MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE
INSTALLATION, USE AND MAINTENANCE HANDBOOK
MANUEL D’INSTRUCTIONS POUR L’INSTALLATION, L’EMPLOI ET L’ENTRETIEN
HANDBUCH FÜR INSTALLATION, BEDIENUNG UND WARTUNG
INSTRUCTIES VOOR MONTAGE, GEBRUIK EN ONDERHOUD

12
GB
Dear Customer,
If you follow the recommendations
contained in this Instruction Manual, your
appliance will give you constant high
performance and will remain efficient for
many years to come.
CONTENTS
RECOMMENDATIONS AND SUGGESTIONS 13
CHARACTERISTICS 14
INSTALLATION 15
USE 19
MAINTENANCE 20

13 GB
RECOMMENDATIONS AND SUGGESTIONS
INSTALLATION
•The manufacturer will not be held liable for any damages resulting
from incorrect or improper installation.
•The minimum safety distance between the cooker top and the
extractor hood is 650 mm.
•Check that the mains voltage corresponds to that indicated on the
rating plate fixed to the inside of the hood.
•For Class I appliances, check that the domestic power supply
guarantees adequate earthing.
•Connect the extractor to the exhaust flue through a pipe of minimum
diameter 120 mm. The route of the flue must be as short as possible.
•Do not connect the extractor hood to exhaust ducts carrying
combustion fumes (boilers, fireplaces, etc.).
•If the extractor is used in conjunction with non-electrical appliances
(e.g. gas burning appliances), a sufficient degree of aeration must be
guaranteed in the room in order to prevent the backflow of exhaust
gas.Thekitchenmusthaveanopeningcommunicatingdirectlywith
the open air in order to guarantee the entry of clean air.
USE
•The extractor hood has been designed exclusively for domestic use
to eliminate kitchen smells.
•Never use the hood for purposes other than for which it has ben
designed.
•Never leave high naked flames under the hood when it is in
operation.
•Adjusttheflameintensityto directitonto thebottomof thepanonly,
making sure that it does not engulf the sides.
•Deep fat fryers must be continuously monitored during use:
overheated oil can burst into flames.
•The hood should not be used by children or persons not instructed in
its correct use.
MAINTENANCE
•Switch off or unplug the appliance from the mains supply before
carrying out any maintenance work.
•Clean and/or replace the Filters after the specified time period.
•Clean the hood using a damp cloth and a neutral liquid detergent.
650 mm min.

14
GB
CHARACTERISTICS
Dimensions
Components
Ref. Q.ty Product Components
11Hoo Bo y, complete with: Controls, Light,
Blower, Filters
21Telescopic Chimney comprising:
2.1 1Upper Section
2.2 1Lower Section
8a 1Right Air Outlet Grill
8 1Left Air Outlet Grill
91Re ucer Flange ø 150-120 mm
14 1Hoo Bo y Air Outlet Extension Piece
consisting of two Half Shells
14.1 1Air Outlet Connection Extension
15 1Air Outlet Connection
Ref. Q.ty Installation Components
7.2.1 2Upper Chimney Section Fixing Brackets
11 6Wall Plugs
12a 6Screws 4,2 x 44,4
12c 6Screws 2,9 x 6,5
Q.ty Documentation
1Instruction Manual
1Warranty
300
500
265
898
68 740
740 min
950 max
433
1
11
12a
2.1
2.2
2
9
14.1
15
14
8 8a
12c
12a 7.2.1 11

15 GB
INSTALLATION
Wall drilling and bracket fixing
Wall marking:
•Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of
the area in which the hood will be installed.
•Draw a horizontal line at:
955 mm above the hob for installation without the back panel,
a 955mm above the surface on which the pack panel rests,for installation with the back panel.
•Place bracket 7.2.1 on the wall as shown about 1-2 mm from the ceiling or upper limit aligning the
centre (notch) with the vertical reference line.
•Mark the wall at the centres of the holes in the bracket.
•Place bracket 7.2.1 on the wall as shown at X mm below the first bracket (X = height of the upper
chimney section supplied), aligning the centre (notch) with the vertical line.
•Mark the wall at the centres of the holes in the bracket.
•Mark a reference point on the horizontal reference line as indicated, 116 mm from the vertical
reference line.
•Repeat this operation on the other side.
•Drill ø8 mm holes at all the centre points marked.
•Insert the wall plugs 11 in the holes.
•Fix the brackets using the 12a (4,2 x 44,4) screws supplied.
•Insert the two screws 12a (4,2 x 44,4) supplied in the hood body fixing holes, leaving a gap of 5-6
mm between the wall and the head of the screw.
955 X
116
1÷2
116
955 min.
7.2.1
11
12a

16
GB
REAR PANEL (OPTIONAL)
The Rear Panel comprises a bottom panel and a top profile connecting to the Hood.
TheRearPanel must be fitted before fixing the hood body and, for both upper and lower position fixing,
must be fitted at the correct height prior to installing the bases. As this operation is rather complex, it
shouldbe carriedout eitherby thekitchen installerora qualifiedperson whoknows thefinal dimensions
of the units.
For the upper fixing position, proceed as follows:
Mounting the hood body
•Rest the back panel on the base, inserting the lower plate between
the upper surface and the wall, centring it on the vertical reference
line.
•Mark the centres of the two holes in the upper plate.
•Drill ø8 mm holes at all the centre points marked.
•Insert the wall plugs 11 in the holes.
•Position the top Profile 20 so that it rests against the top edge of the
Back panel, making sure that the screw holes coincide.
•Fix the Back panel to the Profile, using the screws 12a provided.
•Close the holes using the plugs 13 provided.
•Before attaching the hood body, tighten the two
screws Vr located on the hood body mounting
points.
•Hook the hood body onto the screws 12a.
•Fully tighten support screws 12a.
•Adjust screws Vr to level the hood body.
12a 11
20-
13
12a
Vr

17 GB
Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the chimney using either a flexible or rigid
pipe ø150 or 120 mm, the choice of which is left to the installer.
RECIRCULATION VERSION AIR OUTLET
ELECTRICAL CONNECTION
•Connect the hood to the mains through a two-pole switch having a contact gap of at least 3 mm.
•To install a ø120 mm air exhaust connection, insert
the reducer flange 9on the hood body outlet.
•Fix the pipe in position using sufficient pipe clamps
(not supplied).
•Remove any activated charcoal filters.
•Assemblethe two halvesofthe hood bodyextension
piece 14.
•Pushfit theassembled hoodbodyextensionpiece14
onto the air outlet.
•Push fit connection 15onto the hood body extension
piece 14.
•Insert the connection extension pieces laterally 14.1
in connection 15.
•Make sure that the outlet of the extension pieces 14.1 is horizontally and vertically aligned with the
chimneyoutlets.If this is not the case,adjustthe position by either reversing the connectionextension
pieces 14.1 or by cutting the hood body extension 14 along one of the thinner section channels
denoting the pre-fixed lengths, then reassemble as described previously.
•The air outlet directional grills 8a - 8b must be fitted after the lower outlet duct 2.2 has been installed.
•Ensure that the activated charcoal filters have been inserted.
9
ø 120ø 150
14
14.115
8a
8

18
GB
Flue assembly
Upper exhaust flue
•Slightlywiden the twosides of theupperflue and
hookthembehindthebrackets7.2.1,makingsure
that they are well seated.
•Secure the sides to the brackets using the 4
screws 12c (2,9 x 6,5) supplied.
Lower exhaust flue
•Slightly widen the two sides of the flue and hook
them between the upper flue and the wall,
making sure that they are well seated.
•Fixthelowerpartlaterallytothehoodbodyusing
the 2 screws 12c (2,9 x 6,5) supplied.
•On the recirculation version, fit the directional
grids 8a - 8b in their housings making sure that
the directional symbols are towards the top and
front of the hood. Also make sure that they are
correctly inserted in the connection extension
pieces 14.1.
12c
8a
2.1
2.2
2
8
7.2.1
12c

19 GB
USE
Control panel
LLight Switches the lighting system on and off.
S1 Led Motor running led.
S2 Led Optimum speed led.
S3 Led Intensive speed led.
S4 Led Grease filters saturated alarm led.
S5 Led Activated charcoal filter exhausted alarm led.
To disable this indicator (Ducted hoods) simultaneously press buttons R(using a
sharpobject,for example a pencil) andV2. To enable it again, press buttonsRand V3.
RReset Internal Filter Alarms Reset button.
V1 Motor Switches the extractor motor on and off.
V2 Speed Increases the operating speed.
V3 Speed Increases the operating speed.
V4 Optimum
speed Presetoptimumspeed. To customise the Optimum speed setting, select theSpeedyou require using buttons V2 and V3 then press V4 within 10 seconds (during this period
the corresponding led S2 will flash).
The setting you enter will remain active until the Hood is turned off.
V5 Intensive
speed Maximum speed, used to eliminate the highest levels of cooking vapour emission.
Returns to Optimum speed automatically after it has been in operation for 15 minutes.
Intensive speed can also be turned off manually by pressing button V4.
TDelayed
shutdown This device allows any residual odours to be removed without having to wait and turn the appliance off, as the Motor and Lighting will switch off automatically at the end
of the selected time.
By pressing button Tin succession it is possible to set the delayed shutdown of the
appliance to 15, 30 and 60 minutes, respectively. The selected time is shown by leds
T1, T2, T3. To move from one time to another, simply press button Tuntil the
required led lights up. The time selected in this way will start from zero.
The delayed shutdown function can be turned off by pressing button V4.
T1 Led 15’delayed shutdown indicator led.
T2 Led 30’delayed shutdown indicator led.
T3 Led 60’delayed shutdown indicator led.
0 - 1
0 - 1
153060
reset
reset
delay
L
S1
V1 V2 V3 V4 V5 T
S2 S3
S4
T1 T2 T3 S5 R

20
GB
MAINTENANCE
Grease filters
CLEANING METAL SELF-SUPPORTING GREASE FILTERS
Activated charcoal filter (Recirculation version)
REPLACING THE ACTIVATED CHARCOAL FILTER
The filters must be cleaned when led S4 starts to
flash or at least once every two months of opera-
tion,or more frequently withheavyusage, and can
be washed in a dishwasher.
Resetting the alarm signal
•PressbuttonR,usinga sharpobject(forexample
the tip of a pencil).
•The Alarm indicator led S4 will go out.
Cleaning the filters
•Remove the filters one at a time by pushing
them towards the back of the group and pulling
down at the same time.
•Wash the filters, taking care not to bend them.
Allow them to dry before refitting.
•When refitting the filters, make sure that the
handle is visible on the outside.
This filter is not washable and cannot be regener-
ated, and must be replaced when led S5 starts to
flash, or at least once every four months of opera-
tion.TheAlarmis only signalled when the Recircu-
lation motor is turned on.
Resetting the alarm signal
•PressbuttonR,usinga sharpobject(forexample
the tip of a pencil).
•The Alarm indicator led S5 will go out.
Replacing the filter
•Remove the metal grease filters
•Remove the saturated activated carbon filter by
releasing the fixing hooks
•Fit the new filter by hooking it into its housing
•Replace the metal grease filters.

21 GB
Lighting
LIGHT REPLACEMENT
• 20 W halogen light.
•Remove the 2 Screws fixing the Lighting
support, and pull it out of from the Hood.
•Extract the Lamp from the Support.
•Replace with another of the same type, making
sure that the two pins are properly inserted in
the lamp holder socket holes.
•Replace the Support, fixing it in place with the
two Screws removed as above.

Quest’apparecchio é conforme alla norma europea sulla bassa tensione C.E.E. 73/23 relativa
alla sicurezza elettrica e alle norme europee: C.E.E. 8 /336 relativa alla compatibilità elettro-
magnetica e C.E.E. 3/68 relativa alla marcatura CE.
This appliance complies with European regulations on low voltages, EEC Directive 73/23 on
electrical safety, and with the following European regulations: EEC Directive 8 /336 on
electromagnetic compatibility and EEC Directive 3/68 on EC marking.
Cet équipement est conforme à la norme européenne sur la basse tension C.E.E. 73/23 relati-
ve à la sécurité électrique et aux normes européennes: C.E.E. 8 /336 relative à la compatibilité
électromagnétique et C.E.E. 3/68 relative au marquage CE.
Dieses Gerät entspricht den europäischen Niederspannungsrichtlinien 73/23/EWG zur
elektrischen Sicherheit, den europäischen Richtlinien 8 /336/EWG zur elektromagnetischen
Verträglichkeit und den Richtlinien 3/68/EWG zur CE-Kennzeichnung
Dit apparaat voldoet aan de Europese Laagspanningsrichtlijn 72/23/EEG inzake de elektrische
veiligheid en aan de Europese normen 8 /336/EEG inzake de elektromagnetische compatibiliteit
en 3/68/EEG inzake de CE-markering.
436000287 01 020115
