Zanussi Electrolux Built-in oven User manual

54
English
Warnings - Built-in ovens
It is most important that the instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred to another owner, or should you move
house and leave the appliance, always ensure that the book is supplied with the appliance in
order that the new owner can be acquainted with the functioning of the appliance and the
relevant warnings. These warnings are provided in the interest of safety. You must read
them carefully before installing or using the appliance.
Installation
lAny installation work must be undertaken
by a qualified electrician or competent
person.
lInstallation and initial adjustment of your
oven MUST be carried out by qualified
personnel in compliance with current
re ulations. Specific installation
instructions for the installer are iven in this
booklet.
During use
lThis appliance has been desi ned for
cookin edible foodstuffs only, and must
not be used for any other purposes.
lIt is dan erous to alter the specifications
or modify the product in any way.
lAppliances become very hot with use, and
retain their heat for a lon period after use.
lAlways ensure that the control knobs are
in the off position when not in use.
lFor hy iene and safety reasons, this
appliance should be kept clean at all times.
A build-up of fats or foodstuffs could result
in a fire.
lNever line any part of the oven with
aluminium foil.
lEasy clean-liners (if provided) should never
be cleaned with any other than soapy water.
lBefore any maintenance or cleanin work
is carried out on the appliance, always turn
off the isolator switch at the cooker point,
and allow to cool.
lEnsure that the shelves are put in place in
the correct way.
lThis oven (even if it is linked to an electrical
cookin table) is made to function at 230 V
mono, double or three-phase with neutral.
lA polyphase linkin without neutral (400 V)
can induce the distruction of the oven and
of the eventual cookin table.
Child safety
lThis appliance is desi ned to be operated
by adults. Children should not be allowed
to tamper with the controls or play with the
product.
lChildren should be supervised at all times
and should not be allowed to touch the hot
surfaces or be in the vicinity when in use
or until the appliance has cooled after use.
lDurin oven cookin and rillin , the
appliance door and the surroundin parts
are warmed up to a very hi h temperature.
Be careful and keep children away from
the appliance while you are usin it. When
you connect other appliances to a plu near
the oven, check carefully that the wire does
not touch warm parts of the oven and does
not et taken in the oven door.
Technical assistance
lThis appliance should be serviced by an
authorized Network Service Centre, and
only enuine spare parts should be used.
lUnder no circumstances should you
attempt to repair the appliance yourself.
Repairs carried out by inexperienced
persons may cause injury or serious
malfunctionin . Refer to your local Service
Centre. Always insist on enuine spare
parts.

55
Oven door protection device
(stainless steel models)
All our appliances comply with the
European Safety Standards.
Nevertheless, in order to ensure the
highest safety level, and avoid little
children to be exposed to the heat
when the appliance is operated, it is
possible to fit a special protection device
to the oven door. This device can be
purchased in our Service Force entres,
specifying the relevant code ( 35791)
and the Product No. shown on the
rating plate. Fitting instructions are
provided with the kit package.
Guide to Use the
instructions
Safety Instructions
Step by step instructions for an
operation
Hints and Tips
F
Once the oven has been installed:
a) set the thermostat knob to MAX (250);
b) switch the oven function control knob to
conventional cooking ( );
c) allow the oven to run empty for
approximately 45 minutes;
d) open a window for ventilation.
During this time, an unpleasant odour may
be emitted. This is absolutely normal, and
is caused by residues of manufacturing.
Repeat this operation for the grill and fan
cooking function.
Once this operation is carried out, let the
oven cool down, then clean the oven cavity
with a soft cloth soaked in warm soapy
water.
Before cooking for the first time,
carefully wash the oven
accessories.
hen the oven is first installed
F
MANUFACTURER:
ELE TROLUX ZANUSSI S.p.A.
Viale Bologna, 298
47100 FORLÌ (Italy)
Fi . 1
To open the oven door, always
catch the handle in its central part
(Fi . 1).
- +
FO 2161

56
Description of the appliance
1. ontrol panel
2. Oven Thermostat control knob
3. Oven Function control knob
4. Overall control light
5. Oven thermostat control light
6. Oven lamp
7. Telescopic shelf supports
6
23
1
5
7

57
Electric oven
Oven Function and
Thermostat control kno s
They enable to select the most appropriate
type of heating for the different cooking
requirements by appropriately connecting
the heating elements (Fig. 2) and adjusting
temperature to the required level (Fig. 3) .
Oven Light - The oven light will be on
without any cooking function
onventional cooking - The heat
comes from both the top and bottom
element, ensuring even heating inside
the oven.
Top heating element - The heat comes
from the top of the oven only.
Bottom heating element - The heat
comes from the bottom of the oven
only.
Inner grill element only - can be used
for grilling small quantities.
Double Grill - The full grill element will
be on.
Thermal Grilling - This function offers
an alternative method of cooking food
items, normally associated with
conventional grilling. The grill
element and the oven fan operate
together, circulating hot air around the
food. When usin this function,
select a maximum temperature of
200°C and do not exceed 1 hour of
operation.
Fan cooking - This allows you to roast
or roast and bake simoultaneously
using any shelf, without flavour
transference.
Defrost Setting - This setting is
intended to assist in thawing of frozen
food.
Fi . 3
Fi . 2
FO 2153
100
150
200
MAX
50
0
FO2000
Thermostat control light
(°C)
This light goes off when the oven heats up
to the temperature set and comes on again
every time the thermostat cuts in to stabilize
temperature.
Operating control light
It indicates that one or more of the heating
elements are turned on.
Safety thermostat
In order to avoid excessive overheating due
to incorrect use of the appliance or else to a
faulty component, the oven is equipped with
a safety thermostat which cuts off the power
supply if necessary. Operation is restored
automatically when the oven temperature
decreases to normal values. Therefore, if the
thermostat cuts in because you have not
been using the appliance correctly, the oven

58
can be used again simply by waiting for the
appliance to cool down. If, instead, the
thermostat cuts in because of a faulty
component, you should call the Service
Department.
The Cooling Fan for the
Controls
This oven is provided with a cooling fan,
meant to keep the front panel, the knobs and
the oven door handle cool. This fan may run
on after the oven or grill is switched off, until
a normal temperature is reached.
Fi . 4
3
2
1
FO 2296
FO 2297
Fi . 5
The oven has four shelf levels. The shelf
positions are counted from the bottom of the
oven as shown in figure 4.
Shelf levels 1, 2 and 4 are fitted with
telescopic shelf supports, to allow en easier
operation when inserting or removing the
shelves.
Pull the right and left hand telescopic shelf
supports completely out, as shown in figure
5.
Place the shelf or the grill pan on the
telescopic shelf supports, then gently push
them all inside the oven (Fig. 5).
Do not attempt to close the oven door if
the telescopic shelf supports are not
completely inside the oven. This could
dama e the door enamel and lass.
Shelf supports

59
Hints and tips for using the oven
Always cook with the oven door
closed.
Conventional cooking
Heat comes from the top and from the
bottom, therefore it is preferable to use the
central runners.
If cooking requires more heat from the top
or from the bottom use the top or the bottom
runners.
Fan cooking
The food is cooked by means of preheated
air force blown evenly round the inside of
the oven by a fan set on the rear wall of the
oven itself.
Heat thus reaches all parts of the oven evenly
and fast and this means that you can
simultaneously cook different types of foods
positioned on the various oven shelves (fig.
6). Fan cooking ensures rapid elimination
of moisture and the dryer oven environment
stops the different aromas and flavours from
being transmitted from one food to another.
The possibility of cooking on several shelf
heights means that you can cook several
different dishes at the same time and up to
three tins of biscuits and mini pizzas to be
eaten immediately or subsequently deep
frozen.
Naturally the oven can also be used for
cooking on just one shelf. In this case you
should use the lowest set of runners so that
you can keep an eye on progress more
easily.
In addition, the oven is particularly
recommended for sterilizing preserves,
cooking home-made fruit in syrup, and for
drying mushrooms or fruit.
Fan cookin
Grilling
When grilling meat or fish, spread a little oil
on them and always place them on the oven
grid. The shelf level depends on the
thinckness of the food.
Always place the dripping pan at the lowest
level, with some water in it, to avoid smoke
and unpleasant smells.
Thermal grilling
When usin this cookin function, select
a maximum temperature of 200°C and
do not exceed 1 hour of operation.
The full grill element and the oven fan operate
alternately, circulating hot air around the
food. The need to check and turn food is
reduced. With the exception of toast and
rare steaks, you can thermal grill all the
foods you would normally cook under a
conventional grill.
Defrosting
The oven fan operates without heat and
circulates the air, at room temperature, inside
the oven.
Fi . 6 FO 0351

60
Some hints
For bakin cakes
akes require a moderate temperature
(normally between 150 and 200° ). In
addition, the oven must be heated up
beforehand - for about 10 minutes.
The oven door should not be opened before
at least 3/4 of the set cooking time is up.
Normal short pastry dough should be cooked
in a mould or tin for 2/3 of total cooking time
required and then garnished as desired
before being cooked completely.
learly, the remaining cooking time depends
on the type of garnish used (jam, fruit, etc.).
are should be taken to ensure that any
dough and cake mixes are of the right
consistency since an unduly moist mix
lengthens cooking time unnecessarily. The
raw dough or mix should therefore be fairly
difficult to detach from the spoon or beater.
If three shelves are filled with cakes and tarts
simultaneously, it is advisable to slot in an
extra shelf between the two lower shelves
(Fig. 6).
For cookin meat and fish
Meat cooked in the oven should weigh at
least 1 kg to prevent it from becoming too
dry during cooking. Very tender red meat to
be cooked rare, i.e. well cooked on the
outside but extremely juicy inside, requires
high-temperature cooking (200-250° ).
White meat, poultry and fish instead require
low-temperature cooking (150-175° ).
The ingredients for the accompanying sauce
or gravy should be put in the baking pan at
the very beginning only when cooking times
are short.
Otherwise they should be added during the
last half hour. A simple way of checking
whether meat is done or not is to press it
with a spoon; if the meat does not yield
under this pressure it means that it is done
to a turn. In the case of roast beef and fillet
steaks, the inside of which should remain
fairly pink in color, cooking times must be
short.
The meat can be cooked in a baking pan or
else directly on the shelf - in this case a
dripping pan must obviously be placed
underneath the shelf to collect the juice.
Should you cook very fat food, place the
meat directly on the grill and the grill over
the dripping pan in order not to dirty the oven.
Once the meat is cooked, it is advisable to
let it rest for at least 15 minutes before
carving so that the juice does not seep out.
To prevent the formation of too much smoke
in the oven during roasting, it is a good idea
to pour a little water into the dripping pan
andto prevent steamto add a little bit
more during cooking if the original amount
dries up too much.
Before serving, the various courses can be
kept hot in the oven which should be turned
down to the minimum temperature.
Attention! - Do not place pans,
dripping pans, biscuit pans or
aluminium foil on the oven bottom.
This could cause a heat build-up
which would affect the baking results
and damage the oven enamel.
Cooking times
ooking times vary according to the type of
food to be cooked, its consistency, and
volume.We suggest that you take particular
note of your first cooking experiments with
the oven, since operating in the same
conditions for the same dishes you will of
course obtain similar results.
Only experience will enable you to make
the appropriate changes to values given on
charts.

61
temp.
°
Cakes
Whipped up kneading 2 180 2 (1 and 3)* 160 45 ~ 60
Leavened kneading 2 180 2 (1 and 3)* 160 20 ~ 35
Shortbread dough 2 180 2 (1 and 3)* 160 20 ~ 30
Butter-milk cheese cake 1 175 2 150 60 ~ 80
Apple cake 1 180 2 (1 and 3)* 160 40 ~ 60
Strudel 2 175 2 (1 and 3)* 150 60 ~ 80
Jam-tart 2 180 2 (1 and 3)* 160 45 ~ 60
Small cakes 2 180 2 (1 and 3)* 160 15 ~ 25
Biscuits 2 180 2 (1 and 3)* 160 10 ~ 20
Meringues 2 100 2 (1 and 3)* 100 90 ~ 120
Bread and Pizza
1000 White bread 1 200 2 175 45 ~ 60 1 piece
500 Rye bread 2 200 2 175 30 ~ 45 In bread pan
500 Bread rolls 2 200 2 (1 and 3)* 175 20 ~ 35 8 rolls
250 Pizza 1 220 2 (1 and 3)* 200 20 ~ 35 In baking pan
Flans
Pasta flan 2 200 2 (1 and 3)* 175 40 ~ 50
Vegetable flan 2 200 2 (1 and 3)* 175 45 ~ 60
Quiches 2 200 2 (1 and 3)* 175 35 ~ 45
Lasagne 2 200 2 175 45 ~ 60
Meat
1000 Beef 2 200 2 175 50 ~ 70 On grid
1200 Pork 2 200 2 175 100 ~ 130 On grid
1000 Veal 2 200 2 175 90 ~ 120 On grid
1500 English roast beef 2 220 2 200 50 ~ 70 On grid
1200 Lamb 2 200 2 175 110 ~ 130 Leg
1000 hicken 2 200 2 175 60 ~ 80 Whole
4000 Turkey 2 200 2 175 210 ~ 240 Whole
1500 Duck 2 175 2 160 120 ~ 150 Whole
3000 Goose 2 175 2 160 150 ~ 200 Whole
1200 Hare 2 200 2 175 60 ~ 80 ut in pieces
Fish
1000 Whole 2 200 2 (1 and 3)* 175 40 ~ 60 2 fishes
800 Fillets 2 200 2 (1 and 3)* 175 30 ~ 40 4 fillets
Fan Oven
onventional
ooking NOTES
WEIGHT
(GR.)
ooking
time
minutes
Level
TYPE OF DISH 4
3
2
1
4
3
2
1
temp.
°
Cooking Tables
NOTES: Cooking times do not include pre-heating time. We reccomend a short oven pre-heating (about 10
minutes) before baking or cooking pizza.
(*) f you need to cook more than one dish at the same time, we recommend you to place them on the levels
quoted between brackets.

62
Steaks 4 800 4 max 10 8
hops 4 600 4 max 12 8
Sausages 8 500 4 max 10 6
hicken (cut in pieces) 6 800 3 max 30 20
Kebabs 4 700 4 max 12 10
hicken (breast) 4 400 4 max 13 10
Tomatoes 8 500 4 max 12 
Fish (fillets) 4 400 4 max 8 6
Sandwiches 4  4 max 8 
Toast 4  4 max 2~3 1
Upper
side
°C
temp.
PIE ES WEIGHT
Quantity ooking time
(minutes)
Lower
side
Grilling
TYPE OF DISH
Level
4
3
2
1
Type of dish Quantiy ( r.) Level from Temp. °C Time in minutes
the bottom lower side upper side
Pork 1500 2 or 3 170 45 30
Roastbeef 1500 3 200 30 20
hicken 1200 2 or 3 190 40 30
Kebabs 800 3 200 15 10
Fish (whole) 800 3 200 12 8
Grilling
The drippin pan must be placed on the first shelf from the bottom.
When using the Thermal grill function, select a maximum temperature of 200°C and do not
exceed hour of operation.
Thermal grilling
Grease Filter
When cooking meat, the grease filter must
be fitted over the oven fan by clipping it over
the vents in the back panel. This will
prevent a built-up of fat on the fan impellor.
Do not use abrasive materials to clean the
seal. The grease filter is dishwasher
proof.When cooking is completed and the
oven has cooled down, remove the filter by
pushing the protruding tongue on the filter
upward (Fig.7) Wash the filter after use
using warm soapy water. Fit the rease
filter only when roastin .
Fi . 7 FO 0018

63
Before any cleanin switch the
oven off and let it cool down. This
appliance cannot be cleaned with
steam or with a steam cleaning
machine.
Important! Before carryin out
maintenance and cleanin
operations, make sure that your
oven is disconnected from the
mains power supply.
leaning must be carried out after the oven
has cooled down. Wash the enamelled parts
with lukewarm water and detergent. Do not
use abrasive products, such as steel wool
pads, acids etc. since these could damage
the various surfaces. Rinse stainless steel
parts with water after use, and dry them with
a soft cloth or chamois leather.
In the case of persistent stains, you can
use normal non-abrasive detergents or
products specific for stainless steel readily
available on the market. Another alternative
is a drop of hot vinegar.
When cleaning the oven door with the glass
top cover use just hot water, taking care to
avoid using coarse cloths or abrasive
products.
The hot acids of fruit (e.g. Iemons, stewed
prunes, etc.) leave difficult-to-remove stains
on the enamelled surfaces; this inconvenient
may remove enamel gloss, but, it does not
impair oven operation.
lean the oven thoroughly after use; in this
way it will be possible to remove cooking
residuals more easily, thus avoiding these
from burning the next time the oven is used.
Cleaning and Maintenance
FO 0030
Fi . 8
Replacing the oven light
Disconnect the appliance from its power
supply point. Proceed as follows:
- Push in and unscrew the glass cap (Fig.
8).
- Unscrew the light bulb and replace it with
a new heat-proof bulb (300° ) having the
following features:
- Operative tension: 230 V (50 Hz);
- Power: 25 W;
- Fitting: E 14.
- Reconnect the appliance.

64
The Hinged Grill
Some models are fitted with a hinged grill
element, to enable you to clean the roof of
the oven easily.
Before proceedin ensure the
oven is cool and is isolated from
the electricity supply.
lUndo the screws which hold the grill in
place (see Fig. 9). When doing this
operation for the first time, we
recommend using a screwdriver.
lThen gently pull the grill downward to
allow access to the oven roof.
llean the oven roof with a suitable
cleaner and wipe dry before replacing the
hinged grill element.
lGently push up the grill element into
place and firmly screw into place the
holding nuts.
Ensure the rill holdin nuts are
firmly in place to avoid the rill
fallin down when in use.
Fi . 9
Telescopic shelf supports
The telescopic shelf supports can be
removed for easy cleaning. Undo the fixing
nut then remove the shelf supports from both
the oven sides (Fig. 10). To clean the
telescopic shelf supports, soak in warm
soapy water and remove stubborn marks
with a well wetted soap impregnated pad.
Rinse well and dry with a soft cloth. Please,
ensure the retaining nuts are secure when
refitting the shelf support.
When cleanin the shelf supports, take
care not to remove the lubricatin
rease behind the telescopic runners.
This is meant to ensure their ood
operation.
Fi . 10

65
Technical Data
This appliance complies with the
following E.E. . Directives:
- 73/23 - 90/683 (Low Voltage Directive);
- 89/336 (Electromagnetical ompatibility
Directive);
- 93/68 (General Directives)
and subsequent modifications.
Dimension of the oven
recess
Height 59,5 cm
Width 56,0 cm
Depth 55,0 cm
Dimensions of the oven
cavity
Height 32,5 cm
Width 42,0 cm
Depth 39,0 cm
apacity 53 dm3
Oven thermostat regulation: from 50 up to
250 °
Heating elements
Oven lamp 25 W
Electric grill 1750 W
Top Heating Element 800 W
Bottom Heating Element 1000 W
Top + Bottom Heating Elements 1800 W
Simple Grill heating element 1750 W
Double Grill heating element 2550 W
Oven rear heating element 2000 W
onvection fan 30 W
ooling fan 25 W
Maximum Power absorbed: 2600 W
Operating Voltage (50Hz) 230 V

66
Instructions for the installer
The instructions iven below are
desi ned specifically for a
qualified installer and should aid
him or her to perform all
installation, adjustment, and
maintenance operations with
absolute precision and in
compliance with all current
le islation and re ulations. We
stron ly recommend that all
operations for the installation of
your cooker be carryed out by
Qualified Personnel in
accordance with existin rules
and re ulations.
Electrical connection
Prior to making the electrical connection,
make sure that:
 the protection fuse and the domestic
wiring system are suitable to carry the
total electric load of the oven (see rating
plate);
 your domestic wiring system has an
efficient earth connection in compliance
with rules and laws in force;
 the wall socket or the omnipole switch
used for the electrical connection can
easily be reached after the oven is built
in.
This appliance is delivered without an electric
supply cable, therefore, you will have to fit
to it a supply cable with standard plug,
suitable for the total electric load shown on
the rating plate. The plug is to be inserted
into a suitable wall socket. If you require a
direct connection to the electric network
(mains), it will be necessary to fit between
the appliance and the mains an omnipole
switch, with a minimum gap between
contacts of 3 mm, suitable for the required
load and in compliance with rules in force.
The green & yellow ground wire must not be
interrupted by the switch. The supply cable
must in all cases be laid out in such a way
as to ensure that it does not reach at any
given point a temperature 50° higher than
the ambient temperature.
Suitable power supply cables are the
following types, considering the respective
necessary section of cable: H07 RN-F, H05
RN-F, H05 RR-F, H05 VV-F, H05 V2V2-F
(T90), H05 BB-F.
Terminal lock
The oven has an easily accessible terminal
block, which is meant to work with an
electric single-phase rate of 230 V (Fig. 11).
The Manufacturer disclaims any liability
in case these accident-preventin rules
are not observed.
FO 2159
Fi . 11

67
To ensure correct operation of the built-in
assembly, the kitchen cabinet and the
recess for the built-in appliance must have
suitable dimensions.
When the appliance is fitted-in, there must
be no open spaces left and it must be closed
on all sides by the kitchen furniture to prevent
the possibility of inadvertently touching live
(current carrying) parts of the oven.
All parts ensuring such a protection,
including any covering panel (for instance, if
the appliance is installed at the end or at
the beginning of a kitchen counter) must be
fastened in such a way as to prevent removal
of the same without the aid of some tool.
This appliance belongs to the Y class
relevant to protection against ambient
over-heating.
This means that the appliance can be placed
with its back and with one side close to ap-
pliances or walls of higher height. The other
side, instead, must be placed close to furni-
ture or appliances, having the same height.
Overall oven dimensions (Fig. 12)
In-Column recess dimensions
The recess must have the dimensions
shown in Fig. 13.
Undertop recess dimensions
The recess must have the dimensions shown
in Fig. 14.
Building-in
FO 0207
Fi . 12
Fi . 13 FO 0290
Fi . 14
FO 2562
550 MIN
595
560 - 570
80÷100

68
Fi . 15
A
A
B
FO 0849
Fi . 16
Fi . 17
Fi . 18
FO 0851
FO 0850
FO 0852
Securing the oven to the
ca inet
This operation must be carried out by a
qualified technician.
Figures from 15 to 18 show how to secure
the oven to the cabinet.
- Fig.15) Fit the appliance into the cabinet
recess, open the oven door and unscrew
the two upper screws of the door hinge.
- Fig. 16) Slightly slide forward the door in
order to disengage it from the upper
hinge.
- Fig. 17) Lift the oven door to disengage ti
from the lower hinge slipping of the pivot.
- Fig. 18) Secure the oven to the kitchen
cabinet with four wood screws wich fit
the holes provided in the oven frame.
Reassemble the oven door carrying out
the foreseen procedure backwards.

69
When callin for repairs durin the period of uarantee ofthe appliance, the ori inal invoice
or receipt must be shown or sent to ether with the appliance to be repaired.
General conditions of uarantee
1The manufacturer uarantees the appliance indicated on the relative invoice for a period
of one year from the date of purchase. In case of a fault durin this period if caused bya
defect in materials and/or construction, the client is entitled to repair free of char e.
1a Concernin vacuum cleaners for domestic use, the total periodof uarantee is two
years. Accessories are subject to a direct usa e, consequently these articles are
excluded from the uarantee.
The manufacturer uarantees technical assistance and repairsfor one year. Spare
parts fitted durin repair are also covered by a one year uarantee from the date of repair.
In case of fault durin this period, as a direct result of the repair work carried out or
caused by the new parts fitted on such occasion, the client is entitled to repair free of
char e. The execution of repairs does not prolon the total period of uarantee coverin
the appliance.
3Technical Assistance at domicile will be provided only for lar e apparatus which are
difficult to transport such as: washin machines, spin-driers, dishwashers,refri erators,
freezers (vertical or horizontal), ovens, cookers and built-in appliances.
3a The above-mentioned conditions are also valid for refri erators for caravens on condition
that they are situated within the national boundaries and are accessible by roads open
to traffic. Furthermore, at the time of the intervention the appliance and its owner, or the
person so authorized, must be present at the place a reed upon for the intervention.
4If, in the opinion of the manufacturer, the appliance as described in point 3 must be
transported to a Technical Assistance laboratory, the transportation will be carried out
as established by the manufacturer, at his expense and under his responsibility.
5All appliances not mentioned under points 3 and 3a, includin appliances havin the
same functional characteristics but whose transport is easy, must be sent to the
Technical Assistance or taken to them. Throu hout the period of uarantee the cost of
return transportation will be taken care by the manufacturer.
6If durin the period of uarantee a disfunction occurs due to a defect which cannot be
repaired, the appliance will be replaced free of char e.
Extension of the uarantee
7For motorcompressors of refri erators/ freezers (excludin the startin device and
thermal interrupter) a decreasin uarantee of 20% per year for a period of five years
from the date of purchase of the appliance indicated on the relative invoice with repairs
free of char e throu hout the entire period under uarantee. On completion of the total
period of uarantee the cost of travel, workmanship and eventual spare parts will be at
the expense of the client.
GUARANTEE - SPARE PARTS (only for BENELUX)

Exclusion from uarantee
8The free execution of work for the repair and/ or substitution as set out above will not
apply if:
- The purchase invoice or receipt indicatin the date of purchase and the identification of
the appliance cannot be presented or was not sent with the appliance to be repaired;
- The appliance is used for purposes other than those of the domestic nature for which
it was made;
- The appliance was not installed, handled or used in conformity with the indications in
the instruction manual or in the modalities for use;
- The appliance has been repaired or modified incorrectly by unqualified personnel.
8a If the appliance has been built-in, underinserted, suspendedor installed in such a way
that the time required to move it and put it back in position exceeds thirty minutes in total,
the extra expenditures occurred will be billed to the owner of the appliance.
8b ln case of deterioration due to an irre ular installation carried out in a reement with the
owner of the appliance, the manufacturer and the technical assistance decline all
responsibility.
8c Dama e such as scratches, knocks or breaka e of movable or dismountable units
which were not notified to the manufacturer at the time of delivery are not covered by the
uarantee.
Important notice
This appliance has been made to be safe. Inadequate repairs can nonetheless compromi-
se this safety. To avoid such problems and to prevent any eventual dama e we advise you
to have repairs carried out exclusively by qualified
personnel.We advise you to have repairs or
maintenance carried out by the retailer or the Electrolux
Service and to request only ori inal spare parts.
Belgium
Bergensesteenweg 719 / B - 1520 Halle (Lembeek)
Repairing to customer's house:
Tel.: [phone]
Fax.: [phone]
Spare parts:
Tel.: [phone]
Fax.: [phone]
Luxem ourg
7, Rue de Bitbourg / L-1273 Luxembourg-Hamm
ustomer care:
Tel.: 42 43 11
Fax: [phone]

35671-8302 10/01
Grafiche MDM - Forlì
