Zetor Proxima Plus Series User manual

1
ZETOR
This present operation manual provides information with operation and maintenance of your new tractor the
PROXIMA PLUS.
Despite the fact that many of you have rich experience with operation of other types of tractors, please read this
manual carefully to acquaint yourself with its contents as thoroughly as possible.
In the manual, you can find a lot of information how to utilise the best your tractor with various types of work.
When following the given principles of operation and maintenance of the tractor and safety of driving, your tractor
will become your reliable partner for many years.
The manufacture of your tractor wishes you thousands hours of satisfying work.
ZETOR
Brno

2
Information on the technical data, construction, equipment, material and appearance is valid at the time of printing. The manufac-
turer reserves the right of changes.

3
CONTENTS
The operation manual includes descrip-
tion, operation and maintenance of stan-
dard accessories of the tractor. The ac-
cessory that is not installed by the manu-
facturer (manufacturing plant) as stan-
dard is not covered by the warranty. The
service cheque book for tractors is not
included in the operation manual; it is a
separate brochure that is delivered to
you with purchase of a new tractor.
Page
Location of serial numbers..........................................................................................5
Safety instructions for the user....................................................................................7
Preventive daily maintenance ...................................................................................21
Getting to know the tractor........................................................................................27
Driving.......................................................................................................................61
Running-in the tractor................................................................................................81
Transport use............................................................................................................85
Drive of farming machines.........................................................................................93
Hydraulic system.....................................................................................................101
Mechanical hydraulics.............................................................................................107
Electro-hydraulic system.........................................................................................121
Hitches....................................................................................................................139
Change of wheels tread ..........................................................................................147
Additional weights...................................................................................................153
Electric installation ..................................................................................................159
Tractor maintenance ...............................................................................................169
Maintenance instructions ........................................................................................189
Adjustments ............................................................................................................211
Essential technical parameters ...............................................................................223
Index.......................................................................................................................245

4
TRACTORS PROXIMA PLUS
TRACTORS WITH FRONT DRIVING AXLE (4 x 4):
Engine power
(kW)
Type of
the tractor EC 24 2000/25/EC
Z90 60 64,3
Z100 66 70,4
Z110 74 78,4
G1

5
LOCATION OF SERIAL NUMBERS
G2

6
LOCATION OF SERIAL NUMBERS
When ordering spare parts and with all written and oral communication use please the data of your tractor that you shall write
down to the following frames.
Type of the tractor
Zetor Proxima Plus Z90
Zetor Proxima Plus Z100
Zetor Proxima Plus Z110
Designation "to the right", "to the left", "in
the front", "in the back" is meant in direc-
tion of drive of the tractor.
During production, the manufacturer re-
serves the right to carry out changes in
the construction and equipment for the
purpose of technical progress.
Serial number of the tractor Serial number of the engine
G3

7
SAFETY INSTRUCTIONS FOR THE USERS
Pay proper attention to those sections of the operation and maintenance manual that are marked with this symbol.
You can find this symbol with all important warnings that relate to safety of operation.
Follow these warnings and behave with special attention in these cases!
Inform your colleagues and other users about these warnings.
The chapters marked with this symbol should be read thoroughly before any operating, repair or adjustment action on the
tractor.
You can find this symbol with all important warnings that relate to operation, adjustments and repairs of the starter.
Follow these warnings and behave with special attention in these cases!
This symbol appears with the parts of the operation manual that relates to protection of the environment.
∗This symbol indicates the tractor accessories mounted by the manufacturer on the customer’s request.
Instruction manual´s passages related only to models equipped with DPF (diesel particle filter) are labelled with this sym-
bol.
GENERAL SAFETY REGULATIONS
1. The tractor may only be operated by a trained worker having a valid qualification to drive the tractor and who is acquainted
thoroughly with the operational and safety principles.
2. In addition to the warnings relating to safety and given in the operational manual, it is necessary to respect all the generally ap-
plicable safety and traffic regulations of the country in which the tractor is used.
PROPER CLOTHING
3. Do not wear loose clothing and free flying long hair.
4. When executing any work, use suitable (prescribed) personal protective means (working shoes, gloves, etc.)

8
SAFETY INSTRUCTIONS FOR THE USERS
STARTING THE ENGINE
5. Starting of the engine by driving from slopes is not allowed.
6. Make the tractor moving for the purpose of starting the engine using other tractor or another vehicle is permitted only with use
of a tow bar.
7.Start the engine only from the driver’s seat with the shifting level in neutral position and clutch pedal depressed. Danger of
death when starting the engine using short-circuited terminals of the starter!
8. The key in the ignition box shall be in position "I".
9. When warming up the engine using an electric heater, first plug in the power supply cord to the heater and then to the mains
socket. When the engine is warm, first disconnect the supply cord from the mains socket.
DRIVING
10. Hoses of hydrostatic steering, brakes and fuel system shall be checked regularly and in case that some traces of damage are
observed, replace the damaged components. The traces of damage include, for example, cracks, loose pre-stressing of hose
connections (this can be verified by easy pulling out the hose from the coupling) and mechanical damages of hoses. The hoses
with specified life span shall be replaced immediately after termination of the specified period.
11. When driving with trailers and implements on roads the brake pedals shall be connected by a latch.
12. Brakes and steering shall be always in perfect condition.
13. Driving downhill without shifted any gear is forbidden!
14. Special attention shall be paid to driving a tractor on slopes, muddy, sandy, icy and uneven surfaces.
15. Observe the permitted angle of the gradient accessibility, i.e. max. 12°.
16. Respect the total permitted weight of the vehicle train, given on the type plate of the tractor or mudguard of the rear wheel.
17. When driving through road bends, do not use the differential lock.
18. Getting on and off the moving tractor is forbidden.
19. When driving a tractor with agricultural machines suspended on the front three-point suspension reduce travel speed of the
tractor to 15 km.h-1.
20. When driving a tractor with machines suspended in the rear hitch, loading of the steered axle shall not be reduced under 20%
of the immediate weight of the vehicle train. In case of travel speed reduced to 20 km/h, loading of the steered axle may be re-
duced to 19% of the immediate weight of the vehicle train (vehicle train up to 4.5t) and to 18% of the immediate weight (vehicle
train over 4.5t).

9
SAFETY INSTRUCTIONS FOR THE USERS
TRANSPORT OF VEHICLES, OPERATION
21. The tractor may transport only so many people as specified in the MOT certificate of the vehicle.
22. The persons that are not charged to work with the accessories of the tractor may not stay between the tractor and the hitched
machined (tools).
23. Before you bring the tractor in motion, check whether an unauthorised person or barrier obstructs your drive.
24. With aggregation of the tractor with machines and tools with great tractive resistance, when speed of the engine decreases
and the engine has a tendency to stop, the reduction gears 1R, 2R may not be used to work with these machines.
EXTRICATION, PULLING
25. Ung bars or ropes for extrication of a stuck tractor.
Never use chains! A risk of death in case of a chain rupture!
26. When extricating a tractor it is dangerous to stay close the towing rope.
27. A front hook is installed on the frame of the tractor; this hook can only be used for towing of the tractor itself, i.e. without trailer
or other additional equipment.
28. Then pushing other vehicles (trailers, etc.) by the tractor never use freely inserted balks or bars between the tractor and the
pushed object.
LEAVING THE TRACTOR
29. Do not park the tractor with carried tools in lifted position.
30. Before you leave the tractor, do not forget to brake the tractor using the hand brake, shift a gear and reversing lever move to
position for driving forward, remove the key from the ignition box and lock the cabin.
31. Use left side to get out of the tractor. Look around whether some vehicle does not come near to jeopardise your safety when
getting out of the vehicle.
32. When getting out of the tractor, use footboards and hold tight to the grab handles. Pay special attention close to the shifting
lever and lever of manual regulation of fuel supply.
33. When leaving the tractor with engine running apply the hand brake.

10
SAFETY INSTRUCTIONS FOR THE USERS
ONLY WITH ENGINE STOPPED
34. All works connected with refilling of fuel, cleaning, lubrication and adjustments of the tractor or suspension machines may only
be carried out with engine stopped and stopping of movable parts of the tractor, except check of function of brakes, hydraulics
and recharging of the battery.
35. Before removing the bonnet it is always necessary to stop the engine. In closed rooms the engine of the tractor may run only
if sufficient ventilation is provided. Exhaust gases are harmful for human health.
PRINCIPLES OF FIRE SAFETY
36. Carry out refilling of fuel with engine stopped.
37. In summer season do not refill fuel tank to its full capacity. Wipe immediately spilled fuel.
38. Do not refill fuel in vicinity of open flame and do not smoke.
39. When inspecting level of electrolyte in the battery, do not smoke and do not use open flame. Pay attention to consistent ob-
servation of fire safety instructions in environment of increased risk of fire (haylofts, straw stacks, etc.).
40. In case that the tractor is equipped with a fire extinguisher, have it still available.
PROTECTION OF HEALTH AND THE ENVIRONMENT
41. The tractors are not equipped with any special filters of air supplied to the cabin. Therefore the tractors are not designed for
work with aerosols and other harmful substances. Kerosene, diesel oil and other oil products that are used for operation and
treatment of the tractor may cause skin diseases with direct contact, show irritation effects to mucous membranes, eyes, diges-
tive and upper respiratory tract. Some of them may cause general poisoning when swallowed.
42.The workers that come into contact with oil products are obliged to observe safety and hygienic directives, use suitable pro-
tective means and work in well ventilated rooms.
WHEN WORKING WITH OIL PRODUCTS
43. After end of your work of before taking a food it is necessary to wash the hands thoroughly with a non-irritating washing
preparation and use a suitable protective hand cream.
44. When connecting and disconnecting quick-couplings of hydraulic circuits remove, using any textile material, excessive hy-
draulic oil remaining in the socket or plug of the quick-coupling.

11
SAFETY INSTRUCTIONS FOR THE USERS
DISPOSAL OF WASTE
45. With disposal of the tractor or its parts (including its operational fluids) after termination of their service life it is necessary to
follow the applicable laws and executing notices to the laws of the country in which the tractor is used. Based on the act on
waste, when selling the tractor, the final dealer of the tractor is liable to inform the consumer about the way of back taking of
some used parts of the tractor. These include oils and other operational fluids, batteries and tyres. Back taking of these used
products shall be carried out without any demands for any payment from the consumer for this back taking.
DAILY PREVENTIVE MAINTENANCE
46. Perform this daily or at least every 8-10 working hours of the engine.
SAFETY CABIN
47. In case that the protective frame of the cabin is damaged from corrosion, accident or otherwise, the safety cabin shall be re-
placed for a new one.
AIR-CONDITIONING
48. In any case do not dismount, change direction or otherwise manipulate with the fitting of the air-conditioning system. This
may cause a sudden escape of the cooling medium and fast local cooling. A contact of such component with skin may result in a
serious injury.
49. The air-conditioning system is equipped with quick-couplings that allow, if necessary, to separate the cab from the tractor
body without any leakage of the cooling medium. Any interventions into the air-conditioning system should be performed by a
specialised service shop.

12
SAFETY INSTRUCTIONS FOR THE USERS
ELECTRIC INSTALLATION
50. No additional modifications of electric installation of the tractor shall be carried out (such as connection of other elec-
tric appliances) due to its possible overloading!
51. Values of electric installation:
Nominal voltage 12 V =
Grounded minus ( - ) pole
Use of starting trucks or other auxiliary sources with a different voltage or polarity may cause serious damages to the tractor.
52. When manipulating with the battery pay special attention and avoid short circuits. The tractors are equipped with a battery
disconnector that shall be switched off before any manipulation with the battery.
53. The tractors cannot be operated with disconnected battery; this may cause serious damages to the tractor.

13
SAFETY INSTRUCTIONS FOR THE USERS
FH13N002
FRONT PASSENGER´S SEAT NOTIFICATION
Transportation of personnel on front passenger’s seat is allowed only with road
transportation.
- Transportation of front passenger outside the seat designed for this pur-
pose is forbidden.
- Using the seat for front passenger during the work with a tractor (e.g. during
the work on the fields) is explicitly forbidden.
- The use of safety belt on front passenger’s seat is governed by valid regu-
lations. In this respect, keep the regulations valid in the country, where the
tractor is operated.
FH13N003
PROTECTION OF CAB AGAINST
AEROSOLS
The cab of Zetor tractors in standard de-
sign is not designed for work with aero-
sols and other health hazardous sub-
stances.
The level of cab protection in standard
design complies with
EN 15695-1:2009 standard - level 2
(only dust proof cab)

14
SAFETY INSTRUCTIONS FOR THE USERS
THE LEVEL OF EXTERNAL NOISE OF TRACTOR
The exposition to the effects of high levels of noise for a longer period of time may lead to hearing disorders or deafness.
Protect your hearing with protective means, e.g. headphones, ear plugs etc.
Resulting levels of noise when measuring noise for hearing of a person near a tractor
Based on European directive 2009/63/EC – Amendment VI
TRACTORS PROXIMA PLUS
Model Proxima Plus 90 Proxima Plus 100 Proxima Plus 110
Travel speed 30 km 40 km 30 km 40 km 30 km 40 km
Tractor noise levels when travelling dB(A) 81 80.5 80.5 80.5 81.5 80.5
Tractor noise levels when standing dB(A) 79.5 82.5 80.5 81 81.5 81.5

15
SAFETY INSTRUCTIONS FOR THE USERS
THE LEVEL OF INTERNAL SOUND OF TRACTOR
The exposition to the higher sound levels for longer periods of time may lead to hearing disorders or deafness. Protect
your hearing with protective measures, e.g. headphones, ear plugs etc.
Resulting levels of noise when measuring noise for hearing of driver
Based on European directive 2009/76/EC – Amendment VI
TRACTORS PROXIMA PLUS
Model Proxima Plus 90 Proxima Plus 100 Proxima Plus 110
Travel speed 30 km 40 km 30 km 40 km 30 km 40 km
Noise levels – Closed windows dB(A) 80.5 78.5 79.5 78 80 78.5

16
SAFETY INSTRUCTIONS FOR THE USERS
THE LEVEL OF VIBRATIONS ON DRIVER´S SEAT
ZETOR tractors are classified in A category in classes I and II. “A” category includes all tractors with set level of vibrations owing
to similar specifications of construction:
Results of measurement on testing bench are listed in the following table pursuant to directive 78/764/EEC. The value a*wS is an
adjusted value of effective acceleration balanced according to vibration movement.
The following table is valid for all type series of Zetor tractors.
Class I & II
Brand of seat Model Springing a*wS (1)
(m/s²) a*wS (2) (m/s²)
GRAMMER MSG85/721 mechanical 1.18 0.8
GRAMMER MSG95A/721 pneumatic 1.16 1.1
MARS 78/764-73xx mechanical 1.25 1.23
SEARS 3008 mechanical 1.24 1.06
SEARS 3045 pneumatic 1.13 1.03
(1) Values corresponding to driver’s weight of 50 kg.
(2) Values corresponding to driver’s weight of 120 kg.

17
SAFETY INSTRUCTIONS FOR THE USERS
TRACTORS EQUIPPED WITH FRONT END LOADER
Zetor Tractors in standard design are designed for utilization in agriculture and are not designed for special purposes.
Tractors designed for operation within the European Union must be equipped, in case of using front end loader, with a protective
structure (FOPS – Falling Object Protective Structure) protecting drivers from potential falling objects.
It is necessary to observe applicable local valid regulations in countries which are not part of the European Union.
Two types of cab roofs are mounted to Zetor tractors.
1. Standard cab roof
2. Cab roof designed for tractors equipped with front end loader meeting the OECD code 10 (FOPS) conditions.
Tractors ZETOR supplied already from production with front end loader are equipped with cab roof according to point 2.
From safety reasons, series ZETOR tractors supplied without front end loader with standard roof pursuant to point 1 must not be
equipped or used with front end loader.
In case of additional front end loader assembly, it is necessary to equip tractor with cab roof pursuant to point 2.
Only front end loaders approved by ZETOR TRACTORS may be mounted to ZETOR tractor.
Additional assembly of front end loader approved by ZETOR TRACTORS can be done only by authorized ZETOR
service.
It is forbidden to use front end loaders unapproved of by ZETOR TRACTORS.
Not observing this instruction may cause serious accidents.
Carefully observe instructions for use supplied by the manufacturer of front end loader.

18
SAFETY INSTRUCTIONS FOR THE USERS
PRINCIPLES FOR OPERATING TRACTORS EQUIPPED WITH FRONT END LOADER
Carefully study operation manual supplied by the manufacturer of front end loader.
In case of discord of Principles for operating tractors equipped with front end loader and operation manual for
front end loader, which was supplied by the manufacturer of front end loader, the wording listed in operation
manual supplied by the manufacturer of front end loader shall apply.
- The use of front end loader for transporting material at places accessible to the public is forbidden.
- The use of front end loader for transporting material in places inaccessible to the public is possible only in a limited way. In
such case, instructions in user’s manual supplied by the loader manufacturer must be observed.
- Observe local valid regulations at all times.
- A strict ban on transportation and lifting of people by means of loader is in effect.
- No matter whether the front end loader is loaded or empty, no-one may stand in front of the loader if it is in lifted position. When
driving with a lifted loader, there is a risk of load transported by front end loader falling (there is a risk of disrupting the balance
of the tractor).
- Never leave the tractor standing with the loader in lifted position.
- If it is necessary to open the bonnet of the engine at intervention, disconnect the front end loader first or secure hydraulic rollers
of front end loader by metallic props designed for this purpose.
- Hydraulic circuit of the front end loader is designed in such a way to endure the maximum operation pressure of 20 MPa (200
bar). Do not do any changes on couplers of hydraulic circuit hoses.
- Any front end loader ZETOR mounting without observing the recommendation of ZETOR TRACTORS valid to the day of pur-
chase revokes the validity of guarantee for the whole of supply.
- The loader may be used, maintained and repaired only by people who perfectly know the machine and who are informed about
potential risks.
- When driving on roads do not transport any material on the front end loader.
- It is necessary to observe special instructions related to accidents prevention and general rules related to technical safety, la-
bour medicine, labour hygiene and regulation defining operation on roads.
- The manufacturer does not bear any responsibility for any potential damage incurred as a result of changes conducted on the
loader without their consent.
- Do not ever adjust the front end loader by yourselves and do not use the adjusted front end loader without prior ZETOR´s ap-
proval. The loader may become dangerous as a result of not observing these instructions. ZETOR TRACTORS shall not be
held responsible in case of any damage or injury.

19
SAFETY INSTRUCTIONS FOR THE USERS
- Use front end loader without additional weights on the tractor (danger of mutual contact). The load of front and rear drive axle
must not exceed the maximum permitted load listed in the manual. The use of front end loader requires mounting of counter
weight in the rear part of the tractor.
- Each working tool was reconstructed for the purpose of specific usage and has its own tolerance of resistance and tightness.
- It is forbidden to use front end loader for cultivating soil and stubbing. Such work needs to be done with a special tool, front end
loader is not designed for doing this.
- Using controls which would set the loader into motion without driver holding the gear shifting lever is strictly forbidden and re-
sults in installation not meeting the prescribed standard.
- To penetrate the loaded material, better use the kinetic energy of the tractor rather than pressing force which causes higher
strain of both the loader and the tractor.
- Do not overload hydraulic parts if the load is too heavy or pistons are in end positions.
- Control the loader exclusively from driver’s seat, if you are sitting on driver’s seat.
- Do not leave the seat if you have not blocked any movement of controls.
- No people can be present in the working zone of the loader.
- When working with a lifted loader, mind electric and external cables etc.
- Loader/tractor set needs to be parked on a horizontal and solid base, the arms of the lifting device must be set in the lower po-
sition. After using the front end loader, park the tractor and lower the tool to the ground.
You will find more information in user’s manual to front end loader.
Important notification:
Work always safely and with consideration.
