YY-Electron Wireless Home Security Alarm System User manual

USER MANUAL
Wireless Home Security Alarm System
YY -ELECTRON.INC

Table of contents
Powering Up The Keypad/Control Unit ............................................................................................................................2
Attach Siren .......................................................................................................................................................................3
Attaching Telephone to Keypad Dialer .............................................................................................................................3
Activating Wireless Outdoor Siren. ...................................................................................................................................4
Activating Wireless Siren /w Strobe. ................................................................................................................................4
Activating Wireless Luxury out/indoor Siren w/strobe. ....................................................................................................4
Programming status ..........................................................................................................................................................5
Change Password .............................................................................................................................................................6
Activating Your Key Fob Remote. .....................................................................................................................................6
Activating Your Second Keypad. ......................................................................................................................................6
Activating Your Portable Keypad. .....................................................................................................................................7
Activating Your Panic Button .............................................................................................................................................7
Activating the Motion Detector / Pet Immune Motion Detector .........................................................................................8
Activating the Smoke Detector/Gas Detector/Glass Break Detector. ...............................................................................8
Activating the Door/Window Sensor ...............................................................................................................................10
Activating Wireless Range Bean Motion Detectors./ Wireless Bean Motion Detectors. ..............................................10
Deactivating a Sensor........................................................................................................................................................11
Deactivating All Your Key Fob Remote / Second Entry Keypad / Portable Keypad / Panic Button................................11
Deactivating All Sensors and Your Key Fob Remote / Second Entry Keypad
/ Portable Keypad / Panic Button .....................................................................................................................................11
Disable a Sensor................................................................................................................................................................11
Setting the Exit DelayTime/ Arm Delay Model. .............................................................................................................12
Setting the Entrance Delay Time/ Disarm Delay Model. ................................................................................................12
Setting Siren Sounding Time/ Silent Alarm Model. ........................................................................................................12
Phone Line Anti-Cut Monitoring. .....................................................................................................................................13
Remote Access to Keypad/Dialer. ..................................................................................................................................13
Record Message. ............................................................................................................................................................13
Play Back. ........................................................................................................................................................................13
Programming Stored Phone Numbers. ..........................................................................................................................14
Resetting Your System Functions. .................................................................................................................................14
Keypad/Controller Operation. .......................................................................................................................................15
Key Chain Remote Operation. .........................................................................................................................................15
Remote Operation by Phone............................................................................................................................................15
What to do When the Alarm Auto-Dialer call you?...........................................................................................................16
Wireless Portable Keypad Operation...............................................................................................................................16
Wireless Second Entry Keypad Operation. ....................................................................................................................17
Setting up the SIM Card ..................................................................................................................................................18
Connecting theGSM Module to the Keypad ..................................................................................................................19
Operation of GSM Terminal ..................................................................................................................20

yy-electron.inc 1

yy-electron.inc 2
Activating Sensors
Powering Up The Keypad/Control Unit
Plug power cord into keypad unit receptacle labeled “POWER
This keypad/controller has an enhancing security design with the on/off switch on the top of the
keypad/controller unit. To switch the keypad/control on and off, please press the yellow power switch all the way
down with the tip of a pen or pencil.
” and then into AC power outlet.
Special Note On Setting Up YourAlarm System:
We strongly suggest all our customers program the system and activate all sensors first. Installation of the sensors should be
done after programming process is completed.
To best prevent possible interference, please activate one sensor at a time. Please make sure while activating each sensor,
the rest of the sensors are switched off or power off.
It is preferable that the keypad power adapter be plugged into its own outlet and not share an outlet with other devices
which are potential sources of interference.
Please try to program your system in an area with the least possible interference, for example your basement or a room with
concrete walls to avoid interfering signals being accidentally programmed into the system.
The internal rechargeable system drains down during shipping so the first step in setting up is to turn on the keypad power
switch, attach and plug in the keypad power adapter and let the system recharge for 8-10 hours
The YY Alarm
Systems are designed for Wireless operation using both AC and DC [using a power inverter] power. They have
the capability to work on both 110 AC current and 220 AC current.

yy-electron.inc 3
Attach Siren
Insert plug of your wired alarm siren into" siren" receptacle on keypad/controller
Attaching Telephone to Keypad Dialer
Insert your land line into “LINE
Insert the line from your telephone into the “
” receptacle on the top of the keypad/controller.
PHONE
” receptacle on the top of your keypad.
Notice: Phone line inserted into wrong dialer phone jack may prevent accessibility of keypad/dialer from a remote location
by telephone.

yy-electron.inc 4
Activating Wireless Outdoor Siren.
A. Turn keypad/controller power switch on. Depress the
keypad “PANIC
” button.
B. Plug power cord of wireless outdoor siren into power
receptacle and then into your wall outlet. Repeat this action
until you hear “short sound”, and then you will hear “long
sound ” that indicating it has been activated. Turn keypad
power switch off.
Activating Wireless Siren /w Strobe.
Plug siren. Depress and hold black button on side of cover which will
produce light in red LED case. Depress the keypad PANIC button, and
then wait five seconds you will hear “long sound
” that indicating it
has been activated. Turn keypad power switch off .
Activating Wireless Luxury out/indoor Siren w/strobe.
Turn keypad/controller power switch on. Depress the keypad
“PANIC
” button.
Plug power cord of wireless luxury out/indoor siren w/strobe into
power receptacle and then into your wall outlet. Repeat this
action until you hear “short sound”, and then you will hear
“long sound
” that indicates the siren has been activated. Turn
keypad power switch off.

yy-electron.inc 5
Programming status
Each component of the alarm system has to be activated to become functional; all activation takes
place when the system is in Programming status ,
To place system into programming status, enter
in the keypad the factory password numbers 【 1, 2, 3, 4 , 】 and push the button 【 # 】 (you can
substitute your own password for factory default password- see page 6
). You are now in
programming status and in position to program any of the changes listed below.

yy-electron.inc 6
Changing the Password.
With your system in programming status (see page 5),enter the number below into your keypad/controller, You will
hear a double beep
sound to indicate that it has been changed.
【5 1 New Password (must be 4 digits) #】
Activating Your Key Fob Remote.
With your system in programming status
(see page 5) , push
button【study 6 4 # 】on keypad controller , and then
push any of the four buttons on your key fob remote. You will hear
two beeping sounds indicating that your remote control key fob is
now activated. Push EXIT to complete the process.
See page 15 for Key Chain Remote operation.
Activating Your Second Keypad.
With your system in Programming Status(see page 5) on keypad
controller, push button 【Study 6 4 #】on Keypad
Controller , and then push button【1 2 3 4 # 4 】on
your Second Entry Keypad
See page 17 for Second Entry Keypad operation.
. You will hear two beeping sounds
indicating that your second entry keypad is now activated. Push
EXIT to complete the process.

yy-electron.inc 7
Activating Your Portable Keypad.
With your system in programming status(see page 5),push
button 【study 64#】on Keypad Controller , and then
enter into the Portable Keypad
:【1 2 3 4 # 1 】. You will
hear two beeping sounds indicating that your Portable Keypad is
now activated. Push EXIT to complete the process.
See page 16 for Portable Keypad operation.
Activating Your Panic Button
With your system in programming status (see page 5) , push button
【study 64#】on keypad controller , and then push button on
your Panic Button. You will hear two beeping sounds indicating that your
panic button is now activated. Push button EXIT to complete the process
Note: Program motion detectors first before programming other components. After programming each
motion detector turn its power switch to “off” [turn pet immune motion detectors face down]. After
programming all of the other components then turn the motion detectors back on.
Each individual sensor (Motion detector, window/door sensor, smoking/gas detector.....) has to be individually
activated while unit is in “programming status” (see page 5).
This system is unique in letting you know exactly which sensor is setting off the alarm. Each sensor is
programmed to have its own numerical identity. To perform this activation programming, you first assign a
two digit numbers to each sensor. Window/door sensors may be assigned any number between 09 and 63;
motion detectors for any number between 01 and 05, smoke, gas detector & glass break detector for any
number between 06 and 08. These are zone numbers. You may assign up to three sensors to the same zone.
When a sensor is triggered the assigned zone number will light up on the LED screen of the keypad. It may be
helpful for you to keep a list of the areas corresponding to the assigned zones

yy-electron.inc 8
Activating the Motion Detector / Pet Immune Motion Detector
For each motion detector you use choose a number from 01 to 05
(notice: must be 2 digits)(see page 7),with your system
in programming status(see page 5), enter the number below into
the keypad/controller. In the place of {01 to 05} enter the number you
have chosen for the sensor. after the pound sign (#), you will need to
physically trigger the motion detector to activate it. On the motion
detector, switch the ON/OFF switch to the on position. Secondly,
physically move the motion detector about in front of an object as the
motion detector warms up; you will hear a double beep
sound
indicating that it has been activated. Push EXIT to complete the
process, Each motion detector has to be individually activated using this procedure.
【study (01 to 05) #】
Program Home Arm Feature for your motion. (this step is to make sure your motion detectors will be disabled when you
home arm the system).
with your system in programming status
【
7 2

(01 to 05) 3 #
】
(see page 5), enter the number below into the keypad/controller. In the place of {01
to 05} enter the number you have chosen for the motion detector
Activating the Smoke Detector/Gas Detector/Glass Break Detector.
For each smoke detector/gas detector/glass break detector you use, choose a number from 06 to 08 (notice: must be
2 digits). With your system in programming status
(see page 5), on your keypad enter the number sequence below.
In the place of In the place of {01 to 08}, enter the number you have chosen for the sensor. After entering the pound
sign (#), you will need to physically trigger the smoking/gas detector/glass break detector to activate them. Activation
will be confirmed by a double beeping sound, Push button EXIT to complete the process.
【study (06 to 08) #】

yy-electron.inc 9
A．To trigger the smoke detector, depress the clear plastic button on
the face of the smoking detector. You will hear a double beep sound
to indicate that it has been activated.
B. To trigger the gas detector, depress the white plastic button on the
face of the gas detector. You will hear a double beep
sound to
indicate that it has been activated.
C. To trigger the glass break detector, knock your glass window with
any metal. Until you hear a double beep
sound from your wireless
keypad controller to indicate that it has been activated.
Each smoke/ gas detector/glass break detector has to be individually activated using this procedure.
Program Emergency Feature for your gas detector, smoke detector & glass break detector.. (this step is to make sure these
sensors are working around the clock to protect your home and your family even when your system is not armed).
with your system in programming status (see page 5), enter the number below into the keypad/controller. In the place of {06
to 08} enter the number you have chosen for the smoking detector, gas detector, glass break detectors.
【7 2

(06 to 08) 2#】

yy-electron.inc 10
Activating the Door/Window Sensor
For each door/window sensor, choose a number from 09 to 63
(notice: must 2 digits),with your system in programming
status(see page 5),enter the number below into your
keypad/controller. In the place of {09 to 63}, enter the number you
have chosen for the sensor. after the pound sign (#),, you will need
to physically trigger the door/window sensor to activate it by bring
the magnetic bar and the sensor together and then separating them.
Activation will be confirmed by a double beeping sound. Each door/window sensor has to be individually activated
using this procedure. Push button EXIT to complete the process.
【study (09 to 63) #】
Activating Wireless Range Bean Motion Detectors./ Wireless Bean Motion
Detectors.
For each wireless range motion detector/ wireless bean motion detector you use choose a number from 09 to 63
(notice: must 2 digits),with your system in programming status(see page 5),
enter the number below into the
keypad/controller. In the place of {09 to 63} enter the number you have chosen for the sensor. after the pound sign (#),
you will need to physically trigger the wireless range motion detector/ wireless bean motion detector to activate it.
Activation will be confirmed by a double beeping sound. Push button EXIT to complete the process.
【study (09 to 63) # 】

yy-electron.inc 11
Deactivating a Sensor
With your system in programming status(see page 5),enter the number below into your keypad/controller. In the
place of {01 to 63}, enter the number you have chosen to deactivating.
【study (01 to 63) # 】
Deactivating All You r Key Fob Remote / Second Entry Keypad / Portable
Keypad / Panic Button
With your system in programming status(see page 5),enter the number below into your keypad/controller
【study 6 4 # 】
Deactivating All Sensors and You r Key Fob Remote / Second Entry Keypad /
Portable Keypad / Panic Button
With your system in programming status(see page 5),enter the number below into your keypad/controller
【study #】
Disable a Sensor
With the keypad/control panel in disarm or power off position, simply take out the batteries from those sensors you
wish to disable or switch the sensor off.
Disabling a sensor does not delete the programming codes recorded in the keypad/controller. Once batteries are
placed back or power is switched on, those sensors are still connected and controlled by the keypad/control panel.
Therefore, if you wish to use any of the disabled sensors down the road, there is no need to re-program or re-activate
that sensor.

yy-electron.inc 12
Program Functions
Setting the Exit Delay Time/ Arm Delay Model.
This function allows you to activate your system while providing you with time to exit your premises without triggering
the alarm system; you can adjust the delay time from zero (00) to thirty (30) minutes. With your system
in programming status(see page 5),enter the number sequence below, and where the {00 to 30} appears enter the
delay time you wish (up to 30 minutes).
The default factory setting for delay time is one minute.
【5 5 (00-30) # 】
Setting the Entrance Delay Time/ Disarm Delay Model.
This function allows you time to enter your premises when your alarm system is armed without triggering the alarm
system. The entrance delay time can be set from zero (00) to thirty (30) minutes. With your system in programming
status(see page 5),enter the number sequence below into your keypad. In place of the {00 to 30}, enter the delay
time (up to 30 minutes). The default factory setting for delay time is zero minute
.
【5 6 (00-30) # 】
Setting Siren Sounding Time/ Silent Alarm Model.
This function allows you to set the length of time your siren will sound; you have a range from silent alarm (00) up to
thirty (30) minutes. The factory default setting is three (01) minutes. With your system in programming status(see
page 5),enter the number below into your keypad. In place of the {00 to 30}, enter the length of siren sounding time
from zero (00) to thirty (30
) minutes.
【5 4 (00-30) # 】

yy-electron.inc 13
Phone Line Anti-Cut Monitoring.
This system is programmed with an alarm function to alert you when your phone line is cut or disconnected; this
function must be turn on to be operational. With your system in programming status(see page 5),enter the number
sequence below into the keypad. In place of the {0 or 1}, press “1” to turn on this function or “0” to turn off this
function. The default factory setting is “ 0” ( Off )
,When this function is activated and the alarm system is “armed”,
line interruption is signaled by three siren blasts at ten second intervals, followed by beeping at five second intervals.
When the alarm system is “disarmed”, line interruption is signaled by beeping at ten second intervals.
【6 2 0/1 # 】
Remote Access to Keypad/Dialer.
You may change your dialer function settings (arm, disarm, monitor) remotely by phone.
The number of times the phone rings before you are connected with the Dialer System can be preset by entering the
number sequence below into your keypad. With your system in programming status(see page 5),enter the number
below into your keypad. In place of the {00 to 12} enter the number of rings from (01) to (12). Entering (00) turns off the
remote access function.
The default factory setting is “00”(off).
【5 3 (0 0-12) # 】
Record Message.
To record your outgoing message, while in programming status (see page 5), press: rec + # and record your
message for a maximum of 10 seconds.
【REC # 】
Play Back.
To play back recorded message, enter the sequence code below,After entering the pound sign (#), pick up the phone
receiver to hear the message.
【REC 】

yy-electron.inc 14
Programming Stored Phone Numbers.
To program your dialer with the phone numbers you want called when the alarm is triggered (up to six numbers), enter
the number sequence below into your keypad. In place of the (enter phone number), enter the phone number that you
want called when the alarm is triggered. If your calling location requires a calling prefix (e.g. New York requires you to
dial 1 first), enter the prefix along with your phone number.
If you want to change any stored phone number, re-enter the sequence code for that number and enter the new
number; you do not have to delete the old number as the system will automatically replace it with the new number.
【41 (Phone Number) # 】
【42 (Phone Number) # 】
【43 (Phone Number) # 】
【44 (Phone Number) # 】
【45 (Phone Number) # 】
【46 (Phone Number) # 】
Resetting Your System Functions.
Please press the “# key” and the “power button” (the one on the top of the keypad in Blue color) at the same time.
Hold them for 2-3 seconds until on the keypad/control panel, the “arm”, “away” and “home” all 3 lights are flashing then
let go of “# key” & “power button”. You will see on the keypad/control panel something look like a pair of parenthesis
appears. Then turn the keypad/control panel off (by pressing the little blue power button again).
Once the above step is performed, turn it on. Use the factory default admin password “1234” and just simply
re-program each and every component.
Please try to program your system in an area with the least possible interference, for example your basement or a room with
concrete walls to avoid interfering signals being accidentally programmed into the system.

yy-electron.inc 15
Operation
Arm Function: all sensors are active.
Home Arm Function: all sensors are active except motion detectors.
Keypad/Controller Operation.
To arm the alarm system:
Press button【AWAY 】The default factory setting for Arm delay time is one minute
To home arm the alarm system:
( see page 12 )
Press button 【HOME 】
To disarm the alarm system:
Press button【Password + DISARM 】
For emergency:
Press button【PANIC 】
Key Chain Remote Operation.
To arm system; press the “lock” button
To disarm system; press the “unlock” button.
To home arm system: press the “house” button.
For emergency; press the “alarm” button
Remote Operation by Phone.
Dial the phone number that is connected to your alarm system and after approximately 8 rings (the number of rings
can be changed: see page 13 “Remote Access to Keypad / Dialer ”), you will hear two Beeping sounds. That is the
signal to enter the password + #.
This will be followed by two beeping sounds. Follow the beeps by entering the
number of the function you want to activate:
To arm system: press number: “1”
To disarm system: press number: “2”
To monitor your home: press: “”, this allows 30 seconds of listening time; press “” for an additional 30
seconds.
To exit: press “#”

yy-electron.inc 16
When you have an answering machine on the same line as your alarm system
you have a basic conflict since both programs are designed to receive phone calls. Unless you want to
have a phone line dedicated solely to your Alarm System you will need a way for the two to share the
phone line and we have found ‘taking turns’ to work best. There is no conflict with the alarm system
calling out to you and when it does you can disarm/re-arm on the phone and monitor your premises.
The problem is calling into your system. Usually an answering machine is called into service to receive
calls more frequently than an alarm system is being called into so we recommend that when you need
to cal
l into your alarm system you first call in to turn off your answering machine and when you have
finished calling into your alarm system then you call to turn your answering machine back on.
What to do When the Alarm Auto-Dialer call you?
When you receive the recorded message from your alarm system you have three options:
Press “” This allows you to monitor your premises for 30 seconds. You can press “” again for an additional
30 seconds.
Press “#” This allows you to turn off the automatic calling system. If you do not turn off. The system will
continue dialing all of your stored phone numbers.
Handing up phone. System will proceed to dial the next stored numbers. While the system is dialing through
the stored number you cannot call in to your phone.
While the system is dialing through the stored numbers, your land line is in use. You will not be able to use it until the
auto-dialer stops calling.
Wireless Portable Keypad Operation.
Activating Wireless Portable Keypad.
With your system (wireless keypad/controller)
in programming status(see page 5),push button 【study
6 4 #】on keypad controller , and then enter into
the portable keypad
:【1 2 3 4 # 1 】. You will hear
two beeping sounds indicating that your Portable Keypad is
now activated. Push EXIT to complete the process

yy-electron.inc 17
Change Portable Keypad Password, Press the follow button below on wireless portable keypad.
【Password (factory password is 1234) # new password (must 4 digits) # 】
To arm the alarm system: Press the follow button below on wireless portable keypad.
【Password (factory password is 1234) # 1 # 】
To home arm the alarm system: Press the follow button below on wireless portable keypad.
【Password (factory password is 1234) # 2 # 】
To disarm the alarm system: Press the follow button below on wireless portable keypad.
【Password (factory password is 1234) # 3 # 】
For Emergency: Press the follow button below on wireless portable keypad.
【Password (factory password is 1234) # 】
Resetting Wireless Portable Keypad. Press the follow button below on wireless portable keypad.
【0 0 0 0 # 】
Wireless Second Entry Keypad Operation.
With your system in Programming Status(see page 5)
on keypad controller, push button 【Study 64
#】on Keypad Controller , and then push button【1
2 3 4 # 4 】on your Second Entry Keypad
. You
will hear two beeping sounds indicating that your second
entry keypad is now activated. Push EXIT to complete
the process.
Change Second Entry Keypad password. Press the follow button below on Second Entry Keypad.
【1 2 3 4 (factory password) new password (must 4 digits) # 】
Operation.
Arm : 【password # 1 】
Home Arm: 【password # 2 】
Disarm: 【password # 3 】
Help: 【password # 4 】

yy-electron.inc 18
Cellular GSM Security Alarm Systems
The YY alarm Systems are designed for Wireless operation using both AC and DC [using a power inverter] power. These alarm
system work with landline, online and cellular telephonic net works. The core elements of the Cellular GSM Security Alarm
Systems consist of the Keypad/Control unit (with 12 volt power adapter) and the GSM Terminal Module (with 12 volt power
adapter). Both Keypad and Terminal incorporate built-in battery back-up power systems for continuous operation during
power failure
The Keypad contains an integrated automatic dialer with the memory capacity to store six phone numbers (up to 21 digits long)
and a recorded message; it has a built-in back-up battery power supply system. All sensors and sirens are activated by entering
a code into the keypad; follow Alarm System User Manual for instructions on setting up the Alarm System. The Keypad must
be connected to an AC power source or to a DC power source at all times to assure continuous and stable operation. [Ignore
all references to “landline” in the User Manual which do not apply to the Cellular GSM System].
The GSM Terminal is a Fixed Single SIM Card GSM Terminal with the capability to operate on all world cellular band frequencies.
This Terminal replaces a landline and allows the Keypad’s automatic dialer to dial out the pre-stored phone numbers to deliver
the pre-recorded message to the intended recipient. The GSM Terminal functions like a mobile phone.
The GSM Terminal requires a SIM card to connect to the cellular network just as many mobile phones do [Verizon and Sprint do
not use SIM cards]. SIM cards may be purchased from any Cellular company such as AT&T or T-Mobile as part of a monthly plan
or as a prepaid card with a specific amount of time [e.g. 60 minutes]. When purchasing a card specify to the dealer that you
would like the card to work with all cellular devices [it should be ‘unlocked’ ].
Setting up the SIM Card
The SIM card slides into the SIM card holder located on the back of the GSM Terminal. The following pictures illustrate
insertion of the SIM card:
