Zest Lily Relax Seat User manual

Assembly Instructions
(W x D x H) 0.72m x 0.92m x 0.92m
Product Name: Lily Relax Seat
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]

Lily Relax Seat Assembly Instructions
Requires 2 person assembly.All screw holes to be pre-drilled.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit,
4mm Hex Key.
Lily Relax Seat Pack List
Item Description Quantity
A Back SupportAssembly 1
B SeatAssembly 1
C BackAssembly 1
D1/D2 Armrest/LegAssembly 2
Fixings
50mm Screws 8
Hex Bolts 6
‘T’ Nuts 6
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] option 1 or email:
[email protected]
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozi-drive Bit/Screwdriver, 3mm Drill Bit,
4mm Hex Key.
Lily Relax Seat is now complete.
1. Insert Back AssemblyA between rear legs of Seat Assembly B, align bolt holes
and insert 2no Hex Bolts and ‘T’ Nuts. See Figs. 1a, 1b & 1c.
Do not fully tighten at this stage.
2. Locate Back Assembly C as shown in Fig 2a and fix in position using 6no Screws.
See Figs 2b & 2c.
3. PositionArmrest/LegAssembly D1 as shown in Fig.3a.Align bolt holes and insert
2no Hex Bolts and ‘T’ Nuts. See Fig. 3b. Do not fully tighten.
Attach Armrest/Leg Assembly D1 to Back Support Assembly A using 1no Screw.
See Fig.3c.
Repeat procedure for Armrest/LegAssembly D2.
Fully tighten all bolts at this stage.
