Zephyr PRW24C02BPG Installation guide

WWW.ZEPHYRONLINE.COM
JUN20.0301
lower zone
eno
z
reppu
PRW24C02BPG
Presrv Dual Zone Panel Ready Wine Cooler
EN Use, Care, and Installation Guide
FR Guide d’utilisation, d’entretien et d’installation

2PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™

3
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Contents
Page
Safety Information ............................................................................4-11
Types of Safety Warnings................................................................... 4
General Safety ..................................................................................5-7
Save These Instructions ...................................................................... 8
Disposal of Old Appliance................................................................... 8
Before Using Your Appliance ............................................................... 9
Installation of Your Appliance ...........................................................9-10
Attention.............................................................................................10
Electrical Connection .........................................................................11
Introduction ....................................................................................... 12
List of Materials.................................................................................. 13
Product Specications .....................................................................14-17
Product Summary ..............................................................................14
Internal Storage..................................................................................14
Parts Identification .............................................................................15
Dimensions...................................................................................... 16-17
Installation Instructions....................................................................18-23
Installation Clearance Requirements ..................................................18
Reversing the Door Swing of Your Appliance .......................................19
Installing the Handle.......................................................................... 20
Reversing the Door Swing of Your Appliance .......................................21
Installing the Wooden Shelves ........................................................... 22
Removing the Wooden Shelves .......................................................... 22
Carbon Filter ..................................................................................... 23
Operating Your Appliance ............................................................... 24-26
Using the Control Panel..................................................................... 24
Internal Light ..................................................................................... 25
Door Open Alarm............................................................................... 25
Sabbath Mode................................................................................... 25
Demonstration Mode ......................................................................... 26
Temperature Alarm ............................................................................ 26
Defrosting.......................................................................................... 26
Care and Maintenance.................................................................... 27-28
Normal Sounds.................................................................................. 27
Cleaning the Unit .............................................................................. 27
Power Failure..................................................................................... 28
Moving Your Wine Cooler................................................................... 28
Energy Saving Tips ............................................................................ 28
Troubleshooting............................................................................... 29-30
Notes................................................................................................31-32
Limited Warranty ...............................................................................33
Product Registration...........................................................................34

4PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Safety Information
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual for your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can cause severe
bodily injury or death. All safety messages will follow the Safety Alert Symbol and either the words
“DANGER” “WARNING” or “CAUTION”
DANGER
WARNING
CAUTION
Danger means that failure to heed this safety
statement may result in severe injury or death.
Warning means that failure to heed this safety
statement may result in extensive product damage,
serious personal injury, or death.
Caution means that failure to heed this safety
statement may result in minor or moderate
personal injury, property or equipment damage.

5
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
When using an electrical appliance, basic precautions should
always be followed to reduce the risk of fire, electric shock, and
injury to persons.
DANGER
For your safety, read all instructions carefully before operating the appliance.
To reduce the risk of fire, electric shock or personal injury, unplug
or disconnect the appliance from the power supply before
servicing.
WARNING
Flammable refrigerant used! When handling, moving and use of
the refrigerator, make sure to avoid either damaging the
refrigerant tubing, or increasing the risk of a leak.
CAUTION
►Use this appliance only as described in this manual. Other uses not recommended may cause fire,
electric shock or personal injury.
►This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
►Young children should be supervised to ensure that they never play with the appliance.
►To protect against the risk of electric shock, NEVER IMMERSE the unit, cord, or plug in water or
spray any other liquid.
►Unplug the appliance from the plug socket when not in use, when moving from one location to
another and before cleaning.
General Safety

6PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Safety Information
For your safety, read all instructions carefully before operating the appliance.
►To disconnect the appliance, grip the plug and pull it from the wall outlet. Never pull by the cord.
►Never operate the appliance in the presence of explosive and/or flammable fumes.
►Never place the appliance or any of its parts near an open flame, cooking or other heating
appliance.
►Never operate the appliance with a damaged cord or plug, if the product malfunctions, or if it is
dropped or damaged in any manner.
►The use of attachments not recommended by the manufacturer may be hazardous.
►Never operate if the housing is removed or damaged.
►A loose fit between the AC outlet (receptacle) and plug may cause overheating and a distortion of
the plug. Contact a qualified electrician to replace loose or worn outlet.
Prop. 65 Warning for California Residents: This product may
contain chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
WARNING
►Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
►This appliance is CFC and HFC free and contains small quantities of Isobutane (R600a), an
environmentally friendly coolant.
►You must ensure that the cooling circuit is undamaged when installing the appliance. However, if it
becomes damaged, avoid proximity to open fires and heat sources of all kinds. The room in which
the appliance is located should be ventilated properly and according to state and local codes.
►Never use an appliance with a damaged circuit.
►Ensure that the ventilation openings to and from a built-in appliance are never blocked or covered.
►No liability will be accepted for any damage caused by misuse of the appliance, or as a result of
repairs carried out by unqualified person. In this case neither the warranty nor any other liability
claims will apply.

7
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
For your safety, read all instructions carefully before operating the appliance.
Never operate any other electrical appliance inside this
appliance.
WARNING
►Never attempt to repair or replace any part of your appliance unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified technician.
►Replace all access panels before operating.
►Use two or more people to move and install the appliance. Failure to do so can result in back or
other injury.
►Never clean appliance parts with flammable liquids. These fumes can create a fire hazard or
explosion. Never store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance. The fumes can create a fire hazard or explosion.
►Never connect or disconnect the electric plug with wet hands.
►It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned o by a switch or pull chain.
To reduce the risk of fire, electric shock or personal injury, unplug
or disconnect the appliance from the power supply before
servicing.
WARNING

8PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Safety Information
For your safety, read all instructions carefully before operating the appliance.
Save These Instructions
If you are experiencing problems, check the Troubleshooting Guide at the back of this manual. It lists
causes of minor operating problems that you can correct yourself.
Disposal of Old Appliance
Dispose of your appliance packaging properly. Refrigeration equipment must be properly disposed
of in a way which protects the environment. This applies to your old appliance and to your new unit
once it has reached the end of its service life.
Please ensure that old, worn appliances are rendered unusable
before disposal by removing the plug, cutting the power cable,
and removing or destroying any snap fastenings or bolts. You will
thus prevent children from locking themselves in the appliance
during play (risk of suocation) or endangering their lives in any
other way.
WARNING
►The appliance must not be disposed with normal household waste collection.
►The coolant circuit, particularly the heat exchange at the back/bottom of the unit, must not be
damaged.
►The symbol on the product or its packaging indicates that this product is not to be handled
as normal household waste but is to be taken to a recycling collection point for electrical and
electronic goods. By correctly disposing of this product you are contributing to the protection of
the environment. Improper disposal endangers health and the environment. Further information
about the recycling of the product may be obtained from your town hall or local waste collection
department.

9
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
For your safety, read all instructions carefully before operating the appliance.
Before Using Your Appliance
►Remove all exterior and interior packing.
►Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system caused by handling
during transportation.
►Clean the interior surface with warm water using a soft cloth.
►The door on this appliance can be opened from either the left or the right side. The unit is delivered
with the door opening on the left side. Should you wish to open the door from the right, follow the
instructions, “Reversing the Door Swing of your Appliance,” listed below.
Installation of Your Appliance
Do not store or install the appliance outdoors.
WARNING
►The appliances are designed for either built-in, or free-standing installation.
►Place your appliance on a floor that is strong enough to support it when it is fully loaded. To level
your appliance, adjust the 4 legs until level.
►Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may aect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.
►Never place the unit in damp areas.
►Plug the appliance into an exclusive, easily accessible electrical socket.
►Any questions concerning power and/or electrical connection should be directed towards a
qualified electrician or an authorized products service center.
►The air vent at the front of the appliance must never be covered or blocked in any way.

10 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Safety Information
For your safety, read all instructions carefully before operating the appliance.
►The appliance must be installed to all electrical connections in accordance with state and local
codes.
►Use two or more people to move and install the wine cooler. Failure to do so can result in back or
other injury.
►The cooler may experience decreased cooling eciency if air flow is restricted due to a fully
loaded cabinet.
►Install the wine cooler in a well-ventilated area where the ambient temperature is above 50ºF and
below 90ºF.
Attention
►Never overload the cabinet.
►Never open the door unless necessary.
►Never cover shelves with aluminum foil or any other shelf material which may prevent air
circulation.
►Should the appliance be left empty for long periods, it is suggested that the appliance be
unplugged, and, after careful cleaning, leave the door ajar to allow air to circulate inside the
cabinet in order to avoid possible condensation, mold or odors from forming.

11
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
For your safety, read all instructions carefully before operating the appliance.
Electrical Connection
Check that the voltage marked on the product corresponds with your supply voltage.
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-pin plug which mates with standard three-pin wall outlets to minimize the
possibility of electrical shock.
Never under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard two-pin wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded three-pin wall outlet.
To prevent accidental injury, the cord should be secured behind the appliance and not left exposed or
dangling.
The appliance should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevent overloading wiring circuits that could cause a fire hazard from overheating. Never unplug
the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from the
receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Never use a cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
Never use your appliance with an extension cord unless this cord has been checked and tested by a
qualified technician or service person. The extension cord must be a UL/CUL Listed, 3-wire grounding
extension cord that has a grounding plug and outlet and that the electrical rating of the cord is 115
volts and at least 10 amperes.
Improper use of the grounded plug can result in the risk of
electrical shock. If the power cord is damaged, have it replaced
by a qualified electrician or an authorized service center.
WARNING

12 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Introduction
Thank you for purchasing your Zephyr wine cooler. Zephyr is dedicated to developing products that
will enhance your lifestyle with superior quality and distinctive features. Please visit
www.zephyronline.com for more information on your product and other Zephyr products.
This manual contains important information regarding the proper installation, use, and maintenance
of your wine cooler. Following this manual will ensure that your product will work at its peak
performance and eciency.
For Your Records
Please write down the model number and serial number below for future reference. Both numbers are
located on the rating label on the back of your unit and are needed to obtain warranty service. You
may also want to staple your receipt to this manual as it is the proof of your purchase and may also
be needed for service under warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer service:
If you received a damaged product, immediately contact the retailer or dealer that sold you the
product.
►Read and follow this instruction manual carefully to help you install, use and maintain your wine
cooler.
►Read the troubleshooting section of this manual as it will help you diagnose and solve common
issues.
►Visit us on the web at http://www.zephyronline.com to download product guides, additional
troubleshooting resources and up-to-date information.
►If you need warranty service, our friendly customer service representatives are available on our
website at http://zephyronline.com/contact or by telephone at 888-880-8368.

13
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
List of Materials
Reversible door hinge bracket
Upper door axis
Lower door axis
Self-tapping screws (ST4*30)
Black decorative nails
Screws (M4*10)
Door handle screws (pre-installed)
Flat washers
Screws (M4*12)
Quantity Part

14 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Product Specications
Product Summary
This appliance requires a standard 115/120 Volt AC~60Hz electrical ground outlet.
DESCRIPTION OF PRODUCT Presrv Dual Zone Panel Ready Wine Cooler
MODEL PRW24C02BPG
VOLTAGE/FREQUENCY AC 115/60Hz
AMPERAGE 1.5A
COLOR Black Cabinet with Black Panel Ready Door
STORAGE CAPACITY* (45) 750ml bottles
REFRIGERANT R600a
TEMPERATURE RANGE 40°F - 65°F
DIMENSIONS (HxWxD) 33-7/8’’ X 23-7/8’’ X 23-3/4’’
GROSS WEIGHT (lb) 139lb
OPTIONAL PRO HANDLE ACCESSORY PRHAN-C001
OPTIONAL CONTEMPORARY HANDLE
ACCESSORY, STAINLESS STEEL
PRHAN-C101
OPTIONAL CONTEMPORARY HANDLE
ACCESSORY, BRUSHED GOLD
PRHAN-C102
OPTIONAL CONTEMPORARY HANDLE
ACCESSORY, MATTE BLACK
PRHAN-C104
REPLACEMENT CARBON FILTER Z0F-C004
*Storage capacity is based on standard 12 oz. cans and 750 ml. Bordeaux-style wine bottles.
NOTE: Depth provided includes a 3/4” overlay panel.
Internal Storage
R
8 bottles x 2
(max. Ø 3- 3/8 ”)
45 bottle capacity
8 bottles x 2
(max. Ø 3- 3/8 ”)
6 bottles
(max. Ø 3- 3/8 ”)
7 bottles
(max. Ø 3- 1/2” )

15
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Product Specications
Parts Identication
Panel Ready Door
Carbon Filter
Leveling Legs
Front Vent
Roll-out Shelf
Control Panel
Internal Fan
Without Door
lower zone
upper zone
lower zone
upper zone
With Door
Sensor

16 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Product Specications
Dimensions
Top View
Side View
Max 135°
23-7/8”
33-7/8” - 34-7/8”
21-7/8”
23-3/4”
25-3/4”
24-3/4”
46-5/8”
23-5/8”
29-7/8”
5/8” - 3/4”
(depth of overlay panel)
NOTE: Cabinet depth provided includes a 3/4” overlay panel.
NOTE: A screw is present on the top hinge of the unit, adding an additional 1/8” to the height of the
cooler. If installing cooler flush with cabinet fronts, additional clearance may be needed.

17
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Product Specications
Dimensions
23-1/2”
29-3/4” - 29-13/16 ”
2-5/8” - 5”
2-5/8” - 5”
Overlay Panel
1-1/8”
1-1/2”
2-3/16”
4-1/4”
7-5/16”
Panel Thickness: 5/8” - 3/4”
3/16”
Panel-ready Door
15”
19-1/4”
(Optional Zephyr handle
screw holes)
15”
5-1/4”
NOTE: Compatible with framed overlay panels only.

18 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Installation Instructions
Installation Clearance Requirements
When installing the wine cooler under a counter, follow the recommended spacing dimensions shown.
►If the cooler is flush-mounted with the front of the cabinets, an additional 1/8” cabinet height
clearance will be required.
►For proper clearance of the electrical plug, allow at least 1” of clearance at the back as shown in
the diagram.
►An installation next to a wall will require a minimum 2-1/4” door clearance to accommodate the
Zephyr handle. If a custom handle is used, the dimensions will need to be measured accordingly
based on the handle dimensions.
►The cabinet should allow at least 24” for the width and 34” for the height to accommodate the
wine cooler.
►The power cable is located on the back right of the unit and has a length of 72” to accommodate
multiple outlet locations.
►Once you are ready to install the unit, you must adjust the feet to level the wine cooler.
►The installation should allow the unit to be pulled forward for servicing, if necessary.
2-1/4” Min.
24” Min.
34” Min.
1” Min.

19
PRW24C02BPG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Reversing the Door Swing of Your Appliance
Should you desire to reverse the opening direction of the door, please follow the instructions below.
Safely reversing the door swing of your appliance should require at least two people.
1. Open the door.
2. Temporarily remove the door gasket to see the 10 holes for the overlay panel. There are 2 holes on
the top and bottom sides of the door with either 3 or 5 holes on the left and right side depending
on where the handle is located. The handle side will have 5 holes.
3. Open the hardware package containing 10 self-tapping screws (ST4*30 size) for the overlay panel.
4. Clamp the overlay panel with the door firmly with bar clamps and screw the self-tapping screws
into the overlay panel. Perform this step per screw until the overlay panel is completely secured.
5. Reattach the door gasket and close the door.
NOTE: If handles will be installed, thread 2 pre-installed screws onto the overlay panel and refer to
Installing the Handle instructions. If they will not be installed, remove the screws from the door.

20 PRW24C02BPG Use, Care, and Installation Guide
WINE COOLER
DUAL ZONE
PRESRV™
Installation Instructions
Handle
Door Frame
Gasket
Flat Washer
Locked Washer
Screw
22-1/4”
23-5/8”
2”
2”
Zephyr Presrv Contemporary Handles
Zephyr Presrv Pro Handle
Part #: PRHAN-C101
Part #: PRHAN-C102
Part #: PRHAN-C104
Color: Stainless Steel
Color: Brushed Gold
Color: Matte Black
Part #: PRHAN-C001 Color: Stainless Steel
Installing the Handle
If an optional contemporary or pro handle is desired, refer below for the handle dimensions and part
number.
1. Confirm if the overlay panel has already been installed onto the unit. If not, refer to Overlay Panel
Installation to mount the overlay panel onto the unit.
2. Push aside the door gasket. Under the gasket you will see two designated holes for handle
installation. Mark handle hole locations on the overlay panel.
3. Remove overlay panel from door. Using 3/16” drill bit, create holes for handle screws.
4. Re-install overlay panel on the door.
5. Install the handle tightly as shown with two 1-1/2” machine screws.
NOTE: If using a custom handle, install the handle in the position of your choosing with counter sunk
screw holes prior to installing the overlay panel to door.
