Zepter NEB-01-C User manual

Instruction for Use
Portable Mesh
Nebulizer
NEB-01-C

1. Safety Notes
2. Disposal
3. Item Description
3.1 Content of Packaging
3.2 Device Description
4. Instruction for Use
5. Cleaning and Disinfection Method
6. Technical Data
7. Trouble Shooting Guideline
8. Declaration of Conformity
9. Warranty
4.1 Before First Use
4.2 Installation
4.3 Charging
4.4 Instruction for Use
4.5 Nebulization
3-4
4-5
5
5
5
6
6
6
6-7
7-8
8-9
10-11
11
12
13
13-14
Contents

1. Safety Notes
Before using the appliance for the first time, read the Instructions for Use carefully and ensure you
comply with the safety instructions!
• The appliance must only be used as described in these instructions. The manufacturer is not liable
for damages arising from any use contrary to the intended purpose.
• Keep these instructions for future reference.
• If you pass the appliance on to someone else, please include these instructions.
Do not use health products or medicines containing essential oils for nebulization.
For the type, dose, and regimen of the medication, be sure to follow the instructions of a
doctor.
Children may not play with the appliance.
This appliance may be used by persons with reduced physical, sensory or mental
capabilities, or by persons with little or no knowledge of the appliance, as long as they are
under proper supervision and have received instructions as to the safe use of the appliance,
and as long as they understand the implicit risks.
This unit is only used for specified purposes, only for nebulization. Do not use the device for
any other purpose.
Clean and disinfect the medication cup and accessories before using or if you will not use
the unit foralong time.
Stop using the device if the components are damaged or fall into water accidentally.
Intended User
The device is a mesh nebulizer designed to aerosolize liquid for inhalation therapy in
professional healthcare and in home healthcare environment.
Suitable for pediatric and adult patient. Infants, children and compromised individuals
should use it under adult supervision.

Do not expose the nebulizer and accessories to corrosive liquids and gases.
Do not wrap the power cord around the unit.
Do not use nebulizer nearaheating device or open flame.
Do not useamicrowave oven, fan or hair dryer to dry or disinfect the nebulizer or
accessories.
Do not immerse the main unit in water or wash under running water.
Do not use the device in shower!
Do not spill liquid on the device to avoid leakage, the possibility of electric shock or
malfunction.
Do not touch the center of spray mesh by hand or other sharp objects. It may cause
damage, so you will not be able to use it.
The nebulizer has no moisture and dust function, and the product should not be stored in a
wet or dusty environment.
Volatile oils are not allowed, as they may cause damage to the module.
Oily medications are not allowed.
2. Disposal
At the end of the nebulizer lifetime, we recommend not to dispose of the appliance as ordinary
waste, but to leave it with personnel qualified to collect such material. In this way, it will be
properly disposed of and recycled. This is a valuable aid for safeguarding our environment!
4

This product contains batteries. The symbol indicates that the battery should not be disposed of with
normal household waste. Instead, they should be handed over to appropriate collection point to be
recycled.
Warning: Do not dump batteries into fire. Never incinerate or dispose of batteries in fire as they
may explode. This is very dangerous and prohibited.
For your own safety, don’t remove the battery from the product and please contact only authorized
Zepter Service Centre.
5
3. Item Description
3.1 Content of Packaging
3.2 Device description
a) Portable mesh nebulizer
b) Medication cup
c) Spray nozzle
d) USB micro cable
Cup components
Power switch
Schematic diagram of host structure
1. Lid
2. Medication cup
3. Spray nozzle
4. Power switch
5. Increase nebulization rate
6. Decrease nebulization rate
7. Main unit
8. "Press" button
9. USB charging port
10. Mouthpiece
11. Mask

6
4.1 Before First Use
4.2 Installation
4.3 Charging
1. When the low battery is detected, the blue indicator flashes for5times and turns o�.
2. Plug the USB cable to mini connector, connect the other terminal to power adapter and charge
the device. Use the power adapter with rated output DC 5.0 V, 1A.
3. While the device is charging, the green indicator flashes continually.
4. The LED indicator is lit steadily when the battery is fully charged.
5. The appliance can be used during charging process.
1. Remove all packaging from the main device and accessories.
2. Verify if all content is intact.
3. Charge the appliance minimum for 30 min before first use.
Note: Clean, disinfect and dry all parts before installation
4. Instruction for Use

7
Note! Before charging, make sure it is
normally charged through the connected
socket.
Note! This device is independent charging, do
not use any other electronic equipment for
charging.
4.4 Instruction for Use
Description of indicators
Note: There is enough liquid, but the orange light flashes ten times. While the orange light
is flashing, press switch key once to continue work.
Long press for3seconds to switch the atomization mode
Blue light keeps on
(uniform nebulization mode)
Blue light flashes
(microwave mode)
Blue light flashes 3 times
Green light flashes
Green light keeps on
Blue light flashes 5 times
Orange light flashes 10 times
Blue light flashes 10 times
Battery low, shut down
Without medication and shut down
Charging
10 minutes set time
Fully charged
Working

8
1. Clean and disinfect the component and spray nozzle medication cup before each use.
2. Inject the liquid: Open the cap by turning it counterclockwise, inject the solution and return the cap
by turning it clockwise.
Note: Do not exceed the maximum capacity of 10 ml of the liquid. After injecting the liquid, do not
open the liquid cup lid, so as not to spill liquid.
Note! Add the liquid before turning
on the device.
The nozzle is a disposable accessory, max. reusable time is up to3times. It is only for single person
use and can’t be shared, to avoid cross-infection.
4.5 Nebulization
1) Connect mask or mouthpiece, click " " to switch power on, start nebulization.
2) It starts withamedium spray rate, and spray rate can be adjusted by pressing "+"&"-" as needed.
3) This device also has a microwave mode in which the spray rate is changed automatically with the
breathing. After the device is started, long press " " button for 3s (when the blue light flashes 3
times) to switch to the microwave mode.
4) After switching to the surge mode, press and hold the " " button for 3s, or press "+" or "-" to switch
back to uniform mode.
5) Boot before atomization, shake slightly for full contact of the solution with atomizer. Use the following
three ways of inhalation according to individual needs.

a. Direct inhalation b. By mask c. By mouthpiece
9
6) Slowly takeadeep breath and then breathe in the medication.
7) The nebulizer can set the working time to 10 minutes, and it will shut down automatically after 10
minutes. If you need to continue to use, press the power switch " ". Please make sure there is
enough liquid in the medication cup.
8) After nebulization, press the power switch " " to turn o�and stop the nebulization. Pour out the
traces of residual liquid in the medication cup and do not reuse.
9) Use clean water to clean the medication cup, spray nozzle, lid, threaded assemblies and
accessories, and then follow the recommended method of disinfection.
1) Hold nebulizer to keep the liquid and nebulization mesh disc in full contact. Slight swing does not
a�ect the use, but do not lean back.
2) Liquid can be coagulated around the spray connector and mesh disc, which will a�ect the
nebulization. You should stop nebulization, remove the nozzle and other accessories. Then use a
clean medical gauze to wipe the residue. Do not touch the mesh disc center spray area to prevent
damage to the mesh disc.
Note:

5. Cleaning and Disinfection Method
After each use, it is necessary to clean and disinfect the cup components (including spray nozzle,
medication cover), mask and mouthpiece. The specific methods of cleaning and disinfection are
recommended as follows:
1. Cleaning
Please turn o�the power when cleaning the device. Do not connect the device with power supply.
1) Remove the components from the main unit: the medication cup components (including the spray
nozzle, medication cover), the inhalation mask or the mouthpiece, and soak them in clean warm
water (which is no more than 40 degrees centigrade) for about 5 minutes.
2) After cleaning, wipe all the components with clean and sterile medical gauze, and let them dry
su�ciently.
3) Wipe the outer shell of main unit. If there is medication residue at the electrode contact, please
clean it with wet sterile medical gauze. After cleaning, keep the main unit dry.
4) Store all the parts inadry and clean place to avoid contamination.
10
2. Disinfection
After each use, it is necessary to disinfect the components of the cup, including spray nozzle,
medication cover, mask, mouthpiece, etc., as follows:
1)Disinfection with hydrogen peroxide
Disinfect all the components by placing them in 2% hydrogen peroxide for 10 minutes, including
medication cup components (such as spray nozzle and medication cover), mask and mouthpiece,
or wipe and disinfect the medication cup components (including spray nozzle, medication cover),
mask and mouthpiece. After disinfection, rinse all the parts with distilled water, then wipe with clean
and sterile medical gauze or air-dry naturally to keep all parts dry.
Notes: The main unit cannot be washed with water to prevent water from entering the main unit.
Use clean sterile gauze to wipe the moisture on the main unit and components and keep them
dry to ensure safe use next time.

A. Please study the user guidance of hydrogen peroxide and do not immerse in solution foralong
time.
B. Do not use strong oxidizing agents such as perchlorate or disinfectants that are corrosive to metals,
polymer compounds or polymers.
2) Ethanol disinfection
Place the liquid cup components (including spray nozzle, medication cover), mask and mouthpiece
in 75% medical ethanol for 5~10 minutes for disinfection, or wipe and disinfect the medication cup
component (including spray nozzle, medication cover), mask and mouthpiece. After disinfection,
rinse all the parts with distilled water, then wipe with clean and sterile medical gauze or air-dry
naturally to keep all parts dry.
Notes: Disinfectants remaining on components need to be wiped with sterile medical gauze to
ensure safe use next time. Do not touch the central area of the mesh diaphragm when washing
or cleaning the spray nozzle, so as to avoid damaging the mesh diaphragm.
5. Technical Data
Product name
Type of battery
Product Item code
Charging time
Usage time
Charger/Adaptor input
Charger/Adaptor output
Country of origin
Portable Mesh Nebulizer
NEB-01-C
Li-ion battery, DC2.4V, 2x500mAh, 1.2 Wh
Approx. 2 hrs
60 minutes continual use after full charge
100-240V~, 50/60Hz, 0.5 A
5V 1.5 A
China
11

7. Trouble Shooting Guideline
12
Does not work when
turned on
Low nebulization
Which medication is more
suitable for nebulization
Medication residue
Special care for babies
and children
Each user needs individual
consumable item
1) Check whether the nebulizer is charged. If the blue and
green indicators are always on, recharge the device.
2) Check if the medication cup has been fully filled.
1) Check if the medication cup has been filled with the right medication,
which should be water soluble and non-corrosive.
2) Check whether there is enough liquid.
3) Tilt the unit so that the medication is in contact with the spray mesh.
4) The spray mesh may be blocked, you can drop2or3drops of white
vinegar into the medication cup with 3-6 ml of water. Clean the
medication cup to disinfect for next nebulization.
1) Please refer to and follow doctor's advice.
2) Only doctors can advise the users which medication should be used
for treatment.
3) Don't useamedication that is too sticky.
1) It is normal, but if there is some strange noise or the unit shuts o�due
to insu�cient medication, stop the nebulization.
1) Each user should use individual consumable items, including mask,
mouthpiece.
1) Please use the babies mask to cover mouth and nose for better
e�ect.
2) Please use kids mask to cover mouth and nose for better e�ect.
Note: Children and babies should be helped and watched by an
adult when using the device. Keep it away from children when not
is use.

Portable mesh nebulizer complies with European directives:
a) Directive 2006/95/EC of the European Parliament and of the Council relating to electrical equipment
designed for use within certain voltage limits
b) Directive 2014/30/EU of the European Parliament and of the Council on the harmonization of the
laws of the Member States relating to electromagnetic compatibility (recast)
c) Directive 2011/65/EU of the European Parliament and of the Council on the restriction of the use of
certain hazardous substances in electrical and electronic equipment
13
8. Declaration of Conformity
9. Warranty
This device can only be assigned to the functions it has been designed for, i.e. nebulization. The
manufacturer cannot be held responsible for any damage deriving from improper, incorrect or
unreasonable use.
All our appliances have undergone strict inspection test and are guaranteed against manufacturing
defects. The guarantee starts from the date of purchase. The date of purchase is the date shown on the
invoice issued by the dealer upon the delivery of the appliance. Evidence of original purchase is
required for warranty services, so it is important to keep your sales receipt.
The warranty period is applicable according to local country law and regulation in force.
The manufacturer undertakes to repair or replace cost-free within the warranty period those parts that
prove to have manufacturing defects. Those defects that are not clearly attributable to either material
or the manufacturing will be examined at one of ZEPTER Service Centres or at our headquarters and
charged according to the outcome.

The warranty is only valid if:
• The device shows material or manufacturing defects
• No signs of breaking by the customer or the presence of no original pieces fit by other people had
been found.
The warranty does not include:
• the parts which can normally wear out
• the damages caused by transport, inadequate use, negligence and/or incorrect use
• any damages due to nebulizer being used for unintended purposes
• any damages due to non-observance of safety regulations or the instructions in the User Manual
• any damages to the product resulting from repairs and/or maintenance done by unauthorized repair
centre
This guarantee does not a�ect the consumer`s statutory rights under applicable national legislation in
force, nor the customer’s rights against the retailer arising from the sales/purchase agreement.
In the absence of applicable national legislation, this guarantee will be consumer's sole and exclusive
legal remedy, and the manufacturer shall not be liable for any incidental or consequential damages for
breach of any express of implied guarantee of this product. The liability of manufacturer is limited to and
shall not exceed the purchase price of the product actually paid by the consumer.
Attention! If, after the purchase of the product, its label with serial number has been removed or is
not recognizable, the manufacturer reserves the right to refuse the warranty service.
If you have any comments or questions concerning the functioning of the device or warranty, please
contact your ZEPTER Sales Representative.
14
