Mira MB-90 User manual

MB-90
Powered Air-Purifying
Respirator (PAPR)
RD011721

DESCRIPTION
Warning
Warning
RESPIRATORS CAN BE USED IN AN
EMERGENCY; HOWEVER, TRAINING
IS VERY STRONGLY RECOMMENDED
BY THE MANUFACTURER. FOLLOW
THE INSTRUCTIONS HEREIN
CAREFULLY. THIS POWERED
AIR-PURIFYING DEVICE IS ONLY FOR
USE IN SPECIFIC ATMOSPHERES
UNDER CERTAIN CONDITIONS. USE
OF THIS RESPIRATOR WITHOUT
PROPER KNOWLEDGE AND
TRAINING CAN RESULT IN SERIOUS
INJURY OR DEATH.
IMPROPER USE OF THIS RESPIRATOR MAY RESULT IN PERSONAL INJURY OR DEATH. IMPROPER USE INCLUDES, BUT IS NOT LIMITED TO, USE IN
ATMOSPHERES CONTAINING UNKNOWN CONTAMINANTS AND/OR UNKNOWN CONCENTRATIONS OF CONTAMINANTS, USE WITHOUT ADEQUATE
TRAINING, DISREGARD OF THE WARNINGS AND INSTRUCTIONS CONTAINED HEREIN OR FAILURE TO INSPECT AND MAINTAIN THIS RESPIRATOR. THIS
RESPIRATOR IS NOT INTENDED FOR USE IN ATMOSPHERES WHICH ARE, OR MAY BECOME, IMMEDIATELY DANGEROUS TO LIFE OR HEALTH, OR IN
ATMOSPHERES WHERE THE IDENTITY AND/OR CONCENTRATION OF THE CONTAMINANT IS UNKNOWN.
THIS RESPIRATOR DOES NOT SUPPLY OXYGEN AND MUST NOT BE USED IN OXYGEN-DEFICIENT ATMOSPHERES CONTAINING LESS THAN 19.5%
OXYGEN.
THIS RESPIRATOR IS INTENDED TO BE USED ONLY IN CONJUNCTION WITH AN ORGANIZED RESPIRATORY PROTECTION PROGRAM OR LARGER
PERSONAL PROTECTIVE EQUIPMENT (PPE) SYSTEM.
Warning
THE FOLLOWING INFORMATION IS MEANT TO SUPPLEMENT, NOT REPLACE, EXISTING TRAINING AND PROTOCOL REGARDING THE USE OF PPE AND
GAS MASKS/FULL-FACE RESPIRATORS. PLEASE CONSULT LEADERSHIP OR RELEVANT AUTHORITIES REGARDING THE DEPLOYMENT OF THIS
EQUIPMENT. SEE WARNING ON THE COVER OF THIS MANUAL.
Warning
DO NOT OPERATE THIS EQUIPMENT WHILE UNDER THE INFLUENCE OF DRUGS, ALCOHOL, OR ANY OTHER MEDICATIONS OR SUBSTANCES WHICH
MAY AFFECT VISION, DEXTERITY OR JUDGMENT. USERS OF THIS EQUIPMENT MUST BE IN GOOD PHYSICAL AND MENTAL HEALTH IN ORDER TO
OPERATE IT SAFELY. DO NOT USE THIS EQUIPMENT WHEN FATIGUE PREVENTS SAFE OPERATION. STAY ALERT WHEN OPERATING THIS EQUIPMENT.
INATTENTION OR CARELESSNESS WHILE OPERATING THIS EQUIPMENT COULD RESULT IN SERIOUS INJURY OR DEATH.
The MIRA Safety MB-90 Powered Air-Purifying Respirator is a blower-assisted device
commonly referred to as a PAPR. Training is required before use.
The MIRA Safety MB-90 has an enclosed and sealed design that contains NO
user-replaceable parts. Opening the PAPR enclosure could compromise its functionality
and immediately voids the warranty. If you experience functionality issues, please
contact MIRA Safety Customer Service.
The MIRA Safety MB-90 is designed to be used with a full-face respirator/gas mask and
40 mm NATO standard gas mask lters, tted head harness, a breathing tube to
connect the PAPR to the face mask, and eight (8) AA batteries to ensure functionality.
Each of these elements MUST be functioning properly for your PAPR to work as
designed.
Page 1

METHOD OF OPERATION Warning
RESPIRATORS SHALL NOT BE WORN
WHEN CONDITIONS PREVENT A
GOOD SEAL. SUCH CONDITIONS
INCLUDE, BUT ARE NOT LIMITED TO,
THE PRESENCE OF BEARDS,
SIDEBURNS, OR FACIAL HAIR, OR
CORRECTIVE LENSES WITH ARMS
THAT EXTEND OVER THE EARS.
Warning
THE BLOWER ASSEMBLY IS A
BATTERY-OPERATED ELECTRICAL
DEVICE THAT HAS NOT BEEN
EVALUATED AS AN IGNITION
SOURCE. THIS DEVICE IS NOT TO BE
USED IN A POTENTIALLY EXPLOSIVE
ATMOSPHERE. USE IN A
FLAMMABLE OR EXPLOSIVE
ATMOSPHERE COULD RESULT IN
IGNITION AND CAUSE SERIOUS
INJURY OR DEATH.
For this equipment to function as intended, the user must be wearing a t-tested respirator and facepiece that provides a
complete seal while maintaining visibility for the intended activities. Follow the manufacturer’s procedure for donning and
dong your mask.
MIRA Safety gas mask instruction manuals are included with purchase or are available by contacting Customer Service.
The blower assembly contains an electric motor driving a mechanical air blower. The battery pack compartment is in the
lower part of the blower assembly with an attached cap. The battery pack uses standard AA batteries due to their ready
availability and low cost.
The ON/OFF power switch is on the top front of the blower assembly. On the front, there are two (2) threaded inlets to attach
40 mm lters. The MIRA Safety MB-90 PAPR can use up to two (2) lters. New lters must be installed prior to use.
The waist belt supports the blower assembly at the waist or on a pack, and it is fully adjustable.
The MIRA Safety MB-90 is a Powered Air-Purifying Respirator (PAPR). The user of this
respirator breathes ambient air that has been passed through the attached lter
elements. The lter elements may include a mechanical lter to trap airborne
particulates or a sorbent bed of impregnated activated carbon to trap and/or neutralize
various gases and vapors. Filtration elements must be selected specically to suit the
hazardous atmosphere.
This equipment must be used with a functioning lter, gas mask/full-face respirator,
eight (8) AA batteries, and the included breathing tube. Once installed and turned on,
the blower will draw ambient air through the lter element and create positive pressure
inside the facepiece, aording protection from contaminants in the atmosphere while
enhancing breathing ease.
To maintain this level of protection:
The user must be wearing a properly tted and sealed gas mask with valve
covers and breathing tube properly tested and installed.
1
The blower must ALWAYS be turned on when the user is in a contaminated atmosphere.
2
Page 2

USE SPECIFICATIONS AND
LIMITATIONS
The MIRA Safety MB-90 PAPR is intended for use as respiratory protection from airborne contaminants when used in
conjunction with a lter and gas mask/full-face respirator.
1
The personnel using this respirator must have read this manual completely, and, ideally, received training from their
employer or team leader prior to use. Each user must also have received training in the use of their existing respirator
equipment including, but not limited to, pre-use check, donning, seal check, use, dong and after-use care of the
respirator.
2
To use this equipment, you must follow the instructions regarding the use of the lter and gas mask/full-face
respirator you attach to it. Most (but not all) gas masks/full-face respirators are incompatible with facial hair. Beards,
sideburns, and other facial hair must be shaved clean so the mask can securely seal around its edges. Likewise, most
gas masks are not compatible with corrective lenses that could interfere with the seal. Consult your gas
mask/full-face respirator instruction manual for details.
3
The individual using the respirator must ensure it is properly inspected before use, properly decontaminated after
use (if necessary), properly cleaned and maintained after use, and properly stored between uses.
4
The MIRA Safety MB-90 PAPR (when used with compatible gas mask/full-face respirator and lter) protects only the
face and respiratory tract from airborne contaminants. Additional protective clothing, equipment, and headwear will
often be required, though it must not interfere with the operation of the respirator.
5
Use in explosive atmospheres is NOT PERMITTED. The MIRA Safety MB-90 PAPR contains a battery and must not be
taken into or used in atmospheres containing ammable or explosive gases, vapors, or dusts when the concentration
of such contaminants constitutes a re or explosion hazard.
6
The MIRA Safety MB-90 PAPR is NOT A TOY and should only be used according to the instructions herein. Do NOT
use the MB-90 PAPR for reghting, in oxygen-decient atmospheres, or for protection against contaminants that
the lter elements do not protect against.
7
The MIRA Safety MB-90 PAPR must NOT be used with expired or incompatible lter elements and/or gas masks.
8
Page 3

Warning
IF THE POSITIVE AIR PRESSURE
FROM THE BLOWER CEASES FOR
ANY REASON, LEAVE THE
CONTAMINATED AREA AS SOON AS
IT IS SAFE TO DO SO. A LACK OF
POSITIVE AIR PRESSURE FROM THE
BLOWER MAY REDUCE THE
PROTECTION PROVIDED BY THE
RESPIRATOR, WHICH COULD
RESULT IN SERIOUS INJURY OR
DEATH.
Warning
IF YOU DETECT ANY CONTAMINANT
ODOR OR TASTE, OR EXPERIENCE
IRRITATION OF THE EYES, NOSE OR
THROAT, THERE MAY BE EXPOSURE
TO THE CONTAMINANT. RETURN TO
FRESH AIR IMMEDIATELY.
DETERMINE THE REASON FOR THE
EXPOSURE AND TAKE APPROPRIATE
CORRECTIVE ACTION BEFORE
CONTINUING USE OF THE
RESPIRATOR. FAILURE TO TAKE THE
PROPER CORRECTIVE ACTION MAY
RESULT IN EXPOSURE TO THE
CONTAMINANT, WHICH COULD
CAUSE SERIOUS INJURY OR DEATH.
Warning
IF THE BATTERY COMPARTMENT
BECOMES HOT, IMMEDIATELY
LEAVE THE AREA REQUIRING
RESPIRATORY PROTECTION. TURN
OFF THE EQUIPMENT AND ALLOW
IT TO COOL AT LEAST 60 MINUTES
BEFORE REMOVING THE BATTERY
PACK. DO NOT HANDLE BATTERIES
DIRECTLY IF YOU SMELL AN ACRID
ODOR.
The MIRA Safety MB-90 PAPR is designed to be used with a wide variety of CBRN gas
masks/full-face respirators and compatible NATO standard 40 mm lter cartridges. The
essential operation of this PAPR remains the same, provided you adhere to all
guidelines and instructions for your mask and lter cartridge.
To use your MIRA Safety MB-90 PAPR
USING YOUR MB90- PAPR
Ensure the power switch is in the OFF position and that the batteries are fully
charged. Turn the power switch ON briey to ensure the unit is functioning.
Turn the power switch OFF again.
1
The blower assembly and breathing tube must be arranged so that
There is enough slack in the
breathing tube for the user
to turn their head through
the full range of motion
without the breathing tube
pulling on the facepiece, the
breathing tube being
pinched closed, or the
breathing tube interfering
with other protective
clothing or equipment.
7
Inspect the PAPR and breathing tube as outlined in the PAPR MAINTENANCE
AND INSPECTION section of this manual.
2
Attach two (2) lter elements to the PAPR housing by threading them onto the
inlet ports until hand tight. DO NOT OVER TIGHTEN FILTER ELEMENTS.
3
Insert eight (8) fully charged AA batteries into the battery holder, ensuring
correct polarity. Then insert the battery holder into the battery compartment,
inspecting the battery compartment for any signs of corrosion before
installing.
4
Don the waist belt with blower assembly so the breathing tube outlet is at the
top of the unit. Fasten the buckle and adjust the waist belt.
5
Position the blower assembly at the back of either the right or left hip. When
properly donned, the power switch should be accessible.
6
a
The PAPR blower assembly
and breathing tube must be
positioned so that excessive
slack in the breathing tube
is not likely to catch on
objects.
b
If additional protective
clothing is used, it must be
arranged so that it does not
interfere with the t of the
gas mask or restrict airow
to the lter elements.
c
Page 4

Attach breathing tube and valve covers to the gas mask, ensuring the mask is eectively sealed and functioning
before attaching the breathing tube to the PAPR unit.
8
If, during use, the airow from the blower assembly should noticeably decrease or stop completely, or if inhalation
should become dicult, immediately leave the contaminated area. Decontaminate and, if necessary, check the
PAPR.
14
After four (4) hours of continuous use, the user must leave the contaminated area, decontaminate if required, and
inspect for damage.
13
If the airborne contaminant is detected by odor, taste, eye irritation, or if any discomfort is felt during use,
immediately leave the contaminated area. Decontaminate and, if necessary, check the PAPR.
15
If the battery compartment should become hot to touch, immediately turn the Power Switch to OFF. Do not
remove the facepiece, but continue to breathe through the respirator and immediately leave the contaminated
area. Decontaminate and, if necessary, check the PAPR.
16
Manually inspect the seals and junctions of your gas mask, breathing tube, and PAPR lter connectors to ensure
none are drawing air. This could indicate a faulty seal somewhere in the system.
Do not permit the batteries to completely discharge during use. Always monitor battery performance and change the batteries immediately after
use or if they expire.
10
Turn the power switch to the ON position. You should immediately notice improved airow within your gas mask.
9
Use of the PAPR must be in strict accordance with the guidelines and warnings contained herein. The maximum
safe duration of use primarily depends on
12
Note
Perform a NEGATIVE LEAK PRESSURE TEST before using in the eld.
11
The amount and
type(s) of
contaminant(s) in
the air and the
capacity of the
lter elements to
absorb and
neutralize the
contaminant(s).
a
The amount of
airborne particles
(dust) in the
atmosphere.
b
The charge in the
batteries.
c
The physiological
limits of the user.
d
Page 5

Warning
IF THE POSITIVE AIR PRESSURE
FROM THE BLOWER CEASES FOR
ANY REASON, LEAVE THE
CONTAMINATED AREA AS SOON AS
IT IS SAFE TO DO SO. LACK OF
POSITIVE AIR PRESSURE FROM THE
BLOWER MAY REDUCE THE
RESPIRATOR PROTECTION WHICH
COULD RESULT IN SERIOUS INJURY
OR DEATH.
Temporarily positioning the PAPR blower assembly at the front of the waist will facilitate performing a negative leak
pressure test.
If, for any reason, the blower assembly stops operating, becomes very noisy, or the
battery compartment becomes hot to the touch, immediately leave the area requiring
respiratory protection, turn the power switch to the OFF position and determine the
cause of the problem.
Do not submerge the blower assembly in water during use as water will be drawn into the lter elements. If accidental
immersion occurs during use, leave the area requiring respiratory protection, turn the unit o, remove the respirator from
service, and tag it for inspection and repair. If it becomes impossible to inhale through the lter elements after accidental
immersion, proceed as directed above.
If, for any reason, it becomes impossible to inhale through the respirator during use,
the user may have to disconnect the facepiece from the breathing tube or remove
the facepiece. THIS WILL TERMINATE RESPIRATORY PROTECTION AND THE USER
WILL BE BREATHING THE ATMOSPHERE THE RESPIRATOR WAS INTENDED TO
PROTECT AGAINST.
PERFORMING A NEGATIVE LEAK
PRESSURE TEST
EMERGENCY USE
With the unit donned and turned o, close the inlet side of both lter elements by covering them with your palms
or other airtight objects, and press rmly to seal the inlets.
1
Inhale slowly and hold your breath momentarily. The mask should be drawn slightly in toward your face and stay
there, indicating there are no obvious leaks in the system.
2
If air leakage is detected during this procedure, remove and replace the facepiece following the gas mask/full-face
respirator donning procedure before repeating the test. If leakage persists, DO NOT USE THE EQUIPMENT.
3
In addition to poor facepiece t, leakage can result from loose breathing tube connections, improperly tightened lter elements, damaged or
missing gaskets at the breathing tube and/or lter element connections, a damaged or missing exhalation valve, or other damaged respirator
components. DO NOT USE A DAMAGED OR LEAKING RESPIRATOR. Make repairs and recheck respirator or remove from service and tag it for
repairs by authorized personnel.
To remove the breathing tube from the facepiece (if and when it is safe to do so), unthread the breathing tube from the facepiece.
Note
Page 6

Warning
IF YOU DETECT ANY CONTAMINANT ODOR OR TASTE, OR
IRRITATION OF EYES, NOSE OR THROAT THAT SUGGESTS
EXPOSURE TO THE CONTAMINANT, RETURN TO FRESH AIR
IMMEDIATELY. DETERMINE THE REASON FOR THE EXPOSURE
AND TAKE APPROPRIATE CORRECTIVE ACTION BEFORE
CONTINUING USE OF THE RESPIRATOR. FAILURE TO TAKE THE
PROPER CORRECTIVE ACTION MAY RESULT IN EXPOSURE TO
THE CONTAMINANT WHICH COULD CAUSE SERIOUS INJURY
OR DEATH.
Warning
IF BATTERY COMPARTMENT BECOMES HOT, IMMEDIATELY
LEAVE THE AREA REQUIRING RESPIRATORY PROTECTION,
TURN OFF THE EQUIPMENT, AND ALLOW THE BATTERIES TO
COOL AT LEAST 60 MINUTES BEFORE REMOVING IT. DO NOT
HANDLE BATTERY DIRECTLY IF YOU SMELL AN ACRID ODOR.
Warning
DO NOT REMOVE THE FACEPIECE,
BREATHING TUBE, OR ADAPTER
FROM THE FACEPIECE WHILE IN A
HAZARDOUS ATMOSPHERE EXCEPT
IN AN EMERGENCY. REMOVING ANY
OF THESE ITEMS WILL TERMINATE
RESPIRATORY PROTECTION AND
EXPOSE THE USER TO THE
HAZARDOUS ATMOSPHERE, WHICH
MAY RESULT IN SERIOUS INJURY OR
DEATH.
Termination of use occurs when the user leaves the contaminated area and does not
intend to reenter. Removal must be done in a fresh air environment after thorough
decontamination. To do the facepiece
The MIRA Safety MB-90 PAPR must be cleaned, inspected, and prepared for its next use. Refer to the CLEANING AND
STORAGE section of this manual.
TERMINATION OF USE
Exit the area requiring respiratory protection and, if necessary, proceed to
decontamination as directed by your respiratory protection program.
1
Remove the blower assembly by disengaging the belt and removing the blower assembly from the belt.
3
Open the battery compartment by unthreading (counterclockwise) its cover and remove the batteries.
5
Unthread and remove the lter elements. Replace the cap and plug on each lter element. Do not dispose of lter
elements as ordinary waste. See DISPOSAL OF USED FILTER ELEMENTS in this manual.
4
When it is safe to remove the respirator and handle it:
2
Turn the power switch to the OFF position.
a
Remove the respirator facepiece as directed
by its instruction manual. Do not remove
the facepiece by pulling on the breathing
tube assembly.
b
Page 7

Warning
ALL VALVES, COVERS, AND FILTER
ELEMENTS MUST BE CLEAN AND
MUST SEAL PROPERLY BEFORE USE.
FAILURE TO VERIFY THAT EACH
ELEMENT SEALS PROPERLY COULD
RESULT IN THE UNIT FAILING TO
FUNCTION OR EXPOSE THE USER
TO THE CONTAMINATED
ATMOSPHERE, WHICH MAY CAUSE
SERIOUS INJURY OR DEATH.
Warning
FOLLOW THE REGULAR
INSPECTION PROCEDURE EXACTLY.
IF ANY DAMAGE OR OPERATIONAL
MALFUNCTION IS NOTED, DO NOT
USE THE RESPIRATOR. REMOVE THE
RESPIRATOR FROM SERVICE, AND
TAG IT FOR REPAIR BY AUTHORIZED
PERSONNEL. FAILURE TO PROPERLY
IDENTIFY DAMAGE OR
MALFUNCTIONS MAY RESULT IN
SERIOUS INJURY OR DEATH.
Warning
DO NOT STORE THE BLOWER
ASSEMBLY WITH A BATTERY
INSTALLED. IF THE BATTERY
SHORTS OR OVERHEATS IN
STORAGE, IT MAY CAUSE A FIRE,
VENTING GAS OR FUMES, OR THE
LEAKAGE OF CORROSIVE
ELECTROLYTES FROM THE BATTERY,
WHICH MAY CAUSE SERIOUS
INJURY OR DEATH.
The MIRA Safety MB-90 PAPR is designed to work as a single enclosed unit. There are
NO user-replaceable parts. Opening the housing or replacing any parts (other than the
breathing tube and external lter cartridges) voids the warranty. For a replacement
breathing tube or lter cartridges, please contact MIRA Safety Customer Service
Your MIRA Safety MB-90 PAPR comes with an enclosed breathing tube. If the tube is
damaged or dysfunctional in any way, contact MIRA Safety for a replacement. Inspect
the breathing tube as follows:
PAPR MAINTENANCE AND
INSPECTION
BREATHING TUBE INSPECTION
Examine the outer surface for cracks, tears, or leaks.
1
If anything is malfunctioning or out of place, replace prior to use
3
Inspect the gasket inside the threaded connector to ensure it is in place and
intact.
2
Do NOT attempt to open the PAPR housing or lter elements. Handle all batteries with
care. Inspect the blower unit as follows:
BLOWER ASSEMBLY INSPECTION
Examine the outer surface of the housing for damage, cracks, or missing
components. If any damage is found, do not use the PAPR.
1
Inspect the gaskets, breathing tube, and lter elements to ensure they are all operational.
3
Install a set of AA test batteries as follows:
2
Ensure the power
switch is in the
OFF position.
a
Remove the battery
cover.
b
Inspect the internal
battery contacts for
corrosion, damage
or accumulated
sediment. If you
discover any
damage to the unit,
discontinue use
and contact the
proper authority.
c
Install the test
batteries and
ensure each
battery ts as
intended and that
the battery cover
ts over the
batteries as
intended.
d
Page 8

If you experience any functionality issues or have questions that are not answered by this manual, please contact MIRA Safety
Customer Service (contact information on the back page of this manual).
If needed, the equipment may be wiped down with a clean, dry cloth to remove exterior dust.
Clean your facepiece according to the manufacturer’s directions. Decontaminate and
clean the exterior of the blower assembly as follows:
Warning
THOROUGHLY CLEAN AND
DECONTAMINATE THE FACEPIECE,
BREATHING TUBE, WAIST BELT, AND
BLOWER ASSEMBLY AFTER EACH
USE. FAILURE TO CLEAN AND
DECONTAMINATE THE EQUIPMENT
MAY EXPOSE THE USER TO
SUBSTANCES THAT CAN CAUSE
SERIOUS INJURY OR DEATH.
Caution
CERTAIN CLEANING AND
DISINFECTING AGENTS SUCH AS
QUATERNARY AMMONIUM
COMPOUNDS (AMMONIUM
CHLORIDES) MAY CAUSE DAMAGE,
DETERIORATION, OR ACCELERATED
AGING OF THE RESPIRATOR. USE
ONLY THE RECOMMENDED
CLEANING AND DISINFECTING
AGENTS.
After any required decontamination, respirators must be cleaned, disinfected, and
inspected after each use. After cleaning and inspection, the respirator must be stored in
a clean, dry area and reinspected before the next use. Refer to the manufacturer’s
Safety Data Sheet (SDS) for any cleaning or disinfecting/sanitizing preparations used.
Used lter elements must be removed and disposed of as directed in the DISPOSAL OF
USED FILTER ELEMENTS section of this manual.
CLEANING AND STORAGE
Warning
INSPECT THE FACEPIECE,
BREATHING TUBE, WAIST BELT, AND
BLOWER ASSEMBLY AFTER EACH
USE. FAILURE TO INSPECT THE
EQUIPMENT TO ENSURE PROPER
FUNCTIONING MAY RESULT IN A
MALFUNCTION AND POTENTIALLY
EXPOSE THE USER TO SUBSTANCES
THAT CAN CAUSE SERIOUS INJURY
OR DEATH.
Inspect the equipment for worn or aging rubber parts, worn or frayed harness
webbing, or damaged components.
1
Disconnect the breathing tube from the facepiece and the blower assembly.
2
DO NOT USE AN AUTOCLAVE TO DISINFECT/SANITIZE ANY OF THE COMPONENTS IN THIS
RESPIRATOR
Note
IF THE RESPIRATOR IS (OR IS SUSPECTED OF BEING) CONTAMINATED BY A HAZARDOUS
SUBSTANCE, THE CONTAMINANT MUST BE IDENTIFIED AND PROPERLY REMOVED, OR THE
CONTAMINATED COMPONENT(S) MUST BE REPLACED BEFORE NEXT USE. DISPOSE OF ANY
CONTAMINATED COMPONENT(S) IN ACCORDANCE WITH APPLICABLE REGULATIONS.
IF THE RESPIRATOR IS (OR IS SUSPECTED OF BEING) EXPOSED TO CBRN CLASS HAZARDOUS
SUBSTANCES, HANDLE AND/OR DISPOSE OF THE UNIT IN ACCORDANCE WITH THE
REQUIREMENTS OF YOUR CBRN RESPIRATORY PROTECTION PROGRAM.
Note
PRIOR TO HANDLING OR USING ANY CLEANING AGENTS MENTIONED, CONSULT THE
MANUFACTURER’S MATERIAL SAFETY DATA SHEET (SDS) FOR PRECAUTIONS AND IMPORTANT
INSTRUCTIONS.
Note
Page 9

After cleaning, the MIRA Safety MB-90 PAPR must be stored in a manner that
Protects the components from dirt or
debris entering the breathing path
Warning
AFTER DECONTAMINATION,
DISPOSE OF FILTER ELEMENTS IN
ACCORDANCE WITH FEDERAL,
STATE, AND LOCAL
ENVIRONMENTAL REGULATIONS.
DO NOT THROW AWAY DAMAGED
OR UNUSABLE FILTER ELEMENTS AS
ORDINARY WASTE. IMPROPER
DISPOSAL OF CONTAMINATED
FILTER ELEMENTS MAY RESULT IN
EXPOSURE TO CONTAMINANTS
WHICH MAY CAUSE SERIOUS
INJURY OR DEATH.
Filter elements must be removed and disposed of properly to avoid exposure to
contaminants.
DISPOSAL OF USED FILTER
ELEMENTS
Perform regular operational inspections as detailed in this manual.
5
Carefully wash the blower assembly with a warm water solution containing a mild detergent. DO NOT IMMERSE
THE BLOWER ASSEMBLY. A soft cloth may be used for scrubbing extremely dirty areas. Clean the breathing tube
connection and lter element mounts to remove any dirt that could prevent an airtight seal. Rinse thoroughly with
clean water.
3
DO NOT STORE BATTERIES IN THE BLOWER UNIT. Store AA batteries separately according to the manufacturer’s
guidance.
1
Store the MIRA Safety MB-90 PAPR blower, belt, and accessories with this instruction booklet in a suitable
protective container, such as its original packaging, that will protect the components from impacts, dirt, and
distortion. The breathing tube may be stored with the blower.
2
Handle the lter elements as potentially contaminated objects.
1
Dispose of the lter elements in accordance with federal, state, and local
environmental regulations for hazardous waste.
2
Carefully wash the inside and outside of the breathing tube assembly in a warm water solution containing a mild
detergent. Clean the breathing tube connections to remove any dirt that could prevent an airtight seal. Rinse
thoroughly with clean water.
4
IF ACCIDENTAL IMMERSION OCCURS, ALLOW THE BLOWER ASSEMBLY TO AIR DRY AND THEN TEST TO CHECK WHETHER THE MOTOR WAS
DAMAGED.
Note
DO NOT STORE THE MIRA SAFETY MB-90 PAPR WITH FILTER ELEMENTS OR BATTERIES INSTALLED
Note
Protects the components from impact
damage Protects the components from distortion.
Page 10

Do not throw away used lter elements as ordinary waste.
Dispose of AA batteries according to your state and local environmental regulations.
DISPOSAL OF USED BATTERIES
SERVICE AND REPLACEMENT PARTS
ONE-YEAR LIMITED WARRANTY
The MIRA Safety MB-90 PAPR has no user-serviceable parts. For lters or a replacement breathing tube, contact MIRA
Safety Customer Support by calling 1462-316-888 or e-mailing [e-mail].
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1) YEAR from
the date of retail purchase by the original end-user purchaser (“Warranty Period”).
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be replaced or
repaired in the following ways: (1) Return the product to the manufacturer for repair or replacement at the manufacturer’s
option. Proof of purchase may be required. (2) Return the product to the retailer where the product was purchased for an
exchange (provided that the store is a participating retailer). Returns to a retailer should be made within the period of the
retailer’s return policy for exchanges only (usually 30 to 90 days after sale). Proof of purchase may be required. Please
check with the retailer for their return policy regarding returns beyond the time set for exchanges.
This warranty does not apply to accessories, attachments, or optional upgrades; defects resulting from normal wear and
tear; accidents; damage during shipping; alterations; unauthorized use or repair; neglect, misuse, or abuse; or the failure to
follow the instructions for proper care and maintenance of the product.
This warranty gives the original retail purchaser specic legal rights, and you may have other rights that vary from state to
state or province to province. This product is not intended for commercial use.
Please direct all warranty claims to MIRA Safety Customer Service at:
Page 11
888-316-1462 [e-mail]

MIRA Safety LLC
7301 N FM 620 RD, STE 259# 155
Austin, TX 78726
© 2021 MIRA Safety LLC
MIRA Safety, the MIRA Safety logo, and MB-90 are registered and/or unregistered marks of MIRA Safety LLC, or its
aliates.
888-316-1462
[e-mail]
