Contents

Air Set Power Cord x1
Package Contents
ZEROTIME Air Set (ZT3024A) x1
(306/%
Ground Set Power Cord x1
Ground Set Antenna x2
Ground Set Antenna Extension x2
Air Set Antenna x2
UART Connector x1
UART Connector x1
Backup Power Cord x2
ZEROTIME Ground Set (ZT3024G) x1
"*3


ZEROTIME is an HD image transmission device. It contains an Air Set and a Ground Set, both of which are
compact and work smoothly with low signal transmission delay and high sending and receiving
sensitivities. ZEROTIME uses wireless links to transfer collected videos and images, flight control signals
and commands emitted from the Ground Set. ZEROTIME features a 2.4 GHz working frequency, low signal
delays (within 45ms), and long ranges of transmission (up to 2 km), and the device supports 1080P HD
video transmission.
Product Overview
Air Set
Ground Set
MINI-HDMI IN POWERἷ8-12VἸ
UART
RST
LINK
C-LED
V-LED
A1’
A1 A2
A2’
"*3
(306/%
MINI-HDMI OUT POWERἷ8-12VἸ
UART
RST
LINK
C-LED
V-LED
UPGRADE
UPGRADE
A1’
A1 A2
A2’
Ground Set Antenna
Port (Backup)
Ground Set Antenna Ports
Ground Set Antenna Port
(Backup)

Power Port
Firmware Upgrade Port
Link Button
Reset Button
Video Indicator
Control Indicator
HDMI Signal In Port
UART Port
Air Set Antenna Port
(Backup)
Air Set Antenna Ports
Air Set Antenna Port
(Backup)
Firmware Upgrade Port
Power Port
HDMI Signal Out Port
Link Button
Reset Button
Video Indicator
Control Indicator
UART Port

Labels, Buttons and Ports
Air Set
HDMI Signal In Port Connect this port to the HDMI signal out port on a
camera.
The Air Set carries the label "AIR".
Ground Set
AIR
MINI-HDMI IN
Power Port Connect to 8V-12V DC power.
POWER
UART Port
UART
Firmware Upgrade Port Connect this port to a smart phone or a
computer for firmware upgrade.
UPGRADE
Reset Button Reset the device to facotry default settings.
RST
Link Button Push to link the Air Set to the Ground Set.
LINK
Control Indicator Indicates the connecting status of the Air and the
Ground Sets.
C-LED
Video Indicator Indicates the status of video transmission.
V-LED
Air Set Antenna Ports A1 and A2 are default antenna ports.
A1' and A2' are backup antenna ports.
A1A2 / A1ἶA2ἶ
HDMI Signal Out Port Connect this port to an HDMI display.
The Ground Set carries the label "GROUND".
GROUND
MINI-HDMI OUT
Power Port Connect to 8V-12V DC power.
POWER
UART Port
UART
Firmware Upgrade Port Connect this port to a smart phone or a
computer for firmware upgrade.
UPGRADE
Reset Button Reset the device to facotry default settings.
RST
Link Button Push to link the Ground Set to the Air Set.
LINK
Control Indicator Indicates the connecting status of the Air and the
Ground Sets.
C-LED
Video Indicator Indicates the status of video transmission.
V-LED
Ground Set Antenna Ports A1 and A2 are default antenna ports. A1'
and A2' are backup antenna ports.
A1A2 / A1ἶA2ἶ


Cords, Cables and Connectors
For the Air Set
Ground Set Power Cord
Connect one end to the Ground Set Adapter.
Plug the other end into the Power Port of the
Ground Set.
Ground Set Antenna
Attach this to a Ground Set Antenna Extension.
Ground Set Antenna Extension
Connect one end to a Ground Set Antenna and plug
the other end into a Ground Set Antenna Port.
Air Set Antenna
Plug into the Air Set Antenna Ports A1 and A2
(default ports), or A1' and A2' (backup ports).
Air Set Power Cord
Plug one end into the Power Port on a ZEROTIME
Air Set and plug the other end into a DC power
outlet.
For the Ground Set
UART Connector
Insert Łof the split end into the COM port on the
flight controller and insert the other end into the
UART port of the Air Set.
UART Connector
Insert Łof the split end into the COM port on the
flight controller and insert the other end into the
UART port of the Ground Set.
Backup Power Cord
Connect one end to a power source and the other
end to an Air or Ground Set Power Port. Use
compatible adapters when necessary.

ŀ
Ł
ł
ŀ
Ł
ł

Installation Guide
Air Set Installation喍with UART port for flight controller喎
Connect the MINI-HDMI Signal In Port on the Air Set to the HDMI port of a camera.
Plug the Air Set Anetennas into the Air Set Antenna Ports A1 and A2.
Connect the UART port on the Air Set to a flight controller using a UART Connector.
Connect the Air Set to a power source.
ŀ
Ł
ł
Ń
Set the camera's outgoing signal to HDMI format and make sure its resolution matches that of the Air Set. The Air Set's
default resolution is 720P60, which can be changed using the ZEROTIME Mobile App.
Use only the antennas designed for this device and install them carefully.
To protect the circuit and hardware, install antennas before connecting the device to power.
Use power source between 8V-12V. The manufacturer recommended power is 12V DC.
After connecting to power, check the fan of the Air Set. If the fan is not spinning properly, unplug the Power Cord and check
the installation.
dž
dž
dž
dž
dž
喆
ZEROTIME-ZT3024A
AIR
MINI-HDMI IN
UARTPOWER
A1
A2
Flight Controller
COM
Camera
HDMI
Power Source
Air Set Antennas


Ground Set Installation (with UART port for remote control)
Connect the MINI-HDMI Signal Out Port on the Ground Set to a display device.
Attach the Ground Set Anetennas to the Ground Set Antenna Extentions and then push the
Entension Cords firmly into the Ground Set Antenna Ports A1 and A2.
Connect the UART Port on the Ground Set to a remote control using the UART Connector.
Connect the Ground Set to a power source using the Power Cord and the Adapter.
ŀ
Ł
Use only the antennas designed for this device and install them carefully.
To protect the circuit and hardware, install antennas before connecting the device to power.
Use power source between 8V-12V.
After connecting to power, check the fan of the Ground Set. If the fan is not spinning properly, unplug the Power Cord and
check the installation.
dž
dž
dž
dž
喆
ZEROTIME-ZT3024G
GROUND
MINI-HDMI OUT
UARTPOWER
A1
A2
Remote Control
UART
Display Device
HDMI
Power Source
Ground Set Antenna
Extensions
Ground Set
Antenna
Ground Set
Antenna

ł
Ń

Setup and Calibration
Linking
Keep the distance between the Air Set and the Ground Set between 1 and 2 meters. Connect both
Sets to power.
Press the Link Buttons on the Air and the Ground Sets for 3 seconds until the C-LED indicators
turn flashing green. Linking begins.
Linking is successul if the C-LED indicators on the Air and Ground Sets turn green.
ŀ
喆The Ground Set is linked to the Air set by default. Linking is required when a new Ground Set is used.
After linking an Air Set to a new Ground Set, the Air Set's previous linking to another Ground Set is automatically abolished.
Ł
ł
Signal lights
Green Flashing Green Red Flashing Red
ŀC-LED Indicator
V-LED IndicatorŁ
Pattern Status Operation
Pattern Status Operation
Linking.
The Link Button has been pressed. The Air Set is
in the process of linking to the Ground Set.
Communicating Wait for the linked Sets to communicate.
Linked. No futher operation is needed.
Initializing. Wait for the device to finish initializing.
Functioning normally. 
Corresponding indicators on the Air Set and on the Ground Set specify the same status.
喆
LINK
C-LED
Link Button
Control Indicator
Linking
Linked


ZEROTIME Mobile App
Install ZEROTIME App on a mobile device and connect the device to the Ground Set with an OTG
Cable.
Turn on power for both the Ground and the Air Sets.
The Air and the Ground Sets are communicating normally when the C-LED indicators on them turn
green.
Wait until the USB Calibration screen appears.
Press "OK" to enter the main page. When the video transmission icon appears white, connection is
made and ZEROTIME is working properly. With functioning flight control, the Mobile App shows
realtime flying data.
ŀ
Using the Mobile App
USB Calibration Screen
Main Page

ń
Ł
ł
Ń

In the main menu, press to enter the settings page and adjust video transmission settings.
)%
$IBOOFM]4.
      





/PJTFἷE#NἸ
4FUUJOH
$IBOOFM"VUP
7JEFPSFTPMVUJPO
7JEFPUSBOTGFSSBUF
#BOEXJEUI"JS
04%
1
.CQT
.CQT

9
dž
dž
dždž
dž
dž
dždž
ZEROTIME Video Transmission Settings

Channel Selection
The current video transmission data is illustrated graphically. Signal strength in each channel is
plotted. Channel settings may be done automatically (Auto) or they may be customized (Custom).
Video Resolution
The video quality can be set to 720P30, 720P60, 1080P30, or 1080P60. The default quality is
720P60.
Auto (default): When switched to Auto, the Ground Set selects the channel with the strongest
signal and adjusts the video transmission quality as distance changes.
Custom: When switched to Custom, video transmission channel and image quality are set
manually.
dž
dž
dž
dž
Image Bit Rate
Set the bit rate to adjust video transmission quality.
Note: The value of image bit rate must be smaller than that of the chanel bandwidth.
dž
Channel Bandwidth
Set the bandwidth to adjust video transmission quality. Small bandwidth corresponds to large
transmission distance and low image quality. Large bandwidth corresponds to small transmission
distance and high image quality.
Note: The value of the chanel bandwidth must be larger than that of image bit rate.
dž
OSD Settings
Enable on-screen display for flight information including altitute, distance, battery percentage,
photo/video switch, GPS satellite data, image signal strength, flight time, vertical speed, horizontal
speed, flying mode etc..
Users can add, remove or arrange icons on the display.
dž

Firmware Upgrade
The way of upgrading the firmware of the Air Set or Ground Set is totally the same, let's take the Air
Set as an example.
Download the ZEROTIME setup package (ZEROTIME.zip) from ZEROTECH's official website
(http://www.zerotech.com).
Extract the package and save it to a USB storage.
ŀ
Step 1喟Before upgrading
ŀ
Ł
Use an OTG cable to connect the USB storage to the Firmware Upgrade Port on the Air Set. Turn
on the power for the Air Set.
The Video Transmission System automatically loads the firmware and installs the upgrade.
Upgrade is completed when the C-LED indicator is green.
Step 2喟Upgrade

Ł

Appendix
Specifications
Items
General
Maximum Transmission Distance
EIRP
Operating Frequency
Receiving Sensitivity
Frequency Setting Mode
Parameters
2 km
100mW @ 2.4GHz
2 406 -- 2476MHz
-90dBm@15Mbit/s喠-93dBm@10Mbit/s喠-96dBm@5Mbit/s
Frequency scanning, Manual frequency setting, Frequency
adjustment, Device linking
ݪ:
56mm*86mm*23mm
120g
2±0.7dBi@ 2.450GHz
650mA
8-12V
ܟ
MMCX*4
Mini-HDMI
56mm*86mm*23mm
120g
5±0.7dBi@ 2.450GHz
650mA
8-12V
ܟ
MMCX*4
Mini-HDMI
ȟ
T30ȠT36ȠT-M43ȠT-BMPCC喍BM series喎
S4-V6
EAGLEEYE MINI, T-M43 Carrier
ȟ
720P30720P601080P301080P60
ȟ
720P30720P601080P301080P60

Power
Air Set
Size
Weight
Antenna Gain
Operating Current
Operating Voltage
Operating Temperature
Antenna Connector
Video Connector
Ground Set
Size
Weight
Antenna Gain
Operating Current
Operating Voltage
Operating Temperature
Antenna Connector
Video Connector
Supported ZEROTECH Products
Gimbals
Flight Control Systems
Flying Platforms
Supported Video Input Formats
HDMI
Supported Video Output Formats
HDMI

This content is subject to change.
© 2016 ZEROTECH. All Rights Reserved.
Made in China

Visit ZERO TECH's official website for the latest version of this handbook.

FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
