ZAFFER MULTI TIMER User manual

zAffer®
multi timer
16 ChAnnels
with time setting
Patented Technology
Belgium - Version: 1.3
( NL-FR ) - 2014

Timer off / On
Up Time
Down Time
Timer On
Timer OFF
Position
Multi Timer
Down
Stop
Up
Timer ON
Time
16 channel remote controller with
timer option

Kanaal indicator op scherm.
Indicateur de canal sur l’écran.
Channel indicator displayed.
Channel selection
Weergave locatie rolluik op scherm.
Location du volet indiquée sur l’écran.
Shutter location displayed.
Location
«Alle rolluiken» Toets voor
globale bediening.
Bouton «Tous volets» pour
commande globale.
«All shutters» button for global command.
All shutters
« Lage batterij » indicator.
Indicateur de niveau « faible batterie ».
« Low battery » indicator.
Low Battery

1
2

Download and instal zaffer soft from www.zaer.be
Windows based PC. (Windows XP, Windows Vista, Windows 7)
Time zone setting
Please connect your device
USB
A.
B.
C.
D.
Time zone (select from list)
Country (select from list)
City (select from list)
Date - Time
Updated from computer automatically
Click send to device button
To nish
Changing shutter name

Timer setting
Click send to device button
To nish
F.
Week day select from list
B.
E.
To Clear select empty line from list
Clear :
Up time type time HH-MM or select from list C.
Down time type time HH-MM or select from list
D.
Shutter with
time setting
have this icon
Shutter
A. select
from list

Pairing with the zaer motor only for installer
1.
2.
Click
Enter Password
3.
4.
Motor number
Enter motor number
Paswoord vereist voor inbreng of aanpassing motornummers (alleen voor professionelen).
Mot de passe requis pour encoder ou adapter des numéros de moteur (seulement pour professionnels).
Password required for input and modication motor numbers (only for professionals).
!
Click send to device button
To nish

Power input : Power input : 1,5 V dc with 2 X AA batt.
Frequency : 433 MHz.
Working temperature : -20°C + 55°C
Radiated power : Estimed at approx. 1mW
IP : 40
Zaffer B.v.b.a reserves the right to modify
its products without any notice.
CE Declaration of Conformity
ZAFFER B.v.b.a - Weiveldlaan 41 B-1930 Zaventem Belgium, declares that the product.
ONE, meet the essential requirements of the R&TTE directive 1999/5/EC for the intended use of the devices.
Note: A copy of the original declaration of conformity for each product can be requested from ZAFFER Bvba.
CAUTION RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS

© Copyright ZAFFER / www.zaer.be
www.zaffer.be
mini
multi
multi timer
code clw
tiimer one
