1.1 Important Notices
Please use the Real Scan under a normal environment
1. Try to avoid the following circumstances.
Heat or direct sunlight places
Location with huge magnetic field
Unstable or vibrational places
Exposure to rain or moisture places
2. For the unauthorized person, please don't service this product ; otherwise the
damage caused by unauthorized servicing is not covered by warranty.
3. Unplug this product from AC outlet and remove batteries from IR control, when
this product is left unused for a long time.
1.2 Product Functions
With the advanced video processing technology to improve video quality.
Double scan conversion (15.75 KHz to 31.5 KHz) and 3:2 pull down technology.
Full screen, true color display.
Easy operation - With one button to switch signals coming from composite
VIDEO, S-VIDEO.
On screen display operation with IR remote controller.
2
Chapter 1 Introduction
Thanks for your purchase of Zinwell Real Scan. With Real Scan, you can turn your
existing standard video to a high quality on your display devices. The system set
up is very easy and there is no additional requirement for hardware or software.
You don't need to learn a complicated set up procedure and you can enjoy your
Real Scan with just plug and play.
Introduction

1.3 Package Contents
As you unpack the Real Scan, please make sure the following items were
included. If any of these items are missing, call your local agencies.
1. Real Scan .......................................................................................x1
2. Power supply ..................................................................................x1
3.Video cable.......................................................................................x1
4.S-video cable....................................................................................x1
5.VGA cable.........................................................................................x1
6. AAA batteries ..................................................................................x2
7. IR control.........................................................................................x1
8. User manual....................................................................................x1
1. Real Scan 2. Power supply
8. User manual
7. IR control
6. AAA batteries x2
3
Introduction
