Zepter AqueenaPro WT-100 User manual

WT-100
INSTRUCTION MANUAL
AR
UK
SR
RU
PL
HU
IT
FR
ES
DE
EN

1
EN
Instruction Manual pag. 02
DE
Bedienungsanleitung Seite 27
ES
Manual de Instrucciones Página 52
FR
Manuel d’utilisation page 77
IT
Manuale d’Uso pagina 102
HU
Használati útmutató 127. oldal
PL
Instrukcja obsługi strona 152
RU
Инструкция по эксплуатации стр. 177
SR
Uputstvo za upotrebu str. 202
UK
Інструкція з експлуатації стр. 227
AR

EN
2
INTRODUCTION
AQUEENAPRO: WATER PURIFIER
Thank you for choosing ZEPTER AqueenaPro water purifying system and your trust in Zepter
International. Your AqueenaPro will reliably provide clean, healthy and great-tasting water for you
and your family. Place Zepter AqueenaPro in your home and enjoy an endless source of pure spring
water, every day. Zepter International is a global specialist in health and lifestyle.
This guideline will help you get the best out of your water filtration system. Please go through this user
instruction manual to familiarise with its operation and maintenance.
To make sure the warranty is effective, follow all instructions provided in this user manual. For further
information or support, please contact your Zepter sales representative*.
For any questions regarding AqueenaPro installation, maintenance or filter replacement, please
contact your service technician/Zepter Service Centre*.
*All contact details can be found in the Warranty card.

EN
3
INTRODUCTION 02
CONTENT 03
SAFETY INFORMATION 04
AQUEENAPRO TECHNOLOGY 10
AQUEENAPRO FEATURES 10
AQUEENAPRO OVERVIEW 11
ITEMS IN THE BOX 12
AQUEENAPRO INSTALLATION 12
– Installation Instructions 13
OPERATING INSTRUCTION 13
– Before first use 13
– RO Membrane Installation 14
– Display functions 15
MAINTENANCE AND FILTER REPLACEMENT METHOD 16
– Flushing the RO Membrane 16
– Filter Replacement Method 16
– Filters replacement procedure 16
– Restoring leakage sensor 17
– After filter replacement 18
– The RO replacement procedure 19
– Filter Replacement Time 19
– RO membrane replacement time 20
TECHNICAL INFORMATION 21
OPERATING INFORMATION 21
TROUBLESHOOTING GUIDELINE 22
DISPOSAL INFORMATION 23
WARRANTY CARD 24
WARRANTY STATEMENT 25
AQUEENAPRO PERFORMANCE DATA SHEET 26
CONTENTS

EN
4
SAFETY INFORMATION
The manual uses specifications to draw your attention
to some details
Warning! Failure to observe a warning may result
in severe physical injury or property damage
Caution! For safety reasons, be careful! Failure to
observe a caution sign may result in minor physical
injury or property damage
Note! It contains additional information and useful
advice for the proper use of the water filtration unit.
Caution!
• This user manual is an integral part of the
appliance. Read all the instructions and safety
precautions contained in this manual carefully,
as they provide important information on
the use and maintenance of the device.
Keep the manual for future reference.
• After removing the packaging, make sure that
the water filtration unit is intact, carefully
inspect the device body and the accessory box.
• This appliance should only be used for its
intended purpose. The manufacturer shall
not be held liable for any damages caused
by improper, incorrect or unreasonable use.

EN
5
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they are
supervised or have been instructed on the
use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that
they do not to play with the appliance.
• At the end of its lifetime, the appliance should
be disposed of separately from ordinary
waste, leaving it with operators who are
qualified to collect this kind of material.
In this way it will be properly disposed of and
recycled, helping to safeguard the environment!
Note!
1. AqueenaPro is a water filtration system for
household use. Any use outside your home
and for purposes other than purifying water for
household use will automatically void your
warranty.
2. The AqueenaPro should not be used on feed
water that is microbiologically unsafe or has
unknown microbiological quality without
disinfecting the water before using the device.

EN
6
3. Cold water plumbing – AqueenaPro must
be connected to a cold water pipe. Using
hot water (>38°C) as a water source will cause
permanent damage to the RO membrane and
severely degrade the performance of the product.
Warning!
Important safety information:
Warning for the European market:
This appliance can be used by children aged over
8 years and persons with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge if they are supervised or have been
instructed on the safe use of the appliance and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be carried out by children
without supervision
Warning for Non-European markets:
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they are supervised or have been
instructed on the use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance. The new hose-sets
supplied with the appliance are to be used and old
hose-sets should not be reused.

EN
7
• Do not disassemble
or modify AqueenaPro
on your own!
Never attempt to repair or change
any internal part of AqueenaPro,
as it may compromise the efficiency
and safe operation of your water
purifier. Any unauthorised change
will automatically void the warranty.
If you find that a repair is needed,
please contact your Zepter service
technician for support.
• Do not use AqueenaPro
under high water pressure!
Operating under high pressure
conditions may result in rupture of the
waterpurifierpipesandaconsequent
water leakage. Recommended inlet
pressure is 0.1MPa to 0.35MPa.
(14.5 - 50.8 psi).
• Do not use AqueenaPro
near gas, naked flames,
explosive or highly
flammable materials.
Do not leave the water purifier near
fireplaces or other high temperature
heat sources (stove, oven), as it can
result in deformation or melting of
the housing.

EN
8
• AqueenaPro
is a free-standing unit.
Do not place or keep anything on
top of the unit.
• Before connecting the unit
to the mains, make sure the
information found on the data plate
matches that of your electricity
mains.
• Do not use the appliance if
the power cord or plug are
damaged.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order
to avoid a hazard. The appliance
is only to be used with the power
supply unit provided with the water
dispenser.
• Do not touch the power
plug with wet hands!
It may lead to electric shock.

EN
9
Caution!
• Do not use any chemicals
when cleaning the outside
casing of AqueenaPro.
Alcohol, petrol, organic and
inorganic acids and strong basic
chemicals like concentrated
dishwashing detergents will
irreparably damage the plastic
housing of your AqueenaPro.
• Do not use your
AqueenaPro outdoors!
Using AqueenaPro outdoors can
accelerate the corrosion of pipes
and parts, which can result in
leaks or damage to the device.

EN
10
AQUEENAPRO TECHNOLOGY
AQUEENAPRO FEATURES
AqueenaPro is a low-noise 5-stage filtration system which uses the most advanced international RO
(reverse osmosis) technology currently available.
The heart of the AqueenaPro water filtration system is a RO membrane with 0.0001-micron small
pores designed to remove even dissolved impurities (heavy metals), pesticide residues as well as
harmful micro organisms (bacteria and viruses). AqueenaPro significantly reduces bacteria and
infectious viruses.
•Built-in water tank, theoretical volume 2.5 Gallon (9.5 l).
•Computer control box, which automatically adjusts AqueenaPro’s working status.
•Filter change alarm, which indicates when the filter needs to be replaced.
•RO membrane integrated with the membrane housing to prevent tampering.
•Leakage sensor, to detect device leakage; it secures the user`s property
and avoids damages caused by leaks.
•High pressure pump, which creates a stable environment for the RO membrane.
•Flushing solenoid valve, to flush the RO membrane automatically and control waste water flow.
•Inlet solenoid valve, which by definition opens or shuts inlet water pressure in a range
between 0.03 and 0.6MPa (4.35 – 87 psi).
•Checking flow valve, to prevent water backflow.
•Safe feature, pressure switch.
Low pressure switch
Inlet water
5μm PP filter
1μm PP filter
Pump
Reverse osmosis
Coconut filter
Tank valve
Tank
Pure water Faucet
Flow
Waste water
Flushing solenoid valve
Inlet
solenoid valve
Pellet
carbon
filter
High pressure switch

17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
EN
11
AQUEENAPRO OVERVIEW
1. Upper cover
2. 5 micron PP Filter
3. Inlet Solenoid Valve
4. Pellet Carbon Filter
5. Computer control box
6. Low Pressure Switch
7. Pump
8. Bracket for inlet/outlet water
9. Lower cover
10. Leakage sensor
11. 2.5G water tank
12. Display
13. High pressure switch
14. Flushing Solenoid Valve
15. Reverse Osmosis
16. 1 micron PP Filter
17. Coconut Filter

EN
12
ITEMS IN THE BOX
1. AqueenaPro water filtration system 1 piece
2. RO membrane in protective film 1 piece
3. Power supply adaptor 1 piece
4. User manual 1 piece
5. Drinking water faucet 1 piece
6. Tube 5 m
7. Drainage clamp 1 piece
8. Wrench for membrane housing 1 piece
9. Accessory bag 1 piece
a) Inline feed water connector 1 piece
b) Clip for quick connectors 2 pieces
c) Faucet fixture 1 piece
AQUEENAPRO INSTALLATION
Installation, servicing, maintenance and repairs should only be performed by
Zepter authorised staff.
All maintenance should be performed using original Zepter replacement cartridges and spare parts.
Warning!
•Avoid exposure to direct sunlight and installation in damp areas
It may create a breeding ground for microorganisms resulting in reduced purified
water quality, as the internal components of the water purifier can be polluted
•Inlet water cannot exceed 38°!
Using a hot water source (>38°C) will cause permanent damages to the RO
membrane and severely degrade the performance of the product.
Make sure that AqueenaPro is connected to a cold water supply only.
• The maximum distance between the water source and the
purifier should not be more than 3 m.
• Avoid sharp bends in the pipe. Do not bend or block the
reject water tube.
• Do not confine your AqueenaPro in a tight cabinet.
• Do not use the AqueenaPro when the drain is clogged up.
•Do not use AqueenaPro at temperatures below 5°!
If the room temperature is below 5°, it can result in pipes cracking due to water
freezing inside the machine.

EN
13
Note!
Aqueena Pro water purifier has been designed to be installed under the sink. The initial installation
requires carpentry and plumbing works.
Installation, servicing, maintenance and repairs should only be performed by
Zepter authorised staff .
Recommended side preparation
• Mains connection no more than 1.5 m from the point of installation of AqueenaPro
• Water supply no more than 3 m away
• Drain for rejected water no more than 3 m away
• Space as per the size of AqueenaPro
• It is preferable to install AqueenaPro near a sink so that inlet and reject water
lines are easily available.
Important notes!
1. If you are not using your AqueenaPro for more than two days (48 hrs),
switch off the device and drain the storage tank.
2. To keep the storage tank clean, it should be drained once every 2 days.
3. The buzzer will sound to indicate a fault in the purifier. If you hear an audible alarm, take action as
reported in the “Display function” section and/or the “Troubleshooting guideline” or call a
service technician for support.
4. Do not try to service the AqueenaPro on your own. Call a service technician/Zepter Service centre
for help.
Installation Instruction
OPERATING INSTRUCTIONS
Before first use
1. Install the RO membrane according to the section RO Membrane Installation
2. Make sure that all connections are secure.
3. Connect the water purifier to the mains. Make sure the power connector plug
can plug into the local power socket.
4. Bypass the water tank, close the water tank valve.
5. Open water inlet valve and water faucet
6. Switch on your AqueenaPro. As a start up audio signal will be activated 1 buzz.
7. Let water run through the system for approx. 5-10 min (system stabilisation)
and check all connections.
Caution! If you find any leaks, do not proceed further until the leaks are fixed.
8. Turn off the water faucet and check if the flow of waste water stops
(approx. after 30 s).
9. If no deviation or leak is found, open the water tank valve and let the system fill with water.
10. Drain the first two water tanks before use.

EN
14
Note! The first two tanks can contain black residues.
These are carbon particles washing away from the carbon filter and
will not affect future system performance nor the quality of purified water.
11. Measure TDS level and record it on your Product Warranty Card.
RO Membrane Installation
Note!
• The AqueenaPro water purifier is delivered with the RO membrane uninstalled
and packed separately with protective film.
• In order to prevent microbial contamination of membrane components during storage
and transportation, the RO membrane package contains a small amount of protective solution.
1. Remove the AqueenaPro top cover.
2. Unscrew the cap’s nut from the membrane housing and remove inlet water pipe.
3. Disassemble membrane cap with the enclosed wrench.
4. Remove RO membrane from its protective film.
5. Insert RO membrane into membrane housing. The membrane end with O-ring must be placed
on the bottom of the housing. (see picture below)
6. Close the membrane casing with the cap. Use the wrench to tighten the cap properly.
7. Connect the inlet water pipe and secure it with the cap’s nut.
8. Place the RO membrane cartridge in the correct position.
9. Check all connections and make sure that there are no leaks.
10. Close the AqueenaPro top cover.
O-rings
cartridge
membrane cap

EN
15
Warning!
Pay attention to the direction of the membrane; the membrane ending with an O-ring must be placed
in the bottom part of the housing.
• Do not force the RO membrane into the membrane casing; it may cause permanent damage
to the membrane shell or membrane components.
• If the RO membrane is installed correctly in the membrane housing, there is no need to force it.
Note! If any leaks occur, all icons (“Working”, “ Water source”, “Standby” and “Flush” icons) will
flash at same time along with an audible alarm.
Filter Status Display: It shows the actual filter status.
Green light – the filter works at its optimum level.
Orange light - the filter will soon need replacing. Please contact Zepter Service for maintenance
support.
A red light along with an audible alarm (4 buzzes) means that the filter must be changed immediately.
Further use of the filter is not recommended.
5 – micron PP filter WT-100-72
Pellet carbon filter WT-100-73
1 – micron PP filter WT-100-74
Coconut filter WT-100-75
Display functions
5
3
2
1
12
53
If a display icon lights up:
Working: Water purification is in the progress, the device is in working mode.
Water
Source: Flashing light - missing inlet water source or low inlet water pressure.
The “Water source” icon will light up with an audible alarm (7 buzzes).
Standby: The water purifier is in standby mode.
Flush: The flushing function is activated.

EN
16
Flushing the RO Membrane
The RO membrane is automatically flushed for 18 seconds when the device is turned on.
When the water tank is full, the RO membrane is automatically flushed for 10 seconds.
Filter Replacement Method
Note! Filters and membranes are consumables. Their replacement time
depends on the quality of raw water and water consumption.
They are not covered by the warranty.
Filter Replacement procedure
1. Turn off the power supply.
2. Close the inlet water valve.
3. Remove the top cover.
4. Unplug the “old” filter – disconnect filter from quick connectors (memorise filter orientation).
5. Replace the filter – Pay attention to correct water flow direction!
6. Check all connections and make sure there are no water leaks.
7. Close the top cover.
8. Open the inlet water valve and turn on the power supply.
MAINTENANCE AND FILTER REPLACEMENT METHOD
FLOW

EN
17
Restoring Leakage sensor:
1. Turn off the power supply
2. Close the inlet water valve
3. Remove the top cover
4. Repair the leakage
5. Drain the water out of the housing by removing the rubber cap at the bottom of the housing.
6. Dry the sensor
Warning!
When installing a new filter, pay special attention to water flow direction – the arrow on the filter label
shows the correct water flow direction.
The filter cannot be installed upside down.

EN
18
After filter replacement
“Select” button: After the filters are replaced, press the “Select” button to select the
corresponding filter icon. Icon will start to blink.
“Reset” button: Select the corresponding filter and press the “Reset” button, hold for more than 3
seconds until the function is effective. After resetting, the red light will turn green.
