Zartek ZA-438 User manual

USB Rechargeable
LED Headlamp
ZA-438
USERS MANUAL
Thank you for purchasing this Zartek headlamp. This headlamp has been
engineered and manufactured to give you years of dependable operation. Please
take a few moments to read through the manual to get full usage from this
innovative product.
Included items:
1 x LED Headlamp, 1 x Mains USB Adaptor, 1 x C type USB cable
SPECIFICATIONS:
Front COB LED, 350 Lumen
Side XPE LED, 150 Lumen
5 Modes:
Front Hi 2.5hrs, Med 5 hours
Side Hi 4 hours, Med 8 hours
Flashing both (press ON, then press in 2s)
Hand Induction Sensor to Switch On / Off
Wide beam 230° and 50 square meters
Rechargeable via USB type C (cable included)
Built-in 1200mAh Li-ion Rechargeable Battery
USB Charging Indicator Light
Charge time: 4 hours
Lightweight Silicon Rubber (weight 70g) Comfortable Headband
Durable & Splashproof IPX4
USB Mains Adaptor Included
Ideal for camping, running, hiking, cycling, fishing, reading, working, repair,
general
1 Year Limited Warranty

BRIGHT BEAM
Avoid direct eye exposure or serious eye injury could result.
To prevent damage to eyesight, never look into light when it is on.
Do not shine in any face.
This item is not a toy. Keep out of reach of children
Charging:
This headlamp has a built-in 1200mAH Li-ion battery pack. The Zartek ZA-438
headlamp is USB rechargeable yet bright with a long operating time. To locate
the charging socket, lift the rubber cover on the back of the headlamp. Plug in
provided USB mains adaptor, attach cable and then insert C type cable USB
connector into socket to charge. Recharge also via USB port on computer, laptop
or using a standard micro USB mains charger not exceeding 5V or 1A.
A red LED on the headlamp indicates charging, which turns to green when
fully charged.
Recharging is easy and safe as the battery cannot be overcharged. Charging will
stop once full.
•Charging time (1A): 4 hours
•Li-ion rechargeable battery
•Over 500 recharge cycles possible
Charging time may vary depending on the current rating of the supply.

Although the unit arrives partially charged from the factory, it must be fully
charged for 4 hours before first use. This initial charge pre-conditions the battery
for full capacity. Failure to charge may shorten the life span of the battery. Once
the light gets dim, recharge the battery immediately as it could get damaged if
left very flat.
Always make sure to push down the rubber cover over the socket after charging
to keep headlamp splash proof.
WARNING!
•Fully charge the headlamp before storing for long periods. Keep recharging
every few months or the battery may go faulty.
•Do not recharge this headlamp with any other adaptors other than those
stipulated: micro USB 5V, not exceeding 1A.
•Do not dispose of the battery in a fire or ordinary waste.
•Do not operate the headlamp in high temperature, hazardous or explosive
environments.
•Do not subject the headlamp to strong impacts or tight compressions.
•Do not disassemble or modify the headlamp as it contains protective
devices which, if damaged, may cause the battery to heat or ignite.
•Do not leave the headlamp in direct sunlight or hot spaces for extended
periods.
•Never short circuit, reverse polarity, disassemble, damage or heat the
battery packs over 100°C. If an exploded Li-ion battery does ignite, it will
burn more violently if it comes into contact with water or moisture. Never
put water on a burning Li-ion battery only use a fire extinguisher.
•This headlamp is rain and splash proof only but not submersible. If the light
gets submersed in water, immediately dry the headlamp and do not use for
a few days. Water damage is usually irreparable.
Operation:
Press the side ON button switch multiple times to toggle between lighting modes.
The ZA-438 headlamp is elegantly designed with 2 types of LED which provide
different beam shapes of light.
Rectangle front COB LED, 350 Lumens, is a wide 230° beam and with uniform
brightness for area lighting up to 50 square meters. The side round XPE LED,
150 Lumens, is a focused beam. Both lights have high modes for maximum

lighting applications as well as medium brightness modes for longer operating
times.
There are 5 modes:
Front Hi 2.5hrs > Med 5 hours > Side Hi 4 hours > Med 8 hours > OFF
Flashing both LED, once light is ON, press in and hold button for 2
seconds to switch flashing ON.
Hand Induction Sensor
The ZA-438 headlamp is equipped with a hand
induction sensor to easily switch the light On / Off
by passing ones hand over the sensor without
pressing buttons.
Select one of the four modes (Front Hi –Med, Side
Hi - Med. Flashing with induction is not supported)
using ON button then press INDUCTION button
next to ON button. Green indicator light shows induction is active. Pass a hand
within 5cm of the sensors located below buttons to switch light On or Off. To
disable, press INDUCTION button.
The Zartek ZA-438 headband headlamp is lightweight (70g) with silicon rubber
for comfortable wearing even over long times whilst camping, running, hiking,
cycling, fishing, reading, working, repair or with general use. Its casing is durable
and splashproof IPX4 to provide years of daily use. LED globes are shockproof
and never need replacing.
Maintenance:
All batteries lose charge over time. It is recommended that the headlamp should
be fully recharged every 2-3 months when not in use.
If the unit gets dirty, gently clean the outer surface of the headlamp with a soft
cloth moistened with a mild solution of water and detergent.
Store in a cool, dry place.
Warranty:
This product is warranted by Zartek against manufacturing defects in materials
and workmanship under normal use for a 12 month period from date of purchase
via our authorized appointed dealers.
For further information or any queries, please email us: [e-mail]
