ZIMSTONE GA3 Manual

PREMIUM DISPLAY EQUIPMENT & MEDIA
GAZEBO
INSTRUCTION GUIDE

This kit includes
Toolkit
If you purchased a Tool Kit, you
will have 4 pegs, 4 ropes and a
rubber mallet.
Aluminium Frame
The Gazebo Frame is supplied fully
assembled and in a collapsed position.
Carry Bag
We recommend purchasing a
Slip/Zip Bag to transport and
store the Gazebo when not in
use.

1
3
Pull corners outwards until frame
is approximately 3 quarters expanded
2
Pause expansion at this point, drape the canopy over
the frame and attach velcro on each corner.
velcro
attachment
TOP
VIEW
90˚
FLAT SURFACE
Place the closed frame on
its base in an open area,
make sure the area is
flat/stable.

Expand the frame and lock in the 4 upper
sliding hubs at each corner. You can unlock
the sliding hub by pressing and holding
the green lever to disengage the internal
prong.
Expand the legs to one side of the tent
until the sliding hubs snap lock into the
first hole. Then lift the opposite side to
level out. You can unlock the sliding hub
by pressing and holding the green lever
to disengage the internal prong.
With the frame leveled at the first hole
of each leg, continue to move the
sliding hubs up to the 3rd hole. You
can unlock the sliding hub by pressing
and holding the green lever to
disengage the internal prong.
4
A
A
B
A
B
B
A
B
A
B

Lift the 4 side header flaps of the canopy
and Velcro attach the middle points to
the scissor frame.
The frame will have one canopy
tensioner at the center of the
underside. Carefully turn the lever
clockwise to create tension on the
canopy. This will raise the canopy
and eliminate wrinkles.
5
