Yueming CMA1325 User manual

Owner's Manual
NestCutting Series Machine
For：CMA1325/CMA1625/CMA2222

I
Copyright Statement
GD Han’s Yueming Laser Technology co.,Ltd.
All rights reserved.
GD Han’s Yueming Laser Technology co.,Ltd (Han’s Yueming Laser hereafter) reserves the
right to modify the products and product specifications described in this manual without
advance notice.
Han’s Yueming Laser is not responsible to any direct, indirect, or consequential damage or
liability caused by improper use of this manual or the product.
Han’s Yueming Laser owns the patent, copyright or any other intellectual property right of
this product and the related software. No one shall duplicate, reproduce, process or use this
product and its parts, unless authorized by Han’s Yueming Laser .
All the name refered in this manual only for identification, if belongs to other company’s
registered trademark or copyright, proprietary rights of the name belongs to their respective
holder.

II
Disclaimer and Responsibility Statement
Whole using the machine from our company, users are required to ensure integrity and
independence of the product including but not limited to: mechanical, electrical, optical, control
software and accessories. Unauthorized modification is strictly prohibited. It is a must to satisfy
operating environment and operating specifications specified in the owner’s manual.
For the followings:
Machine modified with no authorization (including but not limited to: add, remove,
modify, unauthorized disassembly, replacing parts);
Use the machine in the environment failing to satisfy the operating requirements;
Operate disobeying the specifications of our company;
Unauthorized use the machine parts, accessories and auxiliaries on to other machine
or in other places;
Viciously disassemble, destroy, decode hardware and software of the machine from
our company
Our company shall not undertake any direct, indirect or joint responsibility. Our company
reserves the rights to ascertain legal responsibility for the serious consequences or
economic losses or reputation losses caused by what mentioned above.

III
Foreword
Thanks for purchasing the laser engraving machine control system of our company.
Before operating, please read this manual carefully to ensure proper operation.
Please keep the manual properly for reference.
Since the configs are different, certain models do not have the functions listed in this
manual. Please refer to the specific functions for details.
Due to the constantly tech update, the specification for reference only, subject to the real
standard.
Tags in this book:
Warming
Special Attention: User must follow and perform as the manual;
otherwise, it could lead to errors or relatively serious problem.
Note
Note: User should comply with the attention and suggestion in this
manual; it could bring much easier operation.

IV
Safety Precautions
Attention
◆Before using the machine, users are required to carefully read this manual and
other operating requirements, strictly abide by the operating specifications.
Professional are required for operating the machine.
Attention
◆The machine uses class 4 laser (strong laser radiation). The laser radiation may
possibly cause the following accidents: ①emblaze the surrounded flammable
materials; ②generate other radiations and toxic or hazardous gas by processed
objects during laser processing; ③direct irradiation of laser radiation cause
harm to human body. Therefore, fire fighting devices are required in the
operating place of the machine. Stacking flammable or explosive objects near the
machine is strictly prohibited. Good ventilation is a must. Only the qualified
personnel are authorized to approach the machine.
Attention
◆The processed objects and discharged materials are required to satisfy
requirements as per local laws and regulations.
Attention
Laser processing is with potential risks. Users should carefully make sure if the
processed objects are suitable for laser processing.
There is high voltage and potential risk in the laser machine. Unauthorized
disassembly by unqualified personnel is prohibited.
Reliable earthing is required for the machine and related other machine before
power-on.
During operating, removing any cover of the machine is strictly prohibited.
During operating, the operators are required to observe working status of the
machine all the time. In case of any abnormality, it is immediately to disconnect
power supply and take active and corresponding measures.
After power-on, special personnel are required for monitoring. Unauthorized
leaving is strictly prohibited.
It is a must to disconnect the power supply before leaving.
Attention
It is strictly prohibited to placing any unrelated all-reflective or diffusion
reflective objects in the machine to prevent laser reflecting to human body or
flammable materials.
Attention
The environment for the machine should be dry, free of interference and
influences from pollution, vibration, high voltage and strong magnet. The
operating ambient temperature ranges 5-40℃, and the humidity ranges 5-95%
(no dew);

V
The machine should be far from electric appliances sensitive to electromagnetic
interference;
Operating voltage: AC220V, 50Hz. Power-on is strictly prohibited in case of
unstable voltage of the power grid or unspecified voltage.
Attention
Chapter two of this manual is for Safety Rules. Please refer to the chapter more
details concerning safe operation of the machine. Users are required to carefully
read and abide by all the requirements of safety.

- 1 -
Contents
Copyright Statement .......................................................................................................... I
Disclaimer and Responsibility Statement.......................................................................... II
Foreword .......................................................................................................................... III
Safety Precautions............................................................................................................ IV
Chapter 1 Machine Introduction................................................................................... - 1 -
1.1 Instructions of machine model ....................................................................... - 1 -
1.2 Machine compositions ................................................................................... - 1 -
1.2.1 Compositions of the machine ................................................................. - 2 -
1.2.2 Man-machine interface........................................................................... - 4 -
1.2.3 Compositions of movement mechanism ................................................ - 5 -
1.2.4 Working platform.................................................................................... - 6 -
1.2.5 Compositions of optical mechanism....................................................... - 7 -
1.2.6 Brush-pencil mechanism......................................................................... - 7 -
1.2.7 Electric dual-laser head mechanism ....................................................... - 8 -
1.2.8 Auxiliary parts ......................................................................................... - 8 -
1.3 Machine parameters .................................................................................... - 10 -
1.4 System configuration.................................................................................... - 12 -
1.5 Operating environment................................................................................ - 13 -
1.6 Suitable materials ......................................................................................... - 13 -
1.7 Applicable fields............................................................................................ - 13 -
Chapter 2 Safety Rules................................................................................................. - 14 -
2.1 Product safety............................................................................................... - 14 -
2.2 Safe equipment ............................................................................................ - 14 -
2.3 Safety awareness.......................................................................................... - 14 -
2.4 Requirements for personnel......................................................................... - 15 -
2.4.1 Definition of terms................................................................................ - 15 -
2.4.2 Qualifications ........................................................................................ - 15 -
2.4.3 Responsibility ........................................................................................ - 15 -

- 2 -
2.4.4 Personal protective devices .................................................................. - 16 -
2.5 Special product risks..................................................................................... - 16 -
2.5.1 Laser radiation risk................................................................................ - 16 -
2.5.1.1 Common mode................................................................................... - 16 -
2.5.1.2 Maintenance mode ............................................................................ - 17 -
2.5.1.3 Direct laser ......................................................................................... - 17 -
2.5.1.4 Reflection and diffuse radiation ......................................................... - 18 -
2.5.2 High voltage risk.................................................................................... - 18 -
2.5.3 Risk of electric shock............................................................................. - 18 -
2.5.4 Hazard of processing outgrowth........................................................... - 19 -
2.5.5 Risk of optical system............................................................................ - 20 -
2.5.5.1 Routine operation .............................................................................. - 20 -
2.5.5.2 Warning for fire accident.................................................................... - 21 -
2.5.6 Other risks............................................................................................. - 21 -
2.5.7 Measures for emergency ...................................................................... - 21 -
2.5.7.1 Measures for personal injury ............................................................. - 21 -
2.5.7.2 Measures for fire accident ................................................................. - 21 -
Chapter 3 Machine Installation and Debugging .......................................................... - 23 -
3.1 Machine Installation..................................................................................... - 23 -
3.1.1 Steps of unpacking ................................................................................ - 23 -
3.1.2 Unpacking check ................................................................................... - 24 -
3.1.3 Preparations for machine installation .................................................. - 25 -
3.1.4 Steps of installation............................................................................... - 26 -
3.1.4.1 Laser tube installation ........................................................................ - 26 -
3.1.4.2 Cooling system installation................................................................. - 28 -
3.1.4.3 Air pump installation.......................................................................... - 29 -
3.1.4.4 Air compressor installation................................................................. - 30 -
3.1.4.5 Blower installation.............................................................................. - 30 -
3.1.4.6 Machine earthing ............................................................................... - 30 -

- 3 -
3.1.4.7 Software and machine drive installation............................................ - 31 -
3.1.4.8 Other auxiliary part installation ......................................................... - 32 -
3.2 Instructions of machine button and indicator light...................................... - 32 -
3.2.1 Master switch of power supply .......................................................... - 32 -
3.2.2 Emergency stop button......................................................................... - 32 -
3.2.3 Operation panel .................................................................................... - 33 -
3.2.4 Working indicator light ......................................................................... - 36 -
3.3 Machine debugging ...................................................................................... - 37 -
3.3.1 Sequence of power-on and power-off.................................................. - 37 -
3.3.2 Movement debugging........................................................................... - 38 -
3.3.2.1 Motor shaft movement...................................................................... - 38 -
3.3.2.2 Pulse setting ....................................................................................... - 39 -
3.3.2.3 Stroke, limit and reset ........................................................................ - 42 -
3.3.2.4 Straightness and perpendicularity ..................................................... - 42 -
3.3.3 Laser debugging .................................................................................... - 43 -
3.3.3.1 Light emitting test .............................................................................. - 43 -
3.3.3.2 Light route adjustment....................................................................... - 44 -
3.3.4 Trial operation of processing ................................................................ - 46 -
Chapter 4 System Maintenance .................................................................................. - 47 -
4.1 Mechanical maintenance ............................................................................. - 47 -
4.1.1 Guide rail, linear shaft, slide block assembly (metal guide pulley), nylon
guide pulley - 47 -
4.1.2 Synchronous belt, synchronous belt wheel.......................................... - 48 -
4.1.3 Fasten screws and coupling .................................................................. - 49 -
4.2 Electric maintenance .................................................................................... - 49 -
4.2.1 Limit switch ........................................................................................... - 49 -
4.2.2 Emergency stop button......................................................................... - 49 -
4.2.3 Other button and indicator light maintenance..................................... - 50 -
4.3 Light route maintenance .............................................................................. - 50 -
4.4 Auxiliary parts maintenance......................................................................... - 51 -

- 4 -
4.4.1 Water replacement and water tank cleaning ....................................... - 51 -
4.4.2 Blower cleaning..................................................................................... - 51 -
4.4.3 Water chiller maintenance ................................................................... - 51 -
Chapter 5 Trouble Shooting ........................................................................................ - 53 -
Appendix...................................................................................................................... - 55 -
Appendix 1 Electric wiring diagram for No.3 controller.......................................... - 55 -
Appendix 2 The control figure of main power supply for CMA1625F.................. - 56 -
Appendix 3 The control panel and I/O config for CMA1625F .............................. - 57 -
Appendix 4 Export Config of CMA1625F ................................................................. - 59 -
Post.............................................................................................................................. - 60 -

- 1 -
Chapter 1 Machine Introduction
NestCutting series laser machine is laser processing device for large breath of garment cloth
developed by Guangdong Han’s Yueming Laser Technology Co., Ltd. The machine is mainly
equipped with sealed 80W-150W CO2 glass laser tube or metal radio-frequency tube with the
function of cutting large breadth garment cloth, leather or wood and with the wide scope of
application in the field of garment, advertisement and lamp. It is a large breath of laser cutting
machine with high speed and high breath.
1.1 Instructions of machine model
Indications of Han’s Yueming laser machine model:
Fig.1-1 Instruction of machine model
1.2 Machine compositions
Due to different models and improvement of products, the industrial design and details of
some types of machine may be different. The compositions are subject to the actual product. The
following takes general CMA1325 as an example for the compositions of the machine.
Note
The standard config of CMA1325/1625/2222 is No.3 control system, it can running
independently without company, and the working platform is strip soleplate.
The standard config of CMA1625F (auto feeding machine) is No.4 control system, it
must running with computer, the working platform are vacuum adsorption
soleplate and feeding mesh belt.
The standard config of CMA2240 is No.4 control system, it must running with
computer, the working platforms are vacuum adsorption soleplate and Strip
soleplate.
Series:
CMA：CMA series
……
CMA
XXXX
X
Instructions of auxiliary
models:
F: Automatic feeding
……
Processing breadth:
1325：1300mm X 2500mm
1625：1600mm X 2500mm
1628：1600mm X 2800mm
2222：2200mm X 2200mm
2240：2200mm X 4000mm
… …

- 2 -
1.2.1Compositions of the machine
Front view of the machine is as shown in the figure below:
Fig.1-2 Front view of the machine
Back view of the machine is as shown in the figure below:
Fig.1-3 Back view of the machine
○
13
○
14
○
15
○
16
○
13 Water chiller
○
14 Air pump
○
17 Indicator
○
18 side cover of machine (each 3 at left and right)
○
15 turbine exhaust blower
○
16 Exhaust blower
○
18
○
17
○
10 Cutting table (Beehive soleplate, Strip soleplate, mesh belt)
○
1 Main unit
○
2 Electric control box
○
3 Versatile ball (some)
○
4 USB or network interface
○
5 Control panel
○
6 Footmaster caster (6 in all)
○
7 Laser power supply control cabinet
○
8 Master switch of power supply
○
9 Emergency switch (each two at front and back)
○
11 Crossbeam (X/Y movement mechanism and laser tube)
○
11
○
3
○
10
○
8
○
9
○
7
○
5
○
6
○
4
○
2
○
1
○
12
○
12 Laser cutting head

- 3 -
CMA1625 is shown as following figure:
Fig.1-4 Illustration of CMA1625
CMA1625F is shown as following figure:
Fig.1-5 Illustration of CMA1625F
CMA2240 is shown as following figure:
Fig.1-6 Illustration of CMA2240

- 4 -
Machine control is as shown in the figure below:
Fig.1-7 Illustration of machine control
1.2.2 Man-machine interface
Man-machine of CMA1325 is shown as following figure:
Fig.1-8 Man-machine of CMA1325
Man-machine of CMA1625 is shown as following figure:
Fig.1-9 Man-machine of CMA1625
Man-machine of CMA1625F is shown as following figure:
Machine structure
Movement mechanism
Blower
Control system
Optical mechanism
Air pump
Water
chiller

- 5 -
Fig.1-10 Man-machine of CMA1625F
The control panel of CMA2240 is shown as follow:
Fig.1-11 Control panel of CMA2240
1.2.3 Compositions of movement mechanism
Plane movement mechanism is composed of X-axis and Y-axis movement mechanisms in
vertical relation as shown in the figure below:

- 6 -
Fig.1-12 Illustration of movement mechanism
1.2.4 Working platform
Working platforms of NestCutting series laser machine are mainly strip soleplate or feeding
belt. Feeding belt is mainly used for placing soft materials like cloth or leather, while strip soleplate
is mainly for hard materials like organic glass or thick plank.
Fig.1-13 Working platform
Feeder mesh belt
Strip soleplate
○
7 Y-axis guide rail beam (each one at left and right)
○
11 Y-axis timing belt (each one at left and right)
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
○
9
○
10
○
11
○
1 X-axis motor
○
6 Y-axis guide rail (each one at left and right)
○
5 X-axis sensor (Reset or limit signal)
○
4 Dolly (connecting to cutting head)
○
3 X-axis timing belt
○
2 X-axis beam and guide rail
○
8 Y-axis drive shaft
○
9 Y-axis motor
○
10 Y-axis sensor (Reset or limit signal)
○
12
○
12 Support board of beam

- 7 -
1.2.5 Compositions of optical mechanism
NestCutting laser machine is single-path laser light route; the light mechanism is as
shown in the figure below:
Fig.1-14 Illustration of optical mechanism
1.2.6Brush-pencil mechanism
Some types of machine are with brush-pencil function (e.g. CMA1610ETP). The brush-pencil
mechanism is as shown in the figure below:
Fig.1-15 Brush-pencil mechanism
○
2 Electric magnet
○
1 Brush-pencil
○
3 Brush-pencil fastener
○
1 Laser tube bracket
○
2 Laser tube
○
3 Water circulation joint (an outlet and inlet)
○
4 Laser outlet
○
5 No. 1 reflector
○
6 No. 2 reflector
○
7 No. 3 reflector
○
8 Focus
○
9 Blowing pipe
○
5
○
3
○
6
○
7
○
2
○
4
○
1
○
8
○
9
○
10
○
10 Cycled cooling tube

- 8 -
1.2.7Electric dual-laser head mechanism
Some types of machine are with electric dual-laser head function (e.g. CMA2222EFT). The
structure composition of the electric dual-laser head is as shown in the figure below:
Fig.1-16 Electric dual-laser head mechanism
1.2.8 Auxiliary parts
To ensure normal operation, the laser machine needs also some auxiliary parts like blower, air
pump and water tank. Different types of machine are with different auxiliary parts, and those are
subject to the actual machine.
Fig.1-17 Auxiliary parts
○
1 Right dolly head
○
2X positive sensor block
○
3 Right laser head (Master laser head)
○
4 Z positive sensor block
○
5 Z-axis sensor
○
6 Right laser head (Slave laser head)
○
9 Z-axis motor (Left dolly head motor)
○
3
○
2
○
1
○
6
○
7
○
8
○
9
○
5
○
4
○
8 Left dolly head
○
7 X negative sensor block
Air pump
Water tank,
water pump
Blower
Air pump
Water tank,
Water pump
Blower

- 9 -
For the feeding machine CMA1625F, in order to the users to feeding conveniently, the
machine config feeding and dossal mechanism as the following figure:
Fig.1-18 Feeding stand and dossal stand
Due to the cloth is not regularity or the piece goods under the uneven power, the feeding
cloth may offset left or right, our company has collocated auto correct excursion machine to
correct excursion when feeding. The frame of correct excursion machine is shown as follow:
Fig.1-19 Auto correct excursion machine
The feeding machine (CMA1625F) has the control interface of auto correct excursion machine;
it is convenient for the users to use and control.
Feeding stand
Dossal stand

- 10 -
1.3 Machine parameters
Machine parameters quite differ from each other due to different types and configurations.
The parameters are subject to the ex-factory nameplate attached to the machine. The nameplate is
generally stuck to the back or left side of the machine. The following is a nameplate of CMA1325
type:
Fig.1-20 Machine nameplate
Instructions of each parameter on the nameplate of the machine:
Machine name: name of machine;
Machine type: type of the machine. Refer to section 1.1 in this manual for instructions of
machine type;
Laser type: laser type configured on the machine mainly including two types as CO2 and
YAG;
Laser power: Rated power of the laser machine;
Total power: the rated power during working;
Note
Feeding stand and auto correct excursion machine are not the normal
schemes; please contact our sellers to buy it if you need.
Please refer to auto correct excursion machine user’s manual about how to
use the auto correct excursion machine.
