Zanussi ZWD 71460 CW User manual

GETTING
STARTED?
EASY.
User Manual
ZWD 71460 CW
EN User Manual
Washer Dryer

SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible for any
injuries or damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and accessible
location for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons with very
extensive and complex disabilities shall be kept away unless
continuously supervised.
•Children of less than 3 years of age should be kept away
unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when the door
is open.
•If the appliance has a child safety device, it should be activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
GENERAL SAFETY
•Do not change the specification of this appliance.
•The appliance shall be installed as a freestanding product or
below the kitchen worktop if space margins permit.
2

•Do not install the appliance behind a lockable door, a sliding
door or a door with a hinge on the opposite side, that would
prevent the appliance door from being fully open.
•Connect the mains plug to the mains socket only at the end of
the installation process. Make sure that the mains plug is
accessible after installation.
•The ventilation opening in the base must not be covered by a
carpet, mat, or any floor covering.
•WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by a utility.
•Ensure good air ventilation in the room where the appliance is
installed to avoid the backflow of unwanted gases into the room
from appliances burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is used for
exhausting fumes from any appliances burning gas or other
fuels.
•The operating water pressure at the water entry point from the
outlet connection must be between 0.5 bar (0.05 MPa) and 8
bar (0.8 MPa).
•Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
•The appliance must be connected to the water mains using the
new supplied hose sets, or other new hose sets supplied by
the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre or
similarly qualified persons to avoid an electrical hazard.
•Wipe away lint or packaging debris that has accumulated
around the appliance.
•Items that have been soiled with substances such as vegetable
or mineral oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed
separately with an extra amount of detergent before being dried
in the washer dryer.
3

•Do not use the appliance if items have been soiled with
industrial chemicals.
•Do not dry unwashed items in the wash dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and clothes, or
pillows fitted with foam rubber pads should not be dried in the
washer dryer.
•Fabric softeners, or similar products, should only be used as
specified by the product manufacturer’s instructions.
•Remove all objects from items that could be a source of fire
ignition such as lighters or matches.
•Never stop the washer dryer before the end of the drying cycle
unless all items are quickly removed and separated so that
residual heat can dissipate.
•The final part of the washer dryer cycle takes place without heat
(cool down cycle) to ensure that items reach a temperature that
will not cause damage to them.
•Do not use high pressure water sprays and/or steam to clean
the appliance.
•Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
SAFETY INSTRUCTIONS
INSTALLATION
The installation must comply with
relevant national regulations.
• Follow the installation instructions supplied with
the appliance.
• Do not install or use the appliance where the
temperature can be less than 0°C or where it is
exposed to the weather.
• Always keep the appliance vertical when being
moved.
• Make sure that there is air circulation between
the appliance and the floor.
• Remove all the packaging and the transit bolts.
• The floor area on which the appliance is to be
installed must be flat, stable, heat resistant and
clean.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in the future they must
be reattached to lock the drum to prevent an
internal damage.
• Always take care when moving the appliance as
it is heavy. Always use safety gloves and
enclosed footwear.
• Do not install or use a damaged appliance.
• Do not install the appliance where the appliance
door cannot be fully opened.
• Adjust the feet to have the necessary space
between the appliance and the flooring.
4

• When the appliance is in its permanent position,
check that it is fully level with the aid of a spirit
level. If it is not, adjust the feet accordingly.
ELECTRICAL CONNECTION
WARNING! Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and extension
cables.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains plug
with wet hands.
• UK and Ireland only. This appliance is fitted with
a 13 A mains plug. If it is necessary to change
the mains plug fuse, use only a 13 A ASTA (BS
1362) fuse.
• This appliance complies with the E.E.C.
Directives.
WATER CONNECTION
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not used
for a long time, where repair work has been
carried out or new devices fitted (water meters,
etc.), let the water flow until it is clean and clear.
• Ensure that there are no visible water leaks
during and after the first use of the appliance.
USE
WARNING! Risk of injury, electric
shock, fire, burns or damage to the
appliance.
• This appliance is for household use only.
• Do not put flammable products or items that are
wet with flammable products in, near or on the
appliance.
• Do not touch the glass door while a programme
is in operation. The glass can get hot.
• Do not dry damaged (torn, frayed) items that
contain padding or fillings.
• If laundry has been washed with a stain
remover, carry out an additional rinse cycle
before starting a drying cycle.
• Make sure that all metal objects are removed
from the laundry.
• Only dry fabrics that are suitable to dry in the
washer dryer. Follow the cleaning instruction on
the item label.
• Plastic items are not heat resistant.
– If a detergent ball is used, remove it before
starting a drying programme.
– Do not use a detergent ball if setting a non-
stop programme.
WARNING! Risk of injury or damage
to the appliance.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
appliance.
DISPOSAL
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to the
appliance and dispose of it.
• Remove the door catch to prevent children or
pets from becoming trapped in the drum.
• Dispose of the appliance in accordance with
local requirements for the disposal of Waste
Electrical and Electronic Equipment (WEEE).
5

PRODUCT DESCRIPTION
APPLIANCE OVERVIEW
1 2 3
5
6
7
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
INSTALLATION ON SUSPENDED FLOORING
Suspended wooden floors are particularly
susceptible to vibration.
To limit vibration we recommend placing a
waterproof wooden panel, at least 15 mm thick,
under the appliance. It should be screwed to at
least 2 floor beams and should extend beyond the
front feet.
If possible, install the appliance where the floor is
more stable.
FIXING PLATE KIT (4055171146)
Available from your authorised dealer.
If you install the appliance on a plinth, secure the
appliance in the fixing plates.
Read carefully the instructions supplied with the
accessory.
HOW TO ACTIVATE THE CHILD SAFETY
DEVICE
This device prevents children or pets from being
closed in the drum.
Turn the device clockwise, until the groove is
horizontal.
You cannot close the door.
To close the door, turn the device anticlockwise
until the groove is vertical.
6

CONTROL PANEL
CONTROL PANEL DESCRIPTION
20°
90° 40°
30°
800
60°
1200
1400
400
Spin
Start/Pause
Cotton
Synthetics
Economy
Synthetics
Dry
Cotton
Dry
Wool
Delicates
Spin
Rinse
Wool
Dry
Drain
Mix 20°
Super ECO
Temp.
Drying Time Prewash
Extra Rinse
Auto Dry
1 2 3 4
9
1011
7
6
8
5
1Programme knob
2Spin reduction (Spin)
3Temperature (Temp.)
4Display
5Drying time (Drying Time)
6Prewash phase (Prewash)
7Additional rinse (Extra Rinse)
8Automatic drying level (Auto Dry)
9Start/Pause (Start/Pause)
10 Delay start
11 Time save
DISPLAY
A B
E DFG
C
7

A
Time area : Programme duration
: Selected drying time
: Delay start
: Alarm codes
: Message of error
: The programme is completed.
Time programme indicators : Normal duration indicator
: Quick indicator
: Super quick indicator
BDelay start indicator
CChild safety lock indicator
DDoor locked indicator
E, , Indicators of dryness level
FDrying phase indicator
GWashing phase indicator
PROGRAMMES
PROGRAMME CHART
Programme
Temperature range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
Washing programmes
Cotton
90°C - (Cold)
7 kg
1400 rpm White cotton and coloured cotton. Normal soil and light soil.
Economy1)
60°C - 40°C
7 kg
1400 rpm White cotton and fast-coloured cotton. Normal soil. The energy consumption decrea-
ses and the time of the washing programme is
extended.
Synthetics
60°C - (Cold)
3,5 kg
1200 rpm Synthetic items or mixed fabric items. Nor- mal soil.
8

Programme
Temperature range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
2) Wool
40°C - (Cold)
1,5 kg
1200 rpm Machine washable wool, hand washable wool and other fabrics with «hand washing»
care symbol3).
Delicates
40°C - (Cold)
3,5 kg
1200 rpm Delicate fabrics such as acrylics, viscose and mixed fabrics requiring a mild wash-
ing. Normal soil.
Mix 20°
20°C
3 kg
1200 rpm Special programme for cotton, synthetic and mixed fabrics lightly soiled. Select this pro-
gramme to reduce the energy consumption.
Make sure that the detergent is suitable for low
temperatures in order to have good washing re-
sults4).
Super Eco
Cold
3 kg
1200 rpm Mixed fabric (cotton and synthetic items)5).
Drain 7 kg To drain the water in the drum. All fabrics.
Spin 7 kg6)
1400 rpm7)
To spin the laundry and to drain the water in the
drum. All fabrics, except woollens and del-
icate fabrics.
Rinse 7 kg6)
1400 rpm7)
To rinse and spin the laundry. All fabrics, ex-
cept woollens and very delicate fabrics. Reduce
the spin speed accordingly to the type of laun-
dry.
8) Wool Dry 1 kg Drying programme for woollens.
Synthetics Dry 2 kg Drying programme for synthetic items.
Cotton Dry 4 kg Drying programme for cotton items.
9

Programme
Temperature range
Maximum load
Maximum spin
speed
Programme description
(Type of load and soil level)
Miniprogramme
30°C
1,5 kg
800 rpm A short cycle for synthetic and delicate items with light soil level or for items to
freshen up.
1) Cottons energy saving programme. This programme at a 60ºC with a load of 7 kg is the reference pro-
gramme for data entered in the energy label, in compliance with EEC 92/75 standards. Set this pro-
gramme to have a good washing results and decrease the energy consumption. The time of the washing
programme is extended.
2) Woolmark Apparel Care. The wool wash cycle of this machine has been approved by The Woolmark
Company for the washing of machine washable wool products provided that the products are washed ac-
cording to the instructions on the garment label and those issued by the manufacturer of this washing ma-
chine. M1380 In UK, Eire, Hong Kong and India the Woolmark symbol is a certification trademark.
3) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
4) The appliance performs the short heating phase if the water temperature is below 20°C. The appliance
can show the temperature setting as “cold”.
5) This programme is for daily use and has the lowest energy and water consumption whilst maintaining a
good washing performance.
6) The maximum load refers to cottons items. Reduce the load accordingly in case of other type of laundry.
7) The maximum spin speed is related to cotton items. Set the spin speed. Make sure that it agrees with
the laundry.
8) Woolmark Apparel Care. The wool drying cycle of this machine has been approved by The Wool-
mark Company for the drying of machine washable wool products provided that the products are washed
and dried according to the instructions on the garment label and those issued by the manufacturer of this
machine. M1381 In UK, Eire, Hong Kong and India the Woolmark symbol is a certification trademark
Programme options compatibility
Programme
■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■1) ■
■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■
■ ■ ■■1) ■
■ ■ ■ ■■
■
10

Programme
■ ■ ■
■ ■ ■ ■■
■2) ■■
1) Only the QUICK option is available.
2) Available only if the last spin speed step is lower than 800 rpm.
PROGRAMMES FOR AUTOMATIC DRYING
Dryness Level Type of fabric Load
Extra Dry
For towelling materials
Cottons and Linen
(bathrobes, bath towels, etc) up to 4 kg
Cupboard Dry1)
For items to be stored
Cottons and Linen
(bathrobes, bath towels, etc) up to 4 kg
Synthetics and mixed fab-
rics
(jumpers, blouses, underwear,
household and bed linen)
up to 2 kg
Iron Dry
Suitable for ironing
Cottons and Linen
(sheets, tablecloths, shirts, etc) up to 4 kg
1) Hints for test institute The test performance, in accordance with EN 50229, must be carried out with
a FIRST drying load of the maximum declared drying capacity (load composition according to EN61121)
by setting the AUTOMATIC CUPBOARD DRY for Economy programme. The SECOND drying load with
the residual load must be tested by setting the AUTOMATIC CUPBOARD DRY for Economy programme.
PROGRAMMES FOR TIMED DRYING
Dryness Level Type of fabric Load (kg) Spin speed
(rpm)
Suggested
duration
(mins)
Extra Dry
For towelling materials Cottons and Linen (bathrobes, bath towels, etc) 4 1400 200 - 215
2 1400 115 - 125
1 1400 60 - 70
Cupboard Dry
For items to be stored Cottons and Linen (bathrobes, bath towels, etc) 4 1400 190 - 205
2 1400 105 - 115
1 1400 50 - 60
11

Dryness Level Type of fabric Load (kg) Spin speed
(rpm)
Suggested
duration
(mins)
Cupboard Dry
For items to be stored Synthetics and mixed fab- rics
(jumpers, blouses, underwear,
household and bed linen)
2 1200 95 - 110
1 1200 45 - 55
Iron Dry
Suitable for ironing Cottons and Linen (sheets, tablecloths, shirts, etc) 4 1400 110 - 125
2 1400 65 - 75
1 1400 40 - 50
Wool dry Wool
(woollen jumpers) 1 1200 80 - 100
CONSUMPTION VALUES
Stated values are obtained in laboratory conditions with relevant standards. Different cau-
ses can change the data: the quantity and type of laundry and ambient temperature. Wa-
ter pressure, the supply voltage and the temperature of inlet water may also affect the
washing programme duration.
Technical specifications may be changed without prior notice to improve the quality of
product.
At the start of the programme, the display shows the programme duration for the maxi-
mum load capacity.
During the washing phase the programme duration is automatically calculated and can be
greatly reduced if the laundry load is lower than the maximum load capacity (e.g. Cotton
60°C, maximum load capacity 7 kg, the programme duration exceeds 2 hours; actual load
1 kg, the programme duration will be less than 1 hour).
When the appliance is calculating the real programme duration a dot flashes in the dis-
play.
Programmes Load (kg) Energy con- sumption
(kWh)
Water con-
sumption (litre)
Approximate pro-
gramme duration (mi-
nutes)
Cottons 60°C 7 1.25 70 146
Economy
Cotton Energy Saving Pro-
gramme 60°C1) 7 0.98 52 238
Cottons 40°C 7 0.78 70 161
12

Programmes Load (kg) Energy con- sumption
(kWh)
Water con-
sumption (litre)
Approximate pro-
gramme duration (mi-
nutes)
Synthetics 40°C 3,5 0.47 50 171
Delicates 40°C 3,5 0.53 62 121
Wool/Handwash 30°C 1,5 0.25 45 58
1) «Cotton Energy Saving programme » at 60°C with a load of 7kg is the reference programme for the data
entered in the energy label, in compliance with EEC 92/75 standards.
OPTIONS
TEMP.
Set this option to change the default temperature.
Indicator = cold water.
The display shows the set temperature.
SPIN
With this option you can change the default spin
speed.
The indicator of the set speed comes on.
Additional spin options:
No Spin
• Set this option to deactivate all spin phases.
Only the drain phase is available.
• The related indicator comes on.
• Set this option for very delicate fabrics.
• The rinses phase uses more water for some
washing programmes.
Rinse Hold
• Set this option to prevent the laundry creases.
• The related indicator comes on.
• There is a water in the drum when the
programme is completed.
• The drum turns regularly to prevent the laundry
creases.
• The door stays locked. You must drain the water
to unlock the door.
To drain the water refer to ‘At the end
of the programme’.
DRYING TIME
With this option you can set the time for the fabrics
you have to dry. The display shows the set value.
Each time you press this touchpad the time value
increases by 5 minutes.
You cannot set all time values for
different types of fabrics.
AUTO DRY
With this option you can set an automatic level of
dryness for the laundry. The display shows the
symbol of the set level.
•Extra dry level for cotton items
• Cupboard dry level for cotton and synthetic
items
• Iron dry level for cotton items
PREWASH
With this option you can add a prewash phase to a
washing programme.
Use this option for heavy soil.
When you set this option the programme duration
increases.
The related indicator comes on.
EXTRA RINSE
With this option you can add some rinses to a
washing programme.
Use this option for persons allergic to detergents
and in areas where the water is soft.
The related indicator comes on.
DELAY START
With this option you can delay the start of a
programme from 30 minutes to 20 hours.
The display shows the related indicator.
13

TIME SAVE
Press Time Save to decrease the programme time.
You can select:
• QUICK: to wash items with daily soil.
• SUPER QUICK: to wash quickly items with
almost no soil.
Some programmes accept only one of
these options.
SETTINGS
CHILD LOCK
With this option you can prevent that the children
play with the control panel.
• To activate/deactivate this option, press
and at the same time until the indicator
comes on/goes off.
You can activate this option:
• After you press : the options and the
programme knob are locked.
• Before you press : the appliance cannot
start.
PERMANENT EXTRA RINSE
With this option you can permanently have an extra
rinse when you set a new programme.
• To activate/deactivate this option press
and at the same time until the indicator
comes on/goes off.
ACOUSTIC SIGNALS
The acoustic signals operate when:
• The programme is completed.
• The appliance has a malfunction.
To deactivate/activate the acoustic signals,
press and at the same time for 6 seconds.
If you deactivate the acoustic signals,
they continue operate when the
appliance has a malfunction.
BEFORE FIRST USE
1. Connect the mains plug to the mains socket.
2. Open the water tap.
3. Put 2 litre of water in the detergent
compartment for washing phase.
This activates the drain system.
4. Put a small quantity of detergent in the
compartment for washing phase.
5. Set and start a programme for cotton at the
highest temperature without laundry.
This removes all possible dirt from the drum and the
tub.
DAILY USE - WASHING ONLY
WARNING! Refer to Safety chapters.
LOADING THE LAUNDRY
Open the water tap. Connect the mains plug to the
mains socket.
1. Pull the door handle to open the appliance
door.
2. Put the laundry in the drum, one item at a time.
3. Shake the items before you put them in the
appliance.
Make sure not to put too much laundry in the drum.
Refer to max. loads indicated in "Programme chart".
4. Close the door.
14

CAUTION! Make sure that no laundry
stays between the seal and the door.
There is a risk of water leakage or
damage to the laundry.
Washing heavily oiled, greasy stains
could cause damage rubber parts of
the washing machine.
USING DETERGENT AND ADDITIVES
1. Measure out the detergent and the fabric
conditioner.
2. Put the detergent and the fabric conditioner
into the compartments.
3. Carefully close the detergent drawer.
DETERGENT COMPARTMENTS
Detergent compartment for pre-
wash phase.
Detergent compartment for
washing phase.
Compartment for liquid additives
(fabric conditioner, starch).
Flap for powder or liquid deter-
gent.
LIQUID OR POWDER DETERGENT
A
1. Position Afor powder
detergent (factory setting).
1
2
2. Extract the detergent
dispenser.
3. Turn the flap down-
wards.
B
4. Position Bfor liquid de-
tergent.
5. Close the detergent
dispenser.
15

When you use the liquid deter-
gent:
• Do not use gelatinous or thick liq-
uid detergents.
• Do not put more liquid then the
maximum level.
• Do not set the prewash phase.
• Do not set the delay start.
SETTING A PROGRAMME
1. Turn the programme knob to switch the
appliance on and set the required programme:
• The indicator flashes.
• The display shows the level of the Time
Manager, the programme duration and the
indicators of the phases of the programme.
2. If necessary, change the temperature and the
spin speed or add available options. When you
activate an option, the indicator of the set
option comes on.
If you set something incorrect, the
display shows the message .
STARTING A PROGRAMME WITHOUT THE
DELAY START
Press .
• The indicator of stops to flash and
stays on.
• The indicator starts to flash on the
display.
• The programme starts, the door locks, the
display shows the indicator .
• The drain pump can operate for a short time
when the appliance fills water.
After approximately 15 minutes from
the start of the programme:
• The appliance adjusts automatically
the programme duration agree with
the laundry load.
• The display shows the new value.
STARTING A PROGRAMME WITH THE DELAY
START
1. Press again and again until the display
shows the delay you want to set.
The related indicator comes on the display.
2. Press :
• The appliance starts the countdown.
• The door locks, the display shows the
indicator .
• When the countdown is completed, the
programme starts automatically.
You can cancel or change the set of
the delay start before you press the
. To cancel the delay start:
• Press to set the appliance
to pause.
• Press until the display
shows '.
• Press again to start the
programme immediately.
INTERRUPTING A PROGRAMME AND
CHANGING THE OPTIONS
You can change only some options before they
operate.
1. Press .
The indicator flashes.
2. Change the options.
3. Press again.
The programme continues.
CANCELLING A RUNNING PROGRAMME
1. Turn the programme knob to position to
cancel the programme and to deactivate the
appliance.
2. Turn the programme knob again to activate the
appliance. Now, you can set a new washing
programme.
Before starting the new programme
the appliance could drain the water. In
this case, make sure that the detergent
is still in the detergent compartment, if
not fill the detergent again.
OPENING THE DOOR
CAUTION! If the temperature and
level of the water in the drum are too
high and the drum still rotates, you
cannot open the door.
While a programme or the delay start operates, the
appliance door is locked and the display shows the
indicator .
Open the appliance door when the
programme or the delay start operates:
16

1. Press to pause the appliance.
2. Wait until the door lock indicator goes off.
3. Open the door.
4. Close the door and press again .
The programme or delay start continues to operate.
AT THE END OF THE PROGRAMME
• The appliance stops automatically.
• The acoustic signal operates (if it is activated).
• In the display comes on.
• The indicator of the goes off.
• The door lock indicator goes off.
• You can open the door.
• Remove the laundry from the appliance. Make
sure that the drum is empty.
• Close the water tap.
• Turn the programme knob to position to
deactivate the appliance.
• Keep the door ajar, to prevent the mildew and
odours.
The washing programme is completed, but
there is water in the drum:
• The drum turns regularly to prevent the creases
in the laundry.
• The door lock indicator is on. The indicator
flashes. The door stays locked.
• You must drain the water to open the door.
To drain the water:
1. Press . The appliance drains the water and
spins.
2. When the programme is completed, and the
door lock indicator goes off, you can open
the door.
3. Turn the programme knob to position to
deactivate the appliance.
The appliance drains and spins
automatically after approximately 18
hours (except for Wool programme).
STAND-BY
Some minutes after the end of the washing
programme, if you do not deactivate the appliance,
the energy saving status activates.
The energy saving status decreases the energy
consumption when the appliance is on the stand
by.
• All indicators and the display go off.
• The indicator of the flashes slowly
• Press one of the options to deactivate the
energy saving status.
If you set a programme or an option
that ends with water in the drum, the
energy saving status function doesn't
activate to remind you to drain the
water.
DAILY USE - DRYING ONLY
WARNING! Refer to Safety chapters.
This appliance is an automatic washer
dryer.
DRYING SETTING
WARNING! Make sure that the
water tap is open.
1. Turn the programme knob to to activate the
appliance.
2. Load the laundry one item at a time.
3. Turn the programme dial to the programme
applicable for the items to dry. The display
shows the drying indicator .
To have a good drying performance
do not exceed the maximum drying
loads recommended in the user
manual. Do not set a spin speed
lower than the automatic speed of the
set programme.
DRYING AT AUTOMATIC LEVELS
The laundry can be dried at pre-defined levels of
dryness:
1. Press again and again until the display
shows one of the dryness level indicator:
• : IRON DRY level indicator for cotton
items
• : CUPBOARD DRY level indicator for
cotton and synthetic items
•: EXTRA DRY level indicator for cotton
items
17

The display shows a time value, calculated on the
default load size. If the amount of your laundry is
more or less than the default size, the appliance
adjusts automatically the time value during the
cycle.
2. Press to start the programme.
The display shows the door locked indicator .
The drying indicator starts to flash.
You cannot set all dryness levels for
any type of laundry.
TIMED DRYING
The laundry can also be dried with a manual timed
drying:
1. Press again and again to set the time value
(see the «Programmes for timed drying» table).
• The display shows 10 minutes. Each time
you press this touchpad the time value
increases by 5 minutes.
• The display shows the set time value: for
example – .
• After some seconds the display shows a
new time value: . The appliance
calculates also the duration of the anti-
crease and the cooling phases.
2. Press to start the programme.
• The display shows regularly a new time
value.
• The drying indicator starts to flash.
• The display shows the door locked
indicator .
If you set only 10 minutes of drying,
the appliance performs only a cooling
phase.
If the laundry is not sufficient dry, set
again a short drying time.
END OF THE DRYING PROGRAMME
The appliance stops automatically.
• The acoustic signals operate (if they are active).
• In the display comes on.
• The indicator goes off.
• The last minutes of the drying cycle the
appliance performs a cooling and anti-crease
phase. The door is still locked.
When the door locked goes off in the display,
you can open the door.
1. Turn the programme knob to to deactivate
the appliance.
After some minutes from the end of the programme,
the energy saving function automatically
deactivates the appliance.
2. Remove the laundry from the appliance.
Make sure that the drum is empty.
3. Keep the door ajar, to prevent mildew and
odours.
4. Close the water tap.
DAILY USE - WASHING & DRYING
WARNING! Refer to Safety chapters.
This appliance is an automatic washer
dryer.
NON-STOP PROGRAMME
1. Turn the programme knob to to activate the
appliance.
2. Load the laundry one item at a time.
To have a good drying performance
do not exceed the maximum drying
loads recommended in the user
manual. Do not set a spin speed
lower than the automatic speed of the
set programme.
3. Put the detergent and the additives in the
appropriate compartment.
4. Turn the programme dial to the washing
programme.
The display shows the indicators of the different
washing phases.
5. Set the available options.
WASHING & AUTOMATIC DRYING
1. Press again and again until the display
shows one of the dryness level indicator:
• : IRON DRY level indicator for cotton
items
• : CUPBOARD DRY level indicator for
cotton and synthetic items
•: EXTRA DRY level indicator for cotton
items
18

The display shows the indicator . The time value
on the display is the duration of the washing +
drying cycles, calculated on a default load size.
To have a good drying the appliance
does not let you set a too low spin
speed for the items to be washed and
dried.
2. Press to start the programme.
In the display the indicator of the set dryness level
stays on.
The door locked indicator goes on.
The display shows regularly a new time value.
The last minutes of the drying cycle
the appliance performs the anti-crease
and the cooling phases.
WASHING & TIMED DRYING
To have a good drying the appliance does not let
you set a too low spin speed for the items to be
washed and dried.
1. Press to set the drying time value. The
display shows 10 minutes.
The indicator comes on in the display. The
display shows the set drying value time. for
example: . After some seconds the display
shows the final time value , that is the total
duration of the washing and drying cycles (washing
+ drying + anti-crease + cooling phases).
If you set only 10 minutes of drying
after washing, the appliance calculates
also the duration of the anti-crease
and the cooling phases.
2. Press to start the programme.
In the display the indicator comes on. The door
is locked. The display shows regularly a new time
value.
END OF THE PROGRAMME
The appliance stops automatically. The acoustic
signals operate (if they are active).
For more information see "At the end of the drying
programme " of the previous chapter.
1. Remove the laundry from the appliance.
Make sure that the drum is empty.
2. Keep the door ajar to prevent mildew and
odours.
3. Close the water tap.
FLUFF IN THE FABRICS
During the washing and/or drying phase, some
types of fabric, (sponge, wool, sweatshirt) could
release fluff.
The released fluff could stick to the fabrics during
the next cycle.
To prevent the fluff in your laundry, we recommend
that you:
• Do not wash dark fabrics after you have washed
and dried light coloured fabrics (new sponge,
wool, sweatshirt ) and the contrary.
• Line dry this type of fabrics at open air when
they are washed the first time.
• Clean the drain filter.
• After the drying phase, clean the empty drum,
the gasket and the door with a wet cloth.
HOW TO REMOVE THE FLUFF IN THE
GARMENTS
To remove the fluff inside the drum, set a special
programme:
1. Empty the drum.
2. Clean the drum, the gasket and the door with a
wet cloth.
3. Set the rinse programme.
4. Press at the same time and to activate
the cleaning function until the display shows
CLE.
5. Press to start the programme.
HINTS AND TIPS
WARNING! Refer to Safety chapters.
THE LAUNDRY LOAD
• Divide the laundry in: white, coloured,
synthetics, delicates and wool.
• Obey the washing instructions that are on the
laundry care labels.
• Do not wash white and coloured items together.
• Some coloured items can discolour with the first
wash. We recommend that you wash them
separately for the first times.
• Button up pillowcases, close zippers, hooks and
poppers. Tie up belts.
• Empty the pockets and unfold the items.
• Turn multilayered fabrics, wool and items with
painted illustrations inside out.
19

• Remove hard stains with a special detergent.
• Wash and pre-treat heavy soil stains before
putting items in drum
• Be careful with the curtains. Remove the hooks
and put the curtains in a washing bag or
pillowcase.
• Do not wash laundry without hems or with cuts.
Use a washing bag to wash small and/or
delicate items (e.g. underwired bras, belts,
tights, etc. ).
• A very small load can cause balance problems
with the spin phase. If this occurs, adjust
manually the items in the tub and start the spin
phase again.
STUBBORN STAINS
For some stains, water and detergent is not
sufficient.
We recommend that you pre-treat these stains
before you put the items in the appliance.
Special stain removers are available. Use the
special stain remover that is applicable to the type
of stain and fabric.
DETERGENTS AND ADDITIVES
• Only use detergents and additives specially
made for washing machines:
– powder detergents for all types of fabric,
– powder detergents for delicate fabrics (40
°C max) and woollens,
– liquid detergents, preferably for low
temperature wash programmes (60 °C max)
for all types of fabric, or special for woollens
only.
• Do not mix different types of detergents.
• To help the environment, do not use more than
the correct quantity of detergent.
• Obey the instructions that you find on the on
packaging of these products.
• Use the correct products for the type and colour
of the fabric, the programme temperature and
the level of soil.
• If your appliance does not have the detergent
dispenser with the flap device, add the liquid
detergents with a dosing ball (supplied by the
detergent's manufacturer).
ECOLOGICAL HINTS
• Set a programme without the prewash phase to
wash laundry with normal soil.
• Always start a washing programme with the
maximum load of laundry allowed.
• If necessary, use a stain remover when you set a
programme with a low temperature.
• To use the correct quantity of detergent, check
the water hardness of your domestic system.
Refer to "Water hardness".
WATER HARDNESS
If the water hardness in your area is high or
moderate, we recommend that you use a water
softener for washing machines. In areas where the
water hardness is soft it is not necessary to use a
water softener.
To know the water hardness in your area, contact
your local water authority.
Use the correct quantity of the water softener.
Obey the instructions that you find on the
packaging of the product.
DRYING HINTS
Prepare the drying cycle
• Open the water tap.
• Check if the drain hose is connected properly.
Refer to installation chapter for more
information.
• For the maximum laundry load of the drying
programmes, refer to the drying programmes
table.
ITEMS NOT SUITABLE FOR DRYING
Do not set a drying programme for this
laundry:
• Synthetic curtains.
• Pieces of clothing with metal inserts.
• Nylon stockings.
• Quilts.
• Bed covers.
• Duvets.
• Anoraks.
• Sleeping bags.
• Fabrics with residue of hair sprays, nail solvents
or similar.
• Garments with foam-rubber or materials similar
to foam-rubber.
GARMENT LABELS
When you dry the laundry, obey the indications on
the labels of the manufacturers:
• = The item can be tumble dried
• = The drying cycle is at high temperature
• = The drying cycle is at reduced
temperature
• = The item can not be tumble dried.
DRYING CYCLE DURATION
The drying time can change depending on:
• speed of the last spin
20
