Z-Wave T100R User manual

DCN: 140-01773-01 Page 1
Installation Guide
Model T100R
Z-Wave Thermostat
This thermostat is compatible with most HVAC systems, including the following:
24VAC systems Note: requires both the 24R and 24C (common) wires
Standard gas/oil/electric heating systems
o1 stage heating and cooling
o2 stage heating and cooling
Heat Pump systems:
o1 stage heating and cooling
o2 stage heating and cooling
o2nd or 3rd stage Auxiliary heating (heat strips)
Do NOT use for line voltage controls (120/240VAC)
Stop! Before removing your existing thermostat, be sure to label the
wires with the terminal markings on the old thermostat and record them
below.
Standard HVAC System Wiring
Terminal
Marking Meaning Typical Wire Color Record the old thermostat wire connections and terminal
marking here
C
24VAC Common Blue
R
24VAC Return Red
G
Fan Green
W or W1
Heat stage 1 White
Y or Y1
Cool stage 1 Yellow
W2
Heat stage 2 Orange
Y2
Cool stage 2 Black
Heat Pump HVAC System Wiring
Terminal
Marking Meaning Typical Wire Color Record the old thermostat wire connections and terminal
marking here
C
24VAC Common Blue
R
24VAC Return Red
G
Fan Green
W or W1
Aux Heat White
Y or Y1
Compressor stage 1 Yellow
O (or B*)
Change Over Valve Orange (brown*)
Y2
Compressor stage 2 Black
* if you have a terminal marked “B” with a brown wire attached to it, that means you have a
changeover (C/O) with heating type heat pump system. Be sure to set the change over
type in the Installer Settings menu to C/O Type: w/Heat. Otherwise leave it set to
w/Cool.

DCN: 140-01773-01 Page 2
INSTALLATION
HVAC System Setup
The thermostat requires that you setup the type and configuration of your HVAC system for
proper operation. This is done in the Thermostat Info screen Setup button or the Installer
Settings screen on the thermostat. The Installer Settings is a hidden screen. To access it,
press the main menu button and when the main menu screen appears, press and hold the
middle two buttons for 5 seconds.
Thermostat Main Menu
Installer Settings screen
Installer Settings
Before operating the system, you must configure the thermostat for the correct HVAC
system type. You will need to know the following information to correctly configure the
thermostat. The HVAC setup is in the Mechanical Settings menu screen.
HVAC system type: What type HVAC system do you have? Standard or Heat pump
For Standard systems: Fan Type: Do you have Gas heat or Electric heat?
For Heat Pump systems: Change over valve (or reversing valve) type: Does your system
change over with cooling operation or with heating operation? Check your existing
Press and hold two middle buttons to enter the Installer Settings screen
75
Done Select
Display Lock N
Service Mode
System Settings
Max Heat SP 90
Installer Settings
+_
75
Done Select
User Settings
Away Setpoints
ZWave Install
Thermostat Info
Menu Selection

DCN: 140-01773-01 Page 3
thermostat connects to help determine this. If the original system had an orange wire
connected to an “O” terminal, then you have a “changeover with cool” system. If you have
a brown wire connected to the “B” terminal, then you have a “change over with heat”
system.
Installer Settings Menu items
Display Lock Range: Y or N Default: N
Y = Display LOCKED
N = Display unlocked
Allows you to lock or unlock the thermostat buttons. When the buttons are locked, you can
still access the main menu, but you will not be allowed to select any menu options. The
Installer Settings hidden button operation is always operational, allowing you to return to
this screen and turn Display Lock off.
Service Mode
Test Mode Range: Y or N Default: N
Y= Test mode on. Reduces all delays to 10 sec for quicker system testing
N= Test mode off. Normal system delays
CAUTION: in test mode all system safety delays are shorten. Do not operate the
system compressor in test mode. Disconnect Y1 or Y2 outputs if using test mode
on a live system.
System Settings Submenu: Sets the HVAC operational settings below
Mechanical Settings Submenu: Sets HVAC system type and configuration
Type Range: Gas/Elec or Heat pump Default: Gas/Elec
Selects HVAC type, Gas/Electric or Heat pump
Fan Type Range: Gas or Elec Default: Gas
Selects the Fan type if system is Gas or Electric
C/O Type Range: w/Cool or w/Heat Default: w/Cool
Selects the Heat Pump Changeover Valve type
2nd Stage Heat Range: Y or N Default: N
Enables the 2nd Stage Heat operation
Aux Heat (HP) Range: Y or N Default: Y
Enables the Auxiliary Heat operation. Typically the Aux Heat will be heat-strips in a Heat
Pump system
2nd Stage Cool Range: Y or N Default: N
Enables the 2nd Stage Cool operation
Schedule Enable Range: Y or N Default: N
When enabled, the local thermostats scheduler function is enabled.
Recovery enable Range: Y or N Default: N
For Heat Pump Systems. Intelligent setback recovery is an automatic advance start of
heating to allow the system to be at setpoint by the schedule time, without the use of Aux
heating.

DCN: 140-01773-01 Page 4
Delta Settings : The Delta T Setting is the delta, or difference between, the setpoint and
current temp for determining when a heat or cool call comes on. The “delta” is the number
of degrees away from setpoint.
H/C Delta Range: 3 - 15 degrees. Default: 3F (1C)
Sets the minimum separation between heating and cooling setpoints. Attempts to lower
the cooling below the heating setpoint by this amount will PUSH the heating setpoint down
to maintain this separation. Same for setting the heating setpoint above the cooling
setpoint, it will PUSH the cooling setpoint up to maintain this separation.
Heating Delta Stage 1 ON Range: 1 to 8 degrees Default: 1
Sets the delta from setpoint that stage 1 heating starts.
Heating Delta Stage 1 OFF Range: 0 to 8 degrees Default: 0
Sets the delta from setpoint that stage 1 heating stops. Stage 1 turns off at setpoint
+ Delta Stage 1.
Heating Delta Stage 2 ON Range: 1 to 8 degrees Default: 2
Sets the delta from setpoint that stage 2 heating starts.
Heating Delta Stage 2 OFF Range: 0 to 8 degrees Default: 0
Sets the delta from setpoint that stage 2 heating stops. Stage 2 turns off at setpoint
+ Delta Stage 2.
Heating Delta Stage 3 ON Range: 1 to 8 degrees Default: 3
Sets the delta from setpoint that stage 3 heating starts.
Heating Delta Stage 3 OFF Range: 0 to 8 degrees Default: 0
Sets the delta from setpoint that stage 3 heating stops. Stage 3 turns off at setpoint
+ Delta Stage 3.
Cooling Delta Stage 1 ON Range: 1 to 8 degrees Default: 1
Sets the delta from setpoint that stage 1 cooling starts.
Cooling Delta Stage 1 OFF Range: 0 to 8 degrees Default: 0
Sets the delta from setpoint that stage 1 Cooling stops. Stage 1 turns off at
setpoint - Delta Stage 1
Cooling Delta Stage 2 ON Range: 1 to 8 degrees Default: 2
Sets the delta from setpoint that stage 2 cooling starts.
Cooling Delta Stage 2 OFF Range: 0 to 8 degrees Default: 0
Sets the delta from setpoint that stage 2 Cooling stops. Stage 2 turns off at
setpoint -Delta Stage 2.
Max Heat SP Range: 40F to 109F (4C-43C)Default: 90F (32C)
Sets the maximum heating setpoint value. Will not ramp or accept setpoints higher that
this maximum.
Min Cool SP Range: 44F to 113F (6C-45C)Default: 60F (15C)
Sets the minimum cooling setpoint value. Will not ramp or accept setpoints lower than this
minimum.
Minimum Run Time (MRT) Range: 1- 9 Minutes Default: 3
Sets the minimum run time before a heating/cooling cycle can turn off.
Sets heating/cooling cycle time. Prevents rapid cycling.
Minimum Off Time (MOT) Range: 5-9 Minutes Default: 5

DCN: 140-01773-01 Page 5
Sets the minimum off time before another heating/cooling cycle can begin. Provides
compressor short cycle protection.
Temp Response Range: 1-6 Default: 2
Adjust the temperature sensor sensitivity. Sets how fast the sensor responds to change.
Fan Cycler
The fan cycler function cycles the HVAC system fan for an ON period followed by an Off
period continuously. Used to provide minimum air ventilation requirements. When the Fan
ON time is set to a value greater than 0, an additional “Cycler” FAN mode is present when
pressing the FAN button.
Fan ON Time Range: 0-120 minutes Default: 0 (=OFF)
Fan OFF Time Range: 10-120 minutes Default: 10
Restore Defaults Range: Yes, No Default: No
Restores all settings to factory defaults.
Press Yes to restore defaults,
Press No to exit and not restore defaults
Relay Status Display the status (on/off) of the thermostat output relays

DCN: 140-01773-01 Page 6
Installer Settings Summary
Setting Range Default
Display Lock Y or N N Locks out front buttons
Service Mode Submenu Test Mode Y or N N Reduces delays for testing
System Settings Submenu
Mechanical Settings Submenu Sys Type Std or HP Std
Fan Type Gas or Elec Gas
C/O Type w/Heat or w/Cool w/Cool
2
nd
Stage Heat Y or N N
Aux Heat Y or N Y
2
nd
Stage Cool Y or N N
H/C Delta 3 – 15 deg 3
Heat Delta Stage 1 On 1 – 8 1
Heat Delta Stage 1 Off 0 – 8 0
Heat Delta Stage 2 On 1 – 8 2
Heat Delta Stage 2 Off 0 – 8 0
Heat Delta Stage 3 On 1 – 8 3
Heat Delta Stage 3 Off 0 – 8 0
Cool Delta Stage 1 On 1 – 8 1
Cool Delta Stage 1 Off 0 – 8 0
Cool Delta Stage 2 On 1 – 8 2
Cool Delta Stage 2 Off 0 – 8 0
Max Heat SP 40-109F (4-42C) 90F
Min Cool SP 44-113F (6-45C) 60F
Min Run Time 1-9 min 3
Min Off Time 1-9 min 5
Temp Response 1-6 2
Fan Cycler Submenu Fan Cycler ON time 0 – 120 min 0 0 = Fan Cycler OFF
Fan Cycler Off Time 10 – 120 min 10
Restore Defaults Yes or No No Exit = no
USER SETTINGS
Filter Service Submenu Service Interval Disabled, 100-4000 hrs 300
Maint Service Submenu Maint Interval Disabled, 100-4000 hrs 3000
Screen Timeout (to minimized screen) 0, 20-120 sec 0 0 = off , will not timeout
F/C Mode F or C F
Sensor Calibration Submenu Internal -7 to +7 0
Backlite/Display Submenu
Backlight Timeout 0, 20-120 0 0 = backlite off
Backlight On Brightness 0-100% 100%
Backlight Off Brightness 0-100% 0%
Contrast 0-20 14

DCN: 140-01773-01 Page 7
Standard HVAC System
G Fan
W1 Heat Stage 1
Y1 Compressor Stage 1
R 24VAC Return
C 24VAC Common
Thermostat Connection
Y2 Compressor Stage 2
W2 Heat Stage 2
Optional 24R Connection for single transformer HVAC Systems
RC and RH are jumpered together on thermostat board.
Cut RC/RH jumper JP1 for separate heating & cooling transformers
Y1
G
Y2
RS2
RS2
RSC
HC
Standard Gas/Electric HVAC System Wiring
Thermostat Setup:
Standard Gas/Electric HVAC Systems
To set the HVAC system type, go to the Thermostat Info screen
and press Setup button
1. Type. Set the HVAC System Type: set to Gas/Elec
2. Fan Type. Set the HVAC Fan Type:
Set to Gas for typical gas furnace (fan is controlled by the furnace)
Set to Elec for electric heat (fan call with heat call)
3. C/O type. Not used for standard systems. Ignore this setting.
4. 2nd Stage Heat. Enable second stage heating outputs
If you have a single stage heating system, leave this set to N
If you have a 2 stage heating system, set to Yto enable.
5. Aux Heat (HP). Not used for standard systems. Ignore this setting
6. 2nd Stage Cool. Enable second stage cooling outputs
If you have a single stage cooling system, leave this set to N.
If you have a two stage cooling system, set to Yto enable.
24
R
C
W1
24RH
W2/O
RS1
RS1
RSC
H1
24C
Cooling 24V
Fan
Cooling stage 1
Cooling stage 2
Remote Sensor 2
Remote Sensor 2
Sensor shield
Humidity Relay Com
24VAC Com
24V Heating
Heating stage 1
Heating stage 2
Remote Sensor 1
Remote Sensor 1
Sensor shield
Humidity Relay
Remote Outside Sensor Remote Indoor Sensor
Shielded cableShielded cable
* Not used on this version
See Humidity enabled Product TZB45H
Default Setup:
Gas/Elec
Gas Heat
1 Stage heating
1 Stage cooling
No setup required for
this configuration
Thermostat back
*
*

DCN: 140-01773-01 Page 8
Heat Pump HVAC System
Thermostat Connection
G Fan
W1 Aux Heat
Y1 Compressor Stage 1
R 24VAC Return
C 24VAC Common
Y2 Compressor Stage 2
O Change Over Valve
For Heat Pump systems, connect the 24R connection
to either the 24RC or 24RH
Y1
G
Y2
RS2
RS2
RSC
HC
Heat Pump HVAC System Wiring
Thermostat Setup:
Heat Pump HVAC Systems
To set the HVAC system type, go to the Thermostat Info screen
and press Setup button.
1. Type. Set the HVAC System Type: set to Heat Pump
2. Fan Type. Automatically set for heat pump systems. Ignore this setting.
3. C/O type. Change Over (reversing) Valve Type. Heat pumps change from heating to cooling by reversing operation.
You must configure the thermostat’s changeover valve setting to work correctly with your HVAC system.
Check your system information to be sure and note the color of original thermostat wire and the terminal it was connected to.
No matter what the old stat connection was (O or B), connect the wire to the thermostats W2/O terminal.
The setting of the C/O Type will set the correct system operation.
For change over with cool systems (Orange wire, O terminal): set C/O type to w/cool (most common and default setting)
For change over with heat systems (Brown wire, B terminal): set C/O type to w/heat
4. 2nd Stage Heat. Enable second stage heating outputs
If you have a single stage heating system, leave this set to N
If you have a 2 stage heating system, set to Yto enable.
5. Aux Heat (HP). If you have auxiliary heat strips, set this to Y to enable.
6. 2nd Stage Cool. Enable second stage cooling outputs
If you have a single stage cooling system, leave this set to N.
If you have a two stage cooling system, set to Yto enable.
24
R
C
W1
24RH
W2/O
RS1
RS1
RSC
H1
24C
Cooling 24V
Fan
Cooling stage 1
Cooling stage 2
Remote Sensor 2
Remote Sensor 2
Sensor shield
Humidity Relay Com
24VAC Com
24V Heating
Aux Heating
Change Over Valve
Remote Sensor 1
Remote Sensor 1
Sensor shield
Humidity Relay
Remote Outside Sensor Remote Indoor Sensor
Shielded cableShielded cable
Thermostat back
Note! If you get heating
when you expected cooling,
change the C/O type to the
opposite setting.
*
*
* Not used on this version
See Humidity enabled Product TZB45H
