Pro for Android™ App. Just launch the App
and enjoy all of your music and audio choices!
Wireless Connectivity: The AZSS1 features
802.11n Wi-Fi
®
to support system communication
and streaming audio. Wired connections are also
supported via an integrated ethernet port.
Integrated Bluetooth Streamer: Connect to the
AZSS1 with any Bluetooth device and stream your
favorite content to just one room or throughout your
entire home.
Streams Everywhere: With multiple AZSS1’s installed
throughout the home, you can listen to music where
you want. The dedicated streamer, allows you to enjoy
jazz in the kitchen, punk on the porch and classical in
the ofce. The AZSS1 has you covered!
Party On!: The AZSS1 can synchronize and control up
to 6 audio players—all from one central location for all
your party needs!
Network-Based Music: Want to dive into your digital
music collection? Stream your network music les
to your TiO system.
Optical Audio Input: Connect your TV, CD player or
any other digital source to your AZSS1 and listen
in one room or throughout your home.
Auto-Switching: The AZSS1 is smart enough to
switch to the optical input when your TV, CD player
or cable box is turned on. When you are done, it will
automatically switch back.
Introduction

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
6
Front-Panel
Status Light
Indicator
Wireless
Antenna
Mounting
Bracket Holes
Screws
Wireless Antenna – For use with Wi-Fi®, the antenna
should always be pointing straight up, in a vertical
position during normal usage. For instance, if you
plan to use it as a tabletop system turn the antenna
counter clockwise until the antenna is standing
upright. See Figure 1. When installed in a wall or a
cabinet, the antenna should be turned upright once
again, to point straight up in the vertical position.
See Figure 2.
Status Light Indicator – Used for setting up
and troubleshooting your AZSS1. Refer to the
troubleshooting guide section of the manual
for more information.
Mounting Bracket Holes – Used for in-wall
installation with supplied mounting bracket and
screws. See page 10 for installation instructions.
Tabletop
Figure 1 Figure 2
In-wall

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
7
Back-Panel
Power Input
Speaker
Connector
Wired
Ethernet
Jack
Wireless
Antenna
Digital
Audio
Input
Variable
Output
Variable Output – 3.5mm stereo variable analog
output, used for connecting the AZSS1 to
an external amplier for additional power.
Speaker Connector – 4 wire speaker connector
that can support up to 12 gauge speaker wire. TiO
recommends 16 gauge speaker wire for multi-space
audio installations.
Power Input – Removable 2 terminal power connector
can support up to 12 gauge wire.
Wired Ethernet Jack – Used for creating a hard wired
network connection. Also used when connecting the
AZPC1 power coupler to provide power to a AZSS1.
Digital Audio Input – Toslink connector accepts
a PCM audio input signal from any supported audio
device, such as a TV, AV Receiver, Blu-Ray or DVD
player.

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
8
For tabletop installation, skip to Wiring Connections below.
STEP 1
Identify a place to install the AZSS1 in the wall.
STEP 2
Cut out a rough opening into the wall and install a single
gang low voltage ring and tighten it down.
STEP 3
Pull the power and other audio wires to the new audio location.
STEP 4
Locate the in-wall mounting bracket that came with the AZSS1.
Align the in-wall mounting bracket so that it lines up properly
with the front panel of the AZSS1. Locate the small screws from
the installation package. Secure the in-wall mounting bracket
to the front of the AZSS1.
STEP 5
Make all wiring connections per the instructions below and
then insert the AZSS1 with bracket into the single gang low-
voltage ring.
WIRING CONNECTIONS
Locate the speaker connector block that came in a clear pack
of accessories with your AZSS1. Loosen the four screws before
attempting to connect the speaker wire. With your speaker wire
ends trimmed back 1/4” inch (.64 cm) insert each speaker wire
and tighten down each screw. Note the polarity: positive (+)
speaker wire on the outside terminal and negative (–) speaker
wire on the inside terminal. See diagrams below for wiring
speakers.
Note: Make sure locking tabs on mating side of Speaker
Connector locks over the top of the receiving connector on
the AZSS1.
Installation - Standard In-wall
STEP 1
In-wall mounting bracket
with small screws
STEP 2
Single gang low-voltage
ring with large screws
Removable
Speaker Connector
+ L – – R +
+ L – – R +
Insert Speaker
Wires
Loosen Screws
Lock Tabs Over
Connector
Parallel Speaker Wire Diagram
+
–
+
–
+
–
+
–
Right
Left
4 Ohm
Load 8 Ohms
8 Ohms
8 Ohms
8 Ohms
+
–
+
–
Speaker Wire Diagram
+
–
+
–
Right
Left
4 Ohm
Load 4 Ohms
4 Ohms
+
–
+
–
WIRING
CONNECTIONS

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
9
STEP 6
Skip to Step 7 if you are using the Cat5 power wiring via
the TiO Remote Power Coupler (AZPC1).
Locate the AZPS1 power supply. To connect the power supply
to the AZSS1 you will need to locate the Power Connector for
the AZSS1. The power connector is located in a clear pack of
accessories in the AZSS1 package. With the Power Connector
in your hand, loosen the two screws, so that the two power
wires can be inserted, then tighten down each screw. Note the
polarity: Left positive (+), Right negative (–). Plug the Power
Connector into the the back of the AZSS1.
Note: Make sure locking tabs on mating side of the Power
Connector locks over the top of the receiving connector on
the AZSS1. Skip to Step 8.
STEP 7
Locate the AZPS1 power supply. To connect the power supply
to the AZPC1 you will need to locate the Power Connector for
the AZSS1. The power connector is located in a clear pack of
accessories in the AZSS1 package. With the Power Connector
in your hand, loosen the two screws, so that the two power
wires can be inserted, then tighten down each screw. Note
the polarity: Left positive (+), Right negative (–). Insert Power
Connector into power socket on the AZPC1.
STEP 8
Network connection. If you are using an Ethernet Cable for
network, plug it in now. No action required, at this time, if
connecting using Wi-Fi.
STEP 9
Attach the optical Line-In if adding a digital input source, and
Line-Out if connecting to a external amplier.
STEP 10
With all connections securely connected to the back of the
AZSS1, insert the AZSS1 into the low voltage single gang ring
and secure it using the two included screws in the package.
STEP 11
For Stand-alone use, connect the Ethernet cable from the
AZSS1 to the home network router (for Wi-Fi connection see
Connecting Using WPS).
For Multi-space use, connect the Ethernet cable from the
AZSS1 to the Master Coordinator (MC1).
STEP 12
With the AZSS1 securely mounted, plug the AZPS1 into an
outlet. The AZSS1 takes approximately one minute to complete
its power up cycle. The AZSS1 Installation is complete.
WARNING: This product should not be mounted in any
box that also has electrical products such as light switches
or outlets installed. Electrical interference from a light
switch or outlet can create unwanted background noise
on your audio space.
IMPORTANT: It is not recommended to mount multiple
AZSS1’s next to each other when connecting over Wi-Fi.
Installing multiple wireless AZSS1’s near each other could
effect their ability to connect wirelessly to the MC1.
DANGER: Avoid all electrical wiring when cutting the rough
opening. Failure to do so may result in serious injury
or death.
NOTE: The power supply used by the AZSS1 is a 90W power
supply rated at 3.75amps (sold separately).
STEP 6
Removable
Power Connector
+ –
+ –
Insert Power
Wires
Loosen Screws

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
10
Rooms Button Moods Button
Home Button
Brings you to the Home Menu.
Rooms Button
Select the room you want to control.
Music Button
Select this button to access and play all of your music.
Moods Button
Used to select Mood settings.
Local Temperature
Displays the Temperature in your area.
Settings Button
The settings choices will vary based on the TiO Element
you are accessing.
Create Experience
Used when you are ready to create Whole House Experiences.
Start Experience
Access and choose an Experience from the list.
Capture Mood
Used when you are ready to create Room based events.
Home Button
Music Button
Temperature
Settings Button
Capture
Mood
Start
Experience
Create
Experience
TiO Home App User Interface
The TiO Home app is a free download form the Android Play Store. The buttons and controls allow the user to quickly and
intuitively navigate and select lighting , music, moods, temperature, security and experience options. Some options are only
available in combination with other TiO Elements, such as the Master Coordinator™ (MC1).

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
11
Source Selection
Press this tab to view a drop down menu of audio sources.
Shortcut Menu
Quickly jump from one feature to the next using these shortcut
buttons; Moods, Music, Lights and Thermostat*.
Audio Settings
Press the Audio Settings button when you need to add or
change a Premium Internet Radio subscription account.
Search
Depending on your source selection you may have the ability
to search for content using Rhapsody, SiriusXM, TuneIn and
VTuner.
Volume Control
Adjust the volume using the slide control or Mute. Unmute
the audio by pressing the Mute button.
Audio Controls
Depending on your music source you may have access to
these control options; Rewind, Pause, Fast Forward, Repeat
and Shuffle.
Audio Settings
Audio
The Audio screen provides simple intuitive features to let you nd and listen to music quickly. Depending on your music
selection you may experience metadata and album art with your music.
Shortcut
Menu
Search
Selection
Source
Selection
Audio
Controls
Volume
Control

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
12
Audio Settings
Press the Audio Settings button when you need to add or
change a Premium Internet Radio subscription account.
Add Subscription Accounts
Used for adding a new subscription account to the TiO
Audio System.
Add Subscription
Accounts Button
Subscription
Accounts Button

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
Turn on a Space –To listen to music, select a station/track/
playlist from the selected source. The space will begin playing
at the default volume set for the space. Space must be off for
at least 1 hour for default volume to set.
Turn off a Space – Press the Stop, Pause or Mute button to
turn off the space.
Source Selection – Pressing the source button will drop down
a list of available sources. Each source has its own menus
to navigate. Using the source’s menus, navigate and select
content to play.
Source Control Options – Control options vary per Source
Options for sources may include the following:
Stop – Stops the source from playing.
Play – Plays music source selected.
Forward – Advances current music to next track.
Back – Plays previous track.
Repeat – Repeat’s current selection.
Pressing the Repeat button once activates single song repeat.
Pressing the Repeat a second time activates repeat all.
Pressing the Repeat a third time turns OFF repeat.
Shuffle – Plays current music selection in a shuffle order.
Volume Control – Move the slide control right or left, to
increase or decrease the volume for that space.
Mute – Press the Audio button to quiet the space. Press the
Mute Audio button a second time to turn on the audio. Volume
will return to the previous volume level. With the Mute On,
adjusting the volume change to slider will cancel the Mute ON
selection.
Search – Press the Search button, to search for specic
content in the selected source. Pressing search opens a search
box. Select the search box to launch the keypad. Type in the
search criteria and press search.
Clear Search Box – To return to the source menu screen.
NOTE: A Master Coordinator (MC1) is needed to set up these
features.
Use the TiO Home App to design room Moods or whole-house
Experiences. The Moods and Experiences can be initiated with
the touch of a button or a timed event.
Setting an Audio Mood
Select the Audio source and content and adjust the volume.
Press the Capture Mood button in the lower right corner of
the audio screen.
Type the name of the mood and select audio and then press
the capture button.
Setting a Scheduled Audio Mood
Select the Audio source and content and adjust the volume.
Press the Capture Mood button in the lower right corner of
the audio screen.
Type the name of the mood and select Audio. Next press the
Add Schedule button and create the schedule for this mood
and press the save button. Finally press the capture button
to create the scheduled Audio Mood.
Creating an Audio Experience
Press the Create Experience Button in the lower left corner
of the audio screen.
From the list of moods on the right hand side of the screen,
drag the moods that you want in this experience and drop them
on the screen to the left.
Press the add delay button on the bottom of the screen, if
you want to add delays between each of the moods.
Next press Schedule this Experience button and create the
schedule you would like, then press the save button.
Finally, press the Save Experience button to create the audio
experience. This will prompt you to Test the experience and
verify that it is working properly. You can choose to edit the
experience if something needs to be changed or you can save
the experience and exit to the Experience Home Screen.
Basic Operation Setting Moods and Experiences
Audio Menu

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
14
Rhapsody
Using Search
Dark Grey Search Button – Search Off.
Blue Search Button – Search On.
Clear the search box to begin a new search.
Select Rhapsody from the source selection.
The button will turn blue and bring up a search box.
Select one of the search options; by Artist, by Album, by Track.
Type in your search criteria and press search.
Choose a selection from the search list.
Options: Play Artist Radio, Artist Sampler, Top Tracks or
Main Releases.
Select one of the options and start listening to content.
Adding content to Rhapsody’s My Library (+)
Playlists must be created on the Rhapsody website at
www.Rhapsody.com.
To add to My Library, press the (+) and then press the Add to
Library button. That’s it, the selection is now added to the My
Library list.
Removing content from Rhapsody’s My Library (Trash Can)
Navigate to the content you would like to remove by Artists,
Albums, Tracks, Radio, Playlists.
Press the (Trash Can) icon to the right of the content to be
removed and then press the Remove from Library button.
Back
Button
Rhapsody Account Set Up
Listen to music like never before with Rhapsody. A Rhapsody
subscription gives you access to the ultimate music catalog,
delivering millions of songs from thousands of artists to your
TiO Audio system.
To set up your account, you will need a computer with internet
access, an email address, and a credit card.
Your new music collection is complete with millions of
songs, entire albums and artists hits spanning the decades.
Rhapsody has the power to play exactly the songs you want,
wherever you are. Load up on new releases, obscure album
cuts and everything in between with Rhapsody’s gigantic
music catalog. There are no limits to how much music you can
play. Listen to the same song over and over or explore new
songs from every genre. Rhapsody is more than just internet
radio.
To nd out more information about Rhapsody in the United
States of America go to www.Rhapsody.com. For Canadian
residents go to www.Rhapsody.com/Napster.
Rhapsody Buttons
My Library, Genres, New Releases, Charts, Staff Picks,
Rhapsody Radio.
Press a selection to look for content.
Light Grey Navigation button – ( < ).
Located below the Rhapsody Button the Back button will
create a bread crumbs list of your selections and will be used
to return you back to the Rhapsody main menu. Pressing
this button will return you up one level per press. Depending
on your location in the Rhapsody menu it may take several
presses of the navigation button to return to the main menu.

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
15
SiriusXM Buttons:
All Channels, Categories and Presets.
Press a selection to search for content.
All channels lists all SiriusXM channels by category.
Categories list all SiriusXM categories. Select a category
then select a channel in the category.
Navigation Back Button
Light Grey Navigation Back button – ( < ).
Located below the SiriusXM Radio Button the navigation back
button will create a bread crumbs list of your selections and
will be used to return you back to the SiriusXM Radio main
menu. Pressing this button will return you up one level per
press. Depending on your location in the SiriusXM Radio menu
it may take several presses of the navigation button to return
to the main menu.
Using Search
Dark Grey Search Button – Search Off.
Blue Search Button – Search On.
Clear the search box to begin a new search.
Press the search button to begin your search.
The button will turn blue and bring up a search box.
Type in your search criteria and press search.
Choose a selection from the search list.
SiriusXM Internet Radio Account Set Up
SiriusXM Internet Radio subscriptions allow one instance of
streaming content per account. The TiO audio system will
allow the listener to share a single instance throughout the
system or will allow multiple accounts to be stored and played
in other audio spaces throughout the home. Selecting an
account that is currently playing will activate the subscription
in your space and disconnect the subscription from the
previous space.
To listen to SiriusXM Internet Radio, you’ll need to subscribe
to SiriusXM Internet Radio service and obtain a user name and
password. SiriusXM Internet Radio is available to residents of
the United States of America and Canada.
Access to SiriusXM Internet Radio requires a minimum of one
subscription. To nd out more information about SiriusXM
Internet Radio visit www.siriusxm.com/internetradio.
Canadian residents should visit www.siriusxm.ca or call
1-888-539-7474(SIRI).
SiriusXM Radio
Categories
My Favorites, Local Radio, Music, Talk, Sports, By Location,
By Language, Podcasts.
Navigation Back Button
Light Grey Navigation Back button – ( < ).
Located below the TuneIn Radio Button the navigation back
button will create a bread crumbs list of your selections and
will be used to return you back to the TuneIn Radio main menu.
Pressing this button will return you up one level per press.
Depending on your location in the TuneIn Radio menu it may
take several presses of the navigation button to return to the
main menu.
Using Search
Dark Grey Search Button – Search Off.
Blue Search Button – Search On.
Clear the search box to begin a new search.
Press the search button to begin your search.
The button will turn blue and bring up a search box.
Type in your search criteria and press search.
Choose a selection from the search list.
Adding content to TuneIn’s My Favorites (+) Button
To add to My Library, press the (+) button and then press the
Add to Library button. That’s it, the selection is now added to
the my library list
Removing content from TuneIn’s My Library (Trash Can)
Navigate to the content you would like to remove by Artists,
Albums, Tracks, Radio, Playlists.
Press the (Trash Can) icon to the right of the content to be
removed and then press the Remove from Library button.
TuneIn Radio Account Set Up
TuneIn Radio service is available on your TiO audio system.
TuneIn to the world’s sports, news, talk, and music from
wherever you are. TuneIn lets you hear what’s happening right
now on over 100,000 radio stations globally and enjoy two
million on-demand programs, like podcasts, concerts and
interviews.
Create a TuneIn account and begin creating and storing your
favorite stations. Go to www.tunein.com and select Sign Up to
create your TuneIn Radio account.
TuneIn Radio

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
16
Categories
Local Stations, Recently Played, Favorites, Location. Genre,
New Stations,Most Popular Stations.
Navigation Back Button
Light Grey Navigation Back button – ( < ).
Located below the vTuner Radio Button the navigation back
button will create a bread crumbs list of your selections and
will be used to return you back to the vTuner Radio main menu.
Pressing this button will return you up one level per press.
Depending on your location in the vTuner Radio menu it may
take several presses of the navigation button to return to the
main menu.
Using Search
Dark Grey Search Button – Search Off.
Blue Search Button – Search On.
Clear the search box to begin a new search.
Press the search button to begin your search.
The button will turn blue and bring up a search box.
Type in your search criteria and press search.
Choose a selection from the search list.
vTuner Internet Radio Account Set Up
vTuner Radio

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
17
Music Setup
Conguring a Stand-alone AZSS1 using the TiO Home App
If you have not already downloaded the TiO Home App you can nd it by searching for “TiO Home Automation”
within the Google Play Store. Choose “Install” and allow the App to fully download before attempting to use.
For more information on using the Google Play Store please visit: http://play.google.com.
STEP 1 Be sure that your tablet is turned on and connected to the
Home Network.
STEP 2 Locate the TiO App on your tablet and start the application.
The TiO App will automatically locate and connect to the AZSS1.
STEP 3 Press the Launch Control button to open the TiO
Control Screen
Wireless
Home Network
Launch Control
Button
TiO App

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
18
STEP 4 From the TiO Home main menu, choose the “Music”
button, and the Audio browser will be displayed.
Music Button
Music Service
Selections
Options
Show Tips
STEP 5 From the TiO Home Music Screen, select a music service
from the drop down menu.
STEP 6 Continue through the Options until desired settings are
selected.
NOTE: By deselecting Show Tips after Initial Music Setup, you will return
to the Now Playing screen.
Music Settings

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
19
System Overview
Element Proles
StealthStream™ 1
TouchLite™ 4
ThermoTouch™ 1
TouchStream™ 7 TouchStream™ 4
Wi-Fi
Wi-Fi
CFLIncandescent
Load Level
Power
Switch
Mode
1, 2, 4
Button
Dimmer
Mode
Wired
Network
TuneIn
VC
Retro-t
SiriusXM®
Power
Coupler
Rhapsody®
Digital
Input
Bluetooth®
Stereo
Output
DLNA
Music
Audio Elements
Lighting Elements
Climate Elements
Wi-FiEnergy
Saver
ElectricGasVacation
Mode
Local
Forecast
HD 3.5
mm
LED
+/-
Home Network
Router
MC1
Internet
TiO App
The Network
1
2
4
vTuner

Imagined by You™
www.tiohome.com
AZSS1 Installation Guide
20
Audio Applications
When setting up a Stand-alone
application be sure the home network
router is Wi-Fi Protected Setup™
enabled.
All Audio zones feature wireless and
wired networking so that you can
choose which method will work the
best for your application.
The MC1 can have up to 4 wired TiO
elements routed directly to it. If you
want to hard wire more Audio zones
simply add a capable network switch
to the connection.
Internet Internet
TiO App TiO App
Home Network
Router
Home Network
Router
MC1
Stand-alone Multi-space
AZSS1
AZSS1
AZSS1
Stand-alone application: The TiO Streaming Audio Players can be congured as a Stand-alone single zone or be tied to a
MasterCoordinator for true Multi-space applications. When installed as a single space, conguration is still completed through
the TiO Pro App and it communicates directly to the Audio Player, through the home network with a wired or wireless connection.
Multi-space applications: For this application, the addition of a MasterCoordinator is required. Conguration is completed through
the TiO Pro App and Audio Zones can be installed for wired or wireless applications.
PSPS
PSPS
PSPS
