Zebra-Tech UW-Calipers User manual

Zebra-Tech
UW-Calipers
Operation Manual

Zebra-Tech UW-Caliper Operation Manual
Contents
1. Your UW-Calipes at a glance............................................................1
Features...........................................................................................2
2. UW-Caliper specifications ...............................................................3
3. Charging your UW-Calipers .............................................................4
4. Operating your UW-Calipers ...........................................................5
Switching on ....................................................................................5
Switching off ....................................................................................5
Taking a measurement ....................................................................5
Logging a measurement ..................................................................5
Tare the UW-Calipers.......................................................................7
5. Communicating with your UW-Calipers ...........................................8
Installing UW-Caliper software onto a PC .......................................8
Connecting the UW-Caliper to a computer.....................................8
UW-Caliper software .......................................................................9
UW-Caliper connection window....................................................10
6. Data file........................................................................................ 13
7. Maintenance ................................................................................ 14
8. Further assistance......................................................................... 15

Zebra-Tech UW-Caliper Operation Manual
| 1 |
1. Your UW-Calipers at a glance
The Zebra-Tech UW-Calipers are rugged field calipers designed to operate
accurately and reliably in harsh environments and underwater to a depth
of 40 meters.
At the push of a button the UW-Calipers record the caliper measurement,
together with the time and date as well as depth if the optional depth
sensor is installed.
Data collected by the UW-Calipers can be offloaded onto a PC and then
simply opened in an Excel spreadsheet.
UW-CALIPERS WITH OVERBITE, CHARGER AND COMS CABLE

Zebra-Tech UW-Caliper Operation Manual
| 2 |
Features
The UW-Calipers offer the following features:
Rugged design
Simple to operate, even while wearing thick dive gloves
One or two button operation
Rechargeable on-board battery with long operating capacity
Capacity to store 8000 records
Simple windows software for offloading collected data
USB communication
UW-CALIPERS WITH 60MM JAWS FITTED

Zebra-Tech UW-Caliper Operation Manual
| 3 |
2. UW-Caliper specifications
Specifications
Maximum depth:
30m
Maximum caliper measurement:
240mm
Caliper resolution:
0.5mm
Caliper accuracy:
Closing jaws +/-1mm or better between 0-40˚C
Depth resolution (optional):
0.1 meter
Memory:
8000 records (each record consists of Caliper
measurement, depth (if fitted), time, date. Data
is non-volatile; if the battery goes flat, data is
not lost).
Battery endurance:
+40 hours on a full charge
Options
Depth sensor:
Depth sensor which enables depth to be recorded with each
measurement
Jaw length:
Button:
60mm or 90mm jaw size
Custom jaw profiles available on request
Single button, or two button
FIELD SWAPPABLE 60MM AND 90MM JAWS

Zebra-Tech UW-Caliper Operation Manual
| 4 |
3. Charging your UW-Calipers
Unscrew the charging/coms cap from the end of the calipers.
Push on the charging plug. Tighten the locking sleeve.
Plug the charger into mains power; the red ‘Power’LED should be
continuously illuminated. For the first minute, the green ‘Ready’LED
should flash. This indicates the battery status is being tested. After one
minute the green ‘Ready’LED will stop flashing while the red ‘Charge’LED
will remain illuminated.
When charging is complete, the red ‘Charge’LED will go off, and the green
‘Ready’LED will flash (trickle charge).
After charging, disconnect the charger from the mains power.
Disconnect the charging cable from the UW-Calipers.
Clean and re-grease the O ring on the charging/coms cap.
Screw the cap back onto the UW-Caliper. Do not over tighten.
UW-CALIPERS WITH CHARGING/COMS CAP UNSCREWED

Zebra-Tech UW-Caliper Operation Manual
| 5 |
4. Operating your UW-Calipers
Switching On
Simply press the blue button to switch on your UW-Calipers. The green
light will light up briefly and the current caliper measurement will be
displayed.
Switching Off
The calipers automatically switch off if the outer jaw is not moved for
5 minutes.
Taking a measurement
Open the outer jaw of the UW-Caliper wider than the object being
measured. Then gently close the jaws on the object.
The UW-Calipers are calibrated for measuring on a closing jaw action. If
the jaw movement directly prior to a measurement is in the opening
direction, then the accuracy of the measurement will be reduced.
Logging a measurement
By simply pressing and releasing the blue button, the current caliper
measurement is logged, together with the current time and date, and the
water depth if the calipers incorporate the optional pressure sensor.
If your caliper has 2 buttons, whichever button is pressed is logged in the
data file. This enables measurement differentiation. For example, you can
differentiate between 2 species, or length and width measurements.

Zebra-Tech UW-Caliper Operation Manual
| 6 |
A break in the data file can be created by logging a closed jaw or fully open
jaw measurement. For example, if measurements are being made along a
transect, a zero measurement can be logged at the end of the transect.
This can then be identified in the data file.
TWO BUTTON UW-CALIPER
ONE
TWO

Zebra-Tech UW-Caliper Operation Manual
| 7 |
Tare the UW-Calipers
When the calipers are gently closed, they should display 0.0mm. If they
don’t, they can be tarred by pressing and holding the blue button. After
10 seconds ‘Tare’should appear on the display. The blue button can then
be released.
ONE BUTTON UW-CALIPER

Zebra-Tech UW-Caliper Operation Manual
| 8 |
5. Communicating with your UW-Calipers
Installing UW-Caliper software onto a PC
The UW-Calipers are supplied with a flash drive that carries the file ‘Install
UW-Caliper version #’.Simply double clicking this file should start the
installer which handles the installation of the software onto the PC.
The latest version of the software can also be downloaded from the Zebra-
Tech web site http://www.zebra-tech.co.nz/downloads
Connecting the UW-Caliper to a computer
Unscrew the charging/coms cap from the end of the calipers.
Push on the communication cable plug, and tighten the locking sleeve.
Plug the USB connector into the PC, and start ‘UW-Caliper’software.
NOTE!
It is recommended that the UW-Caliper software is
installed BEFORE the calipers are connected to the PC for
the first time.

Zebra-Tech UW-Caliper Operation Manual
| 9 |
UW-Caliper Software
When the UW-Caliper is connected to a PC and the software started, the
connection window should open.

Zebra-Tech UW-Caliper Operation Manual
| 10 |
UW-Caliper Connection Window
Your computer has many ‘com ports’. When the UW-Calipers are plugged
into a USB port, the computer assigns it a com port. The com port number
may be the same as previously assigned or it may have changed.
To simplify connection, UW-Caliper software features both an ‘Auto
Detect’ and ‘Manual Detect’ option.
Once the UW-Calipers have been successfully connected, the main
window opens.
Auto detect
If the UW-Calipers have not previously been connected to the
computer or the manual connection doesn’t find the UW-Caliper, then
the auto detect option is recommended to initiate communications.
Pressing the ‘Auto connect’ button causes the computer to
systematically check all available com ports for the UW-Calipers. This
takes a little time, but generally locates them in the end.
Manual detect
If the UW-Calipers have been successfully connected to the PC in the
past, then pressing the ‘Manual connect’ button quickly reconnects
using the same com port.

Zebra-Tech UW-Caliper Operation Manual
| 11 |
About
This button displays the current UW-Caliper firmware and software
versions.
Offload Data
This button enables stored data to be offloaded from the UW-Calipers to
the designated file. A text box opens enabling comments to be typed
directly into the header of the data file.

Zebra-Tech UW-Caliper Operation Manual
| 12 |
Erase Logger Memory
This deletes all data off the UW-Calipers. This should be undertaken after
data has been successfully offloaded from the calipers.
Set Time/date
This sets the UW-Caliper time and date to PC time and date.
After communication, disconnect the UW-Caliper from the coms cable.
Clean and re-grease the O-ring on the coms/charging cap. Screw the cap
back onto the UW-Caliper, but do not over tighten.

Zebra-Tech UW-Caliper Operation Manual
| 13 |
6. Data file
The data file is formatted as comma separated values (.csv). This can be
opened in Excel.
Headers are inserted at the top of the data file during the download.
Example data file:
Serial number Button Date (dd/mm/yy) Time (hh:mm:ss) Caliper (mm) Depth (meters)
112 2 22/11/2011 7:32:01 44 7.9
112 1 22/11/2011 7:32:03 44 7.9
112 1 22/11/2011 7:32:08 44 7.9
112 1 22/11/2011 7:32:10 44 7.9
112 2 22/11/2011 7:35:35 21 7.8
112 2 22/11/2011 7:35:36 21 7.8
112 2 22/11/2011 7:35:38 21 7.8
112 2 22/11/2011 7:35:40 21 7.8
112 2 22/11/2011 7:35:42 21 7.8
112 2 22/11/2011 7:35:44 21 7.8
112 1 22/11/2011 7:41:02 21.5 7.7
112 2 22/11/2011 7:41:05 21 7.7
112 2 22/11/2011 7:41:07 21 7.7
112 1 22/11/2011 7:41:09 21.5 7.7
112 1 22/11/2011 7:56:02 134 7.4
112 1 22/11/2011 7:56:03 134 7.4
112 1 22/11/2011 7:56:04 134 7.4
112 1 22/11/2011 7:56:04 134 7.4
112 1 22/11/2011 7:56:08 134 7.4
112 1 22/11/2011 7:56:54 134 7.4
112 1 22/11/2011 7:56:54 134 7.4
112 1 22/11/2011 7:56:54 134 7.4
112 1 22/11/2011 7:56:55 134 7.4
112 1 22/11/2011 7:56:56 134 7.4
112 1 22/11/2011 7:56:58 134 7.4
112 1 22/11/2011 7:56:59 134 7.4
112 1 22/11/2011 7:57:00 134 7.4
112 1 22/11/2011 7:57:01 134 7.4
112 1 22/11/2011 7:57:02 134 7.4
112 1 22/11/2011 7:57:03 134 7.4

Zebra-Tech UW-Caliper Operation Manual
| 14 |
7. Maintenance
The UW-Calipers should be washed after every day of field use. Mud can
be hosed off and then salt water rinsed off by washing under a tap.
The UW-Calipers should be dried and lubricated prior to storage. To
lubricate, ensure the two caliper guide rods are dry and then apply a few
drops of the supplied lubricant onto each rod. Work the caliper backwards
and forwards a few times to distribute the lubricant.
If fitted, the depth sensor may require cleaning. If the depth measurement
reported rises significantly beyond 0m when the UW-Calipers are not
submerged in water, then it is possible that sediment has built up on the
face of the depth sensor.
To clean the depth sensor, carefully remove the 4 screws in the pressure
sensor cover plate and remove the plate. DO NOT TOUCH THE DEPTH
SENSOR WITH YOUR FINGERS OR ANY OBJECT.
UW-CALIPER DEPTH SENSOR –COVER PLATE REMOVED
DEPTH
SENSOR
COVER
PLATE

Zebra-Tech UW-Caliper Operation Manual
| 15 |
Using a syringe filled with water, or a similar device, gently wash sediment
off the depth sensor face. It may be necessary to soak the sediment
overnight.
Once the depth sensor is clean, replace the cover. DO NOT OVERTIGHTEN
THE COVER RETAINING SCREWS.
8. Further Assistance
For further assistance with this or any other Zebra-Tech product, please
contact:
Zebra-Tech Ltd
PO Box 1668
Nelson 7040
New Zealand
Tel: International 0064 3 548 0468
Fax: International 0064 3 548 0466
Email: [e-mail]
For up to date information about Zebra-Tech products, please visit the
Zebra-Tech Ltd website at: http://www.zebra-tech.co.nz.
Proudly designed and manufactured in New Zealand
