ZEMITS ABIGON PRO User manual

ZEMITS ABIGON PRO
USER'S MANUAL
ULTIMATE BODY REMODELLING SLIMMING SYSTEM
CAVITATION - RADIOFREQUENCY - INFRARED LIGHT - VACUUM

Accessories and handpieces
Configuration
Installation
Operating the system
Theory
Contraindications
Maintenance
Troubleshooting
Warranty
Technical Specifications
Contact
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
02
C O N T E N T

Main unit
Acrylic holders for hand pieces
Cavitation hand piece
Supreme Body Sculpting Slimming applicator with VACUUM & RF SYNERGY
Multipolar RF Body hand piece
Bipolar RF Facial hand piece
Tripolar RF hand piece for Face & Décolleté
Waste Collector External Filter
Power cable
03
ACCESSORIES
AND HANDPIECES

04
CONFIGURATION
Front View
Back view:
Touch screen
Hand pieces
1.
2.
Inputs for each applicator: 1.
A) Cavitation hand piece
B) Bipolar RF hand piece
C) Tripolar RF hand piece
D) Vacuum RF hand piece
E) Multipolar RF hand piece
2. Waste collector External Filter
Right side view:
Vacuum intensity adjuster1.
Left side view:
Power cord input
Power button
1.
2.

05
INSTALLATION
Unpack your new machine
Place it on a steady surface
Attach the acrylic holders
Attach all hand pieces to their specific inputs
Place each hand piece on the acrylic holder
Install vacuum filter to the back of the unit
CONFIGURATION
First screen:
Touch the screen to enter the working menu

06
CONFIGURATION
Working screen:
Cavitation - Targeted fat and cellulite reduction
MultiPolar RF - Body tightening
Vacuum RF - Body sculpting and cellulite reducing lymph
drainage
Tripolar RF - Facial and Décolleté skin firming
Bipolar RF - Targeted facial skin firming
Select the hand piece :
1.
2.
3.
4.
5.

Adjust working time (an average cavitation session is about 20-40 minutes.
Cavitation treatment should not exceed 60 minutes per body per week)
Adjust working intensity Level 1 -10
Select the working mode:
Adjust each step of your settings:
1.
2.
3.
P0 - Most intense mode, constant cavitation. Ideal for the buttocks, back and outer
thighs
P1 - Less intense. Ideal for front and inner thighs
P2 - Medium intensity. Ideal for abdomen and arms
P3 - Pulse mode, the least intensive mode. Ideal for target fat deposits
4. Press Start to start the procedure.
Press on the BACK arrow sign to go back to working menu
07
CONFIGURATION
Cavitation Treatment

Cavitation Theory
Ultrasonic refers to sound frequency. While vibrating, an Ultrasonic Cavitation
handpiece emits sound we cannot hear. We measure the number of vibrations per
second as sound frequency, and refer to this as Hertz. Humans ears can hear
anywhere from 20 to 20,000 hertz, but nothing above or below this parameter.
Therefore, sound waves with frequencies above 20,000 hertz are referred to as
“Ultrasonic”. A Megahertz (MHz) is 1,000,000 hertz. Usually, an ultrasonic
frequency of 1 MHz to 5 MHz is used for various medical treatments. The lower the
megahertz is, the stronger the treatment. Lower frequencies are highly
penetrative and directional.The vibration of ions (positive and negative
alternation of sound waves) produce a strong wave of pressure to fat cell
membranes. Usually a fat cell membrane cannot withstand this pressure, it will
explode into the liquid content. This liquid product leaves the body through the
normal channels of the body’s metabolism.Ultrasonic Cavitation’s results are
achieved by the quantity of fat cells destroyed and removed from the body’s fat
storage compartments.
Ultrasonic cavitation technology enables concentrated sonic energy to be
directed only at localized treatment areas, and is thus capable of selectively
disrupting the subcutaneous fat cells through thousands of microscopic
implosions impacting the fat cell membranes. After the breakdown of adipose
tissue (fat cell membrane), fat is released into interstitial fluid between cells,
where it is enzymatically metabolized into glycerol and free fatty acids. Water-
soluble glycerol travels into the circulatory system to generate energy while
insoluble free fatty acids enter the liver to be decomposed like any other simple
fatty acids.
08
CONFIGURATION

09
CAVITATION MUST-KNOW FACTS
1. Always use the proper technique: direct the handpiece in towards the skin fold
A lot of providers perform incorrect techniques by simply gliding the cavitation probe over the
skin; this technique could potentially be unsafe for the abdomen area.
The proper technique is to hold the skin fold using one hand and focusing the cavitation
handpiece into this fatty fold; this technique helps to accumulate the power of ultrasound
waves inside the hypodermal fatty layer and prevents the ultrasound from going through into
the abdomen area.
2. Perform targeted treatments instead of covering a large area within one treatment
Another mistake that several providers make is treating a large skin area at once combined
with moving the handpiece over the skin too quickly. This technique doesn't allow the
handpiece to stay over the treated area long enough, and ultrasound vibration cannot be
forced on the targeted fatty cells - resulting in a less effective treatment.
The most effective way is to focus on a small skin area about 4" x 4" or 6" x 6" for the entirety of
the treatment of 20-30 minutes depending on the location. You should use slow motions
giving time for the energy to penetrate the skin and effectively work with the adipocytes.
Always ensure to reapply conductive gel during the treatment to allow ultrasound to
penetrate evenly into the skin.
3. Perform the lymphatic drainage treatment for the entire body after each cavitation session
If you have an opportunity to perform a full body lymph drainage massage, such as
Pressotherapy, LPG, or EMS muscle stimulation, always offer these treatments in a package
with your cavitation treatments. An additional full body massage can help to keep healthy
liquid circulation, reduce edema, and drastically enhance skin oxygenation which leads to
firmer skin and less cellulite appearance.

10
CAVITATION PROTOCOL
Duration of cavitation should not exceed more than 40 min per session.
Recommended frequency of cavitation sessions is 1-2 times per week.
Total cavitation exposure should not exceed 60 minutes per week for one person
Clean the treated skin area.
Apply ultrasound conductive gel on the skin.
Select the minimum working parameters on the machine (it is recommended to start an low
intensity and increase steadily throughout the treatment).
Move the handpiece in circular lines without pressure on the skin fold. You should point the
nozzle in direction of the skin-adipose tissue. Do not direct it straight toward the bones or
body cavities.
The handpiece should be in constant motion. Do not stop in one spot.
You should apply cavitation only on the local areas of fatty deposits.
It is prohibited to use cavitation over the protruding angles of bones (iliac bones, ribs, knees,
elbows, etc.)
It is prohibited to use cavitation on the joints, on the projection of the glands, pelvic, popliteal
fossae, elbows, face, neck, and armpits.
You should always control the gel layer by applying more if necessary.
It is necessary to provide lymphatic drainage after cavitation to accelerate the process of
removing the decay products.
The average treatment consists of 5-10 sessions.
Recommendations
Cavitation treatment should be performed one to two times per week
One session consisting of several treatments should be performed twice a year
On the day of treatment, patient should drink at least 1.5-2 liters of water

11
CAVITATION PROTOCOL STEPS
1. Position your client comfortably on a flat massage table.
2. Apply a thick even layer of the conductive gel.
Tip for better service: warm up the gel in hot water prior to applying to avoid any
uncomfortable or cold sensations when applying cold gel on sensitive skin areas.
3. Remember: Cavitation can only be performed on areas with unwanted fatty layers.
4. Perform the cavitation treatment using slow, circular massage motions. Use both of your
hands, where one hand holds the handpiece directed into the fatty fold and the other hand
pushes the skin fold towards the handpiece.
5. Reapply the gel during the treatment when needed. It should always be comfortable and
easy to glide the handpiece.
6. Perform the treatment for 20-30 minutes depending on the size of the treatment area and
the depth of the fatty layer.
7. Important: on the lower abdomen area do not point the cavitation handpiece directly to the
stomach cavity - always point it into the fatty fold, stay on the marked treatment area.
Always take extra precautions to be gentle and careful on the upper abdomen area. Do not
work under the rib cage, stay focused on the fatty fold.
8. At the end of the treatment, wipe away any remaining gel.
9. Always follow up with a lymphatic drainage massage right after the cavitation treatment.
10. For manual lymphatic massage performance, apply a thin layer of massage oil and
perform the massage in the direction of the lymphatic flow.

Adjust working t i m e : an average vacuum rf session is a b o ut 20-30 minutes.
Adjust RF intens i t y Level 1 -20
back of the legs + buttocks - Intensity 12- 18 RF for 30 minutes
the front surface of the legs - Intensity 10- 18 RF for 20 minutes;
abdomen - Intensity 12- 18 RF for 15-20 minutes
sides - Intensity 10- 18 RF for 10 minutes
hands - Intensity 10- 15 RF for 20 minutes
back - Intensity 12- 18 RF for 15 minutes
Adjust each step of your settings:
1.
2.
3. Adjust Vacuu m S uction pattern:
Suction duration in seconds (the longer the suction the more intense the treatment)
Release duration in seconds (the shorter the release the more intense the treatment)
4. Select the wo r k i ng mode
P0 - buttocks/thighs;
P1 - abdomen;
P2 - back, flanks, and waist;
P3 - arms
5. Press Start t o s t art the procedure.
Press on the BACK arrow sign to go back to the working menu
12
CONFIGURATION
Vacuum RF Treatment

In order to achieve stable results after the cavitation session the skincare professional
needs to trigger the lymphatic drainage through specific technique. One of the most
effective ways is Vacuum RF treatment.
The increased lymphatic circulation helps to excrete the wastes of collapsed adipocytes.
Zemits Abigon PRO has the most unique Body Sculpting Applicator, which utilizes a synergy
of RadioFrequency and Vacuum Deep Tissue Massage. The Supreme Body Sculpting
applicator was created for body contouring and sculpting. It is a synergy of two
technologies that can be used simultaneously or as two separate features.
The synergy of RF and Vacuum smooths the skin, flashing the toxins and waste products
with the lymph flow.
Vacuum + RF + InfraRed Light
Abigon PRO has a unique Vacuum RF+IR handpiece, created for body contouring and
sculpting. It is a powerful synergy of three technologies that can be used simultaneously or
as two separate features.
1. Quatro - Polar RadioFrequency
RF utilizes the power of gentle electrical current pulses that stimulate intra-dermal heating.
The heat created by RF initiates a cascade of rejuvenating processes in the skin. As a
result, collagen production increases which leads to skin tightening and firming.
2. Vacuum Lymphatic Drainage
Vacuum aspiration creates negative pressure and pulls the skin into the hand-piece.
Vacuum accelerates both: blood and lymph flow, which in turn increases skin elasticity and
significantly reduces the appearance of cellulite.
3. IR - Infrared Light Skin Tightening
The InfraRed light improves skin imperfections including saggy skin, lack of skin tone and
elasticity, and skin laxity.
Infrared light heats and contracts collagen fibers within the skin to stimulate the formation
of new collagen.
The synergy of Vacuum suction with RF and IR Light helps to smooth and tighten the skin,
flushes the toxins and waste products with the natural lymph flow, decreasing cellulite and
drastically improving skin elasticity.
SUPREME BODY SCULPTING
13

Adjust working t i m e : an average RF session is about 3 0 - 4 5 minutes.
Adjust RF intens i t y Level 1 -20
back of the legs + buttocks - Intensity 12- 18 RF for 40 minutes
the front surface of the legs - Intensity 10- 18 RF for 30 minutes;
abdomen - Intensity 12- 18 RF for 30-35 minutes
sides - Intensity 10- 18 RF for 20 minutes
hands - Intensity 10- 15 RF for 20-30 minutes
Adjust each step of your settings:
1.
2.
3. Press Start t o s t art the procedure.
Press on the BACK arrow sign to go back to the working menu
14
CONFIGURATION
Body Multipolar RF Treatment

15
RF Theory
The RF energy supports the metabolism of large fat granules previously
ruptured by cavitation, forcing the excretion of triglycerides and triggering of
skin tightening.In this process, the dermis and subcutaneous layer are heated
simultaneously, forcing collagen fibers to contract. The contracting fibers pull
on and tighten the skin, creating an immediate effect. Fibroblasts’
metabolism also increases, producing new collagen fibers which last long-
term. RF energy enters the deeper dermal layer, causing the dermis to
thicken. This decreases wrinkle depth and leaves skin firmer with increased,
lifted contour. As a result of radiofrequency’s skin stimulating effects, original
collagen proteins become stronger to increase the production of new
collagen proteins.
By using Ultrasound, RF, and Vacuum technologies together, direct access to
deeper fat cells is significantly increased. Ultrasonic waves and the
production of localized heat brings fat cells to fast-active states, so
effective blood circulation occurs.This increased localized blood circulation
within the dermis tightens sagging or loose, aging skin. Skin elasticity
improvement is aided by increased metabolic activity. And with the aid of the
vacuum, the sweat glands and lymphatic system excrete excess fat and
toxins from the body. The vacuum suction further dissolves fat cell and
strengthens the integrity of cells’ mitochondria, enhancing blood and lymph
circulation with metabolism benefits.

16
RF PROTOCOL
Prepare the client for the session:
Take off all jewelry
Remove makeup and clean the skin
Optional:
Perform dermabrasion or skin exfoliation for a deep cleanse
Apply Zemits FirmingGenius conductive gel on the cleansed skin for better conduction, and
apply Zemits DazzleSkin massage oil for better gliding.
Always start at a low RF intensity to prevent burns, and adjust intensity increase during
treatment if needed.
Slowly move the handpiece on the skin following lymph flow directions.
Note: adjust the vacuum suction pattern gradually: the higher the RF intensity the shorter
vacuum inhale should be.
During treatment, all electrodes on the handpiece must contact the skin tightly and all at
once. Otherwise, burning on the skin may occur.
The higher the intensity, the faster the handpiece must be moved.
Ask your client to inform you if he or she feels any strong discomfort. Normally, patients
experience a comfortable warm sensation throughout treatment.
Duration of Vacuum RF Therapy should be about 20-30 minutes, depending on the size and
condition of the treated zone
Recommended frequency of RF Therapy is 5-15 sessions at 1 session per every 5-15 days.
Here are the time and intensity recommendations per area:
Treatment area
Abdomen
Buttocks
The posterior and outer surface of the thigh
The anterior and inner surface of the thigh
Calves
Hands
Intensity
12-18 J
15 - 18 J
12 - 18 J
10- 18 J
10-15 J
10 - 15 J
Treatment time
15-20 minutes
30 minutes
30 minutes
20 minutes
10-20 minutes
20-40 minutes

17
VACUUM RF THEORY
This mechanical treatment uses external suction to lift the body tissues via moving or static
cups. The treatment is similar to a massage; however, suction is applied instead of pressure. If
performed correctly the treatment is very relaxing. The main use of this treatment is to
stimulate the lymphatic and circulatory systems, thus aiding the flow of waste products and
tissue fluids from the area to the nearest lymph nodes. The treatment can be applied to any
part of the body where there is sufficient adipose tissue. It is often used in conjunction with
other treatments and is most beneficial if used as a course of treatments.
The suction effect occurs due to a reduced atmospheric pressure inside the hand-piece. As
the air is sucked out, the skin and subcutaneous tissue is sucked upwards.
Uses of the vacuum suction treatment
To improve and reduce areas of cellulite.
To improve poor blood circulation.
To improve poor lymphatic circulation and drain waste products from the tissues.
To reduce areas of fluid retention or oedema (non-systemic).
To assist with the removal of fatty deposits for example on the thighs, abdomen, tops of arms,
buttocks or dowagers hump - all in-conjunction with diet and exercise.
A combination of Vacuum and RF in one treatment has been demonstrated to effectively
improve body contour and reduce the appearance of cellulite. In addition, it can result in up to
a seven centimeter reduction in thigh circumference after a complete series of treatment
sessions.Most patients opt for a series of six to ten treatment sessions for each area and see a
gradual, noticeable improvement in skin smoothness, circumference, and contour.While this is
not a permanent treatment and maintenance treatments are necessary, patients can extend
results by adopting a healthy lifestyle that includes regular physical activity and proper
nutrition. Pressing the trigger activates a vacuum coupling and massaging effect. Meanwhile,
Radiofrequency energies are emitted. This widens local blood vessels and increases blood
circulation and lymphatic drainage.The effects of all these changes results in a circumferential
reduction of the treated area, improvement in visible cellulite, and body reshaping.

18
VACUUM RF THEORY CONTINUED
Since cellulite is thought to be triggered by a weakening of connective tissues
and a decrease in microcirculation, vacuum RF is a great alternative to
conventional treatments.
Vacuum RF therapy is now proven to supercharge any cellulite treatment
because:
1. Vacuum RF therapy is proven to reduce overall circumference of the hips,
waist, thighs, and upper arms, with recent studies proving the long-term
effectiveness of results.
2. RF is proven to boost collagen and elastin production (reversing the
breakdown of collagen that induces cellulite, and fixing damaged skin)
3. Vacuum therapy improves lymphatic drainage, essential to any cellulite
treatment for swelling prevention.
With the deep Radiofrequency Energy the dermis and subcutaneous layer are
heated simultaneously, forcing collagen fibers to contract. The contracting fibers
pull on and tighten the skin, creating an immediate effect. Fibroblasts’
metabolism also increases, producing new collagen fibers which last long-
term. Most of the RF energy enters the deeper dermal layer, causing the dermis
to thicken. This decreases wrinkle depth and leaves skin firmer with increased,
lifted contour. As a result of radiofrequency’s skin stimulating effects, original
collagen proteins become stronger to increase the production of new collagen
proteins.Effects Immediately shorten existing collagen fibers, thereby creating an
immediate skin tightening/lifting effect.Stimulate fibroblasts to produce new
collagen and elastin fibers, thus triggering a separate skin tightening
effect.Stimulate and damage adipocytes (fat cells) to release fat into the
bloodstream (adipocytes are very fragile in comparison to fibroblasts or other
tissue cells).

19
Improves local blood circulation
Improves detoxification
Increases results of cryo slimming and toning
Gives skin a healthy, natural skin glow
THE IMPORTANCE OF LYMPH MASSAGE AFTER SESSION
We recommend to perform lymph massage at the end of each cavitation slimming
treatment to improve the results of the session.
Lymph activation prevents sagging and eliminates toxins and tissue waste. Since this
increases blood circulation, cell metabolism in cells is also sped up and the production of
collagen and connective tissue improve.
BENEFITS:
Lymphatic System:
Simulates the pumping effect that the muscles normally create in the lymph vessels. By
alternately applying and releasing pressure over the lymph vessels, lymph fluid is moved
towards the nearest lymph nodes. Lymphatic circulation is increased which assists with the
removal of waste products, and the appearance of any puffiness such as water retention
will improve as a result.
Circulatory System:
Circulation is increased which brings fresh oxygen and nutrients to the area. Extreme
dilation of the blood vessels results in erythema, which this process helps combat by
reducing capillary congestion. Venous flow is also sped up, assisting in the prevention of
couperose skin and rosacea.
Skin: Speeds up cell metabolism, improves facial color, softens fatty deposits, and
increases sebum production

20
TREATMENT TIPS
Mandatory water consumption: 1.5-2 liters of water per day throughout the
slimming course.
During this period, if the amount of water is conscientiously controlled,
healthy water consumption becomes a habit and a person transitions their
diet to be more beneficial.
Consequently, decreasing of the amount of consumed food will positively
contribute to the client's metabolism acceleration and weight loss goals.
2. Stabilization of dietary regime: During the slimming course, it is
recommended eating lighter meals at frequent intervals rather than eating
few heavy meals. This habit has positive effects on the client's body shape
and overall health.
3. It's not recommended to eat carbs 2 hours before or 2 hours after the
procedure, but patients may snack lightly on yogurt or berries. This habit has
the same advantages as staying hydrated and maintaining proper food
intake.
4. Minimal physical activity during the day: steady cardio training or a 30-
minute walk per day accelerates metabolism, helps reduce swelling, and
provokes the quick excretion of cell dissolution products after CoolRestore.
This habit also restores muscle tone which impacts body contour and skin
elasticity. Additionally, this is a great preventative measure against future
swelling and cellulite.
5. Lymphatic massage: After every cavitation procedure, a beauty therapist
must provide the client with a crucial massage to stimulate lymphatic
drainage.
