Zanussi ZKI245 User manual

User
Manual
Washer-
dryer
95°
95°
60°
60°
60°
60°
40°
40°
30°
30°
40°
40°
30°
30°
40°
40°
40°
40°
40°
40°
30°
30°
30°
30°
30°
30°
60°
60°
40°
40°
eco
eco
Anti-kr
Anti-kr
euk
euk
40°
40°
W
W
ol
ol
Spor
Spor
t
t
intensief
intensief
40°
40°
Handw
Handw
as
as
Handw
Handw
as
as
Gor
Gor
dijnen
dijnen
nw
nw
ek
ek
en
en
Spoelen
Spoelen
P
P
ompen
ompen
Centr
Centr
ifuger
ifuger
en
en
ZKI 245
132964630.qxd 17/07/2008 11.43 Pagina 1

2
Content
Safety information - - - - - - - - - - - - - - - - - - -3
Description of the appliance - - - - - - - - - - - -5
Detergent dispenser drawer - - - - - - - - - - - -5
Control panel and functions - - - - - - - - - - - -6
Programme table - - - - - - - - - - - - - - - - - -10
Washing and drying hints - - - - - - - - - - - - -12
Before the first use - - - - - - - - - - - - - - - - -14
Operating Sequence - - - - - - - - - - - - - - - -15
Washing only - - - - - - - - - - - - - - - - - - - - -15
Drying only and autodrying - - - - - - - - - - -17
Drying Times - - - - - - - - - - - - - - - - - - - - -18
Care and cleaning - - - - - - - - - - - - - - - - - -19
What to do if... - - - - - - - - - - - - - - - - - - - - 21
Technical data- - - - - - - - - - - - - - - - - - - - - 24
Consumption values - - - - - - - - - - - - - - - - 25
Installation instruction - - - - - - - - - - - - - - - 25
Environmental concerns - - - - - - - - - - - - - 31
Thank you for selecting our appliance
We wish you lots of enjoyment with your new appliance and we hope that you will consider our
brand again when purchasing household appliances.
Please read this user manual carefully and keep it throughout the product life cycle as a reference
document. The user manual should be passed on to any future owner of the appliance.
The following symbols are used in this manual:
Important information concerning your personal safety and information on how to avoid
damaging the appliance.
General information and tips
Environmental information
132964630.qxd 17/07/2008 11.43 Pagina 2

3
Safety information
In the interest of your safety and to ensure
the correct use, before installing and first
using the appliance, read this user manual
carefully, including its hints and warnings.
To avoid unnecessary mistakes and
accidents, it is important to ensure that all
people using the appliance are thoroughly
familiar with its operation and safety
features. Save these instructions and make
sure that they remain with the appliance if it
is moved or sold, so that everyone using it
through its life will be properly informed on
appliance use and safety.
General safety
●It is dangerous to alter the specifications or
attempt to modify this product in any way.
●During high temperature wash programmes
the door glass may get hot. Do not touch it!
●Make sure that small pets do not climb into
the drum. To avoid this, please check into
the drum before using.
●Any objects such as coins, safety pins, nails,
screws, stones or any other hard, sharp
material can cause extensive damage and
must not be placed into the machine.
●Only use the advised quantities of fabric
softener and detergent. Damage to the fabric
can ensue if you over-fill. Refer to the
manufacturer’s recommendations of
quantities.
●Wash small items such as socks, laces,
washable belts etc in a washing bag or
pillow case as it is possible for such items to
slip down between the tub and the inner
drum.
●Do not use your washer-dryer to wash
articles with whalebones, material without
hems or torn material.
●Always unplug the appliance and turn off the
water supply after use, cleaning and
maintenance.
●Under no circumstances should you attempt
to repair the machine yourself. Repairs
carried out by inexperienced persons may
cause injury or serious malfunctioning.
Contact your local Service Centre. Always
insist on genuine spare parts.
Installation
●This appliance is heavy. Care should be
taken when moving it.
●When unpacking the appliance, check that it
is not damaged. If in doubt, do not use it and
contact the Service Centre.
●All packing and transit bolts must be
removed before use. Serious damage can
occur to the product and to property if this is
not adhered to. See relevant section in the
user manual.
●After having installed the appliance, check
that it is not standing on the inlet and drain
hose and the worktop is not pressing the
electrical supply cable.
●If the machine is situated on a carpeted floor,
please adjust the feet in order to allow air to
circulate freely under the appliance.
●Always be sure, that there is no water
leakage from hoses and their connections
after the installation.
●If the appliance is installed in a location
subject to frost, please read the «dangers of
freezing» chapter.
●Any plumbing work required to install this
appliance should be carried out by a
qualified plumber or competent person.
●Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
132964630.qxd 17/07/2008 11.43 Pagina 3

4
Use
●This appliance is designed for domestic use.
It must not be used for purposes other than
those for which it was designed.
●Only wash fabrics which are designed to be
machine washed. Follow the instructions on
each garment label.
●Do not overload the appliance. See the
relevant section in the user manual.
●Before washing, ensure that all pockets are
empty and buttons and zips are fastened.
Avoid washing frayed or torn articles and
treat stains such as paint, ink, rust, and
grass before washing. Underwired bras must
NOT be machine washed.
●Garments which have been in contact with
volatile petroleum products should not be
machine washed. If volatile cleaning fluids
are used, care should be taken to ensure
that the fluid is removed from the garment
before placing in the machine.
●Never pull the power supply cable to remove
the plug from the socket; always take hold of
the plug itself.
●Never use the washer-dryer if the power
supply cable, the control panel, the working
surface or the base are damaged so that the
inside of the washer-dryer is accessible.
Child safety
●This appliance is not intended for use by
person (including children) with reduced
physical sensory or mental capabilities or
lack of experience and knowledge unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
●The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children -
danger of suffocation! Keep them out of
children’s reach
●Keep all detergents in a safe place out of
children’s reach.
●Make sure that children or pets do not climb
into the drum. To prevent children or pets
becoming trapped inside the drum the
machine incorporates special feature.
To disable this
device and restore
the possibility of
closing the door,
rotate the button anti-
clockwise until the
groove is vertical.
To activate this
device, rotate the
button (without
pressing it) inside the
door clockwise until
the groove is
horizontal. If
necessary use a coin.
132964630.qxd 17/07/2008 11.43 Pagina 4

5
Description of the appliance
Detergent dispenser drawer
Prewash
Wash
Fabric Softener
Detergent dispenser drawer
Control panel
Door opening handle
Rating plate
Drain pump
Adjustable feet
6
5
4
3
2
1
132964630.qxd 17/07/2008 11.43 Pagina 5

Control panel
2 4 5 67
3
18 10
9
Programme selector dial and
On/Off switch
●The programme selector dial allows to select a
programme and/or to switch the machine on/off «O». It
can be turned either clockwise or anticlockwise.
Spin reduction button and
Rinse Hold option
●Press this button repeatedly to change the spin speed, if
you want your laundry to be spun at a speed different
from the one proposed by the washer-dryer or to select
«Rinse Hold» option.
●The relevant light will light up.
1
2
Information
The control panel is illustrated above. It shows the programme selector dial as well as the different
buttons, the pilot light(s) and the display. These are represented by relevant numbers which are
explained in the table below.
Symbols:
= Cotton, = Synthetics, = Delicates, = Drying sector
= Rinses, = Drain, = Spin, = Rinse Hold, = Economy, = Super Quick,
= Door, = Child Safety Lock
6
132964630.qxd 17/07/2008 11.43 Pagina 6

7
Option button:
Economy, Super Quick
●By pressing this button, you can select only one of the
following options: ECONOMY or SUPER QUICK.
●The relevant light will light up.
Start/Pause button
●This button allows to start the selected programme; the
corresponding green pilot light stops flashing.
●This button interrupts also a programme which is running,
the corresponding green pilot light starts to flash.
Door pilot light
●This light illuminates when the appliance is working (after
having pressed button 8and indicates that the door is
locked.
Display
●The display shows the following information: duration of
the selected programme, selected drying time and
delayed start, incorrect option selection, alarm codes,
child safety lock and end of programme.
7
Easy Iron button
●Selecting this option the laundry is gently washed and
spun to avoid any creasing. In this way ironing is easier.
Furthermore the machine will perform additional rinses.
6
3
8
9
Delay button
●By pressing this button, the wash programme can be
delayed from 30 min - 60 min - 90 min, 2 hours and then
by 1 hour up to a maximum of 20 hours. The delay value
appears on the display.
10
Extra Rinse button ●By pressing this button, the machine performs some
additional rinses. The corresponding pilot light illuminates.
4
Drying Time button ●By pressing this button you can select a timed drying for
cotton or synthetics, the relevant light illuminates.
5
132964630.qxd 17/07/2008 11.43 Pagina 7

8
Rinse hold (Button 2)
By selecting this option the water of the last
rinse is not emptied out to prevent the fabrics
from creasing. When the programme has
finished, the door is locked to indicate that the
water must be empty out. To empty out the
water, please read the chapter «At the end of
the programme».
Economy (Button 3)
Only for cottons and synthetics items lightly or
normally soiled at a temperature of 40°C or
higher. The washing time will be prolonged and
the washing temperature will be reduced.
Super Quick (Button 3)
Short cycle for lightly soiled items or for laundry
which needs only freshening up.
We recommend that you reduce the fabrics
loading.
Extra Rinse (Button 4)
The machine performs some additional rinses
during the washing cycle. This option is
recommended for people who are allergic to
detergents, and in areas where the water is
very soft.
Drying Time button (Button 5)
By pressing this button you can select a timed
drying for cotton or synthetics. The relevant
light illuminates.
For Cottons you can select a drying time from
10 minutes to 250 minutes (4.10) while for
Synthetics from 10 minutes to 130 minutes
(2.10). Every time you press the button the
time increases by 5 mins.
Easy Iron (Button 6)
Selecting this option the laundry is gently
washed and spun to avoid any creasing. In this
way ironing is easier. Furthermore the machine
will perform some additional rinses depending
on the fabrics.
Door pilot light (9)
After having pressed the button 8, this light
illuminates and stays on.
This light indicates when the door can be
opened:
●light on: the door is locked and cannot be
opened. The washing or the drying cycle
starts working and the door is locked.
●light off: the door can be opened. The
washing programme has finished.
If there is water left in the tub, the light 9
remains lit. The door will be still locked and it
will be necessary to empty out before
opening the door.
Functions
132964630.qxd 17/07/2008 11.43 Pagina 8

9
The display shows the following information:
Duration of the programme/
After selecting a programme the duration of
the selected programme appears in minutes
or hours and minutes on the display .(e.g.
2.05)
During the programme, the time remaining is
updated every minute.After having started the
programme, the light 9lights up and stays on.
/Selected drying time
After selecting a drying programme the drying
time is shown in minutes or hours and minutes.
After the programme has started, the time
remaining is updated every minute.
/Delay Start
The Delayed start appears on the display for a
few seconds, then the duration of the
previously selected programme is displayed.
The delay time value decreases by one unit
every hour, 90 minutes and then, when 1 hour
remain, every minute.
/Incorrect option selection
The incorrect option selection is indicated by
the message Err displayed for a few seconds
and by flashing of the red light of button 8.
5.1
2.05
5.15.2
/Alarm codes
In the event of operating problems, some
alarm codes can be displayed, (see paragraph
“What to do if...”).
/End of programme
The End of programme or the stop wit water
left in the tub is indicated by a flashing zero
«0».
«Stand by»
If your laundry is not removed within 10
minutes after the programme is finished, the
backlight of the display switches off and the
energy saving system will be enabled.
Only the button 8pilot light is blinking to
indicate that the appliance has to be switched
off.
By pressing any button the appliance will come
out from the energy saving status and you
could set another washing programme or swich
off the appliance.
Child Safety lock
This device permits you to leave the appliance
unattende during its functioning.
5.2
132964630.qxd 17/07/2008 11.43 Pagina 9

10
Programme table
SYNTHETICS
60° - 40° -
30° - Cold
Synthetic or mixed
fabrics
Spin Red. / Rinse Hold,
Super Quick(**),
Economy(*), Easy Iron,
Extra Rinse
Main wash
Rinses, short spin - 900
rpm
Max load: 3 Kg
**Load reduced: 1,5 Kg
DELICATES
40° -
30° - Cold
Delicate items
Rinse Hold,
Super Quick(**),
Extra Rinse
Main wash, rinses, short
spin - 700 rpm
Max load: 3 Kg
Load reduced: 1,5 Kg
Programme/
Temperature Type of laundry Options Description of programme
COTTON
90° - 60°
White cotton (normally
soiled items)
Spin Red. / Rinse Hold,
Super Quick(**),
Economy, Easy Iron,
Extra Rinse
Main wash
Rinses, long spin -1400
rpm
Max load: 6 Kg
**Load reduced: 3 Kg
COTTON
60° - 40° -
30° - Cold
White and coloured
cotton (normally soiled
cotton items)
Spin Red. / Rinse Hold,
Super Quick(**),
Economy(*), Easy Iron,
Extra Rinse
Main wash
Rinses, long spin - 1400
rpm
Max load: 6 Kg
**Load reduced: 3 Kg
(*) This option is not active at a temperature lower than 40°C.
(**)If you select the «Super Quick» option by pressing button 3, we recommend that you reduce
the maximum load as indicated in the table above. Full loading is possible however with
somewhat reduced cleaning results.
COTTON
90° + Prewash
White cotton
(white cotton items
heavily soiled )
Spin red./ Rinse Hold,
Super Quick(**),
Economy, Easy Iron,
Extra rinse
Prewash, Main wash,
Rinses, Long spin -
1400 rpm
Max Load: 6 kg
**Reduced Load: 3 kg
COTTON
60° + Prewash
White cotton and fast
colour cotton
(cotton items heavily
soiled )
Spin red./ Rinse Hold,
Super Quick(**),
Economy, Easy Iron,
Extra rinse
Prewash, Main wash,
Rinses, Long spin -
1400 rpm
Max Load: 6 kg
**Reduced Load: 3 kg
COTTON
40° + Prewash
Cotton colour
(cotton colour items
heavily soiled )
Spin red./ Rinse Hold,
Super Quick(**),
Economy, Easy Iron,
Extra rinse
Prewash, Main wash,
Rinses, Long spin -
1400 rpm
Max Load: 6 kg
**Reduced Load: 3 kg
132964630.qxd 17/07/2008 11.43 Pagina 10

11
Programme table
Programme/
Temperature Type of laundry Options Description of programme
JEANS
40°
Special programme for
free time items as denim,
pants, shirts or jackets,
jersey made of hi-tech
materials. Some extra
rinses will be carried out
Spin Red. / Rinse Hold,
Easy Iron
Main wash
Rinses, long spin - 1200
rpm
Max load: 3 Kg
RINSES
Separate rinses cycle for
hand washed cotton
items. According to the
fabrics, it is possible to
choose a different speed
by pressing the relevant
button from one proposed
by the machine.
Spin Red./ Rinse Hold,
Easy Iron, Extra Rinse
Rinses, long spin at the
max speed - 1400 rpm
Max load: 6 Kg
DRAIN
For emptying out the
water in programmes
which stop with water in
the tub. First, turn the
programme selector dial to
«O»
Draining of water
SPIN
Long spin at max speed
for handwashed cotton
items or for emptying out
the water in the tub
Drain and long spin at
the max speed - 1400
rpm
Max load: 6 Kg
O = Cancelling
/ Switching off
the machine
To interrupt a running programme, to cancel an
incorrect option selection or to switch the machine
off.
Spin Red.
HAND WASH
40° - 30° - Cold
Special programme for
hand washed fabrics
Note: A single or bulky
item may cause
imbalance. If the
appliance doesn’t perform
the final spin phase, add
more items, redistribute
the load manually and
then select the spinning
programme.
Spin Red. / Rinse Hold
Main wash, rinses,
Short spin - 900 rpm
Max load: 2 Kg
132964630.qxd 17/07/2008 11.43 Pagina 11

12
Washing and drying hints
Sorting the laundry
Follow the wash code symbols on each
garment label and the manufacturer’s washing
instructions. Sort the laundry as follows: whites,
coloureds, synthetics, delicates, woollens.
Temperatures
Before loading the laundry
Never wash whites and coloureds together.
Whites may lose their «whiteness» in the
wash. New coloured items may run in the first
wash; they should therefore be washed
separately the first time.
Make sure that no metal objects are left in
the laundry (e.g. hair clips, safety pins,
pins). Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any belts
or long tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special
detergent or detergent paste. Treat curtains
with special care. Remove hooks or tie them
up in a bag or net.
Avoid drying dark clothes with light coloured
fluffy items such as towels as these can attract
the fluff.
Remove the laundry when the appliance has
finished drying.
To avoid a static charge when drying is com-
pleted, use either a fabric softener when you
are washing the laundry or a fabric conditioner
specifically for tumble dryers.
Particularly delicate items such as synthetic
curtains, woollen and silk, garments with metal
inserts, nylon stockings, bulky garments such
as anoraks, bedcovers, quilts, sleeping bags
and duvets must not be machine dried.
Garments padded with foam-rubber or materi-
als similar to foam-rubber must not be machine
dried; they represent a fire hazard.
Also, fabrics containing residues of setting
lotions or hair sprays, nail solvents or similar
solutions must not be machine dried in order to
avoid the formation of harmful vapours.
For drying, follow the indications given on the
manufacturer’s labels.
For drying, follow the indications given on the
manufacturer’s labels.
May be tumble dried
Drying at high temperature
Drying at reduced temperature
Do not tumble dry
IMPORTANT!
As a dryer, the machine works on the
condensation principle.
Therefore, the water tap must be open and
the drain hose must drain water into a sink
or into the drain pipe, even during the dry-
ing cycle.
Maximum loads
Recommended loads are indicated in the
programme charts. General rules:
Cotton, linen: drum full but not too tightly
packed;
90° or 95°
for normally soiled white cottons
and linen (e.g. tea cloths, towels,
tablecloths, sheets...)
50°/60°
for normally soiled, colour fast
garments (e.g. shirts, night
dresses, pyjamas....) in linen,
cotton or synthetic fibres and for
lightly soiled white cotton (e.g.
underwear).
30°-40°
cold
for delicate items (e.g. net
curtains), mixed laundry including
synthetic fibres and woollens
bearing the label «pure new wool,
machine washable, non-shrink».
132964630.qxd 17/07/2008 11.43 Pagina 12

(whites and fast coloureds only).
Ball point pen and glue: moisten with
acetone (*), lay the garment on a soft cloth and
dab the stain.
Lipstick: moisten with acetone as above, then
treat stains with methylated spirits. Remove
any residual marks from white fabrics with
bleach.
Red wine: soak in water and detergent, rinse
and treat with acetic or citric acid, then rinse.
Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the
fabric first with acetone (*), then with acetic
acid; treat any residual marks on white fabrics
with bleach and then rinse thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub with
detergent paste.
(*) do not use acetone on artificial silk.
Detergents and additives
Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the
environment. Although biodegradable,
detergents contain substances which, in large
quantities, can upset the delicate balance of
nature.
The choice of detergent will depend on the
type of fabric (delicates, woollens, cottons,
etc.), the colour, washing temperature and
degree of soiling.
All commonly available washing machine
detergents may be used in this appliance:
●powder detergents for all types of fabric,
●powder detergents for delicate fabrics (60°C
max) and woollens,
●liquid detergents, preferably for low
temperature wash programmes (60°C max)
for all types of fabric, or special for woollens
only.
The detergent and any additives must be
placed in the appropriate compartments of the
dispenser drawer before starting the wash
programme.
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more
than one third full.
Washing a maximum load makes the most
efficient use of water and energy. For heavily
soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
Removing stains
Stubborn stains may not be removed by just
water and detergent. It is therefore advisable to
treat them prior to washing.
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a
special detergent then rub in the soap and
water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and
dab the stain; treat several times.
Dried grease stains: moisten with turpentine,
lay the garment on a soft surface and dab the
stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a
rust removing product used cold. Be careful
with rust stains which are not recent since the
cellulose structure will already have been
damaged and the fabric tends to hole.
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach
1200 gbathrobe
100 gnapkin
700 gquilt cover
500 gsheet
200 gpillow case, towelling towel
250 gtablecloth
200 gnight dress
100 gladies’ briefs, tea cloth
200 gman’s work shirt
100 gman’s shirt
600 gman’s pyjamas
200 gblouse, men’s underpants
13
132964630.qxd 17/07/2008 11.43 Pagina 13

14
If using concentrated powder or liquid
detergents, a programme without prewash
must be selected.
The washing dryer incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.
Pour liquid detergent into the dispenser drawer
compartment marked just before starting
the programme.
Any fabric softener or starching additives must
be poured into the compartment marked
before starting the wash programme.
Follow the product manufacturer’s
recommendations on quantities to use and do
not exceed the «MAX» mark in the
detergent dispenser drawer.
Before the first use
WARNING!
Ensure that the electrical and water
connections comply with the installation
instructions.
IMPORTANT!
Remove the polystyrene block and any
material from the drum.
IMPORTANT!
Before the first wash we reccend you to run a
cotton cycle at the 90°C, without any laundry in
the machine, to remove any manufacturing
residue from the drum and tub. Pour 1/2 a
measure of detergent into the main
compartement of the dispenser drawer and
start the machine.
Acoustic signals
The machine is provided of an acoustic device,
which sounds in the following cases:
●at the end of the cycle
●in the event of operating problems
By pressing the buttons 4and 5
simultaneously for about 6 seconds, the
acoustic signal is deactivated (except for the
events of operating problems).
By pressing these 2 buttons again, the the
acoustic signal is reactivated.
Child safety lock
This device permits you to leave the appliance
unattended during its functionning, so avoiding
that children might accidentally start the
machine or modify a running programme.
This function remains able also when the
washer-dryer is not working.
To enable (disable) this option press
simultaneously for about 6 seconds buttons 2
and 3buttons until the icon appears
(disappears) on (from) the display.
There are two different ways to set this option:
●before pressing the button 8:
it will be impossible to start the machine.
●after pressing the button 8:
it will be impossible to change any other
programme or option.
Quantity of detergent to be used
The type and quantity of detergent will depend
on the type of fabric, load size, degree of soiling
and hardness of the water used. Water hardness
is classified in so-called «degrees» of hardness.
Information on hardness of the water in your
area can be obtained from the relevant water
supply company, or from your local authority.
Follow the product manufacturers’ instructions
on quantities to use.
Degrees of water hardness
Follow the product manufacturers’ instructions
on quantities to use. Use less detergent if:
●you are washing a small load,
●the laundry is lightly soiled,
●large amounts of foam form during washing.
132964630.qxd 17/07/2008 11.43 Pagina 14

15
Operating sequence - Washing only
1. Load the laundry
Open the door by
carefully pulling the
door handle outwards.
Place the laundry in
the drum, one item at
a time, shaking them
out as much as
possible. Close the door.
2. Measure out the detergent and the fabric
softener
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent required,
pour it into the main wash compartment
and, if you wish to carry out a programme with
the prewash, pour it into the compartment
marked .
If required, pour fabric softener into the
compartment marked (the amount used
must not exceed the «MAX» mark in the
drawer). Close the drawer gently.
Select the required programme by means of
the programme selector dial (1)
Turn the programme selector dial to the
required programme. The green light of button
8starts to flash. It can be turned either
clockwise or anticlockwise.
On position «O» the programme is reset and
the machine is switched off.
At the end of the programme the selector
dial must be turned to position «O», to
switch the machine off.
ATTENTION!
If you turn the programme selector dial to ano-
ther programme when the machine is working,
the red pilot light of button 8will flash 3 times
and the message Err is displayed on the dis-
play to indicate a wrong selection. The machi-
ne will not perform the new selected program-
me.
Select the spin speed or the Rinse Hold
option by pressing button 2
When selecting a programme, the light
corresponding to the maximum speed allowed
for that programme will illuminate. The relevant
light will light up.
Select the desired option by pressing
buttons 3, 4 and 6
Depending on the programme, different
functions can be combined. These must be
selected after choosing the desired programme
and before depressing the button 8.
For the compatibility of the options with the
washing programmes, refer to the section
«Programmes table».
Select the delayed start by pressing the
button 10
Press this button to select the required delay.
The selected delay time value will appear on
the display for a few seconds, then the duration
of the programme will appear again.
You must select this option after you have set
the programme and before you press the
button 8.
You can cancel the delay time at any moment,
before you press button 8. If you have already
pressed it, and you wish to cancel the delay
time, proceed as follows:
• set the washer-dryer to PAUSE by pressing
button 8;
132964630.qxd 17/07/2008 11.43 Pagina 15

• press the button 10 once. On the display will
appear the symbol «0’».
• press button 8 again to start the programme.
IMPORTANT!
• The selected delay can be modified only after
you have turned the programme selector dial
to the «O» position and after you have
selected the programme again.
• The door will be locked throughout the delay
time. If you need to open the door, you must
first set the washer-dryer to PAUSE by
pressing button 8.The door can be opened
immediately or after a few minutes depending
on the model. (In any case do not try to open
the door if it is locked!). After you have closed
the door, press the same again.
Note!
The Delay Start cannot be selected with
«Drain» programme.
Start the programme by pressing button 8
To start the selected programme, press this
button; the corresponding green pilot light
stops flashing.
The pilot light 9illuminates to indicate that the
appliance starts operating and the door is
locked.
If a delayd start has been selected, the display
shows the countdown.
IMPORTANT!
If an option which is not compatible with the set
wash programme is selected, the message Err
is displayed for a few seconds and the red light
of this button flashes for 3 times.
Altering an option or a running programme
It is possible to change some options before
the programme carries them out.
Before you make any change, you must pause
the washer-dryer by pressing button 8.
Changing a running programme is possible
only by resetting it. Turn the programme
selector dial to «O» and then to the new
programme position. Start the new programme
by pressing button 8again.
The washing water in the tub will not empty out.
Interrupting a programme
Press the button 8to interrupt a programme
which is running, the corresponding light starts
to flash. Press the button again to restart the
programme.
Cancelling a programme
Turn the selector dial to «O» to cancel a
programme which is running. Now you can
select a new programme.
Opening the door after the programme has
started
First set the machine to pause by pressing the
button 8. If the light 9 goes off, the door can
be opened immediately or after a few minutes
depending on the model.
If it does not switch off, this means that the
machine is already heating or that the water
level is too high. In this cases the door cannot
be opened.
If you cannot open the door but you need to
open it you have to switch the machine off by
turning the selector dial to «O». After a few
minutes the door can be opened
(Pay attention to the water level and
temperature!). After this procedure, it will be
necessary to set the programme and the
options again and then to press button 8.
At the end of the programme
The machine stops automatically. Some
acustic signals sound and on the display will
appear a flashing «0 ». The light of button 8
and the light 9 go off. The door can be
opened.
If at the end of a programme there is water in
the tub, the light 9remains on and the door is
locked to indicate taht the door must be empty
out.
132964630.qxd 17/07/2008 11.43 Pagina 16

17
To empty out the water follow the following
instructions:
1. turn the programme selector dial to «O»
2. select the draining or spinning programme
3. reduce the spin speed, if needed, by
pressing the button 2
4. press button 8
5. at the end of programme, the display shows
a flashing zero «0», the light 9goes off and
it will be possible to open the door.
At the end of the cycle, turn the programme
selector dial to «O» to switch the machine off.
Remove the laundry from the drum and
carefully check that the drum is empty.
If you do not intend to carry out another wash,
close the water tap.
Leave the door open to prevent the formation
of mildew and unpleasant smells.
The recommended load to dry in your washer-
dryer is 3 kg for cotton and 2 kg for synthetics.
Note! It is also possible to dry up to 4 kg of
cotton items (see the drying time table).
The water tap must be open and the drain
hose must be positioned in the sink or connect-
ed to the drain pipe.
1. Load the laundry.
2. Turn the selector dial to «Cotton» or
«Synthetics» programme in the «Drying»
sector.
3. Select the duration of the drying cycle by
pressing repeatedly button 5until the time
you want appears on the display (see the
drying programmes).
For Cottons you can select a drying time
from 10 minutes to 250 minutes (4.10).
For Synthetics you can select a drying
time from 10 minutes to 130 minutes
(2.10). Every time you press the button the
time increases by 5 mins.
Note! The drying time will automatically
increase by up to 2 minutes. This is quite nor-
mal.
4. Press the button 8to start the programme.
After the programme has started, the time
remaining is updated every minute.
5. At the end of the programme, the buzzer
sounds. A flashing zero «0» will appear on
the display. At this point, begins an «anti-
crease phase», which lasts about 10 min-
utes. The light 9is on, the door is locked
and can be opened only at the end of this
phase.
Attention! If you wish to open the door
before the anti-crease phase or to interrupt
it, press any key or turn the programme
selector dial to any programme position
(except «O»). The door can be opened
immediately or in a few minutes depending
on the model.
6. Turn the selector dial to the «O» position
to switch the machine off. Remove the
laundry.
AUTODRYING
Warning! For NON-STOP programmes, the
recommended load to wash and dry in your
washer-dryer is 3 kg for cotton and 2 kg for
synthetics.
Note! It is also possible to dry up to 4 kg of
cotton items (see the drying time table).
Do not use a dosing device/ball when carrying
out a washing & drying programme.
1. Load the laundry.
2. Add detergent and fabric softener.
3. Switch the machine on by turning the
selector dial to the selected wash pro-
gramme/fabric.
Drying only and autodrying (NON-STOP programme)
132964630.qxd 17/07/2008 11.43 Pagina 17

18
4. Select the drying time (see the drying pro-
grammes).
5. Select the required options by pressing the
relevant buttons. The display shows the
entire duration of the washing and the
selected drying cycle.
If possible, do not select a spin speed
lower than that proposed by the appliance
to avoid a too long drying time so saving
energy.
In any case the reduction of the spin speed
is only possible after selecting drying.
6. Start the programme by pressing the button
8. After the programme has started, the
time remaining on the display is updated
every minute.
7. At the end of the programme the buzzer-
sounds. A flashing zero «0» appear on the
display. At this point of the programme,
starts an anti-crease phase which lasts
about 10 minutes. During this time the door
is locked and the display keeps showing
the flashing zero «0». (If you wish to open
the door before or during the anti-crease
phase, please follow the instructions given
in the previous chapter).
8. Turn the selector dial to the «O» position
to switch the machine off.
9. Remove the laundry.
Type of fabric Spin speed Suggested drying
times in mins
140 - 1601400 rpm
4 kg
110 - 1301400 rpm
4 kg
1400 rpm 80 - 903 kg
1400 rpm 40 - 501.5 kg
Suitable for
items to put
away without
ironing
Cotton and linen (bathrobes,
bath towels, etc
Synthetics and mixed fab-
rics (jumpers, blouses,
underwear, household linen)
900 rpm
2 kg 65 - 75
900 rpm
1 k g 30 - 40
In compliance with EC directive EN 50229 the cotton reference programme for the data entered
in the Energy Label must be tested dividing the maximum washing load by two equal parts and
drying with TIMED DRYING each of them.
NOTE!
The different type of cottons (towelling, sheets, shirts and so on) or eventual laundry rolling up
during spinning phase may cause a not uniform dryness. So, in the exceptional case that, at the
end of the cycle, the laundry remains slightly wet, we suggest you to stretch the items rolled up
out, to redistribute evenly the laundry in the drum and to select an additional drying cycle of 20-30
minutes.
Max
Load
Suitable
for ironing
Cotton and linen (sheets,
tablecloths, shirts, etc.) 1400 rpm 65 - 75
1400 rpm 35 - 45
3 kg
1.5 kg
Drying times
Degree of drying
132964630.qxd 17/07/2008 11.43 Pagina 18

19
IMPORTANT!
You must DISCONNECT the appliance from
the electricity supply, before you can carry out
any cleaning or maintenance work.
Descaling
The water we use normally contains lime. It is
a good idea to periodically use a water
softening powder in the machine. Do this
separately from any laundry washing, and
according to the softening powder
manufacturer's instructions. This will help to
prevent the formation of lime deposits.
Maintenance Wash
With the use of low temperature washes it is
possible to get a build up of residues inside the
drum.
We recommend that a maintenance wash be
performed on a regular basis.
To run a maintenance wash:
●The drum should be empty of laundry.
●Select the hottest cotton wash programme.
●Use a normal measure of detergent, must be
a powder with biological properties.
External cleaning
Clean the exterior cabinet of the appliance with
soap and water only, and then dry thoroughly.
Cleaning the dispenser drawer
The washing powder and additive dispenser
drawer should be cleaned regularly.
To aid cleaning, the top part of the additive
compartment should be removed.
Remove the drawer by pressing the catch
downwards and by pulling it out. Flush it out
under a tap, to remove any traces of
accumulated powder.
Cleaning the drawer recess
Having removed the
drawer, use a small
brush to clean the
recess, ensuring that
all washing powder
residue is removed
from the upper and
lower part of the
recess.
Replace the drawer and run the rinse
programme without any clothes in the drum.
Cleaning the pump
The pump should be inspected if
●the machine does not empty and/or spin
●the machine makes an unusual noise during
draining due to objects such as safety pins,
coins etc. blocking the pump.
Proceed as follows:
●Disconnect the appliance.
●If necessary wait until the water has cooled
down.
●Place a container
close to the pump (A)
to collect any spillage.
●Pull out the
emergency emptying
hose (B), place it in
the container and
remove its cap.
●When no more water comes out, unscrew the
pump cover and remove it. Always keep a
rag nearby to dry up spillage of water when
removing the cover.
B
A
Care and cleaning
132964630.qxd 17/07/2008 11.43 Pagina 19

20
●Remove any objects from the pump impeller
by rotating it.
●Put the cap back on the emergency emptying
hose and place the latter back in its seat.
●Screw the pump cover fully in.
IMPORTANT!
When the appliance is in use and depending
on the programme selected there can be hot
water in the pump.
Never remove the pump cover during a wash
cycle, always wait until the appliance has
finished the cycle, and is empty. When
replacing the cover, ensure it is securely
retightened so as to stop leaks and young
children being able to remove it.
Cleaning the water inlet filter
If your water is very hard or contains traces of
lime deposit, the water inlet filter may become
clogged. It is therefore a good idea to clean it
from time to time.
Turn off the water tap.
Unscrew the water
inlet hose. Clean the
filter using a hard
bristle brush.
Tighten up the inlet
hose.
The dangers of freezing
If the machine is exposed to temperatures
below 0°C, certain precautions should be taken.
●Turn off the water tap.
●Unscrew the inlet hose.
●Place the end of the emergency emptying
hose and that of the inlet hose in a bowl
placed on the floor and let water drain out.
●Screw the water inlet hose back on and
reposition the emergency emptying hose
after having put the cap on again.
●When you intend to start the machine up
again, make sure that the room temperature
is above 0°C.
Emergency emptying out
If the water is not discharged, proceed as
follows to empty out the machine:
●pull out the plug from the power socket;
●close the water tap;
●if necessary, wait until the water has cooled
down;
●place a bowl on the floor and place the end
of the emergency emptying hose into the
bowl. Remove its cap. The water should
drain by gravity into the bowl. When the bowl
is full, put the cap back on the hose. Empty
the bowl. Repeat the procedure until water
stops flowing out;
●clean the pump if necessary as previously
described;
●replace the emergency emptying hose in its
seat after having plugged it;
●screw the pump cover again.
132964630.qxd 17/07/2008 11.43 Pagina 20
