Zanussi ZWT 71401 WA User manual

EN
User manual
Washer-dryer
ZWT 71401 WA

Contents
Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4
Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
First use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Personalisation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Daily use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Use - Drying _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 9
Helpful hints and tips _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 10
Drying Hints _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 12
Washing programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13
Drying Programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 16
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 16
What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 18
Technical data _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 21
Consumption values _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 22
Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 22
Building in _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 25
Electrical connection _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 27
Environment concerns _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 27
Subject to change without notice.
Safety information
Important! Read carefully & keep for future reference.
• The safety of Your appliance complies with the industry
standards and with legal requirements on the safety of
appliances. However, as manufacturers, we feel it is
our duty to provide the following safety notes.
• It is most important that this instruction book should
be retained with the appliance for future reference.
Should the appliance be sold or transferred to another
owner, or should you move house and leave the appli-
ance, always ensure that the book is supplied with the
appliance in order that the new owner can get to know
the functioning of the appliance and the relevant warn-
ings.
• You MUST read them carefully before installing or us-
ing the appliance.
• Before first starting up, check the appliance for any
damage incurred during transport. Never connect up a
damaged appliance . If parts are damaged, contact your
supplier.
• If the appliance is delivered in the winter months when
there are minus temperatures. Store it at room temper-
ature for 24 hours before using for the first time.
General safety
• It is dangerous to alter the specifications or attempt to
modify this product in any way.
• During high temperature wash programmes the door
glass may get hot. Do not touch it!
• Make sure that small pets and children do not climb
into the drum. To avoid this, please check into the
drum before using.
• Any objects such as coins, safety pins, nails, screws,
stones or any other hard, sharp material can cause ex-
tensive damage and must not be placed into the ma-
chine.
• Only use the advised quantities of fabric softener and
detergent. Damage to the fabric can ensue if you over-
fill. Refer to the manufacturer’s recommendations of
quantities.
• Wash small items such as socks, laces, washable belts
etc in a washing bag or pillow case as it is possible for
such items to slip down between the tub and the inner
drum.
• Do not use your washing machine to wash articles with
whalebones, material without hems or torn material.
• Always unplug the appliance and turn off the water
supply after use, cleaning and maintenance.
• Under no circumstances should you attempt to repair
the machine yourself. Repairs carried out by inexper-
ienced people may cause injury or serious malfunc-
tioning. Contact your local Service Centre. Always in-
sist on genuine spare parts.
Installation
• This appliance is heavy. Care should be taken when
moving it.
• When unpacking the appliance, check that it is not
damaged. If in doubt, do not use it and contact the
Service Centre.
• All packing and transit bolts must be removed before
use. Serious damage can occur to the product and to
property if this is not adhered to. See relevant section
in the user manual.
2
www.zanussi.com

• After having installed the appliance, check that it is not
standing on the inlet and drain hose and the worktop is
not pressing the electrical supply cable against the
wall.
• If the machine is situated on a carpeted floor, please
adjust the feet in order to allow air to circulate freely
under the appliance.
• Always be sure, that there is no water leakage from ho-
ses and their connections after the installation.
• If the appliance is installed in a location subject to
frost, please read the “dangers of freezing” chapter.
• Any plumbing work required to install this appliance
should be carried out by a qualified plumber or compe-
tent person.
• Any electrical work required to install this appliance
should be carried out by a qualified electrician or com-
petent person.
Use
• This appliance is designed for domestic use. It must
not be used for purposes other than those for which it
was designed.
• Only wash and dry fabrics which are designed to be
machine washed or dried. Follow the instructions on
each garment label
• Do not overload the appliance. See the Washing Pro-
gramme Table.
• Before washing, ensure that all pockets are empty and
buttons and zips are fastened. Avoid washing frayed or
torn articles and treat stains such as paint, ink, rust,
and grass before washing. Underwired bras must NOT
be machine washed.
• Garments which have been in contact with volatile pe-
troleum products should not be machine washed. If
volatile cleaning fluids are used, care should be taken
to ensure that the fluid is removed from the garment
before placing in the machine.
• As some duvets and eiderdowns should be washed/
dried in large commercial machines because of their
bulk, please check with the manufacturer of the item
before washing in a domestic machine.
• The users should always check that they have not left
their gas lighters (disposable or otherwise) in their
clothing.
• Never tumble dry items that have had contact with
chemicals such as dry cleaning fluid. These are of a
volatile nature and could cause an explosion. Only
tumble dry items which have been washed in water or
require airing.
• Plastic detergent dispensers should not remain in the
drum during the drying cycle, as the plastic used is not
designed to withstand the heat. If you wish to wash-
through-to-dry you should use the conventional deter-
gent dispenser drawer.
• Never pull the power supply cable to remove the plug
from the socket; always take hold of the plug itself.
• Never use your new appliance if the power supply ca-
ble, the control panel, the working surface or the base
are damaged so that the inside of the appliance is ac-
cessible.
Child Safety
• This appliance is not intended for use by person (in-
cluding children) with reduced physical sensory or
mental capabilities or lack of experience and knowl-
edge unless they have been given supervision or in-
struction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• The packaging components (e.g. plastic film, polystyr-
ene) can be dangerous to children - danger of suffoca-
tion! Keep them out of children's reach.
• Keep all detergents in a safe place out of children’s
reach.
•
Make sure that children or pets do not climb inside the
drum. To prevent children or pets becoming trapped
inside the drum the machine incorporates a special
feature. To activate this device, rotate the button (with-
out pressing it) inside the door clockwise until the
groove is horizontal. If necessary use a coin. To disa-
ble this device and restore the possibility of closing the
3
www.zanussi.com

door, rotate the button anticlockwise until the groove is
vertical.
Product description
Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and
detergent consumption. Its new washing system allows total use of detergent and reduces water consumption so
saving energy.
1
6
5
3
4
2
1Detergent dispenser drawer
2Control panel
3Door opening handle
4Rating Plate
5Drain pump
6Adjustable feet
4
www.zanussi.com

Detergent dispenser drawer
Compartment for detergent used for prewash and
soak phase or for stain remover used during the stain ac-
tion phase (if available). The prewash and soak detergent
is added at the beginning of the wash programme. The
stain remover is added during the stain action phase.
Compartment for powder or liquid detergent used for
main wash. If using liquid detergent pour it just before
starting the programme.
Compartment for liquid additives (fabric softener,
starch).
Follow the product manufacturer’s recommendations on
quantities to use and do not exceed the «MAX» mark in
the detergent dispenser drawer. Any fabric softener or
starching additives must be poured into the compartment
before starting the wash programme.
Control panel
Below is a picture of the control panel. It shows the programme selector dial as well as the buttons, pilot light and
the display. These are presented by relevant numbers on the following pages.
1 2 3 4 5 6 7 8
10 9
1Programme selector dial
2SPIN reduction button
3OPTIONS button
–SUPER QUICK
–ECONOMY
4EXTRA RINSE button
5DRYING TIME button
6EASY IRON button
7Display
8START/PAUSE button
9DOOR LOCKED pilot light
10 DELAY START button
Programme Selector Dial
It allows you to switch the appliance on/off and/or to se-
lect a programme.
Spin
By pressing this button you can change the spin speed of
the selected programme or to select Rinse Hold option.
5
www.zanussi.com

Rinse hold
By selecting this function the water of the last rinse is not
emptied out to prevent the fabrics from creasing. Before
opening the door it will be necessary to empty out the wa-
ter. To empty out the water, please read the paragraph «At
the end of the programme».
Super Quick
Short cycle for lightly soiled items or for laundry which
needs only freshening up. We recommend you to reduce
the fabrics loading.
Economy
Only for cottons and synthetic items lightly or normally
soiled at a temperature of 40°C or higher. The washing
time will be prolonged and the washing temperature will
be reduced. You can use this option if you want to wash
normally soiled laundry and at the same time save energy.
Extra Rinse
This appliance is designed to save energy. If it necessary
to rinse the laundry using an extra quantity of water (extra
rinse), select this option. Some additional rinses will be
performed. This option is recommended for people who
are allergic to detergents, and in areas where the water is
very soft.
Drying Time
If you wish to carry out a timed drying programme, press
this button until the drying time you want appears on the
display according to the fabrics (cottons or synthetics)
you have to dry. For Cottons you can select a drying time
from 10 minutes to 250 minutes (4.10). For Synthetics
you can select a drying time from 10 minutes to 130 mi-
nutes (2.10). Every time you press this button the drying
time increases by 5 mins.
Easy Iron
By selecting this option the laundry is gently washed and
spun to avoid any creasing. In this way ironing is easier.
Furthermore the machine will perform some additional
rinses in some programmes. On cotton programmes the
maximum spin speed is reduced automatically.
Start Pause
This button allows you to start or to interrupt the selected
programme.
Door locked pilot light
The pilot light 9illuminates when the programme starts
and indicates if the door can be opened:
• light on: the door cannot be opened. The machine in
working or has stopped with water left in the tub.
• light off: the door can be opened. The programme is
finished or the water has been emptied out.
• light flashing: the door is opening.
Delay Start
The programme can be delayed from 30 min - 60 min - 90
min, 2 hours and then by 1 hour up to a maximum of 20
hours by means of this button.
Display
7.27.1
The display shows the following information:
7.1: Child safety lock
This device permits you to leave the appliance unattended
during it's functioning (see «Child Safety Lock» para-
graph).
7.2:
•Duration of the selected programme
After selecting a programme, the duration is displayed
in hours and minutes (for example 2.05 ). The duration
is calculated automatically on the basis of the maxi-
mum recommended load for each type of fabric. After
the programme has started, the time remaining is up-
dated every minute.
•Selected drying time
After selecting a drying programme, the drying time is
displayed in minutes or in hours and minutes (e.g. 130
mins = 2.10 ). After the programme has started the time
remaining is updated every minute.
•Delayed start
6
www.zanussi.com

The Selected delay set by pressing the relevant button
appears on the display for few seconds, then the dura-
tion of the selected programme is displayed again.
•Alarm codes
In the event of operating problems, some alarm codes
can be displayed, for example E20 (see paragraph
«What to do if...»).
•Incorrect option selection
If an option which is not compatible with the set wash
programme is selected, the message Err is displayed at
the bottom of the display for a few seconds and the in-
tegrated red light of button 8start flashing.
•End of programme
When the programme has finished three flashing zeros
are displayed, the pilot light 9and the pilot light of but-
ton 8go out and the door can be opened.
First use
• Ensure that the electrical and water connections
comply with the installation instructions.
• Remove the polystyrene block and any material
from the drum.
• Pour 2 litres of water into the main wash com-
partment of the detergent drawer in order to
activate the ECO valve. Then run a cotton cycle at
the highest temperature without any laundry in
the machine, to remove any manufacturing resi-
due from the drum and tub. Pour 1/2 a measure
of detergent into the main wash compartment and
start the machine.
Personalisation
Acoustic signals
The machine is provided with an acoustic device, which
sounds in the following cases:
• at the end of the cycle
• if there is a fault.
By pressing the 4and 5buttons simultaneously for about
6 seconds, the acoustic signal is deactivated (except if
there is a fault). By pressing these 2 buttons again, the
acoustic signal is reactivated.
Child safety lock
This device permits you to leave the appliance unattended
and not to worry that children might be injured by or
cause damage to the appliance. This function remains en-
abled also when the washing machine is not working.
There are two different ways to set this option:
1. Before pressing button 8: it will be impossible to
start the machine.
2. After pressing button 8: it will be impossible to
change any other programme or option.
To enable or disable this option press simultaneously for
about 6 seconds buttons 2and 3until on the display, the
icon appears or disappears.
Daily use
Washing only
Load the laundry
Open the door by carefully pulling the door handle out-
wards. Place the laundry in the drum, one item at a time,
shaking them out as much as possible. Close the door.
Make sure that no laundry stays between the seal and the
door. There is a risk of water leakage or damage to the
laundry. Measure out the detergent and the fabric softener
Pull out the dispenser drawer until it stops. Measure out
the amount of detergent required, pour it into the main
wash compartment or in the appropriate compartment
7
www.zanussi.com

if the selected programme/option it requires (see more de-
tails in «Detergent dispenser drawer»).
If required, pour fabric softener into the compartment
marked (the amount used must not exceed the
«MAX» mark in the drawer). Close the drawer gently.
Select the required programme by turning the
programme selector dial (1)
Turn the programme selector dial to the required pro-
gramme. The washing machine will propose a temperature
and automatically select the maximum spin value provi-
ded for the programme you have chosen. You can change
these values by operating the corresponding buttons. The
green pilot light of the button 8starts to flash.
The selector dial can be turned either clockwise or coun-
terclockwise. Turn to position to reset programme/
Switching the machine off.
At the end of the programme the selector dial must be
turned to position , to switch the machine off.
Caution! If you turn the programme selector dial to
another programme when the machine is working,
the red pilot light of button 8will blink 3 times and the
message Err is displayed to indicate a wrong selection.
The machine will not perform the new selected
programme.
Reduce the spin speed by pressing button 2
By selecting a programme, the appliance proposes auto-
matically the maximum spin speed provided for that pro-
gramme.
Press button 2repeatedly to change the spin speed, if you
want your laundry to be spun at a different speed. The rel-
evant light illuminates.
Select the available options by pressing buttons 3, 4
and 6
Depending on the programme, different functions can be
combined. These must be selected after choosing the de-
sired programme and before pressing button 8.
When these buttons are pressed, the corresponding icons
appear on the display. When they are pressed again, the
icons disappear. If an incorrect option is selected, the in-
tegrated red pilot light of the button 8flashes for 3 times
and the Err message appears on the display for a few sec-
onds.
For the compatibility among the washing pro-
grammes and the options see chapter «Washing
Programmes».
Select the Delay Start by pressing button 10
Before you start the programme, if you wish to delay the
start, press the button 10 repeatedly, to select the desired
delay.
The selected delay time value (up to 20 hours) will appear
on the display a few seconds, then the duration of the pro-
gramme will appear again.
You must select this option after you have set the pro-
gramme and before you press button 8.
You can cancel or modify the delay time at any moment,
before you press button 8.
Selecting the delayed start:
1. Select the programme and the required options.
2. Select the delay start by pressing the button 10.
3. Press button 8:
– the machine starts its hourly countdown.
– The programme will start after the selected delay
has expired.
Cancelling the delayed start after having pressed button 8:
1. Set the washing machine to PAUSE by pressing but-
ton 8.
2. Press button 10 once until the symbol ’is dis-
played
3. Press button 8again to start the programme.
8
www.zanussi.com

Important! The selected delay can be changed only after
selecting the washing programme again.
The Delay Start can not be selected with DRAIN
programme.
Start the programme by pressing button 8
To start the selected programme, press the button 8, the
green pilot light of the button 8stops blinking.
To interrupt a programme which is running, press the but-
ton 8: the green pilot light starts blinking.
To restart the programme from the point at which it was
interrupted, press the button 8 again. If you have chosen a
delayed start, the machine will begin the countdown. If an
incorrect option is selected, the red pilot light of the but-
ton 8blinks 3 times and the message Err is displayed for
a few seconds.
Altering an option or a running programme
It is possible to change some options before the pro-
gramme carries them out.
Before you make any change, you must PAUSE the appli-
ance by pressing the button 8.
Changing a running programme is possible only by reset-
ting it. Turn the programme selector dial to Oand then to
the new programme position. Start the new programme by
pressing the button 8again. The washing water in the tub
will be not emptied out.
Interrupting a programme
Press the button 8to interrupt a programme which is run-
ning, the corresponding green pilot light starts blinking.
Press the button again to restart the programme.
Cancelling a programme
Turn the selector dial to to cancel a programme which
is running.
You can select now a new programme.
At the end of the programme
The machine stops automatically. Three blinking 0.00 ap-
pear on the display and the pilot light of button 8goes off.
Some acoustic signals sound.
If a programme or an option that ends with water left in the
tub has been selected, the door remains locked to indicate
that the water must be emptied out before opening the
door.
Follow the below instructions to empty out the water:
1. Turn the programme selector dial to O.
2. Select the draining or spinning programme.
3. Reduce the spin speed if needed, by pressing the
relevant button.
4. Press button 8.
At the end of the programme, the door is released and can
be opened. Turn the programme selector dial to Oto
switch the machine off.
Remove the laundry from the drum and carefully check
that the drum is empty. If you do not intend to carry out
another wash, close the water tap. Leave the door open to
prevent the formation of mildew and unpleasant smells.
Stand By: If your laundry is not removed within 10 mi-
nutes after the programme is finished, the back light of the
display switches off and the energy saving system will be
enabled. Only the pilot light of the button 8is blinking to
indicate that the appliance has to be switched off. By
pressing any button the appliance will come out from the
energy saving status and you can set another programme
or switch the appliance off.
Use - Drying
Drying only
Warning!
The recommended load size is 3 kg for cottons and linen,
and 1,5 kg for synthetic items.
By pressing Drying Time button it is also possible
to dry up to 4 kg of cotton items (see the «Drying
Programme » table).
Warning!
The water tap must be open and the drain hose must be
positioned in the sink or connected to the drain pipe.
1. Load the laundry.
2. Select a spin cycle at the maximum spin speed al-
lowed for the type of laundry in order to obtain the
best drying performances.
3. Select the drying programme for Cottons or Synthet-
ic in the Drying sector of the programme selector di-
al.
9
www.zanussi.com

4. If you wish to select a timed drying, press button 5
until the time you want appears on the display (see
the «Drying Programme» table). Every time you
press this button the drying time increases by 5 mi-
nutes.
Note!
The programme time will automatically increase by
some minutes.
5. Press button 8to start the programme.
After the programme has started, the time remaining
is updated every minute.
Note!
The different type of cottons (towelling, sheets,
shirts, and so on) or any laundry items rolling up
during the spinning phase may result in partial dry-
ness. In the exceptional case that at the end of the
cycle the laundry remains slightly wet, we suggest
that you unfold the rolled up items, redistribute them
evenly in the drum and select an additional drying
cycle of 20-30 minutes.
6. At the end of the programme, the buzzer sounds and
three blinking «0.00» appear on the display and the
pilot light 9is on to indicate that the door is locked.
The last 10 minutes of the drying cycle correspond
to an anti-crease phase. During this time the door is
locked and the display keeps showing three flashing
zeros «0.00».
If you wish to open the door before or during the
anti-crease phase or to interrupt it, press any button
or turn the programme selector dial to any programme po-
sition (except O).
7. Turn the selector dial to the Oposition to switch the
machine off.
8. Remove the laundry.
Automatic washing and drying (NON-STOP
programme)
For NON-STOP programmes, the recommended load size
is 3 kg for cotton and 1,5 kg for synthetic.
It is possible to dry up to 4 kg of cotton items by
pressing Drying Time button only (see the «Drying
Programme » table).
Caution! Do not use a dosing device/ball when
carrying out a washing and drying programme.
1. Load the laundry.
2. Add detergent and fabric softener.
3. Switch the machine on by turning the selector dial to
the selected washing programme/fabric.
4. Select the required options by pressing the relevant
buttons.
If possible, do not select a spin speed lower than that
proposed by the appliance to avoid too long a drying time
therefore saving energy.
In any case the reduction of the spin speed is only
possible after selecting drying.
The lowest values you can select are the following:
– 900 r.p.m. for cottons and synthetic with elec-
tronic drying;
– 900 r.p.m. for cottons and 700 r.p.m. for fabrics
with timed drying.
5. Select the drying time by pressing button 5. The dis-
play shows the entire duration of the washing and
the selected drying cycle.
6. Start the programme by pressing button 8. After the
programme has started, the time remaining is upda-
ted every minute.
7. At the end of the programme turn the selector dial to
the Oposition to switch the machine off.
8. Remove the laundry.
Helpful hints and tips
Sorting out the laundry
Follow the wash code symbols on each garment label and
the manufacturer’s washing instructions. Sort the laundry
as follows: whites, coloureds, synthetics, delicates, wool-
lens.
10
www.zanussi.com

Temperatures
95° or 90°
for normally soiled white cottons
and linen (e.g. tea cloths, towels, ta-
blecloths, sheets...)
60°/50°
for normally soiled, colour fast gar-
ments (e.g. shirts, night dresses,
pyjamas....) in linen, cotton or syn-
thetic fibres and for lightly soiled
white cotton (e.g. underwear)
40°-30°- Cold
for delicate items (e.g. net curtains),
mixed laundry including synthetic
fibres and woollens bearing the la-
bel «pure new wool, machine wash-
able, non-shrink»
Before loading the laundry
Never wash whites and coloureds together. Whites may
lose their «whiteness» in the wash.
New coloured items may run in the first wash; they should
therefore be washed separately the first time.
Make sure that no metal objects are left in the laundry
(e.g. hair clips, safety pins, pins).
Button up pillowcases, close zip fasteners, hooks and
poppers. Tie any belts or long tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special detergent or
detergent paste.
Treat curtains with special care. Remove hooks or tie them
up in a bag or net.
Maximum loads
Recommended loads are indicated in the washing pro-
gramme charts.
General rules:
•Cotton, linen: drum full but not too tightly packed;
•Synthetics: drum no more than half full;
•Delicate fabrics and woollens: drum no more than one
third full.
Washing a maximum load makes the most efficient use of
water and energy.
For heavily soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
The following weights are indicative:
bathrobe 1200 g
quilt cover 700 g
man’s work shirt 600 g
sheet, man’s pyjamas 500 g
tablecloth 250 g
pillow case, towelling towel, night
dress, man’s shirt
200 g
tea cloth, ladies’ briefs, napkin,
blouse, men’s underpants
100 g
Removing stains
Stubborn stains may not be removed by just water and de-
tergent. It is therefore advisable to treat them prior to
washing.
Blood: treat fresh stains with cold water. For dried stains,
soak overnight in water with a special detergent then rub
in the soap and water.
Oil based paint: moisten with benzine stain remover, lay
the garment on a soft cloth and dab the stain; treat several
times.
Dried grease stains: moisten with turpentine, lay the gar-
ment on a soft surface and dab the stain with the fingertips
and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust removing
product used cold. Be careful with rust stains which are
not recent since the cellulose structure will already have
been damaged and the fabric tends to hole.
Mould stains: treat with bleach, rinse well (whites and fast
coloureds only).
Grass: soap lightly and treat with bleach (whites and fast
coloureds only).
Ball point pen and glue: moisten with acetone
1)
, lay the
garment on a soft cloth and dab the stain.
Lipstick: moisten with acetone as above, then treat stains
with methylated spirits. Treat any residual marks with
bleach.
Red wine: soak in water and detergent, rinse and treat with
acetic or citric acid, then rinse. Treat any residual marks
with bleach.
Ink: depending on the type of ink, moisten the fabric first
with acetone
1)
, then with acetic acid; treat any residual
marks on white fabrics with bleach and then rinse thor-
oughly.
1) do not use acetone on artificial silk
11
www.zanussi.com

Tar stains: first treat with stain remover, methylated spirits
or benzine, then rub with detergent paste.
Detergents and additives
Good washing results also depend on the choice of deter-
gent and use of the correct quantities to avoid waste and
protect the environment.
Although biodegradable, detergents contain substances
which, in large quantities, can upset the delicate balance
of nature.
The choice of detergent will depend on the type of fabric
(delicates, woollens, cottons, etc.), the colour, washing
temperature and degree of soiling.
All commonly available washing machine detergents may
be used in this appliance:
• powder detergents for all types of fabric
• powder detergents for delicate fabrics (60°C max) and
woollens
• liquid detergents, preferably for low temperature wash
programmes (60°C max) for all types of fabric, or spe-
cial for woollens only.
The detergent and any additives must be placed in the ap-
propriate compartments of the dispenser drawer before
starting the wash programme.
If using liquid detergents, a programme without prewash
must be selected.
Your appliance incorporates a recirculation system which
allows an optimal use of the concentrated detergent.
Follow the product manufacturer’s recommendations on
quantities to use and do not exceed the «MAX» mark in
the detergent dispenser drawer.
Degrees of water hardness
Water hardness is classified in so-called “degrees” of
hardness. Information on hardness of the water in your
area can be obtained from the relevant water supply com-
pany, or from your local authority.
A water softener must be added when water has a
medium-high degree of hardness (from degree of
hardness II). Follow the manufacturer’s instructions. The
quantity of detergent can then always be adjusted to de-
gree of hardness I (= soft).
Level Characteris-
tic
Degrees of water hardness
German °dH French
°T.H.
1soft 0-7 0-15
2medium 8-14 16-25
3hard 15-21 26-37
4very hard > 21 > 37
Drying Hints
Preparing the drying cycle
As a dryer, the appliance works on the condensation prin-
ciple.
Therefore, the water tap must be open and the drain hose
must drain water into a sink or into the drain pipe, even
during the drying cycle.
Attention!
Before starting the drying programme, reduce the loads of
washed laundry, in order to obtain good performances.
Laundry not suitable for drying
• Particularly delicate items such as synthetic curtains,
woollen and silk, garments with metal inserts, nylon
stockings, bulky garments such as anoraks, bed cov-
ers, quilts, sleeping bags and duvets must not be ma-
chine dried.
• Avoid drying dark clothes with light coloured fluffy
items such as towels as these can attract the fluff.
• Remove the laundry when the appliance has finished
drying.
• To avoid a static charge when drying is completed, use
either a fabric softener when you are washing the laun-
dry or a fabric conditioner specifically for tumble dry-
ers.
• Garments padded with foam-rubber or materials simi-
lar to foam-rubber must not be machine dried; they
represent a fire hazard.
• Also, fabrics containing residue of setting lotions or
hair sprays, nail solvents or similar solutions must not
be machine dried in order to avoid the formation of
harmful vapours.
The detergent and any additives must be placed in the ap-
propriate compartments of the dispenser drawer before
starting the wash programme.
12
www.zanussi.com

If using liquid detergents, a programme without prewash
must be selected.
Your appliance incorporates a re-circulation system which
allows an optimal use of the concentrated detergent.
Follow the product manufacturer’s recommendations on
quantities to use and do not exceed the «MAX» mark in
the detergent dispenser drawer.
Garment labels
For drying, follow the indications given on the manufac-
turer’s labels:
•= May be tumble dried
•= Drying at high temperature
•= Drying at reduced temperature
•= Do not tumble dry.
Drying cycle duration
The drying time may vary depending on:
• speed of the final spin
• dryness degree required (iron dry, store dry)
• type of laundry
• weight of the load size .
The average drying time for a timed drying are indicated in
the «Drying programmes» chapter. The experience will
help you to dry your laundry in a more suitable way, ac-
cording to the different fabrics. Take note of the duration
drying time of the already performed cycles.
Additional drying
If the laundry is still damp at the end of the drying pro-
gramme, select a short drying cycle again.
Warning! Do not over dry the laundry in order to
avoid creasing of fabrics or garment’s shrinking.
Washing programmes
Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
1–5
— COTTONS
90°- (Cold)
Main wash - Rinses
Long spin at maximum speed
Max. load 7 kg - Reduced load 3,5 kg
1)
For white and coloured cotton (normally soiled items).
SPIN
RINSE HOLD
ECONOMY
2)
SUPER QUICK
EXTRA RINSE
EASY IRON
6–8
— COTTONS WITH PREWASH
90°-40°
Prewash - Main wash - Rinses
Long spin at maximum speed
Max. load 7 kg - Reduced load 3,5 kg
1)
For white or coloured cottons with prewash phase (heavily
soiled items).
SPIN
RINSE HOLD
ECONOMY
SUPER QUICK
EXTRA RINSE
EASY IRON
3)
13
www.zanussi.com

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
9–12
— SYNTHETICS
60°- (Cold)
Main wash - Rinses
Short spin at 900 rpm
Max. load 3,5 kg - Reduced load 2 kg
1)
Synthetic or mixed fabrics: underwear, coloured garments, non-
shrink shirts, blouses.
SPIN
RINSE HOLD
ECONOMY
2)
SUPER QUICK
EXTRA RINSE
EASY IRON
13–15
— DELICATES
40°- (Cold)
Main wash - Rinses
Short spin at 700 rpm
Max. load kg 3,5 - Reduced. load kg 2
1)
Delicate fabrics: acrylics, viscose, polyester.
RINSE HOLD
SUPER QUICK
EXTRA RINSE
16
— JEANS
40°
Main wash - Rinses
Long spin at 1200 rpm
Max. load 3,5 kg
With this programme it is possible to wash items like pants,
shirts or jackets in denim and also jersey realized with hi-tech
materials.
(The Extra Rinse option will be activated automatically).
SPIN
RINSE HOLD
EASY IRON
17–19
— HANDWASH
40°- (Cold)
Main wash - Rinses
Short spin at 900 rpm
Max. load 2 kg
Special programme for delicate fabrics with «hand washing»
care symbol and machine washable wollens.
SPIN
RINSE HOLD
— DRYING PROGRAMME
20
— COTTON DRYING
Drying programme for cotton items
14
www.zanussi.com

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Spin Speed
Maximum Fabrics Load
Type of Laundry
Options Detergent
Compartment
21
— SYNTHETICS DRYING
Drying programme for synthetic items
SPECIAL PROGRAMMES
22
— RINSES
Rinses
Long spin at maximum speed
Max. load 7 kg
With this programme it is possible to rinse and spin cotton gar-
ments which have been washed by hand. The machine performs
3 rinses, followed by a final long spin. The spin speed can be
reduced.
SPIN
RINSE HOLD
EXTRA RINSE
EASY IRON
23
— DRAIN
Draining of water
Max. load 7 kg
For emptying out the water of the last rinse in programmes with
the Rinse Hold option selected.
24
— SPIN
Drain and long spin
Long spin at maximum speed
Max. load 7 kg
Separate spin for hand washed garments and after programmes
with the Rinse Hold option selected. You can choose the spin
speed by pressing the relevant button to adapt it to the fabrics to
be spun.
SPIN
O = OFF
For cancelling the programme which is running or to switch the
machine off .
1) If you select the Super Quick option by pressing button 3, we recommend that you reduce the maximum load as indicated. Full
loading is possible however with somewhat reduced cleaning results.
2) This option can be selected at the temperature of 40°C or higher only.
3) If using liquid detergents, a programme without PREWASH must be selected.
15
www.zanussi.com

Drying Programmes
Degree of Drying Type of Fabric Max Load Spin Speed
Suggested dry-
ing time in
Mins
Ideal for towelling materials Cotton and linen (bath-
robes, bath towels, etc)
4 kg
3 kg
1,5 kg
1400
160-180
110-120
75-85
Suitable for items to put away with-
out ironing
Cotton and linen (bath-
robes, bath towels, etc)
4 kg
3 kg
1,5 kg
1400
150-170
100-110
65-75
Suitable for items to put away with-
out ironing
Synthetics and mixed
fabrics
2 kg
1 kg 900 90-100 55-65
Suitable for ironing
Cotton and linen
(sheets, tablecloths,
shirts, etc.)
4 kg
3 kg
1,5 kg
1400
120-140
80-90
50-60
In compliance with EC directive EN 50229 the cotton reference programme for the data entered in the Energy Label
must be tested dividing the maximum washing load by two equal parts and drying with DRYING TIME each of
them.
Care and cleaning
Warning! You must DISCONNECT the appliance
from the electricity supply, before you can carry out
any cleaning or maintenance work.
Descaling
The water we use normally contains lime. It is a good idea
to periodically use a water softening powder in the ma-
chine. Do this separately from any laundry washing, and
according to the softening powder manufacturer's instruc-
tions. This will help to prevent the formation of lime de-
posits.
External cleaning
Clean the exterior cabinet of the appliance with soap and
water only, and then dry thoroughly.
Cleaning the dispenser drawer
The washing powder and additive dispenser drawer
should be cleaned regularly.
Remove the drawer by
pressing the catch down-
wards and by pulling it
out. Flush it out under a
tap, to remove any traces
of accumulated powder.
To aid cleaning, the top
part of the additive com-
partment should be re-
moved.
16
www.zanussi.com

Cleaning the drawer recess
Having removed the draw-
er, use a small brush to
clean the recess, ensuring
that all washing powder
residue is removed from
the upper and lower part of
the recess.
Replace the drawer and run the rinse programme with-
out any clothes in the drum.
Cleaning the pump
The pump should be inspected regularly and particularly
if:
• the appliance does not empty and/or spin;
• the appliance makes an unusual noise during draining
due to objects such as safety pins, coins etc. blocking
the pump;
• a problem with water draining is detected (see chapter
“What to do if...” for more details).
Warning! Before opening the pump door, switch the
appliance off and remove the mains plug from the
socket.
Proceed as follows:
• Unplug the appliance.
• If it is necessary, wait until the water has cooled down.
Place a container close to
the pump (A) to collect
any spillage.
Pull out the emergency
emptying hose (B), place it
in the container and re-
move its cap.
When no more water comes out, unscrew the pump
cover by turning it anti-clockwise and remove the filter.
Use pliers, if necessary. Always keep a rag nearby to
dry up any water spillage when removing the cover.
Clean the filter under a tap, to remove any traces of fluff.
Remove foreign bodies
and fluff from the filter seat
and from the pump impel-
ler.
Check carefully whether
the pump impeller rotates
(it rotates jerkily). If it
doesn’t rotate, please con-
tact your Service Centre.
Put the cap back on the
emergency emptying hose
and place the latter back in
its seat.
Replace the filter into the
pump by inserting it cor-
rectly into the special
guides. Screw the pump
cover firmly by turning it
clockwise.
Caution! When the appliance is in use and
depending on the programme selected there can be
hot water in the pump.
Never remove the pump cover during a wash cycle, always
wait until the appliance has finished the cycle, and is
empty. When refitting the pump cover, ensure it is
securely re-tightened so as to stop leaks and young
children being able to remove it.
Cleaning the water inlet filters
Important! If the appliance doesn't fill, takes long to fill
with water, the starting button blinks yellow or the display
(if available) shows the relevant alarm (see chapter "What
to do if..." for more details), check if the water inlet filters
are blocked .
To clean the water inlet filters:
17
www.zanussi.com

• Turn off the water tap.
• Unscrew the hose from
the tap.
• Clean the filter in the
hose with a stiff brush.
• Screw the hose back onto the tap. Make sure the
connection is tight.
• Unscrew the hose from the machine. Keep a rag
nearby because some water may flow.
• Clean the filter in the valve with a stiff brush or with
the piece of cloth.
35° 45°
• Screw the hose back to the machine and make sure
the connection is tight.
• Turn on the water tap.
Frost precaution
If the machine is exposed to temperatures below 0°C, cer-
tain precautions should be taken.
• Turn off the water tap.
• Unscrew the inlet hose.
• Place the end of the emergency emptying hose and that
of the inlet hose in a bowl placed on the floor and let
water drain out.
• Screw the water inlet hose back on and reposition the
emergency emptying hose after having put the cap on
again.
• When you intend to start the machine up again, make
sure that the room temperature is above 0°C.
Emergency emptying out
If the water is not discharged, proceed as follows to empty
out the machine:
• pull out the plug from the power socket;
• close the water tap;
• if necessary, wait until the water has cooled down;
• open the pump door;
• place a bowl on the floor and place the end of the
emergency emptying hose into the bowl. Remove its
cap. The water should drain by gravity into the bowl.
When the bowl is full, put the cap back on the hose.
Empty the bowl. Repeat the procedure until water stops
flowing out;
• clean the pump if necessary as previously described;
• replace the emergency emptying hose in its seat after
having plugged it;
• screw the pump cover again and close the door.
Important! Every time you drain the water through the
emergency emptying hose you must pour 2 litres of water
into the main wash compartment of the detergent drawer
and then run the drain programme. This will activate the
ECO Valve device avoiding that part of the detergent
remains unused at next washing.
What to do if…
Certain problems are due to lack of simple maintenance or
oversights, which can be solved easily without calling out
an engineer. Before contacting your local Service Centre,
please carry out the checks listed below.
During machine operation it is possible that the red pilot
light of button 8blinks, one of the following alarm codes
appears on the display and some acoustic signals sound
every 20 seconds to indicate that the machine is not work-
ing:
•: problem with the water supply.
•: problem with the water draining.
18
www.zanussi.com

•: door open. Once the problem has been eliminated, press the button 8
to restart the programme. If after all checks, the problem
persists, contact your local Service Centre.
Problem Possible cause/Solution
The washing machine does not start:
The door has not been closed. E40
• Close the door firmly.
The plug is not properly inserted in the power socket.
• Insert the plug into the power socket.
There is no power at the socket.
• Please check your domestic electrical installation.
The main fuse has blown.
• Replace the fuse.
The selector dial is not correctly positioned and the button 8has not been
pressed.
• Please turn the selector dial and press the button 8again.
The delay start has been selected.
• If the laundry are to be washed immediately, cancel the delay start.
The Child Safety Lock has been activated.
• Deactivate the Child Safety Lock.
The machine does not fill:
The water tap is closed. E10
• Open the water tap.
The inlet hose is squashed or kinked. E10
• Check the inlet hose connection.
The filter in the inlet hose is blocked. E10
• Clean the water inlet hose filter.
The door is not properly closed. E40
• Close the door firmly.
The machine fills then empties im-
mediately:
The end of the drain hose is too low.
• Refer to relevant paragraph in «water drainage» section.
The machine does not empty and/or
does not spin:
The drain hose is squashed or kinked. E20
• Check the drain hose connection.
The drain filter is clogged. E20
• Clean the drain filter.
An option or a programme that ends with the water still in the tub or that elimi-
nates all the spinning phases has been selected.
• Select the draining or spinning programme.
The laundry is not evenly distributed in the drum.
• Redistribute the laundry.
19
www.zanussi.com

Problem Possible cause/Solution
There is water on the floor:
Too much detergent or unsuitable detergent (creates too much foam) has been
used.
• Reduce the detergent quantity or use another one.
Check whether there are any leaks from one of the inlet hose fittings. It is not
always easy to see this as the water runs down the hose; check to see if it is
damp.
• Check the water inlet hose connection.
The drain or inlet hose is damaged.
• Replace it with a new one.
The emergency emptying cap has not been replaced into the filter or the filter
has not been properly screwed in after cleaning action.
• Refit the emergency emptying cap into the filter or screw the filter fully in.
Unsatisfactory washing results:
Too little detergent or unsuitable detergent has been used.
• Increase the detergent quantity or use another one.
Stubborn stains have not been treated prior to washing.
• Use commercial products to treat the stubborn stains.
The correct temperature was not selected.
• Check if you have selected the correct temperature.
Excessive laundry load.
• Reduce the laundry load.
The door will not open:
The programme is still running.
• Wait the end of washing cycle.
The door lock has not been released.
• Wait for some minutes until the door lock is released.
There is water in the drum.
• Select drain or spin programme to empty out the water.
The machine vibrates is noisy:
The transit bolts and packing have not been removed.
• Check the correct installation of the appliance.
The support feet have not been adjusted.
• Check the correct levelling of the appliance.
The laundry is not evenly distributed in the drum.
• Redistribute the laundry.
Maybe there is very little laundry in the drum.
• Load more laundry.
20
www.zanussi.com
