Zanussi ZKG 2105 User manual

EN
User manual
Washer Dryer
ZKG 2105

Contents
Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Safety instructions _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6
Programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 9
Automatic Drying programmes _ _ _ _ _ _ _ 11
Drying Programmes _ _ _ _ _ _ _ _ _ _ _ _ _ 11
Consumption values _ _ _ _ _ _ _ _ _ _ _ _ _ 12
Helpful hints and tips _ _ _ _ _ _ _ _ _ _ _ _ 12
First use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 14
Personalisation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 15
Daily Use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 15
Use - Drying _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 17
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ 19
What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 22
Technical data _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 25
Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 26
Environment concerns _ _ _ _ _ _ _ _ _ _ _ _ 28
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an incor-
rect installation and use causes injuries and damages. Always keep
the instructions with the appliance for future reference.
Children and vulnerable people safety
Warning! Risk of suffocation, injury or permanent disability.
• Do not let persons, children included, with reduced physical sen-
sory, reduced mental functions or lack of experience and knowl-
edge use the appliance. They must have supervision or instruction
for the operation of the appliance by a person who is responsible
for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door when it is
open.
• If the appliance has a child safety device, we recommend you acti-
vate it.
General Safety
• Before maintenance, deactivate the appliance and disconnect the
mains plug from the mains socket.
2
www.zanussi.com

• Do not change the specification of this appliance.
• Obey the maximum load volume of 6 kg (refer to the “Programme
chart” chapter).
• If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualified persons in order to
avoid a hazard.
•Theoperatingwaterpressure (minimum and maximum) must be
between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa)
• The ventilation openings in the base (if applicable) must not be ob-
structed by a carpet.
• The appliance is to be connected to the water mains using the
new supplied hose-sets. Old hose sets must not be reused.
Safety instructions
Installation
• Remove all the packaging and the transit
bolts.
• Keep the transit bolts. When you move the
appliance again you must block the drum.
• Do not install or use a damaged appliance.
• Do not install or use the appliance where the
temperature is less than 0 °C or where it is
exposed to the weather.
• Obey the installation instruction supplied with
the appliance.
• Make sure that the floor where you install the
appliance is flat, stable, heat resistant and
clean.
• Do not install the appliance where the appli-
ance door can not be fully opened.
• Always be careful when you move the appli-
ance because it is heavy. Always wear safety
gloves.
• Make sure that there is air circulation be-
tween the appliance and the floor.
• Adjust the feet to have the necessary space
between the appliance and the carpet.
Electrical connection
Warning! Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information on
the rating plate agrees with the power supply.
If not, contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and extension
cables.
• Make sure not to cause damage to the mains
plug and to the mains cable. Should the ap-
pliance power supply cable need to be re-
placed, this must be carried out by our Serv-
ice Centre.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains
plug with wet hands.
• Only for UK and Ireland. The appliance has a
13 amp mains plug. If it is necessary to
3
www.zanussi.com

change the fuse in the mains plug, use a 13
amp ASTA (BS 1362) fuse.
•
This appliance complies with the E.E.C. Di-
rectives.
Water connection
• Make sure not to cause damage to the water
hoses.
• The appliance is to be connected to the wa-
ter mains using the new supplied hose-sets.
Old hose sets must not be reused.
• Before you connect the appliance to new
pipes or pipes not used for a long time, let
the water flow until it is clean.
• The first time you use the appliance, make
sure that there is no leakage.
Use
Warning! Risk of injury, electrical shock,
fire, burns or damage to the appliance.
• Use this appliance in a household only.
• Do not change the specification of this appli-
ance.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
• Do not touch the glass of the door while a
programme operates. The glass can be hot.
• Make sure that you remove all metal objects
from the laundry.
• The final part of the drying cycle occurs with-
out heat (cool down cycle) to ensure that the
items will not be damaged.
If you stop the appliance before the end of
the drying cycle, immediately remove and
spread out all items, so that the heat can dis-
sipate.
• If you use detergent, fabric softener or similar
products, obey the instructions on the pack-
aging.
• Wipe away lint that has accumulated around
the appliance.
• Do not dry the damaged items which contain
padding or fillings .
• Do not dry items such as foam rubber (latex
foam), shower caps, waterproof textiles and
rubber backed articles.
• Before drying items that have been in contact
with substances such as cooking oil, ace-
tone, alcohol , petrol, kerosene, spot remov-
ers, turpentine, waxes and wax removers,
wash them in hot water with an extra amount
of detergent.
• Do not dry items if industrial chemicals have
been used for cleaning.
• Make sure that no gas lighters or matches
have been left in the pockets of the clothing.
• Only dry fabrics which are applicable to dry in
the tumble dryer. Follow the instructions on
the fabric label.
• Do not dry not washed items in the appliance.
• If you have washed your laundry with a stain
remover start an extra rinse cycle before you
start the appliance.
• Plastic items are not heat resistant.
– If you use a detergent ball, remove it before
you set the drying programme.
– Do not use a detergent ball when you set a
non-stop programme.
Warning! Risk of injury or damage to the
appliance.
• Do not sit or stand on the open door.
• Obey the maximum load volume.
• Do not dry dripping wet clothes in the appli-
ance.
Care and Cleaning
Warning! Risk of injury or damage to the
appliance.
• Do not use water spray and steam to clean
the appliance.
• Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads,
solvents or metal objects.
Disposal
Warning! Risk of injury or suffocation.
4
www.zanussi.com

• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
Product description
1Detergent dispenser drawer
2Control panel
3Door opening handle
4Rating plate
5Drain pump
6Adjustable feet
12
3
4
5
6
Child safety
Make sure that children or pets do not climb in-
to the drum. To prevent children and pets be-
coming trapped inside the drum this machine in-
corporates a special feature.
To activate this de-
vice, rotate the button
(without pressing it)
inside the door clock-
wise until the groove
is horizontal. If neces-
sary use a coin.
To disable this de-
vice and restore the
possibility of closing
the door, rotate the
button anti-clockwise
until the groove is ver-
tical.
5
www.zanussi.com

Rubber feet kit (4055126249)
Available from your authorized dealer.
The rubber feet are particularly recommended
on floating, slippery and wooden floors.
Mount the rubber feet to prevent vibration,
noises and displacement of the appliance dur-
ing operation.
Read carefully the instructions supplied with the
kit.
Fixing plate kit (4055171146)
Available from your authorized dealer.
If you install the appliance on a plinth, secure
the appliance in the fixing plates.
Follow the instructions supplied with the kit.
Detergent dispenser drawer
Compartment for detergent used for prewash
and soak phase or for stain remover used during
the stain action phase (if available). The prewash
and soak detergent is added at the beginning of
the wash programme. The stain remover is add-
ed during the stain action phase.
Compartment for powder or liquid detergent
used for main wash. If using liquid detergent
pour it just before starting the programme.
Compartment for liquid additives (fabric softener, starch).
Follow the product manufacturer’s recommendations on quantities to use and do not exceed the
«MAX» mark in the detergent dispenser drawer. Any fabric softener or starching additives must
be poured into the compartment before starting the wash programme.
Control panel
On the following page there is a picture of the control panel. It shows the programme selector
dial as well as the buttons, pilot lights and the display. These are presented by relevant num-
bers on the following pages.
1 2 3 4 5 6 7 8
10
9
1Programme selector dial
2Spin button
3Automatic drying button
4Drying time button
6
www.zanussi.com

5Super quick button
6Extra rinse button
7Start/Pause button
8Delay start button
9Door pilot light
10 Display
Table of symbols
Programme dial
Rinses
Drain
Spin
Cold
Push buttons
Rinse hold
Child lock
1-8 Programme selector dial, spin speed
button, drying level and time, and
available options
Programme Selector Dial
It allows you to switch the appliance on/off and/
or to select a programme.
Spin
By pressing this button you can change the spin
speed of the set programme or select the avail-
able option(s).
Rinse hold
By selecting this function the water of the last
rinse is not emptied out to prevent the fabrics
from creasing. Before opening the door it will be
necessary to empty out the water. To empty out
the water, please read the paragraph «At the
end of the programme».
Automatic Dry
By pressing this button you can choose the re-
quired degree of drying for cottons and synthet-
ics:
• Cupboard dry (Cottons and Synthetics)
• Iron dry (Cottons)
The pilot light corresponding to the selected
dryness degree will illuminate.
Drying Time
If you wish to carry out a timed drying pro-
gramme, press this button until the drying time
you want appears on the display according to
the fabrics (cottons or synthetics) you have to
dry. For Cottons you can select a drying time
from 10 minutes to 250 minutes (4.10). For
Synthetics you can select a drying time from 10
minutes to 130 minutes (2.10). Every time you
press this button the drying time increases by 5
mins.
Super Quick
Short cycle for lightly soiled items or for laundry
which needs only freshening up. We recom-
mend you to reduce the fabrics loading.
Extra Rinse
This appliance is designed to save energy. If it
necessary to rinse the laundry using an extra
quantity of water (extra rinse), select this option.
Some additional rinses will be performed. This
option is recommended for people who are al-
lergic to detergents, and in areas where the wa-
ter is very soft.
Start Pause
This button allows you to start or to interrupt the
selected programme.
Delay Start
The programme can be delayed from 30 min -
60 min - 90 min, 2 hours and then by 1 hour up
to a maximum of 20 hours by means of this but-
ton.
7
www.zanussi.com

Door light
The pilot light 9illuminates when the pro-
gramme starts and indicates if the door can be
opened:
• light on: the door cannot be opened. The ma-
chine is working or has stopped with water
left in the tub.
• light off: the door can be opened. The pro-
gramme is finished or the water has been
emptied out.
• light blinking: the door is opening in a few mi-
nutes.
10 Display
10.1 10.2
The display shows the following information:
10.1 Child safety lock
This device permits you to leave the appliance unattended during it's functioning.
10.2 •Duration of the selected programme
After selecting a programme, the duration is displayed in hours and minutes (for example
). The duration is calculated automatically on the basis of the maximum recommended
load for each type of fabric. After the programme has started, the time remaining is updated
every minute.
• Selected drying time
After selecting a drying programme the drying time is shown in minutes or hours and minutes.
After the programme has started, the time remaining is updated every minute.
• Delayed start
The Selected delay set by pressing the relevant button appears on the display for a few sec-
onds, then the duration of the selected programme is displayed again. The delay time value de-
creases by one unit every hour and then, when 1 hour remains, every minute.
• Alarm codes
In the event of operating problems, some alarm codes can be displayed, for example
(see paragraph «What to do if...»).
• Incorrect option selection
If an option which is not compatible with the set wash programme is selected, the message Err
is displayed at the bottom of the display for a few seconds and the integrated red light of button
7start flashing.
• End of programme
When the programme has finished the flashing zero ( ) is displayed, the pilot light 9and the
pilot light of button 7go out and the door can be opened.
8
www.zanussi.com

Programmes
Programme - Maximum and Minimum Temperature -
Cycle Description - Maximum Spin Speed - Maxi-
mum Fabrics Load - Type of Laundry
Options Detergent Com-
partment
Cottons
90° - 60°
Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 6 kg - Reduced load 3 kg
1)
White cotton (heavily and normally soiled items).
SPIN
RINSE HOLD
SUPER QUICK
EXTRA RINSE
Cottons Eco
60°
Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 6 kg
White or fast colour cotton (normally soiled items).
The temperature will decrease and the washing time will be
extended. This allows to obtain a good washing efficiency
by saving energy.
SPIN
RINSE HOLD
EXTRA RINSE
Cottons
60° - Cold
Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 6 kg - Reduced load 3 kg
1)
White or colour cotton (normally or slightly soiled items) .
SPIN
RINSE HOLD
SUPER QUICK
EXTRA RINSE
Cottons + prewash
60° - 40°
Prewash - Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 6 kg - Reduced load 3 kg
1)
White or colour cotton (heavily or normally soiled items)
SPIN
RINSE HOLD
SUPER QUICK
EXTRA RINSE
2)
Synthetics
60° - Cold
Main wash - Rinses
Maximum spin speed at 800 rpm
Max. load 3 kg - Reduced load 1.5 kg
1)
Synthetic or mixed fabrics: underwear, coloured gar-
ments, non-shrink shirts, blouses.
SPIN
RINSE HOLD
SUPER QUICK
EXTRA RINSE
Easy iron
40°
Main wash - Rinses
Maximum spin speed at 800 rpm
Max. load 1 kg
Synthetic or mixed fabrics: selecting this programme
the laundry is gently washed and spun to avoid any creas-
ing. In this way ironing is easier. Furthermore the machine
will perform additional rinses.
SPIN
RINSE HOLD
EXTRA RINSE
9
www.zanussi.com

Programme - Maximum and Minimum Temperature -
Cycle Description - Maximum Spin Speed - Maxi-
mum Fabrics Load - Type of Laundry
Options Detergent Com-
partment
Delicates
40° - Cold
Main wash - Rinses
Maximum spin speed at 600 rpm
Max. load kg 3 - Reduced load kg 1.5
1)
Delicate fabrics: acrylics, viscose, polyester.
SPIN
RINSE HOLD
SUPER QUICK
EXTRA RINSE
Handwash
30° - Cold
Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 2 kg
Washing programme for machine washable wool as well as
for hand washable woollens and delicate fabrics. Note! A
single or bulky item may cause imbalance. If the appliance
doesn’t perform the final spin phase, add more items, redis-
tribute the load manually and then select the spinning pro-
gramme.
SPIN
RINSE HOLD
Jeans
40°
Main wash - Rinses
Maximum spin speed at 1000 rpm
Max. load 3 kg
With this programme it is possible to wash items like pants,
shirts or jackets in denim tissue and also jersey realized
with hi-tech materials. Note! The Extra Rinse option will be
activated automatically.
SPIN
RINSE HOLD
Rinses
Rinses
Maximum spin speed at 1000 rpm
Max. load 6 kg
With this programme it is possible to rinse and spin cotton
garments which have been washed by hand. The machine
performs 3 rinses, followed by a final long spin.
Important!
The spin speed will automatically assume the setting for
cotton items. if required, reduce the speed to the desired
level.
SPIN
RINSE HOLD
EXTRA RINSE
Drain
Draining of water
Max. load 6 kg
For emptying out the water of the last rinse in programmes
which stop with water in the tub.
10
www.zanussi.com

Programme - Maximum and Minimum Temperature -
Cycle Description - Maximum Spin Speed - Maxi-
mum Fabrics Load - Type of Laundry
Options Detergent Com-
partment
Spin
Drain and long spin
Maximum spin speed at 1000 rpm
Max. load 6 kg
Separate spin for hand washed garments and after pro-
grammes which stop with water in the tub. Reduce the spin
speed to the required level to adapt it to the fabrics to be
spun.
SPIN
O/Off
For cancelling the programme which is running or to switch the machine off .
1) If you select the Super Quick option, we recommend that you reduce the maximum load as indicated. Full
loading is possible however with somewhat reduced cleaning results.
2) If you use liquid detergents,set a programme without PREWASH.
Automatic Drying programmes
Degree of Drying Type of Fabric Max Load
Cupboard dry
Suitable for items to put away without ironing
Cotton and linen (bathrobes,
bath towels, etc) 3 kg
Cupboard dry
Suitable for items to put away without ironing
Synthetics and mixed fabrics
(jumpers, blouses, underwear,
household linen)
2 kg
Iron dry
Suitable for ironing
Cotton and linen (sheets, ta-
blecloths, shirts, etc.) 3 kg
Drying Programmes
Degree of Drying Type of Fabric Drying Load Spin Speed
Suggested
drying time
in Minutes
Suitable for items to put away
without ironing
1)
Cotton and linen
(bathrobes, bath tow-
els, etc)
4 kg
3 kg
1.5 kg
1000
170-190
90-100
50-60
Suitable for items to put away
without ironing
Synthetics and
mixed fabrics
2 kg
1 kg 800 70-80 35-45
Suitable for ironing
Cotton and linen
(sheets, tablecloths,
shirts, etc.)
4 kg
3 kg
1.5 kg
1000
130-150
75-85
45-55
1) In compliance with EC directive EN 50229 the cotton reference programme for the data entered in the
Energy Label must be tested dividing the maximum washing load by two equal parts and drying with DRYING
TIME each of them.
11
www.zanussi.com

Consumption values
Programme Energy consumption
(KWh)
Water consumption
(litres)
Programme duration
(Minutes)
White Cottons 90° 2.0 61
For the duration of
the programmes,
please refer to the
display on the control
panel.
Cottons 60° 1.3 58
Cotton Eco 60°
1)
1.02 54
Cottons 40° 0.7 58
Synthetics 40° 0.5 50
Delicates 40° 0.55 60
Wool/ Handwash 30° 0.25 53
1) «Cottons Eco» at 60°C with a load of 6 kg is the reference programme for the data entered in the energy
label, in compliance with EEC 92/75 standards.
Off Mode (W) Left On Mode (W)
0.10 0.98
The information given in the charts above are in compliance with the EU Commission regulation 1015/2010
implementing directive 2009/125/EC.
The consumption data shown on this chart
is to be considered purely indicative, as it
may vary depending on the quantity and type of
laundry, on the inlet water temperature and on
the ambient temperature.
Helpful hints and tips
Sorting out the laundry
Follow the wash code symbols on each garment
label and the manufacturer’s washing instruc-
tions. Sort the laundry as follows: whites, col-
oureds, synthetics, delicates, woollens.
Before loading the laundry
Never wash whites and coloureds together.
Whites may lose their «whiteness» in the wash.
New coloured items may run in the first wash;
they should therefore be washed separately the
first time.
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special de-
tergent or detergent paste.
Treat curtains with special care. Remove hooks
or tie them up in a bag or net.
Removing stains
Stubborn stains may not be removed by just
water and detergent. It is therefore advisable to
treat them prior to washing.
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a spe-
cial detergent then rub in the soap and water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab
the stain; treat several times.
Dried grease stains: moisten with turpentine,
lay the garment on a soft surface and dab the
stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with
rust stains which are not recent since the cellu-
lose structure will already have been damaged
and the fabric tends to hole.
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
12
www.zanussi.com

Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with ace-
tone
1)
, lay the garment on a soft cloth and dab
the stain.
Lipstick: moisten with acetone as above, then
treat stains with methylated spirits. Treat any re-
sidual marks with bleach.
Red wine: soak in water and detergent, rinse
and treat with acetic or citric acid, then rinse.
Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the
fabric first with acetone
1)
, then with acetic acid;
treat any residual marks on white fabrics with
bleach and then rinse thoroughly.
Tar stains: first treat with stain remover, methy-
lated spirits or benzine, then rub with detergent
paste.
Detergents and additives
Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the envi-
ronment.
Although biodegradable, detergents contain
substances which, in large quantities, can upset
the delicate balance of nature.
The choice of detergent will depend on the type
of fabric (delicates, woollens, cottons, etc.), the
colour, washing temperature and degree of soil-
ing.
All commonly available washing machine deter-
gents may be used in this appliance:
• powder detergents for all types of fabric
• powder detergents for delicate fabrics (60°C
max) and woollens
• liquid detergents, preferably for low tempera-
ture wash programmes (60°C max) for all
types of fabric, or special for woollens only.
The detergent and any additives must be placed
in the appropriate compartments of the dis-
penser drawer before starting the wash pro-
gramme.
If using liquid detergents, a programme without
prewash must be selected.
Your appliance incorporates a recirculation sys-
tem which allows an optimal use of the concen-
trated detergent.
Follow the product manufacturer’s recommen-
dations on quantities to use and do not ex-
ceed the «MAX» mark in the detergent dis-
penser drawer.
Quantity of detergent to be used
The type and quantity of detergent will depend
on the type of fabric, load size, degree of soiling
and hardness of the water used.
Follow the product manufacturers’ instructions
on quantities to use.
Use less detergent if:
• you are washing a small load
• the laundry is lightly soiled
• large amounts of foam form during washing.
Degrees of water hardness
Water hardness is classified in so-called “de-
grees” of hardness. Information on hardness of
the water in your area can be obtained from the
relevant water supply company, or from your lo-
cal authority. If the water hardness degree is
medium or high we suggest you to add a water
softener following always the manufacturer’s in-
structions. When the degree of hardness is soft,
readjust the quantity of the detergent.
Drying Hints
Preparing the drying cycle
As a dryer, the appliance works on the conden-
sation principle.
Therefore, the water tap must be open and
the drain hose must drain water into a
sink or into the drain pipe, even during the
drying cycle.
Attention!
Before starting the drying programme, reduce
the loads of washed laundry, in order to obtain
good performances.
1) do not use acetone on artificial silk
13
www.zanussi.com

Laundry not suitable for drying
• Particularly delicate items such as synthetic
curtains, woollen and silk, garments with met-
al inserts, nylon stockings, bulky garments
such as anoraks, bed covers, quilts, sleeping
bags and duvets must not be machine dried.
• Avoid drying dark clothes with light coloured
fluffy items such as towels as these can at-
tract the fluff.
• Remove the laundry when the appliance has
finished drying.
• To avoid a static charge when drying is com-
pleted, use either a fabric softener when you
are washing the laundry or a fabric condition-
er specifically for tumble dryers.
• Garments padded with foam-rubber or mate-
rials similar to foam-rubber must not be ma-
chine dried; they represent a fire hazard.
• Also, fabrics containing residue of setting lo-
tions or hair sprays, nail solvents or similar
solutions must not be machine dried in order
to avoid the formation of harmful vapours.
The detergent and any additives must be placed
in the appropriate compartments of the dis-
penser drawer before starting the wash pro-
gramme.
If using liquid detergents, a programme without
prewash must be selected.
Your appliance incorporates a re-circulation
system which allows an optimal use of the con-
centrated detergent.
Follow the product manufacturer’s recommen-
dations on quantities to use and do not ex-
ceed the «MAX» mark in the detergent dis-
penser drawer.
Garment labels
For drying, follow the indications given on the
manufacturer’s labels:
•= May be tumble dried
•= Drying at high temperature
•= Drying at reduced temperature
•= Do not tumble dry.
Drying cycle duration
The drying time may vary depending on:
• speed of the final spin
• dryness degree required (iron dry, store dry)
• type of laundry
• weight of the load size .
The average drying time for a timed drying are
indicated in the «Drying programmes» chapter.
The experience will help you to dry your laundry
in a more suitable way, according to the differ-
ent fabrics. Take note of the duration drying time
of the already performed cycles.
Additional drying
If the laundry is still damp at the end of the dry-
ing programme, select a short drying cycle
again.
Warning! Do not over dry the laundry
in order to avoid creasing of fabrics
or garment’s shrinking.
First use
• Ensure that the electrical and water con-
nections comply with the installation in-
structions.
• Remove the polystyrene block and any
material from the drum.
• Before the first wash, run a cotton cycle
at the highest temperature without any
laundry in the machine, to remove any
manufacturing residue from the drum
and tub. Pour 1/2 a measure of deter-
gent into the main wash compartment
and start the machine.
14
www.zanussi.com

Personalisation
Acoustic signals
The machine is provided with an acoustic de-
vice, which sounds in the following cases:
• at the end of the cycle
• if there is a fault.
By pressing the 3and 4buttons simultaneously
for about 6 seconds, the acoustic signal is de-
activated (except if there is a fault). By pressing
these 2 buttons again, the acoustic signal is re-
activated.
Child safety lock
This device permits you to leave the appliance
unattended so you do not need to worry that
children might be injured by or cause damage to
the appliance. This function remains enabled al-
so when the washing machine is not working.
There are two different ways to set this option:
1. Before pressing button 7: it will be impossi-
ble to start the machine.
2. After pressing button 7: it will be impossi-
ble to change any other programme or op-
tion.
To enable or disable this option press simulta-
neously for about 6 seconds buttons 2and 3
until on the display, the icon appears or dis-
appears.
Daily Use
Load the laundry
Open the door by
carefully pulling the
door handle out-
wards. Place the
laundry in the drum,
one item at a time,
shaking them out as
much as possible.
Close the door.
Make sure that no
laundry stays be-
tween the seal and
the door. There is a
risk of water leakage
or damage to the
laundry.
Measure out the detergent and the fabric
softener
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent re-
quired, pour it into the main wash compart-
ment or in the appropriate compartment if
the selected programme/option it requires
(see more details in "Detergent dispenser
drawer").
If required, pour fabric softener into the com-
partment marked (the amount used must
not exceed the «MAX» mark in the drawer).
Close the drawer gently.
Select the required programme by means
of the programme selector dial (1)
Turn the programme selector dial to the re-
quired programme.
15
www.zanussi.com

The green pilot light of button 7starts to flash.
The selector dial can be turned either clockwise
or anticlockwise.
Turn the selector dial to position to reset the
programme/to switch the machine OFF.
At the end of the programme the selector
dial must be turned to position , to
switch the machine off.
Important! If you turn the programme selector
dial to another programme when the machine is
working, the red pilot light of button 7will blink
3 times and the messageErr is displayed to
indicate a wrong selection. The machine will not
perform the new selected programme.
Select the spin speed by pressing button 2
When selecting a programme, the appliance
proposes automatically the maximum spin
speed provided for that programme. (See
"Washing programmes" for the maximum al-
lowed spin speed).
Press this button repeatedly to change the spin
speed, if you want your laundry to be spun at a
different speed. The relevant pilot light illumi-
nates.
Select the available options by pressing
the buttons 5 and 6
Depending on the programme, different options
can be combined. These must be selected after
choosing the desired programme and before
starting the programme. When these buttons
are pressed, the corresponding pilot lights illu-
minate. When they are pressed again, the pilot
lights go out. If an incorrect option is selected,
the integrated red pilot light of the button 7
flashes 3 times and the message Err is dis-
played.
For the compatibility among the washing pro-
grammes and the options see chapter «Wash-
ing programmes».
Start the programme by pressing button 7
To start the selected programme, press this
button; the corresponding green pilot light
stops blinking.
The pilot light 9illuminates to indicate that the
appliance starts operating and the door is
locked.
If you have chosen a delayed start, the machine
will begin the countdown.
Important! If an incorrect option is selected,
the message Err is displayed for a few seconds
and the red pilot light of this button blinks 3
times.
Select the Delay Start by pressing button
8
Before you start the programme, if you wish to
delay the start, press this button to select the
desired delay.
The selected delay time value will appear on the
display for a few seconds, then the duration of
the programme will appear again.
You must select this option after you have set
the programme and before you start the pro-
gramme.
You can cancel or modify the delay time at any
moment, before you press button 7.
Selecting the delay start :
1. Select the programme and the required op-
tions.
2. Select the delay start by pressing button 8.
3. Press button 7:
- the machine starts its hourly countdown.
- the programme will start after the selected
delay has expired.
Cancelling the Delay Start after having started
the programme:
1. Set the washing machine to PAUSE by
pressing button 7.
2. Press button 8once. On the display will
appear '.
3. Press button 7again to start the pro-
gramme.
Important!
• The selected delay can be changed only after
selecting the washing programme again.
• The door will be locked throughout the delay
time. If you need to open the door, you must
first set the washing machine to PAUSE by
pressing button 7and wait a few minutes be-
fore opening the door. After you have closed
the door, press the same button again.
16
www.zanussi.com

Important! The Delay Start cannot be
selected with the draining programme.
Altering an option or a running
programme
It is possible to change some options before the
programme carries them out.
Before you make any change, you must pause
the washing machine by pressing button 7.
Changing a running programme is possible only
by resetting it. Turn the programme selector dial
to and then to the new programme position.
Start the new programme by pressing button 7
again.
The washing water in the tub will be not emp-
tied out.
Interrupting a programme
Press the button 7to interrupt a programme
which is running, the corresponding pilot light
starts blinking. Press the button again to restart
the programme.
Cancelling a programme
Turn the selector dial to to cancel a pro-
gramme which is running. Now you can select a
new programme.
Opening the door after the programme
has started
First set the machine to pause by pressing the
button 7.
If the pilot light 9goes off, the door can be
opened.
If the pilot light 9remains lit, this means that the
machine is already heating or that the water lev-
el is too high. In any case, do not force the door!
If you cannot open the door but you need to
open it, switch the machine off by turning the
selector dial to . After a few minutes the door
can be opened.
(Pay attention to the water level and tem-
perature!).
After closing the door, it is necessary to select
the programme and options again and to press
button 7.
At the end of the programme
The machine stops automatically. The blinking
appears on the display, the pilot light of but-
ton 7and the pilot light 9go off.
If a programme or an option that ends with wa-
ter left in the tub has been selected, the pilot
light 9remains on and the door is locked to in-
dicate that the water must be emptied out be-
fore opening the door.
Before you empty out the water, the drum con-
tinues to run at regular intervals until the water
draining.
Follow the below instructions to empty out the
water:
1. Turn the programme selector dial to .
2. Select the draining or spinning programme.
3. Reduce the spin speed if needed, by press-
ing the relevant button.
4. Press button 7.
At the end of the programme, the door is re-
leased and can be opened. Turn the programme
selector dial to to switch the machine off.
Remove the laundry from the drum and carefully
check that the drum is empty. If you do not in-
tend to carry out another wash, close the water
tap. Leave the door open to prevent the forma-
tion of mildew and unpleasant smells.
Stand by : once the programme has finished
after a few minutes the energy saving system
will be enabled. The brightness of the display is
reduced. By pressing any button the appliance
will come out of the energy saving status.
Use - Drying
Drying only
The recommended load size is 3 kg for cottons
and linen, and 2 kg for synthetic items.
By pressing Drying Time button it is also
possible to dry up to 4 kg of cotton items
(see the «Drying Programme» table).
17
www.zanussi.com

The water tap must be open and the drain
hose must be positioned in the sink or
connected to the drain pipe.
1. Load the laundry.
2. Select a spin cycle at the maximum spin
speed allowed for the type of laundry in or-
der to obtain the best drying performances.
3. Select the drying programme for Cottons or
Synthetic in the Drying sector of the pro-
gramme selector dial.
4. If you wish to select an electronic drying,
press the button 3until the pilot light corre-
sponding to the required dryness degree il-
luminates.
5. If you wish to select a timed drying, press
button 4until the time you want appears on
the display (see the «Drying Programmes»
table). Every time you press this button the
drying time increases by 5 minutes.
Note!
The programme time will automatically in-
crease by a few minutes.
6. Press button 7to start the programme.
After the programme has started, the time
remaining is updated every minute.
Note!
The different type of cottons (towelling,
sheets, shirts, and so on) or any laundry
items rolling up during the spinning phase
may result in partial dryness. In the excep-
tional case that at the end of the cycle the
laundry remains slightly wet, we suggest
that you unfold the rolled up items, redis-
tribute them evenly in the drum and select
an additional drying cycle of 20-30 mi-
nutes.
7. At the end of the programme, the buzzer
sounds and a blinking « » appear on the
display.
The last 10 minutes of the drying cycle cor-
respond to an anti-crease phase. During
this time the door is locked and the display
keeps showing the flashing zero « ».
Note!
If you wish to open the door before or dur-
ing the anti-crease phase or to interrupt it,
press any button or turn the programme se-
lector dial to any programme position (ex-
cept ), the door can be opened after a
few minutes.
8. Turn the selector dial to the position to
switch the machine off.
9. Remove the laundry.
Automatic washing and drying (NON-
STOP programme)
For NON-STOP programmes, the recommen-
ded load size is 3 kg for cotton and 2 kg for
synthetic.
Note! It is possible to dry up to 4 kg
of cotton items by pressing Drying
Time button only (see the «Drying Pro-
gramme» table).
Do not use a dosing device/ball when car-
rying out a washing and drying pro-
gramme.
1. Load the laundry.
2. Add detergent and fabric softener.
3. Switch the machine on by turning the se-
lector dial to the selected washing pro-
gramme/fabric.
4. Select the required options by pressing the
relevant buttons.
Note!
If possible, do not select a spin speed low-
er than that proposed by the appliance to
avoid too long a drying time therefore sav-
ing energy.
In any case the reduction of the spin speed
is only possible after selecting drying.
5. Select the drying time by pressing the but-
ton 4or dryness degree by pressing the
button 3. The display shows the entire du-
ration of the washing and the selected dry-
ing cycle.
6. Start the programme by pressing button 7.
After the programme has started, the time
remaining is updated every minute.
7. At the end of the programme the buzzer
sounds. A flashing zero « » appear on the
display.
At this point of the programme, starts an
anti-crease phase which lasts about 10 mi-
18
www.zanussi.com

nutes. During this time the door is locked
and the display keeps showing the flashing
zero « ». (If you wish to open the door be-
fore or during the anti-crease phase, please
follow the instructions given in the previous
chapter).
8. Turn the selector dial to the position to
switch the machine off.
9. Remove the laundry.
Fluff in the garments
During the WASHING AND/OR DRYING
PHASE, certain types of fabric, as sponge-
cloth, sweatshirt, could release fluff.
The released fluff could stick to the fabrics dur-
ing the next cycle.
This drawback increases with technical fabrics.
To prevent the lint in your clothes, it is recom-
mended:
• To do not wash dark fabrics after you washed
and dried light coloured fabrics (new sponge,
sweatshirt especially) and vice versa.
• To air-dry this type of fabrics when they are
washed the first time.
• To clean the filter.
• Perform one or more rinse cycles to wash the
drum between the washing and drying of fab-
rics with different colours.
• After the drying phase, thoroughly clean the
empty drum, the gasket and the door with a
wet rag.
Care and cleaning
Warning! You must DISCONNECT the
appliance from the electricity supply,
before you can carry out any cleaning or
maintenance work.
Descaling
The water we use normally contains lime. It is a
good idea to periodically use a water softening
powder in the machine. Do this separately from
any laundry washing, and according to the soft-
ening powder manufacturer's instructions. This
will help to prevent the formation of lime depos-
its.
External cleaning
Clean the exterior cabinet of the appliance with
soap and water only, and then dry thoroughly.
Cleaning the dispenser drawer
The washing powder and additive dispenser
drawer should be cleaned regularly.
Remove the drawer
by pressing the catch
downwards and by
pulling it out. Flush it
out under a tap, to re-
move any traces of
accumulated powder.
To aid cleaning, the
top part of the addi-
tive compartment
should be removed.
19
www.zanussi.com

Cleaning the drawer recess
Having removed the
drawer, use a small
brush to clean the re-
cess, ensuring that all
washing powder resi-
due is removed from
the upper and lower
part of the recess.
Replace the drawer and run the rinse pro-
gramme without any clothes in the drum.
Cleaning the pump
The pump should be inspected regularly and
particularly if:
• the appliance does not empty and/or spin;
• the appliance makes an unusual noise during
draining due to objects such as safety pins,
coins etc. blocking the pump;
• a problem with water draining is detected
(see chapter “What to do if...” for more de-
tails).
Warning!
1. Disconnect the mains plug from the mains
socket.
2. Do not remove the filter while the appliance
operates. Do not clean the drain pump if
the water in the appliance is hot. The water
must be cold before you clean the drain
pump.
Proceed as follows:
Open the pump door.
Put a container below the recess of the drain
pump to collect the water that flows out.
Press the two levers and pull forward the
drainage duct to let the water flow out.
When the container is full of water, put the
drainage duct back again and empty the con-
tainer. Do steps 3 and 4 again and again until
no more water flows out from the drain pump.
12
Pull back the drainage duct.
Unscrew the filter and remove it.
Remove fluff and objects from the pump.
20
www.zanussi.com
