Outdoor Wireless Acousto-optic Siren
ST -6107W
* This product is a networking accessory that needs to be used with the
company's gateway

—1—
Outdoor Wireless Acousto-optic Siren User’s Manual
1. Brief Introduction
The outdoor wireless acousto-optic siren adopts 8 bit MCU technology, built-in 48 LED lights, 2
wired zone Interfaces, 2 120dB buzzers and 1 built-in 12V/1.2A Lead-acid battery. The outdoor wireless
acousto-optic siren not only can connect with the alarm host via wireless transmission, but also can be
used as an alarm host and a repeater. It is widely used in banks, shops and villas etc.
When the outdoor wireless acousto-optic siren works with wireless alarm host by wireless
transmission, alarm host can input the outdoor wireless acousto-optic siren address, or directly learning
with the outdoor wireless acousto-optic siren. The outdoor wireless acousto-optic siren’s tamper alarm,
AC information, battery voltage information are all transmitted to the alarm host via wireless signal.
Then the alarm host notifies the user about the alarm information via SMS, center and voice.The
outdoor wireless acousto-optic siren also can indicate alarm host arm / disarm status.
Users can buy the relative remote controls and detectors according to their demand when the
outdoor wireless acousto-optic siren is used as the alarm host. It can connect with these wireless
accessories and become a powerful independent alarm system.
The outdoor wireless acousto-optic siren can also be used as a repeater, which can increase the
wireless launch distance effectively.
2. Function Features
◆Used as a repeater, it can transmit 32 wireless accessories.
◆3 colors of indicator lights flashing modes. ( Red/ Blue/ Red+Blue )
◆Design for preventing the siren being removed maliciously .
◆Acousto-optic notice when operating Arm /Disarm.
◆Status reports including the alarm from siren itself, tamper alarm, alternating current information and
battery voltage.
◆Support 8 remote controls, 32 detectors.
◆Built-in 2 NC type wired zone interfaces. Zone No.1 for 24 hours defend and zone No.2 for burglar
defend.
◆Two optional ways to pair: wireless pair and inputting siren numbers to pair.
◆Optional acousto-optic alarm notice when A/C is off.
◆Optional light alarm notice on standby status.
◆120dB alarm sound, flashing lights, a strong deterrent.
◆Built-in 12V/1.2A Lead-acid battery, up to 24 hours of sand-by time
◆Built-in balance device, convenient to install in horizontal direction.
3. Interface definition

—2—
3.1 Siren Setting
①Report transfer
REP_ON: Reports of the wireless siren will be transferred to the panel.
REP_OFF: Reports of the wireless siren will not be transferred to the panel.
② LED light
12L: 12 LED lights flashing 24L: 24 LED lights flashing
③ AC power failure alarming
ON: Alarm sound with light prompt when AC is off OFF: No alarm notice when
AC is off
④ Types of alarm voice
1T: Only 1 voice when alarming 6T: 6 kinds of voice when
alarming
⑤ Alarm time
30S: 30 seconds of alarm sound 3MIN: 3 minutes of alarm sound
⑥ Light notice when standby status
LED_ON: Light alarm notice when siren is in standby status
LED_OFF: No light hint when the siren is in standby status
3.2 Power light
Long ON: Alternating Current is normal Light OFF: Battery-Powered
3.3 Working Mode
Blue: The indicator light is blue Red: The indicator light is red
RED/BLUE:Wireless siren indicate light is red and blue
3.4 Status Lights
① Blue
Light OFF: The outdoor wireless acousto-optic siren/ the alarm host is at disarm or
unknown status.
Flashes once every three seconds: The outdoor wireless acousto-optic siren/ the alarm host
is at arm status.
Fast Flashing: The outdoor wireless acousto-optic siren/ the alarm host is alarming.
② Red
Light OFF: The outdoor wireless acousto-optic siren/ the alarm host is at disarm or
unknown status.
Flashes once every three seconds: The outdoor wireless acousto-optic siren/ the alarm host
is at arm status.
Fast Flashing: The outdoor wireless acousto-optic siren/ the alarm host is alarming.
③ Red+Blue
Blue lights fast flashes 4 times every second: The outdoor wireless acousto-optic siren/ the
alarm host is at disarm or unknown status.
Red lights fast flashes 4 times every second: The outdoor wireless acousto-optic siren/ the
alarm host is at arm status.
Alternately flashes blue and red lights: The outdoor wireless acousto-optic siren/ the alarm
host is alarming.
3.5 Transmitting Mode
ON: Turn on transmitting mode OFF: Turn off transmitting mode
Note: Checking AC power outages need to take 20 seconds of checking time.

—3—
4. Operation Instruction
4.1.Remote Control
4.1.1. Enroll Remote Control
Step1: Under the normal status without alarm event, long press “SET” button with 3s until heard a
short “Di” and address “E1” will be shown in LED, then user can start to enroll remote control. The
current address in LED refers to the current remote control to be enrolled.
Step2: If user wants to enroll the next address“E2” please press “NEXT” button to the next one,
the same as E3,E4...
Attention: If the current address in LED is flashing, it means the current remote control has not
been enrolled and user can press any button of remote control to enroll. If enrollment succeeded, the
siren will prompt a short “Di”, meanwhile address in LED will turn flashing into long bright, it means
remote control enrollment succeed. If the current address in LED is long bright, it means the current
address has been already enrolled. User should delete previous one to re-enrolling. If heard 1 long “Di”,
it means the remote control has already been enrolled.
4.1.2. Delete Remote Control
In remote control enrolling status, press “ NEXT ” button with 3s to delete the existing remote
control. After user heard 2 short ” Di ” from siren and the indicator turned long bright into flashing,
deletion is successful.
4.1.3. Exit Remote Control Enrollment
In remote control enrolling status, short press “SET” button twice to exit.
4.2.Detector
4.2.1.Enroll Detector
Step1: Under remote control enrolling status, short press “SET” button once, then siren enters the
detector enrollment. The address“01”in LED refers to the current zone to be enrolled.
Step2: If user wants to enroll the next address“02”, please short press “NEXT” button to the 2nd
zone, the same as 03,04...
Attention: If the current address is flashing, it means the current detector has not yet been enrolled
and user can enable detector to transmit alarm signal to be enrolled. If enrollment succeeded, siren will
prompt a short “Di”, meanwhile address in LED will turn flashing into long bright, it means successful
enrollment of detector. If the current address in LED is long bright, it means the current address has
been already enrolled. User should delete previous one before re-enrolling. If heard 1 long “ Di ” , it
means the detector has already been enrolled.
4.2.2.Delete Detector
In detector enrolling status, press “NEXT” button with 3s to delete the existing detector. After user
heard 2 short ”Di” and the indicator turned long bright into flashing, deletion is successful.
4.2.3.Exit Detector Enrollment
In detector enrolling status, short press “SET” button once to exit.
4.3.Arm/disarm prompt mode setting
Under the detector enrollment mode, short press the "SET" key once, the siren enters the
arm/disarm prompt setting(the digital tube display shows its mode), then short press the "NEXT" key to
enter the next mode,
if the display showed “0”,means indicating "No light prompt”but with "Sound prompt";

—4—
display 1, indicating "Light prompt”, with "Sound prompt";
display 2, indicating "Light prompt", "No sound prompt";
display 3, indicating "No light prompt", "No sound prompt";
Exit "Arm/disarm prompt mode"
In the setting state of the arm/disarm prompt mode, short press the "SET" key once to exit the
detector code matching state.
4.4.Enroll Siren
Under siren standby status, short press “ENROLL” button once, siren will emit wireless enrolled
signal to host, then alarm host enter siren enrolled status, when user hear a short “DI” from alarm host,
it means siren enrollment succeed.
4.5. Repeater
4.5.1 Enroll Repeater
Step1: Long pressing “SET” and “NEXT” buttons for 3 seconds at the same time, after hearing a
short “ Di ” , the siren enters the detector enrollment. The address “ 01 ” in LED refers to the current
detector which need be transmitted is enrolled.
Step2: If user wants to enroll the next address“02”, please short press “NEXT” button to the 2nd
detector, the same as 03, 04...
Attention: If the current address is flashing, it means the current detector has not yet been enrolled
and user can trigger the detector. If enrollment succeeded, siren will prompt a short “Di”, meanwhile
address in LED will turn flashing into long bright, it means successful enrollment of detector. If the
current address in LED is long bright, it means the current address has been already enrolled. User
should delete previous one before re-enrolling. If heard 1 long “Di”, it means the detector has already
been enrolled.
4.5.2.Delete Repeater
In repeater enrolling status, press “NEXT” button with 3s to delete the existing repeater. After user
heard 2 short ”Di” and the indicator turned long bright into flashing, deletion is successful.
4.5.3.Exit Repeater Enrollment
In repeater enrolling status, short press “SET” button once to exit.
4.6.Copy the siren address
4.6.1. Copy the siren address
Press “ENROLL” and “NEXT” button for 3s, until one short “DI”. Which means enter the copy siren
address status, and the digital tube shows “b1”. If “b1” flashing, it means the factory siren address.
Then long press “ENROLL”button,at the same time short press the “ENROLL” button of the siren you
want to copy. If copy successfully the siren will, prompt one short “DI”, and “b1” will stop flashing into l
ong bright, that the transponder replication is successful. IF “b1” long bright, indicating the current addr
ess of the siren has been copied, the user have to delete first and then do the copy again.
4.6.2 Delete copied siren address
At the copy siren address status, long press “NEXT” button for 3s, to clear the copied siren addres
s and reset to, factory address. Two “Di” will prompt and “b1” indicator change from long bright to flash,
indicating delete successfully.
4.6.3. Exit the copy siren address
At the copy siren status, short press “SET” one time, will exit the copy status.

—5—
4.7. Recovery Factory Default
After the outdoor wireless acousto-optic siren power on, long press “SET” and “ENROLL” , until
hear 2 short “DI” , It means that the siren has been back to factory default.
5. Technical parameter
Size specification: 320mm*213mm *94mm * (length * width *thickness)
Working voltage: DC 15V
Battery: 12V/1.2Ah
Standby current: <35mA/15V
Alarm current: < 400mA/15V
Siren alarm sound: >120dB
Wireless receiving frequency:433.92MHz
Use environment: working temperature -20℃~ +55℃relative humidity 40 ~ 80%
Wireless receiving frequency:433.92MHz
Wireless transmitting distance:≥ 450 Meter (open area)
Wireless receiving distance:≥ 450 Meter (open area)
