Zintra BEAMS PARALLEL RAFTER User manual

PAGE 1
ZINTRA BEAMS
PARALLEL RAFTER
zintraacoustic.com

PARTS AND HARDWARE
8in MAIN BEAMS ( 96in ) - x8
FOR A TYPICAL ASSEMBLY
PAGE 2
ZINTRA BEAMS
PARALLEL RAFTER
zintraacoustic.com
8in END BEAM - x16
8in BEAM CONNECTOR - x16
BEAMS CLIP - x80

PAGE 3
ZINTRA BEAMS
PARALLEL RAFTER
zintraacoustic.com
STEP 1
ASSEMBLE INDIVIDUALS PARTS AS PER PURCHASED PACKAGE.
BEAMS ASSEMBLY
FOLD 8IN MAIN BEAM AND SECURE IT BY INSERTING BEAMS CLIPS INTO PRE-CUT RECTANGULAR HOLES.
*BEAMS CLIPS QTY FOR 8IN MAIN BEAMS - x6 *IMPORTANT: DO NOT INSERT CLIPS INTO
FIRST AND LAST HOLES OF THE MAIN BEAM
FOLD 8IN END BEAM AND SECURE IT BY INSERTING BEAMS CLIPS INTO PRE-CUT RECTANGULAR HOLES.
*BEAMS CLIPS QTY FOR 8IN END BEAM - x2 *IMPORTANT: ON OPEN END DO NOT INSERT
CLIP INTO FIRST HOLE OF THE BEAM
FOLD 8IN BEAM CONNECTOR AND SECURE IT BY INSERTING INTO PRE-CUT RECTANGULAR HOLES.

PAGE 4
ZINTRA BEAMS
PARALLEL RAFTER
zintraacoustic.com
STEP 2
8IN BEAMS CONNECTOR INSTALL
2.1 INSERT 8IN BEAMS CONNECTORS INTO
THE ENDS OF 8IN MAIN BEAMS AS SHOWN.
2.2 WITH THE HELP OF FINGER RISE THE TOP
OF 8IN MAIN BEAM FOR EASY INSERT.
2.3 INSERT THE 8IN BEAMS CONNECTOR INTO
THE CORRESPONDING PRE-CUT RECTANGULAR
HOLES IN THE 8IN MAIN BEAM.
2.4 REPEAT STEPS 2.1 - 2.3 FOR EACH 8IN BEAMS
CONNECTOR UNTIL THE ASSEMBLY AS SHOWN HAS BEEN
COMPLETED.
STEP 3
8IN END BEAMS INSTALL - FINISING INSTALL
3.1 INSERT 8IN END BEAM INTO BEAM COONECTOR
FROM THE STEP 3 ASSEMBLY AS SHOWN.
3.2 USE 2.2 AND 2.3 STEPS FOR END BEAMS INSTALL.
3.3 REPEAT STEPS 3.1 - 3.2 FOR EACH 8IN END BEAMS
UNTIL THE ASSEMBLY AS SHOWN HAS BEEN COMPLETED.
