Zhone 6211 Original operating instructions

6211 ADSL2+ Router
Quick Installation Instructions
Document Number 6211-A2-ZZ10-20
November 2005
Installation
1Connect your ADSL line to the port labeled LINE on the rear
panel of the device.
2For routers with a phone port, optionally connect your
telephone to the port labeled PHONE.
3Connect your PC or a LAN:
— Use the supplied Ethernet cable to connect your PC
directly to the router. Connect one end of the Ethernet
cable to the port labeled LAN on the router and connect
the other end to the Ethernet port of your computer.
— Alternatively, use the supplied USB cable to connect your
PC directly to the router. Connect one end of the USB
cable to the port labeled USB on the router and connect the
other end to a free USB port on your PC. Install the USB
drivers as described in the user’s guide on the CD.
— If your LAN has more than one computer, you can attach
one end of an Ethernet cable to a hub or a switch and the
other to the LAN port of the router. Either a crossover or
straight-through Ethernet cable can be used.
4Connect the AC power adapter to the POWER connector on
the back of the device and plug the adapter into a wall outlet or
power strip.
See the user’s guide on the CD for important safety instructions and more information.
*6211-A2-ZZ10-20*
*6211-A2-ZZ10-20*
04-17510
LINE LAN POWERPHONE USB
OR
1
23
4
DEFAULT
RESET
Copyright © 2005 Zhone Technologies, Inc.
