ZALMAN ZM600-GVM User manual

User's Manual
www.ZALMAN.com
※ To ensure safe and easy installation, Please read the following precautions.
ZM500/600/700-GVM
Dual Forward Switching
Power Supply
Ver.150813
All manuals and user guides at all-guides.com
all-guides.com

11
Power Supply
AC Power Cord
Four Screw Five Cable Tie
User's Manual
1. Warnings and Safety Precautions
2. Components
▶ Opening the cover of the product while the power cord is plugged into an outlet
may cause electrocution or critical damage to the product.
▶ Handling the power cord with wet hands may cause electrocution.
▶ Inserting 󰘰ngers or metallic objects into the cooling fan may cause injury or
electrocution.
▶ Operating the product in an extremely cold or hot environment can degrade
product performance and lifespan.
▶ Exposure to liquids may cause malfunction.
▶ Operation in a humid or non-ventilated environment may reduce product lifespan.
▶ Plugging the main power connector P1 into the motherboard while the product is
connected to the AC power source may cause damage to the motherboard.
▶ Make sure that the connectors are connected to their designated locations, and
that the connectors are not oriented in the wrong direction when connecting the
DC output connectors.
▶ Please use gloves to prevent injuries during installation.
▶ Product designs and speci󰘰cations may be revised without prior noti󰘰cation to
improve quality and performance.
Neglecting the following may cause serious injury or death.
Neglecting the following may cause minor injuries, degrade product
conditions or cause malfunction.
Caution
Warning
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external
causes, including but not limited to, improper use, problems with electrical
power, accident, neglect, alteration, repair, improper installation, or
improper testing.
All manuals and user guides at all-guides.com

22
3. Speci󰘰cations
1) ZM500-GVM Electrical & Physical Speci󰘰cations
AC Input Range Voltage 115~230VAC
±10%
Vout
Output Load Rating Combined
Power
Frequency 50Hz ~ 60㎐ ±3 Imin Imax Ipeak
AC Input Current 115VAC 8A +3.3V 0.1A 20A 103W
500W
230VAC +5V 0.2A 20A
PFC Type Active PFC +12V 0.6A 37.5A 40A 450W
Power Factor Correction Max 99% -12V 0.0A 0.3A 3.6W
Inrush Current Limit
(@ Cold Start at 25℃)
115VAC Max 100A +5VSB 0.0A 2.5A 3.5A 12.5W
230VAC Ambient Temperature
E󰘲ciency Max 88% @ 230VAC, Typical load Operation 0 ~ +45℃
DC Output Voltage
Regulation
Vout Regulation Range
At
Full
Load
Storage -20 ~ +70℃
+3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity
+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95% RH
+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH
-12VDC ±10% -10.8 ~ -13.0V Dimensions 140(L) * 150(W) * 86(H)mm
+5VSB ±5% +4.75 ~ +5.25V Weight 2.35Kg
DC Output Ripple
& Noise
Vout Regulation Range
At
Full
Load
Protection Funtions
+3.3VDC 50mV Over-Voltage Protection (OVP)
+5VDC 50mV Under Voltage Protection (UVP)
+12VDC 120mV Short- Cicuit Protection (SCP)
-12VDC 120mV Over-Power Protection (OPP)
+5VSB 50mV
2) ZM600-GVM Electrical & Physical Speci󰘰cations
AC Input Range Voltage 115~230VAC
±10%
Vout
Output Load Rating Combined
Power
Frequency 50Hz ~ 60㎐ ±3 Imin Imax Ipeak
AC Input Current 115VAC 10A +3.3V 0.1A 22A 120W
600W
230VAC +5V 0.2A 22A
PFC Type Active PFC +12V 0.6A 45A 48A 540W
Power Factor Correction Max 99% -12V 0.0A 0.3A 3.6W
Inrush Current Limit
(@ Cold Start at 25℃)
115VAC Max 120A +5VSB 0.0A 2.5A 3.5A 12.5W
230VAC Ambient Temperature
E󰘲ciency Max 88% @ 230VAC, Typical load Operation 0 ~ +45℃
DC Output Voltage
Regulation
Vout Regulation Range
At
Full
Load
Storage -20 ~ +70℃
+3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity
+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95% RH
+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH
-12VDC ±10% -10.8 ~ -13.0V Dimensions 140(L) * 150(W) * 86(H)mm
+5VSB ±5% +4.75 ~ +5.25V Weight 2.45Kg
DC Output Ripple
& Noise
Vout Regulation Range
At
Full
Load
Protection Funtions
+3.3VDC 50mV Over-Voltage Protection (OVP)
+5VDC 50mV Under Voltage Protection (UVP)
+12VDC 120mV Short- Cicuit Protection (SCP)
-12VDC 120mV Over-Power Protection (OPP)
+5VSB 50mV
All manuals and user guides at all-guides.com

333
3. Speci󰘰cations
3) ZM700-GVM Electrical & Physical Speci󰘰cations
AC Input Range Voltage 115~230VAC
±10%
Vout
Output Load Rating Combined
Power
Frequency 50Hz ~ 60㎐ ±3 Imin Imax Ipeak
AC Input Current 115VAC 10A +3.3V 0.1A 22A 130W
700W
230VAC +5V 0.2A 22A
PFC Type Active PFC +12V 0.6A 52.5A 55A 630W
Power Factor Correction Max 99% -12V 0.0A 0.3A 3.6W
Inrush Current Limit
(@ Cold Start at 25℃)
115VAC Max 150A +5VSB 0.0A 2.5A 3.5A 12.5W
230VAC Ambient Temperature
E󰘲ciency Max 88% @ 230VAC, Typical load Operation 0 ~ +45℃
DC Output Voltage
Regulation
Vout Regulation Range
At
Full
Load
Storage -20 ~ +70℃
+3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity
+5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95% RH
+12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95% RH
-12VDC ±10% -10.8 ~ -13.0V Dimensions 140(L) * 150(W) * 86(H)mm
+5VSB ±5% +4.75 ~ +5.25V Weight 2.5Kg
DC Output Ripple
& Noise
Vout Regulation Range
At
Full
Load
Protection Funtions
+3.3VDC 50mV Over-Voltage Protection (OVP)
+5VDC 50mV Under Voltage Protection (UVP)
+12VDC 120mV Short- Cicuit Protection (SCP)
-12VDC 120mV Over-Power Protection (OPP)
+5VSB 50mV
All manuals and user guides at all-guides.com

44
3. Speci󰘰cations
4) ZM500-GVM Cable Speci󰘰cations
Mainboard Power
Connector
CPU Power
Connector
PCI Express2
Connector
PCI Express1
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
FDD Power
Connector
Peripheral Power
Connector
All manuals and user guides at all-guides.com

55
3. Speci󰘰cations
5) ZM600-GVM Cable Speci󰘰cations
Mainboard Power
Connector
CPU Power
Connector
PCI Express2
Connector
PCI Express1
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
FDD Power
Connector
S-ATA Power
Connector
All manuals and user guides at all-guides.com
all-guides.com

66
3. Speci󰘰cations
6) ZM700-GVM Cable Speci󰘰cations
Mainboard Power
Connector
Mainboard Power
Connector
CPU Power
Connector
CPU Power
Connector
PCI Express2
Connector
PCI Express2
Connector
PCI Express4
Connector
PCI Express1
Connector
PCI Express1
Connector
PCI Express3
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
S-ATA Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
Peripheral Power
Connector
FDD Power
Connector
FDD Power
Connector
S-ATA Power
Connector
Peripheral Power
Connector
All manuals and user guides at all-guides.com

7777
4. Certi󰘰cations
