1. Product Description
ZETA IIoT gateway, supporting LPWAN ZETA protocol, to meet the full
range of ZETA sensor device access. Ethernet or Cellular link way to
connect to the cloud platform, while supporting sensor data back through
BACnet, MODBUS and other protocols. It can be widely used in different
industrial data communication scenarios, such as: energy, transportation,
municipal, agriculture, etc.
2. Applications
ZIntelligent manufacturing, smart farms, industrial control, factory
equipment and other data collection and transmission.
3. Appearance & Interface
Figure 1: The appearance of the gateway

ZETA AP
5
4. Device Specifications
Model No. APZT-UI01/APZT-GI01/APTG-GI01
Wireless
Protocol ZETA
Frequency band 920-925
Output power 20±3 mW
Number of channels 61
Electrical
Power supply DC 5-12V
Power ≤5W
Physical
Size 137*124*30mm
Enclosure material SPCC
Ingress level IP30
Antenna External Antenna
Environmental
Operating
temperature
-20℃~+75℃
Storage
temperature
-30℃~+85℃

ZETA AP
6
5. Installation
5.1. Installation safety notice
It is forbidden to operate with electricity when installing, wiring and
dismantling the equipment.
Place the equipment in a ventilated place to ensure that the equipment
is installed in a dry environment.
Avoid placing the equipment in a high temperature or low temperature
environment.
The installation location of the equipment should be far away from
high-voltage cables to avoid electromagnetic interference during
operation.
The equipment should be far away from the environment of strong
thunderstorm and strong electric field.
Please fix the equipment firmly.
5.2. Installation environment check
The RF antenna is installed vertically, and there should be no large
metal shields such as metal pillars, large metal boxes, etc. within 1
meter around (the upper and lower metal will not affect it).
The installation location needs to consider the power supply of the
equipment. This equipment uses AC100 ~ 240V, a 2-hole power
adapter, and the power cord is 3 meters in length.
5.3. Installation tool
Before installing the equipment, prepare the following installation tools
and auxiliary materials:
Name
No.
Use Case
Screwdriver
1
For AP bracket, antenna, hoop and other screws
Wrench(#10)
1
For fixing screw nuts
Expansion screw
few
Used for equipment installation
Electric percussion
drill
1
For wall turning for the expansion screw
Tool pliers
1
Used to screw the ground wire
Strapping tape
few
For wire fixing

ZETA AP
7
5.4. Installation steps
1) Confirm the installation hole spacing: the four-corner hole can be used
for fixed installation.
2) Use the supporting expansion screws to fix the equipment on the wall
of the building.
Figure 2: Installation diagram
3) Connect the RF antenna and the 4G antenna. The GPS antenna may not
be connected when it is installed in a fixed place in the indoor
environment.
Figure 3: RF antenna installation
4) Arrange the cables and confirm that they comply with the
corresponding cable laying specifications.

ZETA AP
8
6. System Testing
6.1. Check after power-on
After power-on, observe the status of the indicator lights next to the power
interface, and note that the lower two indicator lights are enabled. The
specific functions are shown in the figure below.。
Figure 4: Schematic diagram of power indicator
6.2. Installation information record
After the indicator shows normal, the installation information can be
recorded. Including installation location, equipment code, etc., to facilitate
future maintenance and upgrades.
Photograph record of equipment installation：
1) Close view of the gateway, the following gateway ID label content is
clearly visible
Figure 5: Photograph of gateway label
2) Gateway installation panorama, all parts of the gateway can be clearly
seen

ZETA AP
9
7. Common faults and handling
Check the power supply to ensure that the gateway is powered
normally.
Check the antenna, whether the antennas are connected correctly, and
whether they are properly tightened.
Check the network cable and check if the network cable is properly
connected.
Check the status light to check whether the two status lights on the
gateway core board are normal (one is always on, and one flashes
twice in one second)
View the platform device status. In the (Management Platform -
Gateway Management) list, check whether the current device status is
"Online".
Check whether the heartbeat packet of the gateway (once per minute)
is normal.
If it still does not work, you can power it on again, start the gateway
device, and check to see if it is restored.
Contact ZiFiSense for more solutions.
